2
Table of contents
Important safety instructions
How to use
Assembling vacuum cleaner
Operating vacuum cleaner
Using smart adjustment nozzle / Hard floor nozzle
Using accessory nozzles
Emptying dust tank
Cleaning dust tank
Cleaning dust separator
Using the semi auto filter cleaner
Cleaning the fine dust tank
Cleaning air filter and motor safety filter
Cleaning dust tank
Cleaning exhaust filter
Check before requesting for service
What to do if your vacuum cleaner does not work
What to do when suction performance decreases
...................................................................
....................................................................................................
..............................................................................
................................................................................
..................................................
.................................................................................
.........................................................................................
.........................................................................................
..................................................................................
......................................................................
...............................................................................
..............................................................
.........................................................................................
....................................................................................
...................................................................
...................................
...................................
4~5
6
6
8
9
10
11
12
13
14
14
15
16
17
18
19
19
3
IMPORTANT SAFETY INSTRUCTIONS
Read and follow all instructions before using your vacuum cleaner to prevent the risk of fire,electric shock, personal injury, or
damage when using the vacuum cleaner. This guide do not cover all possible conditions that may occur. Always contact your
service agent or manufacturer about problems that you do not understand. This appliance complies with the following EC
Directives : -2006/95/EC Low Voltage Directive 2004/108/EC EMC Directive.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word WARNING or CAUTION.
These words mean:
WARNING
This symbol will alert you to hazards or unsafe practices which could cause serious
bodily harm or death.
CAUTION
This symbol will alert you to hazards or unsafe practices which could
cause bodily injury or property damage.
WARNING
•
Do not plug in if control knob is not in OFF position.
Personal injury or product damage could result.
•
Keep children away and beware of obstructions
when rewinding the cord to prevent personal injury
The cord moves rapidly when rewinding.
•
Disconnect electrical supply before servicing or
cleaning the unit or when cleaner is not in use.
Failure to do so could result in electrical shock or personal
injury.
•
Do not use vacuum cleaner to pick up anything that
is burning or smoking such as cigarettes, or hot
ashes.
Doing so could result in death, fire or electrical shock.
•
Do not vacuum flammable or explosive substances
such as gasoline, benzene, thinners, propane and
dust hazardous to health (liquids or gases).
The fumes from these substances can create a fire hazard
or explosion. Doing so could result in death or personal
injury.
•
Do not handle plug or vacuum cleaner with wet
hands.
Doing so could result in death or electrical shock.
•
Do not unplug by pulling on cord.
Doing so could result in product damage or electrical shock.
To unplug, grasp the plug, not the cord.
•
Keep hair, loose clothing, fingers, and all parts of
the body away from openings and moving parts.
Failure to do so could result in electrical shock or personal
injury.
•
Do not pull or carry by cord, use cord as a handle,
close a door on cord, or pull cord around sharp
edges or corners. Do not run vacuum cleaner over
cord. Keep cord away from heated surfaces.
Failure to do so could result in electrical shock or personal
injury or fire or product damage.
•
The hose contains electrical wires. Do not use it if it
is damaged, cut or punctured.
Failure to do so could result in death,or electrical shock.
•
Do not allow to be used as toy. Close attention is
necessary when used by or near children.
Personal injury or product damage could result.
•
Do not use the vacuum cleaner if the power cord or
plug is damaged or faulty.
Personal injury or product damage could result. In these
cases, contact LG Electronics Service Agent to avoid hazard.
•
Do not use vacuum cleaner if it has been under water.
Personal injury or product damage could result. In these
cases, contact LG Electronics Service Agent to avoid hazard.
•
Do not continue to vacuum if any parts appear
missing or damaged.
Personal injury or product damage could result. In these
cases, contact LG Electronics Service Agent to avoid hazard.
•
Do not use an extension cord with this vacuum
cleaner
Fire hazard or product damage could result.
•
Using proper voltage.
Using improper voltage may result in damage to the motor
and possible injury to the user. Proper voltage is listed on
the bottom of vacuum cleaner.
•
Turn off all controls before unplugging.
Failure to do so could result in electrical shock or personal injury.
•
Do not change the plug in any way.
Failure to do so could result in electrical shock or personal
injury or product damage. Doing so result in death. If plug
does not fit, contact a qualified electrician to install the
proper outlet.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
•
Repairs to electrical appliances may only be
performed by qualified service engineers.
Improper repairs may lead to serious hazards for the user.
•
Do not put fingers near the gear.
Failure to do so could result in personal injury.
4
IMPORTANT SAFETY INSTRUCTIONS
Thermal protector :
This vacuum cleaner has a special thermostat that protects the vacuum cleaner in case of motor
overheating. If the vacuum cleaner suddenly shuts off, turn off the switch and unplug the vacuum cleaner.
Check the vacuum cleaner for possible source of overheating such as a full dust tank, a blocked hose or
clogged filter. If these conditions are found,fix them and wait at least 30 minutes before attempting to use
the vacuum cleaner. After the 30 minute period, plug the vacuum cleaner back in and turn on the switch.
If the vacuum cleaner still does not run, contact the manufacturer for user support.
CAUTION
•
Do not put any objects into openings.
Failure to do so could result in product damage.
•
Do not use with any opening blocked: keep free of
dust, lint, hair, and anything that may reduce air
flow.
Failure to do so could result in product damage.
•
Do not use vacuum cleaner without dust tank and/or
filters in place.
Failure to do so could result in product damage.
•
Always clean the dust bin after vacuuming carpet
cleaners or fresheners, powders and fine dust.
These products clog the filters, reduce airflow and can
cause damage to the cleaner. Failure to clean the dust bin
could cause permanent damage to the cleaner.
•
Do not use vacuum cleaner to pick up sharp hard
objects, small toys, pins, paper clips, etc.
They may damage the cleaner or dust bin.
•
Store the vacuum cleaner indoors.
Put the vacuum cleaner away after use to prevent tripping
over it.
•
The vacuum cleaner is not intended to use by young
children or infirm people without supervision.
Failure to do so could result in personal injury or product
damage.
•
Only use parts produced or recommended by LG
Electronics Service Agents.
Failure to do so could result in product damage.
•
Use only as described in this manual. Use only with
LG recommended or approved attachments and
accessories.
Failure to do so could result in personal injury or product
damage.
•
To avoid personal injury and to prevent the machine
from falling when cleaning stairs, always place it at
the bottom of stairs.
Failure to do so could result in personal injury or product
damage.
•
Use accessory nozzles in sofa mode.
Failure to do so could result in product damage.
•
Don t grasp the tank handle when you are moving
the vacuum cleaner.
The vacuum cleaner s body may fall when separating tank
and body.Personal injury or product damage could result.
You should grasp the carrier handle when you are moving
the vacuum cleaner. (Page 11)
•
If after emptying the dust tank the indicator light is
on(red), clean the dust tank.
Failure to do so could result in product damage.
•
Make sure the filters (exhaust filter and motor safety
filter) are completely dry before replacing in the
machine.
Failure to do so could result in product damage.
•
Do not dry the filter in an oven or microwave.
Failure to do so could result in fire hazard.
•
Do not dry the filter in a clothes dryer.
Failure to do so could result in fire hazard.
•
Do not dry near an open flame.
Failure to do so could result in fire hazard.
•
Do not use filters that are not dried.
•If the power cord is damaged, it must be replaced
by an approved LG Electronics Service Agent to
avoid a hazard
•This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do
not play with the appliance
•This appliance is not suitable for picking up
hazardous dust.
•This appliance is for dry use only and is not to be
used or stored outdoors in wet conditions.
•Regularly examine the supply cord for damage,
such as cracking or ageing. If damage is found,
replace the cord before further use.
5
•Push telescopic pipe firmly into hose handle.
•Grasp the spring latch to expand.
•Pull out the pipe to desired length.
➊ Smart adjustment nozzle
Hard floor nozzle
➋ Telescopic pipe
Push the nozzle into the telescopic pipe.
How to use
Assembling vacuum cleaner
6
Spring latch
Telescopic pipe
Hose handle
1-1
1-1
Fitting pipe
Flexible hose
Button
7
➌ Connecting the hose to the vacuum cleaner
Attachment point
Push the fitting pipe on the flexible hose
into the attachment point on the vacuum cleaner.
To remove the flexible hose from the vacuum
cleaner, press the button situated on the fitting pipe,
then pull the fitting pipe out of the vacuum cleaner.
8
Plug
Control knob
How to use
Operating vacuum cleaner
➊ How to operate
•Pull out the power cord to the
desired length and plug into the
socket.
•Place the control knob of the
hose handle to the required
position.
•To turn off, slide control knob to
OFF position.
•Press the cord reel button to
rewind the power cord after use.
➌
Park mode
•To store during
vacuuming, for example
to move a small piece of
furniture or a rug, use
park mode to support the
flexible hose and nozzle.
- Slide the hook on the
nozzle into the slot on
the rear of vacuum
cleaner.
NOTICE
When alarm sounds :
1. Dust tank is full
slide handle knob to OFF position and empty dust tank
2. Power is on without dust tank
slide handle knob to OFF position and reattach dust tank
3. Rotating plate in the dust tank is restricted because of obstruction
slide handle knob to OFF position and remove obstruction
➋
Alarm sound
•Alarm will sound when dust
tank is full.
After about 1 min 30 sec,
vacuum cleaner will turn itself off
and alarm will sound.
Empty the dust tank and reuse
the vacuum cleaner.
Cord reel button
9
How to use
Carpet
Floor
Carpet
Floor
How to use
Using Smart Adjustment Nozzle / Hard floor nozzle
➊
Smart Adjustment Nozzle
•Auto Adjustment according to type of floor (carpet or floor)
•Visible Indicator Feature : Color of indicator is changed
when cleaning on carpet
➋ Hard floor nozzle
•Efficient cleaning of hard floors
(wood, linoleum, etc)
Indicator
10
➋
Dusting brush
Dusting brush is for vacuuming picture
frames, furniture frames, books and
other irregular surfaces.
➌
Crevice tool
Crevice tool is for vacuuming in those
normally hard-to-reach places such as
reaching cobwebs or between the
cushions of a sofa.
•Accessory nozzles included in the "BOX" with
owner’s manual.
How to use
Using accessory nozzles
NOTICE
Use accessory in the sofa mode
•BOX•
•Crevice tool included in the
vacuum cleaner body.
Pull back the cover to
lock it into position.
< Dusting brush mode >
Crevice tool
Dusting brush
< upholstery mode >
Functions as a dusting brush and
an upholstery nozzle which is useful
when cleaning furniture.
Attach as shown.
11
The dust tank needs to be emptied when alarm sounds from
the vacuum cleaner.
Moving the vacuum cleaner
•You should grasp the carrier handle when you are moving the vacuum
cleaner.
•Turn off the vacuum cleaner and unplug it.
•Grasp the handle of the tank and then press the tank
separation button.
•Pull out the dust tank.
•Empty the tank and then assemble the dust tank as shown.
NOTICE
•If suction power decreases after empting dust tank, wash the dust tank
next page
•Since dust tank is assumed to be full, alarm continues to sound for 1
min 30 sec and suction power will decrease for a while, then vacuum
cleaner will turn itself off.
How to use
Emptying dust tank
Assembling dust tank
Carrier handle
Dust tank cap
Pull out
Tank handle
Tank separation button
How to use
Cleaning dust tank
NOTICE
If suction power decreases after washing the dust tank,
clean air filter and motor safety filter 15 page
•Press tank separation button and pull out dust tank.
•Raise dust tank cap.
•Empty the dust tank and wash it.
•Allow the tank to dry completely before reassembling and
use.
12
Tank separation button
Pull out
Tank handle
Dust tank cap
How to use
Cleaning dust separator
➊
How to separate
•When suction power is decreased, please clean the dust separator.
•Open the Vacuum cleaner cover by pushing the button.
Hold tank separator handle and take it out.
Open the guide cover by pulling the guide cover lever and remove dust.
13
Dust separator
guide cover lever
How to use
Using the semi auto filter cleaner
How to use
Cleaning the fine dust tank
14
NOTICE
If suction power is decreased after turn the dial a few times.
Please operating vacuum cleaner after cleaning or washing the dust separator and air filter & motor safety filter.
NOTICE
If vacuum cleaner is operated over medium power mode, it may not work efficiently.
Grasp the dial and
please turn the dial a few times in CW.
➊ Press the separate button
to separate the hose
handle and telescopic pipe
➌ Insert the hose handle
into a hole and turn on the
vocuum cleaner with low mode.
➋ Please open
the dust cap up.
separation button
dial
➊
How to clean
If suction power is decreased after cleaning dust tank,
clean air filter and motor safety filter.
Air filter and motor safety filter are located at the up of vacuum
cleaner in the above figure.
•Wash air filter and motor safety filter with water.
•Do not wash filters with hot water.
•Dry fully in shade so that moisture is entirely removed.
•Air filter and motor safety filter should be cleaned in the above
case.
•Do not use filters that is not dried.
➋
How to assemble
•Insert the motor protection filter to the filter case.
•Close the filter cover.
•Close the dust separator cover.
•Hold the handle of the dust separator to firmly assemble
it by pressing it down.
•Close the cleaner cover.
NOTICE
If filters are damaged, do not use them.
In this cases, contact LG Electronics Service Agent.
Wash filters at least once a week.
(Reassemble air filter so
green color is shown)
motor safety filter
air filter
How to use
Cleaning air filter and motor safety filter
15
How to use
Cleaning fine dust tank
NOTICE
If suction power decreases after washing the dust tank,
clean air filter and motor safety filter 15 page
•Press exhaust filter cover lever and separate exhaust filter
cover.
•Take fine dust tank out.
•Empty the dust tank and wash it.
•Allow the tank to dry completely before reassembling and
use.
LOCK
UNLOCK
Lever
Exhaust filter cover
Fine dust tank
16
How to use
Cleaning exhaust filter
•The exhaust filter is a reuseable.
•To clean the exhaust filter, remove the Exhaust filter cover on the body
by pulling out it.
•Separate the exhaust filter.
•Dust off filter.(Do not wash filter with water.)
•The exhaust filter should be cleaned at least a year.
Exhaust filter cover assembling
•Fit exhaust filter cover lugs to the grooves of vacuum cleaner body.
•Join it the body.
LOCK
Lever
Exhaust filter cover
Button
17
(Reassemble air filter so
green color is shown)
motor safety filter
air filter
Suddenly, the suction
does not work.
➊ How to separate
①Raise the handle of vacuum cleaner.
②Grasptheknobofthemotorsafetyfilterand
takeitout.
③Pull out motorsafety filter
➋ How to clean(Clean with cold water.)
①Clean well in flowing water.
②Remove the moisture thoroughly.
③Completely dry it under the shade where it is well
ventilated before reusing it.
How to use
Check before requesting for service
You should not waste money by requesting for service only to find out that it’s not a problem.
If you experience any issues with the product, check the following details before contacting the service
center or the distributor. You may be able to resolve the issue by a simple instruction from the user manual.
•Stage 1 : Check whether the suction control button is set to "High"
•Stage 2 : Clean the dust separator and check and clean all other filters if necessary.
18
What to do if your vacuum cleaner does not work
What to do when suction performance decreases
Check that the vacuum cleaner is plugged in correctly and that the electrical socket is working.
•Turn off the vacuum cleaner and unplug it.
•Check the telescopic pipe, flexible hose and cleaning tool for blockages or obstructions.
•Check that the dust tank is not full. Empty if necessary.
•Check that the exhaust filter is not clogged. Clean the exhaust filter if necessary.
•Check that the air filter is not clogged. Clean the air filter if necessary.
19
Note
LOCK
LOCK
UNLOCK
..............................................................................
.................................................................................................
......................................................................................
.........................................................................................
...................................
...............................................................................
..................................................................................................
...........................................................................................
.....................................................................
...............................................................
..................................................................................
.............................................................
...............................................................................................
............................................................................
.................................................................
....................................................................
.....................................................................
Loading...
