LED Floodlight Installation Instructions
Notes before installation:
Please read LED Flood light use manual carefully before installation and follow the instructions.
To avoid accidents like damage, dropping, electric shock, fire, please don't arbitrarily retrofit or change any lamp fittings.
Clean lamps with a soft wrung-out soapy cloth, and then wipe it with a dry cloth. Please don't wipe the lamps with gasoline
or other volatiles. Please don't spray insecticides on the lamps. Otherwise, it may cause discoloration or damage.
Please do not open the lamp without permission.
Please turn off the power when in installation or maintenance.
(ID:G3) FL10W-06 FL20W-06 FL30W-06 FL50W-06 FL70W-06 FL80W-06 FL100W-06
FL120W-06 FL150W-06 FL180W-06 FL200W-06 FL240W-06
1. Installation Dimensions(Unit: mm)
Product name
FL10W/20W-06 (ID:G3)
FL30W/50W-06 (ID:G3)
FL70W/80W-06 (ID:G3)
FL100W/120W-06 (ID:G3)
FL150W/180W/200W-06 (ID:G3)
L2L1
2. Installation Method
01
Brown - L
Blue -- - N
G/Y --- GND
N
L
GND
02
Power
50W
120 W
200 W
D1 D2
150mm
180mm
180mm
8mm
10m m
10m m
L3
100.0 75.050.0 6.58.5
180.0 140.0100.0 8.58.5
220.0180.0140.0 10.510.5
220.0180.0140.0 10.510.5
220.0180.0140.0 10.510.5
03
RoHS
35,000h
Outdoor
Ø2Ø1
04
L1
L2
L3
Ø1
Ø2
05
Caution:
ver tical ins tallatio n
is abso lutely not pe rmitted
1. The external flexible cable or cord of this luminaire cannot be replaced; if the cord is damaged,
the luminaire shall be destroyed.
2. The light source contained in this luminaire shall only be replaced by the manufacturer or his
service agent or a similar qualified person.
Caution, risk of electric shock
3. Attention
1. Install by qualified electricians only.
2. Make sure that the supply voltage is disconnected before installation.
3. Make sure the voltage is suitable with the lamps, And L/N/G connect properly.
4. All the lights during installation or using should not be leds’s cover vertical upside or Vertical down.
5. Don’t open the lamps without Manufacturer’s Authorization.
Caution:
ver tical ins tallatio n
is abso lutely not pe rmitted
