Tangent
1 1/2 in
[39 mm]
1 in
[27 mm]
3 7/8 in
[97 mm]
3 3/8 in
[85 mm]
1 in
[25 mm]
1 5/8 in
[43 mm]
2
1
6
7
3
4
™
Track Lighting System FXT4P
Page 1 of 1 T4 Pendant
Ordering Information
Catalog No. Finish Track Mountings Lamps
FX T4P
Silver For use on all Tangent Track systems. For
Features
1. Transformer: Class two electronic transformer for 12V Halogen lamps.
2. Track At tachment fitting: Molded thermoplastic clamping adapter with
captive, nickel-plated steel pin. Clockwise rotation of pin secures fixture
adapter to track.
3. Splicing Chamber: Allows for field cut ting of power cable.
4. Power Cable: 1/8" dia. cord with nickel plated braided metal sleeving;
field cut table; 6' max suspension.
5. Socket: Bi-pin low voltage halogen socket with multipoint
contact.
6. Lamp Husk: Die-cast aluminum with brushed finish; circular brim supports
shades.
7. Glass Lamp Guard: Satin finish for effective light diffusion.
Compatible with all Lytejacks shades.
Dimming
Use only dimmers specifically designed for use with electronic transformers.
Low Voltage fixtures may produce audible sound when dimmed.
Finish
All Painted finishes are baked enamel.
Accessories
No accessory capabilit y.
ceiling or suspended track installation. Not
for use on wall mounted track.
Labels
cULus Listed
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • A0407
12V T4 2-pin
GY6.35 Base
35W Max
