MUSIC LIST

USB

You can use the Music List menu to play MP3 files form a USB storage device. This TV cannot play back copy-protected files. The On Screen Display on your model may be slightly different.

Screen Components

Supported music file: *.MP3

Bit rate range 8Kbps ~ 320Kbps

• Sampling rate (Sampling Frequency) MPEG1 : 32000, 44100, 48000Hz MPEG2 : 16000, 24000, 22050Hz MPEG2.5 : 8000, 12000, 11025Hz

Moves to upper level folder

Preview: If any album jacket for the file exists, this jacket is displayed.

Current page/Total pages

Total number of marked musics

Corresponding buttons on the remote control

Select

USB

Select

Musi c List

ENTER

Music List

Up Folder

Title Duration

3 4

Page 2/3

No Marked

Drive1

Navigation Popup Menu Page Change Mark Exit

MARK

00:00 / 04:16

Up Folder

USB

Music Selection and Popup Menu

■

Use the

button to navigation in

the music page.

■

Use

MARK

button to mark or unmark a music file. If no music is marked, all the music in the folder will be played in sequence. When one or more music files are marked, the marked music files will be played in sequence. If you want to listen to only one song repeatedly, just mark that one file and play.

Select the target folder or drive.

Select the desired musics.

Show the Popup menu.

Select the desired Popup menu.

ENTER

RETURN

Return to TV viewing.

Navigation Page Change Mark Exit

MARK

Popup Menu

Navigation Page Change Mark Exit

MARK

Popup Menu

Page 2/3

No Marked

Music List

Up Folder

00:00 / 04:16

Up Folder

Drive1

Title

Duration

Page 2/3

No Marked

Music List

Up Folder

00:00 / 04:16

Up Folder

Drive1

Title

Duration

3945 KB 128 Kbps

Play

Play with Photo

Mark All

Delete

Play

(During stop): Play the selected music.

Once a song finishes playing, the next selected one will be played. When there are no selected musics to play, the next one in the current folder will be played. If you go to a different folder and press the

ENTER

button, the current

music in playback will stop.

Play Marke d

: Play the selected musics. Once a music finishes playing, the next selected one will be played automatically.

Stop Play

(During playback): Stop the play-

ing musics.

Pla y with Photo

: Start playing the selected

musics and then move to the Photo List.

Mark A ll

: Mark all musics in the folder.

Unma rk All

: Deselect all marked music.

Dele t e

: Delete the selected music.

: Close the pop-up menu.

USB

■

The play information box (as shown below) will automatically move across the screen when there is no user input to prevent a fixed image remaining on the screen for a extended period of time.

NOTE

When music is playing, is displayed in front of the music play time.

A damaged or corrupted music file that does not play displays 00:00 as the play time.

Music files with copy-protection will not play.

Press

ENTER

, A, or

RETU R N

button to stop the screen saver.

MOVIE LIST

USB

The movie list is activated once USB is detected. It is used when playing movie files on TV. Displays the movies in the USB folder and supports play. Allows playback of all movies in the folder and user desired files. Editing such as delete and add is not allowed. It is a movie list that displays folder information and Divx file.

NOTE

A video file name and its subtitle file name must be identical for it to be displayed.

Use the button to move to a specific frame forward or backward while playing a movie.

( button may not work properly for some files while playing a movie.)

Screen Components

Moves to upper level folder

Current page/Total pages

Total number of marked movie

Corresponding buttons on the remote control

Select

USB

Select

Movie List

ENTER

Movie List

Up Folder

Title Duration

2 3

Page 1/2

No Marked

Drive1

Navigation Popup Menu Page Change Mark Exit

MARK

640x480, 707MB

Up Folder

KR1

KR2

SJS001

SJS002

SJS003

00:00:00

SJS001

USB

DAT, MPG, MPEG

mpg

VOB

mp4

MKV

divx, avi

DAT, MPG, MPEG, DVD

MPEG-1

MPEG2 -PS

AVI, MP4

MKV

AVI(1.0, 2.0),

DMF0,1,2

Mpeg1,2

MPEG-1

Mpeg1, 2

MPEG4

Divx 3.11, Divx 4.12, Divx

5.x, Divx 6, Xvid 1.00,

Xvid 1.01, Xvid 1.02, Xvid

1.03, Xvid 1.10-beta1/2

MPEG-1,2,4

MPEG2, MPEG4

Divx 3.11, Divx 4.Divx 5,

Divx 6, Xvid 1.00,

Xvid 1.01, Xvid 1.02, Xvid

1.03, Xvid 1.10-beta1/2

720X480@30P

800x432@30P

720X480@30P

800x432@30P

Microsoft MPEG4-v2, v3 is not supported.

WMV serise is not supported.

Spec resolution means up to max supporting resolution.

File Extension Container Video Codec Spec Note

MP3

AC3

MPEG

LPCM

MP3

AC3

MPA

32kbps - 320kbps (Bit rate), 32kHz -48kHz (Sample rate)

32kbps - 640kbps (Bit rate), 32kHz, 44.1kHz, 48kHz (Sample rate)

32kbps - 448kbps (Bit rate), 32kHz - 48kHz (Sample rate)

64Kbps - 1.5Mbps (Bit rate), 8KHz - 48KHz (Sample rate)

Audio Codec

a. Pause & Resume b. Fast forward (2x, 4x, 8x, 16x, 32x) c. Fast backward (2x, 4x, 8x, 16x, 32x)

Trick play

USB

Movie Selection and Popup Menu

00:00:00

01:19:24

Option

Page 1/2 No Marked

Movie List

Up Folder

640x480, 707MB

Up Folder

Title

Duration

KR1

KR2

SJS001

SJS002

SJS003

SJS001

Drive1

■

Use the

button to navigation in

the movie page.

■

Use

MARK

button to mark or unmark a movie file. When one or more movie files are marked, the marked movie files will be played in sequence. If you want to see only one movie repeatedly, just mark that one file and play.

Select the target folder or drive.

Select the desired movies.

Show the Popup menu.

Select the desired Popup menu.

ENTER

RETURN

Return to the previous menu.

Page 1/2 No Marked

Movie List

Up Folder

640x480, 707MB

Up Folder

Title

Duration

KR1

KR2

SJS001

SJS002

SJS003

00:00:00

SJS001

Drive1

624x352, 699MB

Play

Mark All

Delete

00:00:00

Play

(During stop): Play the selected movie

titles.

If you go to a different folder and press the ENTER

button, the current movie in playback

will stop.

Play Mar ked

: Play the selected movie titles. Once a movie finishes playing, the next selected one will be played automatically.

Stop Play

(During playback): Stop the play-

ing movies.

Mark A ll

: Mark all movies in the folder.

Unma rk All

: Deselect all marked movies.

Dele t e

: Delete the selected movie.

: Close the pop-up menu.

■

FF /GG

: Increases the fast forward/reverse

speed.

■

I I

: Displayed the still screen.

■

: A cursor indicating the position

can be viewed on the screen.

■

: Return to normal playback.

Usi ng the r emot e cont rol

You can adjust various method during movie play.

Navigation Page Change Mark Exit

MARK

Popup Menu

Navigation Page Change Mark Exit

MARK

Popup Menu

USB

DivX Audio Language & Subtitle Language

Press the

RED

button when DivX is playing.

Select the desired option.

RETURN

Return to the previous menu.

Return to TV viewing.

Select

Pic ture Size , Aud io Lan gua ge,

Sub titl e Lan guag e, Sy nc

Pos i tion

Picture Size

Audio Language

Subtitle Language

Sync

Position

Full

Off

DIVX REGISTRATION CODE

USB

Display

DivX Reg. C ode

ENTER

Select

USB

Select

DivX Reg. C ode

ENTER

Confirm the DivX registration code number of the TV. Using the registration number, movies can be rented or purchased at www.divx.com/vod.

With a DivX registration code from other TV, playback of rented or purchased DivX file is not allowed (Only DivX files matched with the registration code of the purchased TV are playable).

• Official DivX®Certified Product

• “Plays all versions of DivX® video (including DivX® 6)with standard playback of DivX®media files”

• DivX®Certified Products: “DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license.”

NOTE

When loading, some buttons may not work.

If you use the DivX registration code of another device, the rented or purchased DivX file cannot be

played. Therefore always use the DivX registration code assigned to this product.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

USB

Photo List

Music List

Movie List

DivX Reg. Code

Deactivation

Enter

Move

USB

Photo List

Music List

Movie List

DivX Reg. Code

Deactivation

DivX(R) Video On Demand

Your registration code is : 2KH52HZ7DU

To learn more visit www.divx.com/vod

DEACTIVATION

USB

Select

USB

Select

Yes

Select

Deac tiva t ion

ENTER

RETURN

Return to the previous menu.

Select

Return to TV viewing.

ENTER

Delete the existing authentication information to receive a new DivX user authentication for TV. Once this function is executed, a DivX user authentication is required again to see DivX DRM files.

DivX(R) Video On Demand This device is deactivated.

Your deactivation code is : D868PBIS

To learn more visit www.divx.com/vod

ENTER

Enter

Move

USB

Photo List

Music List

Movie List

DivX Reg. Code

Deactivation

Enter

Move

USB

Photo List

Music List

Movie List

DivX Reg. Code

Deactivation

Yes

DivX(R) Video On Demand

Do you want to deactivate your device?

PICTURE CONTROL

PICTURE SIZE (ASPECT RATIO) CONTROL

PICTURE CONTROL

This feature lets you choose the way an analog picture with a 4:3 aspect ratio is displayed on your TV.

■

RGB-PC input source use 4:3 or 16:9 aspect ratio.

■

You can also adjust

Aspe ct Rat io

the

Q.ME NU

Select

PICT U RE

Select

Aspe ct Rat io

Select the desired picture format.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Aspect Ratio : 16:9

Picture Wizard

Energy Saving

: Off

Picture Mode : Standard

• Backlight 70

• Contrast 90

• Brightness 50

• Sharpness 70

Enter

Move


Aspect Ratio : 16:9

Picture Wizard

Energy Saving

: Off

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

16:9

Just Scan

Set By Program

4:3

Zoom

Cinema Zoom 1

PICTURE CONTROL

16:9

Adjust the picture horizontally, in a linear proportion to fill the entire screen.

Just Scan

Normally the edges of video signals are cropped 1-2%. Just Scan turns off this cropping and shows the complete video.

Notes: If there is noise on the edges of the original signal, it will be visible when Just Scan is activated.

Just S can

operates only in DTV/CADTV/Component/HDMI-DTV/DVI-DTV (720p/1080i/1080p) input source.

Set By Program

Selects the proper picture proportion to match the source’s image.

4:3

Choose 4:3 when you want to view a picture with an original 4:3 aspect ratio.

Zoom

Choose Zoom when you want to view the picture without any alteration. However, the top and bottom portions of the picture will be cropped.

■

When adjusting in Q.MENU menu, a.

or Gbutton: Adjust proportion of Zoom.

or Ebutton: Move the image on the screen.

Cinema Zoom

Choose Cinema Zoom when you want to enlarge the picture in correct proportion.

Note: When enlarging or reducing the picture, the image may become distorted.

■

or Gbutton: Adjust proportion of Cinema

Zoom. The adjustment range is 1-16.

■

or Ebutton: Move the image on the screen.

JUST SCAN

(4:3 4:3)

(16:9 16:9)

Set By Program

PICTURE CONTROL

PICTURE WIZARD

PICTURE CONTROL

Select

PICT U RE

Select

Pict u re

Wiza r d

ENTER

Adjust

Pict ure Wiz ard

Adjust

Whit e Leve l

ENTER

Adjust

Blac k Leve l

ENTER

Adjust

Color

ENTER

Adjust

Tint

ENTER

Picture Wizard

With Picture Wizard, you can adjust the picture quality of the original image.

Black Level

Set the screen above identical to the Recommended sample below.

NextPrevious

• Brightness 50

Low HighRecommended

Color

Set the screen above identical to the Recommended sample below.

NextPrevious

• Color 50

Low HighRecommended

White Level

Set the screen above identical to the Recommended sample below.

NextPrevious

Low HighRecommended

• Contrast 90

Tint

Set the screen above identical to the Recommended sample below.

NextPrevious

Low HighRecommended

• Tint 0

Enter

Move


Aspect Ratio : 16:9

Picture Wizard

Energy Saving

: Off

Picture Mode : Standard

• Backlight 70

• Contrast 90

• Brightness 50

• Sharpness 70

This feature lets you adjust the picture quality of the original image. Use this to calibrate the screen quality by adjusting the Black and White Level etc. You can calibrate the screen

quality by easily following each step. When you adjust the image to

Low, Reco mmend ed

High

, you can see the example of the changes you

made.

PICTURE CONTROL

Adjust

Hori zonta l

Shar pness

ENTER

Select input source to apply the settings.

FAV

MARK

Adjust

Vert ical

Shar pness

ENTER

Adjust

Back light

ENTER

Finish the Picture Wizard.

ENTER

Save.

ENTER

Complete

ConfirmMovePrevious

Horizontal Sharpness

Set the screen above identical to the Recommended sample below.

NextPrevious

• H Sharpness 50

Low HighRecommended

Vertical Sharpness

Set the screen above identical to the Recommended sample below.

NextPrevious

• V Sharpness 50

Low HighRecommended

Backlight

Set the Backlight to your Brightness preference.

NextPrevious

• Backlight 50

Dark BrightRecommended

DTV

AV1

AV2

Component1

Component2

RGB-PC

HDMI1 HDMI2 HDMI3 HDMI4

Select (an) input(s) to apply the settings.

Warning: The picture quality may vary according to the different types of signal and inputs.

Mark

MARK

■

If you stop the setting before the final step, the changes will not be saved to the TV.

The current adjustment value is saved to Expert1.

PICTURE CONTROL

PRESET PICTURE SETTINGS (PICTURE MODE)

PICTURE CONTROL

There are factory presets for picture settings available in the user menus. You can use a preset, change each setting manually, or use the Intelligent Sensor.

Select

PICT U RE

Select

Pict ure Mo de

Select

Intelligent Sen sor, Viv id

Standa rd, Natura l, Cin ema, Spo rt

Game

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Enter

Move


Aspect Ratio : 16:9

Picture Wizard

Energy Saving

: Off

Picture Mode : Standard

• Backlight 70

• Contrast 90

• Brightness 50

• Sharpness 70

Aspect Ratio : 16:9

Picture Wizard

Energy Saving

: Off

Picture Mode : Standard

• Backlight 70

• Contrast 90

• Brightness 50

• Sharpness 70

Intelligent Sensor

Vivid

Standard

Natural

Cinema

Sport

Game

Expert1

Expert2

■

When selecting

Int ellig ent Senso r

Ener gy Saving

is changed to

Auto

automatically.

■

When selecting

Int ellig ent Sens or

, it is changed contrast, brightness, sharpness, color and tint automatically.

■

Vivid, Stan dard, Natu r al, Cine m a

Sport

, and

Game

Settings are preset for the optimum picture quality at the factory.

■

Int ellig ent Se nsor

: The most suitable picture is automatically adjusted according to the surrounding conditions.

■

Vivid

: This is the mode to maximize the effect of the video in the retail store. Strengthen the contrast, brightness, color and sharpness for vivid picture.

■

Stan dard

: This is the mode to realize optimum viewing condition for the general user.

■

Natu r al

: This is the mode to display the

most natural screen status.

■

Cine m a

: This mode optimizes video for

watching movies.

■

Sp o r t

: This is the video mode to emphasize dynamic video and primary color (e.g, white, uniform, grass, sky blue etc.) by realizing the optimal screen for sports.

■

Game

: This is the mode to realize fast

response speed in a fast gaming screen.

■

Expe r t

: This is the mode to adjust the video in detail for video quality expert and general user.

■

You can also adjust

Pict ure Mod e

the

Q.ME NU

PICTURE CONTROL

MANUAL PICTURE ADJUSTMENT - USER MODE

Adjust the picture appearance to suit your preference and viewing situations.

Select

PICT U RE

Select

Pict ure Mo de

ENTER

Enter

Move


• Backlight 70

Enter

Make appropriate adjustments.

Select

Back light, Cont rast, Brig htnes s

Shar pness, Color

, or

Tint

Select

Viv id,Standa rd, Natura l

Cin ema, Spo rt

, or

Game

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

■

When adjusting Energy Saving, Back light

function is disabled.

■

Back light

: This function adjusts the brightness of LCD panel, to control the brightness of the screen. Adjusting the backlight is recommended when setting the brightness of the set. When decreasing the backlight, the brightness of the black becomes darker without any loss in video signal and the power consumption is reduced.

■

Cont rast

: Increase or decrease the gradient of the video signal. You may use Contrast when the bright part of picture is saturated.

■

Brig htnes s

: Adjusts the base level of the signal in the picture. You may use Brightness when the dark part of the picture is saturated.

■

Shar pness

: Adjusts the level of crispness in the edges between the light and dark areas of the picture. The lower the level, the softer the image.

■

Color

: Adjusts intensity of all colors.

■

Tint

: Adjusts the balance between red

and green levels.

Aspect Ratio : 16:9

Picture Wizard

Energy Saving

: Off

Picture Mode : Standard

• Backlight 70

• Contrast 90

• Brightness 50

• Sharpness 70

PICTURE CONTROL

PICTURE IMPROVEMENT TECHNOLOGY

PICTURE CONTROL

Select

PICT U RE

Select

Adv a nced C ontr ol

Select your desired options.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Make appropriate adjustments.

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Picture Reset

Screen (RGB-PC)

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Picture Reset

Screen (RGB-PC)

You can calibrate the screen for each Picture Mode or set the video value according to the special video screen. You can set the video seeing differently for each input. To reset to the factory default after making adjustments to each input source, execute the

Pict ure Reset

function for each Picture Mode.

Color Temperature

Medium

Dynamic Contrast

Off

Dynamic Color

Off

Noise Reduction

Off

Gamma

Medium

Black Level

Low

Eye Care

Off

Real Cinema

Off

TruMotion 120Hz

Low

Color Gamut

High

PICTURE CONTROL

EXPERT PICTURE CONTROL

Select

PICT U RE

Select

Pict ure Mo de

Select

Expe rt Con trol

Select

Expe r t1

Expe r t2

ENTER

Make appropriate adjustments.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


• Brightness 50

• H Sharpness 50

• V Sharpness 50

• Color 50

• Tint 0

• Expert Control

• Picture Reset

Screen (RGB-PC)

Dynamic Contrast

Off

Noise Reduction

Low

Gamma

Medium

Black Level

Low

Real Cinema

Off

TruMotion 120Hz

Low

Color Standard

Color Gamut

Standard

Edge Enhancer

High

Select your desired menu option.

ENTER

Enter

Move


Aspect Ratio : 16:9

Picture Wizard

Energy Saving

: Off

Picture Mode : Expert1

• Backlight 70

• Contrast 90

• Brightness 50

• H Sharpness 50

Intelligent Sensor

Vivid

Standard

Natural

Cinema

Sport

Game

Expert1

Expert2

By segmenting categories,

Expe r t1

and

Expe r t2

provide more categories which users can set as they see

fit, offering the optimal picture quality for users. This may also be used be a professional to help optimize the TV performance in the environment the TV is in.

PICTURE CONTROL

■

Set to warm to enhance hotter colors such as red, or set to cool to make picture bluish.

■

Adjusts the contrast to keep it at the best level according to the brightness of the screen. The picture is improved by making bright parts brighter and dark parts darker.

■

Adjusts screen colors so that they look livelier, richer and clearer. This feature enhances hue, saturation and luminance so that red, blue, green and white look more vivid.

■

Reduces screen noise without compromising video quality.

Low : Make dark and middle gray level area of the picture brighter. Medium: Express original picture levels. High: Make dark and middle gray level area of the picture darker.

■

You can adjust brightness of dark area and middle gray level area of the picture.

Low: The reflection of the screen gets darker. High: The reflection of the screen gets brighter. Auto: Realizing the black level of the screen and set it to High or Low automatically.

■

Set black level of the screen to proper level.

■

This function enables to select 'Low' or 'High' in the following mode: AV (NTSC-M), HDMI or Component. Otherwise, 'Black level' is set to 'Auto'.

■

Adjust the brightness of the screen to prevent the screen from being too bright. Dims extremely bright pictures.

■

This feature is disabled in “

Pic ture M ode-V ivid, Cine m a

”.

■

Makes video clips recorded in film look more natural by eliminating judder effect.

■

DVD and Blu-ray movies are filmed at 24 frames per second. With LG Real Cinema, every frame is consistently processed 5 times in 1/24 of a second producing 120 fps with TruMotion or 2 times in 1/24 of a second producing 48 fps without TruMotion, thus totally eliminating the judder effect.

■

This function can work when TruMotion is off.

High: Provides smoother picture movement. Low: Provides smooth picture movement. Use this setting for standard use. Off: Use this setting when "High" and "Low" setting result in noise.

■

TruMotion120Hz or 240Hz provides even better quality for movies than 3:2 PullDown conversions.

■

TruMotion can reduce the perception of blur on fast moving scenes by displaying 120 or 240 images per second.

■

It is used for the best picture quality without any motion blur or judder when you enter a quick image or Film Source.

■

TruMotion120Hz or 240Hz works with all inputs except PC mode.

■

If you enable "TruMotion 120Hz or 240Hz", noise may appear on the screen. If this occurs, set "TruMotion 120Hz or 240Hz" to "Off".

Dynamic Contrast

Dynamic Color

Noise Reduction

Gamma

Black Level

Eye Care

Real Cinema

TruMotion 120Hz/240Hz

Color Temperature

PICTURE CONTROL

■

Convert the color of a different video to HD color.

■

This is the function to adjust the overall color of the screen to the feeling you want.

a. Method : 2 Points

- Pattern: Inner, Outer

- Red/Green/Blue Contrast, Red/Green/Blue Brightness: The adjustment range is -50 - +50.

b. Method : 10 Point IRE

- Pattern: Inner, Outer

- IRE (Institute of Radio Engineers) is the unit to display the size of the video signal

and can be set among 10, 20, 30 - 100. You can adjust Red, Green or Blue according to each setting.

- Luminance: This function displays calculated luminance value for 2.2 gamma. You can

input luminance value you want at 100 IRE, than the target luminance value for 2.2 gamma is displayed at every 10 steps from 10 IRE to 90 IRE.

- Red/Green/Blue: The adjustment range is -50 - +50.

■

As the tool used by the experts to make adjustments by using the test patterns, this does not affect other colors but can be used to selectively adjust the 6 color areas (Red/Green/Blue/Cyan/Mgt/Yellow).

Color difference may not be distinctive even when you make the adjustments for the general video.

Adjusts Red/Green/Blue/Yellow/Cyan, Magenta.

- Red/Green/Blue/Yellow/Cyan, Magenta Color: The adjustment range is -30 - +30.

- Red/Green/Blue/Yellow/Cyan, Magenta Tint: The adjustment range is -30 - +30.

- This feature is disable in RGB-PC and HDMI-PC mode.

*This feature is not available for all models.

■

As the technology to reduce the power consumption while keeping the same brightness, this has the effect of reducing power consumption, improvement in contrast.

White Balance

Color Management System

OPC

Color Standard

Standard: Displays standard color area. Wide: Mode to use and set the rich color area of the display.

■

Maximize the utilization of color to increase color quality.

Color Gamut

■

Show clearer and distinctive yet natural corners of the video.

Edge Enhancer

■

This is the pattern necessary for expert adjustment.

■

This function is enabled in "

Pict ure Mo de- Expe r t

" when you watch DTV.

Expert Pattern

■

This is the function to filter the specific colors of the video.

You can use the RGB filter to set color saturation and hue accurately.

Color Filter

■

This is the function to express richer color.

■

This feature represents rich color as much as conventional video signal.

■

This function is enabled in "

Pict ure mode- Cine m a, Expe r t

" when xvYCC sig-

nal is inputted through HDMI.

xvYCC

PICTURE CONTROL

ENERGY SAVING

PICTURE CONTROL

It reduces the TV’s power consumption by lowering the backlight level. The default factory setting complies with the

Ener gy S tar

requirements and is adjusted to the comfortable

level to be viewed at home. You can increase the brightness of your screen by adjusting the

Ener gy Savin g

level or by setting the

Pict u re

Mode

■

When selecting

Scr een off

, TV turned

off after 3 seconds.

■

If you adjust “

Ene rgy Savin g-Au to

Mi n i m u m, Me d i u m, Ma x i m u m

”,

Back light

feature will not work.

■

When selecting

Auto, Back l ight

is automatically adjusted through Int ellig ent sens or

according to the

surrounding conditions.

■

Press the

ENE RGY SAV ING

button repeatedly to select the appropriate Energy Saving setup.

Select

PICT U RE

Select

Ener gy Sav ing

ENTER

Select

Auto, Off, Mini m um, Medi u m

Maxi m um

, or

Scre en Off

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Enter

Move


Aspect Ratio : 16:9

Picture Wizard

Energy Saving

: Off

Picture Mode : Standard

• Backlight 70

• Contrast 90

• Brightness 50

• Sharpness 70

Aspect Ratio : 16:9

Picture Wizard

Energy Saving

: Off

Picture Mode : Standard

• Backlight 70

• Contrast 90

• Brightness 50

• Sharpness 70

Auto

Off

Minimum

Medium

Maximum

Screen off

PICTURE CONTROL

PICTURE RESET

Settings of the selected picture modes return to the default factory settings.

Select

PICT U RE

Select

Pict ure Res et

Initialize the adjusted value.

ENTER

Select

Yes

ENTER

Return to TV viewing.

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Picture Reset

Screen (RGB-PC)

Resetting video configuration...

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Picture Reset

Screen (RGB-PC)

Ye s

All picture settings will be resetted. Continue?

PICTURE CONTROL

POWER INDICATOR

PICTURE CONTROL

Select

OPTI O N

Select

Pow e r Indi cato r

ENTER

Select

Stan dby Lig htorPowe r Ligh t

ENTER

Select your desired options.

RETURN

Return to the previous menu.

Return to TV viewing.

■

Standby Light

: Determines whether to set the indicator light on the front of the TV to

O n

Off

in standby mode.

■

Powe r L ight

: Determines whether to set the indicator light on the front of the TV to

O n

Off

when the power turns on.

Enter

Move

OPTION

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

Power Indicator

Demo Mode : Off

Initial Setting : Home Use

Enter

Move

OPTION

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

Power Indicator

Demo Mode : Off

Initial Setting : Home Use

Power Light

Standby Light

Adjust the power/standby indicator light of TV front.

PICTURE CONTROL

DEMO MODE

Select

OPTI O N

Select

Demo M ode

ENTER

Select

O n

to show the various

feature of the TV.

ENTER

Return to TV viewing. After a while,

Demo M ode

starts.

If you want to stop the demo, press any button (Except VOL +, - and MUTE button).

Enter

Move

OPTION

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

Power Indicator

Demo Mode : Off

Initial Setting : Store Demo

Enter

Move

OPTION

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

Power Indicator

Demo Mode : On

Initial Setting : Store Demo

Off

Displays a slide show to explain the various feature of this TV.

■

This feature is disabled in “

Initial

Set t ing- Home U se

”.

PICTURE CONTROL

LOCAL DIMMING

For 55LH95

PICTURE CONTROL

Select

PICT U RE

Select

Loca l Dimm ing

ENTER

Select

O n

Off

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

After analyzing the signal of the input video by areas of the screen, it adjusts the backlight to improve the contrast ratio. This feature is disabled in “

Pic ture M ode-C inem a, Gam e

”.

Enter

Move


• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Picture Reset

Local Dimming : On

Screen (RGB-PC)

Local Dimming Demo

Enter

Move


• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Picture Reset

Local Dimming : On

Screen (RGB-PC)

Local Dimming Demo

Off

SOUND & LANGUAGE CONTROL

AUTO VOLUME LEVELER (AUTO VOLUME)

SOUND & LANGUAGE CONTROL

Auto Volume makes sure that the volume level remains consistent whether you are watching a commercial or a regular TV program.

Because each broadcasting station has its own signal conditions, volume adjustment may be needed every time the channel is changed. This feature allows users to enjoy stable volume levels by making automatic adjustments for each program.

Select

AUDIO

Select

Auto Volum e

Select

O n

Off

Enter

Move

AUDIO

Enter

Move

AUDIO

ENTER

Auto Volume : Off

Clear Voice II : Off

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

Auto Volume : On

Clear Voice II : Off

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

Off

RETURN

Return to the previous menu.

Return to TV viewing.

SOUND & LANGUAGE CONTROL

CLEAR VOICE II

By differentiating the human sound range from others, it improves the sound quality of voices.

Enter

Move

AUDIO

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice II : Off

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

Auto Volume : Off

Clear Voice II : On

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

Select

AUDIO

Select

Clea r Voic e II

Select

O n

Off

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Select

Level

ENTER

Make appropriate adjustments.

ENTER

Adjustment for Clear Voice Level With selecting

O n

-+ -+

Off

SOUND & LANGUAGE CONTROL

PRESET SOUND SETTINGS (SOUND MODE)

Sound Mode lets you enjoy the best sound without any special adjustment as the TV sets the appropriate sound options based on the program content.

Select

AUDIO

Select

Soun d Mode

Select

Stan dard, Music

Cine m a, Sport

, or

Game

ENTER

Enter

Move

AUDIO

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice II : Off

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

Auto Volume : Off

Clear Voice II : Off

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

Standard

Music

Cinema

Sport

Game

■

Stan dard, Music, Cine m a, Sport

and

Game

are preset for optimum

sound quality at the factory.

■

You can also adjust

Soun d Mode

the

Q.ME NU

■

St a n d a r d

: Offers standard-quality

sound.

■

Music

: Optimizes sound for listening to

music.

■

Cine m a

: Optimizes sound for watching

movies.

■

Sport

: Optimizes sound for watching

sports events.

■

Game

: Optimizes sound for playing

games.

RETURN

Return to the previous menu.

Return to TV viewing.

-+ -+

SOUND & LANGUAGE CONTROL

SOUND SETTING ADJUSTMENT - USER MODE

SOUND & LANGUAGE CONTROL

SRS TRUSURROUND XT

Adjust the sound to suit your taste and room situations.

Select this option to sound realistic.

Select

AUDIO

Select

Soun d Mode

Select

Treb l e

Bass

ENTER

Select

Stan dard, Music

Cine m a, Sport

, or

Game

ENTER

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice II : Off

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice II : Off

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

Select

AUDIO

Select

SRS T ruSu r roun d XT

Select

O n

Off

ENTER

■

If you select “

Cle ar V oice II- On

”,

SRS

TruS urro und XT

feature will not work.

■

SRS TruSu rrou nd X T

: TruSurround XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers.

RETURN

Return to the previous menu.

Return to TV viewing.

RETURN

Return to the previous menu.

Return to TV viewing.

Make appropriate adjustments.

ENTER

• Treble 50

• Bass 50

•

SRS TruSurround XT

Off

-+ -+

SOUND & LANGUAGE CONTROL

BALANCE

Select

AUDIO

Select

Bala n ce

Make appropriate adjustments.

ENTER

Adjust the left/right sound of speaker to suit your taste and room situations.

Enter

Move

AUDIO

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice II : Off

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

Auto Volume : Off

Clear Voice II : Off

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

Balance 0

RETURN

Return to the previous menu.

Return to TV viewing.

SOUND & LANGUAGE CONTROL

TV SPEAKERS ON/OFF SETUP

SOUND & LANGUAGE CONTROL

Turn the TV speakers off if using external audio equipment. In

A V, Comp onent, RGB

and

HDMI

with HDMI to DVI cable, the TV speaker can be operational even when

there is no video signal. If you wish to use an external Hi-Fi system or a SRS System, turn off the TV’s internal speakers.

Enter

Move

AUDIO

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Select

AUDIO

Select

TV Sp e aker

Select

O n

Off

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Off

-+ -+

SOUND & LANGUAGE CONTROL

AUDIO RESET

Settings of the selected Sound Mode return to the default factory settings.

Select

AUDIO

Select

Reset

ENTER

Initialize the adjusted value.

ENTER

Return to TV viewing.

Enter

Move

AUDIO

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Enter

Move

AUDIO

• Level 3

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Resetting audio configuration...

SOUND & LANGUAGE CONTROL

STEREO/SAP BROADCAST SETUP

SOUND & LANGUAGE CONTROL

For Analog only: This TV can receive MTS stereo programs and any SAP (Secondary Audio Program) that accompanies the stereo program if the station transmits an additional sound signal. Mono sound is automatically used if the broadcast is only in Mono.

Select

SAP

Select

Mono, Ster e o

, or

SAP

Return to TV viewing.

Q.MENU

Select

Mult i Audi o

Select other languages.

Return to TV viewing.

Q.MENU

Analog TV Digital TV

English

Multi Audio

SOUND & LANGUAGE CONTROL

ON-SCREEN MENUS LANGUAGE SELECTION

The menus can be shown on the screen in the selected language.

Select

OPTI O N

Select

Menu Langu age

Select your desired language. From this point on, the on-screen menus will

be shown in the selected language.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Enter

Move

OPTION

Menu Language : English

Audio Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

Menu Language : English

Audio Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

English

Español

Français

SOUND & LANGUAGE CONTROL

AUDIO LANGUAGE

SOUND & LANGUAGE CONTROL

Other languages may be available if a digital signal is provided by the broadcasting station. This feature operates only in DTV/CADTV mode.

Select

OPTI O N

Select

Audi o Lang uage

Select your desired language.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Enter

Move

OPTION

Menu Language : English

Audio Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

Menu Language : English

Audio Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

English

Spanish

French

SOUND & LANGUAGE CONTROL

CAPTION MODE

Captions are provided to help people with hearing loss watch TV. Select a caption mode for displaying captioning information if provided on a program. Analog caption displays information at any position on the screen and is usually the program's dialog. Caption/Text, if provided by the broadcaster, would be available for both digital and analog channels on the Antenna/Cable. This TV is programmed to memorize the caption/text mode which was last set when you turned the power off. This function is only available when

Capt i on

Mode is set

O n

Select

OPTI O N

Select

Capt i on

Select

O n

ENTER

Select

CC1-4

Text 1-4

Analog Broadcasting System Captions

■

When selecting

Of f

, Sub-menus for

Analog, DTV, and Digital Option become disabled.

■

CAPT I ON The term for the words that scroll

across the bottom of the TV screen; usually the audio portion of the program provided for the hearing impaired.

■

TEXT The term for the words that appear in a

large black frame and almost cover the entire screen; usually messages provided by the broadcaster.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Enter

Move

OPTION

Menu Language : English

Audio Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

Menu Language : English

Audio Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : CC1

Set ID : 1

Mode

CC1

Digital Option

SOUND & LANGUAGE CONTROL

Digital Broadcasting System Captions

Choose the language you want the DTV/CADTV Captions to appear in. Other Languages can be chosen for digital sources only if they are included on the program. This function in only available when Caption Mode is set On.

Select

OPTI O N

Select

Capt i on

Select

O n

ENTER

Select

CC1-4, Text 1-4

, or

Serv ice1- 6

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Enter

Move

OPTION

Menu Language : English

Audio Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

Menu Language : English

Audio Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

Mode

CC1

Digital Option

SOUND & LANGUAGE CONTROL

Caption Option

Customize the DTV/CADTV captions that appear on your screen. This function in only available when Caption Mode is set On.

Select

OPTI O N

Select

Capt i on

Select

O n

ENTER

Select

Cust o m

ENTER

Customize the

Size, Font

, etc., to your preference. A preview icon is provided at the bottom of the screen, use it to see the caption language.

Select

Digi tal Opt ion

Size

A Standard

Font

Font 1

Text Color

White

Text Opacity

Solid

Edge Type

None

Edge Color

Black

Bg Color

Black

Bg Opacity

Solid

Custom

■

Size

: Set the word size.

■

Font

: Select a typeface for the text.

■

Text C olor

: Choose a color for the

text.

■

Text Opaci ty

: Specify the opacity

for the text color.

■

Bg (Ba ckgro und) Color

: Select a

background color.

■

Bg (Ba ckground) Opaci ty

: Select

the opacity for the background color.

■

Edge T ype

: Select an edge type.

■

Edge C olor

: Select a color for the

edges.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Enter

Move

OPTION

Menu Language : English

Audio Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

Menu Language : English

Audio Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Simple Manual

Caption : Off

Set ID : 1

Mode

CC1

Digital Option

TIME SETTING

CLOCK SETTING

TIME SETTING

Auto Clock Setup

The time is set automatically from a digital channel signal. The digital channel signal includes information for the current time provided by the broadcasting station. Set the clock manually if the current time is set incorrectly by the auto clock function.

Enter

Move

TIME

Enter

Move

TIME

Clock

Off Time : Off

On Time : Off

Sleep Timer : Off

Clock

Off Time : Off

On Time : Off

Sleep Timer : Off

Month

Date

Year

2009

Hour

10 AM

Minute

Time Zone

Eastern

Daylight Saving

Auto

Select

TIME

Select

Clock

Select

Auto

ENTER

Select your viewing area time zone.

• U.S.A:

Eas t e r n, Cen t r a l, Moun t a i n

Paci fic, Alas ka

, or

Hawa ii

• Canada:

East e rn, Cent r al, Moun t ain

Paci fic, New F .lan d

, or

Atl a ntic

Select

Auto, Off

, or

O n

(depending on whether or not your viewing area observes Daylight Saving time).

RETURN

Return to the previous menu.

Return to TV viewing.

TIME SETTING

Manual Clock Setup

If the current time setting is wrong, reset the clock manually. If this TV is unplugged once or turn off with the AC power control switch on the TV, reset the

Cloc k

function.

Enter

Move

TIME

Enter

Move

TIME

Clock

Off Time : Off

On Time : Off

Sleep Timer : Off

Clock

Off Time : Off

On Time : Off

Sleep Timer : Off

Select

TIME

Select

Clock

Select

Manu a l

ENTER

Select the Year, Month, Date, Hour, or Minutes option.

Set the Year, Month, Date, Hour, or Minutes option.

RETURN

Return to the previous menu.

Return to TV viewing.

Month

Date

Year

2009

Hour

10 AM

Minute

Time Zone

Eastern

Daylight Saving

Auto

Manual

TIME SETTING

100

AUTO ON/OFF TIME SETTING

TIME SETTING

This function operates only if the current time has been set. The

Off Tim e

function overrides the

On Tim e

function if they are both set to the same time.

The TV must be in standby mode for the

On Tim e

to work.

If you do not press any button within 2 hours after the TV turns on with the

On Time

function, the TV will

automatically revert to standby mode.

■

To cancel

On/O ff Tim e

function, select

Off

■

Only for On Time function

Select

Input

Select the desired input source.

Enter

Move

TIME

Enter

Move

TIME

Clock

Off Time : Off

On Time : Off

Sleep Timer : Off

Clock

Off Time : Off

On Time : 6:30 AM (Once)

Sleep Timer : Off

Select

TIME

Select

Off Tim e

On Tim e

Select

Repe a t

ENTER

Select

Off, Once, Daily, Mon.~Fri.

Mon.~Sat., Sat.~Sun.

, or

Sun.

Select and set

Hour

Minu te

ENTER

When Selecting

T V

set the channel at turn-on.

Adjust to sound level at turn-on.

RETURN

Return to the previous menu.

Return to TV viewing.

Repeat

Once

Hour

6 AM

Minute

Input

Channel

TV 2-0

Volume

Feb. 21, 2009 10:10 AM

TIME SETTING

101

SLEEP TIMER SETTING

The Sleep Timer turns the TV off at the preset time. Note that this setting is cleared when the TV is turned off.

■

You can also adjust

Slee p T i mer

in the

Q.ME NU

Enter

Move

TIME

Enter

Move

TIME

Clock

Off Time : Off

On Time : Off

Sleep Timer : Off

Clock

Off Time : Off

On Time : Off

Sleep Timer : Off

Select

TIME

Select

Slee p Time r

Make appropriate adjustments.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Off

10 min.

20 min.

30 min.

60 min.

90 min.

120 min.

180 min.

240 min.

PARENTAL CONTROL / RATING

102

PARENTAL CONTROL / RATINGS

Parental Control can be used to block specific channels, ratings and other viewing sources.

The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broadcasting station. The default setting is to allow all programs to be viewed. Viewing can be blocked by choosing the type of the program and the categories. It is also possible to block all program viewing for a time period. To use this function, the following must be done :

1. Set ratings and categories to be blocked.

2. Specify a password

3. Enable the lock

V-Chip rating and categories

Rating guidelines are provided by broadcasting stations. Most television programs and television movies can be blocked by TV Rating and/or Individual Categories. Movies that have been shown at the theaters or direct-tovideo movies use the Movie Rating System (MPAA)only.

Ratings for Television programs including made-for-TV movies:

■

TV-G(General audience

)

■

TV-PG(Parental guidance suggested

)

■

TV-14(Parents strongly cautioned

)

■

TV-MA (Mature audience only

)

■

TV-Y(All children

)

■

TV-Y7(Children 7 years older

)

Set up blocking schemes to block specific channels, ratings, and external viewing sources. A password is required to gain access to this menu.

Setting up Your Password

For USA

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

For Canada

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

TV Rating-English

TV Rating-French

Downloadable Rating

Input Block

Enter Password

* * * *

Select

LOCK

ENTER

Input the password.

123

4506

789

■

Enter the password as requested.

■

The TV is set up with the initial password “0-0-0-0”.

SET PASSWORD & LOCK SYSTEM

PARENTAL CONTROL / RATING

103

Enables or disables the blocking scheme you set up previously.

Lock System

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Select

Lock Syste m

Select

O n

Off

ENTER

Enter

Move

LOCK

Lock System : On

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Off

■

When you select

O n

, the Lock System

is enable.

Select

LOCK

ENTER

Input the password.

123

4506

789

RETURN

Return to the previous menu.

Return to TV viewing.

PARENTAL CONTROL / RATING

104

PARENTAL CONTROL / RATINGS

Change the password by inputting a new password twice.

Set Password

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Select

Set Passw ord

Choose any 4 digits for your new password. As soon as the 4 digits are entered, re-enter

the same 4 digits on the

Conf irm

ENTER

123

4506

789

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

New

* * * *

Confirm

* * * *

Select

LOCK

ENTER

Input the password.

123

4506

789

RETURN

Return to the previous menu.

Return to TV viewing.

PARENTAL CONTROL / RATING

105

CHANNEL BLOCKING

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Select

Blo ck Cha nnel

Select a channel to block or unblock.

ENTER

Block or unblock a channel.

Blocks any channels that you do not want to watch or that you do not want your children to watch.

Select

LOCK

ENTER

Input the password.

123

4506

789

RETURN

Return to the previous menu.

Return to TV viewing.

Ch. Change

Page Change

Navigation

Block/Unblock

PARENTAL CONTROL / RATING

106

MOVIE & TV RATING

PARENTAL CONTROL / RATINGS

Movie Rating (MPAA)

For USA

Blocks movies according to the movie ratings limits specified, so children cannot view certain movies. You can set the ratings limit by blocking out all the movies with the ratings above a specified level. Keep in mind that the movie ratings limit only applies to movies shown on TV, not TV programs, such as soap operas.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Select

Mov ie Rat ing

Select G,

P G, PG-1 3, R, NC-1 7

, or

Blocking Off

ENTER

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Blocking off : Permits all programs

PG-13

NC-17

Blocking Off

■

G (General audience)

■

PG (Parental guidance suggested)

■

PG-13 (Parents strongly cautioned)

■

R (Restricted)

■

NC-17 (No one 17 and under admitted)

■

X (Adult only)

■

Blocking Off (Permits all programs)

If you set PG-13: G and PG movies will be available, PG-13, R, NC-17 and X will be blocked.

Select

LOCK

ENTER

Input the password.

123

4506

789

RETURN

Return to the previous menu.

Return to TV viewing.

PARENTAL CONTROL / RATING

107

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Select

TV R atin g-Ch ildr en

Select

Age

Fan tasy Viol ence

ENTER

Select block options.

ENTER

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

■

Age (applies to TV-Y, TV-Y7)

■

Fantasy Violence (applies to TV-Y7)

TV Rating Children

For USA

Prevents children from watching certain children's TV programs, according to the ratings limit set. The children rating does not apply to other TV programs. Unless you block certain TV programs intended for mature audiences in the TV Rating - sub menu, your children can view those programs.

Age

Fantasy Violence

Select

LOCK

ENTER

Input the password.

123

4506

789

RETURN

Return to the previous menu.

Return to TV viewing.

PARENTAL CONTROL / RATING

108

PARENTAL CONTROL / RATINGS

TV Rating General

For USA

Based on the ratings, blocks certain TV programs that you and your family do not want to view.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Select

TV R atin g-Ge nera l

Select

Age, Dial o gue, Lang u age

Sex

Vio l ence

ENTER

Select block options.

ENTER

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

■

Age (applies to TV-G,TV-PG,TV-14,TVMA).

■

Dialogue-sexual dialogue (applies to TV-PG,TV-14).

■

Language-adult language (applies to TV-PG, TV-14, TV-MA).

■

Sex-sexual situations (applies to TV-PG, TV-14, TV-MA).

■

Violence (applies to TV-PG, TV-14, TVMA).

Age

Dialogue

Language

Sex

Violence

Select

LOCK

ENTER

Input the password.

123

4506

789

RETURN

Return to the previous menu.

Return to TV viewing.

PARENTAL CONTROL / RATING

109

TV Rating English

For CANADA

Selecting Canadian English rating system.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

TV Rating-English

TV Rating-French

Downloadable Rating

Input Block

Select

TV R atin g-En glis h

Select E, C,

C8+, G, PG

14+, 18+

, or

Blocking Off

ENTER

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

TV Rating-English

TV Rating-French

Downloadable Rating

Input Block

Blocking off : Permits all programs

C8+

14+

18+

Blocking Off

■

E (Exempt)

■

C (Children)

■

C8+ (Children eight years and older)

■

G (General programming, suitable for all audiences)

■

PG (Parental Guidance)

■

14+ (Viewers 14 years and older)

■

18+ (Adult programming)

■

Blocking Off (Permits all programs)

Select

LOCK

ENTER

Input the password.

123

4506

789

RETURN

Return to the previous menu.

Return to TV viewing.

PARENTAL CONTROL / RATING

110

PARENTAL CONTROL / RATINGS

TV Rating French

For CANADA

Selecting Canadian French rating system.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

TV Rating-English

TV Rating-French

Downloadable Rating

Input Block

Select

TV R atin g-Fr ench

Select E, G,

8ans +, 13an s+

16an s+, 18an s+

, or

Blo cking off

ENTER

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

TV Rating-English

TV Rating-French

Downloadable Rating

Input Block

Blocking off : Permits all programs

8ans+

13ans+

16ans+

18ans+

Blocking Off

■

E (Exempt)

■

G (General)

■

8ans+ (General-Not convenient for little children)

■

13ans+ (Not convenient for children of 13 years and younger)

■

16ans+ (Not convenient for children of 16 years and younger)

■

18ans+ (This programs is only for adults)

■

Blocking off (Permits all programs)

Select

LOCK

ENTER

Input the password.

123

4506

789

RETURN

Return to the previous menu.

Return to TV viewing.

PARENTAL CONTROL / RATING

111

DOWNLOADABLE RATING

This function is available only for digital channels. This function operates only when TV has received Region5 Rating data.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Humor

Sport

Cruelty

Language

Sadness

Genre

Age

Select

Dow nloa dabl e Rat ing

Select desired

Dow nloa dable

Rati ng

option.

ENTER

Select desired option and block it.

ENTER

Select

LOCK

ENTER

Input the password.

123

4506

789

RETURN

Return to the previous menu.

Return to TV viewing.

■

Based on rating table, your TV's OSD (On Screen Display) may differ slightly from what is shown in this manual.

PARENTAL CONTROL / RATING

112

EXTERNAL INPUT BLOCKING

PARENTAL CONTROL / RATINGS

Enables you to block an input.

Select

Inp ut Blo ck

Select input source.

Select

O n

Off

ENTER

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Select

LOCK

ENTER

Input the password.

123

4506

789

RETURN

Return to the previous menu.

Return to TV viewing.

AV1

Off

AV2

Off

Component1

Off

HDMI1

Off

RGB-PC

Off

Component2

Off

HDMI2

Off

HDMI3

Off

HDMI4

Off

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

APPENDIX

113

TROUBLESHOOTING

APPENDIX

The operation does not work normally.

The video does not work.

No picture &No sound

No or poor color

or poor picture

Poor reception on

some channels

Lines or streaks

in pictures

No picture

when connecting HDMI

Horizontal/vertical bars

or picture shaking

Picture appears slowly

after switching on

The remote control

doesn’t work

Power is suddenly

turned off

■

Check to see if there is any object between the product and the remote control causing obstruction. Ensure you are pointing the remote control directly at the TV.

■

Ensure that the batteries are installed with correct polarity (+ to +, - to -).

■

Ensure that the correct remote operating mode is set: TV, VCR etc.

■

Install new batteries.

■

Is the sleep timer set?

■

Check the power control settings. Power interrupted.

■

TV will be automatically turned off, in case of no signal for 15 minutes.

■

Check whether the product is turned on.

■

Try another channel. The problem may be with the broadcast.

■

Is the power cord inserted into wall power outlet?

■

Check your antenna direction and/or location.

■

Test the wall power outlet, plug another product’s power cord into the outlet where the product’s power cord was plugged in.

■

This is normal, the image is muted during the product startup process. Please contact your service center, if the picture has not appeared after five minutes.

■

Adjust Color in menu option.

■

Keep a sufficient distance between the product and the VCR.

■

Try another channel. The problem may be with the broadcast.

■

Are the video cables installed properly?

■

Activate any function to restore the brightness of the picture.

■

Check for local interference such as an electrical appliance or power tool.

■

Station or cable product experiencing problems, tune to another station.

■

Station signal is weak, reorient antenna to receive weaker station.

■

Check for sources of possible interference.

■

Check antenna (Change the direction of the antenna).

■

Check HDMI cable over version 1.3.

The HDMI cables don’t support HDMI version 1.3, it cause flickers or no screen display. In this case use the latest cables that support HDMI version 1.3.

*This feature is not available for all models.

APPENDIX

114

APPENDIX

There is a problem in PC mode. (Only PC mode applied)

■

Adjust resolution, horizontal frequency, or vertical frequency.

■

Check the input source.

■

Work the Auto configure or adjust clock, phase, or H/V position. (Option)

■

Check the signal cable.

■

Reinstall the PC video card.

The signal is out of range

Screen color is unstable

or single color

Vertical bar or stripe on

background &

Horizontal Noise &

Incorrect position

Picture OK & No sound

Unusual sound from

inside the product

No sound

when connecting

HDMI/USB

No output from one

of the speakers

The audio does not work.

■

Press the VOL or VOLUME button.

■

Sound muted? Press MUTE button.

■

Try another channel. The problem may be with the broadcast.

■

Are the audio cables installed properly?

■

Adjust Balance in menu option.

■

A change in ambient humidity or temperature may result in an unusual noise when the product is turned on or off and does not indicate a fault with the product.

■

Check HDMI cable over version 1.3.

■

Check USB cable over version 2.0.

■

Use normal MP3 file.

*This feature is not available for all models.

APPENDIX

115

MAINTENANCE

Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you can enjoy your new TV.

Caution: Be sure to turn the power off and unplug the power cord before you begin any cleaning.

Cleaning the Screen

Here’s a great way to keep the dust off your screen for a while. Wet a soft cloth in a mixture of lukewarm water and a little fabric softener or dish washing detergent. Wring the cloth until it’s almost dry, and then use it to wipe the screen.

Make sure the excess water is off the screen, and then let it air-dry before you turn on your TV.

Cleaning the Cabinet

■

To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth.

■

Please be sure not to use a wet cloth.

Extended Absence

If you expect to leave your TV dormant for a long time (such as a vacation), it’s a good idea to unplug the power cord to protect against possible damage from lightning or power surges.

CAUTION

APPENDIX

116

PRODUCT SPECIFICATIONS

APPENDIX

■

The specifications shown above may be changed without prior notice for quality improvement.

MODELS

AC100-240V ~ 50/60Hz

NTSC-M, ATSC, 64 & 256 QAM

VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135

75 ohm

32 ~ 104°F (0 ~ 40°C)

Less than 80%

-4 ~ 140°F (-20 ~ 60°C)

Less than 85%

Dimensions (Width x Height x Depth)

Weight

Power requirement Television System Program Coverage External Antenna Impedance

Environment condition

With stand

Without stand

With stand Without stand

Operating Temperature Operating Humidity

Storage Temperature Storage Humidity

47LH85

(47LH85-UB)

55LH85

(55LH85-UB)

46.4 x 33.5 x 15.7 inches

1179.0 x 851.4 x 398.8 mm

46.4 x 30.7 x 4.1 inches

1179.0 x 780.6 x 105.9 mm

55.9 lbs / 25.4 kg

47.6 lbs / 21.6 kg

54.0 x 37.9 x 17.8 inches

1373.0 x 964.3 x 454.2 mm

54.0 x 34.9 x 4.2 inches

1373.0 x 888.5 x 106.9 mm

86.4 lbs / 39.2 kg

74.5 lbs / 33.8 kg

Dimensions (Width x Height x Depth)

Weight

16.7 x 9.5 x 2.7 inches

426.0 x 234.5 x 68.6 mm

5.0 lbs / 2.3 kg

MODELS

Media Box

FCC ID: BEJEAX5296, IC: 2703L-EAX5296

Fc (HRP)

BW HRP

BW LRP

P HREIRP

P LREIRP

G HRTX

G LRTX

Frequency Range

HRP Occupied Bandwidth

LRP Occupied Bandwidth

HRP Radiated Power (EIRP)

LRP Radiated Power (EIRP)

HRP Transmit Antenna Gain

LRP Transmit Antenna Gain

59.4

60.48

61.56

1.76

GHz

MHz

dBm

dBi

Symbol Parameter Min. Type Max. Units

APPENDIX

117

IR CODES

Code

Function Note

(Hexa)

Code

Function Note

(Hexa)

08 POWER

Remote control Button (Power On/Off)

45 Q.MENU Remote control Button

43 MENU Remote control Button

0B INPUT Remote control Button

10-19 Number Key 0-9 Remote control Button

4C - (Dash)/LIST Remote control Button

1A FLASHBK Remote control Button

09 MUTE Remote control Button

02 VOL + Remote control Button

03 VOL - Remote control Button

00 CH Remote control Button

01 CH Remote control Button

1E FAV/MARK Remote control Button

40 Remote control Button

41 Remote control Button

07 Remote control Button

06 Remote control Button

44 ENTER Remote control Button

28 RETURN Remote control Button

95 ENERGY SAVING Remote control Button

7E SIMPLINK Remote control Button

AA INFO Remote control Button

30 AV MODE Remote control Button

72 RED Remote control Button

71 GREEN (

) Remote control Button

63 YELLOW (

) Remote control Button

61 BLUE (

l l

) Remote control Button

Remote control Button

D6 TV Discrete IR Code

(TV Input Selection)

C4 POWER ON Discrete IR Code

(Only Power On)

C5 POWER OFF Discrete IR Code

(Only Power Off)

5A AV1 Discrete IR Code

(AV1 Input Selection)

D0 AV2 Discrete IR Code

(AV2 Input Selection)

BF COMPONENT1 Discrete IR Code

(Component1 Input Selection)

D4 COMPONENT2 Discrete IR Code

(Component2 Input Selection)

D5 RGB-PC Discrete IR Code

(RGB-PC Input Selection)

CE HDMI1 Discrete IR Code

(HDMI1 Input Selection)

CC HDMI2 Discrete IR Code

(HDMI2 Input Selection)

E9 HDMI3 Discrete IR Code

(HDMI3 Input Selection)

DA HDMI4 Discrete IR Code

(HDMI4 Input Selection)

76 Ratio 4:3 Discrete IR Code

(Only 4:3 Mode)

77 Ratio 16:9 Discrete IR Code

(Only 16:9 Mode)

AF Ratio Zoom Discrete IR Code

(Only Zoom Mode)

APPENDIX

118

OPEN SOURCE LICENSE

This feature is not available for all models.

APPENDIX

Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.

Preamble

The licenses for most software are designed to take away your freedom to share and change it. By contrast, the GNU General Public License is intended to guarantee your freedom to share and change free software - to make sure the software is free for all its users. This General Public License applies to most of the Free Software Foundation's software and to any other program whose authors commit to using it. (Some other free software foundation software is covered by the GNU Lesser General Public License instead.) You can apply it to your programs, too.

When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new free programs; and that you know you can do these things.

To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you to surrender the rights. These restrictions translate to certain responsibilities for you if you distribute copies of the software, or if you modify it.

For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the recipients all the rights that you have. You must make sure that they, too, receive or can get the source code. And you must show them these terms so they know their rights.

We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives you legal permission to copy, distribute and/or modify the software.

Also, for each author's protection and ours, we want to make certain that everyone understands that there is no warranty for this free software. If the software is modified by someone else and passed on, we want its recipients to know that what they have is not the original, so that any problems introduced by others will not reflect on the original authors' reputations.

Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that redistributors of a free program will individually obtain patent licenses, in effect making

the program proprietary. To prevent this, we have made it clear that any patent must be licensed for everyone's free use or not licensed at all.

The precise terms and conditions for copying, distribution and modification follow.

GNU GENERAL PUBLIC LICENSE TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

0. This license applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License. The "Program", below, refers to any such program or work, and a "work based on the Program" means either the Program or any derivative work under copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or with modifications and/or translated into another language. (Hereinafter, translation is included without limitation in the term "modification".) Each licensee is addressed as "you".

Activities other than copying, distribution and modification are not covered by this license; they are outside its scope. The act of running the Program is not restricted, and the output from the program is covered only if its contents constitute a work based on the program (independent of having been made by running the program). Whether that is true depends on what the program does.

1. You may copy and distribute verbatim copies of the program's source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this license and to the absence of any warranty; and give any other recipients of the program a copy of this license along with the Program.

You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in exchange for a fee.

2. You may modify your copy or copies of the program or any portion of it, thus forming a work based on the Program, and copy and distribute such modifications or work under the terms of section 1 above, provided that you also meet all of these conditions:

a) You must cause the modified files to carry prominent

notices stating that you changed the files and the date of any change.

GNU GENERAL PUBLIC LICENSE

Version 2, June 1991

APPENDIX

119

b) You must cause any work that you distribute or publish,

that in whole or in part contains or is derived from the Program or any part there of, to be licensed as a whole at no charge to all third parties under the terms of this license.

c) If the modified program normally reads commands interac-

tively when run, you must cause it, when started running for such interactive use in the most ordinary way, to print or display an announcement including an appropriate copyright notice and a notice that there is no warranty (or else, saying that you provide a warranty) and that users may redistribute the program under these conditions, and telling the user how to view a copy of this license. (Exception: if the Program itself is interactive but does not normally print such an announcement, your work based on the Program is not required to print an announcement.)

These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived from the Program, and can be reasonably considered independent and separate works in themselves, then this license, and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute the same sections as part of a whole which is a work based on the Program, the distribution of the whole must be on the terms of this license, whose permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.

Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the program.

In addition, mere aggregation of another work not based on the program with the Program (or with a work based on the program) on a volume of a storage or distribution medium does not bring the other work under the scope of this license.

3. You may copy and distribute the program (or a work based on it, under section 2) in object code or executable form under the terms of sections 1 and 2 above provided that you also do one of the following: a) Accompany it with the complete corresponding machine-

readable source code, which must be distributed under the terms of sections 1 and 2 above on a medium customarily used for software interchange; or,

b) Accompany it with a written offer, valid for at least three

years, to give any third party, for a charge no more than your cost of physically performing source distribution, a complete machine-readable copy of the corresponding source code, to be distributed under the terms of sections 1 and 2 above on a medium customarily used for software interchange; or,

c) Accompany it with the information you received as to the

offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in object code or executable form with such an offer, in accord with Subsection b above.)

The source code for a work means the preferred form of the work for making modifications to it. For an executable work, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the executable. However, as a special exception, the source code distributed need not include anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself accompanies the executable.

If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code.

4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this license. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will automatically terminate your rights under this license. However, parties who have received copies, or rights, from you under this license will not have their licenses terminated so long as such parties remain in full compliance.

5. You are not required to accept this license, since you have not signed it. However, nothing else grants you permission to modify or distribute the Program or its derivative works. These actions are prohibited by law if you do not accept this license. Therefore, by modifying or distributing the program (or any work based on the program), you indicate your acceptance of this license to do so, and all its terms and conditions for copying, distributing or modifying the program or works based on it.

6. Each time you redistribute the program (or any work based on the Program), the recipient automatically receives a license from the original licensor to copy, distribute or modify the Program subject to these terms and conditions. You may not impose any further restrictions on the recipients' exercise of the rights granted herein. You are not responsible for enforcing compliance by third parties to this license.

APPENDIX

120

APPENDIX

7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this license, they do not excuse you from the conditions of this license. If you cannot distribute so as to satisfy simultaneously your obligations under this license and any other pertinent obligations, then as a consequence you may not distribute the program at all. For example, if a patent license would not permit royalty-free redistribution of the program by all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this license would be to refrain entirely from distribution of the program.

If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply and the section as a whole is intended to apply in other circumstances.

It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free software distribution system, which is implemented by public license practices. Many people have made generous contributions to the wide range of software distributed through that system in reliance on consistent application of that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other system and a licensee cannot impose that choice.

This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this license.

8. If the distribution and/or use of the program is restricted in certain countries either by patents or by copyrighted interfaces, the original copyright holder who places the program under this license may add an explicit geographical distribution limitation excluding those countries, so that distribution is permitted only in or among countries not thus excluded. In such case, this license incorporates the limitation as if written in the body of this license.

9. The Free Software Foundation may publish revised and/or new versions of the General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns.

Each version is given a distinguishing version number. If the program specifies a version number of this license which applies to it and "any later version", you have the option of following the terms and conditions either of that version or of

any later version published by the Free Software Foundation. If the program does not specify a version number of this license, you may choose any version ever published by the Free Software Foundation.

10.If you wish to incorporate parts of the program into other free programs whose distribution conditions are different, write to the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the sharing and reuse of software generally.

NO WARRANTY

11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

12.IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

APPENDIX

121

END OF TERMS AND CONDITIONS

How to apply these terms to your new programs

If you develop a new program, and you want it to be of the greatest possible use to the public, the best way to achieve this is to make it free software which everyone can redistribute and change under these terms.

To do so, attach the following notices to the program. It is safest to attach them to the start of each source file to most effectively convey the exclusion of warranty; and each file should have at least the "copyright" line and a pointer to where the full notice is found.

one line to give the program's name and a brief idea of what it does. Copyright (C) <year> <name of author>

This program is free software; you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation; either version 2 of the license, or (at your option) any later version.

This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details.

You should have received a copy of the GNU General Public License along with this program; if not, write to the Free Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA.

Also add information on how to contact you by electronic and paper mail.

If the program is interactive, make it output a short notice like this when it starts in an interactive mode:

Gnomovision version 69, Copyright (C) year name of author Gnomovision comes with ABSOLUTELY NO WARRANTY; for details type ‘show w’. This is free software, and you are welcome to redistribute it under certain conditions; type ‘show c’ for details.

The hypothetical commands ‘show w’ and ‘show c’ should show the appropriate parts of the General Public License. Of course, the commands you use may be called something other than ‘show w’ and ‘show c’; they could even be mouse-clicks or menu items-whatever suits your program.

You should also get your employer (if you work as a programmer) or your school, if any, to sign a “copyright disclaimer” for the program, if necessary. Here is a sample; alter the names:

Yoyodyne, Inc., hereby disclaims all copyright interest in the program ‘Gnomovision’ (which makes passes at compilers) written by James Hacker.

signature of Ty Coon, 1 April 1989 Ty Coon, President of Vice

This General Public License does not permit incorporating your program into proprietary programs. If your program is a subroutine library, you may consider it more useful to permit linking proprietary applications with the library. If this is what you want to do, use the GNU Lesser General Public License instead of this license.

APPENDIX

122

APPENDIX

Copyright (C) 1991, 1999 Free Software Foundation, Inc. 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.

[This is the first released version of the Lesser GPL. It also counts as the successor of the GNU Library Public License, version 2, hence the version number 2.1.]

Preamble

The licenses for most software are designed to take away your freedom to share and change it. By contrast, the GNU General Public Licenses are intended to guarantee your freedom to share and change free software - to make sure the software is free for all its users.

This license, the Lesser General Public License, applies to some specially designated software packages - typically libraries - of the Free Software Foundation and other authors who decide to use it. You can use it too, but we suggest you first think carefully about whether this license or the ordinary General Public License is the better strategy to use in any particular case, based on the explanations below.

When we speak of free software, we are referring to freedom of use, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish); that you receive source code or can get it if you want it; that you can change the software and use pieces of it in new free programs; and that you are informed that you can do these things.

To protect your rights, we need to make restrictions that forbid distributors to deny you these rights or to ask you to surrender these rights. These restrictions translate to certain responsibilities for you if you distribute copies of the library or if you modify it.

For example, if you distribute copies of the library, whether gratis or for a fee, you must give the recipients all the rights that we gave you. You must make sure that they, too, receive or can get the source code. If you link other code with the library, you must provide complete object files to the recipients, so that they can relink them with the library after making changes to the library and recompiling it. And you must show them these terms so they know their rights.

We protect your rights with a two-step method: (1) we copyright the library, and (2) we offer you this license, which gives you legal permission to copy, distribute and/or modify the library.

To protect each distributor, we want to make it very clear that there is no warranty for the free library. Also, if the library is modified by someone else and passed on, the recipients should know that what they have is not the original version, so that the original author's reputation will not be affected by problems that might be introduced by others.

Finally, software patents pose a constant threat to the existence of any free program. We wish to make sure that a company cannot effectively restrict the users of a free program by obtaining a restrictive license from a patent holder. Therefore, we insist that any patent license obtained for a version of the library must be consistent with the full freedom of use specified in this license.

Most GNU software, including some libraries, is covered by the ordinary GNU General Public License. This license, the GNU Lesser General Public License, applies to certain designated libraries, and is quite different from the ordinary General Public License. We use this license for certain libraries in order to permit linking those libraries into non-free programs.

When a program is linked with a library, whether statically or using a shared library, the combination of the two is legally speaking a combined work, a derivative of the original library. The ordinary General Public License therefore permits such linking only if the entire combination fits its criteria of freedom. The Lesser General Public License permits more lax criteria for linking other code with the library.

We call this license the "Lesser" General Public License because it does Less to protect the user's freedom than the ordinary General Public License. It also provides other free software developers Less of an advantage over competing non-free programs. These disadvantages are the reason we use the ordinary General Public License for many libraries. However, the Lesser license provides advantages in certain special circumstances.

For example, on rare occasions, there may be a special need to encourage the widest possible use of a certain library, so that it becomes a de-facto standard. To achieve this, non-free programs must be allowed to use the library. A more frequent case is that a free library does the same job as widely used non-free libraries. In this case, there is little to gain by limiting the free library to free software only, so we use the Lesser General Public License.

In other cases, permission to use a particular library in non-free programs enables a greater number of people to use a large body of free software. For example, permission to use the GNU C Library in non-free programs enables many more people to use the whole GNU operating system, as well as its variant, the GNU/Linux operating system.

GNU LESSER GENERAL PUBLIC LICENSE

Version 2.1, February 1999

APPENDIX

123

Although the Lesser General Public License is Less protective of the users' freedom, it does ensure that the user of a program that is linked with the Library has the freedom and the wherewithal to run that program using a modified version of the Library.

The precise terms and conditions for copying, distribution and modification follow. Pay close attention to the difference between a "work based on the library" and a "work that uses the library". The former contains code derived from the library, whereas the latter must be combined with the library in order to run.

GNU LESSER GENERAL PUBLIC LICENSE TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

0. This license agreement applies to any software library or other program which contains a notice placed by the copyright holder or other authorized party saying it may be distributed under the terms of this Lesser General Public License (also called “this license”). Each license is addressed as "you".

A “library” means a collection of software functions and/or data prepared so as to be conveniently linked with application programs (which use some of those functions and data) to form executables.

The “Library”, below, refers to any such software library or work which has been distributed under these terms. A “work based on the Library” means either the Library or any derivative work under copyright law: that is to say, a work containing the library or a portion of it, either verbatim or with modifications and/or translated straightforwardly into another language. (Hereinafter, translation is included without limitation in the term “modification”.)

“Source code” for a work means the preferred form of the work for making modifications to it. For a library, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the library.

Activities other than copying, distribution and modification are not covered by this license; they are outside its scope. The act of running a program using the Library is not restricted, and output from such a program is covered only if its contents constitute a work based on the library (independent of the use of the Library in a tool for writing it). Whether that is true depends on what the library does and what the program that uses the library does.

1. You may copy and distribute verbatim copies of the library's complete source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on

each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this license and to the absence of any warranty; and distribute a copy of this license along with the Library.

You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in exchange for a fee.

2. You may modify your copy or copies of the Library or any portion of it, thus forming a work based on the Library, and copy and distribute such modifications or work under the terms of section 1 above, provided that you also meet all of these conditions: a) The modified work must itself be a software library. b) You must cause the files modified to carry prominent

notices stating that you changed the files and the date of any change.

c) You must cause the whole of the work to be licensed at no

charge to all third parties under the terms of this license.

d) If a facility in the modified Library refers to a function or a

table of data to be supplied by an application program that uses the facility, other than as an argument passed when the facility is invoked, then you must make a good faith effort to ensure that, in the event an application does not supply such function or table, the facility still operates, and performs whatever part of its purpose remains meaningful.

(For example, a function in a library to compute square roots has a purpose that is entirely well-defined independent of the application. Therefore, Subsection 2d requires that any application-supplied function or table used by this function must be optional: if the application does not supply it, the square root function must still compute square roots.)

These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived from the library, and can be reasonably considered independent and separate works in themselves, then this license, and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute the same sections as part of a whole which is a work based on the library, the distribution of the whole must be on the terms of this license, whose permissions for other licenses extend to the entire whole, and thus to each and every part regardless of who wrote it. Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the library.

In addition, mere aggregation of another work not based on the library with the library (or with a work based on the library) on a volume of a storage or distribution medium does not bring the other work under the scope of this license.

APPENDIX

124

APPENDIX

3. You may opt to apply the terms of the ordinary GNU General Public License instead of this License to a given copy of the Library. To do this, you must alter all the notices that refer to this License, so that they refer to the ordinary GNU General Public License, version 2, instead of to this License. (If a newer version than version 2 of the ordinary GNU General Public License has appeared, then you can specify that version instead if you wish.) Do not make any other change in these notices. Once this change is made in a given copy, it is irreversible for that copy, so the ordinary GNU General Public License applies to all subsequent copies and derivative works made from that copy. This option is useful when you wish to copy part of the code of the library into a program that is not a library.

4. You may copy and distribute the library (or a portion or derivative of it, under Section 2) in object code or executable form under the terms of Sections 1 and 2 above provided that you accompany it with the complete corresponding machinereadable source code, which must be distributed under the terms of sections 1 and 2 above on a medium customarily used for software interchange. If distribution of object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place satisfies the requirement to distribute the source code, even though third parties are not compelled to copy the source along with the object code.

5. A program that contains no derivative of any portion of the Library, but is designed to work with the Library by being compiled or linked with it, is called a “work that uses the Library”. Such a work, in isolation, is not a derivative work of the Library, and therefore falls outside the scope of this license.

However, linking a “work that uses the library” with the Library creates an executable that is a derivative of the Library (because it contains portions of the library), rather than a “work that uses the library”. The executable is therefore covered by this license. Section 6 states terms for distribution of such executable.

When a “work that uses the library” uses material from a header file that is part of the library, the object code for the work may be a derivative work of the library even though the source code is not. Whether this is true is especially significant if the work can be linked without the library, or if the work is itself a library. The threshold for this to be true is not precisely defined by law.

If such an object file uses only numerical parameters, data structure layouts and accessories, and small macros and small inline functions (ten lines or less in length), then the use of

the object file is unrestricted, regardless of whether it is legally a derivative work. (Executable containing this object code plus portions of the library will still fall under Section 6.)

Otherwise, if the work is a derivative of the library, you may distribute the object code for the work under the terms of Section 6. Any executable containing that work also fall under Section 6, whether or not they are linked directly with the library itself.

6. As an exception to the sections above, you may also combine or link a "work that uses the library" with the library to produce a work containing portions of the library, and distribute that work under terms of your choice, provided that the terms permit modification of the work for the customer's own use and reverse engineering for debugging such modifications.

You must give prominent notice with each copy of the work that the library is used in it and that the Library and its use are covered by this license. You must supply a copy of this license. If the work during execution displays copyright notices, you must include the copyright notice for the library among them, as well as a reference directing the user to the copy of this license. Also, you must do one of these things:

a) Accompany the work with the complete corresponding

machine-readable source code for the library including whatever changes were used in the work (which must be distributed under Sections 1 and 2 above); and, if the work is an executable linked with the Library, with the complete machine-readable “work that uses the Library”, as object code and/or source code, so that the user can modify the library and then relink to produce a modified executable containing the modified library. (It is understood that the user who changes the contents of definitions files in the library will not necessarily be able to recompile the application to use the modified definitions.)

b) Use a suitable shared library mechanism for linking with the

library. A suitable mechanism is one that (1) uses at run time a copy of the library already present on the user’s computer system, rather than copying library functions into the executable, and (2) will operate properly with a modified version of the library, if the user installs one, as long as the modified version is interface-compatible with the version that the work was made with.

c) Accompany the work with a written offer, valid for at least

three years, to give the same user the materials specified in Subsection 6, above, for a charge no more than the cost of performing this distribution.

d) If distribution of the work is made by offering access to

copy from a designated place, offer equivalent access to copy the above specified materials from the same place.

e) Verify that the user has already received a copy of these

materials or that you have already sent this user a copy.

APPENDIX

125

For an executable, the required form of the "work that uses the library" must include any data and utility programs needed for reproducing the executable from it. However, as a special exception, the materials to be distributed need not include anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself accompanies the executable.

It may happen that this requirement contradicts the license restrictions of other proprietary libraries that do not normally accompany the operating system. Such a contradiction means you cannot use both them and the library together in an executable that you distribute.

7. You may place library facilities that are a work based on the library side-by-side in a single library together with other library facilities not covered by this license, and distribute such a combined library, provided that the separate distribution of the work based on the Library and of the other library facilities is otherwise permitted, and provided that you do these two things:

a) Accompany the combined library with a copy of the same

work based on the Library, uncombined with any other library facilities. This must be distributed under the terms of the sections above.

b) Give prominent notice with the combined library of the

fact that part of it is a work based on the library, and explaining where to find the accompanying uncombined form of the same work.

8. You may not copy, modify, sublicense, link with, or distribute the library except as expressly provided under this license. Any attempt otherwise to copy, modify, sublicense, link with, or distribute the library is void, and will automatically terminate your rights under this license. However, parties who have received copies, or rights, from you under this license will not have their licenses terminated so long as such parties remain in full compliance.

9. You are not required to accept this license, since you have not signed it. However, nothing else grants you permission to modify or distribute the library or its derivative works. These actions are prohibited by law if you do not accept this license. Therefore, by modifying or distributing the library (or any work based on the library), you indicate your acceptance of this license to do so, and all its terms and conditions for copying, distributing or modifying the library or works based on it.

10.Each time you redistribute the library (or any work based on the Library), the recipient automatically receives a license from the original licensor to copy, distribute, link with or modify the library subject to these terms and conditions. You may not impose any further restrictions on the recipients' exercise

of the rights granted herein. You are not responsible for enforcing compliance by third parties with this license.

11. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this license, they do not excuse you from the conditions of this license. If you cannot distribute so as to satisfy simultaneously your obligations under this license and any other pertinent obligations, then as a consequence you may not distribute the library at all. For example, if a patent license would not permit royalty-free redistribution of the library by all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this license would be to refrain entirely from distribution of the library. If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply, and the section as a whole is intended to apply in other circumstances. It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free software distribution system which is implemented by public license practices. Many people have made generous contributions to the wide range of software distributed through that system in reliance on consistent application of that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other system and a license cannot impose that choice. This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this license.

12.If the distribution and/or use of the library is restricted in certain countries either by patents or by copyrighted interfaces, the original copyright holder who places the library under this license may add an explicit geographical distribution limitation excluding those countries, so that distribution is permitted only in or among countries not thus excluded. In such case, this license incorporates the limitation as if written in the body of this license.

13.The Free Software Foundation may publish revised and/or new versions of the Lesser General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns. Each version is given a distinguishing version number. If the library specifies a version number of this license which applies to it and “any later version”, you have the option of following the terms and conditions either of that version or of any later version published by the Free Software Foundation.

APPENDIX

126

APPENDIX

If the library does not specify a license version number, you may choose any version ever published by the Free Software Foundation.

14.If you wish to incorporate parts of the library into other free programs whose distribution conditions are incompatible with these, write to the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the sharing and reuse of software generally.

NO WARRANTY

15.BECAUSE THE LIBRARY IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE LIBRARY, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE LIBRARY "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE LIBRARY IS WITH YOU. SHOULD THE LIBRARY PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

16.IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE LIBRARY AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE LIBRARY (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE LIBRARY TO OPERATE WITH ANY OTHER SOFTWARE), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

END OF TERMS AND CONDITIONS

How to apply these terms to your new libraries

If you develop a new library, and you want it to be of the greatest possible use to the public, we recommend making it free software that everyone can redistribute and change. You can do so by permitting redistribution under these terms (or, alternatively, under the terms of the ordinary General Public License).

To apply these terms, attach the following notices to the library. It is safest to attach them to the start of each source file to most effectively convey the exclusion of warranty; and each file should have at least the “copyright” line and a pointer to where the full notice is found.

one line to give the library's name and a brief idea of what it does. Copyright (C) <year> <name of author>

This library is free software; you can redistribute it and/or modify it under the terms of the GNU Lesser General Public License as published by the Free Software Foundation; either version 2.1 of the license, or (at your option) any later version.

This library is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU Lesser General Public License for more details.

You should have received a copy of the GNU Lesser General Public License along with this library; if not, write to the Free Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA

Also add information on how to contact you by electronic and paper mail.

You should also get your employer (if you work as a programmer) or your school, if any, to sign a “copyright disclaimer” for the library, if necessary. Here is a sample; alter the names:

Yoyodyne, Inc., hereby disclaims all copyright interest in the library ‘Frob’ (a library for tweaking knobs) written by James Random Hacker.

signature of Ty Coon, 1 April 1990 Ty Coon, President of Vice

APPENDIX

127

1.Definitions.

1.0.1. “Commercial use” means distribution or otherwise making the covered code available to a third party.

1.1. “Contributor” means each entity that creates or contributes to the creation of modifications.

1.2. “Contributor version” means the combination of the original code, prior modifications used by a contributor, and the modifications made by that particular contributor.

1.3. “Covered code” means the original code or modifications or the combination of the original code and modifications, in each case including portions thereof.

1.4. “Electronic distribution mechanism” means a mechanism generally accepted in the software development community for the electronic transfer of data.

1.5. “Executable” means covered code in any form other than source code.

1.6. “Initial developer” means the individual or entity identified as the initial Developer in the Source Code notice required by exhibit A.

1.7. “Larger work” means a work which combines covered code or portions thereof with code not governed by the terms of this License.

1.8. “License” means this document.

1.8.1. “Licensable” means having the right to grant, to the maximum extent possible, whether at the time of the initial grant or subsequently acquired, any and all of the rights conveyed herein.

1.9. “Modifications” means any addition to or deletion from the substance or structure of either the original code or any previous modifications. When covered code is released as a series of files, a modification is:

A. Any addition to or deletion from the contents of a file containing original code or previous modifications.

B. Any new file that contains any part of the original code or previous modifications.

1.10. “Original code” means source code of computer software

code which is described in the source code notice required by exhibit as original code, and which, at the time of its release under this license is not already covered code governed by this license.

1.10.1.

“Patent claims” means any patent claim(s), now owned or hereafter acquired, including without limitation, method, process, and apparatus claims, in any patent licensable by grantor.

1.11. “Source code” means the preferred form of the covered code for making modifications to it, including all modules it contains, plus any associated interface definition files, scripts used to control compilation and installation of an executable, or source code differential comparisons against either the original code or another well known, available covered code of the contributor's choice. The source code can be in a compressed or archival form, provided the appropriate decompression or de-archiving software is widely available for no charge.

1.12. “You” (or “Your”) means an individual or a legal entity exercising rights under, and complying with all of the terms of, this license or a future version of this license issued under section 6.1. For legal entities, “You” includes any entity which controls, is controlled by, or is under common control with You. For purposes of this definition, “control” means (a) the power, direct or indirect, to cause the direction or management of such entity, whether by contract or otherwise, or (b) ownership of more than fifty percent (50%) of the outstanding shares or beneficial ownership of such entity.

2. Source Code License.

2.1. The initial developer grant. The initial developer hereby grants You a world-wide, royalty-free, non-exclusive license, subject to third party intellectual property claims:

a) under intellectual property rights (other than patent or

trademark) licensable by initial developer to use, reproduce, modify, display, perform, sublicense and distribute the original code (or portions thereof) with or without modifications, and/or as part of a larger work; and

(b) under patents claims infringed by the making, using or

selling of original code, to make, have made, use, practice, sell, and offer for sale, and/or otherwise dispose of the original code (or portions there of).

MOZILLA PUBLIC LICENSE

Version 1.1

---------------

APPENDIX

128

APPENDIX

effective on the date Initial developer first distributes original code under the terms of this license.

(d) Notwithstanding section 2.1(b) above, no patent

license is granted: 1) for code that You delete from the original Code; 2) separate from the original code; or

3) for infringements caused by: i) the modification of the original code or ii) the combination of the original code with other software or devices.

2.2. Contributor Grant. Subject to third party intellectual property claims, each contributor hereby grants You a world-wide, royalty-free, non-exclusive license

(a) under intellectual property rights (other than patent

or trademark) licensable by contributor, to use, reproduce, modify, display, perform, sublicense and distribute the modifications created by such contributor (or portions thereof) either on an unmodified basis, with other modifications, as covered code and/or as part of a larger work; and

(b) under patent claims infringed by the making, using, or

selling of modifications made by that contributor either alone and/or in combination with its contributor version (or portions of such combination), to make, use, sell, offer for sale, have made, and/or otherwise dispose of: 1) modifications made by that contributor (or portions thereof); and 2) the combination of modifications made by that contributor with its contributor version (or portions of such combination).

effective on the date contributor first makes commercial use of the covered code.

(d) Notwithstanding section 2.2(b) above, no patent

license is granted: 1) for any code that contributor has deleted from the contributor version; 2) separate from the contributor version; 3) for infringements caused by: i) third party modifications of contributor version or ii) the combination of modifications made by that contributor with other software (except as part of the contributor version) or other devices; or 4) under patent claims infringed by covered code in the absence of modifications made by that contributor.

3. Distribution Obligations.

3.1. Application of license. The modifications which You create or to which you contribute are governed by the terms of this license, including without limitation section 2.2. The source code version of covered code may be distributed only under the terms of this license or a future version of this license released under section 6.1, and you must include a copy of this license with every copy of the source code you distribute.

You may not offer or impose any terms on any source code version that alters or restricts the applicable version of this license or the recipients' rights hereunder. However, you may include an additional document offering the additional rights described in section 3.5.

3.2. Availability of source code. Any modification which you create or to which you contribute must be made available in source code form under the terms of this license either on the same media as an executable version or via an accepted electronic distribution mechanism to anyone to whom you made an executable version available; and if made available via electronic distribution mechanism, must remain available for at least twelve (12) months after the date it initially became available, or at least six (6) months after a subsequent version of that particular modification has been made available to such recipients. You are responsible for ensuring that the source code version remains available even if the electronic distribution mechanism is maintained by a third party.

3.3. Description of modifications. You must cause all covered code to which you contribute to contain a file documenting the changes You made to create that covered code and the date of any change. You must include a prominent statement that the modification is derived, directly or indirectly, from original code provided by the initial developer and including the name of the initial developer in (a) the source code, and (b) in any notice in an executable version or related documentation in which you describe the origin or ownership of the covered code.

3.4. Intellectual property matters (a) Third party claims. If contributor has knowledge that a license under a third party's intellectual property rights is required to exercise the rights granted by such contributor under sections 2.1 or 2.2, contributor must include a text file with the source code distribution titled "LEGAL" which describes the claim and the party making the claim in sufficient detail that a recipient will know whom to contact. If contributor obtains such knowledge after the modification is made available as described in section 3.2, contributor shall promptly modify the LEGAL file in all copies contributor makes available thereafter and shall take other steps (such as notifying appropriate mailing lists or newsgroups) reasonably calculated to inform those who received the covered code that new knowledge has been obtained. (b) Contributor APIs. If contributor's modifications include an application programming interface and contributor has knowledge of patent licenses which are reasonably necessary to implement that API, contributor must also include this information in the LEGAL file.

APPENDIX

129

(c) Representations. contributor represents that, except as disclosed pursuant to section 3.4(a) above, contributor believes that contributor's modifications are contributor's original creation(s) and/or contributor has sufficient rights to grant the rights conveyed by this license.

3.5. Required notices. You must duplicate the notice in exhibit A in each file of the source code. If it is not possible to put such notice in a particular source code file due to its structure, then You must include such notice in a location (such as a relevant directory) where a user would be likely to look for such a notice. If You created one or more modification(s), you may add your name as a contributor to the notice described in exhibit A. you must also duplicate this license in any documentation for the source code where You describe recipients' rights or ownership rights relating to covered code. You may choose to offer, and to charge a fee for, warranty, support, indemnity or liability obligations to one or more recipients of covered code. However, you may do so only on your own behalf, and not on behalf of the Initial developer or any contributor. You must make it absolutely clear than any such warranty, support, indemnity or liability obligation is offered by you alone, and You hereby agree to indemnify the Initial developer and every contributor for any liability incurred by the Initial developer or such contributor as a result of warranty, support, indemnity or liability terms you offer.

3.6. Distribution of executable versions. You may distribute covered code in executable form only if the requirements of section 3.1-3.5 have been met for that covered code, and if you include a notice stating that the source code version of the covered code is available under the terms of this license, including a description of how and where you have fulfilled the obligations of section

3.2. The notice must be conspicuously included in any notice in an executable version, related documentation or collateral in which you describe recipients' rights relating to the covered code. You may distribute the executable version of covered code or ownership rights under a license of your choice, which may contain terms different from this license, provided that you are in compliance with the terms of this license and that the license for the executable version does not attempt to limit or alter the recipient's rights in the source code version from the rights set forth in this license. If you distribute the executable version under a different license you must make it absolutely clear that any terms which differ from this license are offered by you alone, not by the Initial developer or any contributor. You hereby agree to indemnify the initial developer and every contributor for any liability incurred by the initial developer or such contributor as a result of any such terms You offer.

3.7. Larger works. You may create a larger work by combining covered code with other code not governed by the terms of this license and distribute the larger work as a single product. In such a case, you must make sure the requirements of this license are fulfilled for the covered code.

4. Inability to comply due to statute or regulation. If it is impossible for you to comply with any of the terms of this license with respect to some or all of the covered code due to statute, judicial order, or regulation then you must: (a) comply with the terms of this license to the maximum extent possible; and (b) describe the limitations and the code they affect. Such description must be included in the LEGAL file described in section 3.4 and must be included with all distributions of the source code. Except to the extent prohibited by statute or regulation, such description must be sufficiently detailed for a recipient of ordinary skill to be able to understand it.

5. Application of this license. This license applies to code to which the initial developer has attached the notice in exhibit A and to related covered code.

6. Versions of the license.

6.1. New versions. Netscape communications corporation (“Netscape”) may publish revised and/or new versions of the license from time to time. Each version will be given a distinguishing version number.

6.2. Effect of new versions. Once covered code has been published under a particular version of the license, you may always continue to use it under the terms of that version. You may also choose to use such covered code under the terms of any subsequent version of the license published by netscape. No one other than netscape has the right to modify the terms applicable to covered code created under this license.

6.3. Derivative works. If You create or use a modified version of this license (which you may only do in order to apply it to code which is not already covered code governed by this license), You must (a) rename Your license so that the phrases "Mozilla", "MOZILLAPL", "MOZPL", "Netscape", "MPL", "NPL" or any confusingly similar phrase do not appear in your license (except to note that your license differs from this license) and (b) otherwise make it clear that Your version of the license contains terms which differ from the Mozilla Public license and netscape Public License. (Filling in the name of the initial developer, original code or contributor in the notice described in exhibit A shall not of themselves be deemed to be modifications of this license.)

APPENDIX

130

APPENDIX

7. DISCLAIMER OF WARRANTY. COVERED CODE IS PROVIDED UNDER THIS LICENSE ON AN “AS IS” BASIS, WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, WARRANTIES THAT THE COVERED CODE IS FREE OF DEFECTS, MERCHANTABLE, FIT FOR A PARTICULAR PURPOSE OR NON-INFRINGING. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE COVERED CODE IS WITH YOU. SHOULD ANY COVERED CODE PROVE DEFECTIVE IN ANY RESPECT, YOU (NOT THE INITIAL DEVELOPER OR ANY OTHER CONTRIBUTOR) ASSUME THE COST OF ANY NECESSARY SERVICING, REPAIR OR CORRECTION. THIS DISCLAIMER OF WARRANTY CONSTITUTES AN ESSENTIAL PART OF THIS LICENSE. NO USE OF ANY COVERED CODE IS AUTHORIZED HEREUNDER EXCEPT UNDER THIS DISCLAIMER.

8. TERMINATION.

8.1. This license and the rights granted hereunder will terminate automatically if you fail to comply with terms herein and fail to cure such breach within 30 days of becoming aware of the breach. All sublicenses to the covered code which are properly granted shall survive any termination of this license. Provisions which, by their nature, must remain in effect beyond the termination of this license shall survive.

8.2. If you initiate litigation by asserting a patent infringement claim (excluding declatory judgment actions) against initial developer or a contributor (the initial developer or contributor against whom you file such action is referred to as “Participant”) alleging that:

(a) such participant's contributor version directly or indi-

rectly infringes any patent, then any and all rights granted by such participant to you under sections 2.1 and/or 2.2 of this license shall, upon 60 days notice from Participant terminate prospectively, unless if within 60 days after receipt of notice you either: (i) agree in writing to pay participant a mutually agreeable reasonable royalty for your past and future use of modifications made by such participant, or (ii) withdraw your litigation claim with respect to the contributor version against such participant. If within 60 days of notice, a reasonable royalty and payment arrangement are not mutually agreed upon in writing by the parties or the litigation claim is not withdrawn, the rights granted by participant to you under sections 2.1 and/or 2.2 automatically terminate at the expiration of the 60 day notice period specified above.

(b) any software, hardware, or device, other than such par-

ticipant's contributor Version, directly or indirectly infringes any patent, then any rights granted to You by

such participant under sections 2.1(b) and 2.2(b) are revoked effective as of the date you first made, used, sold, distributed, or had made, modifications made by that participant.

8.3. If you assert a patent infringement claim against participant alleging that such participant's contributor version directly or indirectly infringes any patent where such claim is resolved (such as by license or settlement) prior to the initiation of patent infringement litigation, then the reasonable value of the licenses granted by such participant under sections 2.1 or 2.2 shall be taken into account in determining the amount or value of any payment or license.

8.4. In the event of termination under sections 8.1 or 8.2 above, all end user license agreements (excluding distributors and resellers) which have been validly granted by you or any distributor hereunder prior to termination shall survive termination.

9. LIMITATION OF LIABILITY. UNDER NO CIRCUMSTANCES AND UNDER NO LEGAL THEORY, WHETHER TORT (INCLUDING NEGLIGENCE), CONTRACT, OR OTHERWISE, SHALL YOU, THE INITIAL DEVELOPER, ANY OTHER CONTRIBUTOR, OR ANY DISTRIBUTOR OF COVERED CODE,OR ANY SUPPLIER OF ANY OF SUCH PARTIES, BE LIABLE TO ANY PERSON FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY CHARACTER INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF GOODWILL, WORK STOPPAGE, COMPUTER FAILURE OR MALFUNCTION, OR ANY AND ALL OTHER COMMERCIAL DAMAGES OR LOSSES, EVEN IF SUCH PARTY SHALL HAVE BEEN INFORMED OF THE POSSIBILITY OF SUCH DAMAGES. THIS LIMITATION OF LIABILITY SHALL NOT APPLY TO LIABILITY FOR DEATH OR PERSONAL INJURY RESULTING FROM SUCH PARTY'S NEGLIGENCE TO THE EXTENT APPLICABLE LAW PROHIBITS SUCH LIMITATION. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THIS EXCLUSION AND LIMITATION MAY NOT APPLY TO YOU.

10. U.S. GOVERNMENT END USERS. The covered code is a "commercial item," as that term is defined in 48 C.F.R. 2.101 (Oct. 1995), consisting of "commercial computer software" and "commercial computer software documentation," as such terms are used in 48 C.F.R. 12.212 (Sept. 1995). Consistent with 48 C.F.R.

12.212 and 48 C.F.R. 227.7202-1 through 227.7202-4 (June 1995), all U.S. Government end users acquire covered code with only those rights set forth herein.

APPENDIX

131

11. MISCELLANEOUS. This license represents the complete agreement concerning subject matter hereof. If any provision of this license is held to be unenforceable, such provision shall be reformed only to the extent necessary to make it enforceable. This License shall be governed by California law provisions (except to the extent applicable law, if any, provides otherwise), excluding its conflict-of-law provisions. With respect to disputes in which at least one party is a citizen of, or an entity chartered or registered to do business in the united states of america, any litigation relating to this License shall be subject to the jurisdiction of the federal courts of the northern district of california, with venue lying in santa clara county, california, with the losing party responsible for costs, including without limitation, court costs and reasonable attorneys' fees and expenses. The application of the united nations convention on contracts for the International sale of goods is expressly excluded. Any law or regulation which provides that the language of a contract shall be construed against the drafter shall not apply to this license.

12. RESPONSIBILITY FOR CLAIMS. As between initial developer and the contributors, each party is responsible for claims and damages arising, directly or indirectly, out of its utilization of rights under this license and you agree to work with initial developer and contributors to distribute such responsibility on an equitable basis. Nothing herein is intended or shall be deemed to constitute any admission of liability.

13. MULTIPLE-LICENSED CODE. Initial developer may designate portions of the covered code as "Multiple-Licensed". "Multiple-Licensed" means that the initial developer permits you to utilize portions of the covered code under your choice of the NPL or the alternative licenses, if any, specified by the initial developer in the file described in exhibit A.

EXHIBIT A -Mozilla Public License.

The contents of this file are subject to the Mozilla Public License Version 1.1 (the “license”); you may not use this file except in compliance with the License. You may obtain a copy of the license at http://www.mozilla.org/MPL/

Software distributed under the license is distributed on an "AS IS" basis, WITHOUT WARRANTY OF ANY KIND, either express or implied. See the license for the specific language governing rights and limitations under the License.

The Original Code is ______________________________________.

Contributor(s): ______________________________________.

Alternatively, the contents of this file may be used under the terms of the _____ license (the "[___] License"), in which case the provisions of [______] license are applicable instead of those above. If you wish to allow use of your version of this file only under the terms of the [____] license and not to allow others to use your version of this file under the MPL, indicate your decision by deleting the provisions above and replace them with the notice and other provisions required by the [___] license. If you do not delete the provisions above, a recipient may use your version of this file under either the MPL or the [___] license."

NOTE: The text of this exhibit A may differ slightly from the text of the notices in the source code files of the original code. You should use the text of this exhibit A rather than the text found in the original code/source code for Your modifications.

LG Electronics USA EAX5296 Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
