FEATURES & SPECIFICATIONS

INTENDED USE — Ideal for applications requiring attractive, quick-installation exit signs and low energy consumption. Certain airborne contaminants can diminish the integrity of acrylic and/ or polycarbonate. Click here for Acrylic-Polycarbonate Compatibility table for suitable uses.

CONSTRUCTION

sion-proof. UL94V-0 ame rating. UV-stable resin resists discoloration from natural and man-made light sources.

Rugged unibody housing snaps together with no additional mechanical fasteners. Faceplate and back cover are interchangeable on housing. Positive snap-t tabs hold faceplate securely, yet easily removable for lamp compartment access.

Universal directional Chevron inserts are easily removed and reinserted. Uniform illumination without shadows or hot spots. Reinforced, impact-resistant color panels. Letters 6” high with 3/4” stroke, with 100 ft. viewing distance rating, based upon UL924 standards.

U.S. Patent No. 5,526,251; 5,611,163; 5,739,639; 5,954,423; 5,988,825; 6,152,581; D383,501 ; D495,751 and 6,502,044. Other patents pending.

OPTICS

lamp operates in normal (AC input) and emergency (DC input) modes.

The typical life of the exit LED lamp is 10 years.

ELECTRICAL

Low-voltage disconnect prevents excessively deep discharge that can permanently damage battery. Conveniently located test switch and LED provide visual and manual means of monitoring system.

Constant-current series charger minimizes energy consumption and provides low operating costs. Printed circuit boards are 100% quality tested during manufacturing. Current-limiting charger circuitry protects printed circuit boards from shorts.

AC/LV reset (line latch) allows battery connection before AC power is applied and aids in preventing battery damage from deep discharge.

Crystal oscillator timing system with watchdog protection for precision accuracy.

Brownout protection is automatically switched to emergency mode when supply voltage drops below 80% of nominal.

Battery: Sealed, maintenance-free nickel-cadmium battery delivers 90-minutes capacity to emergency lamps. Two-state constant-current charge maximizes battery life and automatically recharges after battery discharge.

Diagnostics: Single-point microcomputer control for all electronic features.

Single multi-chromatic LED indicator to display two-state charging, test activation and three-state diagnostic status.

Test switch provides manual activation of 30-second diagnostic testing for on-demand visual inspection. Self-diagnostic testing for ve minutes every 30 days and 90 minutes every six months.

Diagnostic evaluation of LED light source, AC to DC transfer, charging and battery condition. Continuously monitors AC functionality.

INSTALLATION

only.

Easily removed mounting knockouts. J-box pattern on back panel. Housing snaps to canopy with four

positive-locking tabs. Cam-locking pin tightly secures housing to canopy.

Ships standard with additional face plate.

LISTINGS

UL924, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards. Meets all applicable FCC Title 47, Part 15, Subpart B requirements.

—

Engineering-grade thermoplastic housing is impact-resistant, scratch-resistant, and corro-

— LEDs mounted on printed circuit boards. Low energy consumption – less than one watt. LED

— Dual voltage input capability (120/277V) and 120V through 277V for MVOLT with SD.

— Universal mounting canopy for top or end mount. Back mount standard for single face

— UL damp location listed 50°-104°F (10°-40°C) standard. NOM Certied (see options). Meets

Catalog Number

Notes

Type

Thermoplastic Exits

LQM

LED LAMPS

†

Specications

Length: 11-3/4 (29.8)

Depth: 2 (5.1)

Height: 7-5/8 (19.3)

Weight: 2.6 lbs (1.2 kgs)

All dimensions are inches (centimeters) unless otherwise specied.

11-3/4

WARRANTY — 5-ye ar limited warrant y. (Battery is pr orated.) Complete war ranty terms lo cated at:

www.acuitybrands.com/support/customer-support/terms-and-conditions

Note: Actual pe rformance may d ier as a result of end -user environme nt and applicatio n. All values are design or typical values, measured under laboratory conditions at 25 °C. Specications subject to change without notice.

† Exit Signs Certied in the CA Title 20 Appliance Eciency Database.

7-5/8 (19.3)

Looking for Contractor Select readily available congurations? Click here to visit Contractor Select™ spec sheet or go to www.contractorselect.com

Example: LQM S W 3 R 120/277 EL N

ORDERING INFORMATION

For shortest lead times, congure product using bolded options.

LQM

Fami ly Face t ype Housing color Number of faces Letter color Input voltage Operation Options

S Stencil (blank) Black

LQM

W White

3 Single face with

extra faceplate and color panel

R Red G Green

120/ 277 Dual voltage MVOLT Multi volt 120 -277,

50/60 hz

(blank) AC on ly X2 Primary and secondary

AC inputs pr ovided

EL N Nickel cadmium battery

Notes

1 LQM available with Custom Signage. See spec sheet,

Accessories: Order as separate item.

ELA WG1 Back-mount wireguard 6ELA WGEXE End-mount wireguard

ELA WGEXT Top-mount wireguard 6ELA LQMUS12 12" stem kit

Custom-Signage.

2 Only available with EL N SD. See Example for ordering. 3 Not available with other options. Both circuits can be

energized at the same time. 4 Available with stencil face and white housing only. Not

available with MVOLT EL N SD conguration.

EMERGENCY LQM

Example: LQM S W 3 R MVOLT EL N SD

(blank) None

NOM

5 Only available with MVOLT and EL N operation. See

Example for ordering. 6 See spec sheet ELA-WG. 7 See spec sheet ELA-Stemkits.

NOM certied for Mexico

SD Self-diagnostics

Page 2

LQM LED, Quantum

SPECIFICATIONS

ELECTRICAL

Primary Circuit

Type

Typical

LED life

Red LED AC Only 10 years

Green LED AC Only 10 years

Red LED Emergency 10 years

Green LED Emergency 10 years

BATTERY

Nickel Cadmium

Voltage

Typical

shelf life

Typ ical

1.2 3 years 7-9 years none 50°F - 104°F

Notes

1 LED lamps operate in normal (AC input) and emergency (DC input) modes.

2 Based on continuous operation. The typical life of the exit LED lamp is 10 years.

3 At 77°F (25°C).

4 All life safety equipment, including emergency lighting for path of egress must be maintained, serviced and tested

in accordance with all National Fire Protection Association (NFPA) and local codes. Failure to perform the required maintenance, service, or testing could jeopardize the safety of occupants and will void all warranties.

5 Optimum ambient temperature range where unit will provide capacity for 90 minutes. Higher and lower tempera-

tures aect life and capacity.

life

Supply

voltage

Input watts

120 .62 .05 277 .69 .06 120 .62 .05 277 .74 .06 120 .71 .05 277 .92 .06 120 .66 .05 277 .70 .06

Maintenance

Max.

amps

Temperature

range

(10°C - 40°C)

MOUNTING

All dimensions are inches (centimeters) unless otherwise specied.

Shipping weight: 2.6 lbs. (1.2 kgs.)

Top Mounting

End Mounting

5-5/8 (14.7)

11-3/4

(29.8)

Back Mounting

5-7/8 (14.9)

11-3/4

(29.8)

7-5/8 (19.3)

3-7/8 (9.6)

4-1/2 (11.4)

8-3/8 (21.3)

(5.1)

7-5/8 (19.3)
