LG XBV713 User Manual
V271P-M.NA1ULZ_ENG
Installation and Operating Guide | Warranty
Model Number | XBV713 | DVD Player + Video Cassette Recorder
© Copyright 2007, LG Electronics U.S.A., Inc.
For service/
support Call:
Toll Free Number
1-800-243-0000
2
This lightning flash with arrowhead symbol within
an equilateral triangle is intended to alert the
user to the presence of uninsulated dangerous
voltage within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the literature accompanying
the product.
WARNING: Do not install this equipment in a confined
space such as a bookcase or similar unit.
CAUTION: Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to
protect it from over heating.
The openings should be never be blocked by placing the
product on a bed, sofa, rug or other similar surface. This
product should not be placed in a built-in installation such as
a bookcase or rack unless proper ventilation is provided or
the manufacturer's instruction have been adhered to.
CAUTION:
This product employs a Laser System.
To ensure proper use of this product, please read this
owner’s manual carefully and retain it for future reference.
Should the unit require maintenance, contact an authorized
service center.
Performing controls, adjustments, or carrying out procedures other than those specified herein may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open
the enclosure. Visible laser radiation when open. DO NOT
STARE INTO BEAM.
CAUTION: The apparatus should not be exposed to water
(dripping or splashing) and no objects filled with liquids,
such as vases, should be placed on the apparatus.
CAUTION: VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS DEFEATED VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS.
FCC WARNING: This equipment may generate or use
radio frequency energy. Changes or modifications to this
equipment may cause harmful interference unless the
modifications are expressly approved in the instruction
manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is
made.
REGULATORY INFORMATION: FCC Part 15
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC COMPLIANCE: The responsible party for this product’s complian ce is:
LG Electronics U.S.A., Inc.,1000 Sylvan Avenue,
Englewood Cliffs, NJ.
Phone: 1-201-816-2000.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon a
dedicated circuit;
That is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check
the specification page of this owner's manual to be certain.
Do not overload wall outlets. Overloaded wall outlets, loose
or damaged wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or
fire. Periodically examine the cord of your appliance, and if
its appearance indicates damage or deterioration, unplug it,
discontinue use of the appliance, and have the cord
replaced with an exact replacement part by an authorized
servicer.
Protect the power cord from physical or mechanical abuse,
such as being twisted, kinked, pinched, closed in a door, or
walked upon. Pay particular attention to plugs, wall outlets,
and the point where the cord exits the appliance.
To disconnect power from the mains, pull out the mains cord
plug. When installing the product, ensure that the plug is
easily accessible.
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
3
1. Read these instructions. - All these safety and operating
instructions should be read before the product is operated.
2. Keep these instructions. - The safety, operating and use
instructions should be retained for future reference.
3. Heed all warnings. - All warnings on the product and in
the operating instructions should be adhered to.
4. Follow all instructions. - All operating and use instruc-
tions should be followed.
5. Do not use this product near water. – For example: near
a bath tub, wash bowl, kitchen sink, laundry tub, in a wet
basement; or near a swimming pool; and other areas
located near water.
6. Clean only with dry cloth. – Unplug this product from the
wall outlet before cleaning. Do not use liquid cleaners.
7.
Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Slots and
openings in the cabinet are provided for ventilation and to
ensure reliable operation of the product and to protect it
from over- heating. The openings should never be blocked
by placing the product on a bed, sofa, rug or other similar
surface. This product should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have
been adhered to.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. D
o not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades
with one wider than the other. A grounding
type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles, and the point where they exit from the product.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with apparatus. When a cart is used, use caution when moving
the cart/product combination to avoid injury from
tip-over.
13. Unplug this product during lightning storms or when
unused for long periods of time.
14.
Refer all servicing to qualified service personnel.
Servicing is required when the product has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the product, the product has been
exposed to rain or moisture, does not operate normally, or has been dropped.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION:
PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL. AND
THOSE MARKED ON THE PRODUCT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This product has been designed and manufactured to assure personal safety. Improper use can result in electric shock or
fire hazard. The safeguards incorporated in this product will protect you if you observe the following procedures for installation, use, and servicing.
This product does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
4
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . .5
Moisture Condensation . . . . . . . . . . . . . . . . . .5
Symbol Used in this Manual . . . . . . . . . . . . . .5
About the Symbol Display . . . . . . . . . . . . .5
Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . .5
Types of Playable Discs . . . . . . . . . . . . . . . . .6
Region code . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Notes on Copyrights . . . . . . . . . . . . . . . . . . . .6
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Remote Control . . . . . . . . . . . . . . . . . . . . . . . .8
About the Remote Control . . . . . . . . . . . . . . .8
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Preparation . . . . . . . . . . . . . . . . . . . . . .10
Basic TV Connections . . . . . . . . . . . . . . .10-11
Optional TV Connections . . . . . . . . . . . . . . .10
Connection to an Amplifier . . . . . . . . . . . . . .11
Initial Settings - VCR . . . . . . . . . . . . . . . . . . .12
General Operation . . . . . . . . . . . . . . . . . . . .12
CLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
PROGRAM . . . . . . . . . . . . . . . . . . . . . . . . .12
SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Displaying Disc Information on-screen . . . .14
Initial Settings - DVD . . . . . . . . . . . . . . . .14-17
General Operation . . . . . . . . . . . . . . . . . . . .14
LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . .15
• Menu Language . . . . . . . . . . . . . . . . . . .15
• Disc Audio/Subtitle/Menu . . . . . . . . . . . . .15
DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . .15
• TV Aspect . . . . . . . . . . . . . . . . . . . . . . . .15
• Display Mode . . . . . . . . . . . . . . . . . . . . . .15
AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
• Dolby Digital/DTS/MPEG . . . . . . . . . . . . .16
• Sample Freq. (Frequency) . . . . . . . . . . . .16
• DRC (Dynamic Range Control) . . . . . . .16
• Vocal . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
LOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
• Rating . . . . . . . . . . . . . . . . . . . . . . . . . . .16
• Password (Security Code) . . . . . . . . . . . .16
• Area Code . . . . . . . . . . . . . . . . . . . . . . . .17
OTHERS . . . . . . . . . . . . . . . . . . . . . . . . . . .17
B.L.E. (Black Level Expansion) . . . . . . . . .17
Operation . . . . . . . . . . . . . . . . . . . . . . .18
VCR Tape Playback . . . . . . . . . . . . . . . . . . . .18
Basic Instructions . . . . . . . . . . . . . . . . . . . . .18
Auto Tracking . . . . . . . . . . . . . . . . . . . . . . . .18
Manual Tracking . . . . . . . . . . . . . . . . . . . . . .18
Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Still Picture and Frame-by-Frame Playback .18
Slow Motion . . . . . . . . . . . . . . . . . . . . . . . . .19
CM SKIP (Commercial Skip) . . . . . . . . . . . . .19
VCR Tape Recording . . . . . . . . . . . . . . . .19-20
Basic Instructions . . . . . . . . . . . . . . . . . . . . .19
External Timer Recording . . . . . . . . . . . .19-20
Instant Timer Recording . . . . . . . . . . . . . . .20
Recording from External Components . . . . .20
Copying from DVD to VCR . . . . . . . . . . . . . .21
On-Screen Display - VCR . . . . . . . . . . . . . . .21
Additional VCR Information . . . . . . . . . . . . .22
VCR Auto Play System . . . . . . . . . . . . . . . . .22
S-VHS Quasi Playback (SQPB) . . . . . . . . . .22
General Playback Features - DVD . . . . . . . . .23
Additional Features . . . . . . . . . . . . . . . . . . . .24
Playing an Audio CD or MP3/WMA file . . . . .25
Programmed Playback . . . . . . . . . . . . . . . . .25
Repeat Programmed Tracks . . . . . . . . . . . .25
Erasing a Track from Program List . . . . . . .25
Erasing the Complete Program List . . . . . .25
Viewing a JPEG file . . . . . . . . . . . . . . . . . . . .26
Slide Show . . . . . . . . . . . . . . . . . . . . . . . . .26
Still Picture . . . . . . . . . . . . . . . . . . . . . . . . .26
Moving to another File . . . . . . . . . . . . . . . .26
Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Rotating the picture . . . . . . . . . . . . . . . . . .26
Playing a DVD VR format Disc . . . . . . . . . . .27
Maintenance and Service . . . . . . . . . . . . . . .27
Reference . . . . . . . . . . . . . . . . . . . . . . .28
Language Codes . . . . . . . . . . . . . . . . . . . . . .28
Area Codes . . . . . . . . . . . . . . . . . . . . . . . . . .28
Troubleshooting . . . . . . . . . . . . . . . . . . . .29-30
Specifications . . . . . . . . . . . . . . . . . . . . . . . .31
5
To ensure proper use of this product, please read this
owner’s manual carefully and retain it for future
reference.
This manual provides information on the operation
and maintenance of your unit. Should the unit require
service, contact an authorized service location.
Moisture Condensation
Never operate the unit immediately after moving it
from a cold location to a warm location. Leave it
unplugged for two or three hours without operating it.
If you use the unit in such a situation, it may damage
discs/tapes and internal parts.
Symbol Used in this Manual
Note: Indicates special notes and operating fea-
tures.
Tip: Indicates tips and hints for making the task
easier.
A section whose title has one of the following
symbols is applicable only to the disc represented
by the symbol.
All discs listed below
DVD and finalized DVD±R/RW
Audio CDs
MP3 files
WMA files
About the Symbol Display
“ ” may appear on your TV display during operation and indicates that the function is not permitted by
this unit or the disc.
Notes on Discs
Handling Discs
Do not touch the playback side of the disc. Hold the
disc by the edges so that fingerprints do not get on
the surface. Never stick paper or tape on the disc.
Storing Discs
After playing, store the disc in its case. Do not
expose the disc to direct sunlight or sources of heat
and never leave it in a parked car exposed to direct
sunlight.
Cleaning Discs
Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing,
clean the disc with a clean cloth. Wipe the disc from
the center out.
Do not use strong solvents such as alcohol, benzine,
thinner, commercially available cleaners, or anti-static
spray intended for older vinyl records.
WMA
MP3
ACD
DVD
ALL
Introduction
Introduction
6
Types of Playable Discs
DVD
(8 cm / 12 cm disc)
Audio CD
(8 cm / 12 cm disc)
In addition, this unit plays DVD±R/RW and CD-R/RW,
Dual disc that contains audio titles, MP3, WMA,
and/or JPEG files.
This indicates a product feature that is
capable of playing DVD-RW discs recorded
with Video Recording format.
Notes:
• Depending on the conditions of the recording
equipment or the CD-R/RW (or DVD±R/RW) disc
itself, some CD-R/RW (or DVD±R/RW) discs
may not be played on the unit.
• Do not use irregularly shaped CDs (e.g., heartshaped or octagonal) since they may result in malfunctions.
• This DVD player requires discs and recordings to
meet certain technical standards in order to
achieve optimal playback quality. Pre-recorded
DVDs are automatically set to these standards.
There are many different types of recordable disc
formats (including CD-R containing MP3 or WMA
files) and these require certain pre-existing conditions (see above) to ensure compatible playback.
Customers should note that permission is
required in order to download MP3 / WMA files
and music from the Internet. Our company has
no right to grant such permission. Permission
should always be sought from the copyright
owner.
Regional Code
This unit has a regional code printed on the rear of
the unit. This unit can play only DVD discs labeled as
the same as the rear of the unit or “ALL”.
Notes on Regional Codes
• Most DVD discs have a globe with one or more
numbers in it clearly visible on the cover. This number must match your DVD player’s regional code or
the disc cannot play.
• If you try to play a DVD with a different regional
code from your player, the message “Check
Regional Code” appears on the TV screen.
Notes on Copyrights:
It is forbidden by law to copy, broadcast, show,
broadcast via cable, play in public, or rent copyrighted material without permission. This product features
the copy protection function developed by
Macrovision. Copy protection signals are recorded on
some discs. When recording and playing the pictures
of these discs picture noise will appear. This product
incorporates copyright protection technology that is
protected by method claims of certain U.S. patents
and other intellectual property rights owned by
Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only
unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is
prohibited.
7
Introduction
a
11
POWER
Switches the unit ON and OFF.
b z (REC)
Starts recording.
Press repeatedly to set the recording time.
c Disc Tray (DVD deck)
Insert a disc here.
d Cassette Compartment (VCR deck)
Insert a video cassette here.
e
ZZ
VCR
Ejects the tape in the VCR deck.
f
../mm
- DVD: Skip to the beginning of current chapter or
track, press twice in quick successions to go to previous chapter or track. Press and hold button for about
two seconds to search backward.
- VCR: Rewinds the tape during the stop mode or for
fast backward picture search.
g
NN
Starts playback of a disc or tape.
h
MM//>>
- DVD: Skip to next the chapter or track.
Press and hold for two seconds for a fast forward
search.
- VCR: Advances the tape during the STOP mode or
for fast forward picture search.
i
xx
Stops playback of the disc or tape.
j DVD/VCR (output select)
Select one of your output sources to view on the TV
screen between DVD and VCR.
k INPUT
Selects the VCR deck’s source.
(LINE 1 or LINE 2).
l
ZZ
DVD
Opens or closes the disc tray.
m Display Windows
DVD:
The DVD deck is selected.
:
A disc is in the DVD deck.
(Lights when a disc is in the DVD deck and
Flashes when no disc.)
:
Indicates repeat mode.
[P]: Indicates when the Progressive scan is active.
:
Unit is in timer recording or a timer recording is
programmed (VCR part only)
:
A cassette is in the VCR deck.
VCR: The VCR deck is selected.
REC: Unit is Recording.(VCR part only)
PM: Indicates PM time. (AM is not displayed.)
: Indicates total playing time, elapsed time,
remaining time or current deck status
(Playback, Pause, etc).
n Remote Sensor
Point the unit Remote Control
here.
o LINE2 (VIDEO/AUDIO (L/R) input)
Connect to the audio/video output of an external
source (Audio system, TV/Monitor, Another VCR).
Front Panel
a
h
i
j
kol
cb
degf
m
n
8
a
11
(POWER) : Switches unit ON and OFF.
*
: This button is not available.
ZZ
(OPEN/CLOSE) : Opens and closes the disc tray.
DVD : Select the unit function mode to DVD.
VCR : Select the unit function mode to VCR.
INPUT : Selects the VCR deck’s source (LINE 1 or
LINE 2).
DISPLAY : Accesses On-Screen Display.
CLK/CNT : Switches between the clock, tape counter and
tape remaining modes on the display.
DISC MENU : Accesses menu on a DVD disc.
b / B / v / V : Selects menu options.
vv/VV
(TRK) : Adjusts manually the tape’s picture onscreen.
SETUP/MENU : Accesses or removes DVD Setup menu
and VCR menu.
ENTER (OK) : Confirms menu selections. Displays func-
tions on the TV screen.
RETURN (OO) : Removes the setup menu.
b
X (PAUSE/STEP) :
Pause playback or recording temporarily.
Press repeatedly for frame-by-frame playback.
./> (SKIP) :
Go to next the chapter or track.
Returns to beginning of current chapter or track or go to
previous chapter or track.
xx
(STOP) : Stops playback or recording.
m/M (BACKWARD / FORWARD) :
- DVD: Search backward or forward.
- VCR: Rewinds/Advances the tape during the STOP mode,
for fast backward/forward picture search.
HH
(PLAY) : Starts playback.
0-9 Selects numbered options in a menu.
PROGRAM : Shows or hides Program menu.
CLEAR : Removes a mark on the Marker Search menu.
c
AUDIO : Selects an audio language (DVD).
SUBTITLE : Selects a subtitle language.
ANGLE : Selects a DVD camera angle, if available.
ZOOM : Enlarges DVD video image.
MARKER : Marks any point during playback.
SEARCH : Displays Marker Search menu.
TITLE : Displays the disc’s Title menu, if available.
zz
(REC/ITR) : Starts recording.
REPEAT
: Repeat chapter, track, title or all.
RANDOM : Plays tracks in random order.
CM SKIP : Fast forwards picture search through 30 sec-
onds of recording.
A-B : Repeats sequence between two points (A and B).
SPEED : Selects recording speed.
Remote Control
About the Remote Control
Operation Range
Point the Remote Control at the remote sensor and
press the buttons.
Distance: About 23 ft (7 m) from the front of the
remote sensor.
Angle: About 30° in each direction of the front of
the remote sensor.
Battery installation
Detach the battery cover on the rear of
the Remote Control, and insert two
(R03/AAA) size batteries with 3 and #
aligned correctly.
Do not mix old and new batteries and never
mix different types of batteries such as
standard, alkaline, etc.
AAA
AAA
a
b
c
9
Introduction
a VCR IN LINE 1 (VIDEO/AUDIO (Left/Right))
Connect the audio/video output of an external source
(Audio system, TV/Monitor, VCR, Camcorder).
b DVD/VCR OUT (VIDEO/AUDIO (Left/Right))
Connect to a TV with video and audio inputs.
c COMPONENT/PROGRESSIVE SCAN VIDEO
OUT (Y Pb Pr) (DVD EXCLUSIVE OUT)
Connect to a TV with Y Pb Pr inputs.
d AUDIO OUT (Left/Right)
(DVD EXCLUSIVE OUT)
Connect to a TV or other equipment with audio inputs.
e AC Power Cord
Plug into the power source.
f COAXIAL (DIGITAL AUDIO OUT jack)
(DVD EXCLUSIVE OUT)
Connect to digital (coaxial) audio equipment.
g S-VIDEO OUT (DVD EXCLUSIVE OUT)
Connect to a S-Video Input on TV.
abcd e
f
Rear Panel
Caution
Do not touch the inner pins of the jacks on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
g
10
Depending on your TV and other equipment
there are various ways you can connect the
player. Please refer to the manuals of your
TV, VCR, stereo system or other devices as
necessary for additional connection
information.
Notes:
• The picture and sound of a nearby TV, VCR, or
radio may be distorted during playback. Position
the units away from each other or turn off the unit
after removing the disc.
• Do not connect the unit’s AUDIO OUT jack to the
phono in jack (record deck) of your audio system.
Do not connect the unit via another VCR. The
DVD image could be distorted by the copy protection system.
Basic TV Connections
Make one of the following connections, depending on
the capabilities of your TV.
Audio/Video connection
1. Connect the DVD/VCR VIDEO OUT jack on the
unit to the video in jack on the TV using the video
cable supplied (V).
2. Connect the Left and Right DVD/VCR AUDIO
OUT jacks on the unit to the audio left/right in
jacks on the TV using the supplied audio cables
(A1).
Note:
If you use this connection, set the TV’s source selector to VIDEO.
Optional TV Connections
These connections support only DVD playback. The
tuner and VCR still output through the DVD/VCR
OUT (A1, V) jacks.
S-Video connection
Connect the S-VIDEO OUT jack on the unit to the
S-Video jack on the TV using the optional S-Video
cable (S).
Component Video / Progressive Scan
connection
If your television is a high-definition or “digital ready”
television, you may take advantage of the unit’s progressive scan output for the highest possible video
resolution.
Connect the COMPONENT/PROGRESSIVE SCAN
VIDEO OUT jacks on the unit to the corresponding
jacks on the TV using an optional Y Pb Pr cable (C).
Audio connection
Connect the Left and Right AUDIO OUT jacks of the
unit to the audio left/right in jacks on the TV using the
supplied audio cables (A2).
Note:
If you connect both S-Video and component jack to
your TV, the video may be displayed unstably on your
TV. You should disconnect one of both connections to
solve the problem.
Rear of DVD+VCR
L
R
AUDIO INPUT
VIDEO
INPUT
Rear of TV
A1
V
Y
Pb
Pr
COMPONENT/PROGRESSIVE SCAN
VIDEO INPUT
L
R
AUDIO INPUT
Rear of TV
SA2
C
Preparation
Loading...
