DepthQ
HDs3D2
High-Definition Stereoscopic 3D Projector
depthq.com
Page 2
®
DepthQ
HDs3D2
1080p 3D Projector
Our Best Model Yet
®
Every new generation of DepthQ
builds on our original patented design and the
DepthQ® HDs3D2 is our best model yet - a projector
designed by 3D professionals for 3D professionals.
New to the HDs3D2 is HDMI 1.4 connectivity, full HD resolution
1080p 2D & 3D (at 24 or 30 image-pairs/sec)*, dedicated 3D sync,
plus superior contrast, synchronization and crosstalk - to deliver the
highest quality, most satisfying hassle-free 3D experience right out of the box.
DepthQ® HDs3D2 – FULL 3D 1080p
Native full HD 1080p (1920 x 1080) resolution•
2500 ANSI lumens•
10000:1 contrast ratio•
•
3D support for Computer, Blu-ray, Sat/Cable
Boxes and more
NVIDIA 3DTV Play
•
Two HDMI 1.4 inputs, one each of component, •
S-Video, composite, VGA and more
TM
Ready
3D Projectors
VESA standard 3-pin 3D sync output port•
Supports Frame Sequential, Frame Packing, Top/Bottom,
•
and Side-by-Side stereoscopic input formats
•
Single and Double Flash 120Hz*, Triple Flash 144Hz output
3D color management and 3D combination filter•
Screen trigger and USB power port
•
User memory settings•
Internal test patterns, Freeze and Blank Screen function•
Stereoscopic 3D
The DepthQ® HDs3D2 supports multiple forms of stereoscopic 3D including HDMI, Blu-ray, 3D broadcasting, video games and NVIDIA
3DTV PC connectivity – in 1080p Full-HD for your maximum viewing
pleasure. Compatible with the DepthQ
Active Shutter Glasses, and 144Hz DLP Link
®
Polarization Modulator,
TM
3D glasses.
3D Triple Flash
®
HDs3D2 uses the latest Texas Instruments DLP® Dark Chip 3 technology and drivers
(DLP 0.65” 1080p s600 DC3) and incorporates 3D Triple Flash technology.
3D Triple Flash triples the normal HDMI 1.4 1080 24p 3D frame rate of 48 Hz (24 for the right eye
and 24 for the left) to 144 Hz, for an amazingly fluid and flicker-free 3D experience.
The DepthQ
Audio
®
The DepthQ
for bigger, larger than life sound effects. So you can take this complete 3D projection
system anywhere. No additional audio equipment is required.
131496-12
*When using a frame sequential double flash mode, the L>R R>L Eye-Coding will be selected randomly upon projector sync. You may have to use your 3D app to change the
stereo polarity (swap eyes) to correct for pseudo-stereo. Exiting the app or otherwise causing the projector to re-sync may cause the projector to choose a random eye-coding.
HDs3D2 features 10W on-board speaker and SRS WOW HD technology
S&E
N10533
E134786
2K12
I.T.E.
PROJECTOR
Page 3
UNISHAPE Lamp Technology
UNISHAPE (UNIversal SHAPEd Lamp Light Technology) shapes the light to provide the best possible image output for
every millisecond of video – adding contrast to dark scenes, for example, and providing more color variations and
brightness exactly where it’s needed. The light waveform shape is repeated in synchronization with the image processor
and color wheel of the DepthQ HDs3D2 to achieve the very best possible image output.
• Up to 40% brighter*
• At least 60% less dithering noise*
• At least 80% more colors*
• Up to 100% higher contrast*
*Than conventional DVE CW projection systems, depending on projector
Variable Plateau
This is the solution to the problem that the brightness of the image is reduced in existing
technologies due to color correction and dark video enhancement. UNISHAPE™
counteracts this effect by adapting lamp output dynamically to the color wheel segment.
• Up to 40% brighter image*
• Flexible color correction
• Loss-free adjustment of white point
• Full digital control
*Compared to DVE color wheel system
Low Pulse
Above all, UNISHAPE™ microsecond-precision reduction of light power adapted to the
image delivers more colors and better color gradation. Each 50% low pulse doubles
the number of true colors and halves the dithering noise.
• Increases color bit depth
• More colors (1–2 additional bits per color possible)
• Improved color gradients
• Effective image improvement of dark frames
Dynamic Dimming
Especially for dark scenes, conventional technologies have the problem of unsatisfactory color
reproduction and contrast. UNISHAPE™ with dynamic dimming adapts with millisecond precision
to the differences in brightness in the image. That leads to greater contrast and a “blacker black.”
• Up to 43% more colors in dark scenes*
• Higher contrast ratio*
• Replaces the need for mechanical aperture
• Allows smaller projector designs
*In comparison to projection systems without light modulation
Connectivity
The DepthQ® HDs3D2 comes fully loaded with the
latest and complete set of connections:
• HDMI 1.4 x 2 (HDMI cable included)
• VESA 3D sync out
• RS232
• Component
• S-Video
• Composite
• VGA
• USB Type-A (power only)
• USB Mini-B (service only)
• 12V screen trigger
• RCA stereo audio in (L/R)
• 3.5mm stereo audio in
• 3.5mm stereo audio out
Page 4
Specifications*
DepthQ® HDs3D2
1080p (1920 × 1080)Native Resolution
Display Technology
Data Processor
Brightness
Brightness Uniformity
Lamp Life**
Lamp Type
Contrast Ratio
Input Connections
Output Connections
Control
Stereoscopic 3D
Video Compatibility
3D Data Compatibility
2D Data Compatibility
Color Wheel
Color Reproduction
Lens Type
Aspect Ratio
Throw Ratio
Zoom Ratio
Image Size
Projection Distance
H/V Image Shift
Sync - Horizontal Scan Freq
- Vertical Scan Freq
Projection Offset
Keystone Correction
Audio
Audible Noise
Power Supply
Power Consumption
Product Weight
Product Dimensions (W×D×H)
Shipping Weight
Shipping Dim’s (W×D×H)
Security Features
Warranty
Ships with - Accessories
Menu Languages
2500 ANSI lumens (2000 ANSI lumens Eco Mode)
6,000 hours (Eco Mode), 4,500 hours (Standard Mode)
OSRAM UNISHAPE™ lamp with Dynamic Dimming, Low Pulse with µsec precision and Dynamic Variable Plateau Technology
HDMI 1.4 × 2, VGA, Component, S-Video, Composite, RCA stereo audio in (L/R), 3.5mm stereo audio in
3D sync out, RS232, 12V screen trigger, USB Mini-B (service), USB Type-A (power only) 5V, 1.5A
VESA 3D Sync Port for DepthQ® Polarization Modulator or IR emitter + 3D glasses. Supports all major 3D standards for DLP projectors,
including 3D content from PC, Blu-ray, Cable boxes, Dish services, and more (over HDMI at 1080p). Also supports DLP-Link
NTSC/NTSC 4.43, PAL B/G/H/I/M/N 60, SECAM, 1080p/720p/480p/480i
FHD (1920x1080), HD (1280x720), WXGA (1280x800), XGA (1024x768), SVGA (800x600)
WUXGA, UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA, Mac NTSC/PAL/SECAM, SDTV: 576i, 480i, EDTV: 576p, 480p, HDTV: 1080p, 1080i, 720p
16:9 (native), 16:10, 4:3, letter box, 2.35:1 (supported)
~15% of the Projected Image Height, assuming level projector
350 W (Standard Mode), 290 W (Eco Mode), <0.5 W (Standby Mode)
2 years (projector), 6 months (lamp), 90 days (accessories)
Remote control, Lamp, Lens Cap, Power cord (US), DVI to HDMI cable, HDMI cable, Quick Start Guide
Arabic, Brazilian Portuguese, Danish, Dutch, English, Finnish, French, German, Italian, Japanese, Kazakh, Korean,
DLP 0.65” 1080p s600 DC3
2 × LVDS, Max 175MHz, DDP4422
95%
10000:1
3.5mm stereo audio out
6-segment (RGBCMY)
Graphic/Video: 30 bit 1 billion true color
Manual zoom, Manual focus
1.39~2.09:1
Optical zoom: 1.5:1, Digital zoom: 21 steps
25.4 cm - 4.27 m (10 in - 14 ft)
53.1 cm – 8.9 m (20.9 in – 29.3 ft)
+50 -50 pixels (100 total)
15, 30-90KHz
43-85 Hz (120Hz)
+/- 40° (vertical only)
SRS WOW, 10 W speaker
33 dB (Standard Mode), 29 dB (Eco Mode)
AC input 100~240 Voltage (auto ranging)
6.94 lbs / 3.15 kg
11.2 x 10.3 x 4.8 in / 285 × 261 × 122 mm
10.25 lbs / 4.65 kg
14.5 x 15.4 x 8.2 in / 369 × 392 × 208 mm
Security lock slot, Security bar
Norwegian, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Vietnamese
Approvals
CB (International), CCC (China), CE (Europe), C-Tick (Australia), cUL (Canada), EAC (Russia), FCC-B (USA),
PSB (Singapore), TUV-GS (Germany), UL (USA)
* Product specifications, terms, and offerings are subject to change at any time without notice.
** Actual lamp life may vary based on the ambient environment and projector usage. Conditions that may affect lamp life include temperature, altitude, and rapidly switching the projector on and off.
