Model
Language
Page
Material Size(W*H)
Date
Part No.
V-C6501HTU.CBNQBWT & V-C6502HT.CBTQBWT
English & Russian
9
Weight
100g
2005.09.15
MFL32709203
Color(cover/body)
Designer
Description
1/1
150*220(mm)
JIA LEI
owner's manual
Chage Record
No. Date
change the file for new accessory
1
2
change the file for cleaning powerful turbine brush
3
4
5
6
7
8
9
Change content
ECO No.
ACTT605906
ACTT605972
06.09.25
06.09.28
Designer
jialei
jialei
Confirm
cuiyt
cuiyt
V-C6501HTU
V-C6502HT
E
P/No.:MFL32709203
13
14
8
9
10
– 2 –
6
7
8
10 30
12
17
9
13
14
16
18
18
20
– 3 –
Очистка Мощная туpбощетка
Откpойте
Откpойте
Cleaning Powerful Turbine Brush
Видсвеpху
Вид снизу
Open
Top
Open
Bottom
26
24
25
27
29
28
- 4 -
E
Information for your safety
Please read all the following information,
which contains important instructions for
the safety, the use and the maintenance
of the appliance.
This appliance complies with the following
EC Directives: -73/23/EEC, 93/68/EECLow Voltage Directive-89/336EEC -EMC
Directive.
Never allow children to use the appliance
unsupervised.
Do not use the appliance If the main lead
is damaged or faulty.
If the main lead is damaged, it must be
replaced by an approved LG Electronics
Service Agent to avoid a hazard.
Always switch the vacuum cleaner off
before :
• changing the dust bag
• changing or cleaning the filters.
If no dustbag is inserted, the cover
cannot be closed. Please do not use
force!
Do not vacuum flammable or explosive
substances(liquids or gases).
Do not vacuum hot ash, embers etc. nor
sharp objects.
Do not vacuum water or other liquids.
When you vacuum with an attachment
appliance that has a rotating brush roller,
do not reach into the running brush roller.
How to Use
Connecting the flexible hose
Push the end of the head (1) on the flexible
hose (2) into the attachment point on the
vacuum cleaner.
To remove the flexible hose from the
vacuum cleaner, press on the button (3)
situated on the head, then pull upwards.
Assembling the tubes
• Telescopic tube (4)
(depending on model)
- Hold spring latch (5)
- Pull out the tube to required length.
- Release spring latch to lock.
- Assembly(30): Connect the nozzle to
the telescopic tube.
Using the cleaning head and Accessory
Nozzles
Fit the large cleaning head onto the end of the
tube.
• The 2 position head (6) is equipped with a
pedal (7) which allows you to alter its
position according to the type of floor to be
cleaned.
Hard floor position(tiles, parquet floors...).
Press on the pedal to lower the brush.
Carpet or rug position.Press on the pedal
to lift the brush up.
•
Upholstery Nozzle (8)
Upholstery Nozzle is for vacuuming upholstery,
mattresses, etc.
The thread collectors help to pick up the
threads and fluff.
•
Dusting Brush & Crevice Tool (9)
Dusting Brush is for vacuuming picture frames,
furniture frames, books and other irregular
surfaces.
Crevice Tool is for vacuuming in those
normally hard-to-reach places such as reaching
cobwebs, or between the cushions of a sofa.
•
Accessory Holder can be attached on the
Extention wands using clamping hook.
Accessories can be stored in the holder (10).
(depending on model)
How to plug in and use
Pull out the mains lead to the desired
length and plug into the socket.
Adjusting the power level
•
Electronic power control (12)
Suction capacity increases smoothly
up to MAX.
Storage (11)
When you have switched off and unplugged
the appliance, press on the button (14) to
automatically rewind the cord.
You can move or store your appliance in a
vertical position by sliding the hook on the
large cleaning head into the clip on the
underside of the appliance.
– –
5
-
(7)
(30):
(6)
(8)
(9)
(12)
(10)
(11)
(14)
(18)
(13)
(15)
(19)
(23)
(22)
(21)
(23)
P/No.:MFL32709203
