LG WC1NP8 Users manual

SPECIFICATIONS

PRODUCT NAME : 802.11a/b/g/n/ac + Bluetooth Combo Module
MODEL NAME : WC1NP8

The information contained herein is the exclusive property of LG Innotek
and shall not be distributed, reproduced or disclosed in whole or no in part

without prior written permission of LG Innotek.

Designed Checked Approved

H.J. ROH D.S. OH S.D. CHOI

2017.10.22 2017.10.27 2017.11.01

LG Innotek Co., Ltd.

DOCUMENT No.

PAGE 25

17(개A)ER-005

(00)-0073

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

S P E C I F I C A T I O N

WC1NP8

REV.NO : 2.0

PAGE :

Index

No Description Page

1 Features 2

2 Ordering Information 2

3 Label Marking 2
4 Block Diagram 3
5 Absolute Maximum Ratings 3
6 Operating Conditions 4
7 Standard Test Conditions 4

8 Electrical Specifications for Wi-Fi 5

1 / 22

9 Electrical Specifications for Bluetooth 11
10 Environment Tests 14
11 Pin Description 15
12 Test Method 16

13 Mechanical Characteristics 17

14 Outline Drawing 18
15 Insulation Parts List 19
16 Packing Information 20
17 LG CI Specification 22
18 Change History of Revision 25

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

S P E C I F I C A T I O N

WC1NP8

REV.NO : 2.0

PAGE :

1. Features

WC1NP8 is the small size and low power module for IEEE 802.11ac wireless LAN &

BT4.2 + HS. TWCM-E001D is based on QCA9379-7 solution.

* Caution: This model don’t support AC Mode

 IEEE 802.11 a/b/g/n/ac Dual Band WLAN infrastructure
 Bluetooth 4.2+ HS , BLE
 Size : 68.0mm x 38.0 x 6.8 mm
 Two stream spatial multiplexing up to 300Mbps(802.11n)/ 867Mbps(802.11ac)
 WLAN Metal Press antenna(Ready), BT Printed antenna on
 Use on-chip OTP (One-Time Programmable)
 Host Interface :

-WLAN : USB2.0

2 / 22

-BT : USB1.1

 Security : WAPI, WEP, WPA, WPA2, WMM, AES, WEP, TKIP, CKP

 Application: DTV, DVR, HD DVD Player, Blue-ray Disk Player, STB

2. Ordering Information

Model Description

TWCM-E001D

WC1NP8

802.11 a/b/g/n/ac + BT combo Module, Dual Band 2T2R MIMO

3. Label marking

①

EAT64113401

1710A210101

④

②
③

① Customer P/N ④ Product Lot No. : 1710A210101

TWCM-E001D

001EB2B00339

⑤

② MAC Address BAR Code -17 : Year - 21 : Date
③ Model No - 10: Month - 01 : Manufactured Process

- A : Revision No - 01 : Change History of Revision

⑤ MAC Address No.

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

4. Block Diagram

ANT0

Diplexer
& Balun

ANT1

BT

ANT

Matching

Diplexer
& Balun

Matching

LPF

S P E C I F I C A T I O N

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

QCA9379

2.4GHz
5GHz

2.4GHz

5GHz

2.4GHz

11ac 2T2R

Baseband

BT

Baseband

40MHz

32bit RISC CPU

Packet buffer/

Security engine

Main

Clock

MAC /

Bluetooth

MAC

DC Buck

REV.NO : 2.0

PAGE :

System

Control

USB2.0

Interface

USB1.1

Interface

1.1V

3.45V

3 / 22

USB I/F 12PIN CONNECTOR

5. Absolute Maximum Ratings

Caution : The specifications in Table 1 define levels at which permanent damage to the

device can occur. Function operation is not guaranteed under these conditions.
Operating at absolute maximum conditions for extend periods can adversely affect the
long-term reliability of the device.

Parameter Min Max Unit

Storage Temperature -20 +80 ℃

Storage Humidity (40℃) - 90 %

< Table 1 >

. Other conditions

1) Do not use or store modules in the corrosive atmosphere, especially where chloride
gas, sulfide gas, acid, alkali, salt or the like are contained.
Also, avoid exposure to moisture.

2) Store the modules where the temperature
and relative humidity do not exceed 5 to 40℃ and 20 to 60%.

3) Assemble the modules within 6 months.
Check the soldering ability in case of 6 months over.

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

4 / 22

6. Operating Conditions

Parameter Min Typ Max Unit

Ambient Temperature 0 - 60 ℃

Ambient Humidity (40℃) - - 85 %

Supply Voltage 3.35 3.45 3.6 Vdc

7. Standard Test Conditions

The Test for electrical specification shall be performed under the following condition

Otherwise this following conditions, not guaranteed this performance.

7-1. Ambient condition

Temperature 25 ± 5℃

Humidity 65 ± 5%

7-2. Power supply voltages

Input power Supply Voltage

VDD_3.3V 3.35 ~ 3.6V

7-3. Current consumption (2X2 Continuous Power)

Current Consumption Min. Typ. Max. Unit

TX Mode ( CCK 1M @ 17dBm) - 1A mA

Note 1 : This figure is the RMS(root mean square) Value.

7-4. ESD Information

Human Body Model (HBM) Min. Max. Unit

Contact - ±2
Air - ±10

Note 1 : IEC 61000-4-2 (150pF, 330R)
※ Test condition : After 8-pin USB Cable connect to module, progress ESD test.

Copyrightⓒ. 2016. All Rights Reserved.

kV

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

5 / 22

8. Electrical Specifications for Wi-Fi ( Radiation Test )

8-1. RF Characteristics for IEEE802.11b ( 11Mbps mode unless otherwise specified)

Items Contents

Specification IEEE802.11b
Mode DSSS/CCK
Channel frequency
Data rate 1, 2, 5.5, 11Mbps

TX Characteristics Min. Typ. Max. Unit

Power Level

2)

Spectrum Mask

2400 ~ 2483.5 MHz

14 17 20 dBm

1st side lobes ( to fc ±11MHz) - -43 -30 dBr
2nd side lobes ( to fc ±22MHz) - -58 -50 dBr
Modulation Accuracy (EVM) - 30 35 %
Power On/Off ramp - 0.5 2.1 Usec
Freq. Tolerance -20 - 20 ppm
Chip Clock Freq. Tolerance -20 - 20 ppm

RX Characteristics Min. Typ. Max. Unit

Minimum Input Level Sens. (FER ≤ 8%) -88 -82 dBm
Maximum Input Level (FER ≤ 8%) -10 - - dBm

* Normal Condition : 25℃, VDD=3.3V.
Note 1. This varies by regulatory domain.

Refer to the product documentation for specific details for each regulatory domain.
Note 2. The maximum power setting will vary by channel and according to individual country regulations.

Refer to the product documentation for specific details.

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

6 / 22

8-2. RF Characteristics for IEEE802.11g ( 54Mbps mode unless otherwise specified)

Items Contents

Specification IEEE802.11g
Mode OFDM
Channel frequency
Data rate 6, 9, 12, 18, 24, 36, 48, 54Mbps

TX Characteristics Min. Typ. Max. Unit

Power Level
Spectrum Mask
at fc ±11MHz - -32 -20 dBr

2400 ~ 2472 MHz

12 15 18 dBm

at fc ±20MHz - -43 -28 dBr
at fc ≥ ± 30MHz - -48 -40 dBr
Constellation Error (EVM) - -32 -25 dB
Freq. Tolerance -20 - 20 ppm
Chip Clock Freq. Tolerance -20 - 20 ppm

RX Characteristics Min. Typ. Max. Unit

Minimum Input Level Sens. (PER ≤ 10%) - -74 -67 dBm
Maximum Input Level (PER ≤ 10%) -20 - - dBm

* Normal Condition : 25℃, VDD=3.3V.
Note 1. This varies by regulatory domain.

Refer to the product documentation for specific details for each regulatory domain.
Note 2. The maximum power setting will vary by channel and according to individual country regulations.

Refer to the product documentation for specific details.

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

7 / 22

8-3. RF Characteristics for IEEE802.11a ( 54Mbps mode unless otherwise specified)

Items Contents

Specification IEEE802.11a
Mode OFDM
Channel frequency
Data rate 6, 9, 12, 18, 24, 36, 48, 54Mbps

TX Characteristics Min. Typ. Max. Unit

Power Level

2)

Spectrum Mask
at fc ±11MHz - -32 -20 dBr

5150~5850 MHz

10 13 16 dBm

at fc ±20MHz - -43 -28 dBr
at fc ≥ ± 30MHz - -48 -40 dBr
Constellation Error (EVM) - -32 -25 dB
Freq. Tolerance -20 - 20 ppm
Chip Clock Freq. Tolerance -20 - 20 ppm

RX Characteristics Min. Typ. Max. Unit

Minimum Input Level Sens. (PER ≤ 10%) - -73 -67 dBm
Maximum Input Level (PER ≤ 10%) -30 - - dBm

* Normal Condition : 25℃, VDD=3.3V.
Note 1. This varies by regulatory domain.

Refer to the product documentation for specific details for each regulatory domain.
Note 2. The maximum power setting will vary by channel and according to individual country regulations.

Refer to the product documentation for specific details.

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

8 / 22

8-4. RF Characteristics for IEEE802.11gn ( MCS7 mode unless otherwise specified)

Items Contents

Specification IEEE802.11n – 2.4GHz
Mode OFDM
Channel frequency
Data rate 6.5, 13, 19.5, 26, 39, 52, 58.5, 65Mbps

TX Characteristics Min. Typ. Max. Unit

Power Level (HT20:MCS7) 12 15 18 dBm
Spectrum Mask (HT20)

2400 ~ 2483.5 MHz

at fc ±11MHz - -32 -20 dBr
at fc ±20MHz - -35 -28 dBr
at fc ±30MHz - -45 -40 dBr
Constellation Error (EVM) - -32 -28 dB
Freq. Tolerance -20 - 20 ppm
Chip Clock Freq. Tolerance -20 - 20 ppm

RX Characteristics Min. Typ. Max. Unit

Minimum Input Level Sens.

(HT20,PER ≤ 10%)

- -73 -66 dBm

Maximum Input Level (PER ≤ 10%) -20 - - dBm

* Normal Condition : 25℃, VDD=3.3V.
Note 1. This varies by regulatory domain.

Refer to the product documentation for specific details for each regulatory domain.
Note 2. The maximum power setting will vary by channel and according to individual country regulations.

Refer to the product documentation for specific details.

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

9 / 22

8-5. RF Characteristics for IEEE802.11an ( MCS7 mode unless otherwise specified)

Items Contents

Specification IEEE802.11n – 5GHz
Mode OFDM
Channel frequency
Data rate 6.5, 13, 19.5, 26, 39, 52, 58.5, 65Mbps

TX Characteristics Min. Typ. Max. Unit

Power Level (HT20/HT40:MCS7) 10 13 16 dBm
Spectrum Mask (HT20)
at fc ±11MHz - -32 -20 dBr

5150~5850 MHz

at fc ±20MHz - -35 -28 dBr
at fc ±30MHz - -45 -40 dBr
Constellation Error (EVM) - -32 -28 dB
Freq. Tolerance -20 - 20 ppm
Chip Clock Freq. Tolerance -20 - 20 ppm

RX Characteristics Min. Typ. Max. Unit

Minimum Input Level Sens.
(HT20,PER ≤ 10%)

Minimum Input Level Sens.
(HT40,PER ≤ 10%)

- -70 -64 dBm

- -67 -62 dBm

Maximum Input Level (PER ≤ 10%) -30 - - dBm

* Normal Condition : 25℃, VDD=3.3V.
Note 1. This varies by regulatory domain.

Refer to the product documentation for specific details for each regulatory domain.
Note 2. The maximum power setting will vary by channel and according to individual country regulations.

Refer to the product documentation for specific details.

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

10 / 22

8-4. RF Characteristics for IEEE802.11ac ( MCS8/9 mode unless otherwise specified)

Items Contents

Don’t support This Model

Note 1: This varies by regulatory domain
Refer to the product documentation for specific details for each regulatory domain

Note 2: The maximum power setting will vary by channel and according to individual country regulations.
Refer to the product documentation for specific details.

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

11 / 22

9. Electrical Specifications for Bluetooth ( Conducted Test )

9-1. Transmitter Performance

Parameter (Condition) Min. Typ. Max. Unit

Transmit Power (PGPSK) 6 11 15 dBm
Power Density - - 20 dBm
Frequency Range 2400 - 2483.5 MHz
20dB Bandwidth - - 1000 kHz
In-band Spurious Emissions
± 500kHz - - -20 dBc
|M-N| = 2MHz - - -20 dBm
|M-N| ≥ 3MHz - - -40 dBm
Modulation Characteristics, frequency Deviation
ΔF1avg (00001111 sequence in payload) 140 155 175 kHz
ΔF2max (10101010 sequence in payload) 115 - - kHz
ΔF1avg / ΔF2max 80 90 - %
Initial Carrier Frequency Tolerance -75 - 75 kHz
Carrier Frequency Drift
DH1 Packet -25 - 25 kHz
DH3 Packet -25 - 25 kHz
DH5 Packet -40 - 40 kHz
Drift rate -20 - 20 kHz / μs

* Normal Condition : 25℃, VDD=3.5V.
* Supported bluetooth tx power class 1.

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

12 / 22

9-2. Transmitter Performance

Parameter (Condition) Min. Typ. Max. Unit

EDR Relative Transmit Power -4 - 1 dB

EDR Carrier Frequency Stability

ωi (2-DH5 and 3-DH5) -75
ω0 (2-DH5 and 3-DH5) -10
ωi + ω0 (2-DH5 and 3-DH5) -75
EDR Modulation Accuracy

RMS DEVM

99% DEVM

DEVM < 0.30, π/4-DQPSK

DEVM < 0.20, 8DPSK symbols

2-DH5
3-DH5
2-DH5

3-DH5

-

-

99 - - %
99 - - %

-

-

-

75 kHz
10 kHz

75 kHz

6 20 %
6 13 %

2-DH5

-

13 35 %

Peak DEVM

3-DH5

EDR Differential Phase Encoding

(packet with 0 error > 99%)

-

13 25 %

99 - - %

EDR In-band Spurious Emissions
|M-N| = 1MHz - -

Ptx_ref-

26

dBm

|M-N| = 2MHz - - -20 dBm
|M-N| = 3MHz - - -40 dBm

Enhanced Power Control - - 4 dBm

9-3. BLE RF Performance

Parameter (Condition) Min. Typ. Max. Unit

Tx Power 0 4 8 dBm
Rx sensitivity (GFSK, BER, 1 Mbps) - -90 -80 dBm
Mod Char : delta F1 average 225 255 275 kHz
Mod Char : delta F2 max 99.9 - - %
Mod Char : ratio 80 95 - %

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

13 / 22

9-4. Receiver Performance

Parameter (Condition) Min. Typ. Max. Unit

Rx sensitivity
GPSK, 0.1% BER, 1Mbps - -85 -70 dBm

π/4-DQPSK, 0.01% BER, 2Mbps - -80 -70 dBm

8-DPSK, 0.01% BER, 3Mbps - -80 -70 dBm
C/I performance
C/I co-channel (GFSK, 0.1%BER) - - 11 dB
C/I 1MHz (GFSK, 0.1%BER) - - 0 dB
C/I 2MHz (GFSK, 0.1%BER) - - -30 dB
C/I ≥3MHz (GFSK, 0.1%BER) - - -40 dB

C/I image (GFSK, 0.1%BER) - - -9 dB

C/I image± 1MHz (GFSK, 0.1%BER) - - -20 dB
C/I co-channel (π/4-DQPSK, 0.1%BER) - - 13 dB
C/I 1MHz (π/4-DQPSK, 0.1%BER) - - 0 dB
C/I 2MHz (π/4-DQPSK, 0.1%BER) - - -30 dB
C/I ≥3MHz (π/4-DQPSK, 0.1%BER) - - -40 dB
C/I image (π/4-DQPSK, 0.1%BER) - - -7 dB

C/I image±1MHz (π/4-DQPSK,0.1%BER) - - -20 dB

C/I co-channel (8-DPSK, 0.1%BER) - - 21 dB
C/I 1MHz (8-DPSK, 0.1%BER) - - 5 dB
C/I 2MHz (8-DPSK, 0.1%BER) - - -25 dB
C/I ≥3MHz (8-DPSK, 0.1%BER) - - -33 dB
C/I image (8-DPSK, 0.1%BER) - - 0 dB
C/I image±1MHz (8-DPSK, 0.1%BER) - - -13 dB

Intermodulation(BER≤0.1%)

Input = -64dBm, n=5

-39 - - dBm

Out-of-band blocking (CW, BER≤0.1%)

30MHz ~ 2000MHz -10 - - dBm

2000MHz ~ 2399MHz -27 - - dBm
2498MHz ~ 3000MHz -27 - - dBm
3000MHz ~ 12.75GHz -10 - - dBm
Maximum input (GFSK, 0.1% BER) -20 - - dBm

* Normal Condition : 25℃, VDD=3.3V.

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

10. Environment Tests

Item Test Conditions Specifications

Initial values are measured at standard test condition.

Heat

Load Test

Humidity

Load Test

Leave samples in 60℃±3℃ for 96±5 hours, and in

standard test condition for 30 minutes, then take
measurements within 1 hour.

- Supply voltage : standard ± 5%

Initial values are measured at standard test condition.
Leave samples in 40℃±3℃, 90 ~ 95% RH for 96 ±5

hours, and in standard test condition for 30 minutes,

then take measurements within 1 hour.

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

14 / 22

Heat Test

Cold Test

Temperature

Shock

- Supply voltage : standard + 5%

Initial values are measured at standard test condition.
Leave samples in 70℃±2℃ for 96 ±5 hours, and
in standard ambient for 1 hour with standard power

Supply then take measurements within 1 hour.

Initial values are measured at standard test condition.

Leave samples in －20℃±2℃ for 96 ±5 hours, and

in standard ambient for 1 hour with standard power
Supply then take measurements within 1 hour.

Take measurements in standard test condition.
Temp. : -40℃ ~ +85℃
Duration : 30 min
Ramp-up & Ramp-down for 5 min
Cycle : 200cycle.

•TX Power

: ±4dB Max

• Min Input Level
: ±4dB Max

Initial value measure at standard test condition.
Sweep rate : 1 single sweep/ minute

Vibration

Test

Amplitude : 1.5 mm
Frequency : 10-55Hz
Duration : 1 Hours per direction (X,Y,Z)

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

11. Pin Description

Pin No. Pin Name I/O Pin Description

1 VCC I Power Supply 3.3V

2 USB_DN_WiFi I/O WiFi USB Communication signal USB D-

3 USB_DP_WiFi I/O WiFi USB Communication signal USB D+

4 GND I Ground

5 WOWL I Wake On WLAN

6 VCC I Power Supply 3.3V

REV.NO : 2.0

PAGE :

15 / 22

7 WLAN_EN I WiFI_RESET

8 GND I Ground

9 USB_DN_BT I/O BT USB Communication signal USB D-

10 USB_DP_BT I/O BT USB Communication signal USB D+
11 GND I Ground

12 BT_EN I BT_RESET

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

12. Test method

This is a conducted test method of WiFi RF performance.

1) Test Condition.

Auto test
Program

S P E C I F I C A T I O N

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

LAN Cable

LitePoint IQxel

RF Cable

Attanuator

Cable

Power 5V

REV.NO : 2.0

PAGE :

16 / 22

TESCOM
Shield Box
( TC-5910DP)

Power Supply

2) Test Set-up List.

- Instrument : LitePoint IQxel

- Shield Box : Tescom TC-5910DP

- RF Cable : TESCOM 4011-0011

- Attenuator : Mini-Circuit 15542 10dB attenuator

- USB Cable, LAN Cable, Murata RF Cable : MXHT83QE3000 or MXHS83QE3000

- Power Supply

3) Test Flow

- Install the test set-up.

- Power OFF.

- Open the Shield box and install the DUT for test.

- Close the shield box.

- Power ON.

- Check the driver icon.

- Start testing.
#. Notes.

- Be careful that you can consider a RF cable LOSS.

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

S P E C I F I C A T I O N

13. Mechanical Characteristics

1) Outline view

Item Test Conditions

Assembly No defects of wiring, soldering and assembling

Appearance No dirt, rust, corrosion or foreign material

2) Appearance structure

Item Test Conditions

Dimension As assembly drawing

REV.NO : 2.0

PAGE :

17 / 22

Mounting As assembly drawing

Weight 8 g

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

Jangeun Yang

Hojin Roh

Yeongtaek Kang

'17. 09 13

'17. 09 13

'17. 09 13

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

14. Outline Drawing

S P E C I F I C A T I O N

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

REV.NO : 2.0

PAGE :

18 / 22

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

15. Packing Information

S P E C I F I C A T I O N

REV.NO : 2.0

PAGE :

19 / 22

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

S P E C I F I C A T I O N

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

REV.NO : 2.0

PAGE :

20 / 22

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

16. LG CI Specification.

■ LG CI regulation

S P E C I F I C A T I O N

MODEL NAME : TWCM-E001D (LGIT)

WC1NP8

REV.NO : 2.0

PAGE :

21 / 22

■ LG CI print in Carton box

■ Planar figure of Carton box

Logo Ratio – 1 : 0.65
Logo Type Color -- Black

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

FCC and ISED Statements

■

MODEL NAME : TWCM-E001D (LGIT)

S P E C I F I C A T I O N

WC1NP8

REV.NO : 2.0

PAGE :

21 / 22

FCC Part 15.19

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

FCC Part 15.21

Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.

FCC Part 15.105

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

- Consult the dealer or an experienced radio/TV technician for help.

OEM Responsibilities to comply with FCC and Industry Canada Regulations

The module has been certified for integration into products only by OEM integrators under the
following condition:

- The antenna(s) must be installed such that a minimum separation distance of at least 20 cm is
maintained between the radiator (antenna) and all persons at all times.

- The transmitter module must not be co-located or operating in conjunction with any other
antenna or transmitter except in accordance with FCC multi-transmitter product procedures.
As long as the two condition above is met, further transmitter testing will not be required.
However, the OEM integrator is still responsible for testing their end-product for any additional
compliance requirements required with this module installed (for example, digital device
emissions, PC peripheral requirements, etc.).

End Product Labeling

The module is labeled with its own FCC ID and IC Certification Number. If the FCC ID and ISED
Certification Number are not visible when the module is installed inside another device, then the
outside of the device into which the module is installed must also display a label referring to the
enclosed module. In that case, the final end product must be labeled in a visible area with the
following:
“Contains FCC ID: BEJ-WC1NP8
“Contains ISED ID: 2703H- WC1NP8”

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

S P E C I F I C A T I O N

WC1NP8

REV.NO : 2.0

PAGE :

21 / 22

RSS-GEN, Sec. 7.1.3 – (licence-exempt radio apparatus)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux C NR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne
doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

RF Exposure

The antenna (or antennas) must be installed so as to maintain at all times a distance minimum
of at least 20 cm between the radiation source (antenna) and any individual. This device
may not be installed or used in conjunction with any other antenna or transmitter.
l'exposition aux RF L’antenne (ou les antennes) doit être installée de façon à maintenir à tout
instant une distance minimum de au moins 20 cm entre la source de radiation (l’antenne) et toute
personne physique.

Caution: Any changes or modifications to this device not explicitly approved by manufacturer

could void your authority to operate thisequipment.Attention:
Les changements ou modifications de cet appareil non expressément approuvé par le fabricant
peuvent annuler votre droit à utiliser cet équipement.

Étiquetage du produit final (IC)

Le module BT111 est étiqueté avec sa propre identification FCC et son propre numéro de
certification IC. Si l’identification FCC et le numéro de certification IC ne sont pas visibles lorsque
le module est installé à l’intérieur d’un autre dispositif, la partie externe du dispositif dans lequel
le module est installé devra également présenter une étiquette faisant référence au module
inclus.
Dans ce cas, le produit final devra être étiqueté sur une zone visible avec les informations
suivantes :
« Contient module émetteur identification FCC ID : BEJ-WC1NP8
« Contient module émetteur ISED ID : 2703H-- WC1NP8”

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

CE Statements

■

Hereby, LG Electronics Inc. declares that the radio equipment type RF Module is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address:

http://www.lg.com/global/support/cedoc/cedoc#

The antenna(s) must be installed such that a minimum separation distance of at least 20
cm is maintained between the radiator (antenna) and all persons at all times. This device
must not be collocated or operating in conjunction with any other antenna or transmitter.

The host manufacturer integrating this module should be assessed total compliance with
all essential requirements regarding this radio module.

The host manufacturer has the responsibility that the host device should be compliance
with all essential requirement of RED.

MODEL NAME : TWCM-E001D (LGIT)

S P E C I F I C A T I O N

WC1NP8

REV.NO : 2.0

PAGE :

21 / 22

Contact Address

LG Electronics European Shared Service Center B.V. Krijgsman 1, 1186 DM
Amstelveen, The Netherlands

Copyrightⓒ. 2016. All Rights Reserved.

DOCUMENT No :

WC40134

REG. DATE : 2017.11.01

REV. DATE : 2017.11.16

MODEL NAME : TWCM-E001D (LGIT)

S P E C I F I C A T I O N

WC1NP8

REV.NO : 2.0

PAGE :

22 / 22

Change History of Revision

Revision Date Contents of Revision Change Remark

1.0 '17.11.01 First release H.J.Roh

2.0 '17.11.16 Remove 802.11AC specification(Customer request) H.J.Roh

Copyrightⓒ. 2016. All Rights Reserved.
