Page 1
Quick Reference Guide
2014 NAVIGATOR
This Quick Reference Guide is not
intended to replace your vehicle
Owner’s Manual which contains more
detailed information concerning the
features of your vehicle, as well as
important safety warnings designed
to help reduce the risk of injury to you
and your passengers. Please read
your entire Owner’s Manual carefully
as you begin learning about your new
vehicle and refer to the appropriate
chapters when questions arise. All
information contained in this Quick
Reference Guide was accurate at the
time of duplication. We reserve the
right to change features, operation
and/or functionality of any vehicle
specification at any time. Your Lincoln
dealer is the best source for the most
current information. For detailed
operating and safety information,
please consult your Owner’s Manual.
Lincoln Navigator
March 2014
Second Printing
Quick Reference Guide
Litho in USA
EL7J 19G217 AA
United States
Lincoln Customer Relationship Center
1-800-521-4140
(TDD for the hearing impaired 1-800-232-5952)
lincolnowner.com
Canada
Lincoln Customer Relationship Centre
1-800-387-9333
lincolncanada.com
WARNING
Driving while distracted can result in loss of vehicle control, crash and
injury. We strongly recommend that you use extreme caution when
using any device that may take your focus off the road. Your primary
responsibility is the safe operation of your vehicle. We recommend
against the use of any hand-held device while driving and encourage
the use of voice-operated systems when possible. Make sure you are
aware of all applicable local laws that may affect the use of electronic
devices while driving.
Page 2
2014 NAVIGATOR
2 3
Basic Commands
What can I say?
List of commands
Main menu
Previous
Next
Go back
Exit
Help
Vehicle health*
Pair my phone
Phone
Phone list of commands
• Dial
• Call <name> on cell/
at home/at work
• Call voicemail
•Donotdisturb<On/O>
• Listen to text messages
(phone-dependent feature)
Entertainment
Audio list of commands:
You can also get detailed
lists of commands for radio,
USB, Bluetooth® audio,
SiriusXM and SD card
Audio<On/O>
Radio
• FM <87.9-107.9>
• FM preset <#>
CD
• Play track <1-512>
•Shue<On/O>
USB
• Play song <name>
• Play album <name>
SiriusXM
• <Channel name>
• Preset <#>
SYNC Services*
Mustsay“Services”rst,
and then
What can I say?
Trac
Directions
Business search
Operator (for direction or
business search)
Favorites
News, sports, weather,
horoscopes, stock quotes,
movies or travel
Help
Table of Contents
Instrument Panel ........................... 4 – 5
Vehicle Stability ............................. 6 – 7
SYNC .............................................. 8 – 9
Convenience ....................................... 10
Comfort ............................................... 11
Essential Information ................. 12 – 13
Function ...................................... 14 – 15
lincolncanada.com
LEARN MORE ABOUT YOUR NEW NAVIGATOR
Scan the country-appropriate QR code with your smartphone
(make sure you have a scanner app installed), and you can
access even more information about your vehicle.
Some services may not be available in your area. For additional support, refer to your Owner’s Manual, visit the website or call the toll-free number.
U.S. customers: Visit SyncMyRide.com or call 1-800-392-3673 (select Option 1 or 2 for language, then press 3). Canadian customers: Visit
SyncMyRide.ca or call 1-800-565-3673 (select Option 1 or 2 for language, then press 3).
lincolnowner.com
*if equipped
Commonly Used Voice Commands SYNC.® Say the Word.
Touch the voice button on the right-hand side of your steering wheel and then say:
Page 3
2014 NAVIGATOR
4 5
1 Lighting Control
Switches the headlamps on.
Switches the headlamps off.
Switches on the parking lamps.
Autolamps: Automatically turns the
exterior lamps on or off based on
available daylight.
Switches on fog lamps when you pull the
control toward you. You can switch the
fog lamps on when the ignition is on, the
lighting control knob is in any position
other than the off position and you do not
switch the high beams on.
2 Parking Brake
3 Windshield Wipers and Washers
Rotate the end of the control lever away
from you or toward you to increase or
decrease the speed of the wipers.
To use the washer feature, push the end
of the lever:
Quickly for a single swipe without fluid.
Hold briefly for three swipes with
washer fluid.
Hold for a longer wash cycle.
To operate your rear window wiper:
Rotate the rear wiper control to 1 (slower
intermittent speed), 2 (faster intermittent
speed) or 0 (off). For a rear wash cycle,
rotate and hold the
control to either
the top or bottom position to activate the
rear washer. The control will return to the
2 or 0 position when you release it.
Note: For optimal wiper performance, clean
your blades and glass regularly. Refer to
your Owner’s Manual for more information.
4 Cruise Control
To set the speed:
A. Press and release ON.
B. Accelerate to the desired speed.
C. Press SET+ and take your foot
off the accelerator.
To set a higher or lower speed, press
and hold SET+ or SET– until you reach
the desired speed. Additionally, you
can press and release either button to
change your set speed in approximately
1 mph (2 km/h) increments.
To cancel a set speed, tap the brake
pedal. The set speed will not be erased.
To return to a previously set speed,
press RESUME.
To switch off, press OFF or switch off
the ignition.
5 Information Display
Shows important vehicle information
through a constant monitor of vehicle
systems. The display will notify you of
potential vehicle problems by showing
system warnings followed by a long
indicator tone. For more details about
your information display functions,
please see your Owner’s Manual.
6 Service Engine Soon Light
Lights briefly when you switch
the ignition on. If it remains on or blinks
after you start the engine, the On-Board
Diagnostics (OBD-II) system has detected
a malfunction. Drive in a moderate fashion
(avoid heavy acceleration and deceleration)
and contact an authorized dealer as soon
as possible.
7 Hazard Control
4
Instrument Panel
Page 4
2014 NAVIGATOR
6 7
*if equipped
Overdrive Control with Tow/Haul Feature
The tow/haul feature improves transmission operation when towing a trailer or a heavy load. To
activate tow/haul, press the button on the side of the gearshift lever. The TOW HAUL indicator light
will illuminate in the instrument cluster. To deactivate, press the button again. Drive with the vehicle in
overdrive(D)withtow/hauloforthebestfueleconomy.RefertotheTransmission chapter of your
Owner’s Manual for more information.
Control Trac® Four-Wheel-Drive (4WD) System*
4X2 (2WD):
Delivers power to the rear wheels only. This is appropriate for normal, on-road driving on
dry pavement.
4X4 AUTO: Provides electronic control four-wheel drive with power delivered to all four wheels, as required, for increased traction.
The information display will show “4X4 AUTO” when this position is selected. This mode is appropriate for all on-road driving conditions,
such as dry road surfaces, wet pavement, snow or gravel.
4X4: Provides electronically locked four-wheel drive power to all four wheels. The information display will show “4X4” when you select
thismode.4x4modeisnotrecommendedforuseondrypavement.Itisonlyintendedforseverewinteroro-roadconditions,suchas
deep snow, ice or shallow sand. Refer to the Using Four-Wheel Drive (4WD) chapter in your Owner’s Manual for more information
including shifting instructions.
AdvanceTrac® with RSC® (Roll Stability ControlTM)
Helps you keep control of your vehicle when on a slippery surface. The electronic stability control portion of the system helps avoid skids and
lateral slides, and roll stability control helps avoid a vehicle rollover. The traction control system helps avoid drive wheel spin and loss
of traction. Refer to the Stability Control chapter in your Owner’s Manual for safety information and more details.
Trailer Sway Control*
This feature applies your vehicle brakes at individual wheels and, if necessary, reduces engine power. If the trailer begins to sway, the stability
controllightashesandthemessageTRAILER SWAY REDUCE SPEEDappearsintheinformationdisplay.Therststeptodoisslowdownyour
vehicle, then pull safely to the side of the road and check for proper tongue load and trailer load distribution. See the Load Carrying chapter in
your Owner's Manualforspecicloadinginformation.
Vehicle Stability
Page 5
2014 NAVIGATOR
8 9
Tips
Make sure you accep t the request from
SYNC to access your phone.
To pair subseq uent phones or to learn
more about your SYNC system, please
refer to Pairing Subsequent Phones in the
SYNC chapter of your O wner’s Manual.
Using Your Phone with SY NC
Note: You must downl oad your phone book
to make phone cal ls with voice command s
by name.
Making a Phone C all
Use SYNC to make a phone cal l to anyone
in your phone b ook by pressing the voi ce
button an d when prompted, give a
voice command.
For example, yo u could say “Call Jake Smith
at home”.Whenthesystemco nrmsthe
number, say “Dial” ag ain to initiate the ca ll.
Note: You can also make ph one calls
by pressing t he voice button
. When
prompted, gi ve the voice command “ Dial”,
then verbal ly say the phone numbe r.
Answering Incoming Calls
Whenever you ha ve an incoming call, you
will be able to s ee the name and number of
the person c alling in your displa y. Press the
phone button
to answer an inc oming
call. You can hang up a t any time by
pressing and h olding the phone bu tton
.
Do Not Distur b Mode
This feature bl ocks incoming call s and text
messages , and saves them for later. You
still have ac cess to outgoing call s when this
feature is ac tive. Say the voice comm and
“Do not dist urb on” to enable and “Do no t
disturb o ” to disable.
Using SYNC to Acce ss Digital Media
SYNC has a media hub w ith multiple inp uts
allowing you t o access personal med ia from
your digital devices. Plug in your USB media
devices such a s phones and MP3 players,
and use SYNC to play a ll of your favorite
music. SYNC indexes all of yo ur music.
The more music s tored on your device, th e
longer it ta kes SYNC to index.
Using Voice Comman ds to Play Music
1. Plug your media player i nto your
USB port.
2. P ress the voice butto n
. When
prompted, sa y “USB”, then follow-up
saying one of t he following
voice commands.
SYNC AppLinkTM*
SYNC AppLink allows voic e access to
select mob ile application s that you already
have or can down load to your Android
TM
,
BlackBerry® or iPhone®.
Current apps available include Pandora
Internet Rad io®, Stitcher Smar t Radio
TM
,
Open Beak (BlackBerry exclusive),
iHeart Radio, Slacker, NPR News a nd
SYNC Destinations and more.
For more information on SYNC, visit the
website or call the toll-free number. See the
inside front cover of this guide for details.
SYNC®
Getting Started with Your SYNC System
SYNC is a hands-free, voice recognition system used
for entertainment, information and communication.
SYNC. Say the Word.
General Tips
Press RETURN to exit a menu.
For additional support, refer to your Owner’s Manual, visit the
website or call the toll-free number. See the inside front cover
of this guide for details.
Before You Get Started
1. Set up your owner account by visiting SyncMyRide.com (U.S.)
or SyncMyRide.ca (Canada). Follow the on-screen instructions.
Note: Your account gives you even more SYNC capabilities,
including personalization features and software updates.
2. SYNC uses a wireless connection called
Bluetooth® to
communicate with your phone. Turn Bluetooth mode on in
yourphone'smenuoptions.ThisletsyourphonendSYNC.
For more details on setting up your phone with SYNC, visit
SyncMyRide.com (U.S.), SyncMyRide.ca (Canada) or your
phone manufacturer’s website.
*if equipped
Pairing Your Phone with SYNC
First-time pairing lets you use
the many featu res of SYNC.
1. Make sure that your vehicle
is in park (P) and you switch
your ignition and radio on.
2. Press the phone button
on your steering wheel or
the Phone button on your
audio controls. When the
No phone paired message
displays on the screen, press
Settings, then press Add to
add your cellular phone.
3. Make sure that you switch
Bluetooth on and your
cellular phone is in the
proper mode. Refer to
your phone’s user guide,
if necessary.
4. Find SYNC will appear on
the touchscreen, indicating
that it is trying to pair with
your cellular phone. When
thesystemndsyourphone,
your touchscreen will display
a six-digit PIN.
5. When prompted on your
cellular phone’s display,
enter the six-digit PIN
provided by SYNC into
your cellular phone.
6. The display indicates when
the pairing is successful.
Note: The system may prompt
you to:
Set your phone as the
primary or favorite (the
primary phone will
receive messages
and voicemail).
Download your phone
book (a requirement
to use the full set of
voice commands).
Switch on 911 Assist®.
Page 6
2014 NAVIGATOR
10 11
Second-Row Heated Seats
The rear heated seat controls are
on the rear of the center console.
Press for maximum heat
or for minimum heat.
Press again to switch off.
Note: The heated seats reset at
every ignition run cycle. They will
turn off automatically when you
switch off the engine.
Memory Seat Feature
The memory function will save
and recall the positions of the
driver seat, power mirrors,
adjustable pedals and steering
column. Use the control located
on the side of the driver’s seat
to program and then
recall saved memory positions.
To program position 1, switch the
ignition on. Move the memory
features to your preferred
position. Press and hold the
1 button for about two
seconds until you hear a tone.
Use this same procedure to set
the second position by using the
2 button . You can now use
these controls to recall the set
memory positions.
Auto-Leveling Suspension*
The system helps keep the rear
of your vehicle at a constant
level, thanks to a hydraulic pump
inside of each rear shock. The
feature helps improve ride,
handling and general vehicle
performance during certain road
conditions, steering maneuvers,
braking and acceleration, and
towing. See the Driving Aids
section of your Owner's Manual
for details.
Convenience
Autowipers
If you switch on this feature, your
wipers will automatically turn on
when moisture is present on the
windshield. The wiper speed
will vary based on the amount
of moisture detected on the
windshield and the sensitivity
setting. The wipers will continue
to wipe as long as moisture is
detected. To deactivate, turn
your wiper controls off.
Note: Make sure you switch this
feature off before entering a
car wash.
MyKey®
MyKey allows you to program
certain driving restrictions in
order to promote good driving
habits. You can set speed
restrictions and limit volume
levels. For complete information,
refer to the MyKey chapter in
your Owner’s Manual.
Power Liftgate
Press on the instrument
panel to open or close the power
liftgate. For added convenience,
there are three more ways
to activate your power
liftgate’s capabilities:
1. On your remote entry
transmitter, press twice
within three seconds to open
or close your power liftgate.
2. To open using the liftgate
control button in the liftgate
handle: Unlock the doors
using either the remote entry
transmitter or the power door
unlock control, and press
the control.
3. To close using the rear
cargo area button: Press and
release the
control
located on the left rear
quarter panel. This button is
automatically disabled when
the liftgate is latched.
Note: Keep clear of the liftgate
when operating the rear switch.
Your power liftgate is equipped
with an obstacle detection
feature which will either stop or
revert to a full open position if
it encounters a solid object. For
complete information, see the
Liftgate section within the Locks
chapter of your Owner’s Manual.
Power-Adjustable
Foot Pedals
Located to the left of your
steering column, your poweradjustable pedal control lets you
move your brake and accelerator
pedals closer. Press the
arrow
to move the pedals closer to
you or the arrow to move
the pedals further away from
you. The pedals should only be
adjusted when the vehicle is
stopped and in park (P).
SecuriCodeTM Keyless
Entry Keypad
Lock or unlock the doors or
release the liftgate glass without
using a key. The keypad can be
operated with the factory-set,
5-digit entry code; this code is
located on the owner’s wallet
card in the glove box. You can
also create up to five of your own
5-digit personal entry codes. To
lock all of the doors and liftgate,
press and hold 7•8 and 9•0 at
the same time. For complete
information, refer to the Locks
chapter of your Owner’s Manual.
*if equipped
Comfort
PowerFold® Third-Row Seat*
60/40 split-folding bench seat
uses a power-activated seatback
release. Fold one side or both
down for more flexibility.
The controls are located on
the right-hand rear quarter trim
panel that is accessible from
the liftgate area.
Note: Make sure you unfasten all
safety belts before lowering seats.
To lower:
1. Make sure that the head
restraints are folded down first.
2. Press “FOLD” on the button.
3. To return the seatback to its
original position, press “UP”
on the button.
Note: The power-folding seats
will operate for 10 minutes after
the ignition switch is turned off.
The transmission must be in
park (P) and the liftgate or
liftgate glass must be open.
Front Climate Controlled Seats
Press the heated seat symbol
or the cooled seat symbol to
cycle through the various settings
and off. More indicator lights show
warmer or cooler settings.
Page 7
2014 NAVIGATOR
12 13
Fuel Type and Fuel Tank Capacity
Depending on your vehicle, your fuel tank
has a capacity of either 28 gallons (106L)
or 33.5 gallons (126.8L).
If your vehicle is a Flex Fuel vehicle, it will
have a yellow ring around the top of the
fuel filler inlet. It is designed to use only
E85 FUEL ETHANOL, UNLEADED FUEL
“Regular” unleaded gasoline or any mixture
of the two fuels. It is best not to alternate
repeatedly between gasoline and E85. If you
do switch fuels, it is recommended that you
add as much fuel as possible—at least half
a tank. If you use E85 fuel exclusively, it is
recommended to fill the fuel tank with regular
unleaded gasoline at each scheduled oil
change. See your Owner's Manual for more
specific information and E85 details.
Tire Pressure Monitoring System
Your vehicle is equipped with a Tire Pressure
Monitoring System (TPMS) that displays a
low tire pressure warning light when one
or more of your tires are significantly underinflated. If this happens, stop and check your
tires as soon as possible. Inflate them to the
proper pressure. Refer to the Inflating Your
Tires section in the Wheels and Tires chapter
of your Owner’s Manual for more information.
Location of Spare Tire and Tools
The temporary spare tire is located under
the vehicle, just forward of the rear bumper.
It is designed for emergency use only and
should be replaced as soon as possible. The
jack and tools are under the access panel in
the floor compartment behind the rear seat.
Make sure you switch the deployable running
boards* off prior to jacking, hoisting or towing
your vehicle.
For complete details on how to change your
tire, refer to the Roadside Emergencies
chapter in your Owner’s Manual.
Roadside Assistance
Your new Lincoln Navigator comes with
the assurance and support of 24-hour
emergency roadside assistance. To
receive roadside assistance in the
United States, call 1-800-521-4140.
In Canada, call 1-800-387-9333.
SOS Post-Crash Alert System
TM
The system flashes the direction indicator
lamps and sounds the horn (intermittently) in
the event of a serious impact that deploys
an airbag.
The horn and lamps will turn off when:
You press the hazard control button in
your vehicle or the panic button* on
your keyless remote transmitter.
Your vehicle runs out of power.
Essential Information
Easy Fuel® System
Easy Fuel system is self sealing and
therefore protected against dust, dirt,
water, snow and ice. This type of fuel
system is capless. A locking plug, as
shown, is available. To refill your fuel
tank, open the fuel filler door by pulling
the indent on the door, insert the nozzle
and start fueling. Wait 10 seconds from the time the refueling nozzle
is shut off until you remove the nozzle from the vehicle to allow
residual fuel in the nozzle to drain into the tank. If you need to fill
your fuel tank with a portable fuel container, use the fuel funnel
which is included with the tire changing tools. Slowly insert the
funnel into the Easy Fuel system and fill the tank with fuel from the
container. When done, clean the funnel or properly dispose of it.
Extra funnels can be purchased from your authorized dealer. Do
not use aftermarket funnels as they will not work with the Easy Fuel
system and may cause damage.
Fuel-Efficient Transmission
Your vehicle has been designed to improve fuel economy by
reducing fuel usage while coasting or decelerating. This may be
perceived as a light to medium braking sensation when removing
your foot from the accelerator pedal.
*if equipped
Page 8
2014 NAVIGATOR
14 15
Function
Navigation System*
Set your destination by using your touchscreen or voice commands.
To Program a Destination Using the Touchscreen
1. Press the DEST button and “Accept” when the “Terms of Use”
screen appears.
2. Select from the following:
a. Quick: Allows you to access emergency destinations (such as
police stations or hospitals), save your favorite destinations to
presetsforquickaccess,ndthenearestpointofinterest(POI),
recall a previous destination or entry from your address book to
set as a current destination, or cancel your route.
b. Standard: Allows you to set a destination using any
of the following:
i. Address Book
ii. Previous Destination
iii. Phone Number
iv. Map
v. Street Address
vi. Point of Interest
vii. Freeway Exit/Entrance
viii. Intersection
c. Edit Route: Allows you to make any adjustments to
the currently selected navigation route such as:
i. Cancel Route
ii. Detour
iii. View Route
iv. Edit Route Preferences
v. EditTracPreferences
vi. Edit Destination/Way Points
vii. Edit Turn List
Note: Periodic map updates are available at an additional cost.
Call 1-800-NAVMAPS (in Mexico, call 01-800-557-5539) or
visit www.navigation.com/ford.
14
*if equipped
Rear View Camera*
The rear view camera system is on the liftgate and provides a video image
of the area behind the vehicle. The display will automatically appear on the
navigation system screen* or in the interior mirror whenever the vehicle is in
reverse (R) and uses colored guidelines (green, yellow and red) to indicate
distance. Objects in the red zone are the closest to your vehicle while objects
in the green zone are further away.
Forward and Reverse Sensing Systems
The systems may warn you if there is an object in front of or behind the vehicle.
The system will sound a warning tone that increases in frequency as the object
gets closer and will sound continuously when the object is less than 10 inches
(25 centimeters) away.
Note: Visibility aids do not replace the need to watch where the vehicle is
moving. Refer to your Owner’s Manual for safety information, more details
and limitations.
Moonroof*
The sliding shade can be manually opened or closed when the moonroof is
closed. Pull the shade toward the front of the vehicle to close it. The moonroof
control is located on the overhead console. To open, press and release the
SLIDE control. The moonroof will stop short of the fully opened position. To fully
open the moonroof, press and release the SLIDE control again. To close, pull
and release the SLIDE control. Press and release the TILT control to vent the
moonroof. Pull and hold the TILT control to close the moonroof.
*if equipped
14
Loading...
