Cordless
30 LED
Worklight
Instruction Manual
3-Position Switch
The LIGHTHOUSE Worklight is equipped with
a
3-position switch.
Position (0)
Switch in off position
Position (I)
Operates the centre column of 10
LED bulbs, giving a maximum battery
life of up to 5 hours on a full charge
Position (II) Operates all 30 LED bulbs for maximum
illumination, battery life in this mode
is up to 3 hours on a full charge
Magnetic Base
The LIGHTHOUSE Worklight features a magnetic
base with a soft coating on the bottom, allowing
the worklight to be magnetically attached to a
vehicle or other metal objects without damaging
or scratching the painted surface.
Do not place the worklight on or near
computer equipment, computer disks or
other types of magnetic storage
equipment as strong magnetic fields
can erase or corrupt data.
Care and Maintenance
Storage
Store the LIGHTHOUSE worklight and charging
a
dapters in a clean and dry area.
Be sure to keep the charging adapters supplied
with this product stored separately from similar
items as only charging adapters included with
this worklight are compatible. Using a noncompatible charger could cause damage to the
worklight or personal injury. The worklight may
also be stored in a vehicle for use in roadside
emergencies. If kept in a vehicle, it is
recommended that battery be re-charged every
30-45 days to ensure maximum performance in
an emergency. To prevent the worklight and any
of the accessories being damaged, please
ensure that it is properly secure and in a safe
place inside the vehicle.
Cleaning
All exterior surfaces of the worklight can be
w
iped clean with a soft cloth dampened with a
soap and water solution. Do not immerse or
submerge any part of worklight in water or any
other solvent. Never use solvents or cleaning
agents containing petroleum (petrol, kerosene,
oil), paint thinner, turpentine, alcohol, or
ammonia. Harsh materials like these can
damage surfaces.
Maintenance
Only qualified service personnel must perform
repairs. Do not open e xterior casing of the
worklight, as there are no user serviceable
parts inside. Opening or visible attempts to
open or repair a worklight may void any
guarantee and/or cause damage to the product
or personal injury. LED bulbs will never wear
out under normal conditions and do not need
to be replaced. Rechargeable battery pack
cannot be replaced.
Never attempt to open the battery pack,
under abusive conditions liquid may be
ejected from the battery, if accidental
contact occurs flush the effected area
with water. If the liquid comes into
contact with the eyes flush with water
and seek medical help. Liquid ejected
from batteries may cause irritation or
burns.
This product contains an internal Nickel Metal Hydride battery pack formulated
from environmentally sensitive materials.
This product must be disposed of
properly with due care for the environment.
Please return this product to your local
dealer or to your local recycling station
where batteries will be recycled or
disposed of properly.
Never attempt to incinerate batteries as
they may leak or explode.
One-Year Home Use Limited Guarantee
Lighthouse guarantees this product to the
original purchaser for a period of ONE YEAR
against any defects in material or workmanship
but shall not cover damage caused by misuse,
abuse, alteration, or accident. This product is
intended for home use only and the guarantee
will not cover product used for commercial
purposes.
Ni-MH
IMPORTANT
It is essential that you read the instructions
c
ontained in this manual before using the
worklight for the first time.
Failure to follow these instructions could
result in damage to the worklight, property
damage or personal injury.
This manual should be stored safely for
future reference.
(Product code: L/H 30LEDLAMP)
Fig.3
Fig.2
Bottom
Groove
Top
Groove
Fig.4
Charging
Indicator
LED
Hanging
Hook
Charging
Indicator
LED
Charging
Jack
(on back)
Stand Up
Magnetic
Base
Clear
Cover
and
LED
bulbs
2-Stage
On/Off
Switch
Two Snap-On
Hanging Hooks
240V AC Charging Adaptor
12V DC Charging Adaptor
Hanging Hooks
Locate the grooves around the worklight
body above and below the clear lens cover
section (Figs. 2 and 3). Snap the larger
circular ends of each hook into position
around worklight body in each groove.
Specifications
Power Requirements: 7.2 VDC
Battery Pack: Six 1.2 Volt, 0.60 Amp/Hour cells
Battery Type:
Internal, Rechargeable, Nickel-Metal Hydride
Bulb Type: White LED (Light-Emitting Diode)
Bulb Life: 100,000 Hours
Light Output: 40 watt (420 Lumens)
Your new cordless, LlGHTHOUSE rechargeable multi-purpose worklight is perfect for use
in and around the home and garage, providing a safe and portable source of light for use just
where and when you need it. Great for use during power failures, while camping, fishing or
working on the car, ideal for roadside emergencies.
Charging the LlGHTHOUSE Worklight
The LlGHTHOUSE worklight must be fully charged
before being used for the first time (the indicator
LED glows green when the unit is fully charged)
, this
will ensure that the battery gives its best performance
now and on future re-charging cycles. The AC and DC
charging adapters are for re-charging the battery only.
They cannot be used to directly power the worklight.
Using the AC Charging Adapter
1) Stand the light vertically on its base. Plug the
adapters jack plug into the socket on the base
of the worklight. The jack socket is located on
opposite side of base from the ON/OFF switch.
2) Plug the adapter into 240V socket and switch
the socket on (if applicable).
3) Locate the charging indicator light (Fig. 4). This
is the bottom LED bulb in centre row. When the
unit is charging the bulb will glow yellow.
4) When the indicator light glows green, the unit is
fully charged.
5) Disconnect the jack plug from the worklight,
remove the adapter from the wall socket or
switch off. Under normal conditions the
worklight should be fully charged in less than
three hours.
Safety Precautions
Use 240v AC charging adapter indoors in a dry
l
ocation only. Exposure to damp or wet conditions
could cause electrocution or damage to adapter.
Do not use the charger in the vicinity of flammable
l
iquids or materials.
Do not use the charging adapter in combination
w
ith any extension cord, electrical generators, or
step-up transformers.
Always plug the adapter directly into a 240v outlet in
a
suitable location.
Store in dry location and do not allow the charging
a
dapter to come in contact with water, rain or snow.
If the charging adapter comes into contact with water,
p
lace in a dry location at room temperature, on a soft
a
bsorbent towel and allow to dry thoroughly. Do not
operate the unit until it is completely free of moisture.
If the adaptor becomes submerged in water,
d
iscontinue use immediately and contact your local
LIGHTHOUSE retailer for a replacement charger unit.
Do not store charging adapter where temperatures
m
ay exceed 122°F (50°C).
Use only the AC charging adapter supplied with the
worklight. Do not attempt to charge the worklight with
an adapter that is not compatible as this could result
in a fire, damage to the worklight or personal injury.
Using the DC Charging Adapter
1) Stand the light vertically on its base. Plug the
adapters jack plug into the socket on the base
of the worklight.
2) Plug the adapter into the vehicles 12v DC
cigarette lighter or accessory power socket.
3) Locate charging indicator light (Fig. 4). It is the
bottom LED bulb in centre row. When unit is
charging, the bulb will glow yellow.
4) When the indicator light glows green, the unit is
fully charged.
5) Disconnect the jack plug from the worklight, and
remove the DC adapter from the outlet socket.
Safety Precautions
The DC charging adapter can be used in most
ve
hicles by plugging into the 12v DC cigarette lighter
or accessory power socket.
Consult your vehicle owner's manual for further
i
nformation on operating 12v DC accessories.
Do not drive the vehicle while charging, as an
u
nsecured worklight may be a hazard during certain
driving manoeuvres.
Store in dry location and do not allow the charging
adapter to come in contact with water, rain or snow.
If the charging adapter comes into contact with water,
p
lace in a dry location at room temperature, on a soft
a
bsorbent towel and allow to dry thoroughly. Do not
operate the unit until it is completely free of moisture.
I
f the adaptor becomes submerged in water,
d
iscontinue use immediately and contact your local
LIGHTHOUSE retailer for a replacement charging
adapter.
Do not store charging adapter where temperatures
m
ay exceed 122°F (50°C).
Use only the DC charging adapter supplied with the
wo
rklight. Do not attempt to charge the worklight with
an adapter that is not compatible as this could result
in a fire, damage to the worklight or personal injury.
Running Times
The approximate running times for this torch when
fully charged are as follows.
30 LED 3 Hours
10 LED 5 Hours
