USER´S MANUAL
MANUAL DE USUARIO
INTRODUCTION
Thank you for purchasing this LIGHTSIDE LED SPOT RGBW. For safety and regular
operation of this product, please read this manual carefully before using and
operating it.
UNPACKING
Open the package and go through the light to see if any damage caused on the way of
transportation. Before turning it on, be sure that the mains voltage within the scope
manual shows.
OPERATION
1.- Make sure the input power is complied with rated voltage, and then turn on it
2.- When not used, turn o light to extend the working time
ADDITIONAL SAFETY INFORMATION
Please be sure to turn o the light before installation and maintenance
Please be sure when operating the light you have good ventilation
This light is design for indoor use. Please keep it dry whenever using.
Do not use other voltage that not complied with the instruction showed
Do not stare at the lighting source, it may damage you eyes
Do not operates unless there is stable voltage
Do not uses it in a moist environment
TECHNICAL SPECIFICATIONS
Input power: AC110-220v, 50-60Hz
Light source: 4x3w RGBW LED 4in1
Channels: 6 DMX 512
Play mode: DMX, Automatic, Music Controlled and Master/Slave
Manual Focus
Dimensions: 140 x 142 x 85mm
Weight: 0.85Kg
ENGLISH
1
一、Function Set :
Menu Value Describe
A___ 001~512 DMX（6CH） / Master-Slave
Run_
0 Close the light
1 R、G、B、W monochrome jump Change
2 R ON ，G、B、W jump Change
3 G ON，R、B、W jump Change
4 B ON，R、G、W jump Change
5 W ON，R、G、B jump Change
6
R、G、B、W gradual change ，Low speed
7 R、G、B、W gradual change ，High speed
8 R、G gradual change，B、W OFF
9 R、B gradual change , G、W OFF
A B、G gradual change ，R、W OFF
b R、G、B、W cross fade
C R、G、B、W Mixed color jump change
Sou_
1 Sound 1
2 Sound 2
3 Sound 3
colr
r000~255
Red Linear control（From dark to bright
）
g000~255 Green Linear control（From dark to bright）
b000~255 Blue Linear control（From dark to bright）
y000~255 White Linear control（From dark to bright）
LEon Digital plate ON (Always)
LOFF Digital Plate will OFF Automatically within 3S
ENGLISH
2
MENU
After starting press MENU enter into main menu
Press UP/DOWN to select the submenu, and then press ENTER to conrm
3
DMX TABLE
ENGLISH
二、DMX Control（A001~512）
CHs Value Function Describe
CH1
0~8 Close the light totally
9~134 R、G、B、W from dark to bright ,Linear Control
CH1 135~239 Strobe ，Speed from Slow to Fast
240~255 Combine CH2\CH3\CH4 & CH5, Adjust color’s brightness
(red, green, blue, wh ite)
CH2 0 RED LIGHT OFF
1~255 Red Linear control ,from dark to bright
CH3 0 Green LIGHT OFF
1~255 Green Linear control ,from dark to bright
CH4 0 Blue LIGHT OFF
1~255 Blue Linear contro l ,from dark to bright
CH5 0 White LIGHT OFF
1~255 White Linear control ,fro m dark to bright
CH6
0~2 1~5CH workabl
e
3~31 R、G、B、W monochrome jump Change
32~63 R ON ，G、B、W jump Change
64~79 G ON，R、B、W jump Change
80~95 B ON，R、G、W jump Change
96~111 W ON，R、G、B jump Change
112~143 R、G、B、W gradual change ，Low speed
144~159 R、G gradual change，B、W OFF
160~175 R、B gradual change , G、W OFF
176~191 B、G gradual change ，R、W OFF
192~207 R、G、B、W cross fade
208~223 R、G、B、W Mixed color jump change
224~239 Sound 1
240~249 Sound 2
250~255 Sound 3
INTRODUCCIÓN
Gracias por adquirir LED SPOT RGBW de LIGHTSIDE. Por seguridad y para el
funcionamiento de este producto, porfavor lea este manual cuidadosamente
antes de usarlo.
DESEMBALAJE
Abra el embalaje y compruebe que no existen daños causados por el transporte. Antes
de encenderlo, asegurese que el voltaje coincide con el presentado en este manual
FUNCIONAMIENTO
1.- Asegúrese de que la potencia de entrada cumple con la tensión nominal y, a
continuación, enciendalo.
2.- Cuando no se utilize, mantengalo apagado.
INFORMACIÓN SOBRE SEGURIDAD
Porfavor aseguresé de apagarlo antes de la instalación o mantenimiento
Aseguresé de que el aparato tenga buena ventilación durante su funcionamiento
Este producto esta diseñado para interior. Porfavor mantengalo lejos de la humedad
durante su funcionamiento.
No use un voltaje que no cumpla las especicaciones mostradas en este manual
No mire la fuente de iluminación, puede dañar los ojos
No haga funcionar a menos que haya un voltaje estable
No lo utilize en un ambiente húmedo
ESPECIFICACIONES
Alimentación: AC110-220v, 50-60Hz
Potencia: 4x3w RGBW LED 4en1
Canales: 6 DMX 512
Modos: DMX, Automatic, Music Controlled and Master/Slave
Enfoque Manual
Dimensiones: 140 x 142 x 85mm
Peso: 0.85Kg
ESPAÑOL
4
一、Function Set :
Menu Value Describe
A___ 001~512 DMX（6CH） / Master-Slave
Run_
0 Close the light
1 R、G、B、W monochrome jump Change
2 R ON ，G、B、W jump Change
3 G ON ，R、B、W jump Change
4 B ON，R、G、W jump Change
5 W ON，R、G、B jump Change
6
R、G、B、W gradual change ，Low speed
7 R、G、B、W gradual change ，High speed
8 R、G gradual change，B、W OFF
9 R、B gradual change , G、W OFF
A B、G gradual change ，R、W OFF
b R、G、B、W cross fade
C R、G、B、W Mixed color jump change
Sou_
1 Sound 1
2 Sound 2
3 Sound 3
colr
r000~255
Red Linear control（From dark to bright
）
g000~255 Green Linear control（From dark to bright）
b000~255 Blue Linear control（From dark to bright）
y000~255 White Linear control（From dark to bright）
LEon Digital plate ON (Always)
LOFF Digital Plate will OFF Automatically within 3S
ESPAÑOL
2
MENU
After starting press MENU enter into main menu
Press UP/DOWN to select the submenu, and then press ENTER to conrm
3
TABLA DMX
ESPAÑOL
二、DMX Control（A001~512）
CHs Value Function Describe
CH1
0~8 Close the light totally
9~134 R、G、B、W from dark to bright ,Linear Control
CH1 135~239 Strobe ，Speed from Slow to Fast
240~255 Combine CH2\CH3\CH4 & CH5, Adjust color’s brightness
(red, green, blue, wh ite)
CH2 0 RED LIGHT OFF
1~255 Red Linear control ,from dark to bright
CH3 0 Green LIGHT OFF
1~255 Green Linear control ,from dark to bright
CH4 0 Blue LIGHT OFF
1~255 Blue Linear contro l ,from dark to bright
CH5 0 White LIGHT OFF
1~255 White Linear control ,fro m dark to bright
CH6
0~2 1~5CH workabl
e
3~31 R、G、B、W monochrome jump Change
32~63 R ON ，G、B、W jump Change
64~79 G ON，R、B、W jump Change
80~95 B ON，R、G、W jump Change
96~111 W ON，R、G、B jump Change
112~143 R、G、B、W gradual change ，Low speed
144~159 R、G gradual change，B、W OFF
160~175 R、B gradual change , G、W OFF
176~191 B、G gradual change ，R、W OFF
192~207 R、G、B、W cross fade
208~223 R、G、B、W Mixed color jump change
224~239 Sound 1
240~249 Sound 2
250~255 Sound 3
