Lincoln 1116-080-A, 1132-080-A, 1133-08H-A, 1161-080-A, 1130-08H-A User Manual

...

SERVICE MANUAL

(DOMESTIC)

IMPINGER CONVEYOR OVENS

MODEL 1116-080-A, 1116-080-A1, 1117-080-A, 1117-080-A1, 1130-080-A, 1130-080-A1, 1131-080-A, 1131-080-A1, 1132-080-A, 1132-080-A1, 1133-080-A, 1132-080-A1,

1130-08H-A, 1131-08H-A, 1132-08H-A, 1133-08H-A,

1161-080-A, 1162-080-A

WITH PUSH BUTTON CONTROLS

Lincoln Foodservice Products, LLC

1111 North Hadley Road

Fort Wayne, Indiana 46804

United States of America

Phone : (800) 374-3004

U.S. Fax: (888) 790-8193 • Int’l Fax: (260) 436-0735

Technical Service Hot Line

(800) 678-9511

www.lincolnfp.com

Imp2DigAdvServ REV 3/20/08

SEQUENCE OF OPERATION

IMPINGER II ADVANTAGE, GAS

(OVENS WITH PUSH BUTTON CONTROLS)

MODEL 1116-080-A NAT. GAS 120VAC 60 HZ. 1 PHASE MODEL 1116-080-A1 NAT. GAS 120VAC 60 HZ. 1 PHASE MODEL 1117-080-A LP GAS 120VAC 60 HZ. 1 PHASE MODEL 1117-080-A1 LP GAS 120VAC 60 HZ. 1 PHASE

POWER SUPPLY Electrical power is supplied to the oven by a three-conductor cordset. Voltage

from the black conductor to the white conductor is 120VAC. Black conductor is hot White conductor is neutral.

Green conductor is ground. CONTROL BOX AUTO COOL DOWN

MAIN FAN CIRCUIT Power is permanently supplied, through a 10 amp fuse, to the normally open

BURNER CIRCUIT Closing the main power switch supplies 120VAC to the burner blowe r motor.

IGNITION CONTROL The ignition control operates on both 24VAC and 120VAC. When the control is

TEMPERATURE CONTROL Closing the main power switch supplies 120VAC to the primary of the oven

CONVEYOR DRIVE Closing the main power switch supplies 120VAC to the conveyor motor and to

When the temperature in the control box reaches 120°F ± 3° (48.9°C ± 1.7°), the

cooling fan thermostat will switch power to the control box cooling fans. The

thermostat will interrupt power to the cooling fans when the control box

temperature falls to 100°F ± 3° (37.8°C ± 1.7°).

main power switch. Power is also supplied to the normally open cooling fan

thermostat. Closing the main power switch supplies 120VAC to the main fan

motor, the cooling fan motors, the primary of the control transformer, the

conveyor motor and to the ignition control.

120VAC is also supplied, through the main fan centrifugal switch (this switch

closes when the main fan reaches approx. 1600 RPM) and the normally closed

oven cavity hi-limit thermostat, to the primary of the burner transformer. 120VAC

is also supplied to the oven control.

energized by 24VAC from the transformer, 120VAC is switched by the ignition

control to the hot surface igniter for 45 seconds for the hot surface igniter warm

up. The igniter glows red, 24VAC is switched to the gas valve, which opens, and

ignition should now occur.

control transformer. Secondary voltage, 24VAC, is supplied to the oven control.

The oven control is set to desired temperature. The thermocouple will provide

varying millivolts to the oven control. The oven control supplies 120VAC to the

temperature regulation valve at intermittent intervals to maintain the desired

temperature. The display on the oven control will indicate when the temperature

regulation valve is energized.

NOTE: The display also indicates oven temperature.

the primary of the control transformer. Secondary voltage, 24VAC, is supplied to

the oven control. Setting the oven control to the desired time outputs voltage,

through a reversing switch, to the conveyor motor.

NOTE: The conveyor system uses a hall effect sensor and magnet to prove

operation of the conveyor motor. If the conveyor motor is not running, “BELT

JAM” is indicated on the display.

Impinger II – Advantage Digital Express Service Manual - Domestic

SEQUENCE OF OPERATION

IMPINGER II ADVANTAGE, ELECTRIC

(OVENS WITH PUSH BUTTON CONTROLS)

1130-080-A 120/208VAC 60 HZ. 1 PHASE 1130-080-A1 120/208VAC 60 HZ. 1 PHASE 1130-08H-A 208 VAC 60 HZ. 1 PHASE 1131-080-A 120/240VAC 60 HZ. 1 PHASE 1131-080-A1 120/240VAC 60 HZ. 1 PHASE 1131-08H-A 240 VAC 60 HZ. 1 PHASE 1132-080-A 120/208VAC 60 HZ. 3 PHASE 1132-080-A1 120/208VAC 60 HZ. 3 PHASE 1132-08H-A 208 VAC 60 HZ. 3 PHASE 1133-080-A 120/240VAC 60 HZ. 3 PHASE 1133-080-A1 120/240VAC 60 HZ. 3 PHASE 1133-08H-A 240 VAC 60 HZ. 3 PHASE 1161-080-A 120/240VAC 60 HZ. 1 PHASE 1162-080-A 120/208VAC 60 HZ. 3 PHASE

POWER SUPPLY Electrical power to be supplied to the oven by a three conductor service for

single phase and a four conductor service for three phase. Black conductor is hot. Red conductor is hot. Orange conductor is hot (used for three phase only). White conductor is neutral.

Green conductor is ground. CONTROL BOX AUTO COOL DOWN

MAIN FAN CIRCUIT Power is permanently supplied through the 10 amp fuses, through the normally

TEMPERATURE CONTROL Closing the main power switch supplies 208/240VAC to the primary of the

CONVEYOR DRIVE Closing the main power switch supplies 208/240VAC to the conveyor motor and

AUTOMATIC COOL DOWN When the oven is started, the time delay relay timing circuit is enabled,

When the temperature in the control box reaches 120°F ± 3° (48.9°C ± 1.7°), the

cooling fan thermostat will switch power to the control box cooling fans. The

thermostat will interrupt power to the cooling fans when the control box

temperature falls to 100°F ± 3° (37.8°C ± 1.7°).

closed oven cavity hi-limit thermostat, to the normally open main power switch.

Power is also supplied to the normally open cooling fan thermostat. Closing the

main power switch energizes the coil of the oven start relay, it’s contacts close

enabling the 20 minute time delay relay. The 20 minute time delay relay supplies

120VAC to the oven fan relay, these normally open contacts now close

supplying 208/240VAC to the main fan motor. 120VAC is also supplied to the

cooling fans. 208/240VAC is supplied to the primary of the control transformer,

the conveyor motor and, through the air pressure switch, to the oven control.

control transformer. Secondary voltage, 24VAC, is supplied to the oven control.

The oven control is set to desired temperature. The thermocouple will provide

varying millivolts to the oven control. The oven control supplies 208/240VAC to

the coil of the heater relay at intermittent intervals to maintain the desired

temperature. The display on the oven control will indicate when the heater relay

is energized.

NOTE: The display also indicates oven temperature.

to the primary of the control transformer. Secondary voltage, 24VAC, is supplied

to the oven control. Setting the oven control to the desired time outputs voltage,

through a reversing switch, to the conveyor motor.

NOTE: The conveyor system uses a hall effect sensor and magnet to prove

operation of the conveyor motor. If the conveyor motor is not running, “BELT

JAM” is indicated on the display.

permitting the oven fans to run approximately 20 minutes after the oven is shut

off, to cool the oven. The time delay relay will keep the coil of the fan relay

closed, maintaining operation of the main fan and cooling fans.

Impinger II – Advantage Digital Express Service Manual - Domestic

SCHEMATIC DIAGRAM

MODEL 1116-080-A, 1116-080-A1, 1117-080-A, 1117-080-A1

Impinger II – Advantage Digital Express Service Manual - Domestic

SCHEMATIC DIAGRAM

MODEL 1130-080-A, 1130-080-A1, 1131-080-A, 1131-080-A1

SCHEMATIC DIAGRAM

Impinger II – Advantage Digital Express Service Manual - Domestic

MODEL 1132-080-A, 1132-080-A1, 1133-080-A, 1133-080-A1

Impinger II – Advantage Digital Express Service Manual - Domestic

SCHEMATIC DIAGRAM

MODEL 1161-080-A

Impinger II – Advantage Digital Express Service Manual - Domestic

SCHEMATIC DIAGRAM

MODEL 1162-080-A

Impinger II – Advantage Digital Express Service Manual - Domestic

SCHEMATIC DIAGRAM

MODEL 1130-08H-A, 1131-08H-A

Impinger II – Advantage Digital Express Service Manual - Domestic

SCHEMATIC DIAGRAM

MODEL 1132-08H-A, 1133-08H-A

Impinger II – Advantage Digital Express Service Manual - Domestic

TROUBLESHOOTING GUIDE

GAS OVENS

MODEL 1116-080-A NAT. GAS 120VAC 60 HZ. MODEL 1116-080-A1 NAT. GAS 120VAC 60 HZ. MODEL 1117-080-A LP GAS 120VAC 60 HZ. MODEL 1117-080-A1 LP GAS 120VAC 60 HZ.

SYMPTOM POSSIBLE CAUSE EVALUATION Oven fan will not run Incoming power supply Check circuit breakers, reset if required. Check

power plug to be sure it is firmly in receptacle.

Measure incoming power, call power co. if needed. Fuse, 10 Amp Check, replace if necessary. Fuse holder Check, replace if necessary. Hi-limit thermostat,

control box

Switch, main power Check continuity between switch terminals. Replace Main fan motor Check for 120VAC at motor. If no voltage is present,

Capacitor Check for shorts or grounds.

No control box cooling Incoming power Check circuit breakers, reset if required. Check

Switch, main power Check continuity between switch terminals. Replace Cooling fan Check for 120VAC at cooling fan. If no voltage is

No automatic control box cooling

Cooling fan thermostat Check the cooling fan thermostat. (Thermostat

Cooling fan Check for 120VAC at cooling fan. If no voltage is

Oven will not heat Gas supply Check for adequate gas supply to oven. Manual gas shut off valve. Check to see that the manual gas shut off valve is

Main fan If not operating, refer to “Oven fan will not run”. Centrifugal switch of main fan

Incoming power supply Check circuit breakers, reset if required. Check

motor

Check for voltage on both sides of switch. Terminals

are normally closed. If open, reset and test oven for

proper operation. If thermostat will not hold, and

control box temperature is not exceeding 140°F

(60°C), replace thermostat.

switch as needed.

trace wiring back to main power switch.

WITH POWER OFF: Check for opens, shorts or

grounds. Turn fan blade to check for locked rotor.

WARNING: Capacitor has a stored charge,

discharge before testing.

power plug to be sure it is firmly in receptacle.

Measure incoming power, call power co. if needed.

switch as needed.

present, trace wiring back to power switch. If voltage

is present, and motor does not run, check for opens,

shorts or grounds.

WITH POWER OFF: Check for locked rotor.

power plug to be sure it is firmly in receptacle.

Measure incoming power, call power co. if needed.

closes at 120°F and opens at 100°F). With the

cooling fan thermostat pre-heated, check for

continuity. If switch is open, replace cooling fan

thermostat.

present, trace wiring back to cooling fan thermostat.

If voltage is present, and motor does not run, check

for opens, shorts or grounds.

WITH POWER OFF: Check for locked rotor.

open. Also check flexible gas line connection for any

damage.

Check for 120VAC at wire #5 (input to centrifugal

switch, located at 6-pin connector in raceway near

Impinger II – Advantage Digital Express Service Manual - Domestic

the main fan motor) to neutral. If no voltage is

present, trace wiring back to the main power switch.

If voltage is present, check for 120VAC at wire #22

(output of centrifugal switch) to neutral. If no voltage

is present at #22, and the motor is running, replace

the main fan motor. Hi-limit thermostat,

oven cavity

Terminals are normally closed. If open, reset

thermostat and retest. If thermostat will not hold for

maximum oven temperature, and oven is not

exceeding temperature setting, check for proper

location of capillary bulb in its spring holder. If the

capillary checks okay, replace the hi-limit thermostat. Burner blower motor Check for 120VAC supplied to burner blower motor

at wire #13 to neutral. If no voltage is present, trace

wiring back to the main power switch. If voltage is

present, and the motor is not running, check for

opens, shorts or grounds.

WITH POWER OFF: Turn motor to check for locked

rotor. Burner transformer Check for 120VAC supplied to the primary of the

burner transformer. If no voltage is present, trace

wiring back to the oven cavity hi-limit thermostat. If

voltage is present, check for 24VAC at transformer

secondary. If there is primary voltage but no

secondary voltage, replace burner transformer. Centrifugal switch of burner

blower motor

Check for 24VAC at motor connector, wire #13 to

neutral. If voltage is not present, trace wiring back to

transformer. If voltage is present, check for voltage at

wire #14 to neutral. If no voltage is present at wire

#14, and motor is running, replace burner blower

motor. Ignition control Check for 24VAC at ignition control terminals marked

“24V”, if no voltage is present, trace wiring back to

centrifugal switch. Check for 120VAC to ignition

control at terminal “L1” to neutral. If no voltage is

present, trace wiring back to main power switch.

When 24VAC is supplied to the ignition control, the

ignition control switches 120VAC to the hot surface

igniter If 24VAC and 120VAC are supplied to ignition

control, but there is no voltage at the hot surface

igniter, replace the ignition control. Hot surface igniter If 120VAC is present at hot surface igniter terminals,

visually check to see that the igniter is heating

(igniter may be viewed through the port in the end of

burner tube). The igniter should glow bright red. If the

igniter does not heat, replace the hot surface igniter. Ignition control After 45 seconds of hot surface igniter pre-heat, the

ignition control will switch 24VAC to the gas control

valves. Check for 24VAC output from ignition control

across terminals marked “valve” and “valve gnd”. If

no voltage is present, replace ignition control. Gas control valves When 24VAC is supplied to the gas control valves,

the valve should open. Check for gas pressure at the

manifold tap located just before the burner. If there is

no pressure, check the incoming gas supply to be

sure all manual valves are open and flexible gas

hose is properly connected. If gas is present, and the

gas control valve is energized, but there is no gas

pressure at the burner manifold, replace the gas

control valves. Flame will not stay lit Hot surface igniter Six seconds after the gas valve opens, ignition must

Impinger II – Advantage Digital Express Service Manual - Domestic

+ 28 hidden pages
