Important Safety Precautions

Read these instructions. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide.

WARNING! Violation of the instructions may cause serious injury or death.

1. Never use an unapproved battery since this could damage the phone and/or battery and could cause the battery to explode.

2. Never place your phone in a microwave oven as it will cause the battery to explode.

3. Never store your phone in temperatures less than

-4°F or greater than 122°F.

4. Do not dispose of your battery by fire or with hazardous or flammable materials.

5. When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If wireless equipment is improperly installed and the air bag is deployed, you may be seriously injured.

6. Do not use a hand-held phone while driving.

7. Do not use the phone in areas where its use is prohibited. (For example: aircraft)

Important Safety Precautions

1. Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity, such as a bathroom.

2. Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. This

Important Safety Precautions

could cause a fire.

3. Do not drop, strike, or shake your phone severely. It may harm the internal circuit boards of the phone.

4. Do not use your phone in high explosive areas as the phone may generate sparks.

5. Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose as it may cause a fire or electric shock.

6. Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may cause electric shock or fire.

7. Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone.

8. Do not disassemble the phone.

1. Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.

2. Do not hold or let the antenna come in contact with your body during a call.

3. Make sure that no sharp-edged items such as animal’s teeth or nails, come into contact with the battery. This could cause a fire.

4. Store the battery out of reach of children.

5. Be careful that children do not swallow any parts (such as rubber plugs, earphone, connection parts of the phone, etc.) This could cause asphyxiation or suffocation resulting in serious injury or death.

6. Unplug the power cord and charger during lightning storms to avoid electric shock or fire.

7. Only use the batteries and chargers provided by LG. The warranty will not be applied to products provided by other suppliers.

8. Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty.

9. Your service provider programs one or more emergency phone numbers, such as 911, that you can call under any circumstances, even when your phone is locked. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

Important Safety Precautions

Table of Contents

Important Safety Precautions 1

Table of Contents 4

Welcome 9

Technical Details 10

Important Information 10 FCC Part 15 Class B Compliance 10

Table of Contents

Technical Details 10 FCC RF Exposure Information 11 Bodily Contact During Operation 12 Vehicle-Mounted the External

Antenna 13 FCC Notice and Cautions 13 Caution 14 Part 15.19 statement 14 Part 15.21 statement 14 Part 15.105 statement 15

Phone Overview 16

Menu Overview 19

The Battery 23

Installing the Battery 23 Removing the Battery 23

Charging the Battery 23

Getting Started with Your Phone 23

How to Install Your microSD Card 24

How to Remove Your microSD Card 25

Battery Charge Level 25

Turning the Phone On and Off 25

Turning the Phone On 25 Turning the Phone Off 25

Signal Strength 26

Screen Icons 26

Making Calls 26

Correcting Dialing Mistakes 27

Redialing Calls 27

Receiving Calls 27

™

Quick Access to Convenient Features 28

Lock Mode 28

Mute Function 28

Quick Volume Adjustments 28

Call Waiting 28

Caller ID 29

Speed Dialing 29

Entering and Editing Information 30

Text Input 30

Key Functions 30

Contacts in Your Phone’s Memory 31

The Basics of Storing Contacts Entries 31

Phone Numbers With Pauses 31

Searching Your Phone’s Memory 33

Contacts Options 33

Making a Call From Your Phone’s Memory 34

Phone Menus 36

Contacts 36

1. New Contact 36

2. Contact List 36

3. Groups 37

4. Speed Dials 38

5. My vCard 38

Messaging 39

1. New Text Message 39

2. New Picture Message 41

3. Inbox 42

4. Outbox 44

5. Drafts 45

6. Voicemail 46

7. Templates 46

8. Settings 47

9. Delete All 48

Call History 49

1. Missed Calls 49

2. Received Calls 49

3. Dialed Calls 49

4. All Calls 49

5. Call Timer 50

6. Data Counter 50

Multimedia 50

1. Take Photo 50

2. Record Video 52

3. Record Voice 53

4. Images 53

5. Videos 55

6. Sounds 55

My Schedule 57

1. Alarm Clock 57

Table of Contents

2. Calendar 57

3. Notepad 58

easyedge

1. easyedgeSMApps 60

Music 60

1. Last Played Songs (Now Playing) 61

2. All Songs 61

3. My Playlists 61

4. Artists 62

Table of Contents

5. Albums 62

6. Genres 62

Tools 63

1. Voice Command 63

1.1 Start Command 63

1.1.1 Call <Name> or <Number> 63

1.1.2 Voicemail 63

1.1.3 Missed Calls 64

1.1.4 Messages 64

1.1.5 Time & Date 64

1.1.6 Help 64

1.2 Command Mode 64

1.3 Announce Alert 65

1.4 Train Word 65

1.5 Best Match 65

2. Calculator 65

3. My Menu 66

4. Ez Tip Calculator 66

5. World Clock 66

6. Stopwatch 67

7. Unit Converter 67

Settings 68

1. Sound 68

1.1 Ringtones 68

1.2 Volume 68

1.3 Message Alerts 68

1.4 Alert Type 69

1.5 Service Alerts 69

1.6 Power On/Off Tone 70

1.7 Flip Tone 70

2. Display 70

2.1 Wallpaper 70

2.1.1 Main Screen 70

2.1.2 Lock Screen 70

2.2 Widget Settings 71

2.3 Banner 71

2.4 Backlight 71

2.5 Menu Style 71

2.6 Languages (Idiomas) 72

2.7 Clocks & Calendar 72

2.8 Font Settings 72

2.9 Color Schemes 73

2.0 Word Prediction 73

3. Touch Settings 73

3.1 Touchscreen Calibration 73

3.2 Touchscreen Effect 74

4. Security 74

4.1 Lock Phone 74

4.2 Restrictions 75

4.3 Emergency Numbers 76

4.4 Change Lock Code 76

4.5 Master Reset 77

5. Call Settings 77

5.1 Answer Options 77

5.2 End Call Options 78

5.3 Auto Retry 78

5.4 One Touch Dial 78

5.5 Voice Privacy 78

5.6 Airplane Mode 79

5.7 TTY Mode 79

6. PC Connection 79

7. System 80

7.1 Network 80

7. 2 Location 81

8. Memory 81

9. Phone Info 82

Bluetooth

1. Paired Devices 83

2. Power 84

3. My Visibility 84

4. My Bluetooth Info 84

Tone Room Deluxe 85

PAC-MAN 85

Safety 86

TIA Safety Information 86

Exposure to Radio Frequency Signal 86

Antenna Care 86 Phone Operation 87 Tips on Efficient Operation 87 Driving 87 Electronic Devices 87 Pacemakers 88 Persons with pacemakers: 88 Hearing Aids 88 Other Medical Devices 88 Health Care Facilities 89

Table of Contents

Vehicles 89 Posted Facilities 89 Aircraft 89 Blasting Areas 89 Potentially Explosive Atmosphere 89 For Vehicles Equipped with an

Air Bag 90

Safety Information 90

Charger and Adapter Safety 91 Battery Information and Care 92 Explosion, Shock, and Fire

Table of Contents

Hazards 93 General Notice 93

Warning! Important safety information 95

Avoiding hearing damage 95 Using your phone safely 95 Using headsets safely 96

FDA Consumer Update 96 10 Driver Safety Tips 106 Consumer Information

on SAR 110 FCC Hearing-Aid Compatibility

(HAC) Regulations for Wireless Devices 11 3

Accessories 117

Limited Warranty Statement 118

Index 122

Some content in this user guide may differ from your phone depending on the phone software. Features and specifications are subject to change without prior notice.

Thank you for choosing the UN610 cellular phone; designed to operate with the latest digital mobile communication technology, Code Division Multiple Access (CDMA). Along with the many advanced features of the CDMA system, such as greatly enhanced voice clarity, this compact phone offers:

●

Slim and sleek design with internal antenna.

●

Large, easy-to-read, backlit LCD with status icons.

●

Messaging, voice mail, and caller ID capabilities.

●

QWERTY keypad.

●

Speakerphone feature.

●

Menu-driven interface with prompts for easy operation and configuration.

Welcome

●

Any Key answer, Auto with Handsfree answer, Auto Retry, One Touch Dial and Speed Dialing with 99 memory locations.

●

Bilingual (English and Spanish) capabilities.

●

Bluetooth®wireless technology.

Note

The Bluetooth®word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners.

Welcome

Technical Details

Important Information

This user’s guide provides important information on the use and operation of your phone. Please read all the information carefully prior to using the phone for the best performance and to prevent any damage to or misuse of the phone. Any unapproved changes or modifications will void your

Technical Details

warranty.

FCC Part 15 Class B Compliance

This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received,

including interference that causes undesired operation.

Technical Details

The UN610 is a trimode phone that operates on among (Code Division Multiple Access CDMA) frequencies: cellular services at 800 MHz, (Personal Communication Services PCS) at

1.9 GHz and GPS.

CDMA technology uses a feature called DSSS (Direct Sequence Spread Spectrum) that enables the phone to keep communication from being crossed and to use one frequency channel by multiple users in the same specific area. This results in a 10-fold capacity increase when compared with analog mode. In addition, features such as soft / softer handoff, hard handoff, and

dynamic RF power control technologies combine to reduce call interruptions.

The Cellular and PCS CDMA networks consist of MSO (Mobile Switching Office), BSC (Base Station Controller), BTS (Base Station Transmission System), , MS (Mobile Station) and GPS.

* TSB-74: Protocol between an

IS-95A system and ANSI J-STD008

1xRTT system receives twice as many subscribers in the wireless section as IS-95. Its battery life is twice as long as IS-95. Highspeed data transmission is also possible.

The following table lists some major CDMA standards.

FCC RF Exposure Information

WARNING! Read this information before operating the phone.

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards.

Technical Details

CDMA Standard

Basic Air Interface

Network

Technical Details

Service

Performance

Bodily Contact During Operation

This device was tested for typical use with the back of the phone kept 0.79 inches (2.0 cm) from

Designator

TIA/EIA-95A TSB-74 ANSI J-STD-008 TIA/EIA-IS2000 ANSI TIA/EIA 553A

TIA/EIA/IS-634 TIA/EIA/IS/651 TIA/EIA/IS-41-C TIA/EIA/IS-124

TIA/EIA/IS-96-B TIA/EIA/IS-637 TIA/EIA/IS-657 IS-801 TIA/EIA/IS-707-A

TIA/EIA/IS-97 TIA/EIA/IS-98 ANSI J-STD-018 ANSI J-STD-019 TIA/EIA/IS-125

Description

CDMA Dual Mode Air Interface

14.4kbps radio link protocol and interband operations IS-95 adapted for PCS frequency band cdma2000 1xRTT AirInterface

MAS-BS PCSC-RS Intersystem operations Non-signaling data comm.

Speech CODEC Short message service Packet Data Position Determination Service (gpsOne) High Speed Packet Data

Cellular base station Cellular mobile station PCS personal station PCS base station Speech CODEC

the body. To comply with FCC RF exposure requirements, a minimum separation distance of

0.79 inches (2.0 cm) must be maintained between the user’s body and the back of the phone,

including the antenna, whether extended or retracted. Thirdparty belt-clips, holsters, and similar accessories containing metallic components should not be used. Avoid the use of accessories that cannot maintain

0.79 inches (2.0 cm) distance between the user’s body and the back of the phone and have not been tested for compliance with FCC RF exposure limits.

Vehicle-Mounted the External Antenna

(Optional, if available.)

To satisfy FCC RF exposure requirements, keep 8 inches (20 cm) between the user / bystander and vehicle-mounted the external antenna. For more information about RF exposure, visit the FCC website at www.fcc.gov.

FCC Notice and Cautions

Any changes or modifications not expressly approved in this user guide could void your warranty for this equipment. Use only the supplied antenna. Use of unauthorized antennas (or modifications to the antenna) could impair call quality, damage the phone, void your warranty and/or violate FCC regulations.

Technical Details

Don't use the phone with a damaged antenna. A damaged antenna could cause a minor skin burn. Contact your local dealer for a replacement antenna.

Caution

Use only the supplied and approved antenna. Use of unauthorized antennas or modifications could impair call

Technical Details

quality, damage the phone, void your warranty and/or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin a minor burn may result. Contact your local dealer for a replacement antenna.

Part 15.19 statement

This device and its accessories comply with part15 of FCC rules. Operation is subject to the following two conditions:

(1) This device & its accessories

may not cause harmful interference.

(2) This device & its accessories

must accept any interference received, including interference that may cause undesired operation.

Part 15.21 statement

Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment.

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. if this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Technical Details

Phone Overview

1. Earpiece Lets you hear the caller.

2. LCD Screen Displays messages and indicator icons.

3. Left Soft Key Use to access the Messaging menu from the

standby screen, or the function immediately above it.

4. Speakerphone Key Use to turn Speaker On or Off. Press

and hold for 3 seconds to activate Voice Command.

5. SEND Key Use to place or answer calls.

6. EASYEDGE Key

7. Alphanumeric Keypad Use to enter numbers and select

menu items.

8. Microphone Lets callers hear you.

9. Camera Lens Used to take photos and record video. Keep

it clean for optimal photo quality.

10. Navigation Key Use to navigate through menus and

options. When on the Standby screen, use for quick access to your Widgets, My Menu, Calendar and easyedge.

11.

Menu/OK

Key Lets you access the phone's main Menu

and also selects the highlighted choice when navigating through a menu or function.

12. Right Soft Key Use to access the Contacts menu from

the standby screen, or the function immediately above it.

13. CLR Key Deletes single spaces or characters with a quick

press, but press and hold to delete the text entered in a text field. Will also back you out of menus, one level at a time.

14. PWR/END Key Use to turn the power on/off and to end

a call. Also, use to exit from any function and return to the standby menu.

15. VOICE Key When in standby mode, use to start the

Voice Command feature.

16. MUSIC Key Opens the Music feature.

1. Earphone Jack Allows the use of a hands-free

headset.

2. Side Volume Keys Use to adjust the ringer volume

in standby mode and the earpiece volume during a call.

3. Charger/Accessory Port Connects the phone to

the battery charger or other available accessories.

4. Camera Key Press for 3 seconds to open the

Camera function.

5. Lock Key Use to lock your phone when the flip is

closed. To unlock, press ( ) or open the flip.

microSD™card slot

external memory. Your phone supports a microSD card of up to 16GB (see page 24 for more information).

7. External Touch Screen

of the content and features on your phone.

Insert a microSD™card for

Displays messages and some

™

Charging with PC USB

You can use your computer to charge your phone. Connect one end of a USB cable to the charging accessory port on your phone and the other end to a high-power USB port on your PC.

Phone Overview

Internal Qwerty Keypad

Your phone features a QWERTY keyboard, specifically designed for easy and comfortable text entry. The QWERTY keyboard uses a standard layout.

Phone Overview

1. Function Key allows you enter the alternate

character (such as @ for the Tkey) on the QWERTY keyboard (See "Entering and Editing Information" on page 30 for more information).

SHIFT Key

lets you change letter capitalization when entering text, using the QWERTY keyboard.

3. SPACE Key lets you enter a space.

4. Symbols Key lets you enter symbols when

composing text messages.

5. ENTER Key lets you move the cursor to the beginning of the next line when composing text messages.

6. Back key Deletes single spaces or characters

with a quick press, but press and hold to delete the text entered in a text field. Will also back you out of menus, one level at a time.

Menu Overview

Touch Screen Menu Internal Menu

Messaging

1. Inbox

2. Outbox

3. Drafts

4. Voicemail

Speed Dials

1. View

Call History

1. Missed Calls

2. Received Calls

3. Dialed Calls

4. All Calls

Music

1. Last Played Songs

2. All Songs

3. My Playlists Top Rated Songs

4. Artists

5. Albums

6. Genres

Calendar

1. View

Multimedia

1. Take Photo

2. Record Video

3. Images

1. My Images

2. Default

4. Videos

5. Sounds

1. My Sounds

2. Default

Contacts

1. New Contact

2. Contact List

3. Groups

4. Speed Dials

5. My vCard

Messaging

1. New Text Message

2. New Picture Message

3. Inbox

4. Outbox

5. Drafts

6. Voicemail

7. Templates

8. Settings

1. All Messages

2. Text Message

3. Picture Message

Menu Overview

4. Edit Voicemail Number

9. Delete All

1. Delete Inbox

2. Delete Outbox

3. Delete Drafts

4. Delete All Messages

Call History

1. Missed Calls

2. Received Calls

3. Dialed Calls

4. All Calls

5. Call Timer

6. Data Counter

Multimedia

1. Take Photo

2. Record Video

3. Record Voice

4. Images

1. My Images

2. Default

5. Videos

6. Sounds

1. My Sounds

2. Default

My Schedule

1. Alarm Clock

2. Calendar

3. Notepad

easyedge

Music

1. Last Played Songs (Now Playing)

2. All Songs

3. My Playlists

4. Artists

5. Albums

6. Genres

Tools

1. Voice Command

1. Start Command

2. Command Mode

3. Announce Alert

4. Train Word

5. Best Match

2. Calculator

3. My Menu

4. Ez Tip Calculator

5. World Clock

6. Stopwatch

7. Unit Converter

1. Currency

2. Area

3. Length

4. Mass

5. Temperature

6. Volume

7. Velocity

Settings

1. Sound

1. Ringtones

1. All Calls

2. Caller ID

3. No Caller ID

4. Restricted Calls

2. Volume

1. Master Volume

2. Keypad

3. Earpiece

4. Speaker

3. Message Alerts

1. Text Message

2. Picture Message

3. Voicemail

4. All Messages

5. Message Reminder

4. Alert Type

5. Service Alerts

1. Minute Beep

2. Call Connect

3. Back to Top

4. Low Battery

6. Power On/Off Tone

7. Flip Tone

2. Display

1. Wallpaper

1. Main Screen

2. Lock Screen

2. Widget Settings

1. Widget List

2. Widget

Location

3. Banner

4. Backlight

1. Display Timer

2. Keypad Timer

3. Brightness

5. Menu Style

6. Languages (Idiomas )

7. Clocks & Calendar

8. Font Settings

1. Font Type

2. Dial Font

Style

3. Dial Font Size

9. Color Schemes

0. Word Prediction

3. Touch Settings

1. Touchscreen Calibration

2. Touchscreen Effect

1. Tone Type

2. Tone Level

3. Vibrate Type

4. Vibrate Level

Menu Overview

4. Security

5. Call Settings

Menu Overview

6. PC Connection

1. Lock Phone

2. Restrictions

3. Emergency Numbers

4. Change Lock Code

5. Master Reset

1. Answer Options

2. End Call Options

3. Auto Retry

4. One Touch Dial

5. Voice Privacy

6. Airplane Mode

7. TTY Mode

1. USB Connection Mode

2. Setting Reminder

7. System

1. Network

1. System Select

2. Set NAM

3. Auto NAM

4. Serving System

2. Location

8. Memory

1. Save Options

1. Images

2. Videos

3. Sounds

2. Phone Memory

3. Card Memory

9. Phone Info

1. My Number

2. ESN/MEID

3. Icon Glossary

4. Version

Bluetooth

1. Paired Devices

2. Power

3. My Visibility

4. My Bluetooth Info

Tone Room Deluxe

PAC-MAN

Getting Started with Your Phone

The Battery

The phone comes with a rechargeable battery. The battery charge level is shown at the top of the LCD screen.

Note

It is important to fully charge the battery before initial use of the phone.

Installing the Battery

Remove the battery cover by pressing down at the top-center of the battery cover, then sliding the cover downward. Align the battery with the terminals near the top of the phone (see image

1), then snap the rest of the battery into place (see image 2). Align the battery cover then slide it upward until it clicks into place (see image 3).

Removing the Battery

Turn the phone off. Slide the battery cover downward to remove it. Use the opening near the bottom of the battery to lift the battery out.

Charging the Battery

Use the charger provided with your phone:

Warning! Use only the charger provided with the phone. Using any charger other than the one included with the UN610 may damage your phone or battery.

Getting Start ed with Your Phone

Getting Started with Your Phone

Connect the cableless wall adapter and USB data cable. When connecting as shown below, the LG logo on the USB cable should face toward you.

Getting Start ed with Your Phone

2. Gently uncover the accessory charging port, then plug the end of the AC adapter into the phone’s charger port and the other end into an electrical outlet.

Notice

Please make sure that the 'B' Side faces up before inserting a charger or data cable into the charger port of your phone.

3. The charge time varies depending upon the battery level.

How to Install Your microSD™Card

1. Locate the microSD™slot on the right side of the phone and gently uncover the slot opening (the microSD cover stays attached to the phone so it doesn't become misplaced.

2. Insert the microSD facing up and push in until it clicks into the slot. If you insert the card in the wrong direction, it may damage your phone or your card.

™

slot

MicroSD Slot

™

card

™

How to Remove Your microSD™Card

1. Gently press and release the exposed edge of the

™

microSD

2. Remove the microSD

card to eject it.

™

card from the slot and replace the cover.

Note

Do not attempt to remove the

™

card while reading or

microSD writing to the card.

Battery Charge Level

The battery charge level is shown at the top right of the LCD screen. When the battery charge

level becomes low, the low battery sensor alerts you in up to three ways: sounding an audible tone, blinking the battery icon, and displaying a warning message. If the battery charge level becomes exceedingly low, the phone automatically switches off and any function in progress is not saved.

Turning the Phone On and Off

Turning the Phone On

1. Install a charged battery or connect the phone to an external power source (if the battery is low).

2. Press for about 2 seconds until the LCD screen lights up.

Turning the Phone Off

1. Press and hold until the display turns off.

Getting Start ed with Your Phone

Getting Started with Your Phone

Signal Strength

Call quality depends on the signal strength in your area. The signal strength is indicated on the screen as the number of bars

Getting Start ed with Your Phone

next to the signal strength icon

-- the more bars, the better the signal strength. If the signal quality is poor, move to an open area. If you are in a building, the reception may be better near a window.

Note

The call quality may also be affected by the places where you are and weather/ambient conditions.

Screen Icons

To see the icon glossary, go to

Settings

Icon Glossary

Phone Info

on your phone.

Making Calls

1. With the phone turned on, open the flip.

2. Enter the phone number (include the area code if needed).

3. Press .

4. Press to end the call.

Note

If outgoing calls are restricted, you can only dial phone numbers saved as Emergency Numbers or in your Contact List. To turn off this function:

Menu -> Settings ->

Enter the Lock Code ->

Security ->

Restrictions -> Outgoing Calls ->

Allow All -> ->

Service Lock Code.

Enter the

Correcting Dialing Mistakes

If you make a mistake while dialing a number, press once to erase the last digit entered, or hold down for 2 seconds to go back to standby mode.

Redialing Calls

1. Press twice to redial the number from the last call. The last 150 calls (50 missed, 50 received and 50 dialed) are stored in the call history list and you can also select any of these to redial.

Receiving Calls

1. When the phone rings and/or vibrates, press to answer, or open the flip (depending on your Answer Options).

2. Press to end the call.

Note

If you unlock the phone and press (the side keys) while the phone is ringing, the ringing and/or vibration is muted for that call.

Tip

To set Answer Options:

Menu -> Settings -> Call

Settings -> Answer Options.

Choose from the following options:

Flip Open/ SEND Key Only / Any Key/ Auto with Handsfree

Getting Start ed with Your Phone

Quick Access to Convenient Features

Lock Mode

Sets your phone to require a 4digit password in order to use the phone.

Quick Access to Convenient Features

Note

Until you change it, the default lock code/password is the last 4 digits of your phone number.

To quickly lock your phone press

for three seconds and then enter your Lock Code. To unlock, press Right Soft Key Unlock, enter the password.

Mute Function

The Mute function is available during a phone call. To quickly activate Mute during a call, press Left Soft Key cancel press Left Soft Key Unmute.

Mute, then to

Quick Volume Adjustments

Use the side keys to adjust the Master Volume while in standby mode, and the earpiece volume during a phone call. The upper key increases the volume and the lower key decreases the volume.

Note

Keypad Volume can be adjusted

through the Sound Volume menu:

Menu -> Settings -> Sound -> Volume ->

Keypad -> Use to adjust

volume and press .

Call Waiting

Your cellular service may offer call waiting. While a call is in progress, a beep indicates another incoming call. When call waiting is enabled, you may put the active call on hold while you answer the other incoming call.

Check with your cellular service provider for information about this function.

1. During a call, press to answer the incoming call (Call Waiting).

2. Press again to switch between calls.

Caller ID

Caller ID displays the phone number or name of the incoming call. If the caller’s identity is stored in Contacts, the name will appear along with the phone number. Check with your service provider for availability.

Speed Dialing

Speed Dialing is a convenient feature that allows you to make phone calls quickly. A number key can be assigned to a specific phone number. Then, by pressing

and holding down a number key, your phone will recall the phone number and dial that phone number for you. Speed Dial Number 1 is set to your Voice Mailbox by default and is unchangeable.

Dialing Single Digit Speed Dials (from 2 to 9)

Press and hold the Speed Dial number.

Enter the Speed Dial number and press .

Dialing Double Digit Speed Dials (from 10 to 99)

Press the first digit and then press and hold the key of the second digit.

Enter the first and second digits and press .

Quick Access to Convenient Features

Entering and Editing Information

: Press to change

Text Input

You can customize and enter text in many of the functions in your phone. Including, but not limited to: the Banner, Calendar,

Entering and Editing Information

Contacts and messages. While entering text, the following are your options:

Key Functions

Left Soft Key: Press to scroll through the following text input modes:

T9 Word: T9WORD/ T9Word/ T9word

Abc: ABC/ Abc/ abc 123 Symbols

Shift Key

capitalization

T9Word

: T9Word ->

T9WORD -> T9word

Abc : Abc -> ABC -> abc

Space: Press to complete

a word and insert a space.

Clear: Press to delete a single space or character. Hold to delete the text entered.

FN Key: Corresponding special characters on the QWERTY keypad can be entered, one at a time.

Contacts in Your Phone’s Memory

The Basics of Storing Contacts Entries

1. From standby mode, enter the phone number you want to save (up to 48 digits).

2. Press

3. Select either

Contact

4. Use to highlight a Label and press .

Mobile 1/ Home 1/ Office 1/ Mobile 2/ Home 2/ Office 2/ Fax

Note

Use another phone number to a contact already stored in memory.

5. Enter a name for the phone number (up to 32 characters) and press . A confirmation message is displayed briefly.

Save.

Add New

or Update Existing.

Update Existing

to add

Phone Numbers With Pauses

When you call automated systems, such as voice mail or credit billing numbers, you often have to enter a series of numbers to navigate through the system. Instead of entering these numbers by hand, you can store the numbers in your Contacts separated by special pause characters (W, P). There are two different types of pauses you can use when storing a number:

Wait (W)

The phone stops dialing until you press Right Soft Key

Release

to advance to the next

string of digits.

Pause (P)

The phone waits 2 seconds before sending the next string of digits.

Contacts in Your Phone’s Memory

Storing a Number with Pause or Wait

1. Press

2. Press

Contacts in Your Phone’s Memory

3. Press

4. Enter a name (up to 32 characters) and enter a number.

5. While entering a number, press Right Soft Key

Contacts

New Contact

Options.

6. Press

7. Enter additional number(s) then press

Wait

Save

Pause

Adding a Pause or Wait to an Existing Number

1. Press

2. Press

3. Press

4. Use to highlight the Contact entry to edit, then press

5. Press Left Soft Key

6. Use to highlight the number.

7. Press Right Soft Key

Options

8. Press

9. Enter additional number(s), then press

Contacts

Contact List

View

Wait

Save

Edit

Pause

Searching Your Phone’s Memory

The UN610 phone is able to perform a dynamic search of the contents in your phone’s Contact List. A dynamic search compares entered letters or numbers on the Dialpad against the entries in your Contacts. A matching list is displayed in descending order. You can then select a number from the list to call or view it.

Searching by Letter

1. Press

2. Press

3. Press

4. Start entering the Contact name. The matching entries will be automatically highlighted.

Contacts

Contact List

Scrolling Through Your Contacts

1. Press

2. Press

3. Press

4. Use to scroll through the list.

Contacts

Contact List

Contacts Options

1. Press

2. Press

3. Press

4. Highlight a contact and press Right Soft Key

5. Select an option.

Contacts

Contact List

Options

Send Message

message or picture message to the selected contact.

: Send a text

Contacts in Your Phone’s Memory

Delete

: Delete the selected

entry in your Contacts.

Edit

: Edit the selected

contact information.

Delete Multiple

from

Selective/All

delete multiple entries at one time.

Send via Bluetooth

a contact(vCard) via Bluetooth

: Choose

: Send

Set Speed Dial/ Remove Speed Dial

dial or remove as speed dial.

: Set as speed

Making a Call From Your Phone’s Memory

Once you have stored phone numbers in your Contacts, you can place calls to those numbers quickly and easily.

●

By pressing the Right Soft Key

Contacts

number and pressing .

●

By using Speed Dialing.

From Contacts

1. Press

2. Press

3. Press

4. Use to highlight the Contact entry, then press

View

5. Use to highlight the phone number.

6. Press to place the call.

, highlighting a

Contacts

Contact List

From Call History

1. Press

2. Press

3. Use to highlight the type of recent call, then press .

Call History

Missed Calls/Received Calls/Dialed Calls/All Calls

4. Use to highlight the phone number.

5. Press to place the call.

Speed Dialing

For a single-digit Speed Dial, press and hold the digit or press the digit, then press . For a double-digit Speed Dial, press the first digit and hold the second digit or press the first and second digits, then press

to call.

Contacts in Your Phone’s Memory

Phone Menus

Contacts

The Contacts Menu allows you to store names, phone numbers and other information in your phone’s memory.

Note

When you access your Contacts, the number in parentheses represents the number of entries you have stored (up to 1000).

1. New Contact

Allows you to add a new contact

Contacts

to your Contact List.

1. Press , , .

2. Enter the name, then press to highlight the field you

wish to store the contact information in.

3. Enter the phone number or

e-mail address.

4. When you are finished entering the desired contact information, press save the entry into your Contact List.

Note

Using this submenu, the number is saved as a new Contact. To save the number into an existing Contact, edit the Contact entry.

Save

2. Contact List

Allows you to view your Contact List.

1. Press , , .

2. Choose from the following options:

●

Press to scroll through your Contacts alphabetically.

●

Press Right Soft Key

Options

to select

one of the following:

Send Message/ Delete/ Edit/ Delete Multiple/ Send via Bluetooth/ Set Speed Dial (Remove Speed Dial)

●

Press

View

to view the highlighted contact's information.

●

Press Left Soft Key

New

to create a new

Contact.

3. Groups

Allows you to view your grouped Contacts, add a new group, change the name of a group, or delete a whole group.

1. Press , , .

2. Choose from the following options:

●

Use to highlight a group, then press to view the contacts in the selected group.

●

Press Left Soft Key

New

to add a new group.

●

Use to highlight a group, then press Right Soft Key choose from the following options:

Delete/ Send Message/ Rename Group/ Group Ringtone

/ Delete All

Options

View

Contacts

4. Speed Dials

Allows you to view your Speed Dials list, designate new Speed Dials, or remove Speed Dial designations entered in your Contacts.

1. Press , , .

2. Use to highlight the desired Speed Dial location (or enter the Speed Dial digit), and press

3. Use to highlight the

Contacts

Contact.

4. Use to choose a number, then press .

A confirmation message is displayed.

Assign

5. My vCard

Allows you to edit your vCard, which you can then send to others via Bluetooth.

1. Press , , .

2. Use to highlight the field you wish to edit, and press

Edit

Save

Left Soft Key

3. Edit the information as desired

and press

Note

You cannot edit the Mobile 1 field, but you can add additional contact info.

Messaging

The phone can store up to 835 messages, including a maximum of 500 SMS and 100 MMS messages in the Inbox, and 50 SMS and 50 MMS in the Outbox. The information stored in the message is determined by phone model and service capability. Other limits such as available characters per message may exist. Please check with your service provider for system features and capabilities.

1. New Text Message

Allows you to send text messages and e-mail transmissions.

The Basics of Sending a Text Message

1. Press , , .

2. Enter the recipient's address.

3. Press to access the text field.

Type your message (text or

4. e-mail).

5. Press Send.

A confirmation message is displayed.

Select Recipient(s) Using Options

1. Press , , .

2. Press Right Soft Key

Options

3. Use to highlight an option and press .

Contacts

from your Contact List.

To select a recipient

Messaging

Call History

recipient from your Call History.

Recent Messages

Inbox/ Sent

from your Recent Messages.

Groups

your Groups.

Cancel

message.

4. Complete your message and send or save it.

Messaging

Customize Your Text Message

Using Options

While you are composing the text of a message, you have various options to customize the text.

To select a

to select a recipient

Select a recipient from

Cancels editing your

Choose

1. Press , , .

2. Enter the recipient's address.

3. Use or press to access the text field.

4. Press Right Soft Key

Options

5. Use to highlight an option and press .

Insert Templates/Signature/

Name & Number

Save As Drafts/Templates

Priority Level High/ Normal

Callback Number On

Cancel

Cancels editing your

message.

6. Complete your message and send or save it.

Off

Message Icon Reference

Inbox

New/Unread Text/Picture Message

Opened/Read Text/Picture Message

New/Unread Notification Message

Opened/Read Notification Message

Priority High

Sent

Failed Text/Picture Message

Failed Multiple Text/Picture Messages

Sent Text/Picture Message

Sent Multiple Picture Message

Drafts

Draft Text Message

Draft Picture Message

2. New Picture Message

Allows you send messages with Text, Image/Video and Audio attachments.

1. Press , , .

2. Enter the recipient's address, or press Right Soft Key

Options

to search recent contacts and press to select the desired contact.

3. Use to access the Subject and Text fields.

4. Enter your subject and message.

5. With the

Image/Video

field highlighted, press Left Soft Key

Add

, and press

to select:

Image/ Video/ Take Photo/ Record Video

6. Use to highlight a file, then press Left Soft Key

Set

Messaging

7. With the highlighted, press Left Soft Key

Sounds

following options:

●

Press the Left Soft Key

Voice

to record new audio.

●

Press highlighted file.

●

Right Soft Key attach the highlighted file.

8. Press the Right Soft Key

Messaging

Options

message fields. The following options are available:

* Editing the To: field

Contacts/ Call History/ Recent Messages/ Groups/ Online Album/ Cancel

* Editing the Subject field

Preview/ Add/ Go to/ Save As/ Priority Level/ Remove/

Cancel

Audio

field

Add

to enter

and select from the

Play

to play the

Set

to customize the

* Editing the Text field

Preview/ Add/ Go to/ Save As/ Priority Level/ Remove/ Cancel

* Editing the Image/Video field

Preview/Add Slide/ Go to

Save As Draft/ Priority Level/ Remove/ Cancel

* Editing the Audio field

Preview/Add Slide/Go to

Save As Draft/Priority Level Remove/Cancel

12. Press

Send

3. Inbox

The phone can alert you in several ways when you receive a new message, including:

●

Displaying a notification message on the screen.

●

Displaying the message icon

/ on the status bar (It blinks when the message is urgent).

●

Ringing and/or Vibrating (depending on the Volume settings).

Received messages are displayed from newest to oldest.

Viewing Your Inbox

Up to 700 (500 SMS, 100 MMS and 100 MMS Notifications) messages can be stored in the Inbox.

1. Press , , .

2. Use to highlight an inbox message.

3. Press Left Soft Key

Reply/ D-load

to reply to the message or download the attachment, Right Soft Key

Options

, or

View/

Chat

to view the message.

The following options are available in the Options menu:

For text messages:

Chat/ Change View Type/ Delete/ Forward/ Save Contact/ Lock/ Message Info/ Delete Multiple

For picture messages:

Delete/ Forward/ Save Contact/ Lock/ Message Info/ Delete Multiple

4. Once you select the

View

option for the message, press

Left Soft Key

reply, or Right Soft Key

Options

to view additional

options.

Delete

Deletes the selected

message.

Forward

Forwards the message

to other destination address(es).

Messaging

Save Contact

Stores the callback number, e-mail address, and numbers in the received message into your Contacts.

Save as Template

message as a template for future messages.

Calls the number in the

CallBack

received message.

Lock/Unlock

Locks or unlocks

the selected message.

Message Info

message type, priority, and

Messaging

status.

Note

For picture messages:

Play Again/ Delete/ Reply as Picture Message*/ Forward/ Save Contact/ Save Media(Save Video**)/ Lock(Unlock)/ Extract Address/ Message Info

* If the Reply Setting (Menu >

Messaging > Settings > All Messages > Reply Setting) is set to Text Message Only.

** In case of video.

Shows the

Stores the

4. Outbox

Up to 100 sent messages (50 SMS and 50 MMS) can be stored in the Outbox folder. View the contents of sent messages and verify whether the transmission was successful (if verification is supported by network).

1. Press , , .

2. Use to highlight a sent message.

3. Press Left Soft Key

Resend

to resend the

message to the recipient,

View

to view the message, or Right Soft Key to access the following options:

Delete/ Forward/ Save Contact/ Lock/ Message Info/ Delete Multiple

Options

3. While viewing the selected sent message, press Left Soft

Resend

Key

to resend the message to the recipient, or Right Soft Key

Options

to access the additional options:

Delete

Deletes the selected

message.

Forward

Forwards the message

to other destination address(es).

Save Contact

Stores the callback number, e-mail address, and numbers in the received message into your Contacts.

Save To Templates

Stores the message as a template for future messages.

Lock/Unlock

Locks or unlocks

the selected message.

Message Info

Shows the message type, priority, and status.

Note

For picture messages:

Play Again/ Delete/ Forward/ Save Contact/ Save Media(Save Video*)/ Lock(Unlock)/ Extract Address/ Message Info

*In case of video.

5. Drafts

Displays saved draft messages.

1. Press , , .

2. Use to highlight a Draft/Saved message. Options available are:

●

Press

●

Press Right Soft Key

Options

options:

Delete

message from the Drafts folder.

Save Contact Add New

Contact

Edit

for the following

Deletes the selected

Update Existing

Messaging

Lock/Unlock

so that it is not erased if the Delete Drafts or Delete All feature is used.

Delete Multiple Selective

All

6. Voicemail

Allows you to access new voice messages recorded in your voice mail box. Your phone will notify you when you receive a new voice message.

Messaging

Checking Your Voicemail Box

1. Press , , .

2. Choose from the following options:

●

Press Left Soft Key Clear to clear the voicemail counter.

●

Press to listen to the message(s).

Locks a message

●

Press Right Soft Key to return to the Messaging menu.

Exit

7. Templates

Allows you to display, edit, and add text phrases. These text strings allow you to reduce manual text input into messages.

1. Press , , .

2. Press Left Soft Key to create a new template.

3. Enter text and press to save the template.

4. Use to highlight a template and press Right Soft

Options

Key highlight an option and press

to select:

Edit/ Delete

New

Save

, then

8. Settings

Allows you to configure Messaging settings.

1. Press , , .

2. Use to highlight

Messages

/ Text Message/

Picture Message/ Edit Voicemail Number

3. Use to highlight one of

the submenus and press

to select it.

Message Settings Sub-Menu Descriptions

All Messages

1. Reply Setting (Text Message Only/ Selection)

With

Text Message Only

replies to messages will automatically start as text

All

then press

on,

messages. With you will have the choice to reply with a Text or Picture Message.

Selection

2. Auto Save (Auto Save/ Prompt/ Do Not Save)

With this feature on, messages are automatically saved in the Outbox when transmitted.

3. Auto Delete (On/ Off)

With this feature on, read messages are automatically deleted when you exceed the storage limit.

4. Entry Mode

Allows you to select the default input method between

T9Word, Abc and 12 3 .

5. Signature (On/ Off/ Edit)

Allows you to make/edit a signature to automatically send with your messages.

on,

Messaging

Text Message

1. Auto View (On/ Off)

When set to On, new messages will automatically display on your screen when they are received.

2. Callback Number (On/ Off/ Edit)

With this feature on, you can input the callback number

Messaging

that will be automatically included when you send a message.

Picture Message

1. Auto Receive (On/ Off)

With this set to On, Multimedia content will be automatically downloaded when a new picture message is received.

Edit Voicemail Number

Allows you to manually enter the access number for your Voicemail Service. This feature should only be used when a VMS (Voicemail Service) access number is not provided from the network.

9. Delete All

Allows you to erase the messages stored in your Inbox, Outbox, or Drafts message folders. You can also erase all messages at the same time.

1. Press , , .

2. Use to highlight an Delete Inbox/ Delete

option:

/ Delete Drafts/

Outbox Delete All Messages then

press .

3. Use to highlight

and press .

Ye s/No

Call History

The Call History menu has lists of phone numbers and/or Contacts entries for calls you missed, received, or dialed. It is continually updated as new numbers are added to the beginning of the list and the oldest entries are removed from the bottom of the list.

Note

To quickly view a list of all your recent calls, press

from standby mode.

1. Missed Calls

Allows you to view the list of missed calls; up to 50 entries.

1. Press , , .

2. Use to highlight an entry.

SEND Key

2. Received Calls

Allows you to view the list of incoming calls; up to 50 entries.

1. Press , , .

2. Use to highlight an entry.

3. Dialed Calls

Allows you to view the list of outgoing calls; up to 50 entries.

1. Press , , .

2. Use to highlight an entry.

4. All Calls

Allows you to view the list of missed, received and dialed of calls; up to 150 entries.

1. Press , , .

2. Use to highlight an entry.

Call History

Call History/ Multimedia

5. Call Timer

Allows you to view the duration of selected calls, by type.

1. Press , , .

2. Use to scroll through the

Call History/ Multimedia

list.

Last Call/Home Calls/Roam

All Calls

Calls

6. Data Counter

Allows you to view the amount of Received and Sent data.

1. Press , , .

2. Use to scroll through the

list.

Received Data/Sent Data All Data

Multimedia

View, take, and trade your digital pictures, videos, and audio right from your wireless phone.

1. Take Photo

1. Press , , .

2. Press to access the following camera options:

●

Brightness

●

Resolution

1280X960/ 640X480/ 320X240

●

Capture

●

Zoom

●

Video

1600X1200/

3. Press the Left Soft Key

Gallery

to access

My Images

or press the Right Soft Key

Options

for the following

options:

●

Options Tab

Quality Fine/ Normal/

Economy

Color Effects Color/ Sepia/

Mono/ Negative

White Balance Auto/ Sunny/

Cloudy/ Tungsten/ Fluorescent

Night Mode On/ Off Self Timer Off/ 3 Seconds/

5 Seconds/ 10 Seconds

Frame On

/ Off

Multishot Off/ 3 shots/ 6

shots (Not available on 1600X1200 resolution.)

●

Settings Tab

Memory Storage Phone/Card Shutter Sound None/ Sound

1/ Sound 2/ Sound 3/ Say Cheese

Auto Save On/ Off Send Reminder On/ Off Reset Yes/ No

4. Take a picture by pressing

Capture.

5. Select

Send,Send to Online

, or

View

Album

picture is taken.

after the

Send

will

open a new Picture Message.

Send to Online Album

will send the picture to your online album for storage. will offer the following options:

●

Save

●

Gallery

●

Send

to send by Picture Message, via Bluetooth, or to your Online Album.

●

Set As

to set as the Wallpaper, as the Lock Screen, or as a Picture ID.

●

Delete

View

Multimedia

2. Record Video

Allows you to record a video message with sound.

1. Press , , .

Press to access the

2. following video camera options:

●

Brightness

●

Resolution

176X144

●

Record

●

Multimedia

Zoom

●

Camera

3. Press the Left Soft Key

Gallery to access Videos or

press the Right Soft Key

Options for the following

options:

320X240 /

●

Options Tab

Quality Fine/ Normal/

Economy

Color Effects Color/ Sepia/

Mono/ Negative

White Balance Auto/ Sunny/

Cloudy/ Tungsten/ Fluorescent

Record Time For Send[15s]/

For Save[1hr]

Mute On

●

Settings Tab

/ Off

Memory Storage Phone/Card Auto Save On/ Off Send Reminder On/ Off Reset Yes/ No

4. Press

Record

to begin

recording.

5. Right Soft Key

Stop

stop recording.

6. Select

Send,Send to Online

, or

Album

View

video is taken.

after the

Send

will open

a new Multimedia Message.

Send to Online Album

will send the video to your online album for storage.

View

will offer the following options:

●

Save

●

Gallery

●

Send

to send by Picture Message, via Bluetooth, or to your Online Album.

●

Delete

3. Record Voice

Allows you to add, listen to, and erase short verbal reminders.

1. Press , , .

Record

Stop

to record a

2. Press new voice memo.

3. Talk into the microphone, then press

4. Once you've stopped the recording, press Right Soft Key

Options

to access

the following:

Set As/ Rename/Delete

Press Left Soft Key Save to save the file. The default memo title is the date and time of recording.

Press

Send to send the file

in a Picture Message.

4. Images

Allows you to view the saved images on your phone. You can also select images to customize your phone's Main Screen, Front Screen, or Picture ID.

1. Press , , .

Multimedia

2. Use to highlight My / Default then press

Images

3. Use to highlight an image.

Once you have an image highlighted, you can:

●

Press Right Soft Key

Options

to access the

following options (If you

Edit

select

, please see the

Edit Options

Multimedia

available Edit options.).

Set As/ File Filter/ Slide Show/ Edit/ Image Effects/ Take Photo/ Delete/ Rename/ Lock/Unlock/ List View/ File Info/ Sort By

●

Press

View

selected image.

●

Press Left Soft Key

Send

to send the selected

image to somebody else.

section for

to view the

Edit Options

Zoom Allows you to zoom in/out

of the image. Please note, it does not save the resulting image.

Rotate Rotates an image in steps

of 90 degrees.

Flip Flips an image horizontally or

vertically.

Enhancement Automatically

enhances an image by enhancing white balance, contrast and local boost.

Brightening Brightens the image.

White Balancing Performs an

automatic white balance adjustment for the image.

Local Intensity Boost This effect

enhances images taken in poor light environments. The effect is especially useful when taking photos in direct light or for enhancing details in dark images.

5. Videos

Allows you to view saved video clips.

1. Press , , .

2. Use to highlight a video file. Once you have a video file highlighted, you can:

●

Press Left Soft Key

Send to send the selected

video clip to somebody else.

●

Press selected video clip.

●

Press Right Soft Key

Options

following available options:

File Filter/ Record Video/ Delete/ Rename/ Lock/Unlock/ List View/ File Info/ Sort By

Play

to play the

to access the

6. Sounds

Allows you to access saved audio clips or create new ones on your phone.

1. Press , , .

2. Press Left Soft Key to record an audio clip.

●

Press Left Soft Key

Sounds

to access My

Sound list.

3. Press

Record

recording.

4. While recording, press Left

Stop

Pause

to stop

Soft Key or recording.

5. When you are finished recording, press Left Soft Key

Save to save the audio

clip,

Send to send the

audio clip to somebody else,

Voice

to begin

to pause,

Multimedia

or press Right Soft Key

Options to access additional

options:

Set As (Ringtone/ Contact

ID/ Alert Sounds)/

Delete.

2. Use to highlight

Sounds/ Default

3. Use to highlight the

Multimedia

audio clip. The following options are available:

●

Press Left Soft Key

Send

audio clip to somebody else. Please note that this option is not available for files in the Default folder.

Rename/

and press

to send the selected

●

Press

Play

to play the

highlighted audio clip.

●

Press Right Soft Key

Options

to access the

following options:

For

My Sounds

files:

Set As/ File Filter/ Record Voice/ Delete/ Rename/ Move/Copy/ Lock/Unlock/ File Info/ Sort By

For

Default

files:

Set As (Ringtone/ Contact ID/ Alert Sounds

)

My Schedule

1. Alarm Clock

Allows you to set up to five alarms. At the alarm time, any set alarm can sound (depending on your Master Volume settings) the tone of your choice, and an alarm message will be displayed on the LCD screen.

1. Press , , .

2. Use to highlight the alarm you wish to set, then press to select it.

3. Press Left Soft Key to set an alarm time. Once you set the desired time, press .

4. Use to highlight (recurrence setting).

Set

Repeat

5. Press Left Soft Key to select one of the following.

Once/ Daily/ Mon - Fri/ Weekends

6. Use to highlight

Ringtone, press Left Soft Key

Set and browse for a

ringtone.

7. Press

Save

Set

2. Calendar

Allows you to store and access your agenda(s). Simply enter your appointments in the Calendar, and your phone can (depending on your settings) alert you with a reminder.

1. Press , , .

2. Use to highlight a day.

My Schedule

Moves to the previous day.

Moves to the next day.

Moves to the previous week.

Moves to the next week.

3. Press Left Soft Key

4. Use to highlight the field you wish to edit, then press

My Schedule

Left Soft Key the following schedule information:

●

Subject

●

End Time●Reminder

●

Repeat

●

Ringtone

5. Press

Save

Set

●

Start Time

●

Until

New

to edit

3. Notepad

Allows you to add, read, edit, and erase notes to yourself.

1. Press , , .

2. Press Left Soft Key to write a new note.

3. Type the note, then press

Save

A confirmation message displays briefly, then displays your list of saved notes.

New

My Schedule/ easyedge

Viewing a Notepad Entry

1. Access Notepad and highlight a saved note.

2. Press Right Soft Key

Options

to access the

following available options:”

●

Delete

Delete All

●

Edit

To edit a note, highlight the entry, then press

View

and press Left Soft Key

Edit

. Or press Right Soft Key

Delete.

easyedge

easyedgeSMallows you to do more than just talk on your phone.

easyedgeSMis a

technology and service that allows you to download and use applications on your phone. With easyedgeSM, it is quick and easy to personalize your phone to suit your lifestyle and tastes. Just download the applications that appeal to you. From ringtones and wallpapers to games and productivity tools, you can be assured you will find something useful, practical, or downright entertaining. There are new applications constantly available for your use.

Downloading Applications

You can download applications

easyedgeSMwhere

and use service is available.

My Schedule/ eas y edge

easyedgeSM/ Music

Incoming Calls

When using applications, an incoming call will automatically pause the application and allow you to answer the call. When you complete your call, you can resume using the application.

1. easyedge Apps

easyedge

1. Press , .

Shortcut

When in standby mode, pressing

the right arrow key will start

/ Music

easyedgeSM.

Music

Allows you to listen to songs stored in your memory card. To access this feature, there should be stored music in your memory card.

Notes

●

The microSDTMcard and its adapter can be easily damaged by improper operation. Please be careful when inserting, removing, or handling it.

●

Do not remove a microSDTMcard while files are being accessed or transferred. It will result in loss or damage of data.

Supported music format:

MP3, WMA(32Kbps), AAC, M4A

Music

1. Last Played Songs

(Now Playing)

Allows you to view the songs currently playing, or the most recently played songs. If music is playing in the background,

is shown as the option.

Playing

1. Press , , .

2. Use to highlight a music file and press to play it.

Now

2. All Songs

1. Press , , .

2. Use to highlight the music file and press to play or the Right Soft Key

Options

for the following

options:

Delete/ Add to Playlist/ Delete Multiple

Song Info

All)/

Play

(Selective/

or (when the song that is playing is highlighted):

Now Playing/ Add To Playlist/ Rating/ Song Info/ Settings

(Shuffle/ Repeat/ Background Music)

3. My Playlists

Allows you to create and listen to Playlists.

1. Press , , .

2. Highlight

3. Enter the playlist name and

4. Press

New Playlist

press to add a new playlist.

press to add new songs.

songs to add and press Left Soft Key

Save

Select

. Press

to choose

Done

and

Ye s

Music

5. Press Right Soft Key

Options

for the following

playlist options:

Delete/ Rename/ Delete Multiple/ Import M3U File/ Export M3U File

Notes

Songs rated at 4-Stars, or higher, will be automatically added to the Top Rated Songs playlist.

4. Artists

Allows you to view and listen to

Music

your music by Artist.

1. Press , , .

2. Use to highlight the Artist and press view the songs in your collection by that Artist.

View

5. Albums

Allows you to view and listen to your music by Album.

1. Press , , .

2. Use to highlight the Album and press view the songs from that Album.

6. Genres

Allows you to view and listen to your music by Genre.

1. Press , , .

2. Use to highlight the Genre to view and press

View

to view the songs in that

Genre.

View

Tools

Your phone’s tools include: Voice Command, Calculator, My Menu, Ez Tip Calculator, World Clock, Stopwatch, and Unit Converter.

1. Voice Command

Allows you to use voice commands to use your phone, including to make phone calls quickly and easily by voice. This menu also includes a feature for those who are driving or blind. It also announces time information by voice and allows you to check missed calls, messages and voicemails.

1.1 Start Command

1. Press , ,

While in standby mode, press and hold the Speakerphone Key .

, .

While in standby mode, press the Voice Key , then press

Start

Command

1.1.1 Call <Name> or <Number>

1. Press , , , , .

From standby mode, press and hold and say “Call”.

2. Say the Contact name (and phone type, if necessary) or number.

1.1.2 Voicemail

1. Press , , , , .

From standby mode, press and hold and say “Voicemail”.

2. Press to call Voicemail.

Tools

1.1.3 Missed Calls

1. Press , , , , .

From standby mode, press and hold and say “Missed Calls”.

2. The handset will prompt you to dial each number. Say to proceed.

1.1.4 Messages

1. Press , , , , .

Tools

From standby mode, press and hold and say “Messages”.

2. The handset will prompt you to dial each number from your messages. Say proceed.

Ye s

Yes or No

or Noto

1.1.5 Time & Date

1. Press , , , , .

From standby mode, press and hold and say “Time & Date”.

1.1.6 Help

1. Press , , , , .

From standby mode, press and hold and say “Help”.

1.2 Command Mode

Allows you to set command mode to Normal or Speed (The Speed setting allows you to access and use the Voice Command functions more quickly with a faster non-verbal prompt).

1. Press , , , .

2. Select options.

Normal/ Speed

1.3 Announce Alert

Allows you to customize Announce Alert. Announce Alert lets your hear more information about an incoming call or message instead of, or along with, your ringtone.

1. Press , , , .

2. Select options.

Disable/ Announce/ Announce + Ring

1.4 Train Word

Allows you to train words for improved Voice Command responses.

1. Press , , , .

2. Select options.

Voice Command/ Answer/ Digit Dial

1.5 Best Match

Allows you to choose whether the phone displays the 4 closest matches, or only the closest match, when using the “Call <Name> or <Number>” function.

1. Press , , , .

2. Select options.

1 Match/ 4 Matches

2. Calculator

Allows you to perform simple mathematical calculations.

1. Press , , .

2. Enter data.

●

Use keypad to enter numbers.

Tools

●

Use to enter decimals.

●

Use to insert parentheses.

●

Press Left Soft Key Reset to erase the entry.

●

Press Right Soft Key Options for additional calculating options.

●

Use the Navigation Keys to enter functions.

3. Press to complete

Tools

equation.

3. My Menu

Allows you quick access to your favorite menus. A maximum of 12 items can be stored in My Menu.

1. Press , , .

Highlight the location of your

2. choice by using , then

Set.

press

3. Browse to the menu you wish to add to My Menu by using , then press

Set.

4. Ez Tip Calculator

Allows you to quickly and easily estimate the tip and total amount of a bill by inputting the bill amount before tip, the tip percentage, and dividing it by the number of people paying.

1. Press , , .

5. World Clock

Allows you to determine the current time in another time zone or country.

1. Press , , .

2. Press Left Soft Key to open the map, press to zoom in.

3. Press Left Soft Key to see the cities located in the highlighted area.

Press Right Soft Key

to search through all

available cities.

4. Press highlighted city.

Save

New

City

to select the

6. Stopwatch

Allows you to use your phone as a stopwatch.

1. Press , , .

2. Press press

Start to start, and Stop to stop.

●

You can use the Lap function by pressing Left Soft Key record up to 20 laps and lap times.

3. Press Right Soft Key

Reset to reset.

Lap

7. Unit Converter

Allows you to convert units of Currency, Area, Length, Mass, Temperature, Volume and Velocity.

1. Press , , .

2. Select a unit type.

3. Use to select the known unit type, then enter the unit amount. The conversions will be calculated automatically.

Tools

Settings

1. Sound

Options to customize your phone's sounds.

1.1 Ringtones

Allows you to assign ringtones for incoming calls.

1. Press , , , .

All Calls/Caller ID

2. Select

Settings

No Caller ID/Restricted

Calls

3. Select

My Sounds

4. Use to highlight the ringtone.

5. Press ringtone, or Left Soft Key

Set

to set the ringtone to

your phone.

Play

to preview the

Default

1.2 Volume

Allows you to set various volume settings.

1. Press , , , .

2. Select

3. Use to adjust the volume

Master Volume

Keypad/Earpiece/Speaker

of the ringer, then press to save the setting.

1.3 Message Alerts

Allows you to select the alert tone for new message notifications and set the frequency of the Message

Reminder.

1. Press , , , .

2. Select

Text Message/Picture

Message Messages Reminder.

Voicemail/All

Message

3. Use to highlight the ringtone.

4. Press alert tone, or Left Soft Key

to your phone.

Play

to preview the

Set

to set the alert tone

1.4 Alert Type

Allows you to select the alert types.

1. Press , , , .

2. Use to highlight the alert you wish to edit.

Call Alert/ Message Alert/ Schedule Alert/ Alarm Alert/ E911 Alert

3. Use to scroll through the alert types.

Ring Only/ Vibrate Only/ Ring & Vibrate

4. Press to save.

1.5 Service Alerts

Allows you to set any of the Service Alert preferences.

1. Press , , , .

2. Select an alert type.

1.5.1 Minute Beep

Alerts you 10 seconds before the end of every minute during a call.

1.5.2 Call Connect

Alerts you when the call is connected.

1.5.3 Back to Top

Alerts you when you scroll through the end of a menu list.

1.5.4 Low Battery

Alerts you when the battery charge level is low.

Use to highlight On/ then press . (For Low Battery

Announce/Tone

option,

Off

)

Settings

1.6 Power On/Off Tone

Allows you to set the phone to sound a tone when the phone is powered on and off.

1. Press , , , .

2. Use to highlight

Off

, then press .

1.7 Flip Tone

Allows you to set a flip tone that will play when you flip your phone open or closed.

Settings

1. Press , , , .

2. Use to highlight

Off

, then press .

2. Display

Options to customize your phone's display screen.

2.1 Wallpaper

Allows you to choose the kind of background to be displayed on the phone.

1. Press , , , .

2. Highlight

Screen,

2.1.1 Main Screen

Highlight an image from

Images View

Soft Key wallpaper.

2.1.2 Lock Screen

Highlight an image from

Images View

Soft Key wallpaper.

Main Screen/Lock

then press .

Default

, and press

to view the image, and Left

Set

to set it as the

Default

, and press

to view the image, and Left

Set

to set it as the

2.2 Widget Settings

1. Press , , , .

2. Highlight

Widget Location,

Widget List/

then press

2.3 Banner

Allows you to enter a string of characters which display on the LCD screen.

1. Press , , , .

2. Use to scroll between

On/Off

3. Use to highlight the Text field.

4. Input text and press Left Soft Key

Abc

to change the text entry options, to save the banner, or Right Soft Key editing your banner.

Cancel

Save

to cancel

2.4 Backlight

Allows you to set the duration for illuminating the backlight.

1. Press , , , .

2. Highlight a submenu, then press .

Display Timer/ Keypad Timer/ Brightness

3. Use to highlight a setting, then press .

2.5 Menu Style

Allows you to view the Menu in either Icon or List view.

1. Press , , , .

Highlight Icon or List and

2. press .

Settings

2.6 Languages (Idiomas)

Allows you to use the bilingual feature according to your preference. Choose between English and Spanish.

1. Press , , , .

2. Use to highlight or

Español

, then press .

2.7 Clocks & Calendar

Allows you to select the type of clocks displayed on the main

Settings

LCD or the external LCD.

1. Press , , , .

2. Use to scroll through the different options and press

Set

Normal Clock/ Analog Clock/ Large Analog Clock/ Digital 12 Clock/ Large Digital 12 Clock/ Digital 24 Clock/ Large Digital 24 Clock/ Dual

Clock/ Calendar/ Off

2.8 Font Settings

Allows you to select the type of font displayed on LCD.

1. Press , , , .

2. Highlight a sub-menu and press .

English

Font Type/ Dial Font Style/ Dial Font Size

3. Use to highlight an option, then press .

Options for Font Type

LG Gothic/ LG Greentea/ LG Mint/ LG Round/ LG Secret

Options for Dial Font Style

Robot/ Green Lawn/ Painter/ Basic

Options for Dial Font Size

Normal/Large

2.9 Color Schemes

Allows you to choose the color scheme of the phone menus.

1. Press , , , .

2. Highlight press .

Black/ White

, then

2.0 Word Prediction

Allows you to activate word prediction, a function that uses your past text entries to predict what your next word will be.

1. Press , , , .

2. Use to highlight On/

Off

, then press .

3. Touch Settings

3.1 Touchscreen Calibration

Allows you to calibrate the Touch Screen to ensure it is working properly.

1. Press , , , .

2. Close the flip to start calibration.

3. Touch the target each time it appears.

4. After setting calibration, touch

Check Calibration Without Check

Save

Settings

●

If you touch

Calibration

, touch each target as it appears again. The screen will display a blue dot to indicate the location of your touch. If you are satisfied with your accuracy, touch to save, or touch Noto try again.

●

Touch

Save Without Check

save without viewing your touch accuracy.

Settings

3.2

Touchscreen Effect

Allows you to customize your Touch Screen effects' sound and vibration settings.

1. Press , , , .

2. Select the option you want to customize.

●

Tone Type Vibraphone/ High Pitch/ Glass/ Water Drop

Check

●

Tone Level Off/ Level 1/ Level 2/ Level 3/ Level 4/ Level 5

●

Vibrate Type Short/ Double/ Long

●

Yes

Vibrate Level Off/ Low/ Medium/ High

4. Security

The Security menu allows you to secure the phone electronically.

4.1 Lock Phone

Keeps your phone from unauthorized use. Once the phone is locked, it is in restricted mode until the Lock Code is entered. You can still receive phone calls and make emergency calls. You can modify the Lock Code in the Change Lock Code submenu of the Security menu.

1. Press , , .

2. Enter the four-digit Lock Code.

The default Lock Code is usually the last 4 digits of your phone number.

3. Press

Lock Phone

4. Use to highlight an

option, then press .

Unlock

The phone remains unlocked by default, until it is locked manually.

Lock Locks the phone. When

locked, you can receive incoming calls and make calls only to Emergency Numbers

Menu > Settings >

(

Security > Enter the four-

digit Lock Code >

Emergency Numbers).

On Power Up

The phone is

locked when it is turned on.

4.2 Restrictions

Allows you to set restrictions for Calls, Messaging, Camera or easyedgeSM.

1. Press , , .

2. Enter the four-digit Lock Code.

3. Press

4. Use to highlight

Incoming Calls/ Outgoing Calls/ Incoming Messages/ Outgoing Messages/ Camera/ easyedge

press .

5. Choose the type of restriction and press to set.

6. Enter the four-digit Service Lock Code.

Note

You can receive the incoming calls from saved contacts on your phone, when Contacts Only is on.

Restrictions.

, then

Settings

4.3 Emergency Numbers

Allows you to enter 3 emergency numbers. You can call these emergency numbers and 911, even when the phone is locked or restricted.

1. Press , , .

2. Enter the four-digit Lock Code.

3. Press

Numbers

Settings

4. Highlight one of the 3 options, then press to edit the emergency numbers.

5. When you are finished editing the number, press to save the emergency number, or Right Soft Key

Emergency

Cancel

to cancel editing.

Save

4.4 Change Lock Code

Allows you to enter a new fourdigit Lock Code.

1. Press , , .

2. Enter the four-digit Lock Code.

3. Press

Code

4. Use to highlight an option, then press .

Phone Only Allows you to change the Lock Code. used to lock/unlock the phone.

Call & Applications Allows you to change the Service Lock Code that is used to access the Restrictions menu (see page 75).

5. Enter the four-digit Lock Code.

Change Lock

6. Enter a new 4-digit Lock Code.

7. For confirmation, the phone will ask you to enter the new Lock Code again.

4.5 Master Reset

Allows you to reset your phone settings to the factory default settings.

1. Press , , .

2. Enter the four-digit Lock Code.

3. Press

4. A message will pop up warning you that your settings will be set to factory defaults. Press to proceed.

Master Reset

5. Use to highlight an option and press .

Revert/

Cancel

6. Enter your four-digit Lock Code to confirm your selection.

5. Call Settings

The Call Settings menu allows you to designate how the phone handles both incoming and outgoing calls.

5.1 Answer Options

Allows you to determine how to answer an incoming call.

1. Press , , , .

2. Use to highlight a setting, then press .

Flip Open/SEND Key Only Any Key/Auto with

Settings

Handsfree

5.2 End Call Options

Allows you to determine how to end a call.

1. Press , , , .

2. Use to highlight a setting, then press .

Flip Close/ End Key Only

5.3 Auto Retry

Allows you to set the length of

Settings

time the phone waits before automatically redialing a number when the attempted call fails.

1. Press , , , .

2. Use to highlight a setting, then press .

Off/Every 10 Seconds Every 30 Seconds/Every 60 Seconds

5.4 One Touch Dial

Allows you to initiate a Speed Dial call by pressing and holding the Speed Dial digit. If set to Off, Speed Dial numbers designated in your Contacts will not function.

1. Press , , , .

2. Use to highlight a setting, then press .

On/Off

5.5 Voice Privacy

Allows you to set the voice privacy feature for CDMA calls as Enhanced or Standard. CDMA offers inherent voice privacy. Check with your service provider for availability.

1. Press , , , .

2. Use to highlight a setting, then press .

Enhanced/Standard

5.6 Airplane Mode

Only allows you to use features on your phone that do not require wireless communications.

1. Press , , , .

2. Read the displayed message and press to continue.

3. Use to highlight a setting, then press .

On/Off

5.7 TTY Mode

Allows you to attach a TTY (Teletype writer) device, enabling you to communicate with parties also using a TTY device. A phone with TTY support is able to translate typed characters to voice. Voice can also be translated into characters and then displayed on the TTY.

1. Press , , , .

2. Read the displayed message and press to continue.

3. Use to highlight a setting, then press .

TTY Full/TTY + Talk/TTY +

TTY Off

Hear

6. PC Connection

Allows you to set the preferred connection type between your handset and your PC.

1. Press , , .

2. Use to highlight a

setting, then press .

USB Connection Mode/ Setting Reminder

Settings

7. System

The System menu allows you to designate specific system network settings.

7. 1 Network

7.1.1 System Select

Allows you to set up the phone producer’s management environment. Leave this setting as the default unless you want to alter system selection as instructed by your service

Settings

provider.

1. Press , , , , .

2. Use to highlight

Only/ Automatic A/ Automatic B

Home

, then press .

7.1.2 Set NAM

Allows you to select the phone’s NAM (Number Assignment Module) if the phone is registered with multiple service providers.

1. Press , , , , .

2. Use to highlight

NAM2

, then press .

7.1.3 Auto NAM

Allows the phone to automatically switch between programmed telephone numbers corresponding to the service provider area.

1. Press , , , , .

2. Use to highlight Onor

Off

, then press .

NAM1

7.1.4 Serving System

Identifies the serving system Channel Number and SID Number. This information should only be used for technical support.

1. Press , , , , .

7. 2 Location

Allows you to turn On or Off the Location function on your phone. If set to On, locationbased services are able to access your GPS (Global Positioning System) satellite-assisted location information.

1. Press , , , .

2. Read the disclaimer and press Right Soft Key go to the next screen or Left Soft Key the previous screen. Press Right Soft Key the last screen.

Next to

Prev to go to

3. Use to highlight

setting, then press .

On/ Off

Note

GPS satellite signals are not always transmitted, especially under bad atmospheric and environmental conditions, indoors etc.

8. Memory

Allows you to check out the memory status of your phone and to set the save options.

1. Press , , .

2. Use to highlight

Options/ Phone Memory/ Card Memory

Save

, and press .

Settings

Settings/ Bluetooth

9. Phone Info

The Phone Info menu provides you with specific information about your phone model.

1. Press , , .

2. Use to highlight an option and press .

Settings/ Bluet ooth®

My Number/ESN/MEID/ Icon Glossary/ Version

Bluetooth

The UN610 is compatible with devices that support the

Bluetooth

Headset, HandsFree, Phonebook Access, Object Push, and File Transfer profiles. You may create and store 20 pairings within the UN610 and connect to one device at a time. The approximate communication range for Bluetooth

wireless technology

is up to 30 feet (10 meters).

Bluetooth QD ID B015621

Note

Read the user guide of each Bluetooth accessory that you are trying to pair with your phone because the instructions may be different.

The Bluetooth®features available on this handset may not be compatible with all Bluetooth Your service provider or handset manufacturer cannot be held responsible for compatibility issues with devices not sold by the service provider or handset manufacturer.

enabled devices.

1. Paired Devices

Pairing is the process that allows the handset to locate, establish and register 1-to-1 connection with the target device.

For pairing new Bluetooth device

1. Press , , .

2. Follow the Bluetooth accessory instructions to set the device to pairing mode.

3. Press Left Soft Key

Search.

4. If Bluetooth

power is set to off, you will be prompted to turn power on. Highlight and press .

5. Select

New Search/Last

. The device will appear

Device Found

in the

Ye s

once it has been located. Highlight the device and press

Pair

6. Depending on the type of device:

- The phone will Autopair.

- You will need to confirm matching codes.

- You will need to enter a passkey. Consult the Bluetooth

accessory instructions for the correct passkey (typically “0000” - 4 zeroes). Enter the passkey and press .

7. The handset will prompt you for your connection preferences. Highlight

Always Connect

Ask

Always

and

press .

Bluetooth

Once connected, you will see

the device listed in the

menu.

Devices

2. Power

Allows you to set the Bluetooth power to On/Off.

1. Press , , .

2. Use to highlight a setting, then press .

Bluetooth

On/Off

Note

By default, your device’s Bluetooth functionality is turned off.

Paired

3. My Visibility

Allows you to set the visibility of your Bluetooth

1. Press , , .

2. Use to highlight a setting, then press .

On/ Off

4. My Bluetooth Info

Allows you to view information regarding the Bluetooth function.

1. Press , , .

function.

Tone Room Deluxe/ PAC-MAN

Tone Room Deluxe

Application that allows you to browse and download new ringtones.

1. Press , .

PAC-MAN

Allows you to use the preloaded PAC-MAN application. User charges may apply.

1. Press , .

Tone Room Deluxe/ PAC-MAN

Safety

TIA Safety Information

The following is the complete TIA Safety Information for wireless handheld phones.

Exposure to Radio Frequency Signal

Your wireless handheld portable phone is a low power radio transmitter and receiver. When ON, it receives and sends out Radio Frequency (RF) signals.

In August, 1996, the Federal

Safety

Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards previously set by both U.S. and international standards bodies:

ANSI C95.1 (1992) *

NCRP Report 86 (1986)

ICNIRP (1996)

* American National Standards Institute; National Council on Radiation Protection and Measurements; International Commission on Non-Ionizing Radiation Protection.

Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C95.1).

The design of your phone complies with the FCC guidelines (and those standards).

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments

could damage the phone and may violate FCC regulations.

Phone Operation

NORMAL POSITION: Hold the phone as you would any other telephone with the antenna pointed up and over your shoulder.

Tips on Efficient Operation

For your phone to operate most efficiently:

Don’t touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.

Driving

Check the laws and regulations on the use of wireless phones in

the areas where you drive and always obey them. Also, if using your phone while driving, please observe the following:

●

Give full attention to driving -driving safely is your first responsibility;

●

Use hands-free operation, if available;

●

Pull off the road and park before making or answering a call if driving conditions or the law require it.

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.

Safety

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of six (6) inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.

●

Should turn the phone OFF immediately if there is any reason to suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the customer service line to discuss alternatives).

Persons with pacemakers:

Safety

●

Should ALWAYS keep the phone more than six (6) inches from their pacemaker when the phone is turned ON;

●

Should not carry the phone in a breast pocket;

●

Should use the ear opposite the pacemaker to minimize the potential for

interference;

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Health Care Facilities

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may use equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted Facilities

Turn your phone OFF in any facility where posted notices so require.

Aircraft

FCC regulations prohibit using your phone while in the air. Switch OFF your phone before boarding an aircraft.

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted: “Turn off two-way radio”. Obey all signs and instructions.

Potentially Explosive Atmosphere

Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Safety

Areas with a potentially explosive atmosphere are often, but not always marked clearly. Potential areas may include: fueling areas (such as gasoline stations); below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles (such as grain, dust, or metal powders); and any other area where you would normally be advised to turn off your vehicle

Safety

engine.

For Vehicles Equipped with an Air Bag

An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If

in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

Safety Information

Please read and observe the following information for safe and proper use of your phone and to prevent damage. Also, keep the user guide in an accessible place at all times after reading it.

CCaauuttiioonn!

instructions may cause minor or serious damage to the product.

●

Do not disassemble or open crush, bend or deform, puncture or shred.

●

Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water or other liquids, expose

Violation of the

to fire, explosion or other hazard.

●

Only use the battery for the system for which it is specified.

●

Only use the battery with a charging system that has been qualified with the system per IEEE-Std-1725-2006. Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard.

●

Do not short circuit a battery or allow metallic conductive objects to contact battery terminals.

●

Replace the battery only with another battery that has been qualified with the system per this standard, IEEE-Std-1725-

2006. Use of an unqualified battery may present a risk of fire, explosion, leakage or other hazard.

●

Promptly dispose of used batteries in accordance with local regulations.

●

Battery usage by children should be supervised.

●

Avoid dropping the phone or battery. If the phone or battery is dropped, especially on a hard surface, and the user suspects damage, take it to a service center for inspection.

●

Improper battery use may result in a fire, explosion or other hazard.

●

The phone shall only be connected to USB products that bear the USB-IF logo or have completed the USB-IF compliance program.

Charger and Adapter Safety

●

The charger and adapter are intended for indoor use only.

Safety

●

Insert the battery pack charger vertically into the wall power socket.

●

Use the correct adapter for your phone when using the battery pack charger abroad.

●

Only use the approved battery charger. Otherwise, you may cause serious damage to your phone.

Battery Information and Care

●

Please dispose of your battery properly or take it to your

Safety

local wireless carrier for recycling.

●

The battery doesn't need to be empty before recharging.

●

Use only LG-approved chargers specific to your phone model since they are designed to maximize battery life.

●

Do not disassemble or shortcircuit the battery.

●

Keep the battery’s metal contacts clean.

●

Replace the battery when it no longer provides acceptable performance. The battery can be recharged several hundred times before replacement.

●

Recharge the battery after long periods of non-use to maximize battery life.

●

Battery life will vary due to usage patterns and environmental conditions.

●

Use of extended backlighting, Browser, and data connectivity kits affect battery life and talk/standby times.

●

The self-protection function of the battery cuts the power of the phone when its operation is in an abnormal state. In this case, remove the battery from the phone, reinstall it, and turn the phone on.

Explosion, Shock, and Fire Hazards

●

Do not put your phone in a place subject to excessive dust and keep the minimum required distance between the power cord and heat sources.

●

Unplug the power cord prior to cleaning your phone, and clean the power plug pin when it’s dirty.

●

When using the power plug, ensure that it’s firmly connected. If not, it may cause excessive heat or fire.

●

If you put your phone in a pocket or bag without covering the receptacle of the phone (power plug pin), metallic articles (such as a coin, paperclip or pen) may short-circuit the phone. Always cover the receptacle when not in use.

●

Don’t short-circuit the battery. Metallic articles such as a coin, paperclip or pen in your pocket or bag may shortcircuit the + and – terminals of the battery (metal strips on the battery) upon moving. Short-circuit of the terminal may damage the battery and cause an explosion.

●

Do not disassemble or crush the battery. It may cause a fire.

General Notice

●

Using a damaged battery or placing a battery in your mouth may cause serious injury.

●

Do not place items containing magnetic components such as a credit card, phone card, bank book, or subway ticket near your phone. The magnetism of the phone may damage the data stored in the magnetic strip.

Safety

●

Talking on your phone for a long period of time may reduce call quality due to heat generated during use.

●

When the phone is not used for a long period time, store it in a safe place with the power cord unplugged.

●

Using the phone in proximity to receiving equipment (i.e., TV or radio) may cause interference to the phone.

●

Do not use the phone if the antenna is damaged. If a damaged antenna contacts skin, it may cause a slight burn. Please contact an LG Authorized Service Center to replace the damaged antenna.

●

Do not immerse your phone in water. If this happens, turn it off immediately and remove the battery. If the phone does not work, take it to an LG Authorized Service Center.

●

Do not paint your phone.

●

The data saved in your phone might be deleted due to careless use, repair of the phone, or upgrade of the software. Please backup your important phone numbers. (Ring tones, text messages, voice messages, pictures, and videos could also be deleted.) The manufacturer is not liable for damage due to the loss of data.

●

When you use the phone in public places, set the ringtone to vibration so you don't disturb others.

●

Do not turn your phone on or off when putting it to your ear.

●

Use accessories, such as earphones and headsets, with caution. Ensure that cables are tucked away safely and do not touch the antenna unnecessarily.

Warning! Important safety information

Avoiding hearing damage

Permanent hearing loss may occur if you use your phone and/or headset at a high volume. Set the volume to a safe level. You can adapt over time to a higher volume of sound that may sound normal but can be damaging to your hearing. If you experience ringing in your ears or muffled speech, stop listening and have your hearing checked. The louder the volume, the less time is required before your hearing could be affected. Hearing experts suggest that to protect your hearing:

●

Limit the amount of time you use your phone and/or headset at high volume.

●

Avoid turning up the volume to block out noisy surroundings.

●

Turn the volume down if you can’t hear people speaking near you.

For information about how to set a maximum volume limit on your phone, see the features guide for your phone.

Using your phone safely

Use of your phone while operating a vehicle is not recommended and is illegal in some areas. Be careful and attentive while driving. Stop using your phone if you find it disruptive or distracting while operating any type of vehicle or performing any other activity that requires your full attention.

Safety

Using headsets safely

Use of headsets to listen to music while operating a vehicle is not recommended and is illegal in some areas. Be careful and attentive while driving. Stop using this device if you find it disruptive or distracting while operating any type of vehicle or performing any other activity that requires your full attention.

FDA Consumer

Safety

The U.S. Food and Drug Administration’s Center for Devices and Radiological Health Consumer Update on Mobile Phones:

1. Do wireless phones pose a health hazard?

The available scientific evidence does not show that any health problems are associated with

Update

using wireless phones. There is no proof, however, that wireless phones are absolutely safe. Wireless phones emit low levels of Radio Frequency (RF) energy in the microwave range while being used. They also emit very low levels of RF when in standby mode. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects may occur, but such findings have not been confirmed by additional research. In some cases, other researchers have had difficulty in reproducing those studies, or in determining the reasons for inconsistent results.

2. What is the FDA's role concerning the safety of wireless phones?

Under the law, the FDA does not review the safety of radiationemitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit Radio Frequency (RF) energy at a level that is hazardous to the user. In such a case, the FDA could require the manufacturers of wireless phones to notify users of the health hazard and to repair, replace, or recall the phones so that the hazard no longer exists.

Although the existing scientific data do not justify FDA regulatory actions, the FDA has urged the wireless phone

industry to take a number of steps, including the following:

●

Support needed research into possible biological effects of RF of the type emitted by wireless phones;

●

Design wireless phones in a way that minimizes any RF exposure to the user that is not necessary for device function; and

●

Cooperate in providing users of wireless phones with the best possible information on possible effects of wireless phone use on human health.

The FDA belongs to an interagency working group of the federal agencies that have responsibility for different aspects of RF safety to ensure coordinated efforts at the federal level. The following agencies belong to this working group:

Safety

●

National Institute for Occupational Safety and Health

●

Environmental Protection Agency

●

Occupational Safety and Health Administration

●

National Telecommunications and Information Administration

The National Institutes of Health participates in some interagency working group activities, as well.

Safety

The FDA shares regulatory responsibilities for wireless phones with the Federal Communications Commission (FCC). All phones that are sold in the United States must comply with FCC safety guidelines that limit RF exposure. The FCC relies on the FDA and other health agencies for safety questions about wireless phones.

The FCC also regulates the base stations that the wireless phone networks rely upon. While these base stations operate at higher power than do the wireless phones themselves, the RF exposures that people get from these base stations are typically thousands of times lower than those they can get from wireless phones. Base stations are thus not the subject of the safety questions discussed in this document.

3. What kinds of phones are

the subject of this update?

The term “wireless phone” refers here to handheld wireless phones with built-in antennas, often called “cell”, “mobile”, or “PCS” phones. These types of wireless phones can expose the user to measurable Radio Frequency (RF) energy because of the short distance between the phone and

LG MMBB0378701 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
