Lincat BA3-A004, BS4-A004, BS3-A004, BA4-A004, BA7-A005 Installation, Operating And Servicing Instruction

IS 221 ECN4315 Page 1 of 8

Installation, Operating and Servicing
Instructions

Silverlink 600 Electric Bains Marie
Dry Heat

BA3-A004, BS3-A004, BA4-A004,
BS4-A004, BA7-A005, BS7-A005,
BM3-A003, BM4-A003, BM6-A003,
BM7-A004, BM7X-A001

Wet Well
BS3W-A005, BS4W-A005, BS7W-A005,
BM3W-A005, BM4W-A005, BM6W-A005,
BM7W-A005, BM7XW-A001

Please make a note of your product details for
future use:

Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________

IS 221 ECN4315 Page 2 of 8

CONTENTS

Important Information

2

Warnings and Precautions

3

Technical Data

3

Checklist of Enclosures

4

Installation and Commissioning

4-5

Operating Instructions

5-6

Cleaning

6

Servicing, Maintenance and Component Replacement

6

Fault Finding

6

Spare Parts List

7

Service Information and Guarantee

8

IMPORTANT INFORMATION

Read these instructions carefully before using this product, paying particular
attention to all sections that carry warning symbols, caution symbols and notices.
Ensure that these are understood at all times.

WARNING!

This symbol is used whenever there is a risk of personal injury.

CAUTION!

This symbol is used whenever there is a risk of damaging your Lincat product.

NOTE:

This symbol is used to provide additional information, hints and tips.

KEEP THIS MANUAL FOR FUTURE REFERENCE

IS 221 ECN4315 Page 3 of 8

WARNINGS AND PRECAUTIONS

This appliance must be Installed, Commissioned and Serviced by a qualified
person in accordance with national and local regulations in force in the country of
installation.

If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person.

Ensure that the plug/socket is accessible at all times.

Strip plastic coating and clean the appliance before use.
During operation parts may become hot - avoid accidental burns.
Disconnect this appliance before servicing, maintenance or cleaning.

TECHNICAL DATA

Model

Height (mm)

Width (mm)

Depth (mm)

Weight (kg)

Dry Heat

BM3

290

300

600

10

BA3

290

300

600

12

BS3

324

300

600

12

BM4

290

450

600

12

BA4

290

450

600

15

BS4

324

450

600

15

BM6

290

600

600

14

BM7

290

750

600

16

BA7

290

750

600

21

BS7

324

750

600

21

Wet Well Heat

BM3W

290

300

600

10

BS3W

324

300

600

12

BM4W

290

450

600

14

BS4W

324

450

600

17

BM6W

290

600

600

17

BM7W

290

750

600

21

BS7W

324

750

600

26

IS 221 ECN4315 Page 4 of 8

CHECK LIST OF ENCLOSURES

Warranty Card

Instructions Manual

Drain Pipe (Wet Well models only)

INSTALLATION AND COMMISSIONING

This appliance must be earthed.

An equipotential bonding terminal is provided to allow cross bonding with other
equipment.

Fig 1

IS 221 ECN4315 Page 5 of 8

Install this appliance on a level surface ensuring all vents are unobstructed. Any

partitions, walls or furniture must be of non-combustible material. Minimum

distances A 100mm B 500mm – see Fig 1.

This appliance is fitted with adjustable feet for levelling.

If replacing the plug connect the terminals as follows:

Green and Yellow wire Earth E
Blue wire Neutral N
Brown wire Live L

When fitting countertop appliances to SLS stands, the feet should be located into

the corresponding holes in the base appliances. When fitting onto Ovens, HC

Pedestals or similar closed bases, the feet may be removed.

Power ratings

Model

Power (kW)

Dry Heat

BM3

0.50

BA3, BS3

0.50

BM4

0.75

BA4, BS4

0.75

BM6

0.75

BM7

1.00

BA7, BS7

1.00

Wet Well Heat

BM3W

1.00

BS3W

1.00

BM4W

1.00

BS4W

1.00

BM6W

2.00

BM7W

2.00

BS7W

2.00

OPERATING INSTRUCTIONS

Only qualified or trained personnel should use this appliance.

Bains Marie are intended to maintain food temperature only and are not designed

as a cooker.

Dry Heat Models

Do not fill Dry Heat Models with water.

Switch on the power supply – the green neon illuminates.

IS 221 ECN4315 Page 6 of 8

Turn the control knob to maximum and heat up for 20 minutes. Adjust the

temperature to the desired level.

Place hot food into the containers.

Wet Well Models

Always ensure the drain tap is fully closed to the left. Add water to a depth that

covers around 10mm of the base of the gastronorm or pot.

Switch on the power supply – the green neon lights.

Turn the control knob to maximum and heat up for 20 minutes. Adjust the

temperature to the desired level.

Place hot food into the containers.

Maintain sufficient water to keep the containers immersed in a steam bath. Change

the water regularly and do not allow the appliance to boil dry.

CLEANING

Do not use a water jet or steam cleaner, and do not immerse this appliance.

Clean appliances regularly with hot water and detergent – do not use abrasives or
chlorine based cleaners on stainless steel. Take care to avoid wetting electrical
components.

SERVICING, MAINTENANCE AND
COMPONENT REPLACEMENT

All servicing, maintenance and component replacement on these appliances should

be carried out by one of our recommended service engineers.

Please refer to the Service Help Desk number on the final page of this manual.

FAULT FINDING

IS 221 ECN4315 Page 7 of 8

Part Number

Description

Used on

EL216

Element

BA3, BS3, BA7, BS7, BM3, BM7

EL219

Element

BA4, BS4, BM4, BM6

EL207

Element

BS3W, BS4W, BM3W, BM4W

EL152

Element

BS7W, BM6W, BM7W

EN10

Energy Regulator

BA3, BS3, BA4, BS4, BA7, BS7,
BM3, BM4, BM6, BM7

FE37

Adjustable foot

All

KN182

Control Knob

BS3W, BS4W, BS7W, BM3W,
BM4W, BM6W, BM7W

KN263

Control Knob

BA3, BS3, BA4, BS4, BA7, BS7,
BM3, BM4, BM6, BM7

NE43

Green Neon

All

TH34

Thermostat

BS3W, BS4W, BS7W, BM3W,
BM4W, BM6W, BM7W

TA25

8 Pt Aluminium Pot

BA3, BA4, BA7

TA27

Lid 8 Pt Aluminium Pot

BA3, BA4, BA7

TA23

Stainless Steel Pot and Lid

BS3, BS4, BS7, BS3W, BS4W,
BS7W

Gastronorm Containers

Size

Pot

Lid

1/6

TA34

TA35

1/4

TA36

TA37

1/3

TA85

TA44

1/2

TA38

TA39

SPARE PARTS LIST

IS 221 ECN4315 Page 8 of 8

For help with the installation, maintenance and use of your Lincat equipment,

please contact our service department:

 UK: 01522 875520

For non-UK customers, please contact your local Lincat dealer

All service work, other than routine cleaning should be carried out by one of our

authorised service agents. We cannot accept responsibility for work carried out by

other persons.

To ensure your service enquiry is handled as efficiently as possible, please tell us:

 Brief details of the problem

 Product code

All available on serial plate

 Type number

 Serial number

Lincat reserve the right to carry out any work under warranty, given reasonable

access to the appliance, during normal working hours, Monday to Friday, 08:30 to

17:00.

GUARANTEE

This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is

in addition to, and does not diminish your statutory or legal rights.

The guarantee does not cover:

 Accidental damage, misuse or use not in accordance with the manufacturer’s

instructions

 Consumable items (such as filters, glass, bulbs, slot toaster elements and door

seals.)

 Damage due to incorrect installation, modification, unauthorised service work or

damage due to scale, food debris build-up, etc.

The manufacturer disclaims any liability for incidental, or consequential damages.

Attendance is based on reasonable access to the appliance to allow the authorised
technician to carry out the warranty work.

Service calls to equipment under warranty will be carried out in accordance with the
conditions of sale. Unless otherwise specified, a maximum of 15 minutes of
administrative time, not spent directly carrying out servicing work, is provided for
within the warranty. Any requirement for staff attending the call to spend greater time
than 15 minutes due to administrative requirements, such as on health and safety risk
assessments, will be chargeable at the prevailing rate.
