Page 1
Quick Reference Guide
2017 NAVIGATOR
This Quick Reference Guide is not
intended to replace your vehicle
Owner’s Manual, which contains more
detailed information concerning the
features of your vehicle, and important
safety warnings designed to help
reduce the risk of injury to you and
your passengers. Please read your
entire Owner’s Manual carefully as
you begin learning about your new
vehicle and refer to the appropriate
chapters when questions arise. All
information contained in this Quick
Reference Guide was accurate at the
time of duplication. We reserve the
right to change features, operation
and functionality of any vehicle
specification at any time. Your Lincoln
dealer is the best source for the most
current information. For detailed
operating and safety information,
please consult your Owner’s Manual.
Navigator
April 2016
First Printing
Quick Reference Guide
Litho in USA
HL7J 19G217 AA
United States
Lincoln Client Relationship Center
1-800-521-4140 (TDD for the hearing impaired 1-800-232-5952)
owner.lincoln.com
Canada
Lincoln Client Relationship Centre
1-800-387-9333 (TDD for the hearing impaired 1-888-658-6805)
lincolncanada.com
WARNING
Driving while distracted can result in loss of vehicle control, crash and
injury. We strongly recommend that you use extreme caution when
using any device that may take your focus off the road. Your primary
responsibility is the safe operation of your vehicle. We recommend
against the use of any hand-held device while driving and encourage
the use of voice-operated systems when possible. Make sure you are
aware of all applicable local laws that may affect the use of electronic
devices while driving.
Page 2
2017 NAVIGATOR
Table of Contents
Instrument Panel ................................................. 4–11
SYNC 3 ................................................................12–15
Convenience ........................................................16–17
Comfort .............................................................. 18–19
Function .................................................................. 20
Essential Features ..............................................21–22
Commonly Used SYNC 3 Voice Commands ............ 23
lincolncanada.com
LEARN MORE ABOUT YOUR NEW VEHICLE
Scan the country-appropriate QR code with your smartphone
(make sure you have a scanner app installed), and you can
access even more information about your vehicle.
owner.lincoln.com
The Lincoln Pledge
1
The Lincoln Pledge is the collective promise of everyone at the Lincoln Motor
Company—from our trusted service advisors to expert technicians to the voice
on the other end of the line should you call—that we’ll be there for you and your
Lincoln wherever, whenever, if ever you need us. Here are some of the ways
the Lincoln Pledge comes to life and makes the journey of owning a Lincoln a
rewarding one.
Lincoln Warranties
Be assured that everything between the bumpers of your Lincoln is covered for
four years/50,000 miles2 as well as a six-year/70,000-mile Powertrain Warranty
for life.
2
Roadside Assistance
If ever you need help on the road, the Lincoln Motor Company will be there for
you with 24-hour/seven-days-a-week assistance nationwide.
2
Complimentary Car Wash
As an added touch, after each service visit we’re happy to provide your Lincoln
back to you washed and ready for the road ahead.3
Complimentary Loaner
Should your Lincoln require warranty service, we’ll be there for you with a
loaner vehicle.3
Service Parts Warranty
We’ll stand behind our service and you with a two-year, unlimited-mile
warranty on both parts and labor.2
Dedicated Support
Lincoln Client Relationship Center
and Roadside Assistance
1-800-521-4140
TDD for the Hearing Impaired
1-800-232-5952
owner.lincoln.com
How-to and informational videos.
Warranty and maintenance information.
Make your payment or schedule service online.
Shop for accessories.
Join us in Conversation
1 Canadian Roadside coverage and benefits may differ from the United States
coverage. Canadian clients should refer to the Lincoln Roadside Assistance
section of the Warranty Guide, call 1-800-387-9333 or visit the website at
LincolnCanada.com for more details.
2 See dealer for complete details. Lincoln reserves the right to change
program details at any time without obligations.
3 Availability depends on dealership participation.
Our caring agents are
empowered to handle your call
and concerns from beginning
to end.
Page 3
2017 NAVIGATOR
5
1 Lighting Control
Switches on the headlamps.
Switches the headlamps off.
Switches on the parking lamps.
Autolamps*: Turns the headlamps on
and off based on available daylight.
2 Interior Lamps
Press and hold the top of the control to
switch on the interior courtesy lamps. Press
the bottom of the control to switch off the
interior lamps.
3 Tilt and Telescoping Steering Column
Use the control on the side of the steering column
to adjust the position. The column automatically
moves to the full up position when you switch
the ignition off. It returns to the previous position
when you switch the ignition on. You can switch
this feature off in the information display. For
more details about your information display
functions, please see your Owner’s Manual.
4 Power-Adjustable Foot Pedals*
Your power-adjustable pedal control, on the left
of your steering column, allows you move your
brake and accelerator pedals. Press the ⊳ arrow
to move the pedals away from you or the ⊲ arrow
to move the pedals closer to you.
Note: Adjust the pedals only after you stop the
vehicle and place the transmission in park (P).
5 Cruise Control
To set the speed:
A. Press and release ON.
B. Drive to the desired speed.
C. Press SET+ and take your foot off
the accelerator.
To set a higher or lower speed, press and
hold SET+ or SET– until you reach the desired
speed. Press and release either button to
change a set speed in approximately
1 mph (2 km/h) increments.
To cancel a set speed, tap the brake pedal.
The set speed saves for easy recall.
To return to a previously set speed, press RSM.
To switch off, press OFF or switch the
ignition off.
6 Autowipers
To switch this feature on, move the wiper controls
to intermittent wipe. The autowiper system turns
the wipers on only when moisture is present on
the windshield. The wiper speed depends on
how much moisture the system detects and the
sensitivity setting.
Low sensitivity turns the wipers on when the
rain sensor detects a large amount of moisture
on the windshield.
High sensitivity turns the wipers on when the
rain sensor detects a small amount of moisture
on the windshield.
To switch this feature off, use your wiper
controls. To change this feature to intermittent
wipe every time you use your wipers, use the
information display.
To switch intermittent wipe back to autowipers,
use the information display.
Note: Make sure you switch this feature off
before entering a car wash.
Instrument Panel
*if equipped
4
Page 4
2017 NAVIGATOR
7
7 Left Vehicle Information Display
Shows important vehicle information through a
constant monitor of vehicle systems. For example,
you can view the display mode that shows you
digital readouts of various settings, the trip and
fuel readouts, towing information, off-road status
and vehicle settings that you can switch on and
off. The display notifies you of potential vehicle
problems by showing system warnings followed
by a long indicator tone.
Use the 5-way controls located on your steering
wheel to scroll through, highlight and make minor
adjustments within a selected menu. For more
details about your information display functions,
refer to your Owner’s Manual.
8 Service Engine Soon Light
Lights briefly when you switch the ignition
on. If it remains on or blinks after you start the
engine, the On-Board Diagnostics (OBD-II) system
detects a problem. Drive in a moderate fashion
and contact an authorized dealer as soon
as possible.
9 Right Vehicle Information Display
Displays important vehicle information about
various systems on your vehicle. Use the righthand, 5-way controls located on your steering
wheel to scroll through, highlight and make
minor adjustments within a selected menu.
Refer to the SYNC section of your Owner's
Manual for more details.
10 Media Controls
Press VOL+ or VOL– to increase or decrease
your volume level.
Press to access the previous or next
radio station, CD track or preset satellite
radio channel.*
Press to access voice recognition.
Press to access SYNC® phone features.
Note: Some of your steering wheel media
controls may vary. Refer to the Steering
Wheel chapter in your Owner’s Manual for
more details.
11 Push Button Start*
Allows you to start your vehicle by pressing
the START STOP button when fully pressing
down on the brake pedal. If you leave your
vehicle idling for an extended period of
time, it automatically shuts down. Before the
engine shuts down, a message appears in the
information display, allowing the driver
to override the shutdown feature. Press the
button again to turn the engine off.
Note: A valid transmitter must be inside your
vehicle to switch the ignition on and start the
ignition. Keyless warning alert sounds the
horn twice when you exit the vehicle with the
transmitter and the keyless vehicle is still on.
12 Hazard Warning Control
Instrument Panel (cont.)
*if equipped
6
Page 5
2017 NAVIGATOR
9
13 Audio System Controls
A. VOL and system power: Push to switch
the system on and off. Rotate the control to
adjust the volume.
B. CD slot: Insert a CD.
C. SEEK with Reverse and Fast-forward: Press
to select the next or previous radio
station or CD track.
D. Eject: Push to eject a CD.
E. TUNE: Once you select a frequency band,
rotate the control to find the station you
desire manually.
14 Climate Control
A. Driver – TEMP +: Press to increase or
decrease the air temperature for the driver
side of the vehicle.
B. – Fan speed +: Press to increase or
decrease the volume of air circulated in
the vehicle.
C. Passenger – TEMP +: Press to increase
or decrease the air temperature for the
passenger side of the vehicle.
D. Driver climate controlled seat*: Press
to switch the seat on and off,
or cycle through the settings.
E. Passenger climate controlled seat*: Press
to switch the seat on and off, or cycle
through the settings.
F. Defrost: Press to distribute air to the
windshield vents.
G. Heated rear window: Press to switch the
heated rear window on and off.
H. AUTO: Press to switch on automatic operation.
Select the temperature you desire by using
the temperature control. The system adjusts
fan speed, air distribution, air conditioning
operation, and selects outside air or
recirculated air to heat or cool the vehicle
in order to maintain the temperature. You
can also use the AUTO button to switch
off dual-zone operation by touching and
holding the button for a few seconds.
I. System power on or off.
J. A/C: Press the button to switch the air
conditioning compressor on or off.
Use air conditioning with recirculated
air to improve cooling performance
and efficiency.
K. MAX A/C: Press to maximize cooling.
Recirculated air flows through the instrument
panel vents, air conditioning automatically
turns on and the fan automatically adjusts to
the highest speed.
L. Recirculated air: Press the button to switch
between outside air and recirculated air. When
you select recirculated air, the air currently
in the passenger compartment recirculates.
This may reduce the time needed to cool the
interior (when used with A/C) and may reduce
unwanted odors from entering your vehicle.
Note: Recirculated air may turn on and off
automatically during hot weather to improve
cooling efficiency.
Instrument Panel (cont.)
*if equipped
8
II
JJ
KK
LL
AAAABBBBCCCCDDDDEE
EE
FF
GG
HH
II
8
Page 6
2017 NAVIGATOR
10 11
17 SelectShift® Automatic Transmission*
Gives you the ability to manually change gears if you like.
To use, move the gearshift lever from drive (D) to manual (M).
Press the (+) button to upshift.
Press the (–) button to downshift.
To return back to automatic shifts, move the gearshift lever from manual (M)
to a dierent gearshift position.
18 Overdrive Control with Tow/Haul Feature
The tow haul feature improves transmission operation when towing a trailer
or a heavy load. To switch tow haul mode on, press the control on the
side of the gearshift lever. The TOW HAUL indicator light illuminates in the
instrument cluster. To switch this feature o, press the control again. Drive
with the vehicle in overdrive (D) with tow haul mode o for the best
fuel economy. Refer to the Transmission chapter of your Owner’s Manual
for more information.
19 Stability Control with RSC® (Roll Stability Control
TM
)
Automatically turns on when you start your engine and helps you keep
control of your vehicle when on a slippery surface. The electronic stability
control portion of the system helps avoid skids and lateral slides, and roll
stability control helps avoid a vehicle rollover. The traction control system
helps avoid drive wheel spin and loss of traction. See the Stability Control
chapter in your Owner’s Manual for details.
Trailer Sway Control
Applies your vehicle brakes at individual wheels and, if necessary, reduces
engine power. If the trailer begins to sway, the stability control light ashes and
the message TRAILER SWAY REDUCE SPEED appears in the information display.
The rst thing to do is slow down your vehicle, then pull safely to the side of the
road and check for proper tongue load and trailer load distribution. See the
Towing chapter in your Owner's Manual for specic loading information.
15 Liftgate Release
To open or close the power liftgate, press and release the control.
16 Control Trac® Four-Wheel-Drive (4WD) System*
4X2
Delivers power to the rear wheels only. This is appropriate for normal, on-road driving on
dry pavement.
4X4 AUTO
Provides electronic control four-wheel drive with power delivered to all four wheels, as
required, for increased traction. The information display shows “4A” when you select this
position. This mode is appropriate for all on-road driving conditions, such as dry road
surfaces, wet pavement, snow or gravel.
4X4
Provides electronically locked four-wheel drive power to all four wheels. The information
display shows “4X4” when you select this mode. Lincoln does not recommend using
4x4 mode on dry pavement. Its intended use includes severe winter or o-road conditions,
such as deep snow, ice or shallow sand.
Refer to the Four-Wheel Drive chapter in your Owner’s Manual for more information,
including shifting instructions.
*if equipped
Instrument Panel (cont.)
*if equipped
Page 7
2017 NAVIGATOR
12 13
Pairing Your Cell Phone with SYNC 3
Pair your cell phone to SYNC before using SYNC 3.
Make sure your vehicle is in park (P) and you switch
on your ignition.
Make sure you switch Bluetooth on and your
device is discoverable. See your device’s manual,
if necessary.
Touch Add Phone on the touchscreen.
Select SYNC on your device. A six digit PIN
appears on your device.
If your device prompts you to enter a PIN, enter
the PIN displayed on the touchscreen. Skip the
next step.
When prompted on your cell phone’s display,
confirm that the PIN provided by SYNC matches
the PIN displayed on your cell phone.
The display indicates when the pairing
is successful.
Note: SYNC 3 prompts you to choose your
settings for certain features. Your cell phone may
also prompt you to give SYNC 3 permission to
access information.
For more information on your cell phone’s
capability, see your cell phone’s manual and visit
the website.
Phone
After pairing your phone, you can access more
phone-dependent features:
Recent call lists.
Contacts: Sort alphabetically and choose a
specific letter to begin viewing your entries.
Phone settings: Pair another phone, and set ring
tones and alerts.
Text messages.
Do not disturb: Send all calls to your voicemail,
and all ring tones and alerts set to silent mode.
Note: Use the voice commands to make calls. Say
“Call James at home” or “Dial 555-1212”. You can
use the touchscreen to place calls as well. Refer to
the SYNC 3 chapter in your Owner’s Manual for
complete details.
Making a Phone Call
Use SYNC to make a phone call to anyone in your
phone book through the touchscreen.
Press Contacts and then select the name of the
contact you want to call.
To call using a number from your recent calls,
press Recent Call List and then select an entry
you want to call.
To call a number that is not stored in your
Contacts list, use the Keypad feature to manually
dial the number. Press Call to initiate the call.
Note: Typing the X button deletes the last
typed digit.
Receiving Calls
Whenever you have an incoming call, an audible
tone sounds. Caller information also appears in the
display, if the information is available.
Press Accept on the touchscreen or the phone
button on the steering wheel to answer an
incoming call.
Do nothing to ignore an incoming call, and
SYNC 3 logs it as a missed call.
Reject any incoming call by pressing Reject on
the touchscreen.
Ending the Call
Press and hold the phone button on your
steering wheel.
SYNC® 3
Using SYNC 3
SYNC is a hands-free, voice recognition system used for entertainment,
information and communication.
Use the touchscreen to explore and interact with your vehicle. The touchscreen
works the same way traditional controls, knobs and buttons do. The system
provides easy interaction with your audio, climate, phone, navigation*,
mobile apps and settings.
Press Settings on the feature bar on your touchscreen to personalize
the many features and settings of your vehicle all in one place.
General Tips
Press the home icon at any time to return to the home screen.
For additional support, refer to the SYNC section of your Owner's Manual,
visit the website, owner.lincoln.com or call the toll-free number. See the
inside back cover of this guide for more details.
The touchscreen is sensitive, so make sure you press the icon you
desire accurately.
Why You Need a SYNC Owner Account
A SYNC owner account allows you to receive the latest software updates
and when you have questions, free client support. Some services may not be
available in your area.
Create Your Account
Create your account by visiting the website. Call the toll-free number for
more information.
In the United States:
owner.lincoln.com
1-800-521-4140
In Canada:
syncmyride.ca
1-800-387-9333
*if equipped
Page 8
2017 NAVIGATOR
14 15
SYNC® 3 (cont.)
*if equipped
Navigation*
Press the Navigation* icon to set your destination.
Select one of two ways to find your destination:
Destination mode allows you to key in a specific
address or use a variety of search methods to
locate where you want to go.
Map mode shows advanced viewing of 2D
city maps, 3D landmarks and 3D city models
(when available).
Set a Destination
Press Destination on your touchscreen and then
press Search. Enter a street address, intersection,
city or a point of interest (POI).
After you choose your destination, press Start.
The system uses a variety of screens and visible
prompts to guide you to your destination.
During your route, you can press the maneuver
arrow icon on the map if you want the system to
repeat the previous route guidance instructions.
The navigation map shows your estimated time
of arrival, remaining travel time or the distance to
your destination.
Navigation Menu
When you are on your route, you can change
your touchscreen view. Touch Menu, and then
select Screen View to select from these options:
Full Map
Highway Exit Info displays on the right side of the
touchscreen. View POI icons (restaurants, ATMs,
etc.) as they pertain to each exit. You can select a
POI as a waypoint.
Turn List shows all of the available turns on your
current route.
Traffic List displays SiriusXM Traffic and
Travel Link* information.
Climate
Touch the Climate icon on the touchscreen
to access climate control features including the
temperature, airflow direction, fan speed and other
climate features for you and your front passenger.
Say “Climate set temperature to 72 degrees” and
SYNC 3 makes the adjustment.
You can also use the ▲ or ▼ buttons to change
the temperature setting.
*if equipped
Audio
SYNC 3 gives you a mix of media. Press the Audio
icon on the touchscreen and select Sources. Choose
from AM, FM, SiriusXM*, CD, USB, Bluetooth Stereo
or Apps.
Set Your Radio Presets
Tune to the station and then press and hold one
of the memory preset buttons.
The audio mutes briefly when the system saves
the station and then the audio returns.
Two preset banks are available for AM and three
banks for FM. To access additional presets, tap
the preset button. The indicator on the preset
button shows which bank of presets you are
currently viewing.
Using SYNC 3 to Access Digital Media
Play all of your favorite music from phones, flash
drives and other devices.
Plug your device into a USB port, select Sources
and then choose USB. Wait for the system to finish
indexing your music to begin listening.
Apps
Voice control your smartphone apps
The system supports the use of certain types of
apps such as Pandora® or iHeartRadio® through a
USB or Bluetooth-enabled device. Each app gives
you different on-screen options depending on the
app's content. To find new apps, use the voice
command “Find new apps”.
For more information, refer to the SYNC chapter of
your Owner Manual. For support, visit the website,
owner.lincoln.com or call the toll-free number. See
the inside back cover of this guide for details.
Page 9
2017 NAVIGATOR
16 17
Convenience
Power Running Boards*
When active, the running boards
extend down and out when you open
the doors. They return to the stowed
position after a two-second delay
when you close the doors.
To switch the power running board
feature on and off, refer to the
Information Displays chapter in your
Owner's Manual.
Note: Do not use the running boards,
front and rear hinge assemblies,
running board motors or the running
board under body mounts to lift the
vehicle when jacking. Always use
proper jacking points. See your
Owner's Manual for details.
Power Liftgate
Press on the instrument panel to
open or close the power liftgate. For
added convenience, there are three
more ways to activate your power
liftgate’s capabilities:
1. On your remote entry transmitter,
press twice within a few
seconds to open or close your
power liftgate.
2. To open using the outside
control button:
Unlock the liftgate with the remote
control or power door unlock
control. If an Intelligent Access key
is within 3 ft (1 m) of the liftgate, the
liftgate unlocks with you press the
liftgate release button A. Press B to
open the glass.
3. To close using the rear cargo area
button: Press and release the
control on the left rear quarter
panel in the rear cargo area. This
button automatically turns off after
the liftgate latches.
Note: Keep clear of the liftgate when
operating the rear controls. Your
power liftgate includes an obstacle
detection feature that either stops
or reverts to a full open position
if it encounters a solid object. For
complete information, see the Liftgate
section within the Locks chapter of
your Owner’s Manual.
Leather Cleaning
For cleaning and removing
spots and stains, use Motorcraft®
Premium Leather and Vinyl Cleaner**
or a commercially available
leather cleaning product for
automotive interiors.
Note: Test any cleaning product on an
inconspicuous area first.
Do not use the following products as
these may damage the leather:
Oil and petroleum or silicone-
based leather conditioners.
Household cleaners.
Alcohol solutions.
Solvents or cleaners intended
specifically for rubber, vinyl
and plastics.
For complete information, see the
Vehicle Care chapter of your
Owner’s Manual.
*if equipped
SecuriCodeTM Keyless Entry Keypad
Lock or unlock the doors without using a key. You
can operate the keypad with the factory-set, 5-digit
entry code. This code is on the owner’s wallet card in
the glove box.
You can also create up to five of your own 5-digit
personal entry codes. To lock all of the doors and
liftgate, press and hold 7•8 and 9•0 at the same
time with the driver door closed. For complete
information, refer to the Locks chapter of your
Owner’s Manual.
MyKey®
MyKey allows you to program certain driving
restrictions in order to promote good driving habits.
You can set speed restrictions and limit volume
levels. For complete information, refer to the MyKey
chapter in your Owner’s Manual.
Intelligent Access
Note: Your transmitter must be within 3 feet
(1 meter) of the vehicle for intelligent access to
function properly:
To unlock all of the doors, press the unlock
button on the transmitter or press any number
on the SecuriCode keyless entry keypad to unlock
all doors.
To lock the doors, press the lock button on
the transmitter, or use the SecuriCode keyless
entry keypad.
The transmitter also contains a key blade, which can
be used to unlock the driver's door, if necessary.
See your Owner’s Manual for more information.
Remote Start*
Remote start allows you to start the engine from
outside your vehicle using your key. To start, press
and then press twice within three seconds.
Your vehicle runs for 5, 10, or 15 minutes, depending
on the setting. See the Information Displays chapter
in your Owner’s Manual to select the duration of
the remote start system.
Once inside with your transmitter in the vehicle,
apply the brake while pressing the START STOP
button. Shift into drive (D) and go.
To switch the engine o from outside the
vehicle after using your remote start,
press once.
Note: Your transmitter's operating range is
approximately 33 feet (10 meters). Weather
conditions, nearby radio towers, structures
around the vehicle, etc. can aect your range.
*if equipped
**Do not use on the Reserve Package seats.
See the Vehicle Care chapter in your Owner's Manual for details.
AA
BB
Page 10
2017 NAVIGATOR
18 19
PowerFold® Third-Row Seat*
The 60/40 split-folding bench seat uses a power-activated seatback release. The
three-button system allows you to fold both sides down at once or fold each side
down independently for more flexibility. The controls are on the
right-hand rear quarter trim panel, accessible from the liftgate area.
Note: Before you fold your seats down, make sure that you place your vehicle
in park (P), open the liftgate, unfasten all seatbelts and fold all head restraints down.
To use:
1. Press the corresponding control(s) or use the middle control to fold both
seats down.
2. To return the seatback(s) to the original position(s), press the
corresponding control(s) again.
See the Seats chapter in your Owner's Manual for more information.
Note: The power-folding seats operate for 10 minutes after you switch
the ignition off.
E-Z Entry into the Third-Row Seats*
The feature allows for easier entry and exit to and from the
third-row seats.
To enter the third-row seating area:
1. Fold the head restraint forward.
2. Pull up on Lever 1.
3. Fold down the second-row seat and release the lever.
4. Pull the lever up again until the seat releases from
the oor.
5. Push the seat upward and fold it away from the third row.
To return the seat to an upright seating position:
1. Push the seat down and latch it to the oor.
2. Bring the seatback to an upright position. It should lock
into position.
3. Lift up on the head restraint until it locks into its
original position.
*if equipped
Comfort
*if equipped
Lever 1
Position 2
Position 3
Front Climate Controlled Seats*
To use the heated seats, press the right side of the button . For cooled seats,
press the left side of the button . Press the button repeatedly to cycle through
the settings, from the highest to the lowest, and then off. More indicator lights
mean higher settings.
Second-Row Controls*
Auxiliary climate and heated seat controls, on the rear of the center console
allow second-row passengers to make adjustments and power smaller
accessories independently from the front-row controls.
Memory Seat Feature
The memory function saves and recalls the positions of the driver seat,
power mirrors, adjustable pedals and the steering column. Use the control
located on the side of the driver’s seat to program and then recall
saved memory positions.
To program position 1, switch the ignition on. Move the memory features to the
position you prefer. Press and hold the 1 button until you hear a tone. Use this
same procedure to set the second position by using the 2 button . You can
now use these controls to recall the set memory positions.
You can also program your memory seats to your transmitter. That way, when
you unlock your door with the transmitter, your memory features automatically
move into your saved position. See the Seats chapter in your Owner's Manual
for more details.
Moonroof*
You can open or close the sliding shade
manually after you close the moonroof.
Pull the shade toward the front of
the vehicle to close it. The moonroof
control is on the overhead console.
To open, press and release the SLIDE
control. The moonroof stops short
of the fully opened position. To fully
open the moonroof, press and release
the SLIDE control again. To close, pull and release the SLIDE control. Press and
release the TILT control to vent the moonroof. Pull and hold the TILT control to
close the moonroof.
Page 11
2017 NAVIGATOR
20 21
*if equipped
Function
Rear View Camera
The rear view camera system is on the liftgate and provides a video image of the area behind
the vehicle. The display automatically appears whenever the vehicle is in reverse (R) and uses
colored guidelines (green, yellow and red) to indicate distance. Objects in the red zone are the
closest to your vehicle objects in the green zone are farther away.
Front and Rear Parking Aids
These systems warn you if there is an object in front of or behind the vehicle. The rear sensors
are active only when the transmission is in reverse (R). The front sensors are active when the
gearshift is in any position other than park (P) and the vehicle speed is below 8 mph (13 km/h).
As the vehicle moves closer to the obstacle, the rate of the audible warning increases.
Note: Visibility aids do not replace the need to watch where the vehicle is moving. Refer to
your Owner’s Manual for safety information, more details and limitations.
Ambient Lighting*
When activated, ambient lighting illuminates key areas of your interior with a choice of colors.
To access and make adjustments, use your touchscreen:
1. Press the Settings icon > Ambient Lighting (on the second page).
2. Touch the desired color.
3. Move the color up or down to increase or decrease the color intensity.
To switch the feature on or o, touch the selected color again.
Daytime Running Lamps*
The LED lights automatically turn on when you switch on the ignition and the headlamp control
is in the off , parking lamps or autolamps* positions.
*if equipped
20
Essential Features
Capless Fuel System
When fueling your vehicle:
1. Put your vehicle in park (P) and
switch the ignition off.
2. Open the fuel filler door.
3. Slowly insert the fuel filler nozzle
fully into the fuel system, and
leave the nozzle fully inserted
until you are done pumping.
4. Wait at least 10 seconds before removing
the fuel pump nozzle to allow any residual
fuel to drain into the fuel tank.
When refueling the vehicle fuel tank from a
fuel container, use the plastic funnel located
in the spare wheel storage tray. Clean the
funnel or properly dispose of it.
Note: Do not use aftermarket funnels, as they do not work
with the capless fuel system and may cause damage. You
can purchase extra funnels from an authorized dealer if you
choose to dispose of the funnel.
Drive Control
This feature intelligently integrates chassis and powertrain
systems for personalized ride comfort, steering, handling,
powertrain response and sound. Choose between two
default settings or customize your own.
Factory default settings include Normal Handling and
Normal Performance while you are in drive (D). Select sport
(S) to engage Sport Handling and Sport
Performance settings.
Customize your Handling and Performance settings
through the information display by navigating through the
information display menu to Settings, Vehicle and then Drive
Control to configure:
Handling
Comfort: Provides lower steering efforts and a more
fluid suspension.
Normal: Delivers an engaging drive experience with
confident handling.
Sport: Increases handling and control with a sporty feel.
Performance
Normal: Provides smooth power delivery and a
refined sound.
Sport: Increases engine and transmission
responsiveness while adding a more powerful
engine tone.
21
Page 12
2017 NAVIGATOR
22 23
Basic Commands
Main menu
Go back
Cancel
List of commands
Next page
Previous page
Help
Apps
List mobile apps
Find new apps
Phone
Phone list of commands
Pair phone
Call <name> <on cell/
at home/at work>
Dial <number>
Listen to message
Climate
Climate list of commands
Climate set temperature to
<# degrees>
Audio
AM <530-1710>
FM <87.9-107.9>
CD
USB
Sirius <0-233>
<Sirius channel name>
Bluetooth audio
Help
Navigation*
Navigation list of commands
Destination
<home/previous destination>
Find
<POI/an address/intersection>
Show route
Where am I?
SiriusXM Trac and Travel Link*
list of commands
• Show <trac/weather map/
5 day forecast/fuel prices>
• Help
Some services may not be available in your area. For more complete information on SYNC, refer to your SYNC Supplement, visit the website or call the toll-free
number. For U.S. customers, visit owner.lincoln.com or call 1-800-521-4140 (select Option 1 or 2 for language, then Option 3). For Canadian customers, visit
syncmyride.ca or call 1-800-387-9333 (select Option 1 or 2 for language, then Option 3).
Commonly Used SYNC® 3 Voice Commands SYNC.® Say the Word.
Press the voice button on the right-hand side of your steering wheel and then say:
*if equipped
BLIS® (Blind Spot Information System)
and Cross Traffic Alert
BLIS uses radar sensors to help you determine if a
vehicle may be in your blind spot zone. The cross
traffic alert feature alerts you if a car is coming
toward you when you back out of a parking space.
BLIS and cross traffic alert display an amber indicator
light in your exterior mirrors. Cross traffic alert also
sounds tones and displays messages to warn you
which direction vehicles are approaching. See the
Driving Aids chapter in your Owner’s Manual for
more information.
Tire Pressure Monitoring System
Your vehicle comes with a Tire Pressure Monitoring
System (TPMS) that displays a low tire pressure
warning light when one or more of your tires are
significantly under-inflated. If this happens, stop and
check your tires as soon as possible. Inflate them to
the proper pressure. Refer to the Wheels and Tires
chapter of your Owner’s Manual for
more information.
Fuel Type and Fuel Tank Capacity
Your Navigator's fuel tank capacity is
28 gallons (106L). Navigator L models have
a fuel tank capacity of 33.5 gallons (126.8L).
We recommend regular unleaded gasoline with
a minimum pump (R+M)/2 octane rating of 87.
To provide improved performance, we recommend
premium fuel for severe duty usage such as trailer
towing. Do not use E85 (ethanol), diesel,
fuel-methanol, leaded fuel or any other fuel
because it could damage or impair the
emission control system.
Location of Spare Tire and Tools
The temporary spare tire is under the vehicle, in
front of the rear bumper. Use it only for emergency
use and replace it as soon as possible. The jack
and tools are under the access panel in the floor
compartment behind the rear seat. Make sure
you switch off the power running boards* prior
to jacking, hoisting or towing your vehicle. Refer
to your Owner’s Manual for more information.
Essential Features (cont.)
Loading...
