Calculite®ProSpec
42 1/4"
8"
1
3"
16"
8" Depth
1
3/4"
24"L x 6"W Opening
6
"OC
6
"OC
6
"OC
3
9 1/2"L x 10"W
Tri ml es s
Flanged
Top View
9
10
5
6
1
12
3
2
11
4
8
®
Linear Downlight PB4H3039
Page 1 of 2 4 Light PAR30 MH Series B
Ceiling Cutout: 25 1/16" L x 7 3/16" W
Ordering Information: PAR30 MH Series B
Cat. No. Lamp Ceiling Trim Aperture finish
PB4H3039BL (4) 39W PAR30 MH Overlap Black with White Flange
PB4H3039WL (4) 39W PAR30 MH Overlap White with White Flange
PB4H3039BTL (4) 39W PAR30 MH Trimless Black
PB4H3039WTL (4) 39W PAR30 MH Trimless White
Features
1. Aperture Frame: Provides clean support for lamp holders and overlapping
flange or trimless installation. Extruded aluminum. Rigidly welded together
on all corners.
2. Media Cartridge: Allows convenient loading and removal of up to two
accessories. Easily installed and removed for lamping with a simple twisting
motion. Constructed of formed aluminum.
3. Adjustable Ring: Allows 360° horizontal and min. 40°, max. 45° (on length);
4. Tortionite Spring: For easy installation of aperture frame.
5. Housing: Die-formed 22 ga. steel. Finish: Black
6. Mounting Brackets: Adjustable vertically from inside or outside of housing.
7. Thermal Protector: Meets NEC and UL requirements.
8. Lampholder: Porcelain medium based; nickel plated screw shell. 5KV pulse
9. Ballast Housing: Die-formed 18 ga. steel.
10. Junction Box: 14 ga. steel, 4 x 3 1/2 x 2” box. Allows inspection from
11. Lamp and Accessory Support: .032" steel, flared for easy entry of Media
12. Lens Retaining Ring: .093" spring steel rod. Holds accessories in place.
Electrical
Electronic Ballast: Individual for each lamp. High Power Factor. Input watts:
44, line current: .37 amps. Accessible from below.
UL listed for through branch circuit wiring with maximum of (8) no. 12 AWG,
90°C.
30° (on width) vertical adjustment.
rated, prewired with #18 SF-1 leads to ballast housing.
below.
Cartridge.
PB4H3039BL = (Flanged) Black/White
PB4H3039WL = (Flanged) White
PB4H3039BTL = (Trimless) Black
PB4H3039WTL = (Trimless) White
Finish
All painted finishes are powder coated baked enamel.
Options and Accessories
Accessories: 3 3/4" dia. series, filters, lenses, screens, and louvers (1) max.
Labels
UL/cUL (Suitable for Damp Location), I.B.E.W.
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • B0711
Calculite®ProSpec
®
Linear Downlight PB4H3039
Page 2 of 2 4 Light PAR30 MH Series B
Accent Lighting Performance Data
(FC) is initial footcandles at center of
beam.
Beam length (L) and beam width (W) are
to where the candlepower is reduced to
50% of center beam candlepower.
CBCP is center beam candlepower.
(C) is distance to the center of the beam.
Performance data shown is based on bare
lamp photometrics of MasterColor lamps
by Philips Lighting. Contact lamp
manufacturers for availability and
performance.
39W
Lamp
39W PAR30
SP
39W PAR30
FL
Beam Spread Rated
0% Max CP CBCP Life-Hrs
5
6500
9000
9000
42000
0°
1
30°
0° Aiming angle 30° Aiming Angle 30° Aiming Angle 40° Aiming Angle
FC LW
D
15’ 187 2.6’ 2.6’
0’ 105 3.5’ 3.5’
2
5’ 67 4.4’ 4.4’
2
30’ 47 5.2’ 5.2’
’ 133 3.8’ 3.8’
7
10’ 65 5.4’ 5.4’
13’ 38 7.0’ 7.0’
16’ 25 8.6’ 8.6’
DCFC LW D CFC LW D CFC LW
10’ 5.8’ 273 2.3’ 2.0’
5’ 8.7’ 121 3.5’ 3.0’
1
0’ 11.5’ 68 4.7’ 4.0’
2
25’ 14.4’ 44 5.8’ 5.1’
’ 3.5’ 117 4.4’ 3.7’
6
9’ 5.2’ 52 6.6’ 5.6’
12’ 6.9’ 29 8.8’ 7.4’
15’ 8.7’ 19 11.0’ 9.9’
5’ 8.7’ 210 3.6’ 1.7’
’ 13.9’ 82 5.7’ 2.8’
8
1’ 19.1’ 43 7.9’ 3.8’
1
14’ 24.2’ 27 10.0’ 4.9’
’ 3.5’ 203 5.5’ 2.1’
2
3’ 5.2’ 90 8.2’ 3.2’
4’ 6.9’ 51 10.9’ 4.3’
5’ 8.7’ 33 13.7’ 5.4’
8’ 9.5’ 174 3.4’ 2.2’
2’ 14.3’ 77 5.1’ 3.3’
1
6’ 19.1’ 44 6.9’ 4.4’
1
20’ 23.8’ 28 8.6’ 5.5’
’ 4.6’ 108 5.8’ 3.2’
4
6’ 7.2’ 48 8.7’ 6.0’
8’ 9.5’ 27 11.6’ 6.7’
10’ 11.9’ 17 14.4’ 8.3’
Job Information Type:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • B0711
