See Beyond,
LG Transparent OLED Signage
55EW5F
* All images used are for illustrative purposes only.
A New Level of See-through View
Imagination becomes reality
LG Transparent OLED signage
illuminates spaces that once
were hidden away behind the
display, completely harmonizing
with its surroundings.
Boasting vivid and clear colors
with high transparency, this
display provides valuable
information about as well as
visual enhancements to objects
placed behind it, giving viewers
an impressive “wow” factor.
FULL OF LIFE
Unrivaled Picture Quality
LG’s OLED technology, featuring self-lighting pixels, maintains accurate and vivid colors even
when the display becomes transparent. It brings content to life, making it difficult for people
to separate content from the real objects placed behind the screen. Only when viewed from
a side angle is the content readily distinguishable from the actual object. Also noteworthy,
LG Transparent OLED signage delivers awe-inspiring picture quality in all parts of the screen,
even from wide viewing angles.
SPACIAL HARMONY
High Transparency
Thanks to its high transparency (38%), much higher than conventional
LCD transparent displays, LG Transparent OLED signage blends into its
surroundings seamlessly and naturally. The display’s see-through view
turns places where it is installed into open and interactive spaces.
SPACIAL HARMONY
Customizable and Expandable Design
Wall Mount/1×2 Tiling
LG Transparent OLED signage is designed as a semi-assembled display, meaning you can install it
in various ways to fit into existing structures and spaces. The single stand-alone* type is available,
as well as ceiling and wall-mount types*. Displays can be also tiled* together to make a immersive
screen, enabling installation on large show-windows. There is no limit to the applications of
Transparent OLED signage, and it can complement and enhance any venue in which it is installed.
* Installation accessories are not supplied by LG.
Ceiling/Single
2×2 Tiling
SEE THROUGH
Effective Information Delivery
When people observe an object, having supplemental information can help
provide a richer understanding. In this case, LG Transparent OLED signage is
the optimal solution. While clearly showing objects behind the screen,
it overlays information right over them so that viewers can easily
see both the object and the relevant information without
having to change their view.
VISUAL FEAST PRODUCT DURABILITY
AR Effects in the Dark Robust Design for Safety
Using LG Transparent OLED signage, you can surprise viewers with AR effects in
the dark. The content displayed seems life-like, adding another “wow” factor to the
viewing experience.
The tempered front glass protects the screen from external impact, and its verified
safety design means it is reliable enough to endure shock and vibration caused by the
surrounding environment, such as moving trains.
OLED Panel
(Optically Clear Adhesive)
IEC 61373
Standard Verified
Tempered Glass
(3T)
OCA
AR Film
Dimension
(unit: mm)
Head Signage Box
1,225.5
7.9
7.9
121.7
100 250 150
13.5
6.6
782.8
754
810.1
Connectivity
1 52 3 4 6 7 8 9 10 11
1
USB 2.0
2
HDMI IN
3
DP IN
4
DP OUT
5
USB 2.0
6
LAN IN
7
LAN OUT
8
IR IN
Download
LG C-Display+
Mobile App
Google Play Store
9
RS232C IN
10
RS232C OUT
11
AUDIO OUT
www.lg.com/b2b
www.youtube.com/c/LGECommercialDisplay
www.facebook.com/LGInformationDisplay
www.linkedin.com/company/lginformationdisplay
LG may make changes to specifications and product descriptions without notice.
Copyright © 2020 LG Electronics Inc. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
The names of products and brands mentioned here may be the trademarks of their respective owners.
110
34.7
Specifications
Screen Size
Panel Technology
Native Resolution
Brightness (Typ.)
Contrast Ratio
Dynamic CR
PANEL
238.4
CONNECTIVITY
MECHANICAL
SPECIFICATION
KEY FEATURE
ENVIRONMENT
CONDITIONS
POWER
SOUND
CERTIFICATION
MEDIA PLAYER
COMPATIBILITY
SOFTWARE
COMPATIBILITY
ACCESSORIES
1)
The luminosity ratio of Full Black / Full White color on video input condition.
2)
Brightness may vary for final product (With glass).
3)
Network Based Control
4)
Compatibility may differ by equipment.
5)
The availability can differ by region.
* Specifications are subject to change without notice, so please contact LG sales team to verify before ordering.
Color Gamut
Viewing Angle(H × V)
Color Depth
Response Time
Surface Treatment (Haze)
Operation Hours (Hours/Day)
Portrait / Landscape
Transparency
Input
Output
External Control
Bezel Color
Bezel Width
Weight (Head)
Monitor Dimensions (W × H × D)
Monitor Dimensions with Stand
(W × H × D)
VESA
Protection Glass
Operation Temperature
Operation Humidity
Power Supply
Power Type
Power
Consumption
Speaker
Safety
EMC
ErP
OPS Type Compatible
OPS Power Built In
Basic
1)
2)
TM
Standard Mount Interface
Typ. / Max.
BTU
(British Thermal Unit)
150 / 400 nit (APL 100 % / 25 %, Without Glass)
HDMI (HDCP 2.2), DP (HDCP 1.4), USB 2.0 Type A (2)
RS232C In / Out, RJ45 (LAN) In / Out, IR In (External IR Receiver)
782.8 × 238.4 × 34.7 mm (Signage Box)
Depth 3.0 mm, Tempered / Chemical Strengthening, Anti-Reflective, Shatter-Proof
Internal Memory (64 GB), Temperature Sensor, FAN, webOS 3.0+
Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over,
Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (2),
Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting,
Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager,
Crestron Connected
FFC Cables (1,600 mm × 4 ea for Connection Between Panel and Signage Box),
DP Cable (2 M), LAN Cable (2 M), RS232 Cable (4P-4P,1.5 M), LC Cable (VLC, 3 M),
Screw (M4 × L22, 12 ea / M4 Nut 12 ea / M3 × L5.5, 8 ea / M3 × L3.5, 20 ea),
Ⓡ3)
, PM Mode, Wake on LAN, HDMI-CEC4), SI Server Setting, webRTC
1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.)
SuperSign CMS, SuperSign Control / Control+, SuperSign WB,
SuperSign Media Editor, Signage365Care
Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book,
Tape (10 ea for Cabling / 10 ea EMI Gasket Tape),
Shield Cover Ass'y, Rubber Damper 4 ea
55EW5F
55"
OLED
1,920 × 1,080 (FHD)
150,000 : 1
No
BT709 120 %
178 × 178
1.07 Billion Colors (10 bit)
1 ms (G to G)
No
18 / 7 (Moving Content Only)
Yes / Yes
38 % (SET)
DP, Audio
7.9 / 7.9 / 7.9 / 121.7 mm (T/L/R/B)
13.9 kg (Head), 3.4 kg (Signage Box)
1225.5 × 810.1 × 6.6 mm (Head)
Mirror
No
No
0 °C to 40 °C
10 % to 80 %
AC 100 - 240 V ~, 50 / 60 Hz
Built-in Power
309 W / 318 W
No
CB / NRTL
FCC Class "A" / CE / KC
Yes (EU Only)
No
No
Phone to RS232C Gender,
5)
