CATALOG 30 SUPPLEMENT

Pan Head Slotted/Phillips (2 Way)
Sheet Metal Screws - Zinc Plated - PC 4000

Pan head combo

FASTENERS & HARDWARE

(slotted/phillips) sheet metal
screws will tap their own mat­ing threads when driven into
preformed holes in metal.
Length is determined from the
base of the fastener head.

CAT NO SIZE STD

2WS612 6 x 1/2 100
2WS634 6 x 3/4 100
2WS61 6 x 1 100
2WS812 8 x 1/2 100
2WS834 8 x 3/4 100
2WS81 8 x 1 100
2WS101 10 x 1 100

Other Sizes Available

Pan Head Square Drive Sheet Metal Screws
Zinc Plated - PC 4000

Square drive pan head sheet metal screws will tap their own
mating threads when driven into preformed holes in metal.
Square drive screws provide a positive grip and resist cam out.
Length is determined from the base of the fastener head.

CAT NO SIZE BIT SIZE STD

DDSMS61 #6 6 x 1 #1 100
DDSMST834 #8 8 x 3/4 #2 500
DDSMST81 8 x 1 #2 500

Other Sizes Available

Toggle Bolts Mushroom Head - Spring Wing
Zinc Plated - PC 4050

Combo Square/Slotted
Head Styles also available

CAT NO SIZE DRILL DESC STD

TBC82 1/8 x 2 Slotted/Phillips (Combo) 50
TBC363 3/16 x 3 1/2" Slotted/Phillips (Combo) 50
TBC43 1/4 x 3 Slotted/Phillips (Combo) 50

Other Sizes Available

Light to medium duty
anchors for use in hollow
walls. Mushroom head
provides a large bearing
surface.

T E C H T A L K

Self Drilling Screws

• Manufactured from high quality cold headed material
and heat treated under controlled conditions yielding
optimum drill performance.

• Better thread engagement and optimum holding pow­ers are achieved by using a product which self-drills
its own hole size.

• Available in a variety of head styles and drive systems
to meet special application and installation demands.

Pan Head Phillips Self Drilling Screws
Zinc Plated - PC 4220

Self drilling phillips pan head screws drill a
hole and tap threads in one operation.
The drilling operation removes metal and
can be used with heavier gauge metals.
Length is determined from the base of the

Other Sizes
Available

fastener head.

CAT NO SIZE STD

TEKPH 6 x 1/2 100

CAT NO DESC STD

TK800PH 240 Assorted 1

Self Drilling

Phillips Head Screw:

75 - 8 x 1/2",
50 - 8 x 3/4", 40 - 8 x 1",
30 - 8 x 1-1/4",
25 - 8 x 1-1/2", 20 - 8 x 2",
+ 1 - IB2P Insert Bit

Drywall Screws Phillips Bugle Head
Fine Thread - Black Oxide - PC 4260

Fine thread Bugle head drywall
screws are self piercing and are
used for wood, drywall and alu­minum. Length is determined from
the top of the fastener head.

CAT NO SIZE STD

DWSBX61 6 x 1 100
DWT61 6 x 1 500
DWSBX6114 #6 6 x 1-1/4 100
DWT6114 6 x 1-1/4 500

Other Sizes Available

Drywall Screws Phillips Bugle Head Coarse
Thread Wood Rockets - Yellow Zinc - PC 4260

Coarse thread Bugle head drywall screws
(Wood Rockets) are self piercing and are used
for drywall, particle board and wood. The
course threads provide for a quicker installation.

CAT NO SIZE STD

WR61 6 x 1 100
WR6114
WR6158 6 x 1-5/8 100
WRT6158 6 x 1-5/8 500
WRT6114 6 x 1-1/4 500
WR62 6 x 2 100

Other Sizes Available

#6 6 x 1-1/4 100

Plastic Anchor Kits
PC 4610

Dottie is an industry leader in Anchor Kits. We offer a compre­hensive variety for almost any imaginable need.

CAT NO SCREW ANCHOR DRILL STD

TYPE TYPE

8 x 1 Sheet Metal Screws

RD3 Phillips/Slotted #22 Red Collar 1/4" 1

10 x 1 Sheet Metal Screws

K6CO Phillips/Slotted #22 Red Collar 1/4" 1
K6HX He
2AK Phillips/Slotted #122 Yellow Wing 1/4" 1

x/Phil/Slotted #22 Red Collar 1/4" 1

2

To Order: Phone [phone] / Fax [phone]

Plastic Anchors - Tapered with Collar
PC 4370

Plastic anchors: Tapered w/Collar.
Drill a hole into drywall, concrete,
brick or block and insert anchor. The
screw is then installed through the
fixture into the anchor. Used for light
duty work.

CAT NO SIZE SCREW LENGTH STD

20 4-6-8 3/16" 3/4" 100
21 6-8-10 3/16" 7/8" 100
22 8-10-12 1/4" 1" 100

Other Sizes Available

Wall Driller Anchors - Boxed
PC 4465

Wall Driller: Used only in drywall, this anchor
has better pullout and shear values than plas­tic anchors. Installed by inserting Phillips or
square drive bit into the anchor and driving it
into the drywall until flush. Use the same bit
to insert the proper sheet metal screw to
mount the fixture. The anchor is easy to spot
and will not break out the backing of the dry­wall. No drill bit needed.

CAT NO USE SCREW ANCHOR DRYWALL STD

WD6N #6 Nylon 3/8", 1/2" 100
WD8N #8 Nylon 3/8", 1/2", 5/8" 100

Wall Dog - Phillips / Square / Hex
PC 4731

• Self-drills small hole in wall­board

• Installs quickly and easily
with a Phillips screwdriver

• Can be easily backed-out

• No need for shields

• Case hardened steel anchor

• No hole spotting

• Installs in wallboard, ply­wood, concrete, hollow or
grout filled block, brick and
plaster

• No second step, installs
directly through fixture into
wallboard

• Patented design provides for
smooth entry, clean cutting and a powerful hold

• Thread design prevents spinning and stripping

• Heat treated point penetrates metal and wood studs

• When removed it leaves a much smaller hole than toggles or
other systems

CAT NO DESCRIPTION STD

WDOG 100 Chrome Phillips Wall Dog 1

1 3/16" Carbide Tip Drill Bit
1 IB2PL Phillips Power Bit

WDOGW 100 White Phillips Wall Dog 1

1 3/16" Carbide Tip Drill Bit
1 IB2PL Phillips Power Bit

HXDOG 100 Chrome Hex Drive Wall Dog 1

1 3/16" Carbide Tip Drill Bit
1 MT10 Magnetic Hex Bit

Driller Toggle Kits
PC 4750

• Driller Toggle

• Includes Screws & Power Bit

• Reusable

• Metal/Engineered Plastic

• Versatile for 3/8", 1/2",
& 5/8" Drywall

CAT NO CONTENTS STD

WDT83 1/8" x 3" Truss Hd. Mach. Screws 1
WDT363 3/16" x 3" Truss Hd. Mach. Screws 1
WDT43 1/4" x 3" Truss Hd. Mach. Screws 1

Staples - PC 5020, 5025
Plastic Insulated PC 5026

Staples are used to attach NMC
(non metallic cable) or BX
(armored) cable to wooden studs.
The RX Series is used for
Romex® and the BX Series is
used for Romex® and BX. The
SEU staple is used for service
entrance cable and is available in
100 pack. For electro galvanized
specify G (i.e.; RXG50, BXG or
SEU63G). Plastic Insulated staples
are used for coaxial cable, bell
wire, thermostat wire, telephone
wire and Romex®.

CAT NO CABLE SIZE SIZE (W X L) GAUGE STD
9/16" - 3 Conductor (#10, #12 & #14) Romex®, BX, MC and
other Cable - PC 5022

BX1001 14-3, 12-3, 10-3 9/16 x 1-3/16" 12 GA 100
BXG1005 14-3, 12-3, 10-3 9/16 x 1-3/16" 12 GA 500

CAT NO CABLE SIZE SIZE COLOR STD
Co-Axial Straps (Use Co-Axial RG-6 & RG-59U)

PLX250W 1/4" White 500

Bell, Telephone & Thermostat Wire Straps

PLX18W 1/4 x 1/8" White 500

Bare Ground Clamps
PC 5560

round clamps are used to

Bare g
connect bare copper wire to water
pipe, rebar, ground rod or copper
water tubing for grounding. 20B is
pressure case zinc with Brass
Plating. Additional fittings are UL
listed and cast from high strength,
highly conductive copper alloy with
steel, brass or bronze screws.

WIRE SCREW PIPE

CAT NO RANGE DESCRIPTION TYPE SIZE STD

20B* 8 Sol to 2 Str Pressure Cast Steel 1/2 to 1" 25

ass Plated

*not UL listed

Br

ANCHORS & KITS

FITTINGS & STAMPINGS

See new products at lhdottie.com

3

Safety Plates
PC 5050

Premium Color Coding PVC Tape
PC 5330

Steel saf

FITTINGS & STAMPINGS CHEMICALS & TAPE

protect utility pipes and to prevent nails from penetrating into
hidden live wires (NMC cable) which may be running through
notches or through the drilled holes in the stud.

CAT NO SIZE GAUGE STD

411 1-1/2 x 2-3/4" 16 100
415 1-1/2 x 2-3/4" 16 500
41P 1-1/2 x 2-3/4" 16 500(Pail)

ety plates are affixed to the face of 2" x 4" members to

Mounting Hole Cable Ties - Nylon
PC 5970

CAT NO COLOR L HOLE W THK TENSILE DIA. STD

DTM6 Natural 8.0" No.10 .177" .052" 50 lb. 1.75" 100
DTM6B UV Black 8.0" No.10 .177" .052" 50 lb. 1.75"100
DTM14 Natural 14.5" No.10 .177" .053" 50 lb. 4.00" 100
DTM14B UV Black 14.5" No.10 .177" .053" 50 lb. 4.00" 100

RTV Silicone Sealant
PC 6200

• UL Classified

• Clear / White

• Neutral Cure Silicone

• Non Acetic & Non Corrosive

• Low Odor

• Flexible, Non Sagging, Watertight

• Withstands Temperatures

CAT NO COLOR CONTENTS DESCRIPTION STD

RTV3 Clear 3 oz. Tube 12
RTV8 Clear 8 oz. Pressurized Can 12

PVC Tape is used for insula­tion and protection over wires
and connectors or over splic­ing and filler compounds; the
holding of high voltage electri­cal appliances; color code
identification; wire harnessing
and home maintenance.

Economy
CAT NO DIMENSIONS COLOR STD

360 3/4" x 60' Black 10

Premium
CAT NO DIMENSIONS COLOR STD

66CBLU 3/4" x 66' Blue 10
66CBRN 3/4" x 66' Brown 10
66CGRN 3/4" x 66' Green 10
66CRED 3/4" x 66' Red 10
66CWHT 3/4" x 66' White 10
66CYEL 3/4" x 66' Yellow 10
66CGRY 3/4" x 66' Gray 10

Standard Duty Cable Ties - Nylon
PC 5970

• Made In U.S.A.

• UL Recognized

• Manufactured With Filtered Nylon 6/6

• Finger Grips

• Angled Tail

• One Piece Design, Transition Rails,
And 3 Tooth Pawl

• Rounded Edges

• Bulk quantities and Mil Spec available

CAT NO COLOR L W THK TENSILE DIA. STD

DT4 Natural 4.12" .095" .042" 18 lb. .875" 100
DT4B
DT5 Natural 5.84" .140" .049" 40 lb. 1.437" 100
DT5B UV Black 5.84" .140" .049" 40 lb. 1.437" 100
DT6 Natural 7.56" .180" .052" 50 lb. 1.875" 100
DT6B UV Black 7.56" .180" .052" 50 lb. 1.875" 100
DT11 Natural 11.25" .180" .052" 50 lb. 3.062" 100
DT11B UV Black 11.25" .180" .052" 50 lb. 3.062" 100
DT14 Natural 14.56" .180" .052" 50 lb. 4.125" 100
DT14B UV Black 14.56" .180" .052" 50 lb. 4.125" 100

UV Black 4.12" .095" .042" 18 lb. .875" 100

Pull Line
PC 6000

Fire Stop Caulking Compound
PC 6160

• UL Classified

• Asbestos F

• Red

• 1 to 4 Hour Rating

• Remains Flexible

• Non Sagging

• Non Toxic-No VOC’s

• Interior Use

CAT NO CONTENTS COLOR STD

MC150 10.3 oz. Red 24

ree

4

To Order: Phone [phone] / Fax [phone]

Pull Line is used to pull rope
through conduit and can be used
with power fishing systems.

• Two Ply Pull Line

• Dispensing Box

• Dispensing Pail

• Rot & Mildew Resistant

CAT NO COLOR LENGTH WORKLOAD TENSILE STD

6502 Blue / White 6500' 20# 200# 1
6502P Blue / White 6500' Pail 20# 200# 1

Wiping Rags
PC 6252

Rags are all new material
bleached white knit. They are
medium weight, random size,
soft, absorbent, and are a low
linting Premium all purpose
wiper.

CAT NO DESCRIPTION STD

RGZ2 2 Pound Bag White Knit Rags 1

Tuf Towels
PC 6250

Dottie Tuf Towels are perfect on the
job site or anywhere water is not
readily available.
Powerful cleaning formula combined
with unique dispensing canister
allows for storage and re-use of tow­els, making your dollars last longer!
Tough on grime, but not your hands!

CAT NO DESCRIPTION STD

TT75 75 Pre-moistened 6

Multi-Purpose Hand Towels

CHEMICALS & TAPE

Dust Air
PC 6180

• High-Delivery Trigger Spray Action

• Extension Tube Applicator

• Non-Abrasive, Safe For Use On Plastics
and Energized Equipment

• Removes Microscopic Particles

• Ideal For Delicate Components Where
Residual Entrapment Could Be A Problem

• Debris Forcefully Dislodged From Delicate
Instruments

CAT NO CAN SIZE NET STD

420 12-oz. Aerosol (10-oz.) 6

Lock Back Knife
PC 6510

• Lightweight ABS Handle w/ Clip

• Quick Change Blade Mechanism

• One Hand Opening Mechanism

• Spring Blade Release

• Includes Blade Storage & 6
Blades

• Caution! Always Wear Eye
Protection

CAT NO DESCRIPTION STD

LBK Folding Lock-Back Utility Knife 1

Replacement Blades 0

UBK

Double Pointed Replacement Blades 1
One Card Contains 5 Blades

Wire Stripper / Cutter
PC 6590

This handy Wire Stripper/Cutter
has been one of the most popular
wire strippers contractors use. It is
effective and fits easily in a pouch
or pocket.

• Adjustable

• Cushion Grip

• Caution!
Always Wear Eye Protection

Hornet & Wasp Spray
PC 6180

Fast-acting powerful aerosol satu­rates instantly to eliminate hornets,
wasps, and yellow jackets.

• USDA F-2

• Sprays Up To 20 Ft.

• High-Delivery Valve

• High %Active Ingredient

• High Dielectric Strength of 41kV/mm

• EPA Reg. No. 1021-1649

• Lasting Residual Deposit Prevents
Reinfestation For Weeks

CAT NO CAN SIZE (NET) STD

862 20-oz. Aerosol (15-oz.) 12

ProGrabit - Screw Removal Kit
PC 6352

• Quickly And Easily Removes Most
Damaged Screws Such As Hex,
Phillips, Torx, Square Drive; Sizes No. 4

- No.14 From Wood, Plastic Or Metal

• Two-Step, Drill Bit And Extractor In One
Tool Extracts Broken Bolts And
Damaged Screws Fast

• Use In Reverse Only With 3/8 In.
Variable Speed Reversible Power Drill

• Drills Up To Grade 8 And 10.0 Class
Fasteners; Extracts Bolt Sizes No. 10­3/8 In. (5mm-10mm)

CAT NO DESCRIPTION STD

GBKP 3-Piece ProGr
Replacement Bits Available

abit Screw Removal Kit 1

Sharpie® Holder
PC 6770

• Constructed of Heavy Duty Webbing

• Heavy Duty Belt Clip

• Die Cast Cap

• Webbing Prevents Accidental
Marking of User's Clothing

CAT NO DESCRIPTION STD

SH Shar

pie® Holder 1

TOOLS & SPECIALTY ITEMS

CAT NO DESCRIPTION STD

DS1 Adjustable Stripper Cushion Grip 1

See new products at lhdottie.com

5

13 in 1 Ratcheting Screwdriver
PC 6755

• Convenient Storage For A Wide Range

TOOLS & SPECIALTY ITEMS

Phillips

0+3 1+2

CAT NO CAP/BODY DESCRIPTION STD

D131R Red/Black 13 in 1 Ratcheting Screwdriver 1

Of Bits

• 1/4" Hex Driver Shaft - Great For 1/4"
Hex Head Screws

• Patent Pending ZAD 8 Zinc Alloy SOLID­CORE™ Ratchet Delivers Over 225 lbs
Of Torque Strength

• Display Pack

• Precision 28 Tooth Ratchet Makes
Driving Fasteners Faster And Easier.
Limited Lifetime Warranty.

• Heavy Duty Nylon Reinforced Handle &
Chamfered Solid Steel Shaft For Long
Life & Durability

• Cushion Grip, Tapered Designed Handle

- Extra Comfort And Less Fatigue

Square

1+2

Star

T10+T15 T20+T25

Slotted

4+6

Tamper Proof 15 in 1 Screwdriver
PC 6763

Patented
Bit Storage in
the Handle!

This 15 in 1 Tamper Proof driver is a must for all
commercial/industrial tradesmen (Electricians, Security, etc.).
The 15 in 1 Tamper Proof comes loaded with the most common
security bits, including: Spanner, Hex pin and Star pin.

Hex Pin

1/8+9/64 5/32+3/16

CAT NO CAP/BODY DESCRIPTION STD

D151TP Red/Black 15 in 1 Tamper Proof Screwdriver 1

Spanner

6+8 10+12

T10+T15 T20+T25 T27+T30

Star Pin

Dial-A-Drill
PC 6340

• Industrial Quality

• M2 High Speed Steel

• Jobber Length

• Fractional Sizes

• Caution! Always Wear Eye Protection

CAT NO DESCRIPTION SIZES STD

DB13K 13 pc. set 1/16"-1/4" x 64th 1

Snaggletooth Pro Saw
PC 6559

The Snaggletooth Pro Saw is the right tool for cutting openings
for electrical outlets, and the hardened tip penetrates drywall
easily eliminating the need to drill.

Hex

Hex

8 in 1 Stubby Ratchet Driver (Tamper Proof)
PC 6778

SRD8

#1, #2 x 2pcs

#1, #2 x 2pcs

1/4'', 3/16''

• Contractor Preferred /Industrial Grade

• Includes 8 Industrial Quality Bits

• Non-Slip Grip Design

• High Torque 3 Way Reversible Ratchet Mechanism

• Easy Bit Storage in Handle

CAT NO DESCRIPTION STD

SRD8 8 in 1Stubby Ratchet Driver 1
SRD8TP

8 in 1 Tamper Proof Stubby Ratchet Driver 1

SRD8TP

T15, T20, T25

1/8'', 5/32''

#6, #8, #10

Compact Combo Bit Kit
PC 6340

• 31 Piece Assorted Standard and
Tamper Proof

• Packed In A Belt Mount Case

• Contains Most Popular Sizes of
Standard and Tamper Proof Bits

31 Piece Assortment Kit
contains the f

• Square Dr

• Phillips 1 Ea IB0P, IB1P, (IB2P 2 Ea), IB3P

• Slotted 1 Ea IB0S, IB1S, (IB2S 2 Ea), IB3S

• Star Pin 1 Ea 60TR10, 15, 20, 25, 27, 30,

• Spanner 1 Ea 115-6, 115-8, 115-10, 115-12, 115-14

• Hex Pin 1 Ea 73TR3, 5, 7, 8, 9

• Bit Holder 1 Ea QCA14

CAT NO DESCRIPTION STD

IB31PK 31 Assorted Bits w/ Quick Realease Bit Holder 1

ollowing:

ive 1 Ea IB0, IB1, IB2, IB3

T E C H T A L K

Fastener Tools

Dottie provides professional quality Insert & Power
Bits, Magnetic Hex Tools and Accessories for all your
fastener driving applications including Tamper Proof.
Dottie tools and accessories are manufactured using
shock resistant tool steel, a proprietary heat treatment
process and
are precision
machined,
ensuring maxi­mum durability
and an excel­lent fit which
reduces cam
out and exces­sive wear.

Carded Bits

Bit Holders & Extensions

CAT NO DESCRIPTION LENGTH STD

SNG6 Snaggletooth Pro Saw 6” Blade/ 12” Overall 1

6

To Order: Phone [phone] / Fax [phone]

Magnetic

Hex Tools

Bit Assortments

Protective Eyewear
PC 6610

Tip-Bits™
PC 6375

Industrial safety eyewear is
designed to protect you.
Available in a variety of styles,
finishes and lens color tints,
they are designed down to the
smallest detail to provide opti­mal performance with state of
the art comfort, style and pro­tection.

CAT NO COLOR CONTENTS DESCRIPTION STD

ERAZ100 Razor Matte Black Clear 1
ERAZ120 Razor Matte Black Yellow 1
ERAZ175 Razor Matte Black Dark Blue Mirror 1
EKMD000 Komodo Crystal Clear Clear 1
EKMD110 Komodo Crystal Black Clear 1

Razor

Komodo

Other colors and styles available

Dust Mask
PC 5310

• General Purpose
CAUTION: Do Not Use As Protection From; Asbestos, Silica or
Cotton Dust, Toxic Dust, Fumes, Mists, Gas or Vapor. NOT TO
BE USED IN SPRAY PAINT OPERATIONS!

CAT NO DESCRIPTION STD

MSK50 General Purpose Dust Mask 50
MSK55 General Purpose Dust Mask (5 pack) 12 packs

First Aid Kits
PC 6615

• Molded Handle For Carry or Mount Kit On Work Site

TOOLS & SPECIALTY ITEMS

• No Need To Buy A New Bit
When Just The Tip Is Worn

• A Real Money Saver. Base Bits
Last 3 to 4 Times Longer At A
Fraction Of The Cost

• Economical Replaceable-Tips
Lock In Place.

• Step Bit Performance Remains
Identical To That Of Non­Replaceable Tip Bits.

• Constructed Of M2 High

Speed Steel, Coated With
Titanium And Cobalt.

• Tri-Cut Tip Cuts Smoother,
Faster And Cooler.

CAT NO SIZE RANGE SHANK STD

RTTP6000 Replaceable Tip - 2 Pack 1/4" 1

Fits all Tip Bits.
Can also be used as
a 1/4" - 1/2" Step Drill
Steps: 5/32", 1/4",
5/16", 3/8", 7/16", 1/2"

RTTP6010 1/4" - 7/8" Base & Tip 1/4" 1

Steps: 9/16", 11/16", 3/4",
13/16", 7/8"

RTTP6020 1/4" - 1-1/8" Base & Tip 1/4" 1

Steps: 19/32",21/32", 3/4",
13/16", 7/8", 15/16", 1-1/32",
1-1/18"

RTTP6030 1/4" - 1-3/8" Base & Tip 1/4" 1

Steps: 5/8", 3/4", 7/8", 1",
1-1/16", 1-3/16", 1-1/4",
1-5/16", 1-3/8"

RTTP6040 Kit contains: 1/4" 1

1/4" - 1/2" Extra Tip
1/4" - 7/8" Base & Tip
1/4" - 1-1/8" Base & Tip

CAT NO DESCRIPTION STD

FK25E 25 Person Contractor Kit 1
FKR25E 25 Person Contractor Refill 1
FK50E 50 Person Contractor Kit 1
FKR50E 50 Person Contractor Refill 1
FK75E 75 Person Contractor Kit 1
FKR75E 75 Person Contractor Refill 1

See new products at lhdottie.com

Latex Gloves and Shoe Covers
PC 6771

Shoe Covers

• Anti-Static
vious Material

• Imper

• Non-linting

• EZ On-EZ Off

Latex Gloves

ior Quality

• Super

• Resistant To Most

Residual Solvents &
Chemicals

• Universal Fit

• Perfect For

Finish Work

CAT NO DESCRIPTION STD

SC 50 Shoe Covers in Jar 1
LG100 100 Latex Gloves in Jar 1

7

TOOLS & SPECIALTY ITEMS

Batteries
PC 6790

The Ultimate-X Power batteries are
manufactured to deliver high-perform­ance results and are quality guaranteed
to equal or exceed any standard alka­line battery in the market. Manufactured
under ISO-90001-2004 and ISO-1403­2000 Certificates to guarantee manu­facturing excellence, the Ultimate X­Power dry cell batteries deliver superior
results without the added overhead
costs of nationally advertised brands.

Extension Cords
PC 6800

• Available In 13 Or 15 Amp.

• Wattage Rated At 1625 Or 1875

• Conductor Blade / Pin Designed
To Prevent Break-Off Or Pull-Out

• Light Embedded In The Female
Connector Lights To Let You Know
The Power Is On.

• Triple Tap Provided On 100 Ft.
Cords Allowing Additional Outlets
For Power Distribution.

• Cord Remians Flexible Even
Under The Most Extreme Weather
Conditions

CAT NO SIZE COLOR AWG WIRE AMP WATTS STD

PEC14350 50 Ft. Green Cord/ 14/3 SJTW 15 1875 6

YELLOW Stripe-with clear
lighted end

PEC143100 100 Ft. Green Cord 14/3 SJTW 13 1625 4

Stripe-with clear
lighted-Triple Tap end

CAT NO DESCRIPTION STD
Carded Packs

BATAAACARD 1 Card - 4 AAA Batteries 12
BATAACARD 1 Card - 4 AA Batteries 12
BATCCARD 1 Card - 2 C Batteries 12
BATDCARD 1 Card - 2 D Batteries 12
BAT9VCARD 1 Card - 1 9V Battery 12

Contractor Pac

BATAAA 1 Pack - 24 AAA Batteries 12
BATAA 1 Pack - 24 AA Batteries 12
BATC 1 Pack - 12 C Batteries 12
BATD 1 Pack - 12 D Batteries 12
BAT9V 1 Pack - 8 9V Batteries 12

ks

Flex-A-Bit
PC 6360

Flex A Bits are used to drill within walls and are able to reach
normally inaccessible areas through a small opening. After
(drilling) through a stud or header, a wire is attached to the fish
hole in the flute and the drill is retracted pulling the wire
through. The FG357 Flex A Guide tool aids in positioning the bit.

CAT NO SIZE STD

FB3854 3/8 x 54" 1
FB3872 3/8 x 72" 1
FB5054 1/2 x 54" 1
FB5072 1/2 x 72" 1
FB9654 9/16 x 54" 1
FB9672 9/16 x 72" 1
FB7554 3/4 x 54" 1
FB7572 3/4 x 72" 1

Adapters
PC 6805

• 12/3 STW

• Available In 15 or 20Amp.

• Wattage RatedAt 1875 or 2500

• Solid Molded Vinyl Connectors

PAY12315

PAW12315

PAS12315

PAT12315

CAT NO SIZE COLOR AWG WIRE AMP WATTS STD

PAY12315 2 Ft. Yellow Cord 12/3 STW 15 1875 1

Y Adaptor Straight
(15 Amp)

PAW12315 2 Ft. Yellow Cord 12/3 STW 15 1875 1

W Adaptor Straight
(15 Amp)

PAS12315 2 Ft. Yellow Cord 12/3 STW 15 1875 1

Straight Adaptor
(15 Amp)

PAT12315 2 Ft. Yellow Cord 12/3 STW 15 1875 1

Straight Triple Tap
Adaptor (15 Amp)

8

To Order: Phone [phone] / Fax [phone]

Techwear™ Gloves
PC 6774

• Ergo Cut Technology

• Neoprene-Spandex Laminated Back

• 100% Washable

• Charmude™ Synthetic Leather Palm For Ventilation

• Double-Stitched Schoeller® Keprotec™ Secondary
Palm Layer For Positive Grip And Shock Absorption

Techwear™, a Dottie exclusive, is a form fitting glove that almost
feels like part of your hand. Made with the finest materials, they
are available in three color coded styles; blue for full finger lined,
red for full finger unlined, and yellow for the half finger version.

CAT NO SIZE DESCRIPTION COLOR STD

GVT1M Medium Full Finger (Lined) Blue 1
GVT1L Large Full Finger (Lined) Blue 1
GVT1X X Large Full Finger (Lined) Blue 1
GVT1XX XX Large Full Finger (Lined) Blue 1
GVT2M Medium Full Finger (Unlined) Red 1
GVT2L Large Full Finger (Unlined) Red 1
GVT2X X Large Full Finger (Unlined) Red 1
GVT2XX XX Large Full Finger (Unlined) Red 1
GVT3M Medium Half Finger (Unlined) Yellow 1
GVT3L Large Half Finger (Unlined) Yellow 1
GVT3X X Large Half Finger (Unlined) Yellow 1
GVT3XX XX Large Half Finger (Unlined) Yellow 1

TOOLS & SPECIALTY ITEMS

GVT1

GVT2

GVT3

T E C H T A L K

Posi-GripTM non-slip cradle
for sure grip and control when
handling tools

Neoprene/Spandex™ laminated back

• Neoprene gives soft padded
protection to the back of hand.

• The breathable Spandex™ ventilates to keep
hands cool and flexes for a snug, comfortable fit.

• Full-finger, Full-finger lined, and Half-finger ver­sions available

• 100% washable

Work Gloves
PC 6773

Work gloves are available in a wide variety of fabrics and styles; Cotton, Canvas, Jersey (lined and Unlined), PVC Coated,
Cowhide, Deerskin and Pigskin. Additionally Top Sellers include the Super Gripper, a latex dipped cool cotton glove which resists
punctures, cuts and abrasions. Our Dottie exclusive line of Techwear™ a form fitting glove that is so comfortable it feels like it’s a
part of your hand. Techwear™ is available in three color coded styles.

CAT NO SIZE DESCRIPTION STD

GV20M Medium Cotton Knit Super Gripper 1
GV20L Large Cotton Knit Super Gripper 1
GV20X Extra Large Cotton Knit Super Gripper 1

Techwear™Gloves

Chamude™ synthetic leather
palm absorbs moisture, venti­lates and provides both excel­lent sensitivity and abrasion
resistance

Double-stitched
Schoeller
ary palm layer for positive grip
and shock absorption

®

Keprotec™ second-

GV35M Medium Premium Pigskin Keystone 1
GV35L Large Premium Pigskin Keystone 1
GV35X Extra Large Premium Pigskin Keystone 1

GV42M Medium Top Grain Leather Drivers Pull Strap 1
GV42L Large Top Grain Leather Drivers Pull Strap 1
GV42X Extra Large Top Grain Leather Drivers Pull Strap 1

GV52M Medium Premium Deerskin Drivers 1
GV52L Large Premium Deerskin Drivers 1
GV52X Extra Large Premium Deerskin Drivers 1

See new products at lhdottie.com

GV20

GV35

GV42

GV52

9

Quick Sticks
PC 6055

Dottie Quick Sticks offer unmatched durability to reach over drop

TOOLS & SPECIALTY ITEMS

ceilings, through insulated walls, as well as under floors and in
any confined space. They are flexible enough to bend to the
angle you need, yet rigid enough to push through insulation.

• Quick Sticks Will Flex Up To 90° Without Breaking

• Made From High Strength, Low Weight Fiberglass Material

• Made in USA

• Available Attachments: Pulling Hooks, Pulling Eyes, And Whisk

• Lite Sticks “Glow” In The Dark For Better Visibility During Use

• Caution! Always Wear Eye Protection

T E C H T A L K

Dottie Quick Sticks

Quick Sticks screw together to reach full or desired
length. Use to fish wires through walls, under floors,
over suspended ceilings and into many other
confined spaces. Quick Sticks will flex up to 90° with­out breaking. Made from high strength, low weight
fiber glass material. Quick Sticks are ideal for pulling
and stringing communication wires, alarm system
wires, romex, telephone and thermostat wire.
Available attachments are; Pulling Hooks, Pulling Eyes
and Whisk Heads. Our glow in the dark version is
available in 3/16" & 1/4" diameter.

Whisk
QSW36
QSW25

CAT NO SIZE DESCRIPTION STD

QS3630 3/16" x 30' Tube Contains: Five - 3/16" x 6' 1

QS3630LS 3/16" x 30' Tube Contains: Five - 3/16" x 6' 1

QS3612 3/16" x 12' Kit Contains: Four - 3/16" x 3' 1

QS3612LS 3/16" x 12' Kit Contains: Four - 3/16" x 3' 1

QS3612X4 3/16" x 12' Tube Contains: Three - 3/16" x 4' 1

QS3612X4LS 3/16" x 12' Tube Contains: Three - 3/16" x 4' 1

QS2524 1/4" x 24' Tube Contains: Four - 1/4" x 6' 1

QS2524LS 1/4" x 24' Tube Contains: Four - 1/4" x 6' 1

QS2512 1/4" x 12' Kit Contains: Four - 1/4" x 3' 1

QS2512X4 1/4" x 12' Kit Contains: Three - 1/4" x 4' 1

QS2512LS 1/4" x 12' Kit Contains: Three - 1/4" x 4' 1

Hooks
QSPH36
QSPH25

Red Rods & Two Pulling Eyes

Lite Stick Rods & Two Pulling Eyes

Red Rods w/ Pulling Eye & Hook

Lite Stick Rods w/ Pulling Eye & Hook

Red Rods w/ Pulling Eye & Hook

Lite Stick Rods w/ Pulling Eye & Hook

White Rods & Two Pulling Eyes

Lite Stick Rods & Two Pulling Eyes

White Rods w/ Pulling Eye & Hook

White Rods w/ Pulling Eye & Hook

Lite Stick Rods w/ Pulling Eye & Hook

Eyes
QSPE36
QSOE25

Web Straps (Tie Down)
PC 6775

• Weatherproof

• 750 lb. Test Webbing

• Strong 1" Heavy Duty Web Construction

• Rustproof, Cam-Action Buckle

• For Securing Contractor. DIY, Landscape Maintenance,
Recreational Loads

• Available In 2 Piece Bag Or Counter Merchandiser

• 6 Color Coded Lengths: 2 Ft. To 12 Ft.

• Individual Lengths May
Be Re-ordered In 1
Dozen Quantities

• Display Box Comes With
Header Card

Quick Sticks Accessories

QSPE36 3/16"
QSPH36 3/16" 3/16" Pulling Hook 1
QSW36 3/16" 3/16" Whisk (egg beater) Head 1
QSPE25 1/4" 1/4" Replacement Pulling Eye 1
QSPH25 1/4" 1/4" Pulling Hook 1
QSW25 1/4" 1/4" Whisk (egg beater) Head 1

3/16" Replacement Pulling Eye 1

10

To Order: Phone [phone] / Fax [phone]

CAT NO DESCRIPTION COLOR STD

2WS02 2' Nylon Tie Down w/Buckle Red 1
2WS04 4' Nylon Tie Down w/Buckle Yellow 1
2WS06 6' Nylon Tie Down w/Buckle Green 1
2WS08 8' Nylon Tie Down w/Buckle Purple 1

Tool Holders, Organizers & Accessories
PC 6770

• Ballistic Nylon Bindings And Grip Strip™ Hook And Loop
Fastener System Keeps Pouches In Place

• Double Layer Lightweight Nylon Will Not Crack, Harden Or
Mildew

• Nylon Stitching & Double Steel Rivets Reinforce Major
Stress Points

• All Parts Are Removable & Interchangeable

CAT NO DESCRIPTION STD

YA1148 22-Pocket, Drawstring BucketBag™ 1

10" Round x 6" High

YB1137 12-Pocket Traytote™ Bag 1

12" L x 8" W x 12" H Multi-compartment.
Plastic tray included, 11" X 6"

YB1139 14-Pocket, Large Traytote™ Bag 1

2 Pockets inside, 12 outside. 13-1/2" x 6"
multi-compartment plastic tray included

YB1526 28-Pocket Electrical & Maintenance Tool Pouch 1

7" x 5-1/2" multi-compartment.
Plastic tray included

Need proof positive that something doesn’t have to be made
of leather to be tough and durable? Look no further than
Dottie’s lineup of hard working, hard wearing, nylon tool bags,
featuring stay open pockets. Softside Tool carriers include
handy tote trays and are just one of the creative touches
you’ll find in our product line.

YA1148

YB1137

TOOLS & SPECIALTY ITEMS

YB1530 43 Pockets w/ Plastic Tray 1

Window pockets & shoulder strap
23" L x 12" W x 15" H

YB1537 13" Multi-Compartment Tool Carrier 1

23 Pockets inside and 10 pockets outside.
Zippered side panel. Padded, reinforced web carry­ing handles. 13" L x 7" W x 13" H

YB1572 18" Softsided Tool Box 1

21 Multi-use outside pockets, 12 inside.
Padded rubber web carrying handle.
8" x 4" Multi-compartment plastic tray.
Large interior. 18" L x 9-1/2" W x 14" H

YB1582 15" Zipper Top Tool Carrier with molded base. 1

Exclusive tray system for small parts and acces­sories.
12 external pockets and 8 inside pockets.
15" L x 8-1/2" W x 12-1/2" H

YG6MN Electrical Meter/Tester/Phone Holder 1

YG1104 4 Pocket Multi-purpose Tool Holder 1

YF5508 20-pocket Pro Electrician's Tool Pouch 1

with shoulder strap, 6 large screwdriver holders
1 steel hammer holder, grip-strip hook & loop fas­tening system

YB1139

YB1530

YB1572

YB1526

YB1537

YB1582

YC345 Professional Kneepad 1

SuperThick High Density foam for maximum com­fort. Two strap fastening adds stability.

See new products at lhdottie.com

YG6MN

YG1104

YF5508

YC345

11

For over four decades L.H. Dottie has manufactured quality products for the Security, Electrical,
Plumbing and Industrial trades, and today Dottie continues to provide what the professional
expects – guaranteed, high quality products. Keeping up-to-date with the ever changing demands
of the modern tradesman is a challenge we happily accept. When Security Professionals specify
‘Dottie’ – we know we are on the right track.

L.H. Dottie’s broad array of products appeals to the distributor seeking to consolidate purchases,
as Dottie truly is the one –stop source for Security, Electrical, Plumbing and Industrial products.

Other Products Available From LH Dottie

• Holesaw & Arbors

• Hacksaws & Re-Clip Blades

• Wire Dispensers & Carts

• Paints & Chemicals

Check Our Website For The Latest Innovation!

• Caution - Burial - Detectable Tape

• High Speed Drill Bits

• Masonry Drill Bits

• Bellhanger Bits

lhdottie.com

LH Dottie

1-800-982-1901

Fax: [phone]

6131 S. Garfield Ave.

Commerce, CA 90040

• Spade Bits

• Wire Marker Books

• Handi Foam
