OWNER’S MANUAL
NEW TYPE CYCLONE
VACUUM CLEANER
This information contains important instructions for the safe use and maintenance of the vacuum cleaner. Especially, please read all of the information on page 3, 4, 5 for your safety. Please keep this manual in an easily accessible place and refer to it anytime.
VB-8520HRF
VB-8520HTS
www.lg.com
MFL68000013
Table of contents
Important safety instructions ...................................................................... |
3~5 |
How to use .................................................................................................. |
6~14 |
Assembling vacuum cleaner ........................................................................................ |
6 |
Operating vacuum cleaner ........................................................................................... |
8 |
Using carpet and floor nozzle / Corner free nozzle ...................................................... |
9 |
Using accessory nozzles ........................................................................................... |
10 |
Emptying dust tank .................................................................................................... |
11 |
Cleaning dust tank ..................................................................................................... |
12 |
Cleaning dust separator ............................................................................................. |
13 |
Cleaning exhaust filter ............................................................................................... |
14 |
What to do if your vacuum cleaner does not work ..................................... |
15 |
What to do when suction power decreases ................................................ |
15 |
2
IMPORTANT SAFETY INSTRUCTIONS
Read and follow all instructions before using your vacuum cleaner to prevent the risk of fire, electric shock, personal injury, or damage when using the vacuum cleaner. This guide do not cover all possible conditions that may occur. Always contact your service agent or manufacturer about problems that you do not understand.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “WARNING” or “CAUTION.” These words mean:
WARNING |
This symbol will alert you to hazards or unsafe practices which could cause serious |
bodily harm or death. |
|
CAUTION |
This symbol will alert you to hazards or unsafe practices which could |
cause bodily injury or property damage. |
WARNING
1.This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
2.Children should be supervised to ensure that they do not play with the appliance.
3.If the supply cord is damaged, it must be replaced by LG Electronics Service Agent in order to avoid a hazard
4.This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
3
IMPORTANT SAFETY INSTRUCTIONS
WARNING
•Do not plug in if control knob is not in OFF position.
Personal injury or product damage could result.
•Keep children away and beware of obstructions when rewinding the cord to prevent personal injury
The cord moves rapidly when rewinding.
•Disconnect electrical supply before servicing or cleaning the unit or when cleaner is not in use.
Failure to do so could result in electrical shock or personal injury.
•Do not use vacuum cleaner to pick up anything that is burning or smoking such as cigarettes, or hot ashes.
Doing so could result in death, fire or electrical shock.
•Do not vacuum flammable or explosive substances such as gasoline, benzene, thinners, propane (liquids or gases).
The fumes from these substances can create a fire hazard or explosion. Doing so could result in death or personal injury.
•Do not handle plug or vacuum cleaner with wet hands.
Doing so could result in death or electrical shock.
•Do not unplug by pulling on cord.
Doing so could result in product damage or electrical shock. To unplug, grasp the plug, not the cord.
•Keep hair, loose clothing, fingers, and all parts of the body away from openings and moving parts.
Failure to do so could result in electrical shock or personal injury.
•Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not run vacuum cleaner over cord. Keep cord away from heated surfaces.
Failure to do so could result in electrical shock or personal injury or fire or product damage.
•The hose contains electrical wires. Do not use it if it is damaged, cut punctured.
Failure to do so could result in death, or electrical shock.
•Do not allow to be used as toy. Close attention is necessary when used by or near children.
Personal injury or product damage could result.
•Do not use the vacuum cleaner if the power cord or plug is damaged or faulty.
Personal injury or product damage could result. In these cases, contact LG Electronics Service Agent to avoid hazard.
•Do not use vacuum cleaner if it has been under water.
Personal injury or product damage could result. In these cases, contact LG Electronics Service Agent to avoid hazard.
•Do not continue to vacuum if any parts appear missing or damaged.
Personal injury or product damage could result. In these cases, contact LG Electronics Service Agent to avoid hazard.
•Do not use an extension cord with this vacuum cleaner.
Fire hazard or product damage could result.
•Using proper voltage.
Using improper voltage may result in damage to the motor and possible injury to the user. Proper voltage is listed on the bottom of vacuum cleaner.
•Turn off all controls before unplugging.
Failure to do so could result in electrical shock or personal injury.
•Do not change the plug in any way.
Failure to do so could result in electrical shock or personal injury or product damage. Doing so result in death. If plug does not fit, contact a qualified electrician to install the proper outlet.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
•Repairs to electrical appliances may only be performed by qualified service engineers.
Improper repairs may lead to serious hazards for the user.
•Do not put fingers near the gear.
Failure to do so could result in personal injury.
gear |
4
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
•Do not put any objects into openings.
Failure to do so could result in product damage.
•Do not use with any opening blocked: keep free of dust, lint, hair, and anything that may reduce air flow.
Failure to do so could result in product damage.
•Do not use vacuum cleaner without the dust tank and/or filters in place.
Failure to do so could result in product damage.
•Always clean the dust bin after vacuuming carpet cleaners or fresheners, powders and fine dust.
These products clog the filters, reduce airflow and can cause damage to the cleaner. Failure to clean the dust bin could cause permanent damage to the cleaner.
•Do not use vacuum cleaner to pick up sharp hard objects, small toys, pins, paper clips, etc.
They may damage the cleaner or dust bin.
•Store the vacuum cleaner indoors.
Put the vacuum cleaner away after use to prevent tripping over it.
•The vacuum cleaner is not intended to use by young children or infirm people without supervision.
Failure to do so could result in personal injury or product damage.
•Only use parts produced or recommended by LG Electronics Service Agents.
Failure to do so could result in product damage.
•Use only as described in this manual. Use only with LG recommended or approved attachments and accessories.
Failure to do so could result in personal injury or product damage.
•To avoid personal injury and to prevent the machine from falling when cleaning stairs, always place it at the bottom of stairs.
Failure to do so could result in personal injury or product damage.
•Use accessory nozzles in sofa mode.
Failure to do so could result in product damage.
•Don’t grasp the tank handle when you are moving the vacuum cleaner.
The vacuum cleaner’s body may fall when separating tank and body. Personal injury or product damage could result. You should grasp the carrier handle when you are moving the vacuum cleaner. (Page 11)
•Make sure the filters (exhaust filter and motor safety filter) are completely dry before replacing in the machine.
Failure to do so could result in product damage.
•Do not dry the filter in an oven or microwave.
Failure to do so could result in fire hazard.
•Do not dry the filter in a clothes dryer.
Failure to do so could result in fire hazard.
•Do not dry near an open flame.
Failure to do so could result in fire hazard.
•Do not use filters that is not dried.
•If the power cord is damaged, it must be replaced by an approved LG Electronics Service Agent to avoid a hazard.
•This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
•All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.
•For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product.
Thermal protector :
This vacuum cleaner has a special thermostat that protects the vacuum cleaner in case of motor overheating. If the vacuum cleaner suddenly shuts off, turn off the switch and unplug the vacuum cleaner. Check the vacuum cleaner for possible source of overheating such as a full dust tank, a blocked hose or clogged filter. If these conditions are found, fix them and wait at least 30 minutes before attempting to use the vacuum cleaner. After the 30 minute period, plug the vacuum cleaner back in and turn on the switch. If the vacuum cleaner still does not run, contact a qualified electrician.
5
How to use Assembling vacuum cleaner
Hose handle
Spring latch
Telescopic pipe
Carpet and floor nozzle (depend on model) Telescopic pipe
Push the nozzle into the telescopic pipe.
•Push the hose handle firmly into the telescopic pipe.
•Grasp the spring latch to expand.
•Pull out the pipe to desired length.
6
Click!
Button
Fitting pipe
Flexible hose
Attachment point
Connecting the hose to the vacuum cleaner
Push the fitting pipe on the flexible hose into the attachment point on the vacuum cleaner.
To remove the flexible hose from the vacuum cleaner, press the button situated on the fitting pipe, then pull the fitting pipe out of the vacuum cleaner.
7
How to use Operating vacuum cleaner
Plug |
Cord reel button
Regulator |
MAX line |
How to operate Emptying the dust tank Park mode |
Storage |
|
|
•Pull out the power cord to the desired length and plug into the socket.
•Place the control knob of the hose handle to the required position.
•To turn off, slide control knob to OFF position.
•Press the cord reel button to rewind the power cord after use.
• Always empty the dust |
• To store during |
• When you have |
tank when the dust tank |
vacuuming, for example |
switched off and |
level reaches the MAX |
to move a small piece |
unplugged the vacuum |
line. |
of furniture or a rug, use |
cleaner, press the |
|
park mode to support |
cord reel button to |
|
the flexible hose and |
automatically rewind |
|
nozzle. |
the cord. |
|
- Slide the hook on the |
• You can store your |
|
nozzle into the slot on |
vacuum cleaner in a |
|
the side of vacuum |
vertical position by |
|
cleaner. |
sliding the hook on the |
|
|
nozzle into the slot on |
|
|
the underside of the |
|
|
vacuum cleaner. |
WARNING
No liquid suction.
Liquid suction can cause defects.
8
How to use Using carpet and floor nozzle / Corner free nozzle
Carpet
Pedal
Floor
Carpet and floor nozzle(depend on model)
•The 2 position nozzle
This is equipped with a pedal which allows you to alter its position according to the type of floor to be cleaned.
•Carpet or rug position
Press the pedal (
) to lower brush.
•Hard floor position (tiles, parquets floor)
Press the pedal (
) to lift the brush up.
Corner free nozzle (depend on model)
•You can perform cleaning at any place such as corner or narrow crack by utilizing the structure that both sides of the suction hole are leaned back.
• Cleaning carpet and floor nozzle
• Clean the hole and the brush of the nozzle.
9
How to use Using accessory nozzles
Crevice tool Upholstery nozzle Dusting brush
3 |
4 |
5 |
Crevice tool |
Upholstery nozzle |
Dusting brush |
(depend on model) |
(depend on model) |
(depend on model) |
|
|
|
Crevice tool is for vacuuming in those nomally hard-to- reach place such as reaching cobwebs or between the cushios of sofa.
NOTICE
Use accessory in the sofa mode.
Upholstery nozzle is for vacuuming upholstery, mattresses etc.
Push the button
< Upholstery nozzle mode >
Dusting brush is for vacuuming picture frames, furniture frames, books and other irregular surfaces.
Pull the cover
< Dusting brush mode >
• PE BAG •
• Accessory nozzles included in the "PE BAG" with owner's manual (depend on model
10
How to use Emptying dust tank
Tank separation button
Pull out
MAX line |
Tank handle |
Dust tank cap
The dust tank needs emptying when the dust tank level reaches the MAX line.
•Turn off the vacuum cleaner and unplug it.
•Grasp the handle of the tank and then press the tank separation button.
•Pull out the dust tank.
•Empty the tank and then assemble the dust tank as shown.
Assembling the dust tank
NOTICE
•If suction power decreases after emptying the dust tank, clean the dust tank next page
Moving the vacuum cleaner
•Don't grasp the tank handle when you are moving the vacuum cleaner.
The vacuum cleaner's body may fall when separating tank and body.
You should grasp the carrier handle when you are moving the vacuum cleaner.
Tank |
Carrier |
handle |
handle |
11
How to use Cleaning dust tank
Tank separation button
Pull out
Tank handle
•Press tank separation button and pull out the dust tank.
•Raise the dust tank cap.
•Wash the dust tank.
•Dry fully in shade so that moisture is entirely removed.
NOTICE
If suction power decreases after cleaning the dust tank, clean the air filter and the motor safety filter. Next page
12
Loading...
