1x3 Component / Audio
Distribution Amplier
Model # COMP-DA-1X3
USER MANUAL
www.linearcorp.com
ASKING FOR ASSISTANCE
Technical Support:
Telephone (800) 421-1587
(760) 438-7000
Fax (760) 438-7199
Technical Support Hours:
6:30 AM - 4:30 PM PST Monday through Friday.
Email:
techsupport@linearcorp.com
Website:
www.linearcorp.com
Notice
Linear LLC reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
© 2008 Linear LLC, All Rights Reserved
TABLE OF CONTENTS
Introduction1.
Features2.
Panel Descriptions3.
Connecting and Operating the 1x3 Component / Audio Distribution Amplier 4.
(DA) and Application Diagram
Wiring Diagram5.
Specications6.
Warranty7.
INTRODUCTION
The Linear 1:3 Component With Audio Distribution Amplier is the perfect solution
for anyone who needs to send one source of high denition component video
and analog or digital audio to multiple displays at the same time. It supports all
component equipment, such as DVD players and satellite set top boxes and all
component displays. In operation, the component video source is connected to the
distribution amplier at the input. Three outputs are available to be used in part or
in full. Once the unit is connected and powered, the source is distributed to three
component high denition displays at the same time.
How It Works
Simply connect the source’s component and audio cables to the 1:3’s input. Then,
connect up to three displays to the 1:3’s outputs. Power on the unit and watch up to
full High Denition 1080p on up to three displays without any signal loss or picture
degradation. When two or more 1:3’s are connected together, you can create a
larger video distribution system.
1
Features
Connects up to three component displays at the same time to one video source•
Supports HDTV (Component, YPbPr, RGsB) and SD (Composite, YCbCr) input •
signals
Supports HDTV resolutions up to 1080p•
Both analog and digital audio outputs are active•
Includes:
(1) 1x3 Component / Audio DA
(1) 6ft Component cable
(1) 5V DC Power Supply
(1) Users Manual
FEATURES
2
PANEL DESCRIPTIONS
Analog Audio
Out 1
Analog Audio
Out 2
Component
Digital Audio
Out 1
Digital Audio
Out 2
Out 2
Analog Audio
Input
Analog Audio
Out 3
Component
Digital Audio
Input
Digital Audio
Out 4
Out 3
Component
Out 1
Component
Input
3
5V DC
Power Input
Power LED
CONNECTING AND OPERATING THE 1x3 COMPONENT / AUDIO DA
How to Connect the 1x3 Component / Audio DA to your devices
Connect the supplied Component cable from the source into the 1x3 1.
Component / Audio DA’s input port.
Connect either a SPDIF digital audio or RCA analog right and left audio cable 2.
into the 1x3 Component / Audio DA’s audio input port.
Connect the Component and audio cables from your display(s) (up to 3) into the 3.
Component and audio out slots on the 1x3 Component / Audio DA.
Plug the 5V DC power supply into the 1x3 Component / Audio DA.4.
Plug the 5V DC wall mount power supply into the wall outlet.5.
NOTE: Both analog and digital audio outputs are active on all of the outputs.
Also, Composite video can also be fed into the Component video input to split and
distribute Composite video.
Application Diagram
Multiple COMP-DA-1X3 devices can be daisy chained together to distribute a single
Component signal to 13 units maximum, for a total of 27 displays.
COMP-DA-1X3
COMP-DA-1X3
COMP-DA-1X3
X3
X9
Maximum 27 Displays
Maximum recommended distance of component cabling between each COMP-DA1X3 or display (1080p) is 50 ft. Maximum number of displays that are supported in a
large 1x3 Component / Audio DA system is 27.
4
WIRING DIAGRAM
Component cable maximum distance is 50 feet at 1080p resolution without a COMP-CAT5-EXT
5
SPECIFICATIONS
Input ........ YPbPr x1 or RGsB x1 (or RGBHV), or Composite x 1 (1 Vp-p@ 75 Ohm)
Output .......................................... YPbPr x3, or RGsB(or RGBHV), or Composite x 3
Audio input ................................................................................... Digital (SPDIF) x1 + R/L x1
Audio output ................................................................................. Digital (SPDIF) x3 + R/L x3
Analog audio input/output ............................................... Audio 2 Vrms max 47k Ohm
Bandwidth ........................................................................................... 480MHz (-3dB)
Video Range ........................................................480i, 480p, 720p, 1080i, and 1080p
Differential gain ................................................................................................. 0.05%
Differential phase ..................................................................................... 0.05 degree
Power Supply ................................................................................................... 5V DC
Dimensions ......................................................................... 5.5" W x 1.5" H x 3.65" D
Shipping Weight ................................................................................................. 3 lbs.
6
WARRANTY
Note: These products are designed to be installed and serviced by trained professional
installation companies.
Linear LLC warrants this product to be free from defects in material and workmanship. For the
term of the warranty, see the list of products below. The Warranty Expiration Date is reected by
a date code that is afxed to all of Linear’s products. This warranty extends only to wholesale
customers who buy direct from Linear or through Linear’s normal distribution channels. Linear
does not warrant this product to consumers. Consumers should inquire from their selling dealer
as to the nature of the dealer’s warranty. There are no obligations or liabilities on the part of
Linear LLC for consequential damages arising out of or in connection with use or performance
of this product or other indirect damages with respect to loss of property, revenue, or prot, or
cost of removal, installation or reinstallation. All implied warranties, including implied warranties
for merchantability and implied warranties for tness, are valid only until warranty expiration date
as labeled on the product. This Linear LLC Warranty is in lieu of all other warranties express or
implied. Some states and countries do not allow limitations or how long an implied warranty lasts
or the exclusion or limitation or incidental or consequential damages, so the above exclusions
may not apply. The Linear LLC warranty gives specic legal rights in addition to other rights,
which may exist and vary from state to state and country to country.
All products returned for warranty service require a Return Product Authorization Number (RPA#).
Contact Linear Technical Services at 1-800-421-1587 for an RPA# and other important details.
Consumers: If you have trouble locating your installing company, please contact Linear LLC at
1-800-421-1587 and we will assist you with locating a service and Installation Company.
The following warranty period applies to this set of Linear branded products.
Linear High Denition Video products — Two (2) years. There is no warranty offered on the 1.
batteries supplied with the IR remote Control.
The warranty is limited to repair or replacement of products returned, freight prepaid, to
Linear LLC. There is NO PROVISION FOR LABOR COST OR OTHER REIMBURSEMENTS
OF ANY KIND.
Failures due to product abuse, negligence, improper installation, improper use, and 1.
electrical surge including damage from lightning, water damage or other damage due to
natural disasters are not covered by the warranty.
The warranty shall also be voided by any tampering with the date code, labels or other 2.
markings on the product.
Products that are damaged in transit to Linear LLC due to improper packaging or by the 3.
carrier (shipping company) will not be covered under the warranty. If the product was
damaged or lost by the carrier, it is the sender’s responsibility to create a claim against the
carrier.
The user is responsible for all labor costs associated with removing, reinstalling and 4.
returning the product to Linear LLC.
Linear LLC, at its option, will repair or replace the defective product.5.
Replacements will be made from B-Stock. If an exact replacement is not available Linear 6.
LLC, at its option will select the nearest equivalent product. The user is responsible for
freight charges to Linear LLC.
Linear LLC will return warranted repaired or replacements by UPS Ground or an equivalent 7.
service. A customer may pay the additional costs for second day or next-day service.
7
COMP-DA-1X3
Rev A
