INPUT LIST

Only these input signals which are connected to a TV can be activated and selected.

Input List

Antenna

Cable

AV1

AV2

Component1

1INPUT

ENTER

Antenna

Cable

AV1

AV2

Component1

Component2

HDMI4

HDMI3

HDMI2

HDMI1

RGB-PC

Except 26/32/37/42/47/52LG30/50, 42/50PG10/20

■You can also select the desired input source in the INPUT menu (Only 32/37/42/47/52LG50/60/70, 50/60PG60F).

INPUT

Move

Enter

Antenna

Cable

AV1

AV2

Component1

Component2

RGB-PC

HDMI1

E

■Antenna: Select it when watching the DTV/TV.

■Cable: Select it when watching the CADTV/CATV.

■AV 1-2: Select it when watching the VCR or external equipment.

■Component 1-2: Select it when using the DVD or the Digital set-top box depend on connector.

■RGB - PC: Select it when using PC depend on connector.

■HDMI1-4: Select it when using DVD, PC or Digital set-top box depend on connector.

CONTROL CHANNEL / TV WATCHING

51

WATCHING TV / CHANNEL CONTROL

INPUT LABEL

Sets a label to each input source which is not in use.

WATCHING	OPTION	Move	Enter
	Language	: English
	Input Label
	SIMPLINK	: On
	Key Lock	: Off
	Caption	: Off
TV	ISM Method
	Power Saving	: Level 0
/	Set ID	: 1
CONTROL CHANNEL		E

OPTION	Move	Enter
Language	: EnglishAV1		F	G
Input Label		AV2
SIMPLINK	: On	Component1
Key Lock	: Off	Component2
Caption	: Off
		RGB-PC
ISM Method
		HDMI1
Power Saving
	: Level 0
Set ID	: 1	HDMI2
	E	HDMI3
		HDMI4

Only for

Close 32/37/42/47/52LG60/70,

50/60PG60F

MENU

Select OPTION.

ENTER

ENTER

Select Input Label.

Select the source.

4

Select the label.

5

RETURN

Return to the previous menu.

MENU

Return to TV viewing

52

AV MODE

You can select the optimal images and sounds when connecting AV devices to external input.

Off		Cinema

	Game		Sport

AV MODE

Press the AV MODE button repeatedly to select the desired source.

ENTER

RETURN

Return to the previous menu.

MENU

Return to TV viewing

■If you select “Cinema” in AV mode, Cinema will be selected both for “PICTURE menu - Picture Mode” and “AUDIO menu - Sound Mode” respectively.

■If you select “Off” in AV mode, the picture and image which you initially set will be selected.

CONTROL CHANNEL / TV WATCHING

53

WATCHING TV / CHANNEL CONTROL

CONTROL CHANNEL / TV WATCHING

This function operates only with devices with the logo. Please check the logo.

This allows you to control and play other AV devices connected to the display through HDMI cable without additional cables and settings.

If you require the SIMPLINK menu, select “O n”.

SIMPLINK function is not supported by HDMI IN 4 input source.

OPTION	Move	Enter
Language	: English
Input Label
SIMPLINK	: On
Key Lock	: Off
Caption	: Off
ISM Method
Power Saving	: Level 0
Set ID	: 1
	E

	OPTION	Move	Enter
	Language	: English
	Input Label		Off
	SIMPLINK	: On
			On
	Key Lock	: Off
	Caption	: Off
	ISM Method
	Power Saving	: Level 0
	Set ID	: 1
		E

MENU

Select OPTION.

ENTER

Select SIMPLINK.

ENTER	Select On or Off.

4

RETURN

Return to the previous menu.

MENU

Return to TV viewing

! NOTE

G Connect the HDMI/DVI IN or HDMI IN terminal of the TV to the rear terminal (HDMI terminal) of the SIMPLINK device with the HDMI cable.

G After connecting the HDMI terminal for the home theater with the SIMPLINK function using the above method, connect the DIGITAL AUDIO OUT terminal on the back of the TV to the DIGITAL AUDIO IN terminal on the back of the SIMPLINK device with the OPTICAL cable.

G When you switch the Input source with the INPUT button on the remote control, you can stop the operation of device controlled by SIMPLINK.

G When you select or operate the media device with home theater function, the speaker automatically switches to home theater speaker (HT speaker).

G When you execute ‘PHOTO LIST, MUSIC LIST’ function during DVD playback included in home theater supported the SimpLink stops and the applicable function is executed after switching the input to TV. (This feature is not available for alll models).

54

SimpLink Functions

■ect Play: After connecting AV devices to the TV, you can directly control the devices and play media without additional settings.

■lect AV device: Enables you to select one of the AV devices connected to TV and play it.

■c playback: Control connected AV devices by pressing the , ENTER, G, A, l l, FF and GG buttons. (The Ô button does not provide such functions.) buttons for play, stop, pause, fast reverse, fast forward, chapter skip.

■wer off all devices: When you power off the TV, all connected devices are turned off.

■itch audio-out: Offers an easy way to switch audio-out.

■nc Power on: When you play the connected AV device, TV will automatically turn on.

(A	which is connected to the TV through a HDMI cable but does not support SimpLink, does not provide
this

Note: To operate SIMPLINK, the HDMI cable over 1.2 Version with *CEC function should be used. (*CEC: Consumer Electronics Control).

TV	SIMPLINK
		Display SIMPLINK menu.
	ENTER	Select the desired device.
	ENTER	Control connected AV devices.

SimpLink Menu

1	the previous TV
	channel regardless of the current mode.
2	DISC playback: Select and play discs.

of discs are conveniently displayed at the bottom of the screen.

3VCR playback: Control the connected VCR.

4 HDD Recordings playback: Control recordings stored in HDD.

5Audio Out to Home Theater speaker/Audio Out to TV: Select Home Theater speaker or TV speaker for Audio Out.

1

2

3

4

5

Selected

When no

When a

(displayed in bright color)

CONTROL CHANNEL / TV WATCHING

55

USB

■ This feature is only for 32/37/42/47/52LG50/60/70, 50/60PG60F.

ENTRY MODES

HOST MEDIA

When you connect a USB device, this screen is displayed, automatically.

In USB device, you can not add a new folder or delete the existing folder.

1 Connect the USB device to the USB IN jacks on the side of TV.

	• It doesn’t support USB HDD
	• This TV Supports on JPEG and MP3.
USB SERVUCE ONLY
I IN 3	Select the USB EJECT menu before removing the
2	USB device.
Select PHOTO LIST or MUSIC LIST	Q. MENU	Select USB Eject.

PHOTO LIST	MUSIC LIST
	ENTER
ENTER

Precautions when using the USB device

G Only a USB storage device is recognizable.

G If the USB storage device is connected through a USB hub, the device is not recognizable.

G A USB storage device using an automatic recognition program may not be recognized.

G A USB storage device which uses its own driver may not be recognized.

G In case of a card reader, up to four memory cards are concurrently recognizable.

G The recognition speed of a USB storage device may depend on each device.

G Please do not turn off the TV or unplug the USB device when the connected USB storage device is working. When such device is suddenly separated or unplugged, the stored files or the USB storage device may be damaged.

GPlease do not connect the USB storage device which was artificially maneuvered on the PC. The device may cause the product to malfunction or fail to be played. Never forget to use only a USB storage device which has normal music files or image files.

G Please use only a USB storage device which was formatted as a FAT32 file system provided with the Windows operating system. In case of a storage device formatted as a different utility program which is not supported by Windows, it may not be recognized.

G Please connect power to a USB storage device which requires an external power supply. If not, the device may not be recognized.

G Please connect a USB storage device with cable is offered by USB maker. If connected with cable is not offered by USB maker or an excessively long cable, the device may not be recognized.

G Some USB storage devices may not be supported or operated smoothly.

GIf the name of a folder or file is too long, it will not be displayed or recognized.

GPlease backup the important file because a data of USB device may be damaged. Data management is consumer's responsibility and in consequence the manufactures does not cover the product bearing data damage.

56

PHOTO LIST

It’s available to playback the photo file(*.jpg) in the USB device.

The On Screen Display may be different from your set. Images are an example to assist with the TV operation.

PHOTO (*.JPEG) supporting file

Baseline: width<=15360, height<=8640

•You can play JPEG files only.

•Only baseline scan is supported among JPEG.

•Non-supported files are displayed in the form of icon? Bitmap?.

2

	MENU	ENTER	ENTER	Select Photo List.
	Select USB.
			3	4	5
1
2		PHOTO LIST			USB Device
			Page 2/3	No Marked	Free Space 150MB
		OST
		My Father
	2		My Father	Mulan	Star
3			1
4		1366x768, 125KB
5	1	Upper
6		Navigate			Exit

6

HOST MEDIA

57

USB

Photo Selection and PopUp Menu

HOST MEDIA

PHOTO LIST			USB Device
	Page 2/3	No Marked	Free Space 150MB
OST
My Father
	My Father	Mulan	Star
1366x768, 125KB
Upper
Navigate	CH		Exit

PHOTO LIST Page 2/3			USB Device
	No Marked		Free Space 150MB
OST
GanSik
OST	Photo	X.Box
			1366x768, 125KB
			View
			Mark All
1366x768, 125KB			Delete
			Cancel
Upper
Navigate	CH		Exit

When you select a file (not folder), this PopUp menu is displayed.

G View: Display the selected item.

G Mark All: Mark all photos on the screen. G Unmark All: Deselect all marked photos. G Delete: Delete the selected photo item. G Cancel: Close the pop-up menu.

1
2	ENTER		Select the desired photos.
3	ENTER	Show the PopUp menu.
4		ENTER	Select the desired PopUp menu.

5 RETURN

•Use the CH button to navigation in the photo page.

•Use the FAV button to mark or unmark a photo. When one or more photos are marked, you can view individual photos or a slide show of the marked photos. If no photos are marked, you can view all photos individually or all photos in the folder in a slide show.

58

Set up the menu in Full-Sized Screen

You can change the settings to display photos stored on a USB device, on a full-sized screen.

Detailed operations are available on full-sized photo view screen.

PHOTO LIST			USB Device
	Page 2/3	No Marked	Free Space 150MB
OST
My Father
	My Father	Mulan	Star
1366x768, 125KB
Upper
Navigate	CH		Exit

PHOTO LIST Page 2/3			USB Device
	No Marked		Free Space 150MB
OST
GanSik
OST	Photo	X.Box	1366x768, 125KB
			View
			Mark All
1366x768, 125KB			Delete
			Cancel
Upper
Navigate	CH		Exit

1/17

Slideshow

BGM

Delete Option Hide

The aspect ratio of a photo may change the size of the photo displayed on the screen in full size.

1

2

ENTER

3

ENTER

4

5ENTER

Select the target folder or drive.

Select the desired photos.

show the PopUp menu.

Select View

The selected photo is displayed in full size.

• Use the CH button to navigation in the photo page.

HOST MEDIA

59

USB

1/17

	Slideshow	BGM	Delete Option Hide

HOST MEDIA

6	Select the Slideshow, BGM,	(Rotate),

ENTER	Delete, ption, or Hide.

• Use button to select the previous or next photo.

• Use button to select and control the menu on the full-sized screen.

G Slideshow : When no picture is selected, all photos in the current folder are displayed during slide show. When selected, the selected photos are displayed during slide show.

■ Set the time interval of the slide show in Option.

G BGM : Listen to music while viewing photos in full size.

■Set the BGM device and album in Option. G (Rotate) : Rotate photos.

■Rotates the photo 90°, 180°, 270°, 360° clockwise.

■A slide show continues for a maximum of 4 hours. After 4 hours, the slide show will end and go to TV

mode or external input mode.

GDelete : Delete photos.

GOption : Set values for Slide Speed and Music Folder.

Press F G to set the time interval between slides.

Slide Speed	Fast
Music Folder	Music
ENTER	Cancel

■Use button and ENTER button to set values. Then go to and press ENTER to save the settings.

■You cannot change Music Folder while BGM is playing.

G Hide : Hide the menu on the full-sized screen.

■To see the menu again on the full-sized screen, press ENTER button to display.

! NOTE

G If it is Progressive JPEG format, some photos may be not decorded.

60

MUSIC LIST

Purchased music files(*.MP3) may contain copyright restrictions. Playback of these files may not be supported by this model.

Music file on your USB device can be played by this unit.

The On Screen Display may be different from your TV. Images are an example to assist with the TV operation.

MUSIC(*.MP3) supporting file

Bitrate range 8? 40?Kbps ~ 320Kbps •Sampling rate

MPEG1 : 32000, 44100, 48000Hz

MPEG2 : 16000, 24000, 22050Hz

MPEG2.5 : 8000, 11025, 12000Hz

1

MENU	ENTER	ENTER	Select Music	List.
		3	4	5

1	file
2	If any album jacket

file exists, this jacket is displayed.

Current page/Total pages

2

Total number of marked musics

Usable USB memory

1

Corresponding buttons on the remote control

MUSIC LIST		USB Device
	Page 2/3 No Marked	Free Space 150MB
Music	Title	Play Time
	Upper

1:340, 120KB
Upper
Navigate	Exit

6

2While the music file is being played, the information section does not show the selected file, but the playing file name and the play time information at the bottom.

HOST MEDIA

61

Music Selection and PopUp Menu

As shown, up to 6 music titles are listed per page.

HOST MEDIA

MUSIC LIST		USB Device
	Page 2/3 No Marked	Free Space 150MB
Music	Title	Play Time
	Up Folder
1:340, 120KB
Upper
Navigate	CH	Exit

MUSIC LIST	Page 2/3	No Marked
Music	Title	Play Time
	Up Folder
		4395KB
		1Kbps
		Play
		Play
1:340, 120KB		Mark
		Delete
Upper		Cancel
Navigate	CH	Exit

G Play (During stop): Play the selected musics. Once a music finishes playing, the next selected one will be played. When there are no selected musics to play, the next one in the current folder will be played. If you go to a different folder and press the ENTER button, the current music in playback will stop.

G Play Marked : Play the selected musics. Once a music finishes playing, the next selected one will be played automatically.

G Stop Play (During playback) : Stop the playing musics.

G Play with Photo : Start playing the selected musics and then move to the Photo List.

G Mark All : Mark all musics in the folder. G Unmark All : Deselect all marked musics.

G Delete : Delete the selected musics. G Cancel : Close the pop-up menu.

1

Select the target folder or drive.

2

	ENTER		Select the desired musics.
3	ENTER	Show the PopUp menu.
4		ENTER	Select the desired PopUp menu.

RETURN	Return to TV viewing

•Use the CH button to navigation in the muisc page.

•Use FAV button to mark or unmark a music. When one or more music files are marked, the marked musics will be played in sequence. For example, if you want to listen to only one music repeatedly, just mark the music only and play it. If no music is marked, all the music in the folder will be played in sequence.

62

■If you don't press any button for a while during the playing, the play information box (as shown in the below) will float as a screen saver.

■The ‘Screen Saver’?

Screen saver is to prevent screen pixel damage due to an fixed image remaining on the screen for a extended period of time.

! NOTE

G When music is playing, is displayed in front of the music play time.

G A damaged or corrupted music does not play but displays 00:00 in playtime.

G A music downloaded from a paid service with copyright protection does not start but displays inappropriate information in playtime.

G If you press ENTER, A buttons, screen saver is stopped.

GThe PLAY(G), Pause(II), A buttons on the remote control are also available in this mode.

GIt’s not available to play MP3 file under 16Kbyte.

HOST

63

PICTURE CONTROL

PICTURE SIZE (ASPECT RATIO) CONTROL

This feature lets you choose the way an analog picture with a 4:3 aspect ratio is displayed on your TV. When you receive an analog picture with a 4:3 aspect ratio on your 16:9 TV, you need to specify how the picture is to be displayed.

■ RGB-PC input source use 4:3 or 16:9 aspect ratio.

! NOTE

G If a fixed image is displayed on the screen for a long time, the image may become imprinted on the screen and remain visible.

This phenomenon is common to all manufactures and in consequence the manufactures warranty does not cover the product bearing this phenomenon.

PICTURE	PICTURE		Move		Enter
	Aspect Ratio	: 16:9
	Picture Mode	: Standard
CONTROL		• Backlight	80
		• Tint	0	R	G
		• Contrast	90
		• Brightness	50
		• Sharpness	60
		• Color	60
		E

PICTURE		Move		Enter
Aspect Ratio	: 16:9
Picture Mode	: Standard
	• Backlight	80
	• Contrast	90		Set By Program
	• Brightness	50		4:3
	• Sharpness	60		16:9
	• Color	60		Zoom1
	• Tint	0	R	Zoom2 G
	E			Just Scan

MENU

ENTER

ENTER

RETURN

MENU

Select PICTURE.

■ You can also adjust Aspect Ratio in the Q-Menu.

Select Aspect Ratio.

Select the desired picture format.

Return to the previous menu.

Return to TV viewing

64

Set by program

Selects the proper picture proportion to match the source’s image.

(4:3 4:3)

(16:9 16:9)

4:3

Choose 4:3 when you want to view a picture with an original 4:3 aspect ratio.

16:9

Adjust the picture horizontally, in a linear proportion to fill the entire screen.

Zoom 1

Choose Zoom 1 when you want to view the picture without any alteration. However, the top and bottom portions of the picture will be cropped.

Zoom 2

Choose Zoom 2 when you want the picture to be

altered, both vertically extended and cropped.

The picture taking a halfway trade off between PICTURE alteration and screen coverage.

CONTROL

Just Scan

Following selection will lead to you view the picture of best quality without loss of original picture in high resolution image.

Notes: If there are noise in original picture, you can see the noise at the edge.

Just Scan operates only in DTV/CADTV (720p/1080i/1080p), HDMI-DTV, DVIDTV input source.

65

PICTURE CONTROL

CONTROL PICTURE

PRESET PICTURE SETTINGS

Picture Mode - Preset

Picture Mode adjusts the TV for the best picture appearance. Select the preset value in the Picture Mode menu based on the program category.

PICTURE		Move		Enter
Aspect Ratio	: 16:9
Picture Mode	: Standard
	• Backlight	80
	• Contrast	90
	• Brightness	50
	• Sharpness	60
	• Color	60
	• Tint	0	R	G
	E


Move

Enter

Aspect Ratio	: 16:9		Intelligent Sensor
Picture Mode	: Standard		Vivid
	• Backlight	80	Standard
	• Contrast	90	Cinema
	• Brightness	50	Sport
	• Sharpness	60	Game
	• Color	60	Expert1
	• Tint	0	R Expert2G
	E

MENU	Select PICTURE.
ENTER	Select Picture	Mode.

Select Intelligent Sensor (Only

ENTER

26/32/37/42/47/52LG50/60/70), Vivid, Standard, Cinema, Sport, or Game.

4

RETURN

Return to the previous menu.

MENU

Return to TV viewing

■Intelligent Sensor, Dynamic, Standard, Mild Settings are preset for the optimum picture quality at the factory and are not adjustable.

■When selecting Intelligent Sensor (Only 26/32/37/42/47/52LG50/60/70),

the most suitable picture is automatically adjusted according to the surrounding conditions.

■You can also adjust Picture Mode in the Q. Menu.

66

Color Tone - Preset

Choose one of three automatic color adjustments. Set to warm to enhance hotter colors such as red, or set to cool to see less intense colors with more blue.

To initialize values (reset to default settings), select the Cool option.

PICTURE	Move		Enter
E
• Brightness	50
• Sharpness	60
• Color	60
• Tint	0	R	G
• Advanced Control
• Reset
Screen (RGB-PC)
TruMotion Demo

PICTURE	Move		Enter
E
• Brightness	50	Color Temperature		F Medium	G
• Sharpness	60	Fresh Contrast		Off
• Color	60	Fresh Color		Off
• Tint	0	R	G	Auto
		Noise Reduction
• Advanced ControlGamma				Medium
• Reset		Black Level		Low
Screen (RGB-PC)
		Eye Care		Off
TruMotion Demo
		Film Mode		Off
		TruMotion		High
			Close

MENU

	Select PICTURE.
ENTER	Select Advanced	Control.

ENTER	Select Color	Temperature.

4

Select Cool, Medium, or Warm.

RETURN

Return to the previous menu.

MENU

Return to TV viewing

CONTROL PICTURE

67

PICTURE CONTROL

CONTROL PICTURE

MANUAL PICTURE ADJUSTMENT

Picture Mode - User Mode

Adjust the picture appearance to suit your preference and viewing situations. This feature is disable in “Picture Mode-Intelligent Sensor”.

PICTURE		Move		Enter
Aspect Ratio	: 16:9
Picture Mode	: Standard				E
	• Backlight	80		• Backlight	80	E	E
	• Contrast	90			E		Enter
	• Brightness	50
	• Sharpness	60
	• Color	60
	• Tint	0	R	G
	E

MENU

Select PICTURE.

ENTER	Select Picture Mode.
ENTER	Select Vivid, Standard, Cinema, Sport, or Game.
ENTER	Select Backlight (Only LCD TV), Contrast,
	Brightness, Sharpness, Color, or Tint.
ENTER	Make appropriate adjustments.

6

RETURN

Return to the previous menu.

MENU

Return to TV viewing

68

Picture Mode - Expert Control

By segmenting categories, Expert1 and Expert2 provide more categories which users can set as they see fit, offering the optimal picture quality for users.

PICTURE		Move		Enter
Aspect Ratio	: 16:9			Intelligent Sensor
Picture Mode	: Standard			Vivid
	• Backlight	80		Standard
	• Contrast	90		Cinema
	• Brightness	50		Sport
	• Sharpness	60		Game
	• Color	60		Expert1
	• Tint	0	R Expert2G
	E

PICTURE		Move	Enter
E
• Brightness	50Fresh Contrast			F	Off	G
• Sharpness	60Black Level				Low
• Color	60				Off
• Tint		Noise Reduction
		0 R	G
• Expert Control		Film Mode			Off
• Reset		Color Standard			SD
Screen (RGB-PC)		Gamma			Medium
TruMotion Demo		White Balance			2 Point
		• Red Gain			128
		• Green Gain			128
		• Blue Gain			128
		• Red Offset			64
			E

MENU	Select PICTURE.
ENTER	Select Picture	Mode.
ENTER	Select Expert1 or Expert2.
ENTER	Select Expert	Control.

ENTER	Select your desired menu option.
	Make appropriate adjustments.

7

RETURN

Return to the previous menu.

MENU

Return to TV viewing

CONTROL PICTURE

69

PICTURE CONTROL

PICTURE IMPROVEMENT TECHNOLOGY

Fresh Contrast: Optimizes the contrast automatically according to the brightness of the reflection.

Fresh Color: Adjusts the color of the reflection automatically to reproduce as close as possible natural colors. Noise Reduction: Removes interference up to the point where it does not damage the original picture. Gamma: High gamma values display whitish images and low gamma values display high contrast images.

		PICTURE	Move		Enter
		E
		• Brightness	50
		• Sharpness	60
	PICTURE	• Color	60
		• Tint	0	R	G
		• Advanced Control
		• Reset
		Screen (RGB-PC)
	CONTROL	TruMotion Demo

PICTURE	Move	Enter
	E

	• Brightness	50	Color Temperature						Medium
	• Sharpness	60	Fresh Contrast
								F	Off G
	• Color	60	Fresh Color
									Off
	• Tint	0	R			G
			Noise Reduction						Auto
	• Advanced Control Gamma
									Medium
	• Reset		Black Level
	Screen (RGB-PC)								Low
			Eye Care
	TruMotion Demo								Off
			Film Mode
									Off
			TruMotion
									High
							Close

MENU

Select PICTURE.

ENTER

ENTER

Select Advanced Control.

Select Fresh Contrast, Fresh Color,

Noise Reduction, or Gamma.

Select your desired options.

5

RETURN

Return to the previous menu.

MENU

Return to TV viewing

70

ADVANCED - BLACK (DARKNESS) LEVEL

Adjusting the contrast and the brightness of the screen using the black level of the screen. This feature operates only in AV1-2, Component, or HDMI1-3 (or 4) mode.

PICTURE	Move		Enter
E
• Brightness	50
• Sharpness	60
• Color	60
• Tint	0	R	G
• Advanced Control
• Reset
Screen (RGB-PC)
TruMotion Demo

PICTURE	Move	Enter
	E

	• Brightness	50	Color Temperature						Medium
			Fresh Contrast
	• Sharpness	60							Off
	• Color	60	Fresh Color
									Off
	• Tint	0	R			G
			Noise Reduction						Auto
	• Advanced Control Gamma
									Medium
	• Reset		Black Level
	Screen (RGB-PC)							F	Low G
			Eye Care
	TruMotion Demo								Off
			Film Mode
									Off
			TruMotion
									High
							Close

MENU

ENTER

ENTER

Select PICTURE.

Select Advanced Control.

Select Black Level.

■Low: The r:flection of the screen gets darker.

■High: The reflection of the screen gets brighter.

■Auto: Realizing the black level of the screen and set it to High or Low automatically.

4

Select Low or High.

5

RETURN

Return to the previous menu.

MENU

Return to TV viewing

CONTROL PICTURE

71

PICTURE CONTROL

ADVANCED - EYE CARE - Only LCD TV

It helps you adjust brightness when the screen is too bright to prevent dazzling.

CONTROL PICTURE

PICTURE	Move		Enter
E
• Brightness	50
• Sharpness	60
• Color	60
• Tint	0	R	G
• Advanced Control
• Reset
Screen (RGB-PC)
TruMotion Demo

PICTURE	Move	Enter
	E

• Brightness

50

Color Temperature

Medium

Fresh Contrast

• Sharpness

60

Off

• Color

60

Fresh Color

Off

• Tint

0

R

G

Noise Reduction

Auto

• Advanced Control

Gamma

Medium

• Reset

Black Level

Screen (RGB-PC)

Low

Eye Care

TruMotion Demo

F

Off G

Film Mode

Auto

TruMotion

High

Close

MENU	Select PICTURE.
ENTER	Select Advanced Control.
ENTER	Select Eye	Care.

4

Select O n or Off.

RETURN

Return to the previous menu.

MENU

Return to TV viewing

72

ADVANCED - FILM MODE

Set up the TV for the best picture appearance for viewing movies.

When you operate Film Mode (3:2 Pull-Down Mode or Cinema Correction Mode), the TV will adjust 24 fps video from movies to 30 fps video for display.

This feature operates only in TV (Analog TV/CATV, Digital DTV/CADTV), AV1, AV2, Component 480i/1080i, and HDMI 1080i mode.

PICTURE	Move		Enter
E
• Brightness	50
• Sharpness	60
• Color	60
• Tint	0	R	G
• Advanced Control
• Reset
Screen (RGB-PC)
TruMotion Demo

PICTURE	Move	Enter
	E

	• Brightness	50		Color Temperature				Medium
	• Sharpness	60
				Fresh Contrast				Off
	• Color	60		Fresh Color
								Off
	• Tint	0	R		G
	• Advanced Control			Noise Reduction				Auto
				Gamma
	• Reset							Medium
				Black Level
	Screen (RGB-PC)							Low
	TruMotion Demo			Eye Care				Off
				Film Mode			F	Off G
				TruMotion				High

Close

MENU	Select PICTURE.
ENTER	Select Advanced Control.
ENTER	Select Film Mode.

4

Select O n or Off.

RETURN

Return to the previous menu.

MENU

Return to TV viewing

CONTROL PICTURE

73

PICTURE CONTROL

ADVANCED - TRUMOTION - Only 32/37/42/47/52LG60/70

It is used for the best picture quality without any motion blur or judder when you enter a quick image or Film Source.

This feature is disable in RGB-PC, HDMI (PC) mode.

CONTROL PICTURE

PICTURE	Move		Enter
E
• Brightness	50
• Sharpness	60
• Color	60
• Tint	0	R	G
• Advanced Control
• Reset
Screen (RGB-PC)
TruMotion Demo

PICTURE	Move	Enter
	E

	• Brightness	50	Color Temperature						Medium
	• Sharpness	60
			Fresh Contrast						Off
	• Color	60	Fresh Color
									Off
	• Tint	0		R		G
			Noise Reduction						Auto
	• Advanced Control
	• Reset		Gamma						Medium
	Screen (RGB-PC)		Black Level						Low
			Eye Care
	TruMotion Demo								Off
			Film Mode						Auto
			TruMotion
								F	High G
							Close

MENU	Select PICTURE.
ENTER	Select Advanced Control.
ENTER	Select TruMotion.
4		■	Low: Set amount of film judder to low.
	Select Off, Low, or High.	■	High: Set amount of film judder to high.

RETURN

Return to the previous menu.

MENU

Return to TV viewing

74
