Installation
HDSTB Setup
-This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you do receive Digital signals from a digital set-top box or other digital external device, refer to the figure as shown below.
When connecting with D-sub 15 pin cable
REMOTE (RGB/DVI) CONTROL
2
1
1Connect the RGB output of the digital set-top box to the RGB IN (PC/DTV) ( 32/37/42LC2D Model)/ RGB (PC/DTV) (42PC3D/3DV/50PC3D Model) jack on the set.
2Connect the audio outputs of the set-top box to the AUDIO IN (RGB/DVI) ( 32/37/42LC2D Model) /AUDIO (RGB/DVI) (42PC3D/3DV/50PC3D Model) jack on the set.
on the digital set-top box. (Refer to the owner’s manual for the digital set-top box.)
4Select RGB-DTV input source with using the INPUT button on the remote control.
(R) AUDIO (L) |
RGB-DTV OUTPUT |
Digital Set-top Box
When connecting with a HDMI cable
HDMI/DVI IN |
DIGITAL AUDIO OUT |
|
OPTICAL |
||
|
RS-232C IN
(CONTROL&SERVICE)
1 Connect the HDMI output of the digital set-top box to the HDMI/DVI IN jack on the set.
2Select HDMI/DVI input source with using the INPUT button on the remote control.
1
3 Turn on the digital set-top box. (Refer to the owner’s manual for the digital set-top box.)
HDMIOUTPUT
Digital Set top Box
•TV can receive the video and audio signal simultaneously with using a HDMI cable.
•If the digital set-top box supports Auto HDMI function, output resolution of the digital set-top box will be automatically set to 1280x720p.
•If the digital set-top box does not support Auto HDMI, you need to set the output resolution appropriately. get the best picture quality, adjust the output resolution of the digital set-top box to 1280x720p
26
Installation
When connecting with a Component cable
Digital Set-top Box
|
|
|
B |
|
R |
(R) AUDIO (L) |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
AV OUT |
|
|
|
|
(MONO) |
|
|
VIDEO |
AUDIO |
S-VIDEO |
VIDEO |
|
AV IN 1 |
|
COMPONENT IN |
1 Connect the video outputs (Y, PB, PR) of the digital set-top box to the COMPONENT IN VIDEO jacks on the set.
2 Connect theHDMI/DVIaudioIN outputDIGITAL AUDIOofOUTtheRSdigital-232C IN set-top box
OPTICAL (CONTROL&SERVICE)
to the COMPONENT IN AUDIO jacks on the set.
to the
)
4Select Component 1 input source with using the INPUT button on the remote control.
Signal |
Component1/2 |
RGB-DTV, HDMI/DVI |
480i |
Yes |
No |
480p/720p/1080i |
Yes |
Yes |
When connecting with a HDMI to DVI cable
|
|
ANTENNA |
|
|
|
|
IN |
|
|
|
|
|
AUDIO IN |
REMOTE |
|
|
CABLE |
(RGB/DVI) |
CONTROL |
|
|
|
|
|
|
|
IN |
|
|
HDMI/DVI IN |
DIGITAL AUDIO OUT |
RS-232C IN |
|
|
OPTICAL |
(CONTROL&SERVICE) |
|
|
|
|
|
|
||
|
|
|
RGB IN |
|
|
|
|
(PC/DTV) |
|
2
1
Digital Set-top Box
DVI-DTV OUTPUT (R) AUDIO (L)
1Connect the DVI output of the digital set-top box to the HDMI/DVI IN jack on the set.
2Connect the audio outputs of the set-top box to the AUDIO IN (RGB/DVI) ( 32/37/42LC2D Model) /AUDIO (RGB/DVI) (42PC3D/3DV/50PC3D Model) jack on the set.
3Turn on the digital set-top box. (ReferAUDIOtoIN theREMOTEowner’s manual for the digital set-top box.)
(RGB/DVI) CONTROL
4Select HDMI/DVI input source with using the INPUT button on the remote control.
•If the digital set-top box has a DVI output and no HDMI output, a separated audio connection is necessary.
•If the digital set-top box supports Auto DVI function, the output resolution of the digital set-top box will be automatically set to 1280x720p.
•If the digital set-top box does not support Auto DVI, you need to set the output resolution appropriately. To get the best picture quality, adjust the output resolution of the digital set-top box to 1280x720p.
27
Installation
Monitor Out Setup
- The TV has a special signal output capability which allows you to hook up a second TV or monitor.
AV |
|
|
1 |
Connect the second TV or monitor to the TV’s AV |
|
|
|
OUTPUT jacks. |
|
|
|
|
|
|
|
) |
|
2 |
See the Operating Manual of the second TV or |
|
|
|
monitor for further details regarding that device’s |
|
VIDEO |
S-VIDEO |
VIDEO |
AUDIO |
|
|
1 |
COMPONENT IN |
input settings. |
|
|
|
|
|
|
|
1/2 |
|
|
|
|
|
|
|
|
|
|
• Component |
1-2, |
RGB-PC/RGB-DTV, |
|
|
|
|
|
|
|
HDMI/DVI, DTV input sources cannot be used |
||
S-VIDEO IN |
|
|
|
|
|
|
for Monitor out. |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
||
(R) AUDIO (L) VIDEO |
• When connecting with external audio equip- |
||||||||
|
|
|
|
|
|
|
ments, such as amplifiers or speakers, please |
||
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
turn the TV speakers off. (Refer to p.43) |
||
|
|
|
|
|
|
|
• We recommend to use the video and audio |
||
|
|
|
|
|
|
|
output jacks for VCR recording. |
Digital Audio Output
- Send the TV’s audio to external audio equipment (stereo system) via the Digital Audio Output Optical port.
HDMI/DVI IN |
DIGITAL AUDIO OUT |
RS-232C IN |
|
OPTICAL |
(CONTROL&SERVICE) |
||
|
1/2
1Connect one end of an optical cable to the TV Digital Audio Optical Output port.
2Connect the other end of the optical cable to the digital audio optical input on the audio equipment.
3 See the external audio equipment instruction
-
ments, such as amplifiers or speakers, please turn the TV speakers off. (Refer to p.43)
CAUTION
Do not look into the optical output port. Looking at the laser beam may damage your vision.
28
Installation
PC Setup
- This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings.
When connecting with a D-sub 15 pin cable
AUDIO IN |
REMOTE |
(RGB/DVI) |
CONTROL |
RGB IN (PC/DTV)
2
(R) AUDIO (L) |
RGB-PC OUTPUT |
PC |
1Connect the RGB output of the PC to the RGB IN (PC/DTV) (32/37/42LC2D Model) / RGB (PC/DTV) (42PC3D/3DV/50PC3D Model) jack on the set.
2Connect the PC audio outputs to the AUDIO IN (RGB/DVI) (32/37/42LC2D Model) /AUDIO (RGB/DVI) (42PC3D/3DV/50PC3D Model) jack on the set.
3Turn on the PC and the set.
4Select RGB-PC input source with using the INPUT button on the remote control.
When connecting with a HDMI to DVI cable
|
|
ANTENNA |
|
|
|
|
IN |
|
|
|
|
|
AUDIO IN |
REMOTE |
|
|
CABLE |
(RGB/DVI) |
CONTROL |
|
|
|
|
|
|
|
IN |
|
|
HDMI/DVI IN |
DIGITAL AUDIO OUT |
RS-232C IN |
|
|
OPTICAL |
(CONTROL&SERVICE) |
|
|
|
|
|
|
||
|
|
|
RGB IN |
|
|
|
|
(PC/DTV) |
|
2
1
|
|
PC |
|
|
DVI-PC OUTPUT (R) AUDIO (L) |
1 |
Connect the DVI output of |
to the HDMI/DVI IN jack on the set. |
2 |
Connect the audio outputs |
the PC to the AUDIO IN (RGB/DVI) (32/37/42LC2D Model) |
/AUDIO (RGB/DVI) (42PC3D/3DV/50PC3D Model) jack on the set.
3 Turn on the PC and the set.
AUDIO IN |
REMOTE |
(RGB/DVI) |
CONTROL |
4 Select HDMI/DVI input |
with using the INPUT button on the remote control. |
• If the PC has a DVI |
no HDMI output, a separated audio connection is necessary. |
• If the PC does not support |
DVI, you need to set the output resolution appropriately. To get the |
best picture quality, |
the output resolution of PC graphics card's output resolution to |
1024x768, 60Hz. |
|
29
Installation
1.To get the best picture quality, adjust the PC graphics card to 1024x768, 60Hz.
2.Depending on the graphics card, DOS mode may not work if a HDMI to DVI Cable is in use.
3.When Source Devices connected with HDMI/DVI Input, output PC Resolution (VGA, SVGA, XGA), Position and Size may not fit to Screen.Press the ADJUST button to adjust the screen Position of TV SET and contact an PC graphics card service center.
4.When Source Devices connected with HDMI/DVI Input, output TV SET Resolution (480p, 720p, 1080i) and TV SET Display fit EIA/CEA-861-B Specification to Screen. If not, refer to the Manual of HDMI/DVI Source Devices or contact your service center.
5.In case HDMI/DVI Source Devices is not connected Cable or poor cable connection, "NO SIGNAL" OSD display in HDMI/DVI Input. In case that Video Resolution is not supported TV SET output in HDMI/DVI Source Devices, "INVALID FORMAT"
OSD display. Refer to the Manual of HDMI/DVI Source Devices or contact your service center.
6.Check the image on your TV. There may be noise associated with the resolution, vertical pattern, contrast or brightness in PC, HDMI/DVI mode. If noise is present, change the PC or HDMI/DVI mode to another resolution, change the refresh rate to another rate or adjust the brightness and contrast on the menu until the picture is clear. If the refresh rate of the PC graphic card can not be changed, change the PC graphic card or consult the manufacturer of the PC graphic card.
7.Avoid keeping a fixed image on the TV's screen for a long period of time. The fixed image may become permanently imprinted on the screen.
8.The synchronization input form for Horizontal and Vertical frequencies is separate.
Supported Display Resolution
(RGB-PC, HDMI/DVI Mode)
|
Resolution |
Horizontal |
Vertical |
|
Resolution |
Horizontal |
Vertical |
|
|
|
|
||||||
|
Frequency (kHz) |
Frequency (Hz) |
|
Frequency (kHz) |
Frequency (Hz) |
|
||
|
|
|
|
|
||||
|
* 640x350 |
31.468 |
70.09 |
|
|
35.156 |
56.25 |
|
|
* 720x400 |
31.469 |
70.08 |
|
800x600 |
37.879 |
60.31 |
|
|
|
31.469 |
59.94 |
|
48.077 |
72.18 |
|
|
|
|
|
|
|
||||
|
640x480 |
37.861 |
72.80 |
|
|
46.875 |
75.00 |
|
|
|
37.500 |
75.00 |
|
1024x768 |
48.363 |
60.00 |
|
|
* RGB-PC only |
|
|
56.476 |
70.06 |
|
||
|
|
|
|
|
||||
|
|
|
|
60.023 |
75.02 |
|
||
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
30
Installation
Screen Setup for PC mode
-
-
- In
-
*
5 6
8 9
ADJUST
Mini
Position
Size
Phase
and select the RGB-PC, this function is used.
input and select HDMI/DVI input, this function is used. PHASE is not available.
HDMI/DVI to PC input and checking the screen quality.
Size, and Phase
|
POSITION G |
|
|
|
|
|
|
|
|
|
SIZE |
|
F |
D |
|
|
|||
|
|
|
G |
|
|
PHASE |
|
|
E |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 Press the ADJUST button and then use D / E button to select
POSITION, SIZE, or PHASE.
2 Press ENTER button and then use D / E / F / G buttons to make appropriate adjustments.
•The PHASE adjustment range is -30 ~ +30.
(In HDMI/DVI-PC mode, PHASE is not available.)
•The SIZE adjustment range is -30 ~ +30.
3 Press ENTER button.
* |
factory |
5 |
6 |
8 |
9 |
0 |
FLASHBK |
ADJUST |
|
SOUND |
SAP FREEZE |
APM |
|
- To initialize the adjusted values
|
|
|
|
POSITION |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SIZE |
|
Initialize Settings |
|
|
|
|
|
|
|
||
|
|
|
|
PHASE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RESET G |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Adjust |
|
||||
1 |
|
|
|
|
|
|
|
Press the ADJUST button and then use D / E button to select |
|||||||
|
the RESET option. |
||||||
2 |
Press ENTER button and then use F / G button to select Yes. |
||||||
3 |
Press ENTER button. |
31
Operation
Operation
Basic operation
Turning on the TV
Channel Selection
Press the CH D / E or NUMBER buttons to select a channel number.
• If you intend to be away on vacation, disconnect the power plug from the wall power outlet.
On Screen Menus Language Selection
SETUP |
Aspect Ratio |
SETUP |
|
|
Cinema 3:2 Mode |
|
|
VIDEO |
Caption |
VIDEO |
|
|
Caption/Text |
|
|
AUDIO |
Caption Option |
AUDIO |
|
|
|
||
TIME |
Language |
TIME |
|
ISM Method |
|||
|
|
||
|
Low Power |
OPTION |
|
OPTION G |
|
||
LOCK |
|
LOCK |
Aspect Ratio |
|
|
Cinema 3:2 Mode |
|
|
Caption |
|
|
Caption/Text |
|
|
Caption Option |
|
|
Language |
G |
English |
ISM Method |
|
Español (Spanish) |
Low Power |
|
Français (French) |
MENU |
|
|
-The menus can be shown on the screen in the selected language. First select your language.
1 |
Press the MENU button and then use D / E button to select the |
|
OPTION menu. |
2 |
Press the G button and then use D / E button to select Language. |
3 |
Press the G button and then use D / E button to select your desired |
|
language. From this point on, the on-screen menus will be shown in the |
|
selected language. |
4 |
Press EXIT button to return to TV viewing or press MENU button to |
|
return to the previous menu. |
32
Operation
On Screen Menus Selection and Adjustment
How to adjust the OSD screen
1.Press the MENU button and then D / E button to select each menu.
2.Press the G button and then use D / E / F / G button to display the available menus.
SETUP G |
EZ Scan |
SETUP |
|
EZ Picture |
|
|
|
Manual Scan |
|
|
|
Contrast |
85 |
VIDEO |
Channel Edit |
|
VIDEO G |
|
Brightness |
50 |
|
DTV Signal |
|
|
|
Color |
50 |
AUDIO |
Input Source |
|
AUDIO |
|
Sharpness |
50 |
|
|
|
||||
|
Input Label |
|
|
|
Tint |
0 |
TIME |
|
TIME |
|
|||
Set ID |
|
Color Temperature |
||||
|
|
|
||||
|
|
|
|
|
Video Reset |
|
OPTION |
|
|
OPTION |
|
|
|
|
|
|
|
|
R G
LOCK |
LOCK |
SETUP Lock System
Set Password
VIDEO Block Channel
Movie Rating
AUDIO TV Rating-Children
TV Rating-General
TIME
Input Block
OPTION
LOCK G
SETUP |
Audio Language |
|
|
|
|
EZ SoundRite |
|
|
|
VIDEO |
EZ Sound |
|
|
|
|
Balance |
0 |
L |
R |
|
|
|
||
AUDIO G |
Treble |
50 |
|
|
|
|
|
||
TIME |
Bass |
50 |
|
|
Front Surround |
|
|
|
|
|
|
|
|
|
OPTION |
TV Speaker |
|
|
|
BBE |
|
|
|
|
|
|
|
|
|
LOCK |
|
|
|
|
SETUP |
|
Aspect Ratio |
|
SETUP |
|
Auto Clock |
||
|
|
Cinema 3:2 Mode |
|
|
|
Manual Clock |
||
|
|
|
|
|
||||
VIDEO |
|
Caption |
|
VIDEO |
|
Off Timer |
||
|
|
Caption/Text |
|
|
|
On Timer |
||
AUDIO |
|
|
AUDIO |
|
||||
|
Caption Option |
|
|
Sleep Timer |
||||
|
|
|
|
|
||||
|
|
Language |
|
|
|
Auto Off |
||
TIME |
|
|
TIME G |
|
||||
|
ISM Method |
|
|
|
|
|||
|
|
|
|
|
|
|
||
OPTION G |
|
Low Power |
|
|
OPTION |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
LOCK |
|
|
|
|
|
LOCK |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
*Note: These function are available in 42PC3D/3DV, 50PC3D models only.
•Your TV's OSD (On Screen Display) may differ slightly from what is shown in this manual.
33
Operation
Setup Menu Options
SETUP G |
|
EZ Scan |
|
||
|
|
Manual Scan |
|
|
|
VIDEO |
|
Channel Edit |
|
|
DTV Signal |
AUDIO |
|
|
|
Input Source |
|
|
|
|
|
|
Input Label |
TIME |
|
|
|
Set ID |
|
|
|
|
|
|
|
OPTION |
|
|
|
|
|
LOCK |
|
|
|
|
|
-Automatically finds all channels available through antenna or cable inputs, and stores them in memory on the channel list.
-Run EZ Scan again after any Antenna/Cable connection changes.
-A password is required to gain access to EZ Scan menu if the Lock System is turned on.
EZ Scan (Channel Search) |
||
SETUP |
EZ Scan |
G |
|
Manual Scan |
ANTENNA |
VIDEO |
Channel Edit |
CABLE |
AUDIO |
DTV Signal |
|
Input Source |
Selection ( G or Processing) leads youEZ scan... |
|
|
to the EZ scan |
|
|
Input Label |
|
TIME |
screen. |
|
Set ID |
TV Ch. 2 |
|
|
1 channel(s) found. |
|
OPTION |
|
|
|
Press to stop the |
|
|
|
|
|
current scan and start |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
DIGITAL ANTENNA channel |
|
|
|
|
|
|
|
|
LOCK |
|
|
|
scan. |
|
|
MENU |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MENU |
1 |
Press the MENU button and then use D / E button to select the SETUP menu. |
2 |
Press the G button and then use D / E button to select EZ Scan. |
3 |
Press the ENTER button to begin the channel search. |
Manual Scan
SETUP G |
|
EZ Scan |
|
||
|
|
Manual Scan |
VIDEO |
|
Channel Edit |
|
|
DTV Signal |
AUDIO |
|
|
|
Input Source |
|
|
|
|
|
|
Input Label |
TIME |
|
|
|
Set ID |
|
|
|
|
OPTION |
|
|
|
|
|
LOCK |
|
|
|
|
|
- A password is required to gain access to Manual Scan menu if the Lock System is turned on.
|
|
SETUP |
|
|
EZ Scan |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
Manual Scan |
G |
Select channel type and |
|
|||||
|
|
|
|
|
|
|
RF-channel number. |
|
|
|
|||
|
|
VIDEO |
|
|
Channel Edit |
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
DTV Signal |
|
|
|
|
|
|
|
|
|
|
AUDIO |
|
|
|
|
TV |
|
|
2 |
|
|
|
|
|
|
|
Input Source |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Input Label |
|
|
|
|
|
|
|
|
|
|
TIME |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Set ID |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OPTION |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
LOCK |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MENU |
|
|
|
|
|
|
|
|
|
1 |
|
|
|
|
|
|
|
|
|
|
|
||
Press the MENU button and then use D / E button to select the SETUP menu. |
|||||||||||||
2 |
Press the G button and then use D / E button to select Manual Scan. |
||||||||||||
3 |
Press the G button and then use D / E button to select TV, DTV, CATV, |
||||||||||||
|
and CADTV. |
|
|
|
|
|
|
|
|
|
|||
4 |
Press the G button and then use D / E button to select channel num- |
||||||||||||
|
ber you want to add or delete. |
|
|
|
|
|
|
|
|||||
5 |
Press the ENTER button to add or delete for the channel number. |
||||||||||||
6 |
Press EXIT button to return to TV viewing or press MENU button to |
||||||||||||
|
return to the previous menu. |
|
|
|
|
|
|
|
Mini Glossary |
|
|
|
TV |
Analog antenna (over-the-air) TV signal |
CATV |
Analog cable TV signal |
DTV |
Digital antenna (over-the-air) TV signal |
CADTV |
Digital cable TV signal |
34
Operation
|
|
|
|
|
Channel Edit |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SETUP G |
|
EZ Scan |
|
SETUP |
|
EZ Scan |
|
|
|
|
|
|
Manual Scan |
|
|
|
Manual Scan |
|
|
|
|
|
|
Channel Edit |
|
|
|
|
|
Selection ( G or ) leads you |
||
VIDEO |
|
VIDEO |
|
Channel Edit |
G |
|||||
|
|
DTV Signal |
|
|
|
DTV Signal |
|
to the channel edit screen. |
||
AUDIO |
|
|
AUDIO |
|
|
|
|
|
||
|
Input Source |
|
|
Input Source |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
Input Label |
|
|
|
Input Label |
|
|
|
|
TIME |
|
|
TIME |
|
|
|
|
|
||
|
Set ID |
|
|
Set ID |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
OPTION |
|
|
|
OPTION |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
LOCK |
|
|
|
LOCK |
|
|
|
|
|
|
|
|
|
|
MENU |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
-There are two different ways in order to add or delete scanned channels. One is "Custom List" and the other is "Favorite List" in the channel list. Both of them are available after EZ Scan on the
SETUP menu.
-A Custom List can be created by toggling each channel on or off with ENTER button. The channels in the Custom List are displayed in black color, and the channels deleted from the Custom List are displayed in gray color. Once a channel is highlighted you can add or delete the channel by referring to the small window at the top-left corner of the screen.You can create your own Favorite List. Use the FAV button on the remote control when a channel is highlighted and then you can add or delete the channel to/from the Favorite List.
* Custom List
1 |
Press the MENU button and then use D / E button to select the SETUP menu. |
2 |
Press the G button and then use D / E button to select Channel Edit. |
3 |
Press the G button. You will now see a screen filled with channel num- |
|
bers and a preview picture. |
4 |
Use D / E / F / G button to select a channel and then use the ENTER |
|
button to add or delete it. Press FAV button to add the channel to the |
|
Favorite List. The heart-mark will appear in front of that channel num- |
|
ber. |
5 |
Press EXIT button to return to TV viewing or press MENU button to |
|
return to the previous menu. |
35
Operation
Setup Menu Options continued
DTV Signal Strength
SETUP G |
EZ Scan |
SETUP |
EZ Scan |
|
|
|
|||
|
Manual Scan |
|
Manual Scan |
|
|
|
|
||
VIDEO |
Channel Edit |
VIDEO |
Channel Edit |
|
|
|
|||
|
DTV Signal |
|
DTV Signal |
|
AUDIO |
|
|
||
Input Source |
AUDIO |
Input Source |
||
|
||||
|
|
|
||
TIME |
Input Label |
|
Input Label |
|
|
TIME |
|||
Set ID |
Set ID |
|||
|
||||
|
|
|
||
OPTION |
|
OPTION |
|
|
|
|
|
||
LOCK |
|
LOCK |
MENU |
|
|
|
Bad Normal Good
G |
-Shows how strong your DTV signal is and whether you need to adjust your antenna or digital cable input. The higher the signal strength, the less likely you are to experience picture degradation.
-DTV Signals: Only when the input signal is DTV or CADTV, this function is available.
1 |
Press the MENU button and then use D / E button to select the SETUP menu. |
2 |
Press the G button and then use D / E button to select DTV Signal. |
3 |
View the on-screen signal strength monitor to see the quality of the signal |
|
being received. |
4 |
Press EXIT button to return to TV viewing or press MENU button to |
|
return to the previous menu. |
SETUP G |
EZ Scan |
|
|
Manual Scan |
|
VIDEO |
Channel Edit |
|
|
DTV Signal |
|
AUDIO |
Input Source |
|
|
||
TIME |
Input Label |
|
Set ID |
||
|
||
OPTION |
|
|
LOCK |
|
-Changes the picture source so you can watch your TV, cable TV, VCR, DVD, or any other devices that are connected to your TV.
Input Source
SETUP |
|
EZ Scan |
|
Antenna |
|
|
|||
|
|
Manual Scan |
|
Cable |
VIDEO |
|
Channel Edit |
|
AV1 |
|
|
DTV Signal |
|
AV2 |
AUDIO |
|
|
||
|
Input Source |
G |
Component1 |
|
|
|
|||
|
|
Input Label |
|
Component2 |
TIME |
|
|
||
|
Set ID |
|
RGB-PC |
|
|
|
|
||
OPTION |
|
|
|
HDMI/DVI |
|
|
|
|
|
|
|
|
|
|
LOCK |
|
|
|
|
|
MENU |
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
Press the MENU button and then use D / E button to select the SETUP menu. |
2 |
Press the G button and then use D / E button to select Input Source. |
3 |
Press the G button and then use D / E button to select the source: |
|
Antenna, Cable, AV1, AV2, Component1, Component2, RGB-DTV (or |
|
RGB-PC), or HDMI/DVI. |
|
• To toggle RGB-DTV and RGB-PC, select RGB-DTV(or RGB-PC) and |
|
press G button. |
4 |
Press EXIT button to return to TV viewing or press MENU button to |
|
return to the previous menu. |
36
Operation
SETUP G |
EZ Scan |
|
|
Manual Scan |
|
VIDEO |
Channel Edit |
|
|
DTV Signal |
|
AUDIO |
Input Source |
|
|
||
TIME |
Input Label |
|
Set ID |
||
|
||
OPTION |
|
|
LOCK |
|
-Sets a label to each input source or lets you skip the input source which is not in use when you press TV/VIDEO button.
Input Label
SETUP |
|
EZ Scan |
|
|
|
|
|
|
Manual Scan |
|
AV1 |
|
|
|
|
Channel Edit |
|
|
||
VIDEO |
|
|
Cable Box |
|
||
AUDIO |
|
DTV Signal |
|
AV2 |
VCR |
|
|
Input Source |
|
Component1 |
DVD |
|
|
|
|
|
|
|||
|
|
Input Label |
G |
Component2 |
Set Top Box |
|
TIME |
|
|
||||
|
Set ID |
|
RGB |
PC |
|
|
|
|
|
|
|||
OPTION |
|
|
|
HDMI/DVI |
Game |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
LOCK |
|
|
|
|
|
|
|
MENU |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
Press the MENU button and then use D / E button to select the SETUP menu. |
2 |
Press the G button and then use D / E button to select Input Label. |
3 |
Press the G button and then use D / E button to select the source: AV1, |
|
AV2,Component1-2, RGB, or HDMI/DVI. |
4 |
Press the F / G button to select the label. |
5 |
Press EXIT button to return to TV viewing or press MENU button to |
|
return to the previous menu. |
37
Operation
Video Menu Options
EZ Picture
-EZ Picture adjusts the TV for the best picture appearance. Select the preset value in the EZ Picture menu based on the program category.
-When adjusting Video menu options (con-
trast, |
tint, |
and color |
EZ |
Picture |
. |
- Daylight |
Time, |
Movie, |
set- |
tings are |
qual- |
ity at the |
. |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
|
0 |
FLASHBK |
EZ PIC |
|
|
|
SOUND |
SAP FREEZE |
|
APM |
|
1 |
Press the EZ PIC button repeatedly to select the picture appear- |
|
ance setup option as shown below: Custom (your own settings), |
|
Daylight, Normal, Night Time, Movie, Video Game, and |
|
Sports. |
|
• You can also adjust EZ Picture in the VIDEO menu. |
2 |
Press the EXIT button to save and return to TV viewing. |
APM (Adaptive Picture Mode)
6
9
FLASHBK
EZ
APM
-It allows a viewer to select their preferred mode after comparing picture (Daylight, Normal, Night Time and Custom) settings.
-Note: While operating the 4-split, any button except APM, ENTER,
EXIT, VOLUME D / E, MUTE button on the remote control are not available.
Daylight |
Normal |
|
|
Custom |
|
|
G |
|
F |
EXIT Exit |
|
|
F |
1 |
Press the APM button. |
screen is divided to 4-split. |
2 |
Press the D / E / F / |
to navigate 4 EZ Pictures. By pressing |
|
the ENTER button, you |
select the desired mode. |
3 |
Press the EXIT button |
and return to TV viewing. |
38
