User Guide
BT Digital Baby Monitor & Pacifier
Welcome…
to your BT Digital Baby Monitor
& Pacifier
• Digital sound quality with high definition sound (Hi-dsTM)
lets you hear your baby breathe, gurgle, snuffle or cry
with complete clarity
• Wireless range of up to 300m outdoors and up to 50m
indoors (in ideal conditions, where there is a clear line
of sight between the units) – giving you the freedom to
move around with clear reception and no interference
from other baby monitors
• Out of range warning
• Link light provides continuous confidence that the Parent
unit is receiving a signal from the Baby unit and will alert
you if the link is lost
• 19 Songs or play your own music from the Baby unit
• Talk Back feature lets you instantly reassure and calm
your baby
• Adjustable nightlight brightness on Baby unit
• Lightshow with adjustable brightness on Baby unit
• Room temperature monitor
• Crying alert on Parent unit
• Feed timer and alert on Parent unit
• Torch on Parent unit
This User Guide provides you with all
the information you need to get the
most from your BT Digital Baby Monitor
& Pacifier.
Please read this guide carefully and
keep it for future reference.
Need help?
If you have any problems setting up or using your
BT Digital Baby Monitor & Pacifier (or would like
any additional or replacement batteries), call our
free Helpline on 0808 100 6554*.
Our dedicated advisors are more likely to be
able to help you than the retailer where you
made your purchase.
Alternatively, you may find the answer in the
‘Help’ section at the back of this guide.
Additional answers to Frequently Asked Questions
are also available from www.bt.com/producthelp
* Calls made from within the UK mainland network are free.
Mobile and international call costs may vary.
Got everything?
• Baby unit
• Parent unit
• 2 x AA NiMH 1300mAh
rechargeable batteries
for Parent unit (pre-installed)
• Parent unit charger
• 2 x power adapters
(item code 057711)
• 3.5mm aux audio lead
• Travel bag (located
underneath top layer)
4
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
4
• Your BT Digital Baby Monitor & Pacifier is designed to be an aid and should not
be used as a substitute for responsible and proper adult supervision.
• Make sure the Baby unit, Parent unit and mains adapter cables are kept out of
reach of your baby – at least one metre away.
• Never place the Baby unit inside your baby’s cot, bed or playpen.
• Never cover your Parent or Baby units (e.g. with clothes, towels or blankets).
• Never use or place your Parent or Baby units in moist places or near water.
• If travelling abroad, make sure that the voltage shown on the mains power
adapter corresponds to the local mains power before connecting to the
power supply.
• There is a risk of explosion if the batteries are replaced by an incorrect type.
• Always dispose of batteries in accordance with applicable waste disposal
regulations, never in your household rubbish.
• During continual use the Baby unit and Parent unit power adapters may become
warm to the touch. This is normal and is not something to be concerned about.
• In the event of a power failure, when the power is restored all your settings will
remain unchanged.
Important safety information
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
5
Important safety information ............4
Your BT Digital Baby Monitor
& Pacifier ..........................................7
Parent unit ........................................7
Parent unit display icons .....................8
Parent unit charger ............................9
Baby unit ........................................10
Back of Baby unit .............................11
Parent unit menu map......................12
Setting up .......................................13
Parent unit ......................................13
Baby unit ........................................15
Switch on and link the Parent
and Baby units .................................15
Using your BT Digital Baby Monitor
& Pacifier ........................................17
Switch the Baby unit on ...................17
Switch the Parent unit on .................17
Switch the Baby unit off ...................17
Switch the Parent unit off .................18
Baby sound level LED indicators .......18
Adjust the loudspeaker volume .........19
Mute All feature – Parent unit only ....20
Mute Low – Parent unit only .............20
Talk Back .........................................21
Find ................................................22
Torch ...............................................22
The Parent unit menu .......................23
Lightshow .......................................24
Switch lightshow on/off
using the Baby unit ..........................24
Switch lightshow on/off
using the Parent unit ........................24
Select the lightshow brightness
level using the Parent unit ................25
Set the lightshow timer ....................25
Adjusting the lightshow angle
and focus ........................................25
Nightlight .......................................26
Switch nightlight on/off
using the Baby unit ..........................26
Switch nightlight on/off
using the Parent unit ........................26
In this guide
In this guide
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
6
Select the nightlight brightness level
using the Parent unit ........................27
Set the nightlight timer ....................27
Play music from the Baby unit ..........28
Turn music on/off
using the Baby unit ..........................28
Turn music on/off
using the Parent unit ........................29
Choose a song to play
using the Parent unit ........................29
Connect an auxiliary player ...............30
Set a play time for music ..................30
Feed Timer ......................................31
Set the feed timer
countdown duration ........................31
Start the feed timer countdown ........32
Cancel the feed timer countdown .....32
Switch timer repeat option on or off ..33
Select the type of feed timer alert .....33
Temperature monitor .......................34
Temperature monitor indicators ........34
Select the type of temperature alert ..35
Temperature alert options ................35
Crying alert .....................................36
Select the type of crying alert ...........36
Backlight .........................................37
List of tones ....................................37
Reset the units ................................38
Reset the Parent unit .......................38
Reset the Baby unit ..........................38
Help ...............................................39
General information ........................41
Cleaning ..........................................41
Guarantee .......................................41
Product disposal instructions ............42
R&TTE .............................................43
Declaration of Conformance .............43
User Guide formats ..........................43
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
7
Parent unit
Your BT Digital Baby Monitor & Pacifier
Baby sound level LEDs
Indicates the level of received
sound. The LEDs will light up
progressively as the sound
increases. See page 18 for
further information.
Torch (on back of unit)
Press to switch the torch
feature on and off.
Mute LED
Red indicates that Mute All
has been switched on.
Amber indicates that Mute Low
has been switched on.
Talk (on side of unit)
Press to talk to your baby.
LCD Display
Power saving backlight turns
on when you press any button and
then switches off after 15 seconds.
Press to switch the Lightshow
on the Baby unit on or off.
Menu
Press to open the menu.
Press and hold to exit the menu
and return to the idle screen.
Press to switch the Nightlight
on the Baby unit on or off.
Link indicator
Steady green indicates that the Baby and
Parent units are linked. Flashes green if no
link established for 30 seconds. Flashes
red if no link established after 30 seconds.
Also flashes green when the Talk button
is pressed on the Parent unit to initiate
parental talk back.
Battery status LED
Red light indicates the batteries are low
and need re-charging.
Press to switch the music on the Baby unit
on or off.
OK
Press to confirm the menu option displayed.
Microphone
Up
Increase speaker volume.
Scroll through the menu options.
Mute Low
(on top of unit)
Press to toggle the
Baby unit microphone
sensitivity between
normal and Mute Low.
Mute All
(on top of unit)
Press to toggle the
Parent unit receive
volume between
on and off.
Power on/off
(on top of unit)
Press and hold to
switch the power
on or off.
Down
Decrease speaker volume.
Scroll through the
menu options.
Your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
8
Temperature alert (vibrate on)
Temperature alert (vibrate off)
Displays the temperature as
measured at the Baby unit
Crying alert (vibrate on)
Crying alert (vibrate off)
Feed timer on (vibrate on)
Feed timer on (vibrate off)
Full charge (75-100%)
Medium charge (51-74%)
Low charge (25-50%)
Empty (8-24%)
Flashing (0-7%). Typically you
will be able to use your Parent
unit for at least one hour after
the battery icon starts to flash.
Icon will scroll when charging
Indicates when you can
scroll up or down through
the menu options
Parent unit display icons
Menu options:
Lightshow Nightlight Music Feed Timer Setup
Battery status
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Your BT Digital Baby Monitor & Pacifier 9
BT Baby Pacifier
Charging light
Red when the Parent unit is
correctly placed on the charger.
Power socket
For connection to the mains
power socket via the power
adapter cable supplied.
Parent unit charger
Front
Back
Your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
10
find
Nightlight
Press to switch the
Nightlight on or off.
Lightshow
Press to switch the
Lightshow on or off.
Microphone
Power on/off
Press and hold to switch
the power on or off.
Find
(on side of unit)
Press to emit an alert
beep from the Parent unit–
useful for finding the Parent
unit if you’ve misplaced it.
Nightlight
Illuminates around the base.
Temperature sensor
Make sure the sensor is placed
with clear space around it and
not in contact with any surfaces
to ensure it works effectively.
Music
Press to switch music
on at the Baby unit
(the music and duration will
be as last set at the Parent unit).
Press again to switch
the music off.
Volume +/–
Increase or decrease the
loudspeaker volume for playing
music or for parental talk back.
Link indicator
Steady green indicates that
the Baby and Parent units are
linked. Flashes green if no link
established for 30 seconds.
Flashes red if no link established
after 30 seconds. Also flashes
green when the Talk button is
pressed on the Parent unit to
initiate parental talk back.
Baby unit
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Your BT Digital Baby Monitor & Pacifier 11
Back of Baby unit
Power socket
For connection to the mains
power socket via the power
adapter cable supplied.
Auxiliary input socket
Use to plug in an external audio
source, e.g. MP3 player, so you
can play your own choice of
music to your baby.
Lightshow focus
control
(see page 25)
Lightshow tilt control
(see page 25)
Your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
12
Parent unit menu map
Menu
Lightshow
Nightlight
Music
Feed Timer
Setup
Turn (On/Off)?
Brightness
Timer
Turn (On/Off)?
Brightness
Timer
(Play/Stop)?
Choose Song
Timer
(Start/Stop) Timer
Duration
Timer Repeat
Timer Alert
Crying Alert
Temp Alert
Backlight
High
Medium
Low
High
Medium
Low
5 min
10 min
15 min
Constant
Set Time
Repeat On
Repeat Off
Beep
Beep&Vibe
Vibrate
Screen only
On w alerts
Off w alerts
5 min
10 min
15 min
Constant
5 min
10 min
15 min
Constant
Lullabies
Nature
Classical
External
Beep
Beep&Vibe
Vibrate
Beep
Beep&Vibe
Vibrate
Screen only
Off
Scroll Options
Play All
Scroll Options
Play All
Scroll Options
Play All
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
13Setting up
WARNING!
Only use the power adapters
supplied. Using incorrect power
adapters may permanently
damage your product.
Battery performance
Rechargeable batteries
in the Parent unit will last
approximately 20 hours in
normal use. Please note that
new batteries do not reach full
capacity until they have been in
normal use for several days.
The charge capacity of
rechargeable batteries will
reduce with time as they
wear out, so reducing the
performance time of the Parent
unit. Eventually they will need
to be replaced. New batteries
can be obtained from the
BT Digital Baby Monitor &
Pacifier Helpline
0808 100 6554*.
Parent unit
1. Plug one of the power adapter cables into the
socket marked
on the back of the Parent unit
charger and plug the other end into the mains
power wall socket and switch the power on.
2. Activate the batteries by pulling the plastic tab
away from the back of the Parent unit.
Setting up
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
14
3. Place the Parent unit into the charger. The red
charging light will illuminate on the charger and
the battery icon will start scrolling on the Parent
until display to indicate that the batteries are
being charged.
BT Baby Pacifier
Leave the batteries to charge for 16 hours (if turned off)
or 24 hours (if turned on) to reach maximum charge.
When the batteries are fully charged the battery
icon on the display will show a full charge
.
The Parent unit rechargeable
batteries will lose charge over
a period of time, even if
switched off.
Battery low warning –
Parent unit
When the batteries are low –
approximately within 1 hour of
running out – the Parent unit
will emit a low battery alert,
the low battery indicator will
turn red, the display will show
Low Battery and the icon
will flash. Place the Parent unit
back on the charger to charge
the batteries. To speed up
the charging process turn the
Parent unit off when charging
if it’s not being used.
Charging light
Battery icon
Low battery indicator
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Setting up 15
Baby unit
1. Plug the remaining power adapter cable into the
socket marked
on the back of the Baby unit
and plug the other end into the mains power and
switch on.
Switch on and link the Parent and Baby units
1. Press and hold the
button on the Baby unit
until the nightlight briefly illuminates and the green
Link indicator flashes.
2. Press and hold the
button on the Parent unit
until all the LEDs on the unit briefly illuminate.
The green Link indicator will flash and the display
will show I’m Linking.
WARNING
Never use non-rechargeable
batteries in the Parent unit.
Only use the recommended
type – 2 x AA NiMH 1300mAh
batteries. Using other types
could permanently damage the
unit. Charge the batteries as
instructed in this user guide.
The Parent unit can still be used
when it is in the charger.
Removing the batteries
If you ever need to remove
the batteries, simply slide
open the battery compartment
cover and use the ribbon to
eject the batteries.
Setting up
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
16
Positioning your units
The Baby unit should ideally be
within 1m-2m of your baby for
best performance.
If you place the Parent and
Baby units too close together
you will hear a high pitched
noise, this is normal. The units
are designed to be located at
a distance from one another,
e.g. in separate rooms.
Once the units are linked the green Link indicator
on the Parent unit and the Baby unit will stop
flashing and remain a steady green. The units are
now ready to use.
Important:
The link confirmation between the two units is vital
for use so they can communicate. If the link between
the units is broken at any time, the Link indicators on
both units will flash green as they try to search for
each other. The Parent unit displays I’m Linking...
After 30 seconds, if the link is still broken, the Baby and
Parent units Link indicators will flash red. The Parent
unit display will show No Link and you will hear an
alert signal.
If the link is broken:
• check that the mains power is plugged in and
switched on at the Baby unit
• check that both units are switched on
• check that the batteries are charged in the
Parent unit
• check that the Parent and Baby units are within
range of each other (in ideal conditions the range
is up to 300 metres outdoors and 50m indoors)
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
17
Switching on/off
Switch the Baby unit on
1. Press and hold the
button until the
nightlight briefly illuminates and the green Link
indicator flashes.
Once linked the green Link indicator will remain on.
Switch the Parent unit on
1. Press and hold the
button on the Parent unit
until all the LEDs briefly illuminate. The green
Link indicator will flash and the display will show
I’m Linking.
Once the units are linked the green Link indicators
on the Parent and Baby units will stop flashing
and remain a steady green. The units are now
ready to use.
Switch the Baby unit off
1. Press and hold the
button on the Baby unit.
The green Link indicator will switch off.
Using your BT Digital Baby Monitor & Pacifier
Using your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
18
Switch the Parent unit off
1. Press and hold the
button on the Parent unit
until an audible alert sounds. The green Link
indicator will switch off and the display will go blank.
Baby sound level LED indicators
LEDs 1-2 = Green
(or Amber if
Mute Low is on)
LEDs 3-4 = Green LEDs 5-7 = Red
The seven LEDs across the top of the Parent unit
light up to indicate the level of sound being
received from the Baby unit. The LEDs light up
progressively as the sound increases.
LEDs 1-2 light up Green (or Amber if Mute
Low is on, see page 18) when sounds of 57dB and
63dB are received.
LEDs 3-4 light up Green when sounds of 69dB and
75dB are received.
LEDs 5-7 light up Red when sounds of 83dB, 89dB
or 95dB are received.
Equivalent sound
level examples:
60dB-70dB =
normal conversation
75dB = loud conversation
83-95dB = loud traffic noise
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Using your BT Digital Baby Monitor & Pacifier 19
If you try and set the volume
higher or lower than the 5
settings available on either unit
you will hear an error tone.
Setting the Parent unit to
Volume Off is the equivalent of
switching the Mute All feature
on. See page 20 for more
information on Mute All.
The default loudspeaker volume
on both units is Level 3.
Adjust the loudspeaker volume
At the Parent unit:
1. Press
or to select the required level.
The first press will show the current setting.
There are 5 volume levels and off (Mute). The
volume level will be shown on the display at each
press, e.g. Level 3 is shown as Volume
.
If you wish to switch the volume off, keep pressing
until the display shows Volume Off. The Mute
All indicator will illuminate.
At the Baby unit:
There are 5 volume settings.
1. When Music is being played or Talk back is in
progress from the Parent unit, press the
or
button to adjust the volume.
2. If no music or Talk back is in use, pressing the
or
buttons will adjust the volume and a beep will
sound at the appropriate volume level set.
Using your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
20
Be careful not to accidentally
switch the torch feature on
as Mute All is automatically
activated when this is done.
If the
or buttons
are pressed whilst Mute All
or Mute Low has been set
then Mute All or Low will
be switched off and the
loudspeaker volume will return
to Level 3 automatically.
Mute All feature – Parent unit only
The Mute All feature prevents any sound coming
from the Parent unit loudspeaker. With Mute All
on you can still monitor your baby using the Baby
sound level LED indicators (page 18) and the Crying
Alert (page 36).
1. To switch Mute All on, press the
button located
on the top of the unit. The Mute indicator will
illuminated red.
2. To switch Mute All off, press the
button again.
The red Mute indicator will switch off.
Mute Low – Parent unit only
For discreet operation when you do not wish to hear
any low level sounds, you can still monitor your baby
using the Baby sound level LED indicators (page 18).
When Mute Low is switched on, any sounds from
the Baby unit to the Parent unit will be muted
unless a sound is made above a set level. The set
level are sounds that are louder than the first two
green LEDs would register, as described in ‘Baby
sound level LED indicators on page 18.
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Using your BT Digital Baby Monitor & Pacifier 21
Once the Mute Low sound
threshold has been exceeded,
baby sounds will be able to be
heard for a further six seconds
even if they do not reach the
Mute Low threshold.
You will be able to activate
Talk Back mode even if other
functions have been activated
at the Baby unit like Music
playback or Nightlight on.
Press
or on the Baby
unit to adjust the Talk Back
volume level of the Baby unit
loudspeaker.
Do not press the
button
when the Baby unit and
Parent unit are positioned in
the same room. High-pitch
noise will be generated if the
button is pressed when
Baby unit and Parent unit are
close to each other or within
3 metres distance.
When using Talk Back, hold
the Parent unit approximately
30cm in front of your mouth
when talking to baby.
If the Parent unit receives sound up to the level of
the first two LEDs then they will turn amber but no
sound will be heard, if the sound rises above this
level then the unit will un-mute so you can hear the
sounds.
1. To switch Mute Low on, press the
button
located on the top of the Parent unit. The Mute
indicator will turn amber.
2. To switch Mute Low off, press the
button again.
The amber indicator will switch off.
Talk Back
You can use the Parent unit Talk Back feature as a
one way intercom to comfort and reassure your
baby. By speaking into the Parent unit your baby
will hear your voice from the Baby unit. Please note
that when using Talk Back you will not be able to
hear your baby until you release the
button.
1. Press and hold down the
button on the
Parent unit to speak to your baby.
Whilst the
button is depressed the display
will show Talk and the green Link indicators will
flash on both units.
Using your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
22
When the Torch is switched
on it will automatically switch
Mute All on as well. If you then
press the button Mute will
be disabled and the Torch will
remain on. When the Torch is
switched off, the previous Mute
setting will be restored (No
Mute, Mute All or Mute Low).
Find
You can press the button on the Baby unit
to make the Parent unit sound an alert to help
you find it if it’s been misplaced. If the Parent unit
loudspeaker volume had been Muted (or set to
volume off), the volume level will be reset to the
default setting of Level 3.
1. Press
on the Baby unit. The paging alert will
sound at the Parent unit and the display will show
Here I am!
2. To stop the alert, press any button on the Parent
unit or press the
button again on the Baby
unit. If no button is pressed after 2 minutes then
the alert will automatically stop.
Torch
The Parent unit has a high intensity white LED torch
that can be used when the Parent unit is switched
on or off.
1. Press the
button located on the back of the
Parent unit to switch the Torch on and off.
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Using your BT Digital Baby Monitor & Pacifier 23
The Parent unit menu
The button on the Parent unit can be used to
select and change settings on the Baby unit without
having to risk disturbing your baby. You can access
the settings by:
1. Press
then press or to scroll through
the menu options shown on the top of the display.
Press
when the option you want is displayed.
2. The first sub menu option will be displayed, press
to scroll through the options. The ( arrows)
indicate when you can scroll either up or down.
Press
when the option you want is displayed.
3. To exit the menu at any time, press
briefly
and step back one menu level at a time, or press
and hold
to return to the idle screen. If no
buttons are pressed for 10 seconds whilst accessing
the menu, the display will return to idle and any
unsaved changes will be lost.
Using your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
24
The Baby unit must be switched
on for the Lightshow to work
but need not be linked to the
Parent unit.
You can also switch the
Lightshow on/off using the
Parent unit menu using the
Lightshow menu option.
Lightshow
The Baby unit has a Lightshow feature that projects
a starry image onto the ceiling of your baby’s room.
There are 3 brightness levels to choose from and
you can set a period of time for the Lightshow to
illuminate using the Parent unit menu.
Switch lightshow on/off using the Baby unit
1. To switch on, press the
button. The brightness
level and period of time for the lightshow to
illuminate for will be as last set using the Parent unit.
2. To switch off, press the
button.
Switch lightshow on/off using the Parent unit
1. To switch on, press the
button. The display will
briefly show Lightshow On and the Baby unit
lightshow will turn on.
2. To switch off, press the
button. The display will
briefly show Lightshow Off and the lightshow
will turn off.
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Using your BT Digital Baby Monitor & Pacifier 25
The default setting is Medium.
The default setting is Constant.
Select the lightshow brightness level using the
Parent unit
1. Press
. Lightshow is displayed, press .
2. Turn On? is displayed, press
to display
Brightness and press
.
3. Press
or to display either Low, Medium or
High and press
to select. The display will show
Saved briefly and you’ll hear a confirmation tone.
Set the lightshow timer
1. Press
. Lightshow is displayed, press .
2. Turn On? is displayed, press
until Timer is
displayed and press
.
3. Press
or to display either 5 min,
10 min, 15 min or Constant and press
to
select. The display will show Saved briefly and
you’ll hear a confirmation tone.
Adjusting the lightshow angle and focus
Use the manual controls on the Baby unit
(page 11) to tilt the lightshow to one side of the
current position.
The focus wheel should be used to obtain a clear
picture on the wall or ceiling.
Using your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
26
The Baby unit must be switched
on for the nightlight to work,
but need not be linked to the
Parent unit.
To adjust the brightness level
or set the Nightlight timer,
see page 27.
You can also switch the
Nightlight on/off using the
Parent unit menu using the
Nightlight menu option.
Nightlight
You can set a comforting nightlight on the Baby
unit. There are 3 brightness levels to choose from
and you can set a period of time for the nightlight
to illuminate.
Switch nightlight on/off using the Baby unit
1. To switch on, press the
button.
2. To switch off, press the
button again.
Switch nightlight on/off using the Parent unit
1. To switch on, press the
button. The display
will briefly show Light On and the Baby unit
nightlight will illuminate.
2. To switch off, press the
button. The display
will briefly show Light Off and the nightlight will
turn off.
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Using your BT Digital Baby Monitor & Pacifier 27
The default setting is Medium.
The default setting is Constant.
Select the nightlight brightness level using the
Parent unit
1. Press
. Lightshow is displayed, press to
display Nightlight and press
.
2. Turn On? is displayed, press
to display
Brightness and press
.
3. Press
or to display either Low, Medium or
High and press
to select. The display will show
Saved briefly and you’ll hear a confirmation tone.
Set the nightlight timer
1. Press
. Lightshow is displayed, press to
display Nightlight and press
.
2. Turn On? is displayed, press
until Timer is
displayed and press
.
3. Press
or to display either 5 min, 10 min,
15 min or Constant and press
to select.
The display will show Saved briefly and you’ll
hear a confirmation tone.
Using your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
28
The default music setting
is Lullaby, Play All songs
Constantly.
After power-on, there may
be a delay of a few seconds
before the Baby unit is ready
to play music.
Adjust the volume of the music
using the
or buttons on
the Baby unit.
If music is played at greater
than volume 3, the Crying Alert
may activate if Mute All is used.
Play music from the Baby unit
The Baby unit has 19 songs that can be played
to gently soothe your baby. The songs have been
grouped into 3 categories: Lullabies, Nature
and Classical.
You can select one song to play repeatedly or select
the Play All option for a medley of the songs from
your selected category. The songs can be set to play
in a loop for 5, 10 or 15 minutes or you can leave
them playing constantly.
You can also plug in an external audio source like
an MP3 or CD player and play music or audio books
of your choice to your baby. The auxiliary port is
located on the back of the Baby unit.
Turn music on/off using the Baby unit
1. To turn the music on, press the
button. The most
recently selected song will start playing at the time
period last selected using the Parent unit.
2. To turn the music off, press the
button.
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Using your BT Digital Baby Monitor & Pacifier 29
You can also switch the
music on/off using the Parent
unit menu using the Music
menu option.
Turn music on/off using the Parent unit
1. To turn the music on, press the
button.
The display will briefly show Music On and music
will start playing from the Baby unit.
2. To turn the music off, press the
button.
The display will briefly show Music Off and the
music will turn off.
Choose a song to play using the Parent unit
1. Press
. Lightshow is displayed, press until
Music is displayed and press
.
2. Play? is displayed, press
to display Choose
Song and press
.
3. Use the
or buttons to display the category
of song you want: Lullabies, Nature or
Classical or External if you want to play music
from your own audio source and press
to select.
4. Use the
and buttons to scroll through the
individual song titles and press
when the option
you want is displayed. Or, you can select Play All,
to play a medley of the songs from your selected
category. The display will show Saved briefly and
you’ll hear a confirmation tone.
Using your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
30
Connect an auxiliary player
1. Plug your player into the auxiliary input socket
on the back of the Baby unit using the aux audio
lead supplied.
2. The music selection will immediately change to
External but it won’t start playing until you
switch the music feature on.
Set a play time for music
1. Press
. Lightshow is displayed, press until
Music is displayed and press
2. Play? is displayed, press until Timer is
displayed and press
.
3. Use the
or buttons to scroll through the
options: 5 min, 10 min, 15 min or Constant and
press
when the option you want is displayed.
The display will show Saved briefly and you’ll hear
a confirmation tone.
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Using your BT Digital Baby Monitor & Pacifier 31
The timer can be set from 1
minute to 99 hours 59 minutes.
The feed timer default
countdown duration is set at
02:00 (2 hours).
If the Parent unit is switched
off, the feed timer countdown
will be cancelled and you will
need to start it again when the
unit is switched back on. The
duration, alert type and repeat
settings will still be retained.
Feed Timer
You can set a Feed Timer on the Parent unit to act
as a countdown timer that will alert you when you
next need to feed your baby. You have a choice
of alert types (beep, beep & vibe and vibrate)
and you can set the timer to repeat itself once
the alert sounds.
Set the feed timer countdown duration
1. Press
. Lightshow is displayed, press until
Feed Timer is displayed and press
.
2. Start? is displayed, press
to display
Duration and press
.
3. The display will show 02h:00m (or the currently
set timer). Use the
and buttons to
select the first digit and press
. Repeat this
procedure for each digit and press
. The display will
show Saved and you’ll hear a confirmation beep.
Using your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
32
Start the feed timer countdown
1. Press
. Lightshow is displayed, press until
Feed Timer is displayed and press
.
2. Start? is displayed, press
. The display will
briefly show Timer On and then the timer will be
shown counting down the seconds from the time
you set.
When the timer has finished counting down to
00:00 you will hear an alert beep and the timer and
icon will flash. Press any button on the Parent
unit to stop the alert. If you do not stop the alert
it will automatically stop after 2 minutes (or it will
start again if Timer Repeat has been set to On).
Cancel the feed timer countdown
1. Press
. Lightshow is displayed, press until
Feed Timer is displayed and press
.
2. Stop? is displayed, press
. The display will
briefly show Timer Off , the timer will then
disappear and the display will return to idle.
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Using your BT Digital Baby Monitor & Pacifier 33
The default setting is Repeat On.
Feed timer alert options:
Beep = Parent unit will emit
an alert beep only.
Beep&Vibe = Parent unit will
emit an alert beep and vibrate.
Vibrate = Parent unit will
vibrate only.
The default setting is
Beep&Vibrate.
Switch timer repeat option on or off
1. Press
. Lightshow is displayed, press until
Feed Timer is displayed and press
.
2. Start? is displayed, press
until Timer
Repeat is displayed and press
.
3. Use the
and buttons to display either
Repeat On or Repeat Off and press
to
select. The display will show Saved and you will
hear a confirmation beep.
When Repeat On has been set, the feed timer
countdown will start again once the alert has
sounded if it is not switched off.
Select the type of feed timer alert
1. Press
. Lightshow is displayed, press until
Feed Timer is displayed and press
.
2. Start? is displayed, press
until Timer Alert is
displayed and press
.
3. Use the
and buttons to display either
Beep, Beep&Vibe or Vibrate and press
to
select. The display will show Saved and you will
hear a confirmation beep.
Using your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
34
IMPORTANT!
The temperature sensor used
in this BT Digital Baby Monitor
& Pacifier is intended as a
guide, to provide parents with
an indication of the room
temperature in which the Baby
unit has been placed.
It is designed to operate within
an approximate tolerance of
+/- 1°C and is not intended to
be as accurate as some medical
devices. Please note that your
own temperature reference e.g.
your central heating thermostat
may not be as accurate, possibly
due to tolerances and positioning
of the thermostat in relation
to the Baby Monitor & Pacifier
sensor.
Healthcare professionals advise
that the ideal temperature for
your baby’s room is between
16 °C and 20°C.
Your Parent unit has a built-in
mechanism to prevent repeated
annoying audible alerts if the
room temperature hovers
around an alerting threshold.
Temperature monitor
There is a temperature sensor on the Baby unit
to constantly monitor the temperature in your
baby’s room and you’ll be alerted if it gets too hot,
too warm or too cold by the colour of the Baby
unit nightlight changing and the Parent unit will
vibrate, sound an alert beep and display a message
on the screen. The alerts on the Parent unit can
be changed, see page 35. The temperature will be
constantly shown on the Parent unit display in ˚C.
To stop an alert beep, press any button on the
Parent unit.
Temperature monitor indicators
Temperature On the Baby unit On the Parent unit
Below 16°C Nightlight
glows Blue
Display shows
Too Cold
16 – 20°C Nightlight
glows Yellow
21 – 24°C Nightlight
glows Orange
Display shows
Too Warm
Over 24°C Nightlight
glows Red
Display shows
Too Hot
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Using your BT Digital Baby Monitor & Pacifier 35
Pre-set temperature
alert range
The Baby unit comes with
pre-set maximum and
minimum temperatures,
as recommended by the UK
Department of Health as part
of the recommendations to
reduce the risk of cot death.
If the temperature falls below or
goes above the setting an alert
will sound on the Parent unit
and the display will show
To o
Cold or Too Hot as appropriate.
If it’s too hot, the Baby unit
nightlight will turn red and
if too cold it will turn blue.
The temperature alert pre-set
temperatures are 15°C (and
below) and 25°C (and above).
Alerts will be repeated if the
temperature creeps by 2°C into
an alerting range.
The default setting is
Beep&Vibrate.
Select the type of temperature alert
1. Press
. Lightshow is displayed, press until
SetUp is displayed and press
.
2. Crying Alert is displayed, press
until Temp
Alert is displayed and press
.
3. Use the
and buttons to display either
Beep, Beep&Vibe, Vibrate, Screen Only
or Off and press
to select. The display will show
Saved and you will hear a confirmation beep.
To stop an alert beep, press any button on the
Parent unit.
Temperature alert options
Beep = Parent unit will beep.
icon will flash.
Beep&Vibe = Parent unit will beep and vibrate.
icon will flash.
Vibrate = Parent unit will vibrate.
icon
will flash.
Screen Only =
icon will flash.
Off = No alerts.
icon will not be displayed.
All of the above alerts will also display the
appropriate message: Too Hot or Too Cold.
Using your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
36
Crying alert options
Beep = Parent unit will beep,
Crying Alert will be displayed
and icon will flash.
Beep&Vibe = Parent unit will
beep and vibrate. Crying Alert
will be displayed and icon
will flash.
Vibrate = Parent unit will
vibrate only (no alert beep will
sound). Crying Alert will be
displayed and the icon
will flash.
Screen Only = Crying Alert
will be displayed and the
icon will flash.
The default setting is
Beep&Vibrate.
The Crying Alert is a ‘user alert’
as described on page 37.
Crying alert
The crying alert will only be activated if Mute All
has been switched on (or if the Parent unit volume
has been switched to volume off), see page 20 for
information on the Mute All feature.
With Mute All switched on, if your baby starts to cry
you will not be able to hear the cries, but if the cries
sound above a certain level i.e. if they reach 83dBA,
which is the 1st red Baby sound level LED, then the
Parent unit will activate the crying alert. The default
crying alert is for the Parent unit to vibrate and emit
an audible beep but you can select a different alert
if you want to.
Select the type of crying alert
1. Press
. Lightshow is displayed, press until
SetUp is displayed and press
.
2. Crying Alert is displayed, press
.
3. Use the
and buttons to display either
Beep, Beep&Vibe, Vibrate or Screen Only
and press
to select. The display will show
Saved and you will hear a confirmation beep.
To stop an alert beep, press any button on the
Parent unit.
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
Using your BT Digital Baby Monitor & Pacifier 37
Backlight
You can select whether or not the LCD backlight
comes on when an alert is activated. When the
backlight comes on it will stay on for 15 seconds.
The default setting is On.
1. Press
. Lightshow is displayed, press until
SetUp is displayed and press
.
2. Crying Alert is displayed, press
until
Backlight is displayed and press
.
3. Use the
and buttons to display either
On w alerts or Off w alerts and press
to
select. The display will show Saved and you will
hear a confirmation beep.
List of tones
Your Baby Monitor & Pacifier unit can produce
various tones. They have the following meaning:
Tone Meaning
Single tone Confirmation tone e.g. setting saved.
Double tone (fast) Error tone e.g. max volume reached
when adjusting volume.
Double tone (slow) User alert e.g. crying alert, paging alert etc.
Triple tone (fast) System alert e.g. link lost, battery low etc.
Using your BT Digital Baby Monitor & Pacifier
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
38
Resetting the units is
only advisable if you are
experiencing difficulties with
your product. It is a useful
feature that ensures your Baby
Monitor is returned to its new
“out of the box” settings.
User Alert tones can be silenced by pressing any
button on the Parent unit.
System Alerts can be silenced for a 5 minute period
by pressing any button on the Parent unit.
Reset the units
Resetting either units will return the settings at that
unit back to its default settings.
Reset the Parent unit
1. Within 3 seconds of the Parent unit being switched
on, press and hold the
button for at least
10 seconds. The display will show Reset for
2 seconds during the reset and then you will
hear a confirmation beep once the reset has
been performed.
Reset the Baby unit
1. Within 3 seconds of the Baby unit being switched
on, press the
button for at least 10 seconds.
You will hear a confirmation beep once the reset has
been performed.
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
39Help
Helpline
If you have any problems using
your BT Digital Baby Monitor &
Pacifier, call 0808 100 6554*.
Link light does not come on
• Check that both the Baby and Parent
units are switched on.
• Check that the batteries in the Parent
unit are correctly installed and that
they are charged.
• Check that the mains power is
plugged in and switched on at the
Baby unit.
• Check that the units are within range
of each other.
Link light is flashing green
• If you have pressed
to use
the Talk Back feature, the Link
light will flash to indicate one-way
communication between the units.
• The units are searching for a
communication link.
• Check units are within range of
one another.
• Check both units are turned on.
Link light is red
• The link between your units is
broken. You will also hear an alert on
the Parent unit to let you know there
is no communication between the
units. If this happens, check that the
mains power (or batteries) is correctly
connected and that the units are
within range of one another.
See page 15 for instructions on
linking the units.
Battery low on Parent unit
• Put the Parent unit back on the
charger to charge.
• Place Parent unit back on the charger
as frequently as possible or ideally
leave it on the charger to ensure the
batteries remain charged.
Help
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
40
• To shorten the charging time you
can turn the Parent unit off if it is not
being used while it is charging.
Parent unit remains silent or
very quiet
• You may have set the volume
too low, see page 19 to increase
the volume.
• You may have switched a Mute
feature on, see pages 20-21.
You can hear a high pitched noise
• The units might be too close to
each other.
• The volume setting might be too
high, see page 19.
Talk back feature is not working
• Check that the volume is loud
enough at the Baby unit, see
page 19.
• Check the units are linked, see
page 15.
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
41General information
Cleaning
Both units have splash resistant grilles and casing.
To clean, wipe with a damp cloth.
Guarantee
Your BT Digital Baby Monitor & Pacifier is
guaranteed for a period of 12 months from the
date of purchase.
Subject to the terms listed below, the guarantee
will provide for the repair of, or at BT’s or its
agent’s discretion the option to replace the BT
Digital Baby Monitor & Pacifier or any component
thereof, which is identified as faulty or below
standard, or as a result of inferior workmanship of
materials. Products over 28 days old from the date
of purchase may be replaced with a refurbished or
repaired product.
The conditions of this guarantee are:
• The guarantee shall only apply to defects that occur
within the 12 month guarantee period.
• Proof of purchase is required.
• The equipment is returned to BT or its agent as
instructed.
• This guarantee does not cover the batteries and
any faults or defects caused by accidents, misuse,
fair wear and tear, neglect, tampering with the
equipment, or any attempt at adjustment or repair
other than through approved agents.
• This guarantee does not affect your statutory rights.
Within the 12 month guarantee period
Prior to returning your product, please read the
Help section beginning on page 39 or contact the
BT Digital Baby Monitor & Pacifier Helpline on 0808
100 6554* for assistance. Additional answers to
Frequently Asked Questions are available from
www.bt.com/producthelp
In the unlikely event of a defect occurring, the
Helpdesk will issue a Fault Reference Authorisation
(FRA) number and instructions for replacement or
repair. Please note you will need the FRA number
before returning the product. This does not affect
your statutory rights.
Outside of the 12 month guarantee period:
If your product needs repair after the guarantee
period has ended or if you require technical
assistance outside of the 12 month guarantee
period, please call BT’s approved technical
support agent, Discount Communications Ltd
on 0800 980 8999.
General information
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
42
Returning your product
If the Helpline is unable to remedy your problem
they will issue a Fault Reference Authorisation
number and ask you to return the product to your
original place of purchase. Where possible, pack the
product in its original packaging. Please remember
to include all parts, including the power supply
adapters and the original batteries.
For guarantee purposes proof of purchase is
required so please keep your receipt.
Product disposal instructions
The symbol shown here and on the product
means that the product is classed as
Electrical or Electronic Equipment and
should not be disposed with other
household or commercial waste at the
end of its working life.
The Waste of Electrical and Electronic Equipment
(WEEE) Directive (2002/96/EC) has been put in
place to recycle products using best available
recovery and recycling techniques to minimize the
impact on the environment, treat any hazardous
substances and avoid the increasing landfill.
Product disposal instructions for residential users
When you have no further use for it, please remove
any batteries and dispose of them and the product
as per your local authority’s recycling processes.
For more information please contact your local
authority or the retailer where the product was
purchased.
Product disposal instructions for business users
Business users should contact their suppliers and
check the terms and conditions of the purchase
contract and ensure that this product is not mixed
with other commercial waste for disposal.
If you experience any problems, please call the Helpline on Freephone 0808 100 6554* or visit www.bt.com/producthelp
General information 43
R&TTE
This product is intended for use within the UK.
This equipment complies with the essential
requirements for the Radio Equipment and
Telecommunications Terminal Equipment Directive
1999/5/EC.
Declaration of Conformance
Hereby, CCT declares that this BT Digital Baby
Monitor & Pacifier is in compliance with the essential
requirements and other relevant provisions of
Directive 1999/5/EC.
The Declaration of Conformance for the
BT Digital Baby Monitor & Pacifier is available
from www.bt.com/producthelp
User Guide formats
This document is also available in other formats,
such as Large print, Braille and Audio CD. If you
would like a copy, please call 0808 100 6554*.
Offices worldwide
The services described in this publication are subject to availability
and may be modified from time to time. Services and equipment
are provided subject to British Telecommunications plc’s respective
standard conditions of contract. Nothing in this publication forms
any part of any contract.
© British Telecommunications plc 2011.
Registered Office: 81 Newgate Street, London EC1A 7AJ.
Registered in England No. 1800000.
Printed in China.
Designed and produced by The Art & Design Partnership Ltd.
BT Digital Baby Monitor & Pacifier (03/11) Issue 2
Loading...
