ENGLISH

User Guide

LG-P714

MFL00000000 (1.0)

www.lg.com

Part 15.21 statement

Part 15.105 statement

ENGLISH

User Guide

Screen displays and illustrations may differ from those you see on actual phone.

Some of the contents of this guide may not apply to your phone, depending on the software and your service provider. All information in this document is subject to change without notice.

This handset is not suitable for people who have a visual impairment due to the touch screen keyboard. Copyright ©2013 LG Electronics, Inc. All rights reserved. LG and the LG logo are registered trademarks of LG Group and its related entities. All other trademarks are the property of their respective owners.

Google™, Google Maps™, Gmail™, YouTube™, Google Talk™ and Play Store™ are trademarks of Google, Inc.

Getting to know your phone

Before you start using the phone, please read this!

Please check to see whether any problems you encountered with your phone are described in this section before taking the phone in for service or calling a service representative.

1. Phone memory

When there is less than 10% of space available in your phone memory, your phone cannot receive new messages. You need to check your phone memory and delete some data, such as applications or messages, to make more memory available.

To uninstall applications:

1 Touch > Apps tab > Settings > Apps from the DEVICE category.

2Once all applications appear, scroll to and select the application you want to uninstall.

3 Touch Uninstall.

2. Optimising battery life

Extend your battery's life between charges by turning off features that you don't need to having running constantly in the background. You can monitor how applications and system resources consume battery power.

Extending your phone's battery life:

t Turn off radio communications when you are not using. If you are not using Wi-Fi, Bluetooth or GPS, turn them off.

t Reduce screen brightness and set a shorter screen timeout.

t Turn off automatic syncing for Gmail, Calendar, Contacts and other applications. t Some applications you have downloaded may reduce battery power.

To check the battery power level:

t Touch > Apps tab > Settings > About phone from the SYSTEM > Battery.

The battery status (charging or not charging) and Battery level (percentage charged) is displayed at the top of the screen.

To monitor and control how battery power is being used:

t Touch > Apps tab > Settings > About phone from the SYSTEM > Battery > Battery use.

Battery usage time is displayed on the screen. It tells you how long it has been since you last connected your phone to a power source or if currently connected, how long the phone was last running on battery power. The screen shows the applications or services using battery power, listed in order from the greatest to smallest amount used.

3. Using folders

You can combine several app icons in a folder. Drop one app icon over another on a Home screen, and the two icons will be combined.

Getting to know your phone

4. Before installing an open source application and OS

WARNING

If you install and use an OS other than the one provided by the manufacturer it may cause your phone to malfunction. In addition, your phone will no longer be covered by the warranty.

WARNING

To protect your phone and personal data, only download applications from trusted sources, such as Play Store™. If there are improperly installed applications on your phone, it may not work normally or a serious error may occur. You must uninstall those applications and all associated data and settings from the phone.

5. Using the Hard Reset (Factory reset)

If your phone needs to be restored to its original condition, use Hard Reset to reboot your phone.

1When the phone is switched off, press and hold the Volume down key + Quick key + Power key.

2 Release the Power key when the LG logo appears on the screen.

3Release Volume down key + Quick key when the LG logo disappears. After a while, Android robot will be displayed and recovery will proceed.

Leave your phone for at least a minute while the hard reset is carried out. You will then be able to switch your phone back on.

WARNING

If you perform a Hard Reset, all user applications, user data and DRM licenses will be deleted. Plaese remember to backup any important data before performing a Hard Reset.

6. Opening and switching applications

Multitasking is easy with Android because you can keep more than one application running at the same time. There is no need to quit an application before opening another. Use and switch between several open applications. Android manages each application, stopping and starting them as needed to ensure that idle applications don't consume resources unnecessarily.

To stop applications:

1 Touch > Apps tab > Settings > Apps from DEVICE > RUNNING. 2 Scroll and touch the desired application and touch Stop to stop it.

7. Hold your phone upright

Hold your mobile phone vertically, as you would a regular phone. The LG-P714 has an internal antenna. Be careful not to scratch or damage the back of the phone, as this may affect performance.

While making/receiving calls or sending/receiving data, avoid holding the lower part of the phone where the antenna is located. Doing so may affect call quality.

Getting to know your phone

8. When the screen freezes

If the screen freezes or the phone does not respond when you try to operate it:

Remove the battery, reinsert it, then turn the phone on.

Press and hold the Power/Lock key for 10 seconds to turn it off. If it still does not work, please contact the service centre.

Device components

Front-facing Camera lens

Earpiece

Proximity sensor

Power/Lock key

t Switch your phone on/off by pressing and holding this key. t Short press to lock/unlock the screen.

Back key

t Return to the previous screen.

Home key

t Return to the Home screen from any screen.

Menu key

t Check what options are available.

NOTE: Proximity sensor

When receiving and making calls, the proximity sensor automatically turns the backlight off and locks the touch screen by sensing when the phone is near your ear. This extends battery life and prevents you from unintentionally activating the touch screen during calls.

WARNING

Placing a heavy object on the phone or sitting on it can damage the LCD and touch screen functions. Do not cover the LCD proximity sensor with protective film. This could cause the sensor to malfunction.

Getting to know your phone

Power/Lock key

Quick key

(QuickMemo by default) Instantly access to the app (QuickMemo by default) you preset.

Earphone jack

Charger/USB port

Microphone

Volume keys

t In the Home screen: Control ringer volume.

t During a call: Control your earpiece volume.

t When playing a track: Control volume continuously.

Camera lens

SIM card slot

Battery cover

LED flash

Battery

				Speaker

microSD Card slot
microSD Card slot

Installing the SIM card and battery

Before you can start exploring your new phone, you'll need to set it up. To insert the SIM card and battery:

1To remove the battery cover, hold the phone ﬁrmly in one hand. With your other hand, lift off the battery cover with your thumbnail as shown in ﬁgure.

NOTE: Put your thumbnail into the USB port hole and lift off the battery cover.

Getting to know your phone

2Slide the SIM card into the slot. Make sure the gold contact area on the SIM card is facing downwards.

3Insert the battery into place by aligning the gold contacts on the phone and the battery (1) and pressing it down until it clicks into place (2).

4Align the battery cover over the battery compartment and press down each of the 7 points as shown in the ﬁgure until it clicks into place.

Charging the phone

The charger connector is at the bottom of the phone. Insert the charger and plug it into an electrical outlet.

NOTE: The battery must be fully charged initially to improve battery lifetime.

NOTE: Do not open the battery cover during the charging your phone.

WARNING

Use only LG-approved chargers, batteries, and cables. When using unapproved chargers or cables, it may cause battery charging delay or pop up the message regarding charging delay. Or, unapproved chargers or cables can cause the battery to explode or damage the device, which are not covered by the warranty.

Using the memory card

To insert a memory card:

Insert the memory card into the slot. Make sure the gold contact area is facing downwards.

To remove the memory card safely:

Touch > Apps tab > Settings > Storage from the DEVICE > Unmount SD card

> OK.

Getting to know your phone

NOTE: The LG-P714 supports memory cards up to 32 GB.

WARNING

Do not insert or remove the memory card when the phone is ON. Doing so may damage the memory card as well as your phone, and the data stored on the memory card may get corrupted.

To format the memory card:

Your memory card may already be formatted. If it isn't, you must format it before you can use it.

NOTE: All files on your memory card are deleted when it is formatted.

1 On the home screen, touch > Apps tab to open the menu.

2 Scroll and touch Settings > Storage.

3 Touch Unmount SD card and touch OK to conﬁrm it.

4Touch Erase SD card > Erase SD card > Erase everything, then conﬁrm your choice.

5 If you have set a pattern lock, input the pattern lock then select Erase everything.

NOTE: If there is content on your memory card, the folder structure may be different after formatting as all the files will be deleted.

Locking and unlocking the screen

If you do not use the phone for a while, the screen is turned off and locked automatically. This helps to prevent accidental touches and saves battery power. When you are not using the LG-P714, press the Power/Lock key to lock your phone.

Secure your lock screen

You can lock your screen so that only you can unlock it to access your phone.

To set an Unlock Pattern, PIN or Password for the first time:

1 Touch > Apps tab > Settings > Lock screen > Select screen lock. 2 Choose from None, Swipe, Face Unlock, Pattern, PIN, or Password. 3 Enter the desired information.

NOTE: Precautions to take when using pattern lock

It is very important to remember the unlock pattern you set. You will not be able to access your phone if you use an incorrect pattern 5 times. You have 5 opportunities to enter your unlock pattern, PIN or password. If you have used all 5 opportunities, you can try again after 30 seconds.

When you cannot recall your unlock pattern:

If you logged in to your Google account on the phone but failed to enter the correct pattern 5 times, tap the Forgot pattern? button. You are then required to log in with your Google account to unlock your phone.

If you have not created a Google account on the phone or you forgot it, you have to perform a hard reset.

Your Home screen

Touch screen tips

Here are some tips on how to navigate around your phone.

Touch or tap – To choose a menu/option or open an application, touch it.

Touch and hold – To open an options menu or grab an object you want to move, touch and hold it.

Drag – To scroll through a list or move slowly, drag across the touch screen.

Swipe or slide – To swipe or slide, quickly move your finger across the surface of the screen, without pausing when you first touch it (so you don’t drag an item instead). For example, you can slide the screen up or down to scroll through a list, or browse through the different Home screens by swiping from left to right (and vice versa).

Double-tap – Double-tap to zoom on a web page or a map. For example, quickly double-tap a section of a web page to adjust that section to fit the width of the screen. You can also double-tap to zoom in and out when using Maps.

Pinch-to-Zoom – Use your index finger and thumb in a pinch or spread motion to zoom in or out when using the Browser, Maps, or browsing pictures.

Rotate the screen – From many applications and menus, the orientation of the screen adjusts to the device's physical orientation.

NOTE:

t To select an item, touch the centre of the icon.

t Do not press too hard; the touch screen is sensitive enough to pick up a light, firm touch.

t Use the tip of your finger to touch the option you want. Be careful not to touch any other keys.

Home screen

Simply swipe your finger to the left or right to view the panels. You can customise each panel with Apps, Downloads, Widgets and wallpapers.

NOTE: Some screen images may be different depending on your phone provider.

On your Home screen, you can view quick keys at the bottom of the screen. Quick keys provide easy, one-touch access to the functions you use the most.

Touch the Phone icon to bring up the touch screen dialpad to make a call.

Touch the Contacts icon to open your contacts.

Touch the Messaging icon to access the messaging menu. This is where you can create a new message.

Touch the Apps icon at the bottom of the screen. You can then view all your installed applications. To open any application, simply touch the icon in the applications list.

Customising the Home screen

You can customise your Home screen by adding Apps, Downloads, Widgets or Wallpapers. For more convenience using your phone, add your favourite widgets to the Home screen.

To add items on your Home screen:

1 Touch and hold the empty part of the Home screen.

2In the Add Mode menu, select items you want to add. You will then see added items on the Home screen.

3 Drag it to the location you want and lift your ﬁnger.

To remove an item from the Home screen:

t Home screen > touch and hold the icon you want to remove > drag it to

TIP! To add an application icon to the Home screen from the Applications menu, touch and hold the application you want to add.

Your Home screen

Returning to recently-used applications

1Press and hold the Home key. The screen displays a pop-up with icons of applications you used recently.

2Touch an icon to open the application. Or touch the Back key to return to your current application.

Notification drawer

The notification drawer runs across the top of your screen.

Touch and slide the notification drawer down with your finger.

QuickMemo Sound

Data

Wi-Fi Bluetooth

Below is a table explaining the meaning of icons you're likely to see in the status bar. The Notifications Panel displays all your notifications along with the Quick Settings at the top.

Quick Settings

Swipe the Quick Settings bar left or right to see more keys.

Touch > to manage your Quick Settings. Here you can add and remove manage QuickMemo, Sound profile, Data enabled, Wi-Fi, Bluetooth, GPS, Auto-rotate screen, Accounts & sync, Portable Wi-Fi hotspot, Power saver, or Airplane mode.

Viewing the status bar

The status bar uses different icons to display phone information such as signal strength, new messages, battery life, active Bluetooth and data connections.

Icon Description

No SIM card

No signal

Airplane mode

Connected to a Wi-Fi network

Power saver is on

Wired headset

Call in progress

Call hold

Speakerphone

Phone microphone is muted

Missed call

Bluetooth is on

Icon Description

System warning

Alarm is set

New voicemail

Ringer is silenced

Vibrate mode

Battery fully charged

Battery is charging

Phone is connected to PC via USB cable

Downloading data

Uploading data

GPS is acquiring

Receiving location data from

GPS

Your Home screen

Data is syncing

New Gmail

New Google Talk message

Song is playing

FM radio turned on in the background

USB tethering is active

Portable Wi-Fi hotspot is active

Both USB tethering and portable hotspot are active

On-screen keyboard

You can enter text using the onscreen keyboard. The onscreen keyboard appears automatically on the screen when you need to enter text. To manually display the keyboard, simply touch a text field where you want to enter text.

Using the keypad & entering text

Tap once to capitalise the next letter you type. Double-tap for all caps.

Tap to switch to the numbers and symbols keyboard. You can also touch and hold this tab to view the Settings menu.

Tap to enter a space.

Tap to create a new line.

Tap to delete the previous character.

Entering accented letters

When you select French or Spanish as the text entry language, you can enter special French or Spanish characters (e.g. "á").

For example, to input "á", touch and hold the "a" key until the zoom-in key grows bigger and displays characters from different languages.

Then select the special character you want.

Google account setup

When you first turn on your phone, you have the opportunity to activate the network, to sign into your Google Account and how you want to use some Google services.

To set up your Google account:

Sign into a Google Account from the prompted set up screen.

Touch > Apps tab > select a Google application, such as Gmail > select New to create a new account.

If you have a Google account, touch Existing, enter your email address and password, then touch Sign in.

Once you have set up your Google account on your phone, your phone automatically synchronises with your Google account on the web.

Your contacts, Gmail messages, Calendar events and other information from these applications and services on the web are synchronised with your phone. (This depends on your synchronisation settings.)

After signing in, you can use Gmail™ and take advantage of Google services on your phone.
