Assembly Instructions
Opus 800 Floor Stands
OA8991, OA8992 & OA8993
Fitting Instructions to Floor Stands
IS721
N1
AA
BB
CC
BB
DD
Opus 800 Floor Stand Assembly
Remove all protective packaging before assembling parts.
Please note these Chargrills are heavy, the small unit (OG8401) requires at least two
people to lift and the larger unit (OG8411) will require at least four people.
Fig. 1
Remove each leg from the appliance and discard. Fit plugs to the base of the appliance.
Secure the new adjustable feet to the lower
sub-frame as shown using nuts N1.
Note the hole positions to be used.
For floor stands with castors the braked castors
are fitted to the front and the plain castors to the
rear in the same manner as the adjustable feet. Fig. 2
Secure the sub-frame and lower shelf to the
columns as shown.
Note the radius of the shelf is to the front of
the appliance.
Radius
Sub frame holes (4) to front Fig. 3
IS721
Lower the appliance onto the columns.
Note manual handling assessment should
be observed.
Fig. 4
N1 – M10 Self-locking Nut placed inside of channel
See Fig. 2
AA – M10 Flat Washer
See Fig. 3
BB – M10 Shake Proof Washer
See Fig. 3
CC – M10 Cap Screw (Short)
See Fig. 3
DD – M10 Cap Screw (Long)
See Fig. 1
IS721
Part No.
Description
OA8991
OA8992
OA8993
LE37
Adjustable Leg
4 4 6
CA112
Swivel Castor Braked (Option)
2 2 -
CA113
Fived Castor (Option)
2 2 -
LE84
Tubular Column
4 4 6
FAS091
M10 Shake Proof Washer
8 8 12
FAS831
M10 Flat Washer
4 4 6
FAS509
M10 Self-Locking nut
4 4 6
FAS2017
M10 Cap Screw - Short
4 4 6
FAS409
M10 Cap Screw - Long
4 4 6
LP01
Tapered Plug
4 4 6
8711
Spanner 1 1
1
AK02
Allen Key
1 1 1
Assembly of Appliance to Floor Stand
Remove all protective coating from the appliance and floor stand shelf.
Remove loose parts to reduce weight, i.e. cooking grids, burner caps, splash backs etc.
Note: Manual handling assessment should be observed.
Remove the adjustable feet from the appliance.
Secure the tapered plugs to the base of the appliance.
Fit the new adjustable feet to the sub-frame.
Using the cap screws and washers provided screw the sub-frame through the lower shelf
to the columns, securing fully with the Allen key provided.
Place the appliance onto the assembled floor stand.
Replace the loose parts, i.e. cooking grids, splash backs etc.
Adjust the floor stand legs to level the appliance.
