1. Installation Guide for GEN9.4NADCANADA

This part establishes the installation guide for GEN9.4NADCANADA.

Description of installation is shown as below:







1. Number ① : Top cover

2. Number ② : TCU (Telematics Control Unit) : Power board

3. Number ③ : GEN9.4NADCANADA module

4. Number ④ : TCU main connector bracket.

5. Number ⑤ : Bottom cover

6. Number ⑥ : B to B connector

2/12

LG Electronics Inc. 2 13-12-16 





[Fig.1] VCP [module(NA D) + Power board(TCU)] setting information





[Fig.2] VCP [module(NAD) + Po wer board(TCU) + Housing] setting information (Full A ssembly)





<Front View> <Rear View >
