V 1.6
SilverCrest SFG 8000 B2
Contents
1. General information ............................................................................................... 4
1.1. Read and keep the operating instructions ............................................................................................. 4
1.2. Explanation of the used symbols ............................................................................................................ 4
1.3. FCC compliance ...................................................................................................................................... 5
2. Important safety instructions .................................................................................. 5
3. Introduction ............................................................................................................ 9
4. Intended use ........................................................................................................... 9
5. Package contents ................................................................................................. 10
6. Technical specifications ......................................................................................... 10
7. Copyright ............................................................................................................. 13
8. Overview ............................................................................................................. 13
8.1. Handheld transceiver ........................................................................................................................... 14
8.2. Display items ......................................................................................................................................... 14
8.3. Charger cradle ..................................................................................................................................... 15
9. Before you start .................................................................................................... 15
9.1. Inserting the rechargeable/conventional batteries ............................................................................ 15
9.2. Charging the batteries ......................................................................................................................... 16
9.2.1. Preparing the charging cradle .................................................................................................... 16
9.2.2. Charging the batteries ................................................................................................................. 16
9.3. Installing/removing the belt clip .......................................................................................................... 17
9.3.1. Installing the belt clip ................................................................................................................... 17
9.3.2. Removing the belt clip .................................................................................................................. 17
9.4. Connecting the earphones ................................................................................................................... 17
10. Getting started ................................................................................................... 18
10.1. Powering the handheld transceivers on/off ..................................................................................... 18
10.1.1. Powering the handheld transceiver on ..................................................................................... 18
10.1.2. Powering the handheld transceiver off ..................................................................................... 18
10.2. Adjusting the volume .......................................................................................................................... 18
2 - English
SilverCrest SFG 8000 B2
10.3. Setting a different channel................................................................................................................. 18
10.4. Reception ............................................................................................................................................ 19
10.5. Transmission ....................................................................................................................................... 19
10.6. Battery status indicator ...................................................................................................................... 19
11. Advanced operation ........................................................................................... 19
11.1. CTCSS (Continuous Tone Coded Squelch System)/DCS (Digital Coded Squelch) code ............ 20
11.1.1. Setting the CTCSS code ............................................................................................................ 20
11.1.2. Setting the DCS code ................................................................................................................ 20
11.1.3. Disabling the CTCSS/DCS code .............................................................................................. 20
11.2. Channel monitoring ........................................................................................................................... 21
11.3. Voice-controlled send function (VOX)............................................................................................... 21
11.4. Channel scan ..................................................................................................................................... 21
11.4.1. Searching for an active channel ............................................................................................... 22
11.4.2. Searching for a CTCSS code .................................................................................................... 22
11.4.3. Searching for a DCS code ........................................................................................................ 22
11.5. Dual scan ............................................................................................................................................ 23
11.6. Call tones ............................................................................................................................................ 23
11.6.1. Selecting the call tone ............................................................................................................... 23
11.6.2. Sending the call tone ................................................................................................................. 23
11.7. Setting the roger beep on/off ........................................................................................................... 23
11.8. Setting the button sound on/off ........................................................................................................ 24
11.9. RM (Room Monitor) ........................................................................................................................... 24
11.10. Button lock ....................................................................................................................................... 25
11.11. Chronometer .................................................................................................................................... 25
11.12. Display backlight ............................................................................................................................. 25
11.13 Weather channel .............................................................................................................................. 26
12. Troubleshooting ................................................................................................. 27
13. Maintenance/cleaning ........................................................................................ 27
13.1. Maintenance ...................................................................................................................................... 27
13.2. Cleaning ............................................................................................................................................. 28
14. Environmental information and disposal ............................................................ 28
English - 3
SilverCrest SFG 8000 B2
Congratulations!
By purchasing the SilverCrest SFG 8000 B2 handheld radio transceiver set you have opted for a quality
product.
1. General information
1.1. Read and keep the operating instructions
Before first using it, familiarize yourself with the way the handheld radio transceiver set
works and read these operating instructions through carefully. Be careful to follow the
safety instructions and only use the handheld radio transceiver set as described in the
operating instructions and for the applications given.
Keep these operating instructions in a safe place. If you pass the handheld radio transceiver set on to
someone else, make sure to give them all the relevant documents with it.
1.2. Explanation of the used symbols
The following symbols and signal words are used in these operating instructions, on the handheld radio
transceiver set and on the packaging:
This symbol / signal word indicates a danger with a high degree of risk,
which can lead to death or serious injuries if not avoided.
This symbol / signal word indicates a danger with a medium risk, which can
lead to death or serious injuries if not avoided.
This symbol / signal word indicates a danger with a low risk, which can
lead to minor or moderate injuries if not avoided.
This signal word warns against possible property damage.
This symbol denotes further information on the topic.
Risk of fire! This symbol warns that fires could start if the warning is left
unheeded.
4 - English
Risk of burns! This symbol warns of hot surfaces.
Channels 1-7 & channels 15-22 are GMRS channels
SilverCrest SFG 8000 B2
Children and persons with disabilities
Warning, risk of suffocation!
Packaging material is not a toy. Do not allow children to play with plastic bags. There is a risk of
suffocation.
Small parts can represent choking hazards. Please also note that there is a risk of suffocation if
airways are blocked by the packaging films.
Electrical devices should not be operated by children or people with mental or physical disabilities. Do not
allow these people to use electrical devices when not under supervision. They may fail to understand that
they can be dangerous.
General safety instructions
Risk of electric shock!
This product has a polarized plug (one blade is wider than the other blade). To reduce the risk of
electric shock, this plug is designed to fit into a polarized outlet only one way. If the plug does not
fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not
attempt to modify the plug in any way.
Do not open the handheld radio transceiver set component housings - they contain no serviceable
parts. Opening the housing can expose you to the risk of electric shock.
Make sure that the power adapter’s power cord cannot be damaged by sharp edges or hot spots.
Make sure that the power adapter’s power cord cannot become crushed or squashed.
When disconnecting the power adapter from the wall outlet, always pull on the power adapter
housing and never on the cord itself.
If you notice visible damage to any of the handheld radio transceiver set components, switch off the
device, disconnect the power adapter from the wall outlet, and contact customer service (see
"Warranty information" on page 29).
Only connect the handheld radio transceiver set to a properly installed, easily accessible wall outlet
with the same voltage as detailed on the rating plate. After connecting the device, the wall outlet
must still be easily accessible so that you can disconnect the power adapter quickly in the event of
an emergency.
Please only use the supplied power adapter (manufacturer: O Real / model number:
TGE050P055) for the charging cradle.
6 - English
SilverCrest SFG 8000 B2
Unplug all cables by holding the plugs and never pull on the cables themselves. Never place
pieces of furniture or other heavy objects on the cables and take care that they do not become
damaged, especially at the plugs and sockets. Never tie knots in a cable and do not tie them to
other cables. All cables must be laid so that nobody can trip over them or be obstructed by them.
A damaged power adapter or cord can cause fire or an electric shock. Check the power adapter
and cables from time to time. Never use adapter plugs or extension cords that do not comply with
the current safety regulations, and do not modify the power adapter or power cord yourself.
Never immerse the charging cradle, the power adapter or the handheld radio transceivers in
water or other liquids. If liquid does penetrate the devices, disconnect the power adapter from
the wall outlet immediately and contact the hotline (see "Warranty information" on page 29).
Conventional and rechargeable batteries
Insert the batteries/rechargeable batteries with the correct polarity. Refer to the diagram inside the
battery compartment.
Do not attempt to recharge non-rechargeable batteries and do not dispose of the batteries in a fire.
Use only batteries/rechargeable batteries of the same type.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (NiCd, NiMh, etc.) batteries
Remove the batteries/rechargeable batteries when the device is not going to be used for a long time.
Batteries/rechargeable batteries must be disposed of at specific collection points. For more
information about battery/rechargeable battery disposal, please see the "Environmental information
and disposal" chapter.
Danger of explosion!
Never replace any batteries/rechargeable batteries in an explosion-sensitive environment. While inserting
or removing the batteries (or rechargeable batteries), a spark may be produced causing an explosion.
Power your handheld radio transceiver set off when in a potentially explosive environment. Sparks
in such an environment may cause explosion or fire. In addition, injury or even death may occur.
Explosion-sensitive areas are normally (but not always) labeled. These include fuel storage areas
such as below deck on a boat, fuel line or tank areas, environments where the air contains
inflammable substances (e.g. cereals, metal dust or powder) and any areas where you should
English - 7
SilverCrest SFG 8000 B2
normally switch off your car engine.
Do not throw any batteries or rechargeable batteries into a fire, as they may explode.
Don't try to charge conventional (non-rechargeable) batteries. Only use batteries/rechargeable
batteries of the same type. Always use three batteries/rechargeable batteries of the same type and
capacity. You will find this information in the "Technical specifications" chapter.
Warning about property damage
Position the handheld radio transceiver set on a stable, flat surface and do not place any heavy
objects on the components.
Keep the handheld radio transceiver set away from moisture. Do not place any receptacles
containing liquids (beverages, vases, etc.) next to or on the components. Avoid vibrations, heat and
direct sunlight so that the handheld radio transceiver set is not damaged.
The handheld radio transceiver set is not designed for use in environments with high temperatures or
humidity (e.g. bathrooms) or above-average levels of dust. Operating temperature and operating
humidity: 32 to 86 °F (0 to 30 °C), max. 85% relative humidity.
If the handheld radio transceiver set is exposed to wide temperature fluctuations, condensation can
form and create moisture, which can in turn cause a short circuit. If this occurs, use the handheld
radio transceiver set only after it has reached the ambient temperature.
Make sure that no fire hazards (e.g. burning candles) are placed on or near the handheld radio
transceiver set.
Risk of burns
Never touch the antenna if you find that the antenna insulation is damaged. When the antenna
comes in contact with the skin, minor burns may occur while transmitting.
Batteries and rechargeable batteries may cause material damage and burns if any conductors such
as jewelry, keys or chains touch the battery terminals. The conductive material may close an
electrical circuit causing a short circuit and become very hot. Handle any batteries and
rechargeable batteries carefully, especially when storing them in a pocket, purse or other
receptacle containing metal objects.
8 - English
SilverCrest SFG 8000 B2
Risk of injury
If you notice any smoke, unusual noises or strange smells, switch off the device immediately and
disconnect the power adapter from the wall outlet. If this occurs, do not continue to use the device and
have it checked out by an expert. Never inhale smoke from a possible device fire. If you do inadvertently
inhale smoke, seek medical attention. Smoke inhalation can be damaging to your health.
Do not place the product within the action radius of your vehicle’s airbag. Airbags inflate very
quickly. If a handheld radio transceiver is placed within the airbag deployment radius, the handheld
radio transceiver may be hurled across the vehicle and cause injury to the occupants.
Keep the radio transceivers at least 6 inches (15 cm) away from any pacemakers.
Power your handheld radio transceiver off if you observe any interference caused to medical
equipment.
Risks associated with high noise levels
Caution when using earphones (not supplied). Listening at a high volume can damage your
hearing.
3. Introduction
Your SilverCrest SFG 8000 B2 consists of two portable handheld radio transceivers with a maximum
range of 26,000 feet (8 km). You can choose from 22 channels for communicating between the two
stations. The handheld transceivers are protected against light rain.
You can use your handheld radio transceiver set anywhere you need to communicate with other people.
For instance, you can keep in touch with your children while they are playing in the garden. Once you
have found an interference-free channel, communication will be limited only by obstacles and the
maximum range.
4. Intended use
This handheld radio transceiver set is a consumer electronics device. The SilverCrest SFG 8000 B2
handheld radio transceiver set has been designed for communicating with other people. The handheld
radio transceiver set may be used only for private purposes, and not for industrial or commercial
purposes. It may not be used in tropical climates. Only cables and external devices that comply with
safety standards and the electromagnetic compatibility and shielding quality of this device may be used.
English - 9
SilverCrest SFG 8000 B2
The manufacturer shall not be liable for any damage or malfunctions resulting from any modifications.
Only use accessories recommended by the manufacturer. Any use other than that mentioned above does
not correspond to the intended use.
Observe the regulations and laws in the country of use.
Power your handheld radio transceiver set off when on an aircraft and the cabin attendants
instruct you to do so. You must follow the airline flight and cabin crew instructions when using the
product.
Power the product off wherever you encounter any signs indicating you must do so. Hospitals and
medical facilities may use devices that are sensitive to RF fields.
In some countries it is forbidden to use a handheld radio transceiver while driving a vehicle, in
which case stop your vehicle beside the road before using it.
Do not touch the antenna while transmitting, as this may result in decreased range.
5. Package contents
Take all supplied devices and accessories out of the packaging and inspect them for any damaged or
missing items:
2 SFG 8000 B2 handheld radio transceivers
2 belt clips
1 charger cradle
1 power adapter
6 rechargeable AAA-sized Ni-MH batteries
Operating instructions with safety instructions
If you find any items missing or damaged, please phone our hotline. You will find the phone number in the
last chapter, “Warranty information”.
Remove the protective film from the displays (1) of both transceivers.
6. Technical specifications
Brand SilverCrest
Model name SFG 8000 B2
Channels 22
10 - English
SilverCrest SFG 8000 B2
Subcode CTCSS 38/DCS 83
Frequency 462.5500 – 467.7125 MHz
Range Up to 26,000 feet (8 km) in open field
Per handheld transceiver:
Conventional/rechargeable batteries
Transmission power ≤ 1 W ERP
Modulation type FM – F3E
Channel separation 12.5 kHz
Power adapter for dual charging cradle
Dimensions
Weight
(without batteries/rechargeable batteries)
Environment
IP standard IPX2 protection against water drops
3 x AAA-sized batteries or
3 x rechargeable AAA-sized NiMH batteries
(1.2V/600
Manufacturer: O Real
Type: TGE050P055
Input: 100 ---- 240 V AC, 50/60 Hz
Output: 5 V / 550 mA
Power: max. 2.75 W
Handheld transceiver: 2.2 x 4.1 x 1.4 inch
(55 x 103 x 36 mm)
Charger cradle: 4.1 x 2.4 x 1.4 inch
(102 x 60 x 35 mm)
Handheld transceiver: 3.17 oz (90 g)
Charger cradle: 2.12 oz (60 g)
Power adapter: 1.94 oz (55 g)
Operation:
32 to 86 °F (0 to 30 ºC), max. 85% relative humidity
Storage:
-4 to 131 °F (-20 to 55 ºC), max. 90% relative
humidity
mAh
)
English - 11
SilverCrest SFG 8000 B2
Frequency chart
Channel
CTCSS codes
Code
0 Disabled 10 94.8 20 131.8 30 186.2
1 67.0 11 97.4 21 136.5 31 192.8
2 71.9 12 100.0 22 141.3 32 203.5
3 74.4 13 103.5 23 146.2 33 210.7
4 77.0 14 107.2 24 151.4 34 218.1
5 79.7 15 110.9 25 156.7 35 225.7
6 82.5 16 114.8 26 162.2 36 233.6
7 85.4 17 118.8 27 167.9 37 241.8
8 88.5 18 123.0 28 173.8 38 250.3
9 91.5 19 127.3 29 179.9
Frequency
(MHz)
1 462.5625 7 462.7125 13 467.6875 18 462.6250
2 462.5875 8 467.5625 14 467.7125 19 462.6500
3 462.6125 9 467.5875 15 462.5500 20 462.6750
4 462.6375 10 467.6125 16 462.5750 21 462.7000
5 462.6625 11 467.6375 17 462.6000 22 462.7250
6 462.6875 12 467.6625
Frequency
(Hz)
Code
Channel
Frequency
(Hz)
Frequency
(MHz)
Code
Channel
Frequency
(Hz)
Code
Frequency
(MHz)
Frequency
(Hz)
Channel
Frequency
(MHz)
DCS codes
No. DCS code No. DCS code No. DCS code No. DCS code No. DCS code
1 23 18 125 35 245 52 412 69 624
2 25 19 131 36 251 53 413 70 627
3 26 20 132 37 261 54 423 71 631
4 31 21 134 38 263 55 431 72 632
12 - English
SilverCrest SFG 8000 B2
5 32 22 143 39 265 56 432 73 654
6 43 23 152 40 271 57 445 74 662
7 47 24 155 41 306 58 464 75 664
8 51 25 156 42 311 59 465 76 703
9 54 26 162 43 315 60 466 77 712
10 65 27 165 44 331 61 503 78 723
11 71 28 172 45 343 62 506 79 731
12 72 29 174 46 346 63 516 80 732
13 73 30 205 47 351 64 532 81 734
14 74 31 223 48 364 65 546 82 743
15 114 32 226 49 365 66 565 83 754
16 115 33 243 50 371 67 606
17 116 34 244 51 411 68 612
NOAA Weather channels
Channel Frequency
1 162.550 MHz
2 162.400 MHz
3 162.475 MHz
4 162.425 MHz
5 162.450 MHz
6 162.500 MHz
7 162.525 MHz
7. Copyright
All the contents of this user manual are protected by copyright and provided to the reader for information
only.
Copying data and information without the prior explicit written consent of the author is strictly forbidden.
This also applies to any commercial use of the contents and information.
All texts and diagrams are up-to-date as of the date of printing. Subject to change without notice.
8. Overview
These operating instructions have a fold-out cover. On the inside of the cover the various components are
shown with numbers indicated. The meanings of the numbers are as follows:
English - 13
SilverCrest SFG 8000 B2
8.1. Handheld transceiver
1 Display
2 Power adapter socket (with rubber cover)
3 Earphones connector (with rubber cover)
4 Antenna
5
On/Off button
6 Menu button
- To open the menu settings
7 Down button
- To reduce the speaker volume
- To select the previous menu item
8 Charging contacts
9 Microphone
Up button
10
- To increase the speaker volume
- To select the next menu item
11 Call button
12 PTT button
8.2. Display items
13 RM indicator
14 CTCSS indicator
15 DCS indicator
16 CTCSS/DCS code/chronometer seconds/menu item value
17 Chronometer 1/100 second
18 VOX icon
19 DCM icon
20 WX icon
21 Channel/menu item indication
22 Speaker volume
23 Button lock icon
24 Battery level indicator
25 Reception icon (RX)
14 - English
SilverCrest SFG 8000 B2
26 Transmission icon (TX)
27 Scan icon
8.3. Charger cradle
28 Power adapter socket
29 Battery level indicator
30 Charging contacts
9. Before you start
9.1. Inserting the rechargeable/conventional batteries
(The figure is representational)
If necessary, remove the belt clip (see the chapter “Removing the belt clip”).
Press the ribbed area of the battery compartment cover and slide it downwards. Then lift the battery
compartment cover upwards.
Insert three AAA-sized batteries/rechargeable batteries into the battery compartment by respecting the
correct polarity. Note the + and – icons on the batteries and inside the battery compartment.
Close the battery compartment. Insert the battery compartment cover into the corresponding notch on
the radio transceiver housing and then slide the battery compartment cover upwards until it clicks into
place.
Replace the belt clip (see “Installing the belt clip”).
English - 15
SilverCrest SFG 8000 B2
9.2. Charging the batteries
If you use rechargeable batteries to power your SilverCrest SFG 8000 B2 handheld radio transceiver set,
read this chapter carefully.
9.2.1. Preparing the charging cradle
Place the charging cradle on a stable, flat surface.
Plug the power adapter plug into the power receptacle [28] of the charging cradle.
Plug the power adapter into a wall outlet.
Make sure that the wall outlet is nearby and easily accessible so that you
can unplug the power adapter quickly in case of an emergency. Otherwise
a short circuit or fire can occur.
The charging cradle’s power adapter consumes power even if there is no handheld radio
transceiver placed onto it. It is therefore recommended that you unplug the power adapter from
the wall outlet to completely separate it from the wall outlet and avoid any unnecessary power
consumption.
9.2.2. Charging the batteries
Charge the battery packs of both handheld radio transceivers completely before using them for
the first time. Charging takes approx. 12 hours.
Place the handheld transceivers onto the charging cradle as
shown.
The charging indicator [29] located on top of the charging cradle
illuminates when a transceiver has been inserted properly and its
battery is being charged. Charging takes approx. 12 hours. The
charging indicator [29] is still illuminated when the batteries are
fully charged.
You can also charge a handheld transceiver without the cradle. To do so, insert the power
adapter plug into the power adapter socket [2] of the handheld transceiver. To do this, open
the rubber cover that protects the power adapter socket [2].
16 - English
(The figure is representational)
SilverCrest SFG 8000 B2
The handheld transceivers cannot be used while they are charging.
9.3. Installing/removing the belt clip
9.3.1. Installing the belt clip
Insert the belt clip into the guide located at the handheld transceiver
back panel. The belt clip must click into place.
9.3.2. Removing the belt clip
To remove the belt clip from the handheld transceiver, use your
finger to release the belt clip lock (see the arrow). Once unlocked,
slide the belt clip upwards out of the guide.
(The figure is representational)
9.4. Connecting the earphones
You can use your handheld transceivers with suitable earphones (not supplied). The earphones receptacle
[3] is located behind a protective cover.
Risks associated with high noise levels
Before connecting the earphones, you must reduce the sound volume (see page 18), otherwise you risk
damaging your hearing due to the high earphones level.
1. To connect the earphones, open the rubber cover that protects the earphones receptacle [3].
2. Insert a 2.5 mm jack-type earphones plug into the earphones receptacle [3].
When using the earphones, the IPX2 protection against vertically falling
drops of water with tilted enclosure is not guaranteed.
English - 17
SilverCrest SFG 8000 B2
10. Getting started
In order to be able to communicate using two transceivers, they must be set to the same channel and the
same CTCSS or DCS code. Furthermore, they must be located within range (max. 8 km in open field).
RF communications take place on a free (unscrambled) channel, i.e. other people who have a radio
transceiver or receiver for the set channel will be able to listen to your messages. You can choose from 22
different channels.
This User Manual’s display illustrations show only the information relevant to the functions or
settings being described.
10.1. Powering the handheld transceivers on/off
10.1.1. Powering the handheld transceiver on
Press and hold the On/Off button [5] for at least three seconds. An acoustic
signal can be heard and the currently set channel will appear on the display [1].
The handheld transceiver will be in receive mode as long as it is powered on
and not transmitting (idle mode).
10.1.2. Powering the handheld transceiver off
Press and hold the On/Off button [5] for at least three seconds. An acoustic signal can be heard and
the display [1] will turn blank.
10.2. Adjusting the volume
Press the Up button [10] to raise the audio volume. The speaker volume will
be indicated by the number of bars [22] (one bar = low volume, four bars =
high volume).
Press the Down button [7] to reduce the audio volume.
10.3. Setting a different channel
When setting a different channel, this needs to be done on both handheld radio transceivers for you to be
able to communicate with the remote station.
18 - English
Loading...
