SIGNATURE SERIES
SMAB
SIGNATURE MULTI ADJUSTABLE BENCH
Customer Support Services
PARTS LIST
Page 1
SMAB SIGNATURE MULTI ADJUSTABLE BENCH
PAGE
COMPONENT ASSEMBLY 3
COMPONENT ASSEMBLY LEGEND 4
FRAME ASSEMBLY 5
FRAME ASSEMBLY LEGEND 6
BACK PAD SUPPORT ASSEMBLY 7
SEAT ADJUSTMENT ASSEMBLY 8
BASE FRAME ASSEMBLY 9
IMAGE 10
CONTENTS
________________________________________
________________________________________
NOTE: SUBSTITUTE PART NUMBERS ENDING
WITH ‘XX’ WITH THE REQUIRED COLOR CODES.
FRAME
01 = WHITE
02 = PLATINUM
PADS
01 = BLACK
99 = CUSTOM
03 = BLACK
Page 2
8
9
4
6
7
15
5
2
12
13
11
1
16
3
10
8
14
SMAB SIGNATURE MULTI ADJUSTABLE BENCH
COMPONENT ASSEMBLY
________________________________________
SEE PAGE 4 FOR LEGEND
Page 3
SMAB SIGNATURE MULTI ADJUSTABLE BENCH
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 81815XX ASSY, SMAB, FRAME
2 1 78138XX PAD, 10 X 16 TAPERED CONVEX
3 1 78140XX PAD, 24 X 11 FLAT
4 1 80987XX PTD ASSY, SMAB, BASE FRAME
5 4 3237403 PLUG, 1" HOLE
6 4 3256204 SCREW, M10 X 1.5 35MM ZN
7 2 3256202 SCREW, M10 X 1.5 25MM ZN
8 10 3102514 WASHER, FLAT 3/8" SAE ST ZN
9 2 3242002 NUT, M10 X 1.5 HEX NYLOCK
10 2 3256216 SCREW, M10 X 1.5 95MM ZN
11 1 7810801 PAD, RUBBER FOOT
12 4 3239102 SCREW, M5 X .8 X 12 PHL PAN TT ST BZ
13 4 3114407 WASHER, FLAT #10 SAE ST BZ
14 1 8137701 DECAL, WARNING, HORIZ, MULTI-LANG SHEET
15 1 3256211 SCREW, M10 X 1.5 70MM ZN
16 1 80325XX PAD, 8 X 11 LUMBAR
COMPONENT ASSEMBLY LEGEND
________________________________________
Page 4
SMAB SIGNATURE MULTI ADJUSTABLE BENCH
1
27
13
25
2
23
8
10
9
7
3
16
14
33
31
19
5
34
28
4
29
30
24
7
20
22
12
32
21
15
17
18
6
26
24
11
FRAME ASSEMBLY - 81815XX
________________________________________
SEE PAGE 6 FOR LEGEND
Page 5
SMAB SIGNATURE MULTI ADJUSTABLE BENCH
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 81800XX ASSY, SMAB, FRAME
2 1 82441XX ASSY, SMAB, BACK PAD SPRT
3 1 81799XX WLDMT, SMAB, SEAT
4 1 82442XX ASSY, SMAB, SEAT ADJ
5 1 81379XX WLDMT, SMAB, SEAT SELECTOR TUBE
6 1 8353901 PTD ASSY, SMAB, HANDLE
7 2 8181301 SHAFT, 0.75" DIAM
8 1 8181001 BEARING, BALL, 6203-2Z, SMAB
9 1 8181401 SHAFT, SMAB, SEAT FRONT PIVOT
10 2 3102513 WASHER, FLAT 3/4 SAE ST ZN
12 1 7763001 FOOT, 2.20 X 4.49 FLOV
13 1 7800401 CAP, LRG FLOV END
14 1 7800501 CAP, SML FLOV END
15 1 7662901 CAP, GRIP 1.25 OD
16 2 8140201 SPACER, 0.94 OD X .42 ID X 1" LONG
17 1 8245801 GRIP, 1.50 OD X 4.5"L
18 1 7662801 RING, GRIP 1.25 OD
19 1 8140101 SHAFT; PIVOT, SMAB
20 1 7340201 COVER; FOOT - STRAIGHT
21 2 3251202 M10 X 1.5 X 25MM UNS HEX CS ST ZN
22 2 3242002 NUT, M10 X 1.5 HEX NYLOCK
23 6 3102514 WASHER, FLAT 3/8" SAE ST ZN
24 6 3256202 SCREW, M10 X 1.5 25MM ZN
25 2 3256205 SCREW, M10 X 1.5 40MM ZN
26 4 3247701 M4 X 0.7 X 3 HZS NO CUP ST BO
27 8 3104901 BEARING, FLG .75 ID X 1.00 OD
28 1 7351302 PIN, PULL X 3.375
29 1 7351501 SPRING; PULL PIN LARGE
30 1 7424801 KNOB, POP PIN
31 2 7865201 LABEL, LIFE FITNESS LOGO
32 1 8106801 LABEL, SERIAL NUMBER, LARGE
33 1 7002501 LABEL; H WARNING 4.5 X 1.625
34 2 8087201 BUSHING, SLIP TUBE, PLASTIC, 55.3MM OD X 45.2MM ID
FRAME ASSEMBLY LEGEND
________________________________________
Page 6
SMAB SIGNATURE MULTI ADJUSTABLE BENCH
2
1
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 82441XX ASSY, SMAB, BACK PAD SPRT
2 2 8039501 LABEL, WARNING, TRIANGLE
BACK PAD SUPPORT ASSEMBLY - 82441XX
________________________________________
Page 7
SMAB SIGNATURE MULTI ADJUSTABLE BENCH
2
1
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 82442XX ASSY, SMAB, SEAT ADJ
2 2 8039501 LABEL, WARNING, TRIANGLE
SEAT ADJUSTMENT ASSEMBLY - 82442XX
________________________________________
Page 8
SMAB SIGNATURE MULTI ADJUSTABLE BENCH
9
2
4
3
1
8
7
6
5
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 80986XX WLDMT, SMAB, BASE SPPRT
2 2 7800401 CAP, LRG FLOV END
3 2 7810801 PAD, RUBBER FOOT
4 8 3114407 WASHER, FLAT #10 SAE ST BZ
5 16 3239102 SCREW, M5 X .8 X 12 PHL PAN TT ST BZ
6 4 3232405 RNG, BRE .352,5100-37,ST,PP,B
7 2 7656301 WHEEL, 2 OD X 3/8 ID RUBBER
8 2 7705302 AXLE, WHEEL
9 2 7821701 GUARD, PAINT, SHORT
BASE FRAME ASSEMBLY - 80987XX
________________________________________
Page 9
SMAB SIGNATURE MULTI ADJUSTABLE BENCH
________________________________________
