1m Cat.5e F/UTP Network Cable, Grey
No.: 48342
RJ45, M/M, 100MHz, copper
Description
Twisted Pair Patch Cable with RJ45 connectors
Cat.5e F/UTP, PVC
Integrated snagless connector for latch protection
Gold plated pins for better conductivity and elimination of signal loss
10 year warranty
Cat.5e F/UTP PVC network cable with support for bandwidth up to 100MHz and features a snagless design with gold
plated contacts for ethernet standards up to 1GBase-T.
Cat.5e cable, designed for operating frequencies up to 100MHz. With its overall shielding (F/UTP) in the form of a foil, this
type of cable has been used reliably for decades in many installations in the prosumer sector as well as in the professional
segment, since it can easily be used for Gigabit Ethernet. These cables are manufactured and tested according to the
ISO/IEC 11801 specification. The cables are packaged individually in a polybag.
The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless
strain relief design prevents damage to the connector latch during installation and removal.
Available lengths: 0.3m, 0.5m, 1m, 2m, 3m, 5m, 7.5m, 10m, 15m, 20m, 30m.
Technical details
Connectors
Connector A: RJ45 Male
Connector B: RJ45 Male
Housing Material: Polycarbonate
Connector Plating: Nickel
Pin Construction: Copper Alloy
Pin Plating: Gold plated
Dimensions (approx.) WxDxH: 11.6x22.8x8.3mm (0.46x0.90x0.33in)
Cable Construction
Length: 1m (3.28ft)
Page 2
Colour: Grey
Type: Cat.5e
Jacket Diameter: 5.0mm (0.20in)
Jacket Material: PVC
Conductor Material: Copper
Conductor Gauge: 26AWG
Shielding: Aluminium Foil
Specifications
Supported Bandwidth: 100MHz
Nominal Attenuation: 24dB/100m @100MHz
Minimum Band Radius: 60mm (2.36in)
Operating Temperature: -10°C - 60°C (14°F - 140°F)
Storage Temperature: -20°C - 75°C (-4°F - 167°F)
Miscellaneous
Packaging Type: Polybag
Warranty (Years): 10
Certificated: RoHS, REACH, UL, California Proposition 65
Purchasing Information
No.: 48342
EAN: 4002888483421
This product is also available in other lengths
48340 - 0.3m (0.98ft)
48341 - 0.5m (1.64ft)
48342 - 1m (3.28ft)
48343 - 2m (6.56ft)
48344 - 3m (9.84ft)
48345 - 5m (16.44ft)
48346 - 7.5m (24.61ft)
48347 - 10m (32.81ft)
48348 - 15m (49.21ft)
48349 - 20m (65.62ft)
48350 - 30m (98.43ft)
