Linear 2GIG-GC3GAX-IC Specsheet

2GIG PRODUCT CATALOG

ALWAYS INNOVATING

GC3 CONTROL PANELS & KEYPADS

2GIG-GC3-345

• 7” Capacitive color touchscreen display

• 100 Wireless zones

• 2 Hardwired zones

• 100 User codes

• Fully self contained

• Optional easy install CellSled™ radio module

• Remotely control panel settings over cellular

• Easily updateable for new features

• User ‘bookmarks’

• USB port on top

• ‘Rooms’ feature

LANGUAGE

2GIG-GC3-345 English

• One-touch arming

• Built-in Z-Wave home control

• Weather information display

• DC power receptacle

• ETL listed to UL 1023, UL 1635, ULC-S545-02, and
ulc subject C1023

• ANSI/SIA CP-01-2010 and CSFM listed

2GIG-PAD1-345

Wireless Keypad

• Arms system in Stay or Away Mode

• Disarms system

• Fire and Panic emergency functions

• Lithium batteries

• Transmits 345 MHz

• ETL listed

PAGE 2

GC2 CONTROL PANELS & KEYPADS

2GIG-CP21-345

• Color touchscreen display

• 60 Wireless zones

• 2 Hardwire zones

• 64 User codes

• Fully self contained

• Optional cell radio module

• Optional POTS module

• Remotely control panel settings over cellular

• Two-way voice over POTS or cellular

• Easily updateable for new features

LANGUAGES

2GIG-CP21-345E English
2GIG-CP21-345S Spanish
2GIG-CP21-345C French-Canadian

2GIG-CP21-345E2

Same as

2GIG-CP21-345E

with AC2 Power Supply
[Barrel Connector]

• Built-in Z-Wave home control

• Weather information display (with cell radio)

• DC power receptacle

• Quick arm/exit

• ETL listed to UL 1023, UL
1635, UL 1610, ULC-S545-02,
and ULS subject C1023

• ANSI/SIA CP-01-2010 and
CSFM listed

2GIG-CPX1-345E

Same as 2GIG-CP21-345E without faceplate.

• Perfect for dealers to add own logo to panel
(personalization not provided by 2GIG)

• Silkscreen-ready blank faceplates (2GIG-FP6­20PK) sold separately in packages of 20

2GIG-PAD1-345

Wireless Keypad

• Arms system in Stay or Away Mode

• Disarms system

• Fire and Panic emergency functions

• Lithium batteries

• Transmits 345 MHz

• ETL listed

*CP21 without Faceplate
*Requires FP6 Faceplate to add your own brand

2GIG-TS1

Wireless Touchscreen Keypad

• Full color touch screen interface

• Same easy-to-use interface as the GC2 panel

• Add up to 4 Wireless Touchscreen Keypads to 1 system

• See and hear system status, chimes and alerts

• Requires XCVR2 to be installed in main panel

LANGUAGES

2GIG-TS1-E English
2GIG-TS1-C French
2GIG-TS1-S Spanish

PAGE 3

CONTROL PANEL & KEYPAD KITS

GC2 KITS

2GIG-GCKIT311

KIT INCLUDES:
(1) 2GIG-CP21-345E English GC2 Panel
(3) 2GIG-DW10-345 Door/Window Contact
(1) 2GIG-PIR1-345 Passive Infrared Motion Detector
(1) 2GIG-KEY2-345 Key Ring Remote

2GIG-GCKIT211S

KIT INCLUDES:
(1) 2GIG-CP21-345S Spanish GC2 Panel
(2) 2GIG-DW10-345 Door/Window Contact
(1) 2GIG-PIR1-345 Passive Infrared Motion Detector
(1) 2GIG-KEY2-345 Key Ring Remote

2GIG-GCKIT410

KIT INCLUDES:
(1) 2GIG-CP21-345E English GC2 Panel
(4) 2GIG-DW10-345 Door/Window Contact
(1) 2GIG-PIR1-345 Passive Infrared Motion Detector

KIT INCLUDES:
(1) 2GIG-CP21-345E GC2 Panel (English)
(3) 2GIG-DW10-345 Door/Window Contact
(1) 2GIG-KEY2-345 Key Ring Remote
(1) 2GIG-GB1-345 Glass Break Detector

2GIG-GCKIT30IMG

KIT INCLUDES:
(1) 2GIG-CP21-3X9E English GC2 Panel with factory-installed XCVR2
(3) 2GIG-DW10-345 Door/Window Contact
[1] 2GIG-IMAGE1 Image Sensor

2GIG-GCKIT31GB

2GIG-KIT311-GC3

KIT INCLUDES:
(1) 2GIG-GC3-345 GC3 Panel (English)
(3) 2GIG-DW10-345 Door/Window Contact
(1) 2GIG-PIR1-345 Passive Infrared Motion Detector
(1) 2GIG-KEY2-345 Key Ring Remote

GC3 KITS

PAGE 4

GC2 RADIOS & ANTENNAS

2GIG-GCCDMV-A US Only

ADC - Verizon Cell Module

• CDMA cellular telephone module

• Provides 2-way voice
communication

• Works on Verizon network

• Plugs into GC2 panel

• Compatible with Alarm.com

2GIG-GC3GA-T US & Canada Only

TELGUARD - AT&T Cell Module

• 3G (HSPA) cellular telephone module

• Provides 2-way voice
communication

• Works on AT&T network

• Plugs into GC2 panel

• Compatible with Telguard

2GIG-GC3GAX-IC US Only

iControl - AT&T Cell Module

• 3G (HSPA) cellular telephone module

• Provides 2-way voice
communication

• Works on AT&T network

• Plugs into GC2 Panel

• Compatible with iControl One

*INCLUDES ANT3X ANTENNA

NEW!

2GIG-GC3GA-A US Only

ADC - AT&T Cell Module

• 3G (HSPA) cellular telephone module

• Provides 2-way voice
communication

• Works on AT&T network

• Plugs into GC2 panel

• Compatible with Alarm.com

NEW!

2GIG-GCCDMVX-NET

Securenet - Verizon Cell Module

• CDMA cellular telephone module

• Provides 2-way voice
communication

• Works on Verizon Network

• Plugs into GC2 panel

• Compatible with Securenet

*INCLUDES ANT3X ANTENNA

2GIG-3GTLX-A-GC2

Alarm.com – Telus Cell Module for GC2
Panels Canada Only

• 3G (HSPA) cellular
telephone module

• Provides 2-way voice
communication

• Works on the Telus
network (Canada)

• Plugs into GC2 Panel

• Compatible with Alarm.com

• 2GIG-ANT3X included in the cell module box

2GIG-GC3GR-A Canada Only

ADC - Rogers Cell Module

• 3G (HSPA) cellular telephone module

• Provides 2-way voice
communication

• Works on Rogers
network

• Plugs into GC2 panel

• Compatible with
Alarm.com

2GIG-GC3GUP-U

Uplink 3G Radio for 2GIG GC2

• 3G (HSPA) Cell Radio

• Two-way voice available
as a plan selection

• External antenna

• Multiple service levels
offered with affordable
pricing with two-way
voice as an optional add-on

• Uplink services available in United States

2GIG-XCVR2-345

900 MHz Transceiver

• Enable bi-directional
communication with the
Wireless Touchscreen Keypad (2GIG-TS1),
Go!Bridge (2GIG-BRDG1-900) & IMAGE1

• Easy to install into any GC2 Panel

• Replaces existing
345 MHz receiver and provides both a
900 MHz transceiver and 345 MHz receiver

2GIG-DREC2-319

319/345 MHz Dual Receiver

• InterLogix-compatible 319MHz
wireless protocol

• Integrated into panel, no external
power supply or
translator hardware

• Easy to install into any GC2 panel

• Accepts up to 48 wireless devices using
2GIG, Honeywell, or InterLogix protocols

• External antenna provides reliable range
performance

2GIG-GC-POTS

GC2 POTS Module

• Two-way-voice capable without
a cellular radio

• Central station monitoring
without a cellular radio

• Primary or backup
communications option when
used with a cellular radio

• Full line seizure when used
with a properly connected
RJ31X jack

• Terminals for connecting lineman’s “buttset”

2GIG-ANT3X

External In-wall Cell Radio Module Antenna

• Antenna installs in control panel
or in wall behind panel

• 10-inch cable

• Plugs into the cell radio module

• Locking connector

PAGE 5

2GIG-ANT2X

External (Attic) Cell Radio Antenna

• Antenna installs in attic
above panel

• 10-foot cable

• Plugs into cell radio module

• Locking connector

GC3 RADIOS & ANTENNAS

2GIG-CDMAV-A-GC3 US Only

ADC - Verizon Cell Module

• 3G (HSPA) cellular
telephone module

• Provides 2-way voice
communication

• Works on Verizon network

• Plugs into GC3 panel

• Compatible with Alarm.com

• Built-in cell radio antenna

2GIG-ANT2X

External (Attic) Cell Radio Antenna

• Antenna installs in attic above control panel

• 10-foot cable

• Plugs into cell radio module

• Locking connector

2GIG-3GR-A-GC3 Canada Only

ADC - Rogers Cell Module

• 3G (HSPA) cellular
telephone module

• Provides 2-way voice
communication

• Works on Rogers network

• Plugs into GC3 panel

• Compatible with Alarm.com

• Built-in cell radio antenna

COMING

2GIG-XCVR3-GC3 2GIG-3GTL-A-GC3

Image Sensor Adapter

• 900MHz Transceiver

• Enables bi-directional
communication with IMAGE2

• Easy to install in any GC3 panel

SOON!

2GIG-3GA-A-GC3 US Only

ADC - AT&T Cell Module

• 3G (HSPA) cellular
telephone module

• Provides 2-way voice
communication

• Works on AT&T network

• Plugs into GC3 panel

• Compatible with Alarm.com

• Built-in cell radio antenna

Alarm.com – Telus Cell Module for GC3
Panels Canada Only

• 3G (HSPA) cellular
telephone module

• Provides 2-way voice
communication

• Works on the Telus network
(Canada)

• Plugs into GC2 Panel

• Compatible with Alarm.com

• Built-in cell radio antenna

• Easy to install in any GC3
panel

345 MHZ SENSORS

2GIG-GB1-345

Glass Break Detector

• Monitors for the sound of
breaking glass

• Two test LEDs

• Dual shatter recognition
technology

• Lithium battery

• ETL listed

2GIG-CO3-345

Wireless CO Detector

• Built in 85 dB sounder

• Hush/Test button

• Tamper Protected

• End-of-life detector

• Lithium battery

• ETL listed

2GIG-SMKT3-345 2GIG-RPTR1-345

Smoke, Heat, & Freeze Detector

• Ability to separate the 3
detection features

• Self-contained sounder

• Supervised transmitter and
status LED

• Easy installation and
programming

• ETL listed

2GIG-SDS1-345 2GIG-FF-345 /2GIG-FF-433

Smoke Detector Sensor /
Transmitter

• Installs in between wall and
existing hardwired smoke
detector

• Converts hardwired
interconnected smoke
detector systems to work with
wireless alarm panels

• Backup battery to send alarm
transmissions in the event of power failure

• Easy to see device status indicators

NEW!

Wireless Indoor Repeater

• Repeats 2GIG and 5800
Honeywell 345MHz
signals

• Lithium-Ion battery
included

• Plug & Play – plug it in
and it starts repeating

• Optional zone programming for tamper, AC
power, and low battery supervision

Coming
Soon!

FireFighter

• Detects/reports when adjacent smoke or
CO detector sounds

• 5 year battery life

• Easy to install and supported by all 2GIG
panels and Honeywell 5800 receivers

• Does not impact UL or Fire Marshall
approval of existing smoke detectors

PAGE 6

345 MHZ SENSORS (cont’d)

2GIG-DW10-345

Thin Door/Window Contact

• For narrow applications, sensor is only 3/4” wide

• Fully supervised

• Rare earth magnet

• Supports internal and
external contacts

• Can be used for 2 zones of
protection

• Lithium battery

• ETL listed

also available in 120 pc. bulk
packs: 2GIG-DW10-120PK

2GIG-KEY2-345

4-Button Key Ring Remote

• Arms system in Stay or Away
Mode

• Disarms system

• Auxiliary output and
emergency functions

• Lithium battery

• ETL listed

2GIG-DW20R-345

Recessed Door Contact

• Compact size, only 2-1/2” long

• Fully supervised

• Rare earth magnet

• Lithium battery

• ETL listed

also available in 120 pc. bulk
packs: 2GIG-DW20R-120PK

2GIG-TILT1-345

Wireless Tilt Sensor

• Sensor transmits alert when
tipped 45° off vertical

• Restore signal sent when sensor
returned to less than 45°

• Requires Firmware Version 1.14
or later for GC2 panel and 3.1 or
later for GC3

• Long life lithium battery included

• Screw, adhesive mount hardware
included

2GIG-DW40-345

Bypass Door/Window Contact

• Bypass locally with
integrated button

• Micro-sized sensor

• Logs bypass event in
System History

• Fully supervised

• Lithium battery

• ETL listed

2GIG-DBELL1-345

Wireless Doorbell

• White UV-resistant
plastic

• Surface mount

• 350 ft. range (open air)

• 11 selectable chimes

• Doorbell can illuminate

• Receive text/email
from remote services
provider if/when
doorbell engaged

• Battery or low voltage
for power

• Low battery indicator

• Battery included

• Weatherproof seal included

2GIG-PANIC1-345

Panic Button Remote

• For triggering emergency alarm

• Small and lightweight

• 5-second button lockout

• Lithium battery

• ETL listed

2GIG-F1-345

Fall Detector Pendant

• For triggering emergency alarm

• Multi-axes sensor intelligence
recognizes most falls

• 3D sensing is designed to send an
alert when a fall is detected

• IPX7 water resistant

2GIG-PIR1-345

Passive Infrared Motion Detector

• Dual element sensor with
50’ x 50’ range

• 45 lb. pet immune

• 90-degree look down

• Lithium battery

• ETL listed

2GIG-PHB1-345

Personal Help Button Pendant­Wristband

• For triggering emergency alarm

• Convertible model with option
to wear it as a pendant or on
the wrist

• IPX7 water resistant

2GIG-FT1-345

Flood and Temperature Sensor

• Detects standing
water that reaches
the sensor probe and
notifies the panel

• Sends trouble alert
to the panel when the
ambient temperature
exceeds 84 deg. F

• Sends trouble alert
to the panel when the
ambient temperature
falls below 42 deg. F

• Ships with long life lithium battery life
(typical battery life of 5 years)

• ETL listed

• Requires Firmware Version 1.14 or later for
GC2 panel and 3.1 or later for GC3

PAGE 7

PERIPHERALS

2GIG-TAKE-345

Super Switch Wireless Takeover Module

• Converts hardwired loops into as
many as 8 wireless zones

• Converts 8 zones per module
(additional modules may be added)

• Operates at 9-16 VDC, 50 mA

• Can be powered by and use
backup battery of an existing 3rd
party Control Panel

• ETL Listed

2GIG-CAM-HD100

Indoor Camera With Night
Vision

• 720p resolution HD Video

• Wireless and Ethernet network
connections

• Configurable video motion
detection

• PIR motion detection
enhancement

• Access live video and saved
clips on remote services
provider’s website or mobile device

• IR for viewing in low-light conditions

• Requires Alarm.com service plan

2GIG-TAKE-KIT1

Hardwire Conversion Kit for GC2 Panels

KIT INCLUDES:

• 2GIG-TAKE-345 — 2GIG
Super Switch Wireless
Takeover Module

• ABS Plastic Wall-Mount
Enclosure

• Power Supply Board

• Grounded Plug-in
Transformer

NOTE: Up to 2 additional Takeover Modules can be
installed in the enclosure

2GIG-IMAGE1

Image Sensor

• PIR Motion Detection

• Integrated still camera
(320x240)

• Wireless installation

• Night vision

• Notifications and
images sent to mobile
devices

• Requires Alarm.com
service plan

• Requires XCVR2

2GIG-BRDG1-900

Broadband Communication for GC2 Panels

• Provides dual path
connectivity

• Signal forwarding

• Interactive control

• OTA updates

• Requires XCVR2-345

• Compatible with
Alarm.com, SecureNet
and Uplink

COMING
SOON!

2GIG-IMAGE2

Image Sensor

• Integrated still camera
(320x240)

• Wireless installation

• Night vision

• Notifications and images
sent to mobile devices

• Requires Alarm.com
service plan

• Requires XCVR3 for use with GC3

2GIG VIDEO

Stand-Alone Video Solutions*

2GIG-CAM-100W 2GIG-NVR1-1T

Indoor HD WiFi Camera

• H.264 & MJPEG video encoding

• High resolution (1280 x 720)

• IR illuminator for night vision

• PIR motion sensor

• Built-in SD micro slot for storage

• WiFi, 802.11 b/g/n

• Two-way audio (browser only)

• 2GIG Video remote app for
Apple® iOS®(iPhone® & iPad®)
and Android® devices

• Includes: camera, external power supply, screws,
user manual, CD.

2GIG Camera Mounts

Ceiling Mount Camera Bracket, Angled

• Angled bracket for wall or ceiling mount of
2GIG dome cameras

• Multiple knock-out plugs to conceal cables

• Composition: ABS plastic, black or white color

• Can be used for interior or exterior mounting

• Designed to fit 2GIG-CAM-250P/ -250PB
cameras

• Dimensions: 50mm x 95mm x 95mm

2GIG-MNT-250P (white)
2GIG-MNT-250PB (black)

*Not supported directly by 2GIG Panel, uses stand-alone app.

2GIG-CAM-250P/PB

Outdoor Mini-Dome HD Camera

• H.264 & MJPEG video
encoding

• High resolution (1920 x 1080)

• IR illuminator for Night Vision

• Built-in SD micro slot for
storage

• Power over Ethernet (PoE)
capable

• 2GIG Video remote app for Apple®
iOS®(iPhone® & iPad®) and Android®

2GIG-CAM-250P (white)
2GIG-CAM-250PB (black)

PAGE 8

Network Video Recorder (NVR)

• Power over Ethernet (PoE) supports 4 IP
Cameras

• Plug-N-Play

• Record/playback
video from 2GIG
IP Cameras on
browser or OSD

• Quick Setup

• HDMI and VGA video outputs

• 2GIG NVR app for Apple® iOS®(iPhone® &
iPad®) and Android® devices

The camera and NVR pricing includes an app
for iOS and Android that allows you to see live
video and view recorded video.

ACCESSORIES

2GIG-AC1

Replacement Power Supply

• High efficiency switching power supply

• 120 VAC @ 60 Hz input

• 14 VDC @ 1700 mA output

• Screw terminals for wiring to the
control panel

• Includes retaining bracket for
standard and Decora style outlets

• For GC2 or GC3

2GIG-UPCBL2

Firmware Update Cable for GC2

• Quickly and easily update the GC2 or TS1
without incurring the OTA update
charges from a remote services
provider

• Connect a PC directly to a GC2
or TS1 using the Firmware
Update Cable to update them to
the latest firmware

• Includes a 4-pin adapter for early
TS1 models

2GIG-AC2-PLUG

Replacement Power Supply

• High efficiency switching
power supply

• 120 VAC @ 60 Hz input

• 14 VDC @ 1700 mA output

• 10’ cable

• Barrel connector
simplifies installation
process

• For GC2 or GC3

2GIG-UPDV

Easy Updater for GC2 Panel

• Quickly update GC2
panel or TS1 without a
computer or incurring
OTA charges

• No batteries required
(powered by the panel)

• Includes a 4-pin adapter
for early TS1 models

• Upgradeable via
micro-USB cable (not included) with PC running
Windows 7, 8 or 10

• English firmware preloaded (download other
language versions from dealer site)

2GIG-AC3-INTPLG

International Power Supply

• High efficiency
switching power supply

• 100-240 VAC @ 50/60
Hz input

• 14 VDC @ 1700 mA
output

• 10’ cable

• Barrel connector
simplifies installation
process

• 4 International blades (IEC types A, C, I,
and G)

• For GC2 or GC3

2GIG-BATT2X

Extended Battery Pack for GC2

• Optional extra capacity
battery

• Replaces standard
internal control panel
battery

• Required for UL985 fire warning
system listing

• Nickel metal hydride (NiMH) battery

2GIG-TS1-DESK

TS1 Desktop Kit

• Allows keypad to sit at two different viewing angles

• Sleek form factor

• Bumper pads to protect
furniture & prevent sliding

• Works with any TS1 keypad

2GIG-DEMOKIT 2GIG-GC3-DEMOKIT

GC2 Dealer Demo Kit

KIT INCLUDES:
(1) 2GIG-CP21-345E English GC2 Control Panel
(1) 2GIG-DBELL1-345 Wireless Doorbell
(1) 2GIG-DW10-345 Door/Window Contact
(1) 2GIG-GC-TBZ48 GoControl Thermostat

Equipment comes mounted
and ready for demos in
rugged travel/display case

GC3 Dealer Demo Kit

(1) 2GIG-GC3-345 GC3 Control Panel
(1) 2GIG-DBELL1-345 Wireless Doorbell
(1) 2GIG-DW10-345 Door/Window Contact
(1) 2GIG-GC-TBZ48 GoControl Thermostat

Equipment comes mounted
and ready for demos in
rugged travel/display case

2GIG-CP-DESK

Control Panel Desktop Kit

• Allows panel to sit at two different viewing
angles

• Sleek form factor

• Bumper pads to protect
furniture & prevent
sliding

• Works with any GC2 or
GC3 Panel

NEW!

2GIG-FP6-20PK

Blank Face Plates for GC2

• Blank, silkscreen-ready face plate

• Adhesive backing

• Pack of 20 faceplates

PAGE 9

GOCONTROL AUTOMATION - ELECTRICAL

LB60Z-1

Z-Wave Dimmable LED Light
Bulb

• Wirelessly control the bulb from
anywhere via Z-Wave

• Adjust to 100 levels of brightness

• Repeats Z-Wave signals

• Warm 2700°K light

• 9 watts

• 750 lumens

WS15Z-1

Z-Wave Wall Mount Switch

• Load: Incandescent: 600W
maximum, 120 VAC
Resistive:15A (1800w) Max 120 VAC
Motor 1/2hp max, 120 VAC

• Range: Up to 100 feet line-of-sight
between the wireless controller
and/or the closest Z-Wave device

• Network-wide inclusion

• Security beaming

WD500Z-1 / WD1000Z-1

LBR30Z-1

Z-Wave Dimmable LED Indoor Flood Light

• Uses only 7.5 watts of energy

• Provides as much light
as a traditional 65-watt
incandescent flood light bulb

• Medium-cool 5, 000K light
appearance

• 650 lumens

WO15Z-1

Z-Wave Single Wall Outlet

• Load: Incandescent: 600W
maximum 120 VAC
Resistive: 15 amps (1800 watts)
maximum, 120 VAC

• Tamper Resistant as required by
2008 National Electric Code for
new and renovated dwellings

• Up to 100 feet between the wireless
controller and/or the closest
Z-Wave device

• Network-wide inclusion

• Security beaming

PD300Z-2

LB65R6Z-1

Z-Wave Recessed Retrofit LED Kit

• Fully dimmable, instant-on LED bulb

• Fits 5” and 6” recessed light
housings

• Uses only 8.5 watts; warm
2700°K light color

• Flexible mounting with torsion
springs

• Repeats Z-Wave signals

• 650 lumens

WT00Z-1

Z-Wave 3-Way Wall Accessory/Switch

• Load: does not directly control a
load. Another Z-Wave device is
required.

• Range: Up to 100 feet line-of­sight between the wireless
controller and/or the closest
Z-Wave device

• Network-wide inclusion

• Connect up to 5 devices to create
virtual 3, 4, 5, 6, 7-way operation
(Requires Minimote)

• Security beaming

PS15Z-2

Z-Wave Wall Mount Dimmer

• Load: Incandescent: 500w for
installed light fixtures (Not for
control of receptacles)

• Range: Up to 100 feet line-of­sight between the wireless
controller and/or the closest
Z-Wave device

• Network-wide inclusion

• Security beaming

*Also available in 1000W (Part
#WD1000Z-1)

2GIG-Z-BRDG-433

Z-Wave Energy Bridge

• Whole-home energy
monitoring

• Real-time energy usage at a
glance

• Compare energy usage over
time

• Z-Wave connectivity to the 2GIG panel

• One-controlled outlet to control/dim lamps

• Operational Voltage: 120 VAC, 60Hz

• Z-Wave Range: up to 100ft. line-of-sight
between controller and/or closest Z-Wave
Receiver module

• For use with GC2 panel only

Z-Wave Plug-in Lamp Dimmer Module

• Load: Incandescent: 300W
maximum, 120 VAC

• Range: Up to 100 feet
line-of-sight between the
wireless controller and/or
the closest Z-Wave device

• Network-wide inclusion

• One controlled and one pass-through outlet

• Security beaming

FS20Z-1

Z-Wave Isolated Contact Fixture
Module

• J-Box Mounted

• Dry or wet contact applications

• Range: Up to 100 feet line-of-sight
between the controller and/or the
closest Z-Wave device

• Network wide inclusion

• Security beaming

Z-Wave Plug-in Appliance Module

• Load: 15A for control of
light duty appliances

• Range: Up to 100 feet
line-of-sight between
the wireless controller
and/or the closest
Z-Wave device

• Network-wide inclusion

• One controlled and one pass-through outlet

• Security beaming

TRIM RING COLOR KIT-DIMMER

Dimmer Color Change Kit

• Change color of Wall Mount Dimmer to
Almond, Black, or Brown

• Use with the following dimmers:
WD500Z-1
WD1000Z-1

PART NUMBERS

WDKIT-BK Black
WDKIT-BR Brown
WDKIT-AL Almond

TRIM RING COLOR KIT-SWITCH

Switch Color Change Kit

• Change color of Wall Mount Switches
to Almond, Black, or Brown

• Use with the following switches:
WT00Z-1
WS15Z-1

PAGE 10

PART NUMBERS

WTWSKIT-BK Black
WTWSKIT-BR Brown
WTWSKIT-AL Almond

WA105DBZ-1

Z-Wave Siren

• 105 dB sounder

• 10 Lux LED strobe

• 100’ line-of-sight range

• Anti-tamper design

• AC powered w/battery backup

AUTOMATION - SECURITY

AUTOMATION - COMFORT & CONTROL

GD00Z-4 CONTROLLER GC-TBZ48

Z-Wave Garage Door Controller

• Open/Close garage door
from 2GIG panel or remotely*

• See garage door status

• Works with nearly all garage
door openers

*remote control capability is
back-end service dependent

Z-Wave Programmable Thermostat

• Large, easy-to-read LED
backlit display

• Pre-programmed for
instant, energy-saving use

• Runs on 4 AA batteries and/
or HVAC power

• Thin, sleek design

• Simplified installation

SMART DOORBELL CAMERA

Doorbell Camera*

GC-DBC-1

Smart Doorbell Camera

• Fully weatherproof: Hermetically sealed,
IP65 (Dust and water resistant)

• Wide-angle lens: 180 degrees, fisheye with
fixed focal length, 6” to infinity

• Clearer audio: Two-way, built in speaker
and microphone, active noise cancellation
& echo reduction

MINIMOTE

Z-Wave Minimote

• Great for 3-way Z-Wave switch
association

• Use to create associations between Z-Wave
security and lighting products

*Not supported directly by 2GIG Panel, uses stand-alone app.

PAGE 11

1950 CAMINO VIDA ROBLE, SUITE 150 | CARLSBAD, CA 92008 | TEL [phone] | EMAIL: [e-mail]

Part # 236997E
