LG V-KC403HT User Manual
1
P/No.: 3828FI2873Q
New Type Cyclone vacuum cleaner
OWNER'S MANUAL
V-KC403HT
3828Fi2873Q
2
3828Fi2873Q
Table of contents
Information for Your Safety......................................................................................3
How to Use.................................................................................................................4
Assembling Cleaner ..............................................................................................................4
Using the Cleaning head and Accessory Nozzles.................................................................6
Emptying the Dust Tank........................................................................................................8
Vacuum Cleaner Operation...................................................................................................9
Cleaning the Dust Tank.................................................................................................10~11
Cleaning the Air Filter..........................................................................................................12
Cleaning the Exhaust Filter .................................................................................................13
What to do if your Vacuum Cleaner does not work.............................................14
What to do when suction performance decreases..............................................14
3
3828Fi2873Q
Information for Your Safety
Please read all the following information, which contains important instructions for the safety,
the use and the maintenance of the appliance.
This appliance complies with the following EC Directives:
-73/23/EEC, 93/68/EEC-Low Voltage Directive-89/336EEC -EMC Directive.
❏ Never allow children to use the appliance unsupervised.
❏ Do not use the vacuum as a toy, injury could result.
❏ Do not continue to vacuum if any defect appears, missing or damaged.
In these cases, contact an approved LG Electronics Service Agent.
❏ Repairs, when necessary, must be performed at an approved LG Electronics Service Agent.
❏ Only use parts produced or recommended by LG doing otherwise could invalidate your guarantee.
❏ Do not use without the dust tank or air filter.
❏ Do not use the vacuum cleaner If the power cord is damaged or faulty.
❏ If the power cord is damaged, it must be replaced by an approved LG Electronics Service Agent to avoid a hazard.
❏ Do not unplug by pulling on cord.
❏ Do not pull on the supply cord, run over it, pull it around sharp edges or near/over hot surfaces.
❏ Always turn the vacuum cleaner off before:
Emptying the dust tank.
Cleaning or changing the filter.
Romoving from the mains outlet.
❏ Do not leave vacuum cleaner with the plug connected to a mains outlet-unplug when not in use.
❏ Do not use the vacuum with any of the openings blocked with any object that may restrict the airflow.
❏ Do not put any part of the body, colthes or any object (e.g. stick) into the opening or moving parts of the cleaner.
❏ Do not use outdoors.
❏ Do not vacuum hot ash, embers etc. or sharp objects.
❏ Do not vacuum flammable or explosive substances(liquids or gases).
❏ Do not vacuum water or other liquids.
❏ Do not handle the cleaner or plug with wet hands.
❏ Do not immerse the whole cleaner in water.
❏ Do not use vacuum cleaner without repaired if it was under water.
❏ When you vacuum with an attachment appliance that has a rotating brush roller:
Do not reach into the running brush roller.
❏ The appliance is not intended for use by young children or infirm persons without supervision.
Young children should be supervised to ensure that they do not play with the appliance.
❏ Do not vacuum fine dust.
❏ Do not expose vacuum cleaner to heat.
Thermal protector:
This vacuum cleaner has a special thermostat that protects the cleaner in case of motor overheating.
If the cleaner suddenly shuts off, turn off the switch and unplug the cleaner.
Check the cleaner for a possible source of overheating such as a full dust tank, a blocked hose or clogged filter.
If these conditions are found, fix them and wait at least 30 minutes before attempting to use the cleaner.
After the 30 minutes period, plug the cleaner back in and turn on the switch.
If the cleaner still does not run, contact a qualified electrician.
1
2
Telescopic pipe
Spring latch
4
3828Fi2873Q
How to Use
Assembling Cleaner
Fit the large cleaning head onto
the end of the pipe.
Large cleaning head
Push the head onto the
telescopic pipe.
Telescopic pipe
• Press the spring latch to release.
• Pull out the pipe to the desired length.
• Release spring latch to lock the pipe in position.
• Push telescopic pipe into hose handle firmly.
3
Attachment Point
Button
Flexible Hose
Head
5
3828Fi2873Q
Connecting the hose to the cleaner
Push the head end of the flexible hose into
the attachment point on the vacuum cleaner.
To remove the flexible hose from the body,
press on the button located on the head,
then pull the head out of the vacuum cleaner.
