Quick Start Guide
INPUT OUTPUT
VGA
HDMI
DP
DVI-D
DVI-A
Analog audio
+ Ethernet
+ RS-232
+ Infrared
+ GPIO
VGA laptop
HDMI laptop
HD TV
EthernetPower adaptor Infrared
PC MacBook
Relay box
DP
VGA
Audio
HDMI
RS-232
IR
LAN
GPIO
Power
VIDEO AUDIO
VIDEO AUDIO
VIDEO AUDIO
UMX-HDMI-140
Front View
1
VGA input D-SUB connector for analog video signal.
1
Audio1 input 3.5 mm Jack connector for unbalanced analog audio input
2
HDMI input HDMI connector for HDMI or DVI audio/video signal.
3
DisplayPort
4
input
Input status
5
LEDs
signal.
DisplayPort connector for DisplayPort audio/video signal.
LEDs give feedback about the current status of unit and input
signals.
2 3
4
5
Video Select
6
button
Reset button Pushing the button reboots the unit.
7
Audio Select
8
button
Show Me
9
button
Button for selecting a video source.
Button for selecting an audio source.
Special functions are available with this button (bootload
mode, DHCP settings, restore factory default settings,
7
6 8
condition launching in Event Manager).
9
Status LEDs
INPUT STATUS LEDs
VGA
Audio1
HDMI
HDMI
DP
DP
DVI-D
DVI-D
LIVE
VGA
Audio1
HDMI
HDMI
DP
DP
DVI-D
DVI-D
AUTOSELECT
VGA
Audio1
HDMI
HDMI
DP
DP
DVI-D
DVI-D
Live
Autoselect
DVI-A Video
Audio2
Live
Autoselect
DVI-A Video
Audio2
Live
Autoselect
DVI-A Video
Audio2
OFF: input is not selected.
BLINKING: selected input has no signal.
ON: input is selected and signal is present.
OFF: device is not powered.
BLINKING (slow; 1 sec): device is powered
and operational.
BLINKING (fast; 0,5 sec): device is in
bootload mode.
ON: device is powered but not operational.
OFF: Autoselect function is disabled.
BLINKING: Autoselect function is enabled,
searching for signal (the video LEDs are also blink).
ON: Autoselect function is enabled, the active
video signal is found (the selected video input’s
LED is also ON).
Important Safety Instructions
Please read the supplied safety instruction document before using the product and keep it
available for future reference.
Introduction
Thank you for choosing Lightware UMX-HDMI-140 universal switcher. The product switches
universal 4K video and audio to a HDMI output port. This device was designed for digital and
analog video and audio signals: VGA, DVI, HDMI 1.4 and DP 1.1 with analog stereo audio
from local inputs or embedded 7.1 HBR audio. The unit can also handle HDCP encryption.
Analog signals (both audio and video) are converted into digital format.
Box Contents
Switcher unit 12V DC power adaptor
with interchangeable plugs
Phoenix combicon
5-pole connector
Phoenix combicon
8-pole connector
Phoenix combicon
3-pole connector
Quick
Safety and
Start
Warranty
Guide
Info
Safety and warranty info,
Quick Start Guide
Universal Switcher Concept
UMX-HDMI-140 is an universal audio/video switcher with analog/digital converter and audio
embedder function. The device receives analog (VGA, DVI-A) and digital (DP, HDMI, DVI-D)
video signals and transmits HDMI. Analog audio signals can be received via the 3.5” TRS
(jack) and also the 5-pole Phoenix connector. The device can be controlled via Ethernet,
RS-232 or Infrared and is able to control third-party devices via the RS-232, Ethernet, Infrared,
and GPIO interfaces.
Audio1
VGA
LIVE
RESET
Autoselect
AUDIO1 IN HDMI IN DP IN VGA IN
HDMI HDMI
DP
VIDEO AUDIO
DVI-A Video
Audio2
DVI-DDPDVI-D
SHOWMEAUDIO
VIDEO
SELECTINPUT STATUS
SELECT
HDMI
Rear View
1
2
3
4
5
6
Connecting Steps
162 3 4 5 7
12V DC input
connector
RS-232
connector
GPIO 8-pole Phoenix connector for congurable general purpose
Ethernet RJ45 connector for remote controlling and performing
Infrared
connectors
HDMI output HDMI output port for DVI or HDMI signal. Connect an HDMI
Audio
UMX-HDMI-140
12V DC input for local powering.
3-pole Phoenix connector for serial communication.
input/output ports.
rmware upgrade via LAN.
2 TRS (3.5mm jack) connectors for Infrared units (IR IN for
the detector, IR OUT for the emitter).
cable between the switcher and the display device.
DP
LIVE
RESET
Autoselect
DVI-A Video
Audio2
SHOWMEAUDIO
VIDEO
SELECTINPUT STATUS
SELECT
IR
Power
AUDIO1 IN HDMI IN DP IN VGA IN
GPIO
DVIHDMIVGA
Audio1
VGA
HDMI HDMI
DP
DVI-DDPDVI-D
VIDEO AUDIO
LAN
HDMI
RS-232
8
Audio2 input 5-pole Phoenix connector for balanced analog audio input.
7
DVI-I input DVI-I connector for analog / DVI / HDMI signals.
8
Rear panel LEDs
HDMI OUT - SIGNAL LED
ON: signal is present on the port.
HDMI OUT - HDCP LED
OFF: output signal is not HDCP-encrypted.
BLINKING: non-HDCP capable device is connected, encrypted signal is replaced with
red screen.
ON: output signal is HDCP-encrypted.
Connect the switcher and the sources using the inputs and VGA / DVI-I /
DVI
HDMI
Powering on the devices is recommended to do as the nal step during the installation.
HDMI / DisplayPort cables.
Optionally for audio extension: connect the audio source (e.g. VGA laptop)
to the audio input port by an audio cable.
Connect the sink (e.g. HDTV) to the HDMI output port by HDMI cable.
Optionally for RS-232 extension: connect a controller/controlled device
(e.g. HDTV) to the RS-232 port.
Optionally for Infrared extension:
Connect the IR emitter to the IR OUT port of the switcher, and/or
Connect the IR detector to the IR IN port of the switcher.
Optionally connect the switcher to a LAN network in order to control
the device.
Optionally connect a controller/controlled device (e.g. relay box) to the
GPIO port.
Connect the power adaptor to the DC input of the switcher, then to the AC
power socket.
Mounting
To mount the switcher Lightware supplies optional accessories for different usage. There are
two kinds of mounting kits with similar xing method. The switcher has two mounting holes with
inner thread on the bottom side. Fasten the device by the screws enclosed with the accessory.
Under-desk double mounting kit 1U high rack shelf
The Under-desk double mounting kit makes easy to mount a single device on any at surface,
e.g. furniture. 1U high rack shelf provides mounting holes for fastening two half-rack or four
quarter-rack sized units. Pocket-sized devices can also be fastened on the shelf. To order
mounting accessories please contact [email protected].
Using different (e.g. longer) screws may cause damage to the device.
The switcher is half-rack sized.
Locking DC plug
Twist 90° clockwise to lock.
Further information
The document is valid with the following rmware version: 1.0.5
The product brief and further information are available at www.lightware.com.
See the Downloads section on the dedicated product page.
Contact us
+36 1 255 3800
+36 1 255 3810
Lightware Visual Engineering LLC.
Peterdy 15, Budapest H-1071, Hungary
Doc. ver.: 1.1
19200112
Page 2
TX RX
5: Ground
TX RX
5: Ground
Front Panel Operation
1
1
2
VGA HDMI DP DVI-D AutoselectDVI-A
1 5
2
3
4
Analog audio (Jack)
Analog audio (Phoenix)Embedded audio
51
Video Select Button
Use the button to select video input source. The sequence is:
Audio Select Button
Use the button to select audio input source. The sequence is:
Embedded audio is coming from the digital video input port (HDMI / DP / DVI-D) which is
currently selected. If analog video input signal (VGA / DVI-A) is selected which cannot contain
embedded audio, this source will be skipped.
Port Legend
Video only
Audio only
Video with embedded audio
Restore Factory Default Settings
1. Keep the Show Me button pressed for 10 seconds; after 5 seconds front panel LEDs
start to blink but keep the button pressed; the LEDs start to blink faster 5 seconds later.
2. Release the button, then press it 3 times quickly; the following factory default settings
are restored:
Typical Application
Huddle room
Thunderbolt/DisplayPort
HDMI
Analog audio
LAN
VGA
VGA
Lap top
MacBook
HD Display
with built-in speakers
GPIO - General Purpose Input/Output Ports
The device has seven GPIO pins which operate at TTL digital signal levels and can be set to
high or low level (Push-Pull). The direction of the pins can be input or output (adjustable). The
signal levels are the following:
Input voltage (V) Output voltage (V) Max. current (mA)
Logical low level 0 - 0.8 0 - 0.5 30
Logical high level 2 -5 4.5 - 5 18
GPIO connector and plug pin assignment
Pin nr. Signal
1
2
3
4
5
Congurable
6
7
Ground
The total available current of the controller is 180 mA.
1 2 3 4 5 6 7 8
Crosspoint settings
Video - O1 (HDMI out) I1 (VGA in)
Audio - O1 (HDMI out) I1 (Analog audio in 1)
Video port properties
Autoselect Disabled
Emulated EDID on analog video inputs Factory #89: Universal Analog EDID
Emulated EDID on digital video inputs Dynamic #1: Copy EDID from connected
sink device.
Network settings
IP address (static) 192.168.0.100
Subnet mask 255.255.255.0
Static gateway 192.168.0.1
DHCP Disabled
TCP/IP port nr. LW2 / LW3 10001 / 6107
RS-232 settings
RS-232 mode Control
Control protocol LW2
Port setting 57600 BAUD, 8, N, 1
Command injection port 8001
GPIO settings
GPIO output level High
GPIO direction Input
Software Control – Using Lightware Device Controller (LDC)
The device can be controlled from a computer through the Ethernet or
RS-232 ports using Lightware Device Controller. Please download the
application from www.lightware.com, install on a Windows PC or a macOS
and connect to the device via the Ethernet or RS-232 port.
The default IP address of the device is: 192.168.0.100, DHCP is disabled.
Setting a Dynamic IP Address (DHCP)
1. Keep the Show Me button pressed for 5 seconds; all front panel LEDs start to blink.
2. Release the button, then press it 3 times quickly. DHCP is now enabled.
UMX-HDMI-140
Port Diagram
RS-232
HDMI
Lap top
HDMI
Lap top
UMX-HDMI-140
VGA in
HDMI in
DP in
Analog video
A/D converter
Digital video + Digital audio
Digital video + Digital audio
SIGNAL HDCP
IR IN IR OUT
GPIO
RS-232
PIN: 2.1mm
TX RX
12V 1A DC
Mounted
under desk
5:1 digital
A/V switch
Display control over RS-232
DVI-I IN
AUDIO2 IN
De-embedder
HDMI
(10-20 m)
ETHERNET
Digital video
Embedder
HDMI out
Audio Cable Wiring Guide
UMX-HDMI-140 switcher is built with 5-pole Phoenix input connector. See below a few
example of the most common assembling cases.
From balanced output to balanced input
2x6.3 (1/4”) TRS - Phoenix
From unbalanced output to balanced input
3.5 (1/8”) TRS - Phoenix
From balanced output to balanced input
2xXLR - Phoenix
From unbalanced output to balanced input
2xRCA - Phoenix
For more information about audio cable wiring see the user’s manual of the device or the
Wiring Guide on our website www.lightware.com.
Wiring Guide for RS-232 Data Transmission
The device is built with 3-pole Phoenix connector. See the below examples of connecting to a
DCE (Data Circuit-terminating Equipment) or a DTE (Data Terminal Equipment) type device:
Lightware device and a DCE
D-SUB 9 – Phoenix
Lightware device and a DTE
D-SUB 9 – Phoenix
Types of IR connectors (1/8” TRS / TS)
2 pole, 1 ring: IR transmitter 3 pole, 2 rings: IR receiver
Digital
audio
3:1 digital
DVI in
Analog video
A/D converter
Digital video + Digital audio
audio switch
Analog
audio in 1
Analog
audio in 2
Analog audio
Analog audio
A/D converter
A/D converter
Digital audio
Digital audio
Digital
audio
5
9
2: TX data transmit
3: RX data receive
1
6
1
6
2: TX data receive
3: RX data transmit
5
9
For more information about the cable wiring see the user’s manual of the device or the Cable
Wiring Guide on our website www.lightware.com/support/guides-and-white-papers.
Loading...
