Lindy 70907 User Manual

70907

CARD BUS 32 bit

P&P

2S (16C550 16FIFO)

www.lindy.com

u

DESCRIPTION:

The 70907 is 2 port Serial PCMCIA card which equipped with two RS-232.V24
Standard Serial-Interface, The serial port include 32 Byte FIFO

u

Check your packing listing:

70907 Card
Software Driver
Hardware Guide
44PIN CONNECTOR TO 2S CABLE

u

Hardware Specification

Serial Port :
UART Chipset: SUN1889, Hardware FIFO is 16Byte FIFO,
Compatible chips: with 16C550 and 16C450.
IEEE standard: RS-232 Interface
Driver Chipset: HIN211.

u

Hardware installation guide:

½

Turn off the power of your computer

½

Plug-in the CBS2000 MIO Series Adapter to PCI bus of your computer

½

Add-on the peripheral

this Adapter

½

Turn on the power of your computer

½

After The Screen, your Card install correct, you can install WINDOWS

2000 or XP, Please see INSTALL GUIDE

u

TECHNICAL SPECIFICATION:

Compatibility: -CARD BUSI 32Bit for 2K/XP
Operating system: -WIN 2000,XP
Chips: -1 x SUN1889
Connections: -44 PIN TO 2 x 9 Pin D-SUB male

PCB: - 2 Layer / 120 x 47 mm

Printer, Modem, Scanner… etc. that you need to

connector serial

2
