Lindy 32321, 32320, 32322, 32323 User Manual
User Manual ......................English......................... page 3
KVM Switch Pro USB 2.0 Audio
User Manual English
Benutzerhandbuch Deutsch
Manuel Utilisateur Français
Manuale d’uso Italiano
LINDY No. 32320 – 2 Port VGA
LINDY No. 32321 – 4 Port VGA
LINDY No. 32322 – 2 Port DVI-I
LINDY No. 32323 – 4 Port DVI-I
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (JAN 2008)
For Home and Office Use
Tested to Comply with
FCC Standards
www.LINDY.com
Benutzerhandbuch ........... Deutsch........................Seite 8
Manuel d’utilisateur.......... Français..................... page 13
Manuale d’uso................... Italiano .................... pagina 18
Certifications & Statements.................................. page 24
- 2 -
User Manual English
User Manual English
Introduction
Thank you for purchasing the LINDY KVM Switch Pro USB 2.0 Audio. This
product is covered by a limited 2 Year warranty.
Pease read this manual carefully to fully understand all the functions and features
of this advanced USB KVM Switch.
This KVM Switch allows several USB enabled computers to be connected and
controlled from a single keyboard, monitor and mouse thereby reducing hardware
costs and maximising desk space.
Product Features
The LINDY KVM Switch Pro USB 2.0 Audio supports advanced features that allow
modern USB enabled computers such as PCs and Macs to connect and share
USB peripherals, such as printers, scanners, storage devices etc.
•
Supports USB mice and keyboards as well as USB 2.0 device sharing among
the connected computers
•
Computer port selection by any of the following:
o Front panel push buttons on the switch
o Keyboard Hotkey – configurable by the user
•
Audio support for microphone and speakers. Includes selectable switching
function which can be configured to exclude audio switching for uninterrupted
listening.
•
Built in 2 port USB 2.0 hub allows peripherals to be shared between the
connected computers. USB hub ports can be configured to be excluded from
switching when changing computers.
•
DVI-I and as VGA versions available, both with 2 or 4 ports and supplied with
KVM cables for connecting to the computers.
•
The DVI-I version uses advanced DVI-I technology for digital video as well as
analogue video signals via the DVI-I connector. Supports all digital DVI-D
Single Link resolutions up to 1920 x 1200, and analogue VGA resolutions up to
2048 x 1536.
Package contents
LINDY KVM Switch Pro USB 2.0 Audio
2 or 4 sets of KVM cables (depending on model) to connect the computers
Power supply
This manual
- 3 -
USB 2.0 Device Sharing
This KVM Switch provides USB keyboard and mouse ports as well as two USB 2.0 hub ports to
connect different USB 2.0 devices. The built in USB hub supports USB data rates of up to
480Mbps. The internal USB 2.0 hub ports also support the connection of an additional USB hub
allowing more that two devices to be connected to the KVM switch. USB devices can either be
switched together with the KVM function or configured to be excluded from switching.
Important Note: If you share USB Pen Drives, Card Readers or other memory devices, and
switch them between your computers, you must make sure that any current data transfer is
completed before you change channels. If you do not do this the active data transfer may be
interrupted and files may become corrupted or lost. To prevent such problems make sure that
any data transfer has completed or use the Windows or Mac function to remove the USB
hardware safely.
Installation
DVI version: If you wish to connect computers with both digital DVI-D and
analogue VGA signals then you will need to add the LINDY VGA to DVI Adapter
(Part No. 41223) to your graphics card. Please also ensure your monitor accepts
both digital and analogue signals. This KVM Switch does not convert the video
signal but only switches the analogue and digital signals. If your monitor has two
separate input connectors for analogue (VGA) and digital (DVI-D) signals then you
will require the LINDY Video Splitter Cable (Part No. 41219) to connect to your
monitor.
You can now install your LINDY KVM Switch Pro USB 2.0 Audio by following
the procedure as described below:
Step 1. Connect the power supply to the KVM switch before you connect any
other cables.
Step 2. Connect your keyboard, monitor and mouse to the USB and DVI ports on
the KVM switch labelled CONSOLE. Connect your speakers and microphone if
required.
Step 3. Connect your computers using the cables provided. Should you wish to
extend the operating distance then you may purchase suitable cables from
LINDY. Be advised that the maximum working distance for USB is 5m. If you
require a longer distance then please use the LINDY No. 42915 USB 2.0
Active Extension Cable (Part No. 42915).
Step 4. Turn on the power to all devices and computers.
Step 5. Your computer should now boot and detect the newly installed hardware.
A Windows operating system will detect and install multiple USB device drivers.
Please wait until this procedure has finally completed to ensure correct
operation. A Mac computer system may not identify a PC keyboard at the first
boot up and may show an identification menu; please follow the on screen
- 4 -
User Manual English
information. In some cases it may be nessacery to unplug the mouse and
keyboard and re-connect to allow the USB ports to re-detect.
It may also be necessary to reboot your computer with the mouse and
keyboard directly connected. Once the device drivers have installed correctly
you may remove the mouse and keyboard and connect them directly to the
KVM switch console port. The windows operating system includes all relevant
USB device drivers so no additional drivers are required to be installed.
KVM switching options
Computer port selection may be made by any of the following:
o Front panel push buttons on the switch
o Keyboard Hotkey – configurable by the user
Front panel push buttons with white/red LED indicators
Press the front push button to select the appropriate port/computer. During the
switching process a white LED behind the switch button will flash. The LED will
remain on when switching is completed and the connections are established.
Depending on the configuration only the KVM ports (USB keyboard, mouse and
monitor) or KVM and USB 2.0 hub and/or Audio ports are switched. To learn more
about these options, please refer to the table on the next page.
The white port LEDs refer to the KVM section status, the red port LEDs refer to
the USB 2.0 hub section status and shows the port/computer currently selected.
Keyboard Hotkey Switching
The KVM switch may also be conveniently switched and configured using
keyboard hotkeys. This process is invoked by pressing a universal hotkey on the
keyboard twice within 2 seconds. The factory default setting for this universal
hotkey is the SCROLL LOCK button. The KVM switch can be reconfigured to use
a different hotkey from the following list: NUM LOCK, or CAPS LOCK, or F12 or
Escape (ESC) key.
Press the universal hotkey twice to invoke the switching function – the KVM switch
will confirm this with a short beep signal. Depending on the next key you press
you can select any of the available switching or configuration functions of the KVM
switch. Please refer to the following table for the available options.
User Manual English
Hotkey Switching and Configuration Commands
KVM Switch Pro USB 2.0 Audio
Command Hotkey Input Front
Binds KVM & Hub switching (Default, Z for QWERTY kb!)
Unbinds KVM & Hub switching
Binds KVM & Audio switching (Default)
Unbinds KVM & Audio switching
Switches directly to port 1, 2, 3 or 4
Switches USB Hub to port 1, 2, 3 or 4
Switches Audio devices to port 1, 2, 3 or 4
Switches one port up
Switches one port down
Switches to the previous port
Switches the Beep confirmation tone ON / OFF
Switches the universal Hotkey to **
Switches to Autoscan
Switches to Autoscan with port time 10s (1) to 100s (0)
Stops Autoscan
* + * + Z (or Y)
* + * + X
* + * + Q
* + * + W
* + * + 1-4
* + * + Fn1-Fn4
* + * + Fn5-Fn8
* + * + ↓↓↓↓
* + * + ↑↑↑↑
* + * + ←←←←
* + * + B
* + * + H + **
* + * + S
* + * + S + 0-9
Any key
* stands for the universal hotkey (factory default is SCROLL LOCK, configurable to new
hotkey ** NUM, CAPS, F12, or ESC key)
Fn1-Fn4 stands for the function keys F1, F2, F3, and F4
(#) To change the universal hotkey from the front push buttons please press the highest port
button until you hear two short confirmation beeps. Then press the chosen new hotkey
SCROLL, NUM, CAPS, F12, or ESC on your keyboard. The KVM switch will confirm this
by a short beep and the hotkey is permanently changed.
(Yes) When binding between KVM and USB 2.0 Hub and/or Audio ports is enabled, pressing
the front push button will switch all: KVM & USB hub & Audio. If binding is disabled for
Audio or the USB hub this will not be included for port switching
Yes
(Yes)
(Yes)
Yes (#)
Yes
- 5 -
- 6 -
User Manual English
Benutzerhandbuch Deutsch
Troubleshooting
Note when using older USB computers: When connecting older USB
computers with only USB 1.1 interfaces, ensure that Legacy Support in the BIOS
is enabled. Also ensure your operating system is up to date with the latest USB
HID drivers.
Note for power supply: It is possible to use the KVM switch without the DC
adapter for use with low power devices. However, it is advisable to use the DC
adapter for use with the built in USB 2.0 hub when using bus powered devices.
Fault finding: Please check that all monitor and USB cable connections are well
seated to ensure correct operation of the KVM switch.
1. If the KVM Switch reacts to the universal hotkey with a beep signal, but no
monitor picture is displayed, please check if the currently selected computer is
in sleep mode or powered down.
2. If the monitor picture is not sharp or shows shadows, make sure you have used
high quality video cables with co-axial cores.
a. For analogue VGA signals you may consider reducing the video frame
rate to 72Hz.
b. For digital DVI-D signals please make sure the video frame rate is set
to 60Hz.
c. When using mixed analogue and digital video setups please refer to
the notes in the Installation chapter. Your monitor should automatically
switch between the active analogue or digital signal.
3. Don’t press any keys on the keyboard or mouse whilst a selected computer is
booting up. Please wait until driver installation is complete
4. A computer boots but the keyboard (or mouse) doesn’t work:
a. Use only USB keyboards and mice
b. Check if the keyboard (or mouse) works when directly connected to
the computer
c. Reboot the computer with the keyboard and mouse directly connected
and check the status of the installed drivers
Should you require any help with this product then please contact LINDY
Technical Support Team. Contact information can easily be found on the LINDY
website www.lindy.com.
- 7 -
Einführung
Herzlichen Glückwunsch zum Erwerb des KVM Pro USB Audio.
Bitte lesen Sie dieses Handbuch sorgfältig um die ausgefeilten Möglichkeiten
kennen zu lernen, die Ihnen dieser technisch herausragende KVM-Switch bietet.
Durch den Einsatz dieses LINDY KVM Switches können Sie Kosten für
zusätzliche Monitore, Tastaturen und Mäuse einsparen. Ferner sparen Sie
erheblich an Platz und Sie beseitigen die Problematik, hin und wieder Mäuse und
Tastaturen der einzelnen Rechner zu verwechseln.
Eigenschaften
KVM Switch Pro USB Audio ist ein KVM-Umschalter mit einigen herausragenden
technischen Features zum Einsatz mit modernen USB Computern wie mit PCs als
auch mit Macs mit aktuellen Betriebssystemen:
•
Er unterstützt sowohl USB Tastatur & Maus wie auch USB 2.0 Device Sharing
zwischen den Rechnern
•
Er unterstützt 2 Arten des Umschaltens:
o Umschalttaste am Switch
o Tastatur-Hotkey – durch Anwender konfigurierbar
•
Der KVM-Switch schaltet bei Bedarf auch die Audio-Lautsprecher und ein
Mikrofon mit um. Er kann auch so konfiguriert werden, dass diese vom
Umschalten ausgenommen werden und immer an einen Port / Rechner
gebunden bleiben
•
Auch die USB 2.0 Ports des USB Hub können je nach individuellem Bedarf
vom Umschalten ausgenommen oder mit umgeschaltet werden
•
Er ist als DVI-I sowie als VGA Version verfügbar, jeweils mit 2 sowie mit 4
Rechneranschlüssen und beiliegenden Kabelsätzen.
DVI-I Version: der KVM Switch setzt die DVI-I Technologie für digitale &
analoge Monitorsignale ein, digital bis zu 1920 x 1200 (DVI-D Single Link),
analog bis zu 2048 x 1536 (VGA).
Lieferumfang
LINDY KVM Switch Pro USB 2.0 Audio
2 bzw. 4 Kabelsätze (je nach Modell) zum Anschluss der Rechner
Eco-Weitbereichsnetzteil mit verschiedenen Steckervorsätzen
Dies Handbuch
- 8 -
Loading...
