Video camera

Effect - Choose an effect tone to apply to the video you’re making. See

Choosing an effect tone on page 41.

White Balance - The white balance

ensures that any white in your photos is realistic. In order for your camera to correctly adjust the white balance you may need to determine the light conditions. Choose from Auto,

Daylight, Indoors, Illuminate and Cloudy.

Music video shot - This shot type

allows to take a shot with music or voice.

Recording speed - Record the video using Normal, Slow video, Fast

video.

Duration - Select the maximum

length of the recording.

Memory in use - Choose whether to save your videos to the Handset memory or to the External memory.

Hide icons - Hide the icons to the side of the viewfinder.

Get creative

Voice - Choose Mute to record a video without sound.

NOTE: Always touch Save after selecting a new setting to implement the changes you’ve made.

LG KF757 | User Guide

TIP! When you exit the video

camera all your settings will return to default, except image size and image quality. Any non-default settings you require will need to be reset, for example colour tone and white balance. Check them before you shoot your next video.

Changing the video image size

The more pixels, the larger the file size, which in turn means they will take up more memory. If you want to fit more videos onto your phone you can alter the number of pixels to make the file size smaller.

1 Select Size from the settings menu.

2 Select a pixel value from the four

options:

640x480(W) - The highest quality wide screen option.

320x240 - Smaller image size, therefore smaller file size. Great for saving on memory space.

176x144 - Smallest image size and therefore a smaller file size.

16:9 Wide - Wide screen option.

3 Select the size option you’d like to

use and press Save to implement your changes. The settings menu will automatically close, ready for you to shoot your video.

NOTE: When you view your videos, playback speed is 30 frames per second, with the exception of 120 fps where playback is at 15 frames per second.

WARNING: The great editing software on your LG KF757 is compatible with all video types except 640x480. Don’t record in this format if you plan to edit your video.

Choosing an effect tone

1 Select Settings and choose Effect.

2 There are twelve colour tone

options: Off, Black & White, Negative, Sepia, Blue, Emboss, Sketch, Purpulish, Bluish, Monochrome, Edgemap and Posterize.

3 Choose the colour tone you’d like to

use and press Select.

4 When you’ve made your selection,

the colour tone menu will automatically close, ready for you to shoot your video.

TIP! You can change a video

shot in colour to black and white or sepia after it’s taken, but you cannot change a video shot in black and white or sepia to colour.

Watching your saved videos

1 Select the album icon. Your album

will appear on screen.

2 Highlight the video you want to

view to bring it to the front of the album.

3 Select the video to open it fully.

Get creative

Your photos and videos

Editing photo album options

You can view and edit your images using the Options menu in the photo album.

View - View the image.

Send - Send the image to a friend.

Delete - Delete the image.

Use as - Set the image as a wallpaper/

contacts image/start-up or shut down image.

Slide show - Set the image as a slide show.

Edit - Edit the image.

Print - Print an image file via

PictBridge or Bluetooth.

Editing video album options

You can view and edit your videos using the Options menu in the video album.

Play - Play the video.

Send - Send the video to a friend.

Delete - Delete the video.

Get creative

Use as - Set the video as a ringtone.

Rename - Rename the video.

Edit - Edit the video.

LG KF757 | User Guide

TIP! You can easily delete a

photo or video. Select the photo or video, then select Options and choose Delete.

Adjusting the volume when viewing a video

To adjust the volume of the audio on a video, use up and down on the touch pad.

Capturing an image from a video

1 Play the video you would like to

capture an image from.

2 Press to pause the video on

the frame you’d like to convert to an image and open the options menu.

3 From the options menu select

Capture.

4 The image will appear on the screen

with its assigned image name.

5 Select OK.

6 Select Delete to return to the

album.

7 The image will be saved in the My

files folder and will appear in the album (You need to exit the album and then re-open for this to appear).

WARNING: Some functions

may not work properly if the multimedia le has not been recorded on the phone.

Sending a photo or video from the album

1 Select a photo or video to open it.

If you select a video, press when it starts to play.

2 Select the left soft key to open the

options menu.

3 Select Send and choose how

you would like to send the video or photo: Message, Email or

Bluetooth.

4 The chosen messaging application

will open so you can send the video or photo.

NOTE: The photo or video may need to be resized before it can be sent by MMS. Some videos may be too large to send by MMS at all, in which case you can choose one of the other sending options.

Viewing your photos as a slide show

Slide show mode will show all the photos in your album one at a time as a slide show.

1 Select the photo you would like to

begin the slide show.

2 Press the left soft key to open the

Options menu.

3 Select Slide show and it will begin.

Setting a photo as a wallpaper

1 Select the photo you would like to

set as a wallpaper.

2 Select the left soft key to open the

Options menu.

3 Select Use as - Wallpaper.

Get creative

Your photos and videos

Editing your photos

There are loads of great things you can do to your photos to change them, add to them or liven them up a little.

1 Open the photo you’d like to edit

and select Options.

2 Select Edit.

3 Select an icon to adapt your photo:

Rotate the image left or right.

Change the size of the photo.

Insert an icon to the image.

Clip the image to 640X480,

320X240, 176X146.

Distort the image.

Change the colour tone to Black and white, Sepia, or Colour negative.

Change or add a frame to the

image.

Reverse the picture to a mirror image.

Get creative

Change the image using morphing, fun mirror, or spotlight.

Adding an effect to a photo

1 From the editing screen, select

Special effect or Frame effect.

LG KF757 | User Guide

2 Choose to apply any of the two

options to the photo:

Special effect - Change the colour of a photo to Black and white,

Sepia or Colour Negative.

Frame effect - Add a frame to your

photo. Select the desired frame type. Select OK to have the chosen frame superimposed over your photo.

3 To undo an effect simply select

Undo.

TIP! You can use more than

one eect on a photo, except for a colour eect.

Morphing a photo

Morphing a photo is great for changing the facial expressions of friends, or just for distorting a photo for artistic effect.

1 From the editing screen select More

and then Morphing.

2 If the face in the picture is not

detected, a pop up message Face is not detected will be displayed

and the morphing effect will be cancelled.

3 If the face is detected the first

morphing style will be applied to the picture.

4 Select the morphing style you

would like to use on the photo.

5 Select the intensity of morphing.

6 Select OK to apply the changes.

Spotlighting a photo

1 Select the desired location on the

image.

2 Select the size of spotlight.

3 Select OK to apply the changes.

TIP! Use the Fun mirror to

copy the left side of the image over the right side to make fun pictures.

TIP! You can undo more than

one eect on a photo, except for a resize. If any eect is already applied before the resize eect, the applied and resize eects will be saved. The undo count will then be reset.

Editing your videos

Editing features are available for all video types except 640x480. Don’t record in this format if you plan to edit your video.

Trimming the length of your video

1 Choose the video you’d like to edit,

and touch Options.

2 Select Edit and choose Trim.

3 Select Start and End to mark the

new start and end points.

Merging two videos together

1 Choose the first video you’d like to

edit, and select Options.

2 Select Edit and choose Video

merge.

3 The My videos folder will open.

Choose the video you would like to merge to and choose Select.

4 Select Effect to choose how the

videos merge together: None, Fade out, Pan zoom, Oval, Uncover, Blind, Checker board or Dissolve.

Get creative

Your photos and videos

5 Press to save the new

merged video. Choose to save over the original file or as a new file.

6 Repeat these steps to merge more

videos.

Merging a photo with a video

1 Choose the video you’d like to edit,

and select Options.

2 Select Edit and choose Image

merge.

3 The My images folder will open.

Choose the photo you would like to merge into your video and choose

Select.

4 Select and slide the photo to merge

it to the end or the beginning of the video.

5 Select Effect to choose how the

photo and video merge together:

None, Fade out, Pan zoom, Oval, Uncover, Blind, Checker board or Dissolve.

Get creative

6 Press . Choose to save over

the original file or as a new file.

7 Repeat these steps to merge more

photos.

LG KF757 | User Guide

Adding text to a video

1 Choose the video you’d like to edit,

and select Options.

2 Select Edit and choose Text

overlay.

3 Enter your text using the keypad

and press Save.

4 Press Start and mark when you’d

like the text to appear.

5 Select the area of the screen you’d

like the text to appear in.

6 Select Cancel to mark when you’d

like the text to disappear.

7 Select Save to save it. Choose to

save over the original file or as a new file.

8 Repeat these steps to add more

text.

Overlaying a photo

1 Choose the video you’d like to edit,

and select Options.

2 Select Edit and choose Image

overlay.

3 The My images folder will open.

Choose the photo you would like to overlay your video and choose

Select.

4 Select Start and mark when you’d

like the photo to appear.

5 Select the area of the screen you’d

like the photo to appear in. If the photo is too big it will overlay the whole screen, not just the area selected.

6 Select Cancel to mark when you’d

like the photo to disappear.

7 Select Save to save it. Choose to

save over the original file or as a new file.

8 Repeat these steps to add more

photos.

Adding a voice recording

1 Choose the video you’d like to edit

and select Options.

2 Select Edit and choose Voice

recording. The quality of the

original audio will be affected by adding a voice recording.

3 Select Yes to continue.

4 Press Play to view your video. When

you get to the part you’d like to record your voice over, press Pause.

5 Press End to stop recording.

6 Select Save followed by Yes to save.

Choose to save over the original file or as a new file.

7 Repeat these steps to add more

voice recordings to the video.

Adding a soundtrack to your video

1 Choose the video you’d like to edit

and select Options.

2 Select Edit and choose Audio

dubbing.

3 The My sounds folder will open.

Choose the track you would like to add to your video and press Select.

4 The original audio recording of your

video will be erased.

5 If the audio is shorter than the video

choose whether to play Once or to Repeat it.

6 Choose to save over the original file

or as a new file.

Get creative

Your photos and videos

Changing the speed of your video

1 Choose the video you’d like to edit

and select Options.

2 Select Edit and choose Time

scaling.

3 Select one of the four speed

options: x4, x2, x1/4, x1/2.

4 Choose to save over the original file

or as a new file.

Adding a dimming effect

1 Open the video you’d like to edit,

select and select Options.

2 Select Edit and choose Dimming

effect.

3 Choose to save over the original file

or as a new file.

4 Your video will now fade in at the

start and fade out at the end.

Get creative

LG KF757 | User Guide

Multimedia

You can store any multimedia files on your phone’s memory in My stuff so that you have easy access to all of your pictures, sounds, videos and games. You can also save your files to a memory card. The advantage of using a memory card is that you can free up space on your phone’s memory.

Images

My images contains a list of pictures including default images pre-loaded onto your phone, images downloaded by you and images taken on your phone’s camera.

My images option menus

The options available to you in My images depend on what type of

image you have selected. All of the options will be available for pictures you have taken on the phone’s camera, but only the Use as, Sort

by Grid (List) view and Memory manager options are available for

default images.

Send - Send the image to a friend.

Use as - Set the image to appear on

your phone at certain times.

Move - Move an image from the phone memory to a memory card or vice versa.

Copy - Copy an image from the phone memory to a memory card or vice versa.

Delete - Delete an image.

Mark/Unmark - Select multiple files.

Print - Print an image via PictBridge or

Bluetooth®.

File - Change the name or view the information for the file.

Slide show - Start a slide show.

Sort by - Sort images into a specified

order.

Grid view/ List view - View each image in grid or list type.

Memory manager - View the memory status.

Sending a photo

1 Select My stuff then choose My

images.

2 Select the photo you want to send

and press Options.

Get creative

Multimedia

3 Select Send and choose from

Message, Email, Bluetooth or Blog.

4 If you choose Message or Email,

your photo will be attached to the message and you can write and send the message as normal. If you choose Bluetooth, you will be prompted to turn Bluetooth on and your phone will search for a device to send the picture to.

Using an image

You can choose images to use as wallpapers and screensavers or even to identify a caller.

1 Select My stuff then My Images.

2 Select the image and touch

Options.

3 Select Use as and choose from:

Wallpaper - Set a wallpaper for the

standby screen.

Contacts image - Allocate an image to a particular person in your

Get creative

contacts list so that the picture shows when they call you.

Start up image - Set an image to appear when you switch the phone on.

LG KF757 | User Guide

Shut down image - Set an image to appear when you switch the phone off.

Organising your images

1 Select My stuff, then My images.

2 Select Options, then Sort by.

3 Choose from Date, Type or Name.

Deleting an image

1 Select My stuff, then My images.

2 Select the image you want to delete

and choose Options.

3 Select Delete, then Yes to confirm.

TIP! To quickly delete any

le in My les, highlight it with the cursor and press the key.

Moving or copying an image

You can move or copy an image between the phone memory and the memory card. You might want to do this to either free up some space in one of the memory banks or to safeguard your images from being lost.

1 Select My stuff then My images.

2 Select an image and select Options.

3 Select Move or Copy.

Editing an image

You can edit the image using the

Options menu.

1 Select Multimedia menu.

2 Select Media editor.

3 Select Image editor and choose

from several options. See page 44 for details.

Marking and unmarking images

If you want to move, copy, send or delete several images at once, you first need to identify them by marking them with a tick.

1 Select My stuff then My images.

2 Select Options then Mark/Unmark.

3 A box will appear to the left of each

image. If you select an image, a tick will appear in the box marking it.

4 To unmark an image, select the

image again so that the tick disappears from the box.

5 Once you have marked all of the

appropriate images, choose one of the options to apply to all of them.

Checking your memory status

You can check to see how much of your memory you have used and how much you have remaining.

1 Select My stuff, then My images.

2 Select Options, then Memory

manager.

3 Choose Handset memory or

External memory.

NOTE: If you do not have a memory

card inserted, you will not be able to select External memory.

Sounds

The My sounds folder contains the Default sounds and Voice recordings. From here you can manage, send or set sounds as ringtones.

Using a sound

1 Select My stuff, then My sounds.

2 Select Default sounds or Voice

recordings.

Get creative

Multimedia

3 Select a sound and press Play to

listen to it.

4 Select Options and Use as.

5 Choose from Voice ringtone, Video

ringtone, Message tone, Start-up sound and Shut down sound.

Videos

The My videos folder shows the list of downloaded videos and videos you have recorded on your phone.

Watching a video

1 Select My stuff then My videos.

2 Select a video and press Play.

Using options while video is paused

Select Options while in pause mode and choose from:

Landscape view - View the video file in full shot.

Mute/ Unmute - Switch the sound on/off.

Get creative

Capture - Capture the frozen frame as a picture.

Repeat - Repeat the video file.

File info. - View brief details about

the file.

LG KF757 | User Guide

Send - Send the video in a message, email or via Bluetooth.

Delete - Delete the video.

Use as - Use as a voice/video

ringtone.

Sending a video clip

1 Select a video and press Options.

2 Select Send and choose from

Message, Email or Bluetooth, You Tube.

3 If you choose Message or Email,

your video clip will be attached to the message and you can write and send the message as normal. If you choose Bluetooth, you will be prompted to turn Bluetooth on and your phone will search for a device to send the video to.

Using a video clip as a ringtone

1 Select a video and select Options .

2 Select Use as and choose from

Voice ringtone or Video ringtone.

Using the video options menu

From the My videos folder, you can choose from the following options:

Send - Send a video to a friend.

Use as - Set a video as your ringtone.

Move - Move a video clip from the

phone memory to a memory card or vice versa.

Copy - Copy a video clip from the phone memory to a memory card or vice versa.

Delete - Delete a video.

Mark/Unmark - Select multiple files.

File - Edit the file name and view its

information.

Create new folder - Create a new folder within the My videos folder.

Sort by - Sort videos into a specific order.

Grid view/ List view - View the options menu by grid or list type.

Memory manager - View the memory status.

Games and Applications

You can download games and applications to your phone to keep you amused when you have time to spare.

M-Toy menu

You can enjoy six default games:

Dart, Homerun Derby, Magic Ball,

Hammer, Maze and Fishing.

About - View the information for a

game.

Setting - Set the sound and vibration when activating a game.

Reset data - Reset all settings.

Exit - Leave the M-Toy menu.

Downloading a game or an application

1 Select Download games /

applications and press Connect.

2 You will connect to the web portal

from where you can find a game to download.

Playing a game

1 Select Games menu.

2 Select a game and touch Launch.

Using the games options menu

From the Games and Applications folders, the following options are available:

Create new folder – Create a folder within the games and applications menu.

Sort by - Sort the games and applications by Date, Size or Name.

Get creative

Multimedia

Memory manager - View the memory status.

TIP! You can also access

these games using the touch screen. Press and hold the touch screen button on the righthand side of the phone and touch the M-Toy icon.

Flash contents

The Flash contents folder contains all of your default and downloaded flash contents.

Viewing an SWF/SVG file

1 Select My Files, then Flash

contents.

2 Select the file and press Play.

Using options viewing the SWF/ SVG file

Select Options while in pause mode and choose from:

Play/Pause - Pause or resume

Get creative

playback.

Full screen/ Landscape view - View your SWF/SVG in full screen or landscape view mode (this only appears if you select Options without

LG KF757 | User Guide

pausing).

Mute/Unmute - Switch the sound on/off.

Use as wallpaper - Set the SWF/SVG file as a wallpaper.

File info. - View brief details about the file.

Documents

From the Documents menu, you can view Excel, Powerpoint, Word, text and pdf files.

Transferring a file to your phone

Bluetooth is probably the easiest way to transfer a file from your computer to your phone. You can also use LG PC Suite via your sync cable. See page 64 for details.

To transfer using Bluetooth:

1 Make sure your phone and

computer have Bluetooth switched on and are visible to one another.

2 Use your computer to send the file

via Bluetooth.

3 When the file is sent, you will have

to accept it on your phone by selecting OK.

4 The file should appear in your

Documents or Others folder.

Viewing a file

1 Select My stuff, then Documents.

2 Select a document and choose

View.

Others

The Others folder is used to store files which are not pictures, sounds, videos, games or applications. It is used in the same way as the Documents folder. You may find that when you transfer files from your computer to your phone that they appear in the Others folder rather than the Documents folder. If this happens, you can move them.

To move a file from Others to Documents:

1 Select My Files then Others.

2 Select a file and choose Options.

3 Select Move.

Movie maker

The Movie maker allows you to create an image slide show combined with music.

Creating a movie

1 Go to Entertainment and select

Movie maker.

2 Select to add an image. Choose

the images you want to include then select Done in Options.

3 Select Style menu to choose a

movie style.

4 Select Play to see what you’ve

created.

Music

Your LG KF757 has a built-in music player so you can play all your favourite tracks. To access the music player, select Music from the Multimedia menu. From here you can access a number of folders:

Recently played - View all of the songs you have played recently.

Get creative

Multimedia

All tracks - Contains all of the songs you have on your phone.

Artists - Browse through your music collection by artist.

Albums - Browse through your music collection by album.

Genres - Browse through your music collection by genre.

Playlists - Contains any playlists you have created.

Shuffle tracks - Listen to your music in a random order.

Playing a song

1 Select My music, then All tracks.

2 Select the song you want to play

and choose Play.

3 Press to pause the song.

4 Touch (right) to skip to the

next song.

5 Touch (left) to skip to the

previous song.

Get creative

LG KF757 | User Guide

Using options while playing music

Select Options and choose from:

Minimise - Make the music player

screen disappear so that you can continue using your phone as normal.

Go to my music - Move the file to the My music folder.

Repeat - Repeat the selected track.

Shuffle - Listen to your music in a

random order.

Equaliser - Set the equaliser menu.

Visualisation - Select the visual

effects.

Add to playlist - Add the file to a playlist.

File info. - View brief details about the file.

Send - Send the song as a message or via Bluetooth.

Delete - Delete the song.

Use as - Use the song as one of your

ringtones.

Creating a playlist

You can create your own playlists by choosing a selection of songs from the

All tracks folder.

1 Select My music, then Playlists.

2 Select Add, enter the playlist name

and press Save.

3 The All tracks folder will be

displayed. Select all of the songs that you would like to include in your playlist; a tick will show next to the file name.

To play a playlist, select it and choose

Play.

NOTE: To add a second playlist, select Options then Add new playlist.

Editing a playlist

From time to time, you may want to add new songs or delete songs from a playlist.

1 Select My music, then Playlists.

2 Select the playlist.

3 Select Options.

Add new songs – Add more songs to

the playlist. Mark the ones you want and select Done.

File info. - View the Name, Size, Date,Time, Type, Duration, Protection and Copyright of the song.

Move up/down – Move the song up or down the list to change the playing order.

Send – Send a song as a message or via Bluetooth.

Remove from list – Remove a song from the playlist.

Mark/Unmark – Select multiple files.

Use as – You can set the song as an

effect sound.

Memory manager - You can view the current status of memory.

Deleting a playlist

1 Select My music, then Playlists.

2 Select Options then Delete or

Delete all to delete all of the

playlists.

Using the radio

Your LG KF757 has an FM radio feature so you can tune into your favourite stations to listen to on the move.

NOTE: You need to insert your headphones to listen to the radio. Insert them into the same socket as your charger.

Get creative

Multimedia

Searching for stations

You can tune radio stations by searching for them either manually or automatically. They will be saved to specific channel numbers so you don’t have to keep re-tuning. You can save up to 50 channels in your phone.

To auto tune:

1 From Music select FM radio then

Options.

2 Select Auto scan. The stations

found will automatically be allocated to a channel number.

TIP! You can access music

using the touch screen. Press and hold the touch screen button on the right-hand side of the phone and choose the FM Radio or Music icon. You can then scroll though and select your music files or the radio functions by touching the screen.

To manually tune:

Get creative

1 Select FM radio then Options.

2 Select Channel list and choose the

channel number you want to save the station to.

LG KF757 | User Guide

3 Enter the station frequency and

touch Select to save.

NOTE: You can also manually tune

into a station by using (left) and

(right) displayed next to the radio

frequency.

Editing the channels

You may want to move the stations to another channel so that the ones you listen to most frequently are easier to access.

1 Select FM radio then Options.

2 Select Channel list and select the

channel you want to change.

3 Either select a station from one of

the other channels, or manually tune the channel into the frequency you want.

You can edit each channel by highlighting it and touching Options:

Rename - Rename the channel.

Replace - Set new frequency for the

selected channel.

Resetting channels

1 Select FM radio, then Options.

2 Select Channel list, then Options.

3 Choose Reset channel to reset the

current channel or choose Reset all channels to reset all of the

channels. Each channel will return to the starting 87.5Mhz frequency.

TIP! To improve the radio

reception, extend the headset cord, which functions as the radio antenna.

Listening to the radio

Select FM radio, then enter the channel number of the station you would like to listen to.

Using voice recorder

Use your voice recorder to record voice memos or other sounds.

1 Select Multimedia.

2 Select Voice recorder then options

and choose from:

Duration – Set the recording duration.

Choose from MMS msg. size, 30

secs, 1 min or No limit.

Quality – Select the sound quality.

Choose from Super Fine, Fine or Normal.

Memory in use - Check the current

status of each memory.

Go to Voice recordings – Open the Voice recordings folder in My

sounds.

3 Select Rec. to begin recording.

4 Select Stop to end recording.

5 Select Play in the options menu to

listen to your recording.

Sending the voice recording

1 Once you have finished recording,

select options.

2 Select Send and choose from

Message, Email or Bluetooth. If

you choose Message or Email, the recording will be added to the message and you can write and send it as normal. If you choose Bluetooth, you will be prompted to turn Bluetooth on.

NOTE: After you have finished recording, select Options and choose Play, Send, File, Delete, Use as (to use the recording as your ringtone) or

Go to Voice recordings.

Get creative

Organiser

Adding an event to your calendar

1 From the standby screen, press

and choose Organiser.

Select Calendar.

2 Select the date you would like to

add an event to.

3 Select Options then Add new

event.

4 Select whether you would like to

add an Appointment, Anniversary or Birthday and select Done.

5 Check the date and enter the time

you would like your event to begin.

6 For appointments and anniversaries

enter the time and date your event finishes in the lower time and date boxes.

7 If you would like to add a subject or

a note to your event, touch Subject or Name and type in your note.

8 Select Done and your event will be

saved in the calendar. A cursor will

Get organised

mark the day that any events have been saved to and a bell will ring at the start time of your event, so that you can stay organised.

LG KF757 | User Guide

TIP! You can set a holiday

in your calendar. Select each day you are on holiday one at a time, then choose Options and select Set holiday. Each day will be shaded red. When you come to set an alarm, you can choose to exclude days set as holidays.

Changing your default calendar view

1 From the standby screen press

and choose Organiser.

Select Settings.

2 Select Calendar and choose either

Month view or Week view.

3 Press Done to confirm your choice.

Adding an item to your to do list

1 From the standby screen press

and choose Organiser.

2 Select To do and select Add.

3 Set the date for the to do item, add

notes and select a priority level:

High, Medium or Low.

4 Save your to do list item by

selecting Done.

TIP! You can edit an item

by selecting it, touching Options and Edit. Corm your amends by selecting Save.

Sharing a to do item

1 From the standby screen press

and choose Organiser.

Select To do.

2 Select the to do item you would like

to share, then select Options.

3 Select Send. You can choose to

share your to do item by Text message, Multimedia msg, Email or Bluetooth.

TIP! You can back up and

synchronise your calendar with your computer. See PC Sync on page 64.

Adding a memo

1 From the standby screen press

and choose Organiser

- Memo.

2 Select Add. 3 Type your memo, followed by Save. 4 Your memo will appear on screen

next time you open the Memo application.

TIP! You can edit an existing

memo. Select the one you want to edit and select Edit.

Get organised

Tools

Setting your alarm

1 From the standby screen press

and choose Tools then

Alarms.

2 Select Options and touch Add new. 3 Set the time you would like the

alarm to sound.

4 Choose whether you would like

your alarm to sound Once, Daily, Mon - Fri, Mon - Sat, Sat - Sun or Except holiday.

5 Select and Edit to select a

sound for your alarm. To listen to sounds select the sound, and touch

Play.

6 Add a memo for the alarm and

select Done when you have finished typing. When the alarm sounds the memo will be displayed.

7 Finally, you can set the snooze

interval at 5, 10, 20 or 30 mins, 1 hour or off.

8 Once you have set your alarm,

select Done.

Get organised

NOTE: You can set up to 5 alarms.

The alarm will be alerted on even if the phone is switched off.

LG KF757 | User Guide

Using your calculator

1 From the standby screen, press

and choose Tools. Select

Calculator.

2 Select the numeric keys to input

numbers.

3 For simple calculations, select the

function you require (+, –, x, ÷), followed by =.

4 For more complex calculations,

select Options and choose from +/–, sin, cos, tan, log, ln, exp, sqrt, deg or rad.

Using the stopwatch

1 From the standby screen, press

and choose Tools. Select

Stopwatch.

2 Select Start to begin the timer. 3 Select Stop to stop the timer. 4 Select Lap to measure each lap

time.

5 To restart stopwatch, select

Resume.

6 Select Reset to return to zero.

Converting a unit

1 From the standby screen, press

and choose Tools. Select

Converter.

2 Choose whether you would like to

convert Currency, Surface, Length, Weight, Temperature, Volume or Velocity.

3 You can now select the unit and

enter the value you would like to convert from, followed by the unit you would like to convert to.

4 The corresponding value will appear

on the screen.

Adding a city to your world time

1 From the standby screen, press

and choose Tools. Select

World time.

2 Select Options, followed by Add

city. Start typing the name of the

city you require and it will show at the top of the screen. Alternatively choose Map, and select your chosen city from the map.

3 Press Select to confirm your choice.

TIP! If you are abroad, you

can change your time zone from World time by selecting Options, followed by Change current city. Choose your required city as above.

Get organised

PC Sync

You can synchronise your PC with your phone to make sure all your important details and dates match, and also as a backup to put your mind at ease.

Installing LG PC Suite on your computer

1 From the standby screen press

and choose Connectivity.

2 Select USB connection mode and

click OK.

Music - Music Sync mode.

Others - Data Service mode.

3 Insert the supplied CD into your PC.

Click on the LG PC Suite Installer which will appear on your screen.

4 Select the language you would like

the installer to run in and click OK.

5 Follow the instructions on the

screen to complete the LG PC Suite Installer wizard.

6 Once installation is complete, the

LG PC Suite icon will appear on

Get organised

your desktop.

LG KF757 | User Guide

Connecting your phone and PC

1 Connect the USB cable to your

phone and your PC.

2 Double click on the LG PC Suite

Icon on your desktop.

3 Click on Connection Wizard and

USB.

4 Click on Next, then Next again, and

Finish. Your phone and PC are now

connected.

Backing up and restoring your phone’s information

1 Connect your phone to your PC as

outlined above.

2 Click on the Backup icon, and select

Backup or Restore.

3 Mark the contents you would

like to back up or restore. Select

the location you would like to

backup information to, or restore

information from. Click OK.

4 Your information will be backed up.

Viewing your phone files on your PC

1 Connect your phone to your PC as

outlined above.

2 Click on the Contents icon.

3 All of the documents, flash contents,

images, sounds and videos you have saved onto your phone will be displayed on the screen in the LG Phone folder.

TIP! Viewing the contents

of your phone on your PC helps you to arrange les, organise documents and remove contents you no longer need.

Synchronising your contacts

1 Connect your phone to your PC.

2 Click on the Contacts icon.

3 Select Transfer, then Import from

mobile handset. Your PC will now

import and display all contacts saved to your USIM card and handset.

4 Click on File and select Save. You

can now select where you would like to save your contacts to.

NOTE: To backup contacts saved to your USIM card, click on the SIM card folder on your PC screen. Select Edit at the top of the screen, then Select all. Right-click your contacts and select

Copy to contacts. Now click on the Handset folder on the left of your

screen and all your numbers will be displayed.

Synchronising your messages

1 Connect your phone to your PC.

2 Click on the Messages icon.

3 All of your PC and phone messages

will be displayed in folders on your screen.

4 Use the tool bar at the top of

your screen to edit and rearrange messages.

Synchronising your music

1 Connect your phone to your PC.

2 Click on the Music icon.

3 The music files you have saved will

be displayed on the screen in the Music folder.

Get organised

PC Sync

NOTE: The following conditions must be met.

· Windows XP Service Pack 2 or higher.

· Windows Media Player 11 or higher.

· USB Connection mode should be

active and Music Sync mode should be on.

Using your phone as a mass storage device

Your phone can only be used as a mass storage device if you have a memory card inserted.

1 Disconnect your phone from your

PC.

2 From the standby screen, press

3 Select Connectivity, then USB

connection mode.

4 Highlight Mass storage and press

Select.

5 Connect your phone to your PC.

Your phone will read: Connecting

Get organised

as Mass Storage… followed by Connected as Mass Storage Mode.

Do not disconnect during transfer.

LG KF757 | User Guide

6 All of your phone files will

automatically be stored onto your

PC hard drive.

NOTE: Your phone must be unplugged from your PC to initiate Mass Storage.

NOTE: Mass storage backs up content saved on your memory card only, not your handset memory. To transfer the contents of your handset memory (e.g. contacts) you’ll need to synchronise using PC Sync.

PIN for DivX connection

Install the DivX converter which is supplied on the same CD as the PC Sync software.

Once installed select DivX from the Program Files on your PC, then DivX converter followed by Converter.

This will open the Converter application. Use the arrows in the application to change the conversion format to Mobile. If you right-click on the application box and select Preferences, you can change the location that the converted files are saved in.

Once you are ready to convert your files, simply drag and drop the files into the application. You will need then to select Convert for the process to begin. When the process is finished a “Conversion complete“ pop up will be displayed. The converted file can now be transferred to your phone using the Mass Storage functionality (see page 66 for details) or uploaded using the PC Sync software (see page 64 for details).

Get organised

Browser

With a browser at the tip of your fingers, you can get up-to-date news and weather forecasts as well as information on sports or traffic whenever you need it. In addition, the browser allows you to download the latest music, ringtones, wallpapers and games.

Accessing the web

1 From the standby screen, press

and choose Browser.

2 To access the browser homepage

directly, select Home. Alternatively, select Enter address and type in your desired URL, followed by Open.

NOTE: An additional cost is incurred when connecting to this service and downloading content. Check your data charges with your network provider.

The web

LG KF757 | User Guide

Adding and accessing your bookmarks

For easy and fast access to your favourite websites, you can add bookmarks and save web pages.

1 From the standby screen press

and choose Browser.

2 Select Bookmarks. A list of your

Bookmarks will appear on the

screen.

3 To create a new folder, select

Options and choose Create new

folder. Enter the name of your

bookmark folder.

4 To add a new bookmark, select

Options and touch Add new. Enter

a name for your bookmark followed

by the URL.

5 Select Done. Your bookmark will be

displayed in the list of bookmarks.

6 To access the bookmark, simply

scroll to it and select Open.

Saving a page

1 Access your required webpage as

described above.

2 Select Options, Save items, then

Save this page.

3 Enter a name for the webpage so

you can easily recognise it.

4 Select Save.

TIP! This menu will also

allow you to edit titles of saved pages, protect or unprotect the screen memo, and delete saved pages.

Accessing a saved page

1 From the standby screen press

and choose Browser.

2 Select Saved pages.

3 Select Open to connect to the

saved page.

Viewing your browser history

1 From the standby screen press

and choose Browser, and

then select History.

2 Visual history will be displayed.

Select Options and select List history, to show a list of web page titles you have accessed recently.

3 To access one of these pages, simply

select the required page and touch Open.

Using RSS reader

RSS (Really Simple Syndication) is a family of web feed formats used to publish frequently updated content such as blog entries, news headlines or podcasts. An RSS document, which is called a feed, web feed, or channel, contains either a summary of content from an associated web site or the full text.

RSS makes it possible for people to keep up with their favorite web sites in an automated manner that is easier than checking them manually.

The web

Browser

The user subscribes to a feed by entering the feed’s link into the reader or by clicking an RSS icon in a browser that initiates the subscription process. The reader checks the user’s subscribed feeds regularly for new content, downloading any updates that it finds.

Adding the Feed

You can input the feed directly yourself: Browser ➝ RSS reader ➝ Options ➝ Add new or you can click the feed link by selecting the RSS icon in the webpage.

Updating the RSS reader

1 You can select Update or Update

all Options.

2 If you want to update it

automatically, select Update schedule.

The web

LG KF757 | User Guide

Changing the web browser settings

1 From the standby screen press

and choose Browser. Select

Settings.

2 You can choose to edit Profiles,

Appearance settings, Cache,

Cookies, Security, or Reset

Settings.

3 Once you have changed your

settings, touch Select.

The web

Using your phone as a modem

Your KF757 can double as a modem for your PC, giving you email and internet access even when you can’t connect using wires. You can use either the USB cable or Bluetooth.

Using the USB cable:

1 Ensure you have LG PC Suite

installed on your PC.

2 Connect your KF757 and your PC

using the USB cable and launch the LG PC Suite software.

3 Click Communication on your

PC. Then click Settings and select

Modem.

4 Choose LG Mobile USB Modem

and select OK. It will now appear on screen.

5 Click Connect and your PC will

connect through your KF757.

NOTE: For more information on synchronising using LG PC Suite see page 64.

Using Bluetooth

1 Ensure Bluetooth is switched On

and Visible for both your PC and KF757.

2 Pair your PC and KF757 so that a

passcode is required for connection.

3 Use the Connection wizard on

your LG PC Suite to create an active Bluetooth connection.

4 Click Communication on your PC.

Then click Settings.

5 Click Modem.

6 Choose Standard Modem over

Bluetooth link and click OK. It will

now appear on screen.

7 Click Connect and your PC will

connect through your KF757.

The web

Sending and receiving your files using Bluetooth

Bluetooth is a great way to send and receive files as no wires are needed and connection is quick and easy. You can also connect to a Bluetooth headset to make and receive calls.

To send a file:

1 Open the file you want to send. 2 Select Options and choose Send.

Choose Bluetooth.

3 Select Yes to turn Bluetooth on. 4 Your KF757 will automatically search

for other Bluetooth enabled devices

within range.

5 Choose the device you want to send

the file to and choose Select to

send the file.

6 Your file will be sent.

TIP! Keep an eye on the progress

bar to make sure your le is sent.

To receive a file:

1 To receive files, your Bluetooth

must be both On and Visible. See

The web

Changing your Bluetooth settings

below for more information.

LG KF757 | User Guide

2 A message will prompt you to

accept the file from the sender. Select Yes to receive the file.

3 You will see where the file has been

saved and you can choose to View the file. Files will usually be saved to the relevant folder in My Files.

Changing your Bluebooth settings:

1 Press in the standby screen,

and choose Connectivity.

2 Choose Bluetooth then Settings.

Make your changes to:

My device visibility - Choose to be Visible, Visible for 1 min or Hidden.

My device name - Enter a name for your KF757.

Supported services - Search for the profile supported by KF757. See Using your phone as a modem on page 71 or Using a Bluetooth

headset on page 73.

My address - Search your Bluetooth

device address.

Pairing with another Bluetooth device

By pairing your KF757 and another device, you can set up a passcodeprotected connection. This means your pairing is more secure.

1 Check your Bluetooth is On and

Visible. You can change your visibility in the Settings menu.

2 Select Paired devices, Options,

then Add new device.

3 Your KF757 will search for devices. If

devices are found, Refresh and Add will appear on screen.

4 Choose the device you want to pair

with and enter a passcode then press Add.

5 Your phone will then connect to the

other device, on which you should enter the same passcode.

6 Your passcode-protected Bluetooth

connection is now ready.

Using a Bluetooth headset

1 Check your Bluetooth is On and

Visible.

2 Follow the instructions that came

with your headset to place your headset in pairing mode and pair your devices.

3 Select Yes to Connect now. Your

KF757 will automatically switch to Headset profile.

The web

Settings

Within this folder you can adapt your settings to personalise your KF757.

NOTE: For information on call settings see page 21.

Changing your screen settings

1 From the standby screen, press

and select Settings.

2 Select Screen and then choose

from:

Screen theme - Choose the theme

for your standby screen or start-up,

shut down the phone.

Menu style - Choose the style used

to display menus.

Dialling - Set the display used

when making a call.

Font - Adjust the font.

Backlight - Choose how long the

backlight remains on for.

NOTE: The longer the backlight is on for, the more battery power is used and you may need to charge your phone more often.

Image quality enhancement -

Settings

Choosed the menu to enhance the quality of the selected image.

LG KF757 | User Guide

Handset theme - Quickly change the whole look of your screen.

Greeting message- Enter the greeting message used when the phone is switched on.

3 Choose Select to save your settings.

Personalising your profiles

You can quickly change your profile on the standby screen. Simply touch the currently active profile icon.

Using the settings menu you can personalise each profile setting.

1 From the standby screen, press

and select Settings.

2 Select Profiles and then choose the

profile you want to edit. You cannot edit the Silent profile.

3 Select Options and choose Edit.

4 You can then change all of the

sounds and alert options available in the list, including your Ring tone and Volume, Message alerts and more.

Changing your phone settings

Enjoy the freedom of adapting your KF757 so that it works in a way that suits you.

1 From the standby screen, press

2 Select Settings, then Phone, and

choose from the list below.

Auto key lock - Lock the keypad automatically in the standby screen.

Touchpad - Turn the touchpad vibration On or Off.

Touchscreen effect - Set the effect tone used when touching the screen.

Languages - Change the language of for your KF757’s display.

Power save - Choose to switch the power saving settings On or Off.

Information - View the technical information for your KF757.

Using Date & Time

Date & Time - Adjust your date and time settings or choose to automatically update the time when you travel or for daylight saving.

Changing your other settings

Your connectivity settings have already been set up by your network operator, so you can enjoy your new phone immediately. If you want to change any settings, use this menu.

Network - Your KF757 connects automatically to your preferred network. To change these settings, use this menu.

Internet profiles - Set the profiles to connect to the internet.

Access points - Your network operator has already saved this information. You can add new access points using this menu.

Packet data conn - Set the packet data connection.

Settings

Changing security settings

PIN code request- Set the phone to ask for the PIN code of your SIM card when switching on the phone.

Handset lock - Set the phone lock to avoid unauthorised use. You will need a security code.

Change codes - Change the codes: PIN/ PIN2/ Security code.

Using memory manager

Your KF757 has three memories available: the phone, the USIM Card and an external memory card (you may need to purchase the memory card separately).

You can use memory manager to determine how each memory is used and see how much space is available.

Press in standby screen. Select

Settings then Memory Manager.

Handset Common memory - View

the memory available on your KF757 for images, sounds, videos, flash, MMS, applications, java and others.

Settings

LG KF757 | User Guide

Handset reserved memory - View the memory available on your handset for SMS, contacts, calendar items, to do list, memos, alarms, call history, bookmarks and miscellaneous items.

USIM memory - View the memory available on your USIM Card.

External memory - View the memory available on your external memory card (you may need to purchase the memory card separately).

Primary storage setting - choose Handset memory or External memory.

TIP! See page 12 for information

on Installing a memory card.

Using flight mode

Turn on flight mode by pressing

in standby screen, and then select Settings and Profiles. Select Flight mode and press to activate. Flight mode will not allow you to make calls, connect to the internet, send messages or use Bluetooth.

Accessories

These accessories were supplied with KF757.

Charger USB cable and

Battery User Guide

Stereo headset

Connect and synchronise your KF757 and PC.

Learn more about your KF757.

NOTE:

• Always use genuine LG accessories.

• Failure to do this may invalidate

your warranty.

• Accessories may be different in

different regions; please check with our regional service company or agent for further inquires.

KF757 User Guide

Accessories

Network service Technical data

The wireless phone described in this guide is approved for use on the GSM 900, DCS 1800, PCS1900 and W-CDMA network.

A number of features included in this guide are called Network Services. These are special services that you arrange through your wireless service provider. Before you can take advantage of any of these Network Services, you must subscribe to them through your service provider and obtain instructions for their use from your service provider.

Network service

LG KF757 | User Guide

General

Product name : KF757

System : GSM 900 / DCS 1800 / PCS 1900 / W-CDMA

Ambient Temperatures

Max : +55°C (discharging), +45°C (charging)

Min : -10°C

LG Electronics USA KF757 Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
