Installation, Operating and Servicing
Instructions
Lynx 400 Heavy-Duty Contact Grill
GG1, GG1R, GG1P
IS 316 ECN 3607 Page 1 of 9
CONTENTS
Important Information
2
Warnings and Precautions
3
Technical Data
3
Checklist of Enclosures
3
Installation and Commissioning
3-4
Operating Instructions
5-6
Cleaning
6
Servicing, Maintenance and Component Replacement
7
Fault Finding
7
Spare Parts List
7
Accessories
8
Service Information and Guarantee
9
IMPORTANT INFORMATION
Read these instructions carefully before using this product, paying particular
attention to all sections that carry warning symbols, caution symbols and notices.
Ensure that these are understood at all times.
WARNING!
This symbol is used whenever there is a risk of personal injury.
CAUTION!
This symbol is used whenever there is a risk of damaging your Lincat product.
NOTE:
This symbol is used to provide additional information, hints and tips.
KEEP THIS MANUAL FOR FUTURE REFERENCE
IS 316 ECN 3607 Page 2 of 9
WARNINGS AND PRECAUTIONS
TECHNICAL DATA
Model
Height (mm)
Width (mm)
Depth (mm)
Weight (kg)
GG1, GG1R, GG1P
260 (580 open)
390
380
21.5
CHECK LIST OF ENCLOSURES
Warranty Card
Instructions Manual
Fat drawer
Scraper - (not GG1P)
INSTALLATION AND COMMISSIONING
This appliance must be installed, commissioned and serviced by a qualified person
in accordance with national and local regulations in force in the country of
installation.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person.
Ensure that the plug/socket is accessible at all times.
Strip plastic coating and clean the appliance before use.
During operation parts may become hot - avoid accidental contact.
Disconnect this appliance before servicing, maintenance or cleaning.
This appliance must be earthed.
An equipotential bonding terminal is provided to allow cross bonding with other
equipment.
If replacing the plug connect the terminals as follows:
Green and Yellow wire Earth E
Blue wire Neutral N
Brown wire Live L
IS 316 ECN 3607 Page 3 of 9
Install this appliance on a level surface ensuring all vents are unobstructed. Install
Model
kW
Amps
GG1, GG1R, GG1P
3.0
13.0
this appliance on a level surface ensuring all vents are unobstructed. Any
partitions, walls or furniture must be of non-combustible material. Minimum
distances A 100mm B 500mm – see Fig 1.
Fig 1
Power Rating
IS 316 ECN 3607 Page 4 of 9
OPERATING INSTRUCTIONS
Only qualified or trained personnel should use this appliance.
Fig 2
Connect the appliance to the electricity supply by means of the fitted plug and lead.
Consult Fig 2.
The green neon (C) illuminates to indicate power to the appliance.
Set the desired temperature on the control knob (A). The amber neon (B)
illuminates.
When the set temperature is reached, the amber neon extinguishes. The grill is
now ready for use. The amber neon will periodically illuminate with the element
cycle.
IS 316 ECN 3607 Page 5 of 9
Use the timer (D) to set an audible reminder. The timer does not control the hot
CLEANING
plates – to switch off the appliance, turn the control knob to ‘0’ and switch off at the
supply.
This appliance is fitted with a safety thermostat to cut off the power in the event of a
fault. If the green neon illuminates but the plates do not heat, reset the safety
thermostat by pressing the red button (F) on the rear panel indicated in Fig 3. The
grill must be cool before the safety thermostat can be reset.
Fig 3
Do not use a water jet or steam cleaner, and do not immerse this appliance.
Clean all panels with warm water and mild detergent, do not use abrasive
materials. Dry with a soft cloth.
Empty the fat drawer (Fig 2 – E) regularly.
IS 316 ECN 3607 Page 6 of 9
SERVICING, MAINTENANCE AND
COMPONENT REPLACEMENT
Part Number
Description
Used on
CO110
Adaptaflex lock nut
All
CO98
Adaptaflex conduit
CO99
Adaptaflex gland
EL123
Element - top
EL124
Element - bottom
FE10
Foot
GR63
Griddle plate - top
GG1
GR65
Griddle plate - bottom
GG1, GG1R
GR133
Griddle plate - top
GG1P, GG1R
GR135
Griddle plate - bottom
GG1P
HA56
Handle frame
All
HA63
Handle
KN240
Control knob
KN273
Timer knob
NE42
Amber neon
All
NE43
Green neon
PL202
Mains cable
SP36
LH Torsion spring
SP37
RH Torsion spring
TH46
Thermostat
TH63
Safety thermostat
TI38
Timer
FAULT FINDING
SPARE PARTS LIST
All servicing, maintenance and component replacement on these appliances should
be carried out by one of our recommended service engineers.
Please refer to the Service Helpdesk number on the final page of this manual.
IS 316 ECN 3607 Page 7 of 9
Part Number
Description
Used on
SS1
Sandwich spacer
GG1
OS1
Omelette spacer
GG1
CM01
Charmarker
All
ACCESSORIES
IS 316 ECN 3607 Page 8 of 9
Product code
All available on serial plate
Type number
Serial number
SERVICE INFORMATION
For help with the installation, maintenance and use of your Lincat equipment,
please contact our service department:
UK: 01522 875520
For non-UK customers, please contact your local Lincat dealer
All service work, other than routine cleaning should be carried out by one of our
authorised service agents. We cannot accept responsibility for work carried out by
other persons.
To ensure your service enquiry is handled as efficiently as possible, please tell us:
Brief details of the problem
Lincat reserve the right to carry out any work under warranty, given reasonable
access to the appliance, during normal working hours, Monday to Friday, 08:30 to
17:00.
GUARANTEE
This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is
in addition to, and does not diminish your statutory or legal rights.
The guarantee does not cover:
Accidental damage, misuse or use not in accordance with the manufacturer’s
instructions
Consumable items (such as filters, glass, bulbs, slot toaster elements and door
seals.)
Damage due to incorrect installation, modification, unauthorised service work or
damage due to scale, food debris build-up, etc.
The manufacturer disclaims any liability for incidental, or consequential damages.
Attendance is based on reasonable access to the appliance to allow the authorised
technician to carry out the warranty work.
Service calls to equipment under warranty will be carried out in accordance with the
conditions of sale. Unless otherwise specified, a maximum of 15 minutes of
administrative time, not spent directly carrying out servicing work, is provided for
within the warranty. Any requirement for staff attending the call to spend greater time
than 15 minutes due to administrative requirements, such as on health and safety risk
assessments, will be chargeable at the prevailing rate.
IS 316 ECN 3607 Page 9 of 9
