Lightning Air LA-2SP User Manual

1

User Guide

Model LA-2

SP

Air Purification Unit

Bring Freshness Indoors

2

WARNING

This air unit is not a medical device. Do not stop or alter any
medical therapy programs or medications without the advice of
your physician. Excessive ozone concentrations may cause
mucous membrane or respiratory irritation.

CAUTION

ATTENTION

RISK OF ELECTRICAL SHOCK

DO NOT OPEN

Caution: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT
REMOVE BACK COVER. NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVCE PERSONNEL.

Contents

Quick Start .................................................................................... 3

Features of the Model LA-2SP ................................................. 4

Operation/Installation ................................................................... 6

Determine Your Square Footage ................................................... 7

Using a Timer................................................................................. 8

Where to Use.................................................................................. 8

Service ........................................................................................... 8

Warranty......................................................................................... 8

Cleaning & Maintenance .............................................................. 9

Troubleshooting ............................................................................. 9

Understanding the 03 Sanitizer....................................................... 10

3

1) Normal Operation: Turn the Ionization dial on and
select fan speed. The unit should be located at least two to
three feet off the floor and at least three feet away from
sitting and sleeping areas.

2) Sanitizer Mode: The O

3

Sanitizer is most effective in
unoccupied spaces to eliminate odors and significantly
reduce mold and mildew. Close all doors and windows in
the space to be treated. Turn Sanitizer dial on and select
square feet setting. Vacate the space for 1 to 4 hours de­pending upon the severity of the odors. Return to space,
turn Sanitizer dial off, open doors and outside windows
until sanitizing smell is gone.

Warning: Excess ozone (O

3

) concentrations can cause
mucous membrane and respiratory irritation. If you detect
the sanitizing smell when you walk into the room turn the
Sanitizer dial off or down to a lower level.

QUICK START

Read

ALL instructions and information contained in this

product guide before using this product.

4

Front View

Fan Grill

03 Sanitizer
Control Setting

On/Off
Ionization
Fan Speed

Part

Control for the negative ion generator is separate from the activated oxygen control. Negative ions
can be created around the clock to keep down dust and particulate.

Ozone or activated oxygen is normally kept at modest levels in occupied spaces. To remove heavy
odors, the units may be adjusted to a higher level for a period of time. Some use a timer to
completely deodorize the home or office while away. Unused O3 reverts back to O2 in about an hour.

Dual Ion
Emitters

Ionizer ON/OFF
& Fan Speed

On/Off activates the unit and turns on the Ionic
Purifier it also controls the fan speed.

Activates the ozonator and adjusts by square footage
of treatment area. The unit should be adjusted
according to size of treatment area and sensitivities.

Removable fan grill. May be wash with warm soapy
water. Dry completely before replacing.

(Unplug unit before removing)

Fan Grill

03 Sanitizer
Square Feet

Function
