Contents
Installation |
3 |
Location and function of controls |
4 |
Remote control handset |
|
Battery installation |
|
Front panel / Side panel |
|
Basic operation |
7 |
On and off / Programme selection |
|
Volume adjustment / Quick view |
|
Mute function / Auto Demonstration |
|
On screen language selection (option) |
|
On screen menus |
8 |
Menu selection |
|
Setting up TV stations |
9 |
Auto programme tuning |
|
Manual programme tuning |
|
Programme edit |
|
Favourite programme |
|
Calling the programme table |
|
Picture adjustment |
15 |
PSM (Picture Status Memory) |
|
Picture adjustment / Eye (option) |
|
Turbo picture selection (option) |
|
Sound adjustment (option) |
17 |
SSM (Sound Status Memory) / Sound adjustment |
|
Turbo sound selection (option) |
|
Sound output selection (option) |
|
Stereo/Dual reception (option) |
|
NICAM reception (option) |
|
Time setting |
20 |
Setting the clock / Setting the On/Off timer |
|
Auto sleep |
|
Other functions |
21 |
TV and AV modes / Auto AV switching (option) |
|
Child lock / Blue back (option) / Tilt (option) |
|
Degaussing (option) / Games (option) / Sleep timer |
|
PIP operation (option) |
24 |
On and off / Input mode selection for sub picture |
|
Swapping between main and sub pictures |
|
Programme selection for sub picture |
|
Sub picture size / Sub picture freeze |
|
Sub picture position change / 9 or 4 sub picture |
|
Teletext (option) |
25 |
Switch on/off / SIMPLE text |
|
TOP text (option) / FASTEXT / Special teletext functions |
|
Connection of external equipment |
28 |
Aerial socket |
|
Audio/Video in/out sockets (option) |
|
Euro scart socket (option) |
|
S-video/Audio in sockets (S-AV) (option) |
|
Component in sockets (option) |
|
Headphone socket (option) |
|
Troubleshooting check list |
31 |
2
Installation
Power
This set operates on an AC mains supply, the voltage is as indicated on the label on the back cover. Never apply DC power to the set. In the event of thunderstorms or powercuts, please pull out the aer- ial and mains plugs.
Warning
To prevent fire or shock hazard, do not expose the set to rain or moisture.
The working life of this set is 7 years since the date of delivery to
consumer.
Do not place anything containing liquid on top of the set, this may cause a fire or could give an electric shock.
Service
Never remove the back cover of the set as this can expose you to very high voltage and other hazards. If the set does not operate properly, unplug it and call your dealer.
Aerial
Connect the aerial cable to the socket marked +75 Ω on the back cover. For the best reception an outdoor aerial should be used.
Location
Position your set so that no bright light or sunlight falls directly onto Care should be taken not to expose the set to any unnecessary vibration, moisture, dust or heat. Also ensure that the set is placed in a position to allow a free flow of air. Do not cover
the ventilation openings on the back cover.
3
