User manual
1
Index
1. Product description 1
What is Liip for?
Box content
Product overview
2. Instructions 3
Installation and first usel
Liip Smart Monitor fit and positioning
Washing instructions
3. Important safety instructions 5
Warning
Terms of use
Precautions for battery use
Instructions on recycling and battery disposal
Waste electrical and electronic equipment
RoHs compliance
Electromagnetic waves
4. Guarantees and legal terms 6
Resources
How to obtain warranty service
Exclusions and limitations
Implicit guarantees
Limitation of damages
Applicable law
National legal rights
Customer service
1. Product description
What is Liip for?
Liip Smart Monitor offers tranquility in the care and well-being of your baby, transmitting
information about his status. Through the most innovative technology, Liip detects the main
vital signs of the baby, informs of changes that may pose a problem and indicates the guidelines
for action.
Liip Smart Monitor is a new baby monitor concept that provides the knowledge you need to know
how your baby is doing.
Box content
Liip Smart Monitor core
User manual
Off and reset pusher
Interchangeable wristbands
Charger
USB cable
1
Product overview
1. Led information light
2. Off and reset button
3. Safety catch
4. USB connector for battery charging
5. Pulse oximetry sensor
6. Pin
7. Temperature sensor
1
2
4
6
3
5
7
2
2. Instructions
Installation and first use
A
Charge the Liip Smart Monitor battery until the led
light turns green.
C D
create your user account and link your phone with
your Liip Smart Monitor.
Start the application and follow the instructions to
B
Download the App on your Smartphone looking for Liip
in your app store.
In order to link Liip Smart Monitor with your smartphone,
you must enter the linking code. This code is 6 numbers
and is located at the bottom of the box.
3
Liip Smart Monitor fit and positioning
Liip Smart Monitor should be used on the left leg.
The core should look up and the Liip logo out.
It should be held firmly, so that it does not rotate
around the baby's leg when exerting the slightest
pressure.
In babies older than 12 months, Liip Smart Monitor
can also be used on the wrist. The correct way to
put it is on the left side, with the logo Liip looking
up and inwards.
Washing instructions
The materials used in Liip Smart Monitor are
hypoallergenic and easily washable to facilitate
the maintenance of correct hygiene.The core and
wristbands have to be washed separately.
The wristbands can be washed in the washing
machine at 30ºC. Do not use bleach. Do not tumble
dry. Do not dry clean.
The core should be cleaned with a dry cloth,
taking special care to keep the sensors as clean
as possible for proper operation of them.
4
3. Importat safety instructions
Warnings
Liip Smart Monitor has been designed to comply with the regulations in force in the European
Union, avoiding the risk of drowning by small parts or by long ropes, as well as damage by
sharp edges or sharp points.
Liip Smart Monitor should be used in the surveillance of an adult.
Liip Smart Monitor is not a sanitary product and should not be used for diagnostic,
therapeutic or disease prevention purposes in countries where statistics do not allow it.
Terms of use and safety
1. Read the instructions.
Keep the instructions.
2.
Respect all warnings.
3.
Follow all instructions.
4.
Do not use this device near water.
5.
Do not place the device near heat sources such as radiators, heat
6.
registers, stoves, or other appliances that generate heat.
Use this product only under the supervision of an adult.
7.
Use only the charger and cable sold with the appliance or certified
8.
according to EN 60950-1.
Any repairs must be made by qualified service personnel. The appliance
9.
must be repaired when it is in some way, for example: when the power
cord or plug was damaged, when liquid was spilled when the appliance
was exposed to rain or moisture, when the appliance did not work or
after a fall.
Do not expose this device to splashes or drips and make sure that there
10.
are objects with liquids, such as glasses, on the device.
To completely disconnect the appliance from the mains, disconnect
11.
the power cord plug from the AC receptacle.
The mains plug of the power cord must remain ready to be used again.
12.
Do not expose the batteries to excessive heat, such as the sun, fire or a
13.
similar situation.
Do not attempt to open, disassemble or repair the device yourself.
14.
Do not let it fall, throw it into a vacuum or try to bend it.
15.
Precautions for battery use
1.
Do not try to open the battery.
2.
However, disassemble or short-circuit a battery.
3.
Do not throw it into fire or trash, do not expose it to temperatures
above 60ºC.
4.
Do not use the battery for other uses than it was designed for.
5.
Do not use batteries damaged or not recommended by Wearables
Inteligentes, S.L.
5
Instructions on recycling and disposal of batteries
The new Directive 2006/66/CE on batteries and accumulators that
replaces the previous directive became effective on September 26,
2008. The directive applies to all types of batteries and accumulators
(AA, AAA, button batteries, lead acid, rechargeable), including those
that are incorporated into electrical appliances, except for military,
medical and power tool applications. The directive establishes
standards for the collection, treatment and recycling and disposal of
batteries, and aims to prohibit certain hazardous substances and
improve the environmental performance of batteries and all operators
in the supply chain.
The battery of your device is not removable, and it is not possible for
the user to remove it. The centers of recycling or recovery are those
that manage the dismantling of the product and the extraction of the
battery. If for any reason it is necessary to replace the battery, the
procedure must be carried out in authorized service centers.
In the European Union and elsewhere, it is forbidden to dispose of
batteries together with household waste. All batteries should be
disposed of in a way that is not harmful to the environment. Contact
local waste management officials for information on environmentally
safe collection, recycling and disposal of used batteries.
Waste electrical and electronic equipment
Directive 2012/19 / EU on WEEE (Waste Electrical and Electronic
Equipment, Waste Electrical and Electronic Equipment), resulted in
a fundamental change in the treatment of electrical equipment that
are at the end of their useful life. The objective of this Directive is, as
a priority, the recovery of such waste in order to
reduce disposal. The WEEE logo is on the product
and in its box and indicates the collection of
electrical and electronic equipment. The WEEE
logo consists of the crossed-out waste basket with
wheels, as shown below.
This product must not be disposed of with another household waste.
You have the responsibility to eliminate all waste from your electrical or
electronic equipment and, to that end, you must take them to the
specified collection point for the recycling of said hazardous waste. The
isolated collection and the adequate recovery of the waste of your
electrical and electronic equipment at the time of disposal allow us to
help conserve natural resources. Likewise, the adequate recycling of
waste from your electrical and electronic equipment will guarantee the
safety of human health and the environment. For more information
about disposal, recovery and waste collection points for electrical and
electronic equipment, contact the local city center, the household
waste disposal service, the store where you purchased the equipment
or the manufacturer of the equipment.
RoHS compliance
Through this document, WEARABLES INTELIGENTES SL declares that
this product complies with Directive 2011/65 / EU of the European
Parliament and the Council of June 8, 2011 on the restriction on the use
of hazardous substances in electrical and electronic equipment.
Ondas electromagnéticas
Through this document, WEARABLES INTELIGENTES SL declares that
this equipment complies with the essential requirements and other
relevant provisions of Directive 2014/53 / EU of the European Parliament
and of the Council of April 16, 2014 on the harmonization of the laws of
Member States on the commercialization of radio equipment, including
the guidelines on exposure to electromagnetic waves according to
EN 301.489-1 and EN 301.489-17, and the guidelines on radio frequency
according to EN 300.328.
This device is a transmitter and receiver of radio waves is designed not
to exceed the limits of exposure to radio waves (radiofrequency electro
magnetic fields) recommended by international guidelines. The
guidelines have been developed by an independent scientific
organization (ICNIRP) and include a significant margin of safety to
ensure the safety of all people, regardless of their age or health status.
Following these criteria, the standard establishes that the maximum
legal radiated power for this device is 20mW.
The results of the tests carried out are the following:
Mode Frecuency
Bluetooth
The maximum power radiated by the device is 2.88mW, which meets
the legal requirements.
Max.
Max.
Max.E.I.R.P
(MHz)
Output
Antenna
power
gain (dBi)
(dBm)
2402 4.0 +0.6 4.6 2.88
2440 4.0 +0.6 4.6 2.88
2480 4.0 +0.6 4.6 2.88
(dBm)
Max.E.I.R.P
(mW)
4. Guarantees and legal terms
Wearables Inteligentes S.L. ("Liip") warrants to the original purchaser
that its Liip Smart Monitor electronic device (the "Product") will be free
from defects in materials and workmanship with normal use for a period
of one (1) year from the date of acquisition, unless the buyer resides in
the European Economic Area (EEA) and bought his Liip product in the
EEA, where the warranty period is two (2) years from the date of
acquisition (the " Warranty period").
Liip does not guarantee that the operation of the Product will be
uninterrupted or that it will be free of faults. Liip will not be responsible
for the damages derived from the failure to follow the instructions in
relation to the use of the Product.
This Limited Warranty does not cover the software incorporated in the
product and the services provided by Liip to the product owners.
Consult the license agreement that accompanies the software and the
conditionsof Liip's services to obtain details about your rights with
respect to its use.
Resources
If a hardware defect is detected and Liip receives a valid claim within
the Warranty Period, in its sole discretion and in accordance with the
provisions of law, Liip (1) will repair the Product at no charge by new
or repaired replacement parts. or (2) will change the Product for a new
or repaired Product. In case of a defect, according to what is stipulated
by law, these are your only possible resources. Shipping costs may be
applied except where prohibited by applicable law. This Limited
Warranty is valid only in those jurisdictions in which the products are
marketed by Liip or through its authorized distributors or agents and is
valid to the extent permitted by the laws applicable to those jurisdictions.
All replacement hardware products will be warranted during the
remaining original warranty period or thirty (30) days, whichever is
longer, or during any additional period that is applicable in your
jurisdiction.
How to obtain warranty service
In order to enjoy the warranty service, you must deliver the Product, with
transportation costs paid and in its original packaging or in a package
that provides the same degree of protection at the address specified by
Liip. In accordance with applicable laws, Liip may request that you
provide proof of purchase, that you meet certain registration
requirements or both before you can enjoy warranty service.
*
The battery life of the Product in terms of useful life will depend on the
conditions of use and the conguration of the device. Since batteries are
considered expendable supplies, the specications indicate that you will
get optimum performance for your product during the rst six (6) months
of purchase and approximately for 200 more rells.
*
*
6
Exclusions and limitations
This Limited Warranty applies only to the Product manufactured by or for
Liip and that can be identified by the trademark "Liip", the brand name or
the logo it presents. The Limited Warranty does not apply to (a) Liip
products and services other than the Product, (b) non-Liip hardware
products, (c) consumables (such as batteries), or (d) software, even if
included in the package or it will be sold with the Product or integrated
into the Product. This warranty does not apply to any Product or part of
the Product that has been altered or modified (for example, to alter
functions or capabilities) by anyone other than Liip's representative, or if
the Product is inserted or installed. in an accommodation not provided by
Liip. In addition, this Limited Warranty does not apply in these cases: (a)
damage caused by use with non-Liip products, (b) damage caused by
accident, misuse, improper use, floods, fires, earthquakes or other external
causes, (c) damage caused by using the Product outside of the permitted
or indicated uses described by Liip or together with an inadequate voltage
or power supply, or (d) damage caused by maintenance tasks (including
updates and extensions) made by anyone other than Liip's representative.
The recovery and reinstallation of software programs and user data are
not covered by this Limited Warranty.
No distributor, agent or employee of Liip is authorized to make any
modification, addition or extension to this Limited Warranty. If any term is
declared illegal or not applicable, the legality or enforceability of the
remaining terms will remain valid and will not be affected.
Implicit guarantees
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED
WARRANTIES (INCLUDING WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE) ARE LIMITED IN DURATION TO
THE DURATION OF THIS LIMITED WARRANTY. Some jurisdictions do not
allow limitations on the duration of an implied warranty, so the above
limitation may not apply to you.
Damage limitations
EXCEPT TO THE EXTENT THAT APPLICABLE LAWS PROHIBIT IT, LIIP
SHALL NOT BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL OR
CONSEQUENTIAL DAMAGES INCLUDING, BUT NOT LIMITED TO, LOSS OF
BENEFITS, REVENUES OR DATA AS A RESULT OF ANY VIOLATION OF
EXPRESS OR WARRANTY CONDITIONS OR WARRANTIES. IMPLIED, OR IN
ACCORDANCE WITH ANY OTHER LEGAL THEORY, EVEN IN THE EVENT THAT
LIIP HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some
jurisdictions do not allow the exclusion or limitation of special, indirect,
incidental or consequential damages, so the above limitation or exclusion may
not apply to you.
National legal rights
Consumers residing in some jurisdictions may have legal rights covered by the
national legislation applicable to the sale of consumer goods, including, among
others, national laws transposing Directive 99/44 / EC. These rights will not be
affected by the guarantees established in this Limited Warranty.
Customer Service
For any claim on the application of the legal guarantee of your product, in
accordance with the provisions of Royal Legislative Decree 1/2007, you can
contact us through our email address liip@liip.care or by regular mail to:
Wearables Inteligentes, S.L.
La Marina de València, Muelle de la Aduana s/n
46024 Valencia
Spain
Document version
Date of document: 14/05/2018
Number version: 5
Los consumidores residentes en algunas jurisdicciones pueden tener dere
-
-
-
Applicable law
This Limited Warranty will be governed by the laws of Spain and the European
Union, without any effect of conflict of laws that could allow the application of
the legislation of another jurisdiction.
7
Wearables Inteligentes, S.L. · www.liip.care
Loading...
