LG SD500 Users manual

LG-SD500 Operator’ s Guide

December 08, 1999

jong-gil Lee

FCC RF EXPOSURE INFORMATION

WARNING! Read this information before using your phone

In August 1996 the Federal Communications Commission (FCC) of the United States
with its action in Report and Order FCC 96-326 adopted an updated safety standard for
human exposure to radio frequency (RF) electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are consistent with the safety standard
previously set by both U.S. and international standards bodies. The design of this
phone complies with the FCC guidelines and these international standards.

Use only the supplied or an approved antenna. Unauthorized antennas, modifications,
or attachments could impair call quality, damage the phone, or result in violation of
FCC regulations.

Do not use the phone with a damaged antenna. If a damaged antenna comes into
contact with the skin, a minor burn may result. Please contact your local dealer for
replacement antenna.

Body-worn Operation

This device was tested for typical body-worn operations with the back of the phone kept

0.79 inches (2 cm) from the body. To comply with FCC RF exposure requirements, a
minimum separation distance of 0.79 inches (2 cm) must be maintained between the
user’s body and the back of the phone, including the antenna, whether extended or
retracted. Third-party belt-clips, holsters and similar accessories containing metallic
components should not be used. Body-worn accessories that cannot maintain 0.79
inch (2 cm) separation distance between the user’s body and the back of the phone,
and have not been tested for typical body-worn operations may not comply with FCC
RF exposure limits and should be avoided.

Vehicle Mounted External Antenna (optional, if available.)

A minimum separation distance of 7.9 inches (20 cm) must be maintained between the
user/bystander and the vehicle mounted external antenna to satisfy FCC RF exposure
requirements.

For more information about RF exposure, please visit the FCC website at www.fcc.gov

i

LGIC

Call Status Functions

1. Memo (Memo Soft Key 2)

*

Function to store a telephone number while calling

l Select Memo and enter the telephone number to store.
l Press Store (Soft Key 1) key. (Name is not stored)

2. Record While Calling (Menu Soft Key 1 + 1)

*

Function to record the conversation while calling

3. Send Own No. (Menu Soft Key 1+2)

*

When you leave behind your phone number when using a pager or voice mail, you can use

this function to simply send your own phone number without having to press each digit of
the number. Also, you can send, during a call (when using pager or voice mail), your phone
number to other parties.

4. MIC Volume Control (Menu Soft Key 1 + 3)

*

Function to control the sensitivity of MIC while calling

l You can select ‘ High’ or ‘ Low’

5. Volume Control (Side Keys)

*

Function to control the volume while calling

l You can control the volume by pressing Side Keys.

6. Mute Feature (Clear key)

*

Function to mute the speech voice while calling

l If you press CLR key, the speech tone is muted immediately.

If you want to deactivate this mute function, press CLR key again.

LGIC

Stand-by Status Menu Set-up and Its Functions

PIM

1. PHONE BOOK (Cion Secretary) [Menu + 1]

*

Telephone Directory / Scheduler / Alarm / Call Reserve / World Time

1.1 Contact Secretary [Menu + 1 + 1 ]

1.1.1 NEW ENTRY (Telephone Directory Register) [Menu + 1 + 1 + 1 ]

1.1.2 FIND ENTRY (Telephone Directory Search) [Menu + 1 + 1 + 2 ]

1.1.3 DELETE ENTRY (Telephone Directory Delete) [Menu + 1 + 1 + 3 ]

- See the manual on the telephone directory function.

1.2 Calendar (Schedule Management Secretary) [Menu + 1 + 2 ]

- See the manual on the diary function

1.2.1 Calendar : You can search the calendar by entering the month and year you want to find.

*

Menu +1 +2 + Menu +1

1.2.2 ADD NEW

*

Menu +1 +2 + Menu +2

1.2.3 SEARCH : Used to check if there is schedule,memo,anniversary on the date for your search

*

Menu +1 +2 +Menu +3

1.2.4 DELETE ALL : Used to delete the schedule saved in the phone.

*

Menu +1 +2 +Menu +4

1.2.5 DELETE OLD : Used to delete old records which are now unnecessary because their dates have

expired

*

Menu +1 +2 +Menu +5

1.3 Alarm Secretary [Menu + 1 + 3 ]
Alarm Time

* User can set an alarm to the desired time.

l Select one of ‘ Release / Once / Daily’ .
l If you select ‘ Release’ , it becomes the state of stand-by. In case an alarm time was set previously,

that setting time will be deleted.

l When ‘ Once / Daily’ is selected, you just enter the alarm time in the order of hour and minute.
l In case the alarm time has been set already, the set alarm time and the soft keys of EDIT/OK are

displayed.

- If you select EDIT here, the soft key 1 of EDIT is displayed in ‘ AM’ or ‘ PM” mode for editing the
input.

LGIC

l ‘AM’ and ‘PM’ mode can be switched with Soft Key1[AM/PM]
l You can edit the entered contents using DEL key.
l Press OK key to store the entered alarm time.

Note: The alarm bell is triggered at the set alarm time with the message of “Alarming Now”

displayed on the display.

Note: In case ‘Once’ is selected, if the END key is pressed or 1minute is passed, the alarm time is
deleted.

1.4 Call Reservation Secretary [Menu + 1 + 4 ]
Call Reserve

* Function to originate a call to the reserved number automatically at the reserved time.

l Enter the reservation time in the order of “Hour : Minute”.
l ‘AM’ and ’PM’ mode can be switched with Soft Key 1[AM/PM].
l Press OK key to store the entered reserved call time.
l Enter the reservation telephone number. [Up to 32 characters acceptable]
l Store the entered telephone number using STORE key.

Note: Telephone rings at the reserved time with the message of “Time for Reserved Call” on the
display.

Note: If the END key is pressed or one minute is passed, the reserved call time is automatically
deleted and stored in the last call list.

1.5 World Time Secretary [Menu + 1 + 5]
World Time

* Function to confirm the standard time of major cities in the world based on GPC time.

This function is available in CDMA mode only.

l Select the city you want to check using ‘Soft Key1’ or ‘V/#’ key and press OK key.

Then, the international standard time of the selected city is appeared.

Cities applicable
Guam / New York / Dacca / Dallas / Denver / Delhi / Tokyo / Detroit / London / Rome / Los Angeles /
Lisbon / Riode Janeiro / Manila / Madrid / Mexico / Moscow / Montreal / Bangkok / Berlin / Beijing /
Beirut / Boston / Buenos Aires / Vienna / Sydney / Seattle / Chicago / Singapore / Athens / Abu Dhabi /
Ajoles / Amsterdam / Anchorage / Oakland / Washington / Jakarta / Jedda / Kabul / Cairo / Caracas /
Colombo / Kuwait / Taipei / Tehran / Paris / Hanoi / Helshinki / Honolulu / Hongkong

3

Terminal Development Center

LGIC

2. Volume Control [Menu + 2]

*

Function to control Ring / Key Tone / Call Volume

2.1 Ringer Volume (Receiver Volume Control) [Menu +2 +1]

l Select the volume using the next setup key (Soft Key 1).
l Select the volume you want using V/# keys.
l Store the selected volume using the selection key.

2.2 Key Tone Volume Control [Menu +2 +2]

l Select the volume using the next setup key (Soft Key 1).
l Select the volume you want using V/# key.
l Store the selected volume using the selection key.

2.3 Earpiece Volume Control [Menu +2 +3]

l Select the volume using the next setup key (Soft Key 1).
l Select the volume you want using V/# key.
l Store the selected volume using the selection key.

3. Select Ring (Bell Selection) [Menu + 3 ]

*

Function to select the bell type for the incoming call.

3.1 Types of Bell [Ring / Vibration / Vibration + Ring]

l Select Menu + 3 + 1.
l Select the bell type using the next setup key (Soft Key 1).
l Select the type of bell you want using V/# key.
l Store the selected status using the selection key.

3.2 Bell Selection (17 types)
[General / Sound of glass bead / Kung-tha-ri Shabara / Rise tone / Alarm tone / Chime bell / Code
tone / Tune of Japanese apricot tree / Pathetic sonata / Bolero of love/ Tune of bird / Father’ s
face / Small fountain / Edelweiss / A happy home / Nostalgia / Mail carriage]

l Select Menu + 3 + 2
l Select the type of bell using the next setup key (Soft Key 1).
l Select the bell you want using V/# key.
l Store the selected status using the selection key.

LGIC

4. Call Time [Menu + 4]

*

Function to verify the record on the call time

4.1 Last Call Time

* Function to show the last call time

l Select Menu + 4 + 1.
l Press OK key to return to the stand-by state.

4.2 Total Call Time

* Function to show the number of call and the call time for all calls of receiving and transmitting.
User can verify the total number of calls made and the call time through this function.

l Select Menu + 4 + 2.
l If you select OK key (Soft Key2), it returns to the stand-by status and if you select DEL key (Soft

Key1), you can delete the accumulated total call time.

4.3 Home call + Roam calls

* Used to display the call time for calls only within your business place.
* Used to display the call time of calls with other business enterprise places.

l Select Menu + 4 + 3.

5. Secret Function [Menu + 5 + Password 4-digit]

*

Lock mode setup / Call list delete / Private information delete / Voice list delete /
Emergency phone number store / Password change / International call restrict /
Automatic PIN transmit / Software version confirm functions can be performed in this menu.

5.1. Lock Mode

* Function to restrict the originating and storing functions.
* You can select ‘ Release / Power-On / Always’

l Press Menu + 5 + Password 4-digit + 1
l Select one of ‘ Release / Power-On / Always’ using ‘ Soft Key1’ or ‘ V/#’ key and press the store

key.

l If you select ‘ Always’ , the phone falls in the lock mode always, and [Select] menu and the calling

are locked.

- If you try to call in this case, you are prompted for the password and if the entered password is
identified, the call is established. In the lock mode, if you press [Locking Release] button, the
