LSO & LCO
LDO
13
LSO, LDO, & LCO
22
21
LDCO
27
29
LSO, LDO, & LCO
OPERATOR HEAD PARTS
2
3
10
9
4 5 7 8
11
18
14
MISCELLANEOUS OPERATOR PARTS
23
15
16 17
19
24
30
28
31
32
GARAGE DOOR OPERATOR REPLACEMENT PARTS LIST
LSO/LDO/LCO/HCT/HBT/HCI
ITEM # REPLACEMENT PART PART #
1
REAR LSO& LCO END COVER (WITH LABELS) HAE00041
2
MAIN LSO COVER (WITH LABELS) HAE00026
3
6
12
10
11
12
13
14
25
20
26
33
34
35
15
16
17
18
19
20
21
*22 LDCO ENCODER BOARD HAE00058
23
24
25
*26 LDCO MOTOR (WITH ENCODER) HAE00057
27
28
29
30
31
32
33
34
35
MAIN LCO COVER (WITH LABELS) HAE00042
4
FRONT LSO COVER (WITH LABELS) HAE00028
5
FRONT LCO COVER (WITH LABELS) HAE00043
6
LSO & LCO LENS COVER (FITS BOTH ENDS) 220918
7
LSO MOTOR 220919
8
LCO MOTOR 227645
9
1/3 HP LDO COVER (WITH LABELS) HAE00011
1/2 HP LDO COVER (WITH LABELS) HAE00012
LENS COVER 217645
LDO MOTOR 217881
CONTROL BOARD (LOGIC/RECEIVER/TORQUE) HAE00040
LAMP SOCKET ASSEMBLY 218014-02
1/3HP CAPACITOR (43-53 MFD) FOR LDO33 ONLY 219109
1/2HP CAPACITOR (53-64 MFD) FOR LDO50 ONLY 219110
3/4HP CAPACITOR (65 MFD) FOR LCO75 ONLY 232168
HELICAL AND WORM GEARS (WITH GREASE) HAE00047
HELICAL GEAR (WITH GREASE) HAE00048
LIMIT SWITCH ASSEMBLY HAE00004
LDCO CONTROL BOARD, BBU COMPATIBLE HAE00061
LDCO FRONT COVER (WITH LABEL) HAE00051
LDCO MAIN COVER (WITH INSULATION AND LABELS) HAE00052
LDCO LIGHT LENS 228152
DOOR ARM - STRAIGHT 227966
DOOR ARM - BENT 227967
WALL STATION HAE00001
SAFETY BEAM SENDER & RECEIVER (WITH WIRE) HAE00002
WIRE KIT (15 SETS OF WIRE AND CLIPS) HAE00044
COMPLETE HARDWARE KIT 220205-02
LDO INSTRUCTIONS AND LABELS HAE00030
LSO INSTRUCTIONS AND LABELS HAE00031
LCO INSTRUCTIONS AND LABELS HAE00045
OPERATOR RAIL PARTS
LSO/LDO/LCO
HCT/HBT/HCI
36
37
38
39
HBT BELT DRIVE RAILS
HCT and HCI CHAIN DRIVE RAILS
43
44
42
40
41
GARAGE DOOR OPERATOR REPLACEMENT PARTS LIST
ITEM # REPLACEMENT PART PART #
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
HBT DRIVE SPROCKET 220499
HBT PULLEY AND BRACKET 218954-03
HBT INNER SLIDE ASSEMBLY HAE00022
TROLLEY ASSEMBLY 218189-01
7 FOOT BELT ASSEMBLY HAE00023
8 FOOT BELT ASSEMBLY HAE00033
DRIVE SPROCKET HOLDER AND BELT CLAMP
BELT CLAMP FOR USE ON HBT BELT RAILS ONLY
HCT DRIVE SPROCKET 217436
HCI DRIVE SPROCKET 227653
HCT PULLEY AND BRACKET HAE00014
HCT TURNBUCKLE ASSEMBLY HAE00013
HCT INNER SLIDE ASSEMBLY HAE00018
CENTER SUPPORT BRACKET CSB
7 FOOT CHAIN ASSEMBLY HAE00015
8 FOOT CHAIN ASSEMBLY HAE00032
10 FOOT CHAIN ASSEMBLY HAE00017
12 FOOT CHAIN ASSEMBLY HAE00046
HAE00049
46
47
39
45
48
49
*For LDCO800 operators manufactured before 04/2011, compatible replacement
part number HAE00053 for motor with encoder and HAE00054 for encoder board.
50 51 52
42
