Lytecaster 1052LV
Specification
2 pgs165.27 Kb0

Lightolier Lytecaster 1052LV Specification

Download
Lytecaster
®
Recessed Downlighting 1052LV
Page 1 of 2 5” Aperture Low Voltage Pinhole Reflector Trim
6 5/8”
6 5/8”
1052LV/1000LVNT
MR16 Remote Transformer
7 1/4”
1052LV/1000LV
Standard MR16
1052LV/1004ICV/N
0
6 5/8”
1052LV/1000LVR
Remodeler/Non-IC
™
AirSeal® Insulated Ceiling
35˚
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Low Voltage
Frame-In Kit Installation Type Lamping Height
1000LV 1000LVE1
1052LV
Matte White
1000LVE2 1000LVRE1
1000LVR
1000LVNT
1004ICV/N 1000ICV 1920LV
Features
1. Housing: Hydroformed aluminum, .040” thick (18 ga.); matte white trim
flange.
2. Aperture Plate: Die-formed, 20 ga. steel, matte white finish. Inner shield
welded to aperture plate; matte black finish; cuts off glare at normal viewing angles.
3. Support Ring Assembly: Provides 358° horizontal rotation and 0° to 35°
vertical adjustment. Matte white finish.
4. Frame-In Kit: (1000LV standard frame shown) Other frames listed above and
shown on the right. See Frame-In Kit specification sheets for more details.
Non-IC 42W - 65W MR16 6 5/8"
Non-IC Remodeler 42W - 65W MR16 6 5/8”
Non-IC Remote Trans 20W - 65W MR16 6 5/8”
AirSeal® IC 20W - 37W MR16 6 5/8” IC 20W - 35W MR16 7 5/16” Conversion Kit 20W - 50W MR16 6 5/8”
Labels
UL (Suitable for Damp Locations), I.B.E.W.
Job Information Type:
Job Name:
Cat. No.:
Options & Accessories
Retaining Clips: 1955 - For Installing in Existing Ceiling Extra Wide Trim Flange: 1957 - 7" Outside diameter. MR16 Replacement socket: 1975B
Lamp(s): Notes:
Lightolier a Genlyte company www.lightolier.com
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • H0811
Lytecaster
®
Recessed Downlighting 1052LV
Page 2 of 2 5” Aperture Low Voltage Pinhole Reflector Trim
ACCENT LIGHTING PERFORMANCE DATA UL
(FC) is initial footcandles at center of beam.
Beam length (L) and beam width (W) are to where the candlepower is reduced to 50% of center beam candlepower.
CBCP is center beam candlepower. (C) is distance to the center of the beam.
Lamp data shown is typical, and is based on bare lamp photometrics. Contact lamp manufacturers for availability and performance.
0° AIMING ANGLE 30° AIMING ANGLE 30° AIMING ANGLE
Lamps
(To 50% CBCP) Life (Hrs.)
MR16 LOW VOLTAGE HALOGEN BI-PIN LAMPS
20W MR16 VNSP (EZX) 7˚
20W MR16 NSP (ESX) 13˚
20W MR16 FL (BAB) 40˚
35W MR16 NSP (FRB) 12˚
35W MR16 SP (FRA) 20˚
35W MR16 FL (FMW) 40˚
37W MR16 IR NSP 10˚
37W MR16 IR NFL 25˚
37W MR16 IR FL 40˚
42W MR16 VNSP (EZY) 9˚
50W MR16 NSP (EXT) 14˚
50W MR16 NFL (EXZ) 27˚
50W MR16 FL (EXN) 40˚
50W MR16 WFL (FNV) 55˚
Beam Spread
Rated
CBCP
8200 3000
3600 3000
525 4000
8700 4000
3900 4000
1600 4000
11,500 4000
3,500 4000
2,050 4000
13,100 3500
10,200 4000
3400 4000
1850 4000
1150 4000
D FC L W D C FC L W D C FC L W
7’ 167 0.9’ 0.9’ 10’ 82 1.2’ 1.2’ 13’ 49 1.6’ 1.6’ 16’ 32 2.0’ 2.0’
6’ 100 1.4’ 1.4’ 8’ 56 1.8’ 1.8’ 10’ 36 2.3’ 2.3’ 12’ 25 2.7’ 2.7’
2’ 131 1.5’ 1.5’ 3’ 58 2.2’ 2.2’ 4’ 33 2.9’ 2.9’ 5’ 21 3.6’ 3.6’
7’ 178 1.5’ 1.5’ 10’ 87 2.1’ 2.1’ 13’ 51 2.7’ 2.7’ 16’ 34 3.4’ 3.4’
6’ 108 2.1’ 2.1’ 8’ 61 2.8’ 2.8’ 10’ 39 3.5’ 3.5’ 12’ 27 4.2’ 4.2’
4’ 100 2.9’ 2.9’ 6’ 44 4.4’ 4.4’ 8’ 25 5.8’ 5.8’ 10’ 16 7.3’ 7.3’
6’ 180 1.4’ 1.4’ 12’ 80 2.1’ 2.1’ 16’ 45 2.8’ 2.8’ 20’ 29 3.5’ 3.5’
6’ 97 2.7’ 2.7’ 8’ 55 3.5’ 3.5’ 10’ 35 4.4’ 4.4’ 12’ 24 5.3’ 5.3’
4’ 128 2.9’ 2.9’ 6’ 57 4.4’ 4.4’ 8’ 32 5.8’ 5.8’ 10’ 21 7.3’ 7.3’
8’ 205 1.3’ 1.3’ 12’ 91 1.9’ 1.9’ 16’ 51 2.5’ 2.5’ 20’ 33 3.1’ 3.1’
8’ 159 2.0’ 2.0’ 12’ 71 2.9’ 2.9’ 16’ 40 3.8’ 3.9’ 20’ 26 4.9’ 4.9’
6’ 94 2.9’ 2.9’ 8’ 53 3.8’ 3.8’ 10’ 34 4.8’ 4.8’ 12’ 24 5.8’ 5.8’
4’ 116 2.9’ 2.9’ 6’ 51 4.4’ 4.4’ 8’ 29 5.8’ 5.8’ 10’ 19 7.3’ 7.3’
3’ 128 3.1’ 3.1’ 5’ 46 5.2’ 5.2’ 7’ 23 7.3’ 7.3’ 9’ 14 9.4’ 9.4’
6’ 3.5’ 148 1.0’ 0.8’
9’ 5.2’ 66 1.5’ 1.3’ 12’ 6.9’ 37 2.0’ 1.7’ 15’ 8.7’ 24 2.3’ 2.1’
5’ 2.9’ 94 1.5’ 1.3’
7’ 4.0’ 48 2.1’ 1.8’ 9’ 5.2’ 29 2.7’ 2.4’ 11’ 6.4’ 19 3.4’ 2.9’
2’ 1.2’ 85 2.0’ 1.7’
3’ 1.7’ 38 3.0’ 2.5’ 4’ 2.3’ 21 4.1’ 3.4’ 5’ 2.9’ 14 5.1’ 4.2’
6’ 3.5’ 157 1.7’ 1.5’
9’ 5.2’ 70 2.5’ 2.2’ 12’ 6.9’ 39 3.4’ 2.9’ 15’ 8.7’ 25 4.2’ 3.6’
5’ 2.9 101 2.4’ 2.0’
7’ 4.0’ 52 3.3’ 2.9’ 9’ 5.2’ 31 4.3’ 3.7’ 11’ 6.4’ 21 5.2’ 4.5’
3’ 1.7’ 115 3.0’ 2.5’
5’ 2.9’ 42 5.1’ 4.2’ 7’ 4.0’ 21 7.1’ 5.8’ 9’ 5.2’ 13 9.1’ 7.6’
7’ 4.0’ 152 1.6’ 1.4’
10’ 5.8’ 75 2.3’ 2.0’ 13’ 7.5’ 44 3.0’ 2.8’ 16’ 9.2’ 29 3.7’ 3.2’
5’ 2.9’ 91 3.0’ 2.6’
7’ 4.0’ 46 4.2’ 3.6’ 9’ 5.2’ 28 5.4’ 4.6’ 11’ 6.4’ 19 6.6’ 5.6’
3’ 1.7’ 148 3.0’ 2.5’
5’ 2.9’ 53 5.1’ 4.2’ 7’ 4.0’ 27 7.1’ 5.9’ 9’ 5.2’ 16 9.1’ 7.6’
7’ 4.0 174 1.5’ 1.3’
10’ 5.8’ 85 2.1’ 1.8’ 13’ 7.5’ 50 2.7’ 2.4’ 16’ 9.2’ 33 3.4’ 2.9’
7’ 4.0’ 135 2.3’ 2.0’
10’ 5.8’ 66 3.3’ 2.8’ 13’ 7.5’ 39 4.3’ 3.7’ 15’ 9.2’ 28 5.3’ 4.5’
5’ 2.9’ 88 3.3’ 2.8’
7’ 4.0’ 45 4.6’ 3.9’ 9’ 5.2’ 27 5.9’ 5.0’ 11’ 6.4’ 18 7.2’ 6.1’
3’ 1.7’ 134 3.0’ 2.5’
5’ 2.9 48 5.1’ 4.2’ 7’ 4.0’ 25 7.1’ 5.9’ 9’ 5.2’ 15 9.1’ 7.6’
3’ 1.7’ 83 4.6’ 3.6’
5’ 2.9’ 30 7.6’ 6.0’ 7’ 4.0’ 15 10.7’ 8.4’ 9’ 5.2’ 9 13.7’ 10.8’
2’ 3.5 256 1.0’ 0.5’ 3’ 5.2’ 114 1.5’ 0.7’ 4’ 6.9’ 64 2.0’ 1.0’ 5’ 8.7’ 41 2.5’ 1.2’
2’ 3.5’ 113 1.9’ 0.9’ 3’ 5.2’ 50 2.8’ 1.4’ 4’ 6.9’ 28 3.8’ 1.8’ 5’ 8.7’ 18 4.7’ 2.3’
1’ 1.7’ 66 4.8’ 1.5’ 2’ 3.5’ 16 9.7’ 2.9’ 3’ 5.2’ 7 14.5’ 4.4’ 4’ 6.9’ 4 19.3’ 5.8’
2’ 3.5’ 272 1.7’ 0.8’ 3’ 5.2’ 121 2.6’ 1.3’ 4’ 6.9’ 68 3.5’ 1.7’ 5’ 6.7’ 44 4.3’ 2.1’
2’ 3.5’ 122 3.1’ 1.4’ 3’ 5.2’ 54 4.7’ 2.1’ 4’ 6.9’ 30 6.2’ 2.8’ 5’ 8.7’ 20 7.8’ 3.5’
1’ 1.7’ 200 4.8’ 1.5’ 2’ 3.5’ 50 9.7’ 2.9’ 3’ 5.2’ 22 14.5’ 4.4’ 4’ 6.9’ 13 19.3’ 5.8’
3’ 5.2’ 160 2.1’ 1.0’ 4’ 6.9’ 90 2.9’ 1.4’ 5’ 8.7’ 58 3.6’ 1.7’ 6’ 10.4’ 40 4.3’ 2.1’
2’ 3.5’ 109 4.2’ 1.8’ 3’ 5.2’ 49 6.2’ 2.7’ 4’ 6.9’ 27 8.3’ 3.5’ 5’ 8.7’ 18’ 10.4’ 4.4’
1’ 1.7’ 258 4.8’ 1.5’ 2’ 3.5’ 64 9.7’ 2.9’ 3’ 5.2’ 28 14.5’ 4.4’ 4’ 6.9’ 16 19.3 5.8’
3’ 5.2’ 182 1.9’ 0.9’ 4’ 6.9’ 102 2.6’ 1.3’ 5’ 8.7’ 66 3.2’ 1.6’ 6’ 10.4 45 3.8’ 1.9’
3’ 5.2’ 142 3.1’ 1.5’ 4’ 6.9’ 80 4.1’ 2.0’ 5’ 8.7’ 51 5.1’ 2.5’ 6’ 10.4’ 35 6.2’ 2.9’
2’ 3.5’ 106 4.6’ 1.9’ 3’ 5.2’ 47 7.0’ 2.9’ 4’ 6.9’ 27 9.3’ 3.6’ 5’ 8.7’ 17 11.6’ 4.8’
1’ 1.7’ 231 4.8’ 1.5’ 2’ 3.5’ 58 9.7’ 2.9’ 3’ 5.2’ 26 14.5’ 4.4’ 4’ 6.9’ 14 19.3’ 5.8’
1’ 1.7’ 144 22.3’ 2.1’ 2’ 3.5’ 36 44.5’ 4.2’ 3’ 5.2’ 16 66.8’ 6.2’ 4’ 6.9’ 9 89.1’ 8.3’
35˚
Job Information Type:
Lightolier a Genlyte company www.lightolier.com
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • H0811
