OWNER’S MANUAL

LG CORDLESS

VACUUM CLEANER

This information contains important instructions for the safe use and maintenance of the vacuum cleaner. Especially, please read all of the information on page 3, 4, 5 for your safety. Please keep this manual in an easily accessible place and refer to it anytime.

VR94070NCAQ

www.lg.com

MFL68480210

Table of contents

Important safety instructions.............................................................................	3~5
How to use.........................................................................................................	6~17
Assembling vacuum cleaner ...........................................................................................	6~8
Operating vacuum cleaner ..............................................................................................	8~9
Robosense™ function.......................................................................................................	10
Using carpet and floor nozzle / hard floor nozzle...............................................................	11
Using the accessory nozzles.............................................................................................	12
Charging the Vacuum Cleaner...........................................................................................	13
Emptying dust tank ...........................................................................................................	14
Cleaning dust tank ............................................................................................................	15
Cleaning air filter and motor safety filter ...........................................................................	16
Cleaning exhaust filter ......................................................................................................	17
What to do if your vacuum cleaner does not work ...........................................	18
What to do when the suction performance decreases ......................................................	18
What to do if Robosense™ function does not work...........................................	19

2

IMPORTANT SAFETY INSTRUCTIONS

Read and follow all instructions before using your vacuum cleaner to prevent the risk of fire, electric shock, personal injury, or damage when using the vacuum cleaner. This guide do not cover all possible conditions that may occur. Always contact your service agent or manufacturer about problems that you do not understand. This appliance complies with the following EC Directives :-2006/95/EC Low Voltage Directive -2004/108/EC EMC Directive.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt you and others.

All safety messages will follow the safety alert symbol and either the word “WARNING” or “CAUTION.” These words mean:

WARNING	This symbol will alert you to hazards or unsafe practices which could cause serious
	bodily harm or death.
CAUTION	This symbol will alert you to hazards or unsafe practices which could cause bodily
	injury or property damage.

WARNING

1.This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

2.Children should be supervised to ensure that they do not play with the appliance.

3.If the supply cord is damaged, it must be replaced by LG Electronics Service Agent in order to avoid a hazard

4.This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

5.CAUTION: This hose contains electrical connections:

–do not use to suck up water ;

–do not immerse in water for cleaning;

3

WARNING

– the hose should be checked regularly and must not be used if damaged.

IMPORTANT SAFETY INSTRUCTIONS

WARNING

•Disconnect electrical supply before servicing or cleaning the unit or when cleaner is not in use.

Failure to do so could result in electrical shock or personal injury.

•Do not use vacuum cleaner to pick up anything that is burning or smoking such as cigarettes, or hot ashes.

Doing so could result in death, fire or electrical shock.

•Do not vacuum flammable or explosive substances such as gasoline, benzene, thinners, propane (liquids or gases).

The fumes from these substances can create a fire hazard or explosion. Doing so could result in death or personal injury.

•Do not handle plug or vacuum cleaner with wet hands.

Doing so could result in death or electrical shock.

•Do not unplug by pulling on cord.

Doing so could result in product damage or electrical shock. To unplug, grasp the plug, not the cord.

•Keep hair, loose clothing, fingers, and all parts of the body away from openings and moving parts.

Failure to do so could result in electrical shock or personal injury.

•The hose contains electrical wires. Do not use it if it is damaged, cut punctured.

Failure to do so could result in death, or electrical shock.

•Do not allow to be used as toy. Close attention is necessary when used by or near children.

Personal injury or product damage could result.

•Do not use the vacuum cleaner if the power cord or plug is damaged or faulty.

Personal injury or product damage could result. In these cases, contact LG Electronics Service Agent to avoid hazard.

•Do not use vacuum cleaner if it has been under water.

Personal injury or product damage could result. In these cases, contact LG Electronics Service Agent to avoid hazard.

•Do not continue to vacuum if any parts appear missing or damaged.

Personal injury or product damage could result. In these cases, contact LG Electronics Service Agent to avoid hazard.

•Do not use an extension cord with this vacuum cleaner.

Fire hazard or product damage could result.

•Using proper voltage.

Using improper voltage may result in damage to the motor and possible injury to the user. Proper voltage is listed on the bottom of vacuum cleaner.

•Do not change the plug in any way.

Failure to do so could result in electrical shock or personal injury or product damage. Doing so result in death. If plug does not fit, contact a qualified electrician to install the proper outlet. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

•Repairs to electrical appliances may only be performed by qualified service engineers.

Improper repairs may lead to serious hazards for the user.

•Do not wash the body of the vacuum cleaner with water.

•Do not allow any metals to touch the charging terminal and the connecting joints of the body and hose.

•Before cleaning the body, unplug the power cord and turn off the main power. Always use a dry cloth to clean the body.

•Avoid placing the product, the battery in particular, near any heat source or direct sunlight.

There is danger of an explosion or a fire.

•When disposing of batteries, please follow appropriate disposal methods.

There is danger of an explosion.

•Do not use the product in bathrooms.

•When a problem occurs with the product, stop vacuuming and turn off the main power.

•Do not place the product near industrial oil fumes or metal particulates.

Doing so could result in fire or damage to the product.

•If the battery has leaked, avoid contact with the skin or eyes. If the battery fluid gets on your skin or in your eyes, immediately rinse the affected part with plenty of water and seek medical attention.

Battery fluid may cause a burn on your skin or loss of eyesight.

•Do not put fingers near the gear.

Failure to do so could result in personal injury.

gear

4

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

•Do not put any objects into openings.

Failure to do so could result in product damage.

•Do not use with any opening blocked: keep free of dust, lint, hair, and anything that may reduce air flow.

Failure to do so could result in product damage.

•Do not use vacuum cleaner without the dust tank and/or filters in place.

Failure to do so could result in product damage.

•Always clean the dust bin after vacuuming carpet cleaners or fresheners, powders and fine dust.

These products clog the filters, reduce airflow and can cause damage to the cleaner. Failure to clean the dust bin could cause permanent damage to the cleaner.

•Do not use vacuum cleaner to pick up sharp hard objects, small toys, pins, paper clips, etc.

They may damage the cleaner or dust bin.

•Store the vacuum cleaner indoors.

Put the vacuum cleaner away after use to prevent tripping over it.

•The vacuum cleaner is not intended to use by young children or infirm people without supervision.

Failure to do so could result in personal injury or product damage.

•Only use parts produced or recommended by LG Electronics Service Agents.

Failure to do so could result in product damage.

•Use only as described in this manual. Use only with LG recommended or approved attachments and accessories.

Failure to do so could result in personal injury or product damage.

•To avoid personal injury and to prevent the machine from falling when cleaning stairs, always place it at the bottom of stairs.

Failure to do so could result in personal injury or product damage.

•Do not grasp the tank handle when you are moving the vacuum cleaner.

The vacuum cleaner’s body may fall when separating tank and body. Personal injury or product damage could result. You should grasp the carrier handle when you are moving the vacuum cleaner. (Page 14)

•Make sure the filters (motor safety filter and air filter) are completely dry before replacing in the machine.

Failure to do so could result in product damage.

•Do not dry the filter in an oven or microwave.

Failure to do so could result in fire hazard.

•Do not dry the filter in a clothes dryer.

Failure to do so could result in fire hazard.

•Do not dry near an open flame.

Failure to do so could result in fire hazard.

•Do not use filters that is not dried.

•If the power cord is damaged, it must be replaced by an approved LG Electronics Service Agent to avoid a hazard.

•This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

•Do not approach to vacuum cleaner suddenly, when Robosense™ function activated.

Failure to do so could result in personal injury or product damage.

•The battery for the main body is designed for this vacuum cleaner only. Never use it for any other product.

Doing so could result in fire or damage to the product.

•Do not use the floor nozzle to clean high areas.

•When you dry the filter, do not use a heating device such as a dryer or heater. Leave it in an airy place and let it dry completely.

•Do not carry the vacuum cleaner with the nozzle head connected to the body.

•Empty the dust bin frequently to keep it clean.

•Always use the vacuum cleaner with the filter unit assembled in the dust bin.

•Never remove the hose or pipe when the main power is On.

•Use this vacuum cleaner for household use only.

Thermal protector :

This vacuum cleaner has a special thermostat that protects the vacuum cleaner in case of motor overheating. If the vacuum cleaner suddenly shuts off, turn off the Main Power Switch. Check the vacuum cleaner for possible source of overheating such as a full dust tank, a blocked hose or clogged filter. If these conditions are found, fix them and wait at least 30 minutes before attempting to use the vacuum cleaner. After the 30 minute period, turn on the Main Power Switch.

If the vacuum cleaner still does not run, contact a qualified electrician.

5

How to use Assembling vacuum cleaner

Hose Handle

Spring latch

Transmitting sensor

Telescopic pipe

Carpet and floor nozzle (depend on model)

Push the telescopic pipe into the nozzle.

Telescopic pipe

•Push telescopic pipe firmly into hose handle.

•Grasp the spring latch to expand.

•Pull out the pipe to desired length.

6

Click!	Charging terminal	Receiving sensors

Button

Battery indicator

Fitting pipe

Flexible Hose

Attachment Point

Connecting the hose to the vacuum cleaner

Push the fitting pipe on the flexible hose into the attachment point on the vacuum cleaner.

To remove the flexible hose from the vacuum cleaner,press the button situated on the fitting pipe, then pull the fitting pipe out of the vacuum cleaner.

7

How to use Operating vacuum cleaner

Charging terminal

Main power switch

Control Button

MAX line.

Power button

Control mode button

How to operate	Emptying the dust tank

•Please disconnect the charging cord from the product.

•To operate the vacuum cleaner, press down the power button for about 1 second.

•When you turn it on, Mode is the Middle power.

•You can control Mode of the power using ‘ + ’, ‘ – ’ Button.

•To turn off, Push the power button.

•After the used, Please connect the charging cord to the product.

•Always empty the dust tank when the dust tank level reaches the MAX line.

8

How to use Operating vacuum cleaner

Park mode		Storage

•Turn off the Main power switch position before park.

•To store during vacuuming, for example to move a small piece of furniture or a rug, use park mode to

support the flexible hose and nozzle.

-Slide the hook on the nozzle into the slot on the side of vacuum cleaner.

•After the used product, please connect the charging cord to the product.

•You can store your vacuum cleaner in a vertical position by sliding the hook on the nozzle into the slot on the underside of the vacuum cleaner.

WARNING

No liquid suction.

Liquid suction can cause defects.

9

How to use Robosense™ function

Robosense™ function can measure distance	Transmitting sensor
between the user and vacuum cleaner. After
the measurement, vacuum cleaner will move			Receiving
			sensors
automatically to keep a constant distance
(about 1.0m) between the user and the vacuum
		1 m
cleaner. When distance between transmitting
sensor in the grip handle and receiver sensors
on the vacuum cleaner becomes more than
1m, Vacuum cleaner will move automatically
toward the user. If the distance remains within
1 m, the body just rotates to face the user. The
Auto Moving function does not work properly on
carpets with long hair (longer than 20 mm).

•When using vacuum cleaner, be careful not to block the transmitting sensor by wall or body. If transmitting sensor was blocked, Robosense™ function cannot work properly.

•Keep the direction of grip handle to receiving sensors for sending the signal. If the hose points the wrong direction, Robosense™ function cannot work properly.

NOTICE

Do not put liquid such as water and drink in transmitting sensor and receiving sensors.

Robosense™ function cannot work properly.

10

How to use Using carpet and floor nozzle / hard floor nozzle

1

Carpet

Pedal

Floor

Carpet and floor nozzle (depend on model)

• The 2 position nozzle

This is equipped with a pedal which allows you to alter its position according to the type of floor

to be cleaned.

• Carpet or rug position

Press the pedal ( ) to lower brush.

• Hard floor position (tiles, parquets floor) Press the pedal ( ) to lift the brush up.

• Cleaning carpet and floor nozzle

Hard floor nozzle (depend on model)

• Efficient cleaning of hard floors

(wood, linoleum, etc)

• Clean the hole and brush of nozzle.

11

How to use Using accessory nozzles

Crevice tool Upholstery nozzle Dusting brush

3

4

5

Crevice tool	Upholstery nozzle
Crevice tool is for vacuuming	Upholstery nozzle is for
in those normally hard-	vacuuming upholstery,
to-reach places such as	mattresses etc.
reaching cobwebs or between
the cushions of a sofa.
	Push the button

Dusting brush

Dusting brush is for vacuuming picture frames, furniture frames, books and other irregular surfaces.

Pull the cover

<Upholstery nozzle mode>

<Dusting brush mode>

NOTICE

Be cautious to use the product on TV, LCD, Monitor or furniture, it can cause small scratch.

• PE BAG •

• Accessory nozzles are included in the "PE BAG" with owner's manual.

12
