LG SAMBA 8575 User Manual

LG8 575

Samba

Printed in Korea

P/NO : MMBB0379501(1.0)

Copyright ©2010 LG Electronics, Inc. All rights reserved. LG and the LG logo are registered trademarks of LG Group and its related entities. All other trademarks are the property of their respective owners.

Important Safety Precautions

Read these instructions. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide.

WARNING! Violation of the instructions may cause serious injury or death.

1. Never use an unapproved battery since this could damage the phone and/or battery and could cause the battery to explode.

2. Never place your phone in a microwave oven as it will cause the battery to explode.

3. Never store your phone in temperatures less than

-4°F or greater than 122°F.

4. Do not dispose of your battery by fire or with hazardous or flammable materials.

5. When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If wireless equipment is improperly installed and the air bag is deployed, you may be seriously injured.

6. Do not use a hand-held phone while driving.

7. Do not use the phone in areas where its use is prohibited. (For example: aircraft)

Important Safety Precautions

1. Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity, such as a bathroom.

2. Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. This

Important Safety Precautions

could cause a fire.

3. Do not drop, strike, or shake your phone severely. It may harm the internal circuit boards of the phone.

4. Do not use your phone in high explosive areas as the phone may generate sparks.

5. Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose as it may cause a fire or electric shock.

6. Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may cause electric shock or fire.

7. Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone.

8. Do not disassemble the phone.

1. Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.

2. Do not hold or let the antenna come in contact with your body during a call.

3. Make sure that no sharp-edged items such as animal’s teeth or nails, come into contact with the battery. This could cause a fire.

4. Store the battery out of reach of children.

5. Be careful that children do not swallow any parts (such as rubber plugs, earphone, connection parts of the phone, etc.) This could cause asphyxiation or suffocation resulting in serious injury or death.

6. Unplug the power cord and charger during lightning storms to avoid electric shock or fire.

7. Only use the batteries and chargers provided by LG. The warranty will not be applied to products provided by other suppliers.

8. Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty.

9. Your service provider programs one or more emergency phone numbers, such as 911, that you can call under any circumstances, even when your phone is locked. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

Important Safety Precautions

Table of Contents

Important Safety Precautions 1

Table of Contents 4 Welcome 9 Technical Details 10

Important Information 10 FCC Part 15 Class B Compliance 10 Technical Details 10 FCC RF Exposure Information 12

Ta b le o f C o nt en ts

Bodily Contact During Operation 12 Vehicle-Mounted External Antenna 13 FCC Notice and Cautions 13 Caution 14 Part 15.19 statement 14 Part 15.21 statement 14 Part 15.105 statement 15

Phone Overview 16

Touch Sensitive Soft Keys 18

Quick Glance of the Touch Screen and How to Use It 18

Calibrating the Touch Screen 19

Shortcut Menu 20

Entering and Editing Information 22

Text Input 22

Menu Tree Overview 26 Getting Started with Your

Phone 29

The Battery 29 Charging the Battery 29 Charging with USB 30 How to Install a microSD™ Card 30 How to Remove a microSD™

Card 31 Battery Temperature Protection 32 Battery Charge Level 32 Turning the Phone On and Off 32 Signal Strength 33 Screen Icons 33 Making Calls 33 Correcting Dialing Mistakes 34 Redialing Calls 34 Receiving Calls 34

Main Menu Screen 35

Menu Access 35

Shortcut Menu on the Touch

Screen 36

Shortcuts Bin 36

Quick Access to Convenient Features 38

Lock Mode 38 Quick Volume Adjustment 38 Vibrate Mode 38 Call Waiting 38 Voice Commands 39

Contacts in Your Phone’s Memory 40

Storing Basics 40 Changing Contact Entries 41 Speed Dial 41 Storing a Number with Pauses 42 Deleting 42

Camera Features 43

3D (Three-axis-accelerometer) Rotation 43

Camera Features 44 Camera Settings 45 Video Camera 46 Video Settings 47 Picture Editing 48 Video Player Controls 50

Video Editing 50

Using Phone Menus 52

MESSAGING 52

1. New Message 52

1.1 Text Message 52

1.2 Picture Message 55

1.3 Video Message 57

1.4 Voice Message 58

2. Messages 59

3. Drafts 61

4. Voicemail 61

5. Settings 62

6. Erase Options 64

CALL HISTORY 65

1. Missed Calls 65

2. Received Calls 66

3. Dialed Calls 66

4. All Calls 67

5. View Timers 68

CONTACTS 69

1. New Contact 69

2. Contact List 69

3. Favorites 70

4. Groups 71

Ta b le o f C o nt en ts

Table of Contents

5. Speed Dials 72

6. My Name Card 73

MULTIMEDIA 73

1. Take Picture 73

2. Record Video 74

3. Record Voice 75

4. Images 76

5. Videos 77

6. Audios 78

6.1 My Ringtones 78

Ta b le o f C o nt en ts

6.2 My Sounds 79

BREW 80

1. BREW Apps 80

2. BREW Info 81

WEB 81

MUSIC 89

1. My Music 89

MY SCHEDULE 93

1. Alarm Clock 93

2. Calendar 94

3. Notepad 95

FM RADIO 95

BLUETOOTH 98

TOOLS 103

1. Voice Commands 103

1.1 Call <Name or Number> 104

1.2 Send Msg to <Name or Number> 104

1.3 Go to <Menu> 105

1.4 Check <Item> 105

1.5 Contacts <Name> 105

1.6 Redial 105

1.7 Play 105

1.8 Help 105

2. Ez Tip Calculator 106

3. Calculator 106

4. World Clock 107

5. Stopwatch 107

6. Drawing Pad 108

7. USB Mass Storage 109

SETTINGS 110

1. Sounds Settings 110

1.1 Easy Set-Up 110

1.2 Master Volume 110

1.3 Call Sounds 111

1.3.1 Call Ringtone 111

1.3.2 Call Vibrate 111

1.3.3 Call ID Readout 112

1.4 Alert Sounds 112

1.5 Button Sounds 113

1.6 Digit Dial Readout 113

1.7 Service Alerts 114

1.8 Power On/Off 114

2. Display Settings 115

2.1 Easy Set-Up 115

2.2 Banner 115

2.2.1 Personal Banner 115

2.3 Backlight 116

2.4 Wallpaper 116

2.5 Charging Screen 117

2.6 Display Themes 117

2.7 Fonts 118

2.8 Dial Fonts 118

2.9 Clock Format 119

2.10 Shortcut Bin 119

2.11 Music Handle 120

3. Touch Settings 120

4. Phone Settings 121

4.1 Airplane Mode 121

4.2 Voice Commands 121

4.3 Language 122

4.4 Location 122

4.5 Current Country 123

4.6 Security 124

4.6.1 Edit Codes 124

4.6.2 Restrictions 125

4.6.3 Phone Lock 126

4.6.4 Lock Phone Now 126

4.6.5 Reset Default 127

4.7 System Select 128

4.8 NAM Select 128

5. Call Settings 129

5.1 Answer Options 129

5.2 Show Dialpad 129

5.3 Auto Retry 130

5.4 TTY Mode 130

5.5 One Touch Dial 133

5.6 Voice Privacy 133

5.7 DTMF Tones 134

6. USB Auto Detection 134

7. Memory 135

7.1 Save Options 136

7.2 Phone Memory 136

7.3 Card Memory 137

8. Phone Info 137

8.1 My Number 138

8.2 SW/HW Version 138

8.3 Icon Glossary 139

9. Set-up Wizard 139

Ta b le o f C o nt en ts

Table of Contents

Safety 140

TIA Safety Information 140

Exposure to Radio Frequency Signal 140

Antenna Care 141 Phone Operation 141 Tips on Efficient Operation 141 Driving 141 Electronic Devices 141 Pacemakers 142

Ta b le o f C o nt en ts

Persons with pacemakers: 142 Hearing Aids 142 Other Medical Devices 142 Health Care Facilities 143 Vehicles 143 Posted Facilities 143 Aircraft 143 Blasting Areas 143 Potentially Explosive Atmosphere 143 For Vehicles Equipped with

an Air Bag 144

Safety Information 145

Charger and Adapter Safety 146 Battery Information and Care 146 Explosion, Shock, and Fire Hazards147 General Notice 148

Warning! Important safety information 149

Avoiding hearing damage 149 Using your phone safely 150 Using headsets safely 150

FDA Consumer Update 151 10 Driver Safety Tips 161 Consumer Information on

SAR 165 FCC Hearing-Aid Compatibility

(HAC) Regulations for Wireless Devices 168

Accessories 171 Limited Warranty

Statement 172 Index 176

Welcome

Thank you for choosing the Samba Touch cellular phone designed to operate with the latest digital mobile communication technology, Code Division Multiple Access (CDMA). Along with the many advanced features of the CDMA system, such as greatly enhanced voice clarity, this compact phone offers:

●

Touch Screen and auto Touch Screen lock.

●

Display themes and Wallpapers for customization.

●

Built-in 3.2 Megapixel digital camera (with video mode).

●

Large, easy-to-read, backlit LCD with status icons.

●

Messaging Voicemail, and caller ID.

●

HTML Browser.

●

Dolby®Mobile

●

FM Radio

●

Long battery standby and talk time.

●

Easy operation with intuitive touch screen Menus and prompts.

●

Any Key answer, Auto-answer with Handsfree, auto retry, One Touch and Speed Dialing (with 999 memory locations).

●

Bilingual (English and Spanish) capability.

●

Bluetooth®wireless technology.

●

1GB of internal memory for music

Note

The Bluetooth®word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners.

Wel c ome

Technical Details

Important Information

This user’s guide provides important information on the use and operation of your phone. Please read all the information carefully prior to using the phone for the best performance and to prevent any damage to or misuse of the phone. Any unapproved changes or modifications will void your warranty.

Technical Details

FCC Part 15 Class B Compliance

This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that causes undesired operation.

Technical Details

The Samba Touch is an all digital phone that operates on both Code Division Multiple Access (CDMA) frequencies: Cellular services at 800 MHz and Personal Communication Services (PCS) at 1.9 GHz.

CDMA technology uses a feature called DSSS (Direct Sequence Spread Spectrum) that enables the phone to keep communication from being crossed and to use one frequency channel by multiple users in the same specific area. This results in a 10-fold capacity increase when compared with analog mode. In addition, features such as soft / softer handoff, hard handoff, and dynamic RF power control technologies combine to reduce call interruptions.

The Cellular and PCS CDMA networks consist of MSO (Mobile Switching Office), BSC (Base

Station Controller), BTS (Base Station Transmission System), and MS (Mobile Station).

CDMA Standard

Basic Air Interface

Network

Service

1x EV-DO Related

interface

Designator

TIA/EIA-95A TSB-74 ANSI J-STD-008 TIA/EIA-IS2000

TIA/EIA/IS-634 TIA/EIA/IS/651 TIA/EIA/IS-41-C TIA/EIA/IS-124

TIA/EIA/IS-96-B TIA/EIA/IS-637 TIA/EIA/IS-657 IS-801 TIA/EIA/IS-707-A

TIA/EIA/IS-856 TIA/EIA/IS-878

TIA/EIA/IS-866

TIA/EIA/IS-890

Description

CDMA Dual-Mode Air Interface

14.4kbps radio link protocol and interband operations IS-95 adapted for PCS frequency band CDMA2000 1xRTT Air Interface

MAS-BS PCSC-RS Intersystem operations Non-signaling data comm.

Speech CODEC Short Message Service Packet Data Position Determination Service (gpsOne) High Speed Packet Data

CDMA2000 High Rate Packet Data Air Interface

1xEV-DO Inter-Operability Specification for CDMA2000 Access Network Interfaces

Recommended Minimum Performance Standards for CDMA2000 High Rate Packet Data Access Terminal Test Application Specification (TAS) for High Rate Packet Data Air Interface

Technical Details

* TSB-74: Protocol between an IS-

95A system and ANSI J-STD008

Its battery life is twice as long as IS-95. High-speed data transmission is also possible.

The following tab lists some major CDMA standards.

FCC RF Exposure Information

Technical Details

WARNING! Read this information before operating the phone.

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety

standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards.

Bodily Contact During Operation

This device was tested for typical use with the back of the phone kept 0.79 inches (2.0 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of

0.79 inches (2.0 cm) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Thirdparty belt-clips, holsters, and similar accessories containing metallic components should not be used. Avoid the use of

accessories that cannot maintain

0.79 inches (2.0 cm) distance between the user’s body and the back of the phone and have not been tested for compliance with FCC RF exposure limits.

Vehicle-Mounted External Antenna

(Optional, if available.)

To satisfy FCC RF exposure requirements, keep 8 inches (20 cm) between the user / bystander and vehicle-mounted external antenna. For more information about RF exposure, visit the FCC website at www.fcc.gov.

FCC Notice and Cautions

Any changes or modifications not expressly approved in this user guide could void your warranty for this equipment. Use only the supplied antenna. Use of unauthorized antennas (or modifications to the antenna) could impair call quality, damage the phone, void your warranty and/or violate FCC regulations.

Technical Details

Don't use the phone with a damaged antenna. A damaged antenna could cause a minor skin burn. Contact your local dealer for a replacement antenna.

Caution

Use only the supplied and approved antenna. Use of unauthorized antennas or modifications could impair call

Technical Details

quality, damage the phone, void your warranty and/or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin a minor burn may result. Contact your local dealer for a replacement antenna.

Part 15.19 statement

This device and its accessories comply with part15 of FCC rules. Operation is subject to the following two conditions:

(1) This device & its accessories

may not cause harmful interference.

(2) This device & its accessories

must accept any interference received, including interference that may cause undesired operation.

Part 15.21 statement

Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment.

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. if this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Technical Details

Phone Overview

Note

The SEND Key, CLR/ Voice Commands Key, and PWR / END Key are not illuminated when the display is off. Press the Unlock Key, or any other exterior key, to illuminate the display and keys. To unlock the screen and keys, lightly press and hold the icon

to reveal the Standby mode Touch Screen and Touch Soft Keys.

3.5mm Headset Jack Allows you to plug in an optional

wired headset for convenient, hands-free conversations. The 3.5mm jack also allows you to connect headphones normally used with other portable media (MP3) players.

2. Earpiece Lets you hear the caller.

3. Touch Screen Displays incoming calls, messages and

indicator icons as well as a wide variety of content you select to view.

4. Touch Soft Keys Touch Keys on this Touchpad

provide easy access to Messages, the phone Dialpad, the Main Menu, the Contact List, and Favorites which easily activate with the touch of your fingertip.

5. SEND Key Use to answer incoming calls and to place

calls from the Dialpad. From Standby mode, pressing this key will open the All Calls list.

6. CLR Key / Voice Command Key Deletes single

spaces or characters. Also backs out of menus, one level at a time. While in Standby mode, use for quick access to Voice Command or press and hold to access Voice Recorder.

Proximity Sensor This sensor locks the Touch screen

during a call if an object (like your head) comes within close proximity, to prevent accidental keypresses. Please note that some phone cases may engage the sensor. The sensor is disabled when using the Speakerphone, a Bluetooth headset or the headset jack

8. Light Sensor Detects the amount of light, adjusts

brightness of the LCD. This conserves power and extends battery life.

9. Shortcut Bin Touch Key Allows quick access to a

customizable Shortcuts Menu.

10 . Music Handle Touch Key This shortcut key opens

the My Music application.

11. PWR/END Key Use to turn the power on/off and to

end a call. Also returns to Standby mode.

12 . Camera Lens Used for taking pictures and

recording video. Keep it clean for optimal photo quality.

13 . Accessory/ Charger Port Connects the phone

to the battery charger, or other compatible accessories.

14 . Side Volume Keys Use to adjust the Master

Volume in Standby mode* and the Earpiece Volume during a call.

15 . Speakerphone Keys Press to activate or

deactivate the Speakephone function.

16 . Lock/ Unlock Key Press to lock or unlock the

Touch Screen and keys.

17. My Music Key Use for quick access to your

music.

18 . Camera Key Use for quick access to Camera

function. Press and hold the Camera Key to record Video.

* Standby mode is when the phone is waiting for

input from you and the phone isn’t performing any action. It’s the starting point for all of the instruction steps.

Phone Overview

Quick Glance of the Touch Screen and How to Use It

Touch Sensitive Soft Keys

Quick Glance of the Touch Screen and How to Use It

(,,,,)

1. Make sure your hands are clean and dry. Remove moisture from the surface of your hands. Don't use the touch keys in a humid environment.

2. Touch screen is sensitive to your light touch. You don't need to press it forcefully to use it. Protect your phone from severe impact because touch screen sensors may become damaged from harsh use.

Use the tip of your finger to touch

3. the center of a touch key. If you touch off-center it may activate the nearby function instead.

4. The touch feedback levels can be adjusted to your preference.

5. When both the LCD screen and backlight are off, all keys are deactivated. Press the Unlock Key ( ) twice to turn on and unlock the Touch Screen.

6. The Proximity Sensor protects against accidental key presses during phone calls by locking the screen.

Keep metal and other conductive material away from the surface of touch screen because contact may cause electronic interference.

How to Unlock

Press and hold

to unlock

the screen.

Press the

Unlock Key on the side of your phone. Press twice if the backlight is off.

Calibrating the Touch Screen

Calibration allows the phone to recognize the accuracy of your touch.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone. Then, touch the Menu Touch Soft Key .

2. Touch the Settings icon .

3. Touch

Touch Settings

4. Place your finger on the Touch Screen and slide upward to scroll the list up, then touch

Calibration

5. Touch the target each time it appears.

6. After setting calibration, touch Check calibration or Save without check.

●

If you touch Check calibration, touch each target as it appears again. The screen will display a purple dot to indicate the location of your touch. If you are satisfied with your accuracy, touch Yes to save, or touch No to try again.

●

Touch Save without check to save without viewing your touch accuracy.

Calibrating the Touch Screen

Shortcut Menu

Touch Screen Shortcut Menu

The Touch Screen Shortcut Menu allows instant access to menus and phone features with the quick touch of your fingertip. To use the Shortcut Menu:

1. Press and hold to unlock or press the Unlock Key ( ) on the

right side of your phone.

2. Touch the Shortcut Bin Touch Key .

3. Touch the favorite Media files (including pictures, videos, and music playlists).

4. To close the Shortcut Bin, press the Clear or PWR/END

Shortcut Menu

Key.

My Media

tab to access, and/or manage, shortcuts to your

Touch Soft Keys

Messages: Displays the

Messages menu.

Menu: Displays the Main Menu.

Phone: Displays the Dialpad Touch

Keys so you can make a call. Dial manually using the numeric keys or easily from your Recent Calls, Contacts, or with Voice Dial.

Contacts:

Displays your Contact List.

Favorites: Displays

your favorite contacts.

When you touch the Phone Touch Soft Key the following Dialpad is displayed:

Touch and hold this

Touch Key to call your

voice mail box.

Touch this Touch Key

to dial using Voice

Command.

Touch this Touch Key to view the

recent call history.

Touch this Touch Key to display your Contact List to view or call a Contact.

Touch and hold this Touch Key to toggle your phone between Vibrate Mode and Normal Mode.

Touch this Touch Key to delete digits entered one by one. Hold down to delete the entire entry.

Shortcut Menu

Entering and Editing Information

Text Input

You can enter information using the Touch Screen keypad. There are special key functions to help you with text entry.

Entering and Editing Information

Using the Touch Screen

1. Press and hold to unlock

or press the Unlock Key ( ) on the right side of your phone.

2. Touch the Message Touch Soft

Key .

3. Touch .

4. Select

5. Touch the Text Field to begin

6. To access Text Input options,

Text Entry Options.

Insert Quick Text/ Save As Draft/ Add/ Copy Text/ Paste/ Priority Level/ Callback#/ Save Quick Text/ Cancel Message

Touch to minimize the touch keypad.

Touch to change text input modes.

Handwriting/ Keypad Toggle Key.

NEW

Text Message

entering text. A touch keypad will popup.

press the Text Options Touch Key

. The options are:

Insert Quick Text/ Save As Draft/ Add/ Copy Text/ Paste/ Priority Level/ Callback#/ Save Quick Text/ Cancel Message

Changing Input Method

When entering text, besides "typing" the text with Touch Keys you have the option to write with your fingertip. The Touch Screen will translate your movements into characters.

1. Touch a text field, then touch on the right side of the

display. Use your fingertip to write

each character. You must write in the box that appears in the lower half of the screen. If the Touch Screen does not display the character you intended, press the CLR Key to delete characters, and try again. For instructions on how to better use the handwriting function, see the next page.

TIP

When you "write" on the Touch Screen, the interpreted movements will be displayed. Gaps in lines may indicate that you need to press slightly harder for more constant contact with the Touch Screen.

NOTE

The handwriting option may not be available for all text entry fields.

Handwriting Recognition Field

Entering and Editing Information

The following tables may help in understanding how the Touch Screen interprets movements into characters.

Entering and Editing Information

Writing in Lower-Case

Writing in Upper-Case

NOTE

You must touch the All Caps Touch Key

to write in upper-case letters.

NOTE

You must touch the Numbers Touch Key

to write in upper-case letters.

NOTE

You must touch the Symbols Touch Key

to write in upper-case letters.

To change text input from "handwriting" mode back to "typing" mode, touch on the right-hand side.

Entering and Editing Information

Menu Tree Overview

Menu Access

Unlock the screen by pressing the unlock key on the left side of your phone. Then, touch the Menu Soft Key . To go back to standby mode, press at the bottom center of your phone.

Menu Tree Overview

Messaging

New Message

Text Message Picture Message Video Message

Voice Message Messages Drafts Voicemail Settings

Messages View

Entry Mode

Text Entry Settings

Auto Save Sent

Auto Erase Inbox

Message Font Size

Text Auto View

Text Auto Scroll

Multimedia Auto Receive

Quick Text Voicemail# Callback# Signature Delivery Receipt

Erase Options

Erase Inbox Erase Sent Erase Drafts Erase All

Call History

Missed Calls Received Calls

Dialed Calls All Calls View Timers

Contacts

New Contact Contact List Favorites Groups Speed Dials My Name Card

Multimedia

Take Picture Record Video Record Voice Images Videos Audios

My Ringtones My Sounds

BREW

BREW Apps BREW Info

Web

Launch Prompt

Music

My Music

All Songs Playlists Artists Genres Albums Manage My Music

Erase Move to Card Move to Phone Lock/Unlock

Music Settings

Repeat Shuffle Music Only

My Schedule

Alarm Clock Calendar Notepad

FM Radio

Bluetooth

Tools

Voice Commands

Call <Name or Number>

Send Msg to <Name or Number

Go to <Menu> Check <Item> Contacts <Name> Redial Play

Help Ez Tip Calculator Calculator World Clock Stopwatch

Drawing Pad USB Mass Storage

Settings

Sounds Settings

Easy Set-up

Master Volume Call Sounds

Call Ringtone Call Vibrate Caller ID

Readout

Alert Sounds

Text Message Multimedia

Message Voicemail Emergency Tone

Missed Call Button Sounds Digit Dial Readout Service Alerts

Minute Beep

Call Connect

Charge

Complete

Menu Tree Overview

Power On/Off

Power On Sound

Power On Vibrate

Power Off Sound

Power Off Vibrate

Display Settings

Easy Set-up Banner

Personal Banner Backlight Wallpaper

My Pictures

My Videos

Fun Animations Charging Screen Display Themes Fonts Dial Fonts Clock Format Shortcut Bin Music Handle

Touch Settings

Auto Lock

Vibrate Type Vibrate Level Vibrate Effect Sound Calibration

Phone Settings

Airplane Mode Voice Commands

Confirm Choices Sensitivity Adapt Voice Prompt Mode Audio Playback Prompt Timeout CLR Key

Activation

Info Language Location Current Country Security

Edit Codes

Restrictions

Phone Lock

Lock Phone

Now

Reset Default System Select NAM Select

Call Settings

Answer Options Show Dialpad Auto Retry TTY Mode One Touch Dial Voice Privacy DTMF Tones

USB Auto Detection Memory

Save Options

Pictures

Videos

Sounds Phone Memory Card Memory

Phone Info Set-up Wizard

Getting Started with Your Phone

The Battery

Note

It is important to fully charge the battery before initial use of the phone.

The phone comes with a rechargeable battery. The battery charge level is shown at the top of the LCD screen.

Installing the Battery

To install the battery, insert the edge with the battery contacts into the opening on the back of the phone. Push the battery down until it clicks into place, then attach the back cover.

Removing the Battery

Turn power off and slide the back cover down to remove it. Use the fingertip cutout at the bottom of the battery to lift the the battery out and remove it.

Charging the Battery

Your Samba Touch device comes with a cableless wall adapter and a USB data cable which connect together to charge your phone. To charge your phone:

NOTICE

Please use only an approved charging accessory to charge your LG phone. Improper handling of the charging port, as well as the use of an incompatible charger, may cause damage to your phone and void the warranty.

1. Connect the USB data cable into the cableless wall adapter, as shown below.

Cableless Wall Adapter

Getting Started with Your Phone

2. Gently uncover the phone's accessory/ charging port. Then plug the end of the AC adapter into the accessory/

Getting Started with Your Phone

end into an electrical outlet.

3. The charge time varies depending upon the battery level.

Charging with USB

charger port and the other

You can use your computer to charge your phone. To be able to charge with the USB cable; you may need to have the necessary USB Driver installed on your PC first. Connect one end of the USB cable to the charging accessory port on your phone and the other end to a buspowered USB port on your PC.

Notice

Please make sure that the 'B' side is facing up before inserting a charger or data cable into the charger port of your phone.

Note

Low-powered USB ports are not supported, such as the USB port on your keyboard or bus-powered USB hub.

How to Install a microSD Card

1. Remove the back cover and locate the microSD the left side.

microSDTMSlot

™

slot on

™

2. Insert the microSD™card (purchased separately) with the logos facing up. Push in until it clicks into the slot. Please note that if you insert the card in the wrong direction, it may damage your phone or your card.

How to Remove a microSD™Card

Gently push the card in, this will release the exposed edge of the microSD

2. Remove the microSD™card from the slot and replace the cover.

™

card to eject it.

Note

• Do not attempt to remove the

™

microSD

card while reading or

writing to the card.

• If you wish to transfer, or

download, music onto the microSD™card inserted into this phone (through either Music Sync or over-the-air), you should format the microSD before using it (Menu -> Settings -> Memory -> Card Memory -> Format). Warning: Formatting the microSD contents on the card. In the event the microSD phone without first formatting it, the phone may display “License acquisition failed” during over-theair downloading or Music Sync. Song files downloaded or otherwise purchased from third party providers and stored on the microSD device may be protected or encrypted by such provider and may not be played on this device.

™

card on this handset

™

card will erase all

™

card is used on this

™

card inserted into this

Getting Started with Your Phone

Battery Temperature Protection

Though extremely rare, if the battery becomes overheated, the phone will automatically turn off.

Getting Started with Your Phone

When you turn the phone back on, a message pops up alerting you that the phone was powered off for your safety.

Battery Charge Level

You can find the battery charge level at the top right of the LCD screen. When the charge level becomes low, the battery sensor sounds a warning tone, blinks the battery icon, and/or displays a warning message. As the charge level approaches empty, the phone automatically switches off without saving any work in progress.

Turning the Phone On and Off

Turning the Phone On

1. Install a charged battery or connect the phone to an external power source.

2. Press the PWR/END Key for a few seconds until the Touch Screen lights up.

Turning the Phone Off

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone.

2. Press and hold the PWR/END

Key until the display

turns off.

Signal Strength

Call quality depends on the signal strength in your area. You can tell how much signal strength you have by the number of bars next to the signal strength icon: the more bars, the stronger the signal. If you’re having problems with signal quality, move to an open area or, when inside a building, try moving near a window.

Screen Icons

When the phone is on, the top line of the LCD screen displays phone status icons. To view what they mean:

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch the Settings icon .

3. Scroll the list up, then touch

Phone Info

4. Touch

Icon Glossary

Making Calls

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone.

2. Touch the Phone Touch Soft Key , to display the dialpad you can use to dial. Enter the phone number you want to call.

Note

You can search your Contact List

CONTACTS

( ) or Recent Calls ( ) and select a number to call instead of manually dialing.

Getting Started with Your Phone

3. Press the SEND Key or touch the Call touch key

to place the call.

CALL

4. Press the PWR/END

Getting Started with Your Phone

Key or touch the End touch key to end the call.

END

Correcting Dialing Mistakes

If you make a mistake while dialing a number, touch the Clear touch key once to erase the last digit entered, or hold the Clear touch key down for at least 2 seconds to delete all digits.

CLR

Redialing Calls

With the Touch Screen unlocked, press the SEND Key once to view a list of all of your recent calls. The last 270 calls (90 Received, 90 missed and 90 Dialed) are stored in the call history list. Touch the Dial touch

key next to any of the entries to place a call to that number. You can also press the SEND Key twice to redial the last number you dialed, received or missed in the call history.

Receiving Calls

1. When the phone rings and/or vibrates, press and hold to unlock, then touch the Answer touch key , or press the SEND Key.

2. Press the PWR/END Key to end the call.

Answer

Main Menu Screen

Menu Access

The Menu Touch Soft Key provides access to the main phone menus. To access the main menus, unlock the screen by pressing the unlock key ( ) on the right side of your phone or touch and hold . Touch the Menu Touch Soft Key at the bottom of the screen to open the main menus.

Main Menu Screen

Shortcut Menu on the Touch Screen

Shortcuts Bin

The Shortcuts Bin allows quick, direct access to several frequently used device features from the Touch Screen. Up to 11 shortcuts can be set. To access the Shortcut Menu, unlock the Touch Screen, then touch the

Shortcut Menu on the Touch Screen

Shortcut Bin Touch Key . By default, the shortcuts below are provided, but you can customize them according to your preferences.

Note

Touch the My Media tab to set up to 11 media files (picture, video, or music playlists) with shortcut access.

Bluetooth

Text Msg

Alarm Clock

My Images

Web

Ez Tip Calc

Notepad

Settings

Touch Settings

Shortcut Menu on the Touch Screen

Touch the My Media tab and touch the Add touch key to add files to this shortcut menu.

Use the My Media sub menus to add shortcuts to your selected media files.

Managing Shortcuts

You can add, delete, and rearrange shortcut icons. To add, touch the Add touch key , scroll to the feature you want, then touch it. To remove from the Shortcuts menu, drag and drop the icon on the Trash can touch key (when you hold down a Shortcut item, the Add touch key turns into the Trash can touch key ). To move an icon, drag and drop it on another icon, they will exchange places.

Quick Access to Convenient Features

Lock Mode

Sets your phone to require a 4 digit password in order to use the phone.

Quick Access to Convenient Features

To set lock mode on, touch

Phone Settings

Phone Lock Code

Enter

Phone Lock

Touch

Quick Volume Adjustment

Quickly adjust ringer and earpiece* volumes by pressing the upper side volume key to increase and lower side key to decrease.

*Note

The earpiece volume can only be adjusted by the side volume keys during a call.

Settings

Security

Note

To turn sounds off, unlock the phone, press and hold the lower side volume key for 3 seconds, then press and hold the upper side volume key to return to normal

sounds mode.

Vibrate Mode

Sets the phone to vibrate instead of ringing ( is displayed on the Notifications bar). To set Vibrate Mode, touch the Phone Touch Soft Key , to display the keypad touch keys, then touch and hold the Pound touch key

To return to Normal Mode, touch and hold the Pound touch key .

Call Waiting

During a call, one beep indicates that you have another incoming call.

Ignoring a Call Waiting

If you don't want to answer the incoming call, touch on

Ignore

the Touch Screen. The Call Waiting beep stops and the call goes to your voicemail, if available.

Answering a Call Waiting

1. Press , to automatically put the first call on hold and answer the new call.

2. Press again, to put the second call on hold and return to the first caller.

Voice Commands

Voice Commands allow you to do things by verbal command (e.g., make calls, check Voicemail, etc.). For more information, see page 103.

With the Touch Screen unlocked, press a quick once (an extended press activates the Voice Recorder feature instead).

2. Follow the prompts to use your voice command(s).

Note

Voice Commands can also be started with the designated key on your

Bluetooth

device. Please check the manual of the Bluetooth further instructions.

device for

Quick Access to Convenient Features

Contacts in Your Phone’s Memory

Storing Basics

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your

Contacts in Your Phone’s Memory

phone.

2. Touch the Contact Touch Soft Key .

3. Touch the New touch key

New

4. Touch a field, use the pop-up touch keys to enter information, then touch the Done touch key . Do this for each field you want to enter.

5. When all fields are complete, touch the Save touch key

SAVE

DONE

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone.

2. Touch the Phone Touch Soft Key for the phone dialing keypad.

3. Use the Dialpad that pops up to enter the phone number and touch the Save touch key

SAVE

Add New Contact/

4. Touch

Update Existing

Mobile 1/ Home/

5. Touch

Work/ Mobile 2/ Fax

6. Enter information into the remaining fields, as necessary, and touch the Save touch key

SAVE

to save.

Changing Contact Entries

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone.

2. Touch the Contact List Touch Soft Key .

3. Touch the Contact you want to customize.

4. Touch the Edit touch key

, touch and edit the

EDIT

fields you want to change then touch the Done touch key .

DONE

5. Touch the Save touch key

when edits are

SAVE

complete.

Speed Dial

Allows you to set up your Speed Dials.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone.

2. Touch the Contacts Touch Soft Key .

3. Touch the Contact you want to set with a Speed Dial, then touch the Options icon .

Set Speed Dial

4. Touch

5. Touch an unassigned Speed Dial number.

6. You will be prompted "Assign Speed Dial to Contact?" Touch

Ye s

Contacts in Your Phone’s Memory

4. Touch

Storing a Number with Pauses

Pauses allow you to enter additional series of numbers to access automated systems such as Voicemail or credit billing

Contacts in Your Phone’s Memory

numbers. Pause types are:

(W)

The phone stops dialing

until you press the Release touch

RELEASE

key on the Touch Screen, to advance to the next number.

2-Sec Pause (P)

phone waits two seconds before sending the next string of digits automatically.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone.

2. Touch the Phone Touch Soft Key .

3. Enter the number, then touch the Options icon .

Wa it

The

Add 2-Sec Pause/ Add

, then enter additional

Wa it

numbers.

5. Touch the Save touch key

SAVE

Contact entry as necessary.

Deleting

Deleting a Contact Entry

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone.

2. Touch the Contacts Touch Soft Key .

3. Touch the Contact you want to erase (search using # or alphabet letters at the bottom of the screen, if necessary).

4. Touch the Erase touch key

ERASE

Ye s

5. Touch

, then complete the

Camera Features

3D (Three-axis-accelerometer) Rotation

3D Rotation is a feature that allows you to have flexibility in how you view content on your screen. Simply turn your Samba Touch device from vertical to horizontal (or horizontal to vertical ) and get a whole new perspective. Samba Touch senses the change in orientation and can automatically adjusts to fit the screen. View an image in wide screen orientation. This feature is helpful when you're looking at your pictures, browsing your music by album artwork, browsing websites, or even entering text.

Rotate

Samba Touch

sideways.

Camera Features

The built-in 3.2 MP camera feature is complete with optics for superior photo capabilities with various options, effects, and controls.

Camera Features

Tap the screen to access the options menu.

Back

Brightness

White Balance

Shot Type

Camera Settings

The images below show how to access the camera settings.

Touch to change to video camera mode

Touch to take a picture

Touch to go to My Pictures

Zoom(not available at the highest resolution)

Options in Camera Mode

Brightness Setting

the level of brightness you want.

White Balance

Sunny/ Cloudy/ Fluorescent/ Glow

Touch

Auto/

Shot Types

Normal Panorama Intelligent Facial Makeover

Normal

: No effect is applied to

the picture.

Panorama

from left to right. Take the first shot, align the shadow of the first shot with the next shot, then take that picture. Align and take the third shot to automatically join the three shots together into one panoramic shot.

Intelligent

automatically adjust for up to 5 ambient conditions so that the best picture is taken.

: Take series of pictures

: Camera will

Fac ial Ma keover

detects faces for better portrait quality. Also removes blemishes and enhances facial features.

: Automatically

Camera Settings

Allows you to configure the following camera settings:

Resolution:

1600x1200 / 1280x960/ 800x480 / 640x480 Keep in mind that higher resolution, uses more memory. And, zoom is not available if set to the highest resolution.

Shutter Sound: Shutter / No

Sound / Say “Cheez”/ Ready! 1-2-3

Color Effects:

Aqua/ Sepia/ Black&White

Self Timer:

Seconds/ 10 Seconds

Auto Save Save Option

2048x1536/

Normal/ Negative/

Off/ 3 Seconds/ 5

On/ Off

Internal/ External

Camera Features

Video Camera

The built-in video camera feature comes with options similar to the Camera feature.

Video Camera Settings

The images below show how to access the video settings.

Camera Features

Tap the screen for video options

Brightness

White Balance

Record Settings

Zoom Setting Touch and slide right to zoom in or left to zoom out

Back

Touch to change to Camera mode

Touch to begin recording/end recording

Touch to go to My Videos

Options in Video Mode

Video Settings

Recording Time

Save

For Send

time so the video clip can be sent in a video message. Please note that the video clip may still need to be shortened for Sending.

For Save

saved as a high quality video clip to the phone (regardless of resolution setting). Video clips recorded in the For Save setting can be sent in a video message only if the recorded output is less than 500KB.

: For Send/ For

: Limits the recording

: Allows the video to be

Resolution

176X144

Color Effects

/ Aqua / Sepia / Black&White

Auto Save Save Option

: 320X240 /

: Normal / Negative

: On / Off

: Internal/ External

After Recording Video

After recording, use the Touch screen to select what to do with the video clip. Depending on the size, the options are:

Play / Erase / Send / Save

Play / Erase / Save

Camera Features

Picture Editing

With the Samba Touch’s many picture editing features, you have endless possibilites in creating fun pictures. While viewing a picture, touch the Options icon , then touch Edit.

Editing Touch Keys

Back

Drawing

Composition

Camera Features

Adjustments

Stamp

Undo

Save

Drawing

1. Touch the Drawing touch key . Options available are:

●

Pen

: Allows you to draw on the image using your finger (or a stylus).

●

Eraser

: Allows you to erase the Pen drawings with your finger (or a stylus).

●

Settings

: Allows you to configure the color and width for the Pen. Also allows you to set the Eraser width.

2. Press Save to save and exit.

Composition

1. You can change the photo's composition. Touch the Composition touch key . Options available are:

●

Zoom

: Allows you to zoom

in/out.

●

Rotate

: Allows you to rotate the image 90 degrees at a time.

●

Crop

: Allows you to crop the image. Once you select an area to crop, touch the Composition touch key to finalize cropping.

Adjustments

Improve your photos by adjusting Contrast, Sharpness, Blur or Brightness. Touch the Adjustments icon , then touch on the scroll bar of each

adjustment to increase (right side) or to decrease (left side).

Frames and Stamps

The Samba Touch has multiple frames and stamps to choose from to enhance your pictures.

1. Touch the Overlay icon . The following options are available:

●

Stamp

: Allows you to use stamps to enhance your image.

●

Frame

: Allows you to use

a frame for your image.

2. Touch Save to save the image and exit.

Camera Features

Video Player Controls

To display the video player controls, simply touch the Touch Screen while the video is playing to display the following:

Rewind Fast Forward

/ Play/ Pause

Camera Features

Marks as favorite* Display in wide screen Display in normal size Display in small size

*Note

This option is not available until after the video has been saved.

Video Editing

Editing a Video to Send

You can edit a video then send a video message to friends and family.

1. Access the video (via the Multimedia menu, for example), touch the video clip to open it. As the clip begins to play, touch the screen to display the video player controls.

2. Touch the Options icon , then touch

Msg

3. Touch the Clip icon at the point in the video where you want the video to start (indicated by a red triangle), then touch the Clip icon where you want the video to end (indicated by a blue triangle).

Edit For Video

4. Touch the Save icon to save the edited video or touch the Send icon to send it.

Editing Using Video Effects

Access

Videos

and touch the video clip to open it. Touch the screen as it begins to play, then touch the Options icon for the following options (bulleted):

●

Multi Trim

Use the Clip icon to create a new video with up to 3 clips from the current video. You can add a fade effect between the clipped video pieces by touching the Save icon and then Save with Fade Effect.

●

Multi Capture

You can capture still images from video footage and save in your device's picture gallery. You can save up to 5 still shots. Touch the Snapshot icon to capture. The Player will pause at that position, so touch the Play icon to resume playing the clip. After clip capture(s), touch the Save icon to save.

Camera Features

Using Phone Menus

MESSAGING

The phone can store up to 540 messages (with a maximum of 200 SMS and 100 MMS received messages). The information stored in the message is determined by phone mode and service capability. Other limits to available characters per message may exist. Please check with your service provider for system

MESSAGING

features and capabilities.

Shortcut

Simply touch the Messages Touch Soft Key while in Standby mode.

New Message Alert

Your phone will alert you when you have new messages.

●

The phone displays a message on the screen.

●

The message icon ( ) is displayed on the Notification

bar. In the case of a high priority message, ( ) is displayed.

1. New Message

Allows you to send messages (Text, Picture, Video and Voice). Each message can have multiple destination addresses and can contain various items of information. These are dependent upon the type of message you want to send.

1.1 Text Message

Sending a Basic Message

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

New Message

Text Message

4. Touch

5. Touch to enter the

NEW#

recipient's phone number or email address using the touch keys, then touch the Done touch key .

DONE

6. Touch the Text area to enter your message. Use the keypad that pops up, or touch the Pen touch key to write

PEN

in your message. Please note that you can rotate your phone 90 degrees counterclockwise to use the onscreen QWERTY. When finished entering text, touch the Done touch key .

DONE

7. Touch the Send touch key

SEND

Other Message Options

Entering saved addresses in the To: field

1. Follow steps 1-4 from the Sending a Basic Message instructions. Then, touch the Favorite touch key

Favorite

or touch the Contact touch key .

Contact

●

Favorite

Your list of Favorite Contacts is displayed. Select the one(s) to receive your message.

●

Contact

Your Contact List is displayed. Select the ones you want to receive your message.

MESSAGING

Note

To copy a destination address from Recent Calls or Groups, touch the New # touch key , touch the Options icon , then touch From Recent Calls or Groups and touch your selection.

Text Field Options

1. Touch the text entry area, then touch the Options icon .

2. Select from the following

MESSAGING

options.

Note

Options are dependent on the message type and current field.

Insert Quick Text

to insert a quick text. See page 63 for more information.

Save As Draft

message into the Drafts folder.

Add

Allows you to add a Signature or Contact Number/Email.

New #

Allows you

Saves the

Copy Text Paste Priority Level

Allows you to set the priority level for the message.

High/ Normal

Callback #

Inserts a preprogrammed callback number with your message.

On/ Off/ Edit

Save Quick Text

Allows you to add the text entered as a Quick Text.

Cancel Message

Cancels message editing and goes to Message menu.

3. Complete and then send the message by pressing or touching the Send touch key

SEND

1.2 Picture Message

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

New Message

3. Touch

Picture Message

4. Touch

5. Enter the destination address(es) by touching the Favorite touch key

Favorite

address from a Favorites entry, the Contact touch key

Contact

address from your Contact List, the New # touch key

to manually enter

New #

the address.

to copy the

6. Touch the Done touch key after entering the

DONE

recipient(s) (up to 10).

7. Touch the Text field, then type

your message with the touch keypad.

8. Touch the Picture field. The

pictures in your phone will display. To select a picture, simply touch it, then touch the Select touch key

SELECT

9. Touch the Send touch key

. A confirmation

SEND

message is displayed.

MESSAGING

Other Picture Message Options

Using the To: Field Options

1. Touch the New # touch key , then Touch the

New #

Options icon .

2. Select from the following

options:

From Contacts/ From Recent Calls/ Favorites/ Groups

MESSAGING

Using the Text or Subject Field Options

1. Touch the Options icon .

2. Select from the following

options:

Preview

Displays the Picture message as it would be seen by the recipient.

Save As Draft

message into the Drafts folder.

Saves the

Copy Text

Paste

Insert Quick Text

to insert quick text customized on the phone.

Add Slide

pictures and sound into a picture message.

Priority Level

to the message.

Allows you

Insert multiple

Gives priority

High/ Normal

Cancel Message

Adding Slides to Your Picture Message

When you want to send multiple pictures and sound, use the Add Slide option. This allows you to create one picture message with multiple pictures and sound attached to it.

1. Create a new picture message.

2. Add a picture or sound to your message.

3. Touch the Next Slide touch key .

4. Add another picture or sound file to the new Slide.

5. Repeat adding slides, text and pictures as necessary. Touch the Previous Slide/ Next Slide touch keys / to scroll through the slides attached to your picture message.

6. Complete the message then send the message.

1.3 Video Message

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

New Message

3. Touch

Video Message

4. Touch

5. Enter the destination address(es) by touching the Favorite touch key

Favorite

address from a Favorites entry, the Contact touch key

Contact

address from your Contact List, the New # touch key

to manually enter

New #

the address.

6. Touch after entering

7. Touch the text field, then type

DONE

the recipient(s) (up to 10).

your message with the touch keypad.

to copy the

MESSAGING

Touch the video field, then touch the video you wish to send. Touch to choose the desired video.

9. Touch the Send touch key to send.

SEND

1.4 Voice Message

The Basics of Sending a Message

1. Press and hold to unlock

MESSAGING

or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

New Message

3. Touch

4. Touch

Voice Message

5. Touch the Record touch key

your message.

Select

to start recording

6. Touch the Stop touch key to end recording.

Enter the destination

address(es) by touching the Favorite touch key to copy the address from a Favorites entry, the Contact touch key to copy the address from your Contact List, the New # touch key

New #

the address.

8. Touch the Done touch key

after entering

DONE

recipient(s) (up to 10).

9. Touch the

Subject

fields to add to your

message.

10. Touch the Send touch key

SEND

Favorite

Contact

to manually enter

Te x t

, and/or

to send.

2. Messages

When your phone receives a message, you are alerted by:

●

A notification message on the screen.

●

An alert tone and/or vibration, depending on your volume settings.

If you don’t respond to the notification within a few minutes, the notification message disappears and the New Message icon is displayed on the Notification bar instead ( indicates a high priority message).

You can choose to view your messages by the time received (sorted into Inbox and Sent folders) or by Contact (all messages are located in one folder sorted by address).

To change the message view:

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

Settings

3. Touch

4. Touch

Messages View

, then

touch a setting.

TIME/CONTACT

5. Touch the Save touch key

SAVE

Viewing Your Messages

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

MESSAGING

2. Touch .

3. Touch depending on your Messages View configuration).

4. Touch a message entry.

5. Options available for a received message:

●

message.

●

MESSAGING

message.

●

ERASE

FORWARD

message.

●

The Options key , for the following options:

Reply with Copy/ Save Quick Text/ Lock/Unlock/ Add To Contacts/ Extract Address/ Message Info

Messages

, to reply to the

, to erase the

, to forward the

(or

Inbox

Message Icon Reference

Text/Picture/Video Messages sent

Message delivered

Text/Picture/Video Messages failed

Message pending

Multiple Messages sent

Multiple Messages delivered

Multiple Messages failed

Multiple Messages incomplete

Locked

3. Drafts

Your phone allows you to save Drafts of messages. When Drafts are saved, they are saved in the Drafts folder.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Drafts

4. Touch a message entry.

5. Options from here:

●

Touch the Send touch key

to send the

SEND

message.

●

Touch the Options icon

for the following

options:

Preview / Save As Draft / Priority Level / Callback #

Message Icon Reference

Draft Text Message

Draft Picture/Video Message

4. Voicemail

Shows the number of new voice messages recorded in the Voicemail box. Once you exceed the storage limit, old messages may be overwritten. When you receive a new voice message, your phone will alert you.

Checking Your Voicemail Box

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

MESSAGING

2. Touch .

Voicemail

3. Touch

4. Options from here:

●

Touch the Clear touch key

to clear the

CLEAR

Voicemail counter.

●

Press the SEND Key or touch the Call touch key

to listen to the

CALL

MESSAGING

message(s).

5. Settings

Allows you to configure settings for your messages.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

Settings

3. Touch

Messaging Settings Sub-Menu Descriptions

1. Messages View

Select

TIME

to display messages chronologically in Inbox and Sent folders. Select sort all messages chronologically by Contact in one message folder.

CONTACT

2. Entry Mode

Select T9 Word , Abc , ABC or 123 to be your default input method.

3. Text Entry Settings

Allows you to activate/deactivate the text entry settings Show Candidate, Word Correction, or Word Prediction.

4. Auto Save Sent

Select Onto automatically save your Sent messages.

Off

Select save them. Select whenever a new message is sent.

if you don't want to

Prompt

to be asked

5. Auto Erase Inbox

Select On to automatically delete read messages when you exceed the storage limit.

6. Message Font Size

Select Small or Large for the size of the Messaging characters.

7. Text Auto View

Select On to automatically display message content on the screen. Select On+Readout to automatically display content and read it aloud. Select Off for more security and privacy by requiring the message to be opened to view it.

8. Text Auto Scroll

Select On to automatically scroll text down while viewing messages. Or, select Off.

9. Multimedia Auto Receive

Select On to automatically download attachments to Multimedia messages. Or, select Off.

10. Quick Text

Displays your list of Quick Text phrases to help you to reduce manual input into messages. Use this submenu to edit and add text.

11. Voicemail #

Allows you to manually enter the access number for Voicemail Service. This number should be only used when a VMS (Voicemail Service) access number is not provided by the network.

MESSAGING

12. Callback #

Select On to automatically send a designated callback number with your messages. Or, select Off.

13. Signature

Select Custom to create/edit a signature to automatically send with your messages. Select None for no signature.

14. Delivery Receipt

MESSAGING

When set to On, the phone will indicate Sent messages as having been successfully delivered. Please see page 60 for the icon indicating a "Message Delivered".

6. Erase Options

Allows you to erase all messages stored in your Inbox, Sent, or Drafts folders. Or, to erase all messages at once.

1. Press and hold to unlock

or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Erase Options

options available are:

Erase Inbox/ Erase Sent/ Erase Drafts/ Erase All

. The

CALL HISTORY

The Call History Menu is a list of the last phone numbers or Contact entries for calls you placed, accepted, or missed. It's continually updated as new numbers are added to the beginning of the list and the oldest entries are removed from the bottom of the list.

1. Missed Calls

Allows you to view the list of missed calls; up to 90 entries.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Missed Calls

4. Touch a Missed Call entry to view the entry. Options from here:

●

Touch the Call touch key

to place a call to the

CALL

number.

●

Touch the Message touch key

MESSAGE

to send a

message.

●

Touch the Contact Information touch key

CONTACT INFO

to view the

caller's contact entry. OR Touch the Save touch key

to save the contact

SAVE

information into your Contact List.

●

Touch the Options icon for the following options:

Save To Contacts (Contact info) / Erase/ Lock(Unlock)/ View Timers

CALL HISTORY

2. Received Calls

Allows you to view the list of incoming calls; up to 90 entries.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

Received Calls

3. Touch

CALL HISTORY

4. Touch a Received Call entry to view the entry. Options from here:

●

Touch the Call touch key

to place a call to the

CALL

number.

●

Touch the Message touch key

to send a message.

MESSAGE

●

Touch the Contact Information touch key

CONTACT INFO

caller's contact entry.

to view the

OR Touch the Save touch key

to save the call

SAVE

information into your Contact List.

●

Touch the Options icon for the following options:

Save to Contacts (Contact info) / Erase/ Lock(Unlock)/ View Timers

3. Dialed Calls

Allows you to view the list of outgoing calls; up to 90 entries.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Dialed Calls

4. Touch a Dialed Call entry to view the entry. Options from here:

●

Touch the Call touch key

to place a call to the

CALL

number.

●

Touch the Message touch key

MESSAGE

to send a

message.

●

Touch the Contact Information touch key

CONTACT INFO

to view the

caller's contact entry. OR Touch the Save touch key

to save the call

SAVE

information into your Contact List.

●

Touch the Options icon for the following options:

Save to Contacts (Contact info) / Erase/ Lock(Unlock)/ View Timers

4. All Calls

Allows you to view the list of the most recent calls; up to 270 entries.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

All Calls

3. Touch

4. Touch a Call entry to view the entry. Options from here:

●

Touch the Call touch key

CALL

number.

●

Touch the Message touch key

MESSAGE

●

Touch the Contact Information touch key

CONTACT INFO

the caller's contact entry.

to place a call to the

to send a message.

to view

CALL HISTORY

OR Touch the Save touch key

to save the call

SAVE

information into your Contact List.

●

Touch the Options icon for the following options:

Save to Contacts (Contact info) / Erase/ Lock(Unlock)/ View Timers

Shortcut

CALL HISTORY

To quickly view a list of all your recent calls, press the SEND Key from Standby mode.

5. View Timers

Allows you to view the duration of the different call types. Also allows you to view Data counters.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

View Timers

3. Touch

4. Touch the Reset touch key next to a call list to

reset it. Timers and Counters available are:

Last Call/ All Calls/ Received Calls/ Dialed Calls/ Roaming Calls/ Transmit Data/ Received Data/ Total Data/ Last Reset/ Lifetime Calls/ Lifetime Data Counter

5. To reset all the recorded

timers at once, touch the Reset All touch key .

Note

Not all Timers can be reset.

CONTACTS

The Contacts Menu allows you to store names, phone numbers and other information in your phone’s memory.

1. New Contact

Allows you to add a new number to your Contact List.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

New Contact

4. Enter the name and other contact information for each field.

CONTACTS

●

Touch a field, enter information, then touch the Done touch key .

5. Touch the Save touch key

SAVE

information.

2. Contact List

Allows you to view your Contact List.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Contact List

DONE

to save the

CONTACTS

Direct search touch keys. For example, touch the Pound touch key to display entries that begin with #,

CONTACTS

touching a letter will display entries that begin with that letter, etc.

4. Touch a Contact entry.

5. Options from here:

●

Touch the Erase touch key

ERASE

Contact.

●

Touch the Edit touch key

EDIT

Add a new contact.

Go to

ABC / 123/SYM Mode Toggle Key

to erase the

to edit the Contact.

●

Touch the Message touch key to send

MESSAGE

the Contact a message.

●

Touch the Options icon to select one of the following:

Send Name Card/ Set As Favorite/ Set Speed Dial

●

Press the SEND Key to call.

Note

From this Contact List, touch the Options icon . Then touch Erase. With this menu you can erase multiple contacts at the same time. Select (mark) the Contacts you want to delete then touch Erase.

3. Favorites

Allows you to add Contact entries or Contact groups to your list of Favorites to easily view, call, or send messages.

Shortcut

From the home screen, touch the Favorites icon .

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Fav or ite s

4. Touch the Add touch key

5. Touch

CONTACT

GROUP

6. Mark the contact entry or group to add and touch the Done touch key .

DONE

Note

To remove a contact or group, go to the Favorites screen and drag a Favorite into the drag trash can image ( changes to when you begin to drag an item).

4. Groups

Allows you to view your grouped Contacts, add a new group, change the name of a group, delete a group, or send a message to everyone in the selected group.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Groups

4. Options from here:

●

Touch the Options icon . Touch

edit, erase or send the group contacts as name cards (via Bluetooth).

Manage Groups

CONTACTS

●

Touch the New Group touch key to add

NEW GROUP

a new group to the list.

●

Touch a group with at least one member in it then Touch the Options icon

Mark All / Unmark

to select

All / Remove All

Once one or more contacts is marked, touch the Options icon to select an option:

CONTACTS

Remove/ New Text Message/ New Picture Message/ New Video Message/ New Voice Message/ Mark All/ Unmark All/ Remove All

5. Speed Dials

Allows you to view your list of Speed Dials or designate Speed Dials for numbers entered in your Contacts.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Speed Dials

4. Touch the Speed Dial position.

5. Touch the Contact you wish to assign a Speed Dial.

6. Touch the Contact number you want to assign (if applicable), then touch

Ye s

Contacts/ Multimedia

6. My Name Card

Allows you to create, edit and view your own Contact information including name, phone numbers, and email address.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

My Name Card

4. Touch .

EDIT

5. Enter your information as necessary, then touch the Save touch key .

SAVE

MULTIMEDIA

1. Take Picture

Take pictures straight from your phone.

Tips

●

To take a clear picture, set the proper brightness level and zoom before taking the picture. Zoom is not available at the highest picture resolution.

●

Avoid jolting the camera.

●

Wipe the camera lens with a soft cloth.

Shortcuts

The Side Camera Key ( ) is a shortcut key to Take Picture in Standby mode. Press and hold the Camera Key to record Video.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

Contacts/ Multimedia

MULTIMEDIA

2. Touch .

3. Touch

4. Touch the screen to set camera options. For more information on how to use the camera, see the Camera section on page 44.

●

Select the option(s) to customize.

Brightness

MULTIMEDIA

White Balance

Cloudy/ Fluorescent/ Glow

Shot Types

Panorama/ Intelligent/ Facial Makeover

Settings

Resolution

1600X1200/ 1280X960/ 800X480/ 640X480

Shutter Sound

Sound/ Say "Cheez"/ Ready!123

Tak e Pi ctu r e

Auto/ Sunny/

Normal/

2048X1536/

Shutter/ No

Color Effects

Negative/ Aqua/ Sepia/ Black&White

Self Timer

Seconds/ 10 Seconds

Auto Save Save Option

5. Touch the Take Picture touch key to take the picture.

6. Touch the Save Picture touch key . The picture is stored in My Pictures.

Normal/

Off/ 3 Seconds/ 5

On/ Off

Internal/ External

Tak e

Save

2. Record Video

Lets you record a video, complete with sound.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Record Video

4. Touch the screen to set Video options. For more information on how to use Video recording, see page 46.

●

Select the option(s) to customize.

Brightness

White Balance

Auto/ Sunny/

Cloudy/ Fluorescent/ Glow

Settings

Recording Time

For Send/

For Save

Resolution

320X240/

176X144

Color Effects

Normal/ Negative/ Aqua/ Sepia/ Black&White

Auto Save

On/ Off

Save Option Internal/ External

5. Record a video by touching the Record touch key

, then touch the

Record

Stop touch key to

Stop

end recording.

Note

You can also press the side Camera Key to start and stop recording.

6. Touch the Save touch key

. The video clip is

Save

stored in My Videos.

3. Record Voice

Allows you to use your phone as a voice recorder.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

MULTIMEDIA

3. Touch Record Voice.

4. Start recording by pressing .

Touch to stop.

Touch to pause.

5. After recording, voice memo is

automatically saved in your phone.

4. Images

MULTIMEDIA

Allows you to view photos stored in the phone.

Shortcut

Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone, touch the Shortcut Bin touch key to access the Shortcut menu, then touch the My Images icon .

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

Images

3. Touch

4. Touch your desired picture.

Options from here:

●

Touch the Send touch key

SEND

to send a picture by

message or Via Bluetooth.

●

Touch the Erase touch key

ERASE

to erase picture.

●

Touch the Favorite touch key

FAVORITE

to set as

favorite.

●

Touch the Options icon for the options below:

Options for Standard Images:

Set As

Wallpaper/ Picture ID

Tak e Pi ctu r e

camera function.

Slide Show

view the picture gallery images in a slide show.

Edit

Turns on the

Allows you to

To edit the image.

Rename To rename the image. Print

Via Bluetooth/

Preferences

File Info

Name/ Date/ Time/

Resolution/ Size/ Type

Options for Wallpaper Images:

Take Picture/ Wallpaper

Options for Images with DRM:

Set As/ Take Picture/ Slide Show/ File Info

5. Videos

Allows you to view videos stored in the phone.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Videos

4. From here you can select a video to play or manage your videos.

●

Touch a video file to play it.

●

Touch the Options icon to select one of the following options (options are dependent on file types).

Record Video

video camera function.

Erase

video(s) to erase.

Turns on the

Allows you to select

MULTIMEDIA

Move

Allows you to select video(s) to move between your phone and microSD card.

Lock/ Unlock Allows you to

select video(s) to Lock/ Unlock.

Erase All

Phone

Video Player Options

While the video is playing, touch the screen to access the onscreen options:

MULTIMEDIA

Back

Pause

Rewind

From Card/ From

Fast Forward

Favorite

Player Options:

Send/ Edit for Video

Msg/ Multi Trim/ Multi

Capture/ Add Fade

Effect/ Set as Wallpaper/

Erase/ Rename/ File Info

Screen size

6. Audios

6.1 My Ringtones

Allows you to set a ringtone or download a new one.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

Audios

3. Touch

4. Touch

5. Touch a ringtone to select it.

Note

Touch the Play touch key to play the ringtone.

6. Set the selected tone as:

Call Ringtone/ Contact ID/ Alert Sounds

My Ringtones

●

Call Ringtone: Allows you to set as a Ringtone for incoming calls.

●

Contact ID: Allows you to set the Ringtone to notify you when a specific Contact is calling you.

●

Alert Sounds: Allows you to set the ringtone to notify you whenever a new Text Message, Multimedia Message and/or Voicemail is received.

6.2 My Sounds

Allows you to select saved sounds or to record a new sound.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

Audios

3. Touch

4. Touch

My Sounds

5. Touch the Record New touch key . Or touch a sound using your fingertip.

Options for preloaded sounds:

Set As/ Send/ File Info

Options for user-recorded sounds:

Set As/ Erase/ Send/ Rename/ Move/ Lock/ Erase All/ File Info

MULTIMEDIA

BREW

Brew allows you to do more than just talk on your phone. Brew is a technology and service that allows you to download and use applications on your phone. With Brew, it is quick and easy to personalize your phone to suit your lifestyle and tastes. Just download the applications that appeal to you. With a wide range of software available, from ringtones to games to productivity tools, you can be

BREW

assured that you will find something useful, practical, or down right entertaining.

Downloading Applications

You can download applications and use Brew anywhere on the network, as long as your handset has a digital signal available. Most applications do not use a network connection while in use.

Incoming Calls

While downloading an application, incoming calls can be answered. After the call, BREW is connected again. When using applications, an incoming call will automatically pause the application and allow you to answer the call. When you complete your call, you can resume using the application.

1. BREW Apps

Allows you to download applications from the many fun and available options.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

BREW Apps

Note

If you attempt to download an application when the file memory is full, the following error message will occur: "Memory Full: Your phone does not have enough memory to download this app. Unlock or remove apps and try again."

2. BREW Info

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

BREW Info

BREW/ WEB

WEB

The Web opens a browser so that you can access the internet, directly from your phone. Accessibility and selections within this feature are dependent upon your service provider. For specific information on Web service, contact your service provider.

Start Browser

Starting an Web session.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Launch

. After a few seconds, you will see the home page.

BREW/ WEB

WEB

Ending an Web Session

End an Web session by pressing

Browser Navigation

Links embedded in content

Select items or links by touching it on the screen.

HINT

If you’re having trouble touching the exact link on the screen, use the zoom function to zoom in so that there is a larger area to touch to activate your selection on the Touch

WEB

Screen. You can zoom with the side volume keys.

Scrolling / Fast Scrolling

Use your fingertip to scroll the screen contents in the direction you move your finger. How quickly you move your finger determines the quickness of the scroll.

Panning

Panning is when you move around the screen content by pressing down lightly and dragging the screen with your fingertip (or pen-like stylus) to the area you want to see.

Note

Do not use a sharp item for your pen-like stylus because it could scratch your screen.

Returning to Home Page

Touch the Command bar icon

, then touch the Home icon

Browser Menu Options

Touch the Command bar icon

, then touch the Options

icon .

●

Full Screen View

Use the whole screen including the annuciator and command bar area to view pages. You can get the command bar by touching the Command bar icon .

●

WWW

Takes you to the Go To WWW screen where you can enter the Web address you wish to visit.

●

Add Bookmark

Allows you to

add bookmarks.

●

Find on Page

Allows you to search for text you want to find in the web page. (Search text is not case-sensitive.)

●

History

Displays list of the

most recently web pages.

●

Display Mode

Changes the layout of contents. The options are:

Standard

Displays a standard Browser screen with vertical and horizontal page navigation.

Page Overview

Allows you to select the section to be displayed on full page.

Fixed Width

Displays vertically aligned contents of the Web page which fit the size of the screen. Allows vertical navigation only.

Text O n ly

Displays only text and excludes images used in the Web page.

WEB

●

Send URL

the link of the current page via a text message.

●

Settings

configure to your preferred Browser settings. The options are:

JavaScript

Feed settings

items/ 75 items

RSS Update mode

Automatic/ Manual

Security

Referrer/ Authentication Caching/ SSL3.0/ TLS 1.0/ Root Certificates/ Current Certificate

Manage Memory

to clear memory used by browser.

Allows you to send

Allows you to

ON / OFF

25 items/ 50

Cookies/ Send

Allows you

Restore Defaults

Allows you to restore the Browser to the default settings.

●

Information

Shows Web Page Information or Browser Information.

Entering/Deleting Text, Numbers or Symbols

When a text entry field is touched or tapped, a Touch Keypad will pop up for you to enter text, numbers, or symbols. Simply touch the characters you want and touch the Clear touch key to delete.

NOTE

When entering text in an entry field, turn the device 90 degrees (counter-clockwise) to activate the Qwerty Touch Keypad instead of the Touch Keypad.

Command Bar Icons on the Touch Screen

Go To WWW

you the current page.

Bookmark

RSS Reader Allows you to

Shows

Back/ Forward

Home Returns to

Home Page

Zoom

Allows you to

view saved Bookmarks

access your RSS feeds.

Allows you to

Refresh

reload the current Web page.

*While a page is

loading, is displayed. Touch this to stop loading the page.

Menu Displays the Browser menu

WEB

ZOOM Options

1. Access the Browser.

2. With the Command Bar menu open, touch the Zoom icon

to display the zoom

button.

●

Touch the Plus Zoom icon to zoom in and touch the Minus Zoom icon to zoom out.

Zoom With the Touch Screen

WEB

Zoom bar

Fixed Width Display Mode

The Fixed Width View mode simply resizes the page elements (e.g., images and areas of text) so that they are no wider than the physical width of the screen, causing the text to wrap at the screen's edge.

[ Before Fixed

Width ]

[ After Fixed

Width ]

From the Touch Screen:

1. Access the Browser.

2. Touch the Command bar icon . Then touch the

Options icon .

3. Touch

4. Touch

5. Touch

Display Mode Fixed Width Save

Using RSS reader

RSS (Really Simple Syndication) is a family of web feed formats used to publish frequently updated content such as blog entries, news headlines or podcasts. An RSS document, which is called a feed, web feed, or channel, contains either a summary of content from an associated web site or the full text. RSS makes it possible for people to keep up with their favorite web sites in an automated manner that is easier than checking them manually.

WEB

Add New Feed

When a web page finishes loading, the RSS Feed Indicator will appear on the bottom-left of the screen if an RSS feed is available.

Touch the RSS Feed indicator icon and select the feed you want to add. In the following screen, touch new feed.

WEB

RSS Feed Indicator

Save

Update Feeds

Touch the Command bar icon

, touch the RSS Feeds icon

, and touch the Feed Update

icon .

to save your

Feed Update Button

MUSIC

1. My Music

The Samba Touch allows you to store and to listen to music right from your phone.

Note

Storage availability depends on the size of each file as well as memory allocation of other applications.

Shortcut

Press side Music Key when in Standby mode to easily access My Music.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch a submenu to access your music.

Playing Your Music

It’s easy to find and play the music you’ve stored in your phone and memory card.

Access My Music

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

MUSIC

3. Touch one of the following submenus.

All Songs/ Playlists/ Artists/ Genres/ Albums/ Manage My Music/ Music Settings

4. Touch the name of the song you want to hear to start the music player.

Music Sub-Menu Options

Play All

Allows you to play all songs.

All Songs

MUSIC

Allows you to view all of your songs alphabetically. Touch a song to play it.

Playlists

Allows you to view and play your songs by playlist. Playlists can be created on either your phone or PC then transferred between them, but Playlists can only be managed

(add and delete songs) from where they were created.

Artists

Allows you to view and play your songs grouped by artist.

Genres

Allows you to view and play songs by genre.

Albums

Allows you to view and play songs by album.

Manage My Music

Allows you to manage your music

Erase/ Move to Card/

files. (

Move to Phone/ Lock/ Unlock

Music Settings

Allows you to set one of the following modes:

)

●

Repeat

Repeat All

: Repeats the playlist once the last song is played.

Repeat One

: Plays the

selected song repeatedly.

Repeat Off

: Plays all songs in the list once, then stops and exits the Music Player.

●

Shuffle

Shuffle On

: Shuffles music files in the songs list and plays them in random order.

Shuffle Off

: Plays the music files in the order in which they are displayed.

●

Music Only On

: Allows you to listen

exclusively to your music (as you do with MP3 Players) without being interrupted by calls.

Off

: Wireless communications

are once again enabled.

Note

• The Samba Touch Music Player has

various EQ settings available (Manual, Flat, Bass Boost, Treble Boost, Vocal Boost, Classical) for different playback conditions & sound type.

Dolby Mobile is an audio

•

processing technology platform that brings rich, vibrant surround sound to music on the Samba Touch.

Controlling the Music Player

While listening to your music, use the following to control the Music Player:

●

Options touch key : Allows you to choose:

Exit Player/ Music Only Mode/Add To Playlist/ Song Info /Home Screen

MUSIC

●

Side Volume Keys : Adjust the volume.

*Tip

* This function allows you to join the

band by touching Cymbal, drum or synthesizer and enjoy the music play during the play.

Music Player Controls

Landscape mode

While music is playing, rotate the Samba Touch to enter Landscape mode.

MUSIC

Back key

Shuffle Repeat

Song Name

Rewind/ Skip Back

to Previous Song

Play/ Pause

Options Selected Catalog

Extras

(*Join the Band/ Rhythmical Beat/ Visual Effect/ Pick a Song Image)

EQUALIZER

(Manual/ Flat/ Bass Boost/ Treble Boost/ Vocal Boost/ Classical)

Fast Forward/ Skip to Next Song

MUSIC/ MY SCHEDULE

Background Music Mode

While music is playing, press the PWR/ END Key (or touch the Options icon , then touch Home Screen) to move the Music Player to the background of the Standby mode screen.

Exit From the Music Player

Press the PWR/ END Key twice to exit the Music Player.

MY SCHEDULE

1. Alarm Clock

Allows you to set one of ten alarms. At the alarm time, a notification will be displayed on the LCD screen and the alarm will sound (according to your Master Volume settings).

Shortcut

Unlock the Touch Screen and touch the Shortcut Bin touch key to access the Shortcuts menu, then touch the Alarm Clock Icon .

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Alarm Clock

MUSIC/ MY SCHEDULE

MY SCHEDULE

4. Touch the Add touch key

ADD

. (Up to 10 can be

added).

5. Touch the fields to edit the alarm information, including:

●

Set Time●Repeat

●

Ringtone

6. Touch the Save touch key

after setting all of the

SAVE

Alarm fields as necessary.

MY SCHEDULE

2. Calendar

Allows you to keep your agenda convenient and easy to access. Simply store your appointments and your phone can alert you with a reminder you set.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

Calendar

3. Touch

Note

Touch the Options icon to select from the following options: Weekly/ Go To Date/ Go To Today/ Search/ Erase Old/ Erase All/ Send

4. Touch a day.

5. Touch the Add touch key .

ADD

6. Touch Subject field to enter

text.

Scroll and touch the other Calendar setting fields. For each Calendar event you can set:

●

Start Time●End Time

●

Repeat Alerts Vibrate

●

Until Tones

8. Touch the Save touch key

when Calendar

SAVE

information is complete.

MY SCHEDULE/ FM RADIO

3. Notepad

Allows you to add, read, edit, and erase notes.

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Touch

Notepad

4. Touch the Add touch key

to write a new note.

ADD

Note

Touch the Text Entry touch key

to change the entry mode.

Abc

5. After filling in the note, touch the Done touch key .

DONE

FM RADIO

Listen to FM broadcasts and music from your phone. Wired headphones, or a headset, are required to use this feature.

Access FM Radio

1. Press and hold to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch .

3. Plug a wired headset into the headset jack located at the top left of the phone.

Shortcut

With the Touch Screen unlocked and a wired headset plugged in, press the Music Key (located on the right side of the phone), then touch the FM Radio icon .

MY SCHEDULE/ FM RADIO

FM RADIO

FM Frequency Range

-107.9 MHz.

Automatic Scan Station Tuning

Available broadcast stations are dependent on the transmission signal strength in your current location. Touch the Scan Backward/ Scan Forward touch keys / to scan through the available FM Radio stations in your area.

Manual Tuner Wheel

FM RADIO

Touch and drag your finger across the tuner wheel icon

Back

Current Station

Frequency

Manual Tuner Wheel

Scan Backward

Sets Favorite Channels

Preset Favorite

Channels

: 87.5MHz

to manually tune to

a radio station frequency.

Setting Favorite Channels/Stations

Quickly access your favorite stations. Set up to 12 stations with simple touch access.

1. Access FM Radio.

2. Tune to a station, then touch .

3. Touch an empty preset station

touch key at the bottom of the Touch Screen.

Options

Sound Source Current Frequency Location

Displays Song info Scan Forward

Mute

Displays Preset Favorite Channels 7-12

(Headset or Speaker)

Using Saved Favorite Channels/Stations

●

From FM Radio, touch any preset station to automatically tune to it.

●

From Standby mode with FM Radio playing in the background, touch

the Preset Station List touch key to display your preset favorite stations. Use your fingertip to scroll the list up or down. Touch the preset station you want to listen to.

Returns to

FM Radio

Preset

Station List

FM Radio Options

While using the

My FM Radio

, touch the Options icon to select from the following options:

●

Exit FM Radio

Exits to

Standby mode.

●

Auto scan

Automatically scans for available radio frequencies.

●

Erase channel

Erases the

current preset channel.

●

Reset all channels

Resets all

preset FM Radio channels.

●

RBDS info On/Off

Toggles Radio Broadcast Data System display info on or off.

●

Listen Via

Allows you to switch between listening from the headset or phone’s speaker.

FM RADIO

FM RADIO/ BLUETOOTH

●

Go to My Music

My Music.

●

Home Screen

Standby mode with FM Radio playing in the background.

FM Radio Icon Reference

Icons at the top of the LCD

FM RADIO/ BLUETOOTH

screen indicate the FM Radio status.

FM Radio playing.

FM Radio paused.

Returns to

Exits to

BLUETOOTH

The Samba Touch is compatible with devices that support the Bluetooth Headset, Handsfree, Dial Up Networking, Stereo, Phonebook Access, Basic Printing, Object Push* File Transfer, Basic Imaging and Human Interface profiles. You may create and store 20 pairings within the Samba Touch, though you can only connect to one device at a time. The approximate communication range for Bluetooth wireless technology is up to 30 feet (10 meters).

Bluetooth QD ID B015677

Note*

Your phone is based on the Bluetooth specification, but it is not guaranteed to work with all devices enabled with Bluetooth wireless technology. Phone does not support all Bluetooth OBEX Profiles.

LG SAMBA 8575 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
