Lightolier 8675BD12 User Manual

Lytespan

®

Track Lighting 8675BD12

Page 1 of 2 Display Jacks Sof-Tech®Open Ring MR16

3

POWER JACK

8

MATING SURFACE

180˚ Vertical

Rotation

2 7/8"

Ordering Information

4 1/4"

11 1/2"

3 13/16"

7/16"

2 1/2" DIA

3"

3 3/8"

4

7
2

6

1

5

MATING SURFACE

Catalog No. Finishes Mountings Lamps

8675BD12 WH Matte White All Power Jacks MR16 Bi-Pin
8675BD12 BK Matte Black (Does not mount into 50W Max.

Extender Stems)

9

POWER JACK

360˚

Horizontal

Rotation

Features

1. Ring: die-cast aluminum with cool grip insulation band, a high temperature

silicone rubber which allows aiming adjustments while fixture is on.

2. Socket: bi-pin base ceramic socket, prewired with 18 ga.stranded Teflon
leads with fiberglass outer sleeve.

3. Male Jack Connector: mounted 3/8" dia. stainless steel stem plugs into
any 8600 Power Jack, allows for continuous horizontal rotation.

4. Tension Pivot Mount: die-cast aluminum. Allows for 180°vertical rotation.

5. Lamp Guard: tempered glass.

6. Spring: steel springs hold lamp and housing in place.

7. Socket Boot: high temperature insulated silicone rubber and aluminum heat

shield encases socket.

8. Stem lock: plastic bushing used to lock fixture into Power Jack.

9. Set screw: Locks horizontal rotation.

Finish

All painted finishes are baked enamel.

Options & Accessories

Accessory Holder 7662 Sof-Tech series; holds one accessory.
All 2" Color Filters AF2 (BL, RD, MM, YG, BG, MA, SP, LS,

SB, BA, DA, LP, GR)
Prismatic Spread Lens AF2SY
Beam Elongator AF2AS
UV Filter AF2UV
Beam Smoother AF2LF
Hexcell Louver AL2HC

Electrical/Dimming

For dimming information refer to Power Jack specification sheets.

Labels

UL

Job Information Type:

Job Name:
Cat. No.:

Lamp(s):
Notes:

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • B0806

Lytespan

®

Track Lighting 8675BD12

Page 2 of 2 Display Jacks Sof-Tech®Open Ring MR16

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902

Job Information Type:

Lighting Data

Aiming Angle: 0º 30º 45º or 60º Horizontal 30º 45º or 60º Vertical

L Beam length
W Beam width
C Distance to center of beam
D Distance
A Aiming angle
FC Footcandles
L and W are the outer points where the candlepower

drops to 50% of the maximum. FC are the initial
footcandles at the center of the beam.

Lamp O° Aiming Angle A = 30° Aiming Angle A = 45° Aiming Angle A = 60° Aiming Angle

D

L

FC

W

FC

Beam Spread
50% Max CP

20W MR16 (T-H)

VNSP (EZX) 7˚

20W MR16 (T-H)

NSP (ESX) 13˚

20W MR16 (T-H)

FL (BAB) 40˚

35W MR16 (T-H)

NSP (FRB) 12˚

35W MR16 (T-H)

SP (FRA) 20˚

42W MR16 (T-H)

VNSP (EZY) 9˚

50W MR16 (T-H)

NFL (EXZ) 27˚

50W MR16 (T-H)

FL (EXN) 40˚

50W MR16 (T-H)

WFL (FNV) 55˚

75W MR16 (T-H)

NSP (EYF) 14˚

75W MR16 (T-H)

NFL (EYJ) 25˚

75W MR16 (T-H)

FL (EYC) 42˚

Beam Center

C.P. Candelas

Rated

Life-Hrs

8200 3000

3600 3000

525 4000

8700 4000

3900 4000

13100 3500

3400 4000

1850 4000

1150 4000

12000 4000

4900 4000

2100

4000

DFCL W D C FCL W D CFCL W D CFC LW

67 0.9' 0.9'

7' 1
10' 82 1.2' 1.2'
13' 49 1.6' 1.6'
16' 32 2.0' 2.0'

6' 100 1.4' 1.4'

8' 58 1.8' 1.8'
10' 38 2.3' 2.3'
12' 25 2.7' 2.7'

1 1.5' 1.5'

2' 13

2.2' 2.2'

3' 58

4' 33 2.9' 2.9'

5' 21 3.6' 3.6'

7' 178 1.5' 1.5'
10' 87 2.1' 2.1'
13' 51 2.7' 2.7'
16' 34 3.4' 3.4'

6' 108 2.1' 2.1'

8' 61 2.8' 2.8'
10' 39 3.5' 3.5'
12' 27 4.2' 4.2'

8' 205 1.3' 1.3'
12' 91 1.9' 1.9'
16' 51 2.5' 2.5'

6

' 94 2.9' 2.9'

8' 53 3.8' 3.8'
10' 34 4.8' 4.8'

4' 116 2.9' 2.9'

6' 51 4.4' 4.4'

8' 29 5.8' 5.8'

3' 128 3.1' 3.1'

5' 46 5.2' 5.2'

7' 23 7.3' 7.3'

8' 188 2.0' 20'
12' 83 2.9' 2.9'
16' 47 3.9' 3.9'

6' 136 2.7' 2.7'

8' 77 3.5' 3.5'
10' 49 4.4' 4.4'

4' 131 3.1' 3.1'

6' 58 4.6' 4.6'

8' 33 6.1' 6.1'

12' 6.9' 37 2.0' 1.7'
15' 8.7' 24 2.4' 2.1'

11' 6.4' 19 3.4' 2.9'

12' 6.9' 39 3.4' 2.9'
15' 8.7' 25 4.2' 3.6'

19' 5.2' 31 4.3' 3.7'

111' 6.4' 21 5.2' 4.5'

20' 33 3.1' 3.1'

10' 5.8' 85 2.1' 1.8'
13' 7.5' 50 2.7' 2.4'
12' 24 5.8' 5.8'

10' 19 7.3' 7.3'

20' 30 4.9' 4.9'

10' 5.8' 78 3.3' 2.8'
13' 7.5' 46 4.3' 3.7'
12' 34 5.3' 5.3'

10' 21 7.7' 7.7'

148 1.0' 0.8'

6' 3.5'
9' 5.2' 66 1.5' 1.3'

5' 2.8' 94 1.5' 1.3'
7' 4.0' 48 2.1' 1.8'
9' 5.2' 29 2.7' 2.4'

2' 1.2' 8
3' 1.7' 3
4' 2.3' 21 4.1' 3.4'
5' 2.9' 14 5.1' 4.2'

6' 3.5' 157 1.7' 1.5'
9' 5.2' 70 2.5' 2.2'

5' 2.9' 101 2.4' 2.0'
7' 4.0' 52 3.3' 2.9'

7' 4.0' 174 1.5' 1.3'

5' 2.9' 88 3.3' 2.8'
7' 4.0' 45 4.6' 3.9'
9' 5.2' 27 5.9' 5.0'

3' 1.7' 134 3.0' 2.5'
5' 2.9' 48 5.1' 4.2'
7' 4.0' 25 7.4' 5.9'
9' 14 9.4' 9.4'

3' 1.7' 83 4.6' 3.6'
5' 2.9' 30 7.8' 6.0'
7' 4.0' 15 10.7' 8.4'

7' 4.0' 159 2.3' 2.0'

5' 2.9' 127 3.0' 2.6'
7' 4.0' 65 4.2' 3.6'
9' 5.2' 39 5.4' 4.6'

3' 1.7' 152 3.2' 2.7'
5' 2.9' 55 5.4' 4.4'
7' 4.0' 28 7.5' 6.2'

5 2.0' 1.7'
8 3.0' 2.5'

181 1.0' 0.7'

4' 4.0'
6' 6.0' 81 1.5' 1.0'
8' 8.0' 45 2.0' 1.4'

10' 10.0' 29 2.5' 1.7'

3' 3.0' 141 1.4' 1.0'
5' 5.0' 51 2.3' 1.6'
7' 7.0' 28 3.2' 2.3'
9' 9.0' 18 4.2' 2.9'

2' 2.0' 4
3' 3.0' 2
4' 4.0' 12 6.7' 4.1'
5' 5.0' 7 8.4' 5.1'

4' 4.0' 192 1.7' 1.2'
6' 6.0' 85 2.6' 1.8'
8' 8.0' 48 3.4' 2.4'

10' 10.0' 31 4.3' 3.0'

3' 3.0' 153 2.2' 1.5'
5' 5.0' 55 3.6' 2.5'
7' 7.0' 28 5.1' 3.5'
9' 9.0' 17 6.6' 4.5'

16' 9.2' 33 3.4' 2.9' 11' 11.0' 38 3.5' 2.4'

5' 5.0' 185 1.6' 1.1'
7' 7.0' 95 2.2' 1.6'
9' 9.0' 57 2.9' 2.0'

11' 6.4' 18 7.2' 6.1'

3' 3.0' 134 3.1' 2.0'
5' 5.0' 48 5.1' 3.4'
7' 7.0' 25 7.1' 4.8'
9' 5.2' 15 9.1' 7.6'

3' 3.0' 73 5.0' 3.1'
4' 4.0' 41 6.7' 4.1'
5' 5.0' 26 8.4' 5.1'
9' 5.2' 9 13.7' 10.8'

2' 2.0' 102 5.7' 2.9'
3' 3.0' 45 8.6' 4.4'
4' 4.0' 25 11.4' 5.9'

16' 9.2' 30 5.3' 4.5'

5' 5.0' 170 2.5' 1.7'
7' 7.0' 87 3.5' 2.4'
9' 9.0' 52 4.5' 3.1'

11' 6.4' 26 6.0' 5.6'

3' 3.0' 192 2.8' 1.9'
5' 5.0' 69 4.7' 3.1'
7' 7.0' 35 6.5' 4.4'
9' 5.2' 17 9.7' 8.0'

3' 3.0' 82 5.4' 3.3'
4' 4.0' 46 7.2' 4.3'

5' 5.0' 30 9.0' 5.4'

5 3.4' 2.1'
1 5.0' 3.1'

D

A

W

C

256 1.0' 0.5'

2' 3.5'
3' 5.2' 114 1.5 0.7'
4' 6.9' 64 2.0' 1.0'
5' 8.7' 41 2.5' 1.2'

2' 3.5' 113 1.9' 0.9'
3' 5.2' 50 2.8' 1.4'
4' 6.9' 28 3.8' 1.8'
5' 8.7' 18 4.7' 2.3'

1' 1.7' 6
2' 3.
3' 5.2' 7 14.5' 4.4'
4' 6.9' 4 19.3' 5.8'

2' 3.5' 272 1.7' 0.8'
3' 5.2' 121 2.6' 1.3'
4' 6.9' 68 3.5' 1.7'
5' 8.7' 44 4.3' 2.1'

2' 3.5' 122 3.1' 1.4'
3' 5.2' 54 4.7' 2.1'
4' 6.9' 30 6.2' 2.8'
5' 8.7' 20 7.8' 3.5'

3' 5.2' 182 1.9' 0.9'
4' 6.9' 102 2.6' 1.3'
5' 8.7' 66 3.2' 1.6'
6' 10.4' 45 3.8' 1.9'

9 9.0' 159.2' 6.1'

'
2' 3.5' 106 4.6' 1.9'
3' 5.2' 47 7.0' 2.9'

4' 6.9' 27 9.3' 3.8'
5' 8.7' 17 11.6' 4.8'

6'6.0' 18 10.1' 6.2'
1'1.7'

2' 3.5' 58 9.7' 2.9'
3' 5.2' 26 14.5' 4.4'
4' 6.9' 14 19.3' 5.8'
5'5.0' 1614.3 7.4'
1' 1.7' 14422.3' 2.1'
2' 3.5 36 44.5 4.2'
3' 5.2' 16 66.8' 6.2'
4' 6.9' 9 89.1' 8.3'

11'11.0' 35 5.5' 3.8'

3' 5.2' 167 3.1' 1.5'
4' 6.9' 94 4.1' 2.0'
5' 8.7' 60 5.1' 2.5'
6' 10.4' 42 6.2' 2.9'
9'9.0' 21 8.4' 5.6'
2' 3.5' 153 4.2' 1.8'
3' 5.2' 68 6.2' 2.7'
4' 6.9' 38 8.3' 3.5'
5' 8.7' 25 10.4' 4.4'
6'6.0' 2110.8' 6.5'
1' 1.7' 263 5.5' 1.5'
2' 3.5' 66 11.0' 3.1'
3' 5.2' 29 15.5' 4.6'
4' 6.9' 16 22.0' 6.1'

6 4.8' 1.5'

5 16 9.7' 2.9'

231

4.8' 1.5'

D

A

FC

W

C
