LG M2362DP, M2362DP-PZ, M2262DP, M2262DP-PZ, M1962DP-PZ Owner's Manual
...
ENGLISH
OWNER’S MANUAL
MONITOR TV
Please read this manual carefully before operating
your set and retain it for future reference.
MONITOR TV MODELS
M1962DP
M2062DP
M2262DP
M2362DP
M2762DP
www.lg.com
CONTENTS
CONTENTS
PREPARATION
FRONT PANEL CONTROLS ..............................4
BACK PANEL INFORMATION ............................5
STAND INSTALLATION ......................................6
DETACHING STAND ..........................................8
DETACHING STAND BODY .............................10
WALL MOUNT : HORIZONTAL INSTALLATION ....11
DESKTOP PEDESTAL INSTALLATION ...........12
POSITIONING YOUR DISPLAY .......................12
SWIVEL STAND(Only M2762DP) .....................13
LOCATION ........................................................13
SECURING THE SET TO THE WALL TO
PREVENT FALLING WHEN THE SET IS USED ON
A STAND (Only M2762DP) ...............................14
ATTACHING THE TV TO A DESK (Only
M2762DP) .........................................................15
KENSINGTON SECURITY SYSTEM ...............16
EXTERNAL EQUIPMENT SETUP
ANTENNA CONNECTION ................................17
HD RECEIVER SETUP ....................................18
DVD SETUP ......................................................21
VCR SETUP ......................................................24
INSERTION OF CI MODULE ...........................26
DIGITAL AUDIO OUT SETUP...........................27
USB SETUP ......................................................28
HEADPHONE SETUP ......................................29
PC SETUP ........................................................30
BACK COVER FOR WIRE ARRANGEMENT .....33
SUPPORTED DISPALY RESOLUTION ...........34
WATCHING TV / PROGRAMME
CONTROL
REMOTE CONTROL KEY FUNCTIONS ..........36
TURNING ON THE TV .....................................38
PROGRAMME SELECTION .............................38
VOLUME ADJUSTMENT ..................................38
QUICK MENU ...................................................39
ON SCREEN MENUS SELECTION AND
ADJUSTMENT ..................................................40
AUTO PROGRAMME TUNING ........................41
CABLE DTV SETTING (IN CABLE MODE ONLY) ........46
MANUAL PROGRAMME TUNING
(IN DIGITAL MODE) ...................................47
MANUAL PROGRAMME TUNING
(IN ANALOGUE MODE) .............................49
PROGRAMME EDIT .........................................51
IN DTV/RADIO MODE ......................................52
IN TV MODE .....................................................52
SOFTWARE UPDATE ......................................54
DIAGNOSTICS .................................................56
CI [COMMON INTERFACE] INFORMATION ...57
SELECTING THE PROGRAMME LIST ............58
FAVOURITE PROGRAMME SETUP ................59
INPUT LIST .......................................................60
EPG (ELECTRONIC PROGRAMME
GUIDE)(IN DIGITAL MODE)
Switch on/off EPG .............................................61
Select a programme ..........................................61
Button Function in NOW/NEXT Guide Mode ...62
Button Function in 8 Day Guide Mode .............62
Button Function in Date Change Mode ............63
Button Function in Extended Description Box ..63
Button Function in Record/Remind Setting Mode ........64
Button Function in Schedule List Mode ............64
PICTURE CONTROL
PICTURE SIZE (ASPECT RATIO) CONTROL .65
PICTURE WIZARD ...........................................67
ꕊ ENERGY SAVING .......................................68
PRESET PICTURE SETTINGS ........................69
MANUAL PICTURE ADJUSTMENT .................70
PICTURE IMPROVEMENT TECHNOLOGY ....71
EXPERT PICTURE CONTROL ........................72
PICTURE RESET .............................................75
SCREEN SETUP FOR PC MODE ...................76
SOUND CONTROL
AUTO VOLUME LEVELER ...............................81
CLEAR VOICE II ...............................................82
BALANCE ..........................................................83
2
PRESET SOUND SETTINGS-SOUND MODE ......84
PRESET SOUND SETTINGS-USER MODE ...85
Surround X ........................................................85
AUDIO RESET ..................................................86
DIGITAL AUDIO OUT ........................................87
TV SPEAKERS ON / OFF SETUP ...................88
DTV AUDIO SETTING
(IN DIGITAL MODE ONLY) ........................89
I/II
Stereo/Dual Reception
(In Analogue Mode Only) ......................90
NICAM Reception
(In Analogue Mode Only) ......................91
Speaker Sound Output Selection ...............91
INPUT BLOCK ................................................107
KEY LOCK ......................................................108
TO USE A USB DEVICE
WHEN CONNECTING A USB DEVICE..........109
PHOTO LIST ...................................................111
MUSIC LIST ....................................................117
MOVIE LIST ....................................................121
DIVX REGISTRATION CODE ........................128
DEACTIVATION ..............................................129
TELETEXT
CONTENTS
TIME SETTING
CLOCK SETUP .................................................92
AUTO ON/OFF TIME SETTING .......................93
SLEEP TIMER SETTING ..................................94
OPTION SETTING
ON-SCREEN MENU LANGUAGE / COUNTRY
SELECTION ......................................................95
LANGUAGE SELECTION
(IN DIGITAL MODE ONLY) .......................96
AUDIO DESCRIPTION
(IN DIGITAL MODE ONLY) .......................97
DATA SERVICE .................................................98
INPUT LABEL ...................................................99
POWER INDICATOR ......................................100
DEMO MODE ..................................................101
MODE SETTING .............................................102
INITIALIZING(RESET TO ORIGINAL FACTORY
SETTINGS) .........................................................103
PARENTAL CONTROL / RATINGS
SWITCH ON/OFF ...........................................130
SIMPLE TEXT .................................................130
TOP TEXT .......................................................130
FASTEXT ........................................................131
SPECIAL TELETEXT FUNCTION ..................131
DIGITAL TELETEXT
TELETEXT WITHIN DIGITAL SERVICE ........132
TELETEXT IN DIGITAL SERVICE ..................132
APPENDIX
TROUBLESHOOTING ....................................133
MAINTENANCE ..............................................137
PRODUCT SPECIFICATIONS .......................138
IR CODES .......................................................143
EXTERNAL CONTROL DEVICE SETUP
RS-232C Setup ........................................144
Type of Connector; D-Sub 9-Pin Male .....144
RS-232C Configurations ..........................144
Set ID ........................................................145
Communication Parameters .....................146
SET PASSWORD & LOCK SYSTEM .............104
BLOCK PROGRAMME ...................................105
PARENTAL CONTROL
(IN DIGITAL MODE ONLY) ......................106
3
PREPARATION
FRONT PANEL CONTROLS
■ This is a simplified representation of the front panel. The image shown may be somewhat different
from your set.
PREPARATION
1
2
9
3 4 5 6 7 8
Headphone Jack
1
IR receiver (Remote controller receiver)
2
INPUT Button
3
MENU Button
4
OK Button
5
VOLUME Button
6
7
PROGRAMME Button
8
Power Button
Power Indicator
9
Illuminates blue when the set is switched on.
Note: You can adjust Power indicator in the OPTION menu.
4
BACK PANEL INFORMATION
■ This is a simplified representation of the front panel. The image shown may be somewhat different from your
set.
1
2
3 4 5 6
PREPARATION
7 9
PCMCIA (PERSONAL COMPUTER MEMORY CARD
1
INTERNATIONAL ASSOCIATION) CARD SLOT
Insert the CI Module to PCMCIA CARD SLOT.
(This feature is not available in all countries.)
2
HDMI/DVI INPUT
Connect a HDMI signal to HDMI IN.
Or DVI (VIDEO) signal to HDMI IN with DVI to HDMI
cable.
RGB/DVI AUDIO INPUT
3
Connect the audio from a PC.
OPTICAL DIGITAL AUDIO OUT
4
Connect digital audio to various types of equipment.
Connect to a Digital Audio Component.
Use an Optical audio cable.
5
USB Input
6
Euro Scart Socket (AV IN)
Connect scart socket input or output from an external
device to these jacks.
8
1110
Power Cord Socket
7
This set operates on AC power. The voltage is indicated on the Specifications page. Never attempt to
operate the set on DC power.
8
RS-232C IN (CONTROL & SERVICE) PORT
Connect to the RS-232C port on a PC.
This port is used for Service or Hotel mode.
9
COMPONENT INPUT
Connect a component video/audio device to these
jacks.
10
RGB INPUT (PC)
Connect the output from a PC.
11
ANTENNA / CABLE INPUT
Connect over-the-air signals to this jack.
5
PREPARATION
<M1962DP/M2062DP/M2262DP/M2362DP>
STAND INSTALLATION
■ The image shown may be somewhat different from your set.
PREPARATION
Carefully place the product screen side down
1 2
on a cushioned surface that will protect product and screen from damage.
Turn the Stand Base Lock through 90° to fix the Stand Base to the Stand Body.
3
Insert the Stand Base into the product.
Stand Base
4 5
Base Lock
<Locked>
6
STAND INSTALLATION
■ The image shown may be somewhat different from your set.
Carefully place the product screen side down on a
1
cushioned surface that will protect product and
screen from damage.
Insert the stand base into the product.
2
<M2762DP>
PREPARATION
Use a Coin on the bottom of the stand base
3
and turn the screw clockwise to tighten.
Stand Base
Coin
7
PREPARATION
<M1962DP/M2062DP/M2262DP/M2362DP>
DETACHING STAND
■ The image shown may be somewhat different from your set.
PREPARATION
Place the set screen side down on a cushion
1 2
or soft cloth.
Turn the Stand Base Lock through 90° to separate the Stand Base from the Stand Body.
3
Detach the monitor to the Stand Base by
turning the screw to the left.
Pushing Latch inside, Take the stand base from stand body.
4
Latch
8
DETACHING STAND
■ The image shown may be somewhat different from your set.
Place the set screen side down on a cushion or soft
1
cloth.
Detach the monitor to the Stand Base by turning the
2
screw to the left.
Turn the screw by using a Coin.
<M2762DP>
PREPARATION
Pull the stand base.
3
Coin
9
PREPARATION
DETACHING STAND BODY
■ The image shown may be somewhat different from your set.
■ Remove the Stand Body in the same way as the following when using it as a Wall Hook.
PREPARATION
<M1962DP/M2062DP/M2262DP/M2362DP>
1. Remove the screw 2 point.
2. Pull the stand body.
<M2762DP>
1. Remove the screw 4 point.
2. Pull the stand body.
10
WALL MOUNT : HORIZONTAL INSTALLATION
For proper ventilation, allow a clearance of 10 cm on each side and from the wall. Detailed installation
instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and
Setup Guide.
10 cm
10 cm
10 cm 10 cm
10 cm
If you intend to mount the set to a wall, attach Wall mounting interface (optional parts) to the back of the set.
When you install the set using the wall mounting interface (optional parts), attach it carefully so it will not drop.
1. Be sure to use screws and a wall mount that meet VESA standards.
2. Using screws longer than those recommended might damage the product.
3. Using screws that do not meet VESA standards might either damage the product or result in it coming
away from the wall. We will not be held responsible for any damage resulting from failure to follow these
instructions.
4. VESA compatible only with respect to screw mounting interface dimensions and mounting screw speci-
fications
5. Please use VESA standard as below.
5-1) 784.8 mm (30.9 inch) and under
* Wall Mount Pad Thickness : 2.6 mm
* Screw : Φ 4.0 mm x Pitch 0.7 mm x Length 10 mm
5-2) 787.4 mm (31.0 inch) and above
* Please use VESA standard wall mount pad and screws.
PREPARATION
< Screw Mounting Interface Dimensions >
Model
M1962DP
M2062DP
M2262DP
M2362DP
M2762DP
VESA ( A x B) 100 x 100 200 x 100
Wall mount
RW120 RW240
bracket(optional)
Wall Mount Pad
11
PREPARATION
DESKTOP PEDESTAL INSTALLATION
■ The image shown may be somewhat different from your set.
For proper ventilation, allow a clearance of 10 cm on each side and from the wall.
PREPARATION
10 cm
10 cm
10 cm 10 cm
POSITIONING YOUR DISPLAY
■ The image shown may be somewhat different from your set.
Adjust the position of the panel in various ways for maximum comfort.
12
* Tilt range
-5°
15°
SWIVEL STAND(Only M2762DP)
■ The image shown may be somewhat different from your set.
After installing the set, you can adjust the set manually to the left or right direction by 179 degrees to
suit your viewing position.
LOCATION
Position your set so that no bright light or sunlight falls directly onto the screen. Care should be taken not to
expose the set to any unnecessary vibration, moisture, dust or heat. Also, ensure that the set is placed in a
position to allow a free flow of air. Do not cover the ventilation openings on the back cover.
PREPARATION
WARNING
■ When adjusting the angle of the screen, do not put your
finger(s) in between the head of the monitor and the stand
body.
You can hurt your finger(s).
13
PREPARATION
SECURING THE SET TO THE WALL TO PREVENT FALLING WHEN THE SET IS USED ON A STAND (Only M2762DP)
■ The image shown may be somewhat different from your set.
We recommend that you set up the set close to a wall so it cannot fall over if pushed backwards.
Additionally, we recommend that the set be attached to a wall so it cannot be pulled in a forward direction,
PREPARATION
potentially causing injury or damaging the product.
Caution: Please make sure that children don’t climb on or hang from the set.
■ Insert the eye-bolts (or set brackets and bolts) to tighten the product to the wall as shown in the picture.
* If your product has the bolts in the eye-bolts position before inserting the eye-bolts, loosen the bolts.
* Insert the eye-bolts or set brackets/bolts and tighten them securely in the upper holes.
Secure the wall brackets with the bolts (sold separately) to the wall. Match the height of the bracket that is
mounted on the wall to the holes in the product.
Ensure the eye-bolts or brackets are tightened securely.
■ Use a sturdy rope or cord (sold separately) to tie the product. It is
safer to tie the rope so it becomes horizontal between the wall and
the product.
NOTE
!
►When moving the set, undo the cords first.
► Use a platform or cabinet strong enough and large enough to support the size and weight of the set.
► To use the set safely make sure that the height of the bracket on the wall and the one on the set are the
same.
14
ATTACHING THE TV TO A DESK (Only M2762DP)
■ The image shown may be somewhat different from your set.
The SET must be attached to desk so it cannot be pulled in a forward/backward direction, potentially causing
injury or damaging the product. Use only an attached screw.
1-Screw
(provided as parts of the product)
PREPARATION
Stand
Desk
WARNING
►To prevent SET from falling over the SET should be securely attached to the floor/wall per installation
instructions. Tipping,shaking, or rocking the machine may cause injury.
15
PREPARATION
KENSINGTON SECURITY SYSTEM
- The product is equipped with a Kensington Security System connector on the back panel. Connect the
Kensington Security System cable as shown below.
- For detailed installation and use of the Kensington Security System, refer to the user’s guide provided
PREPARATION
with the Kensington Security System.
For further information, contact http://www.kensington.com, the internet homepage of the Kensington
company. Kensington sells security systems for expensive electronic equipment such as notebook
PCs and LCD projectors.
NOTE
- The Kensington Security System is an optional accessory.
NOTES
a. If the product feels cold to the touch, there may be a small “flicker” when it is turned on.
This is normal, there is nothing wrong with product.
b. Some minute dot defects may be visible on the screen, appearing as tiny red, green, or blue spots.
However, they have no adverse effect on the monitor’s performance.
c. Avoid touching the LCD screen or holding your finger(s) against it for long periods of time.
Doing so may produce some temporary distortion effects on the screen.
16
EXTERNAL EQUIPMENT SETUP
■ To prevent damage do not connect to the mains outlet until all connections are made between the devices.
ANTENNA CONNECTION
■ For optimum picture quality, adjust antenna direction.
■ An antenna cable and converter are not supplied.
Multi-family Dwellings / Apartments
Wall
Antenna
Socket
(Connect to wall antenna socket)
EXTERNAL EQUIPMENT SETUP
RF Coaxial Wire (75 Ω)
Outdoor
Antenna
Antenna
■ In poor signal areas, to get better picture quality, install a signal amplifier to the antenna as shown above.
■ If signal needs to be split for two sets, use an antenna signal splitter for connection.
Single-family Dwellings / Houses
(Connect to wall jack for outdoor antenna)
UHF
Signal
Amplifier
VHF
17
EXTERNAL EQUIPMENT SETUP
■ To avoid damaging any equipment, never plug in any power cords until you have finished connecting all equipment.
■ The image shown may be somewhat different from your set.
HD RECEIVER SETUP
Connecting with a component cable
Connect the video outputs (Y, PB, PR) of the digital
EXTERNAL EQUIPMENT SETUP
1
set-top box to the COMPONENT IN VIDEO jacks on
the SET.
Connect the audio output of the digital set-top box
2
to the COMPONENT IN AUDIO jacks on the SET.
Turn on the digital set-top box.
3
(Refer to the owner’s manual for the digital set-top
box.)
Select COMPONENT input source using the INPUT
4
button on the remote control
► HDMI Audio Supported format : Dolby Digital, PCM
► DTS Audio format is not supported.
Signal Component HDMI
480i / 576i YES No
480p / 576p YES YES
720p / 1080i YES YES
1080p
(50 Hz / 60Hz only)
YES
(24 Hz / 30 Hz / 50Hz / 60Hz)
YES
1
2
18
Connecting a set-top box with a HDMI cable
Connect the digital set-top box to HDMI/DVI IN jack
1
on the SET
Turn on the digital set-top box.
2
(Refer to the owner’s manual for the digital set-top box.)
Select HDMI input source using the INPUT button on
3
the remote control.
EXTERNAL EQUIPMENT SETUP
1
NOTE
!
►Check that your HDMI cable is High Speed HDMI Cable. If the HDMI cables are not High Speed
HDMI Cable, flickering or no screen display can result. Please use the High Speed HDMI Cable.
19
EXTERNAL EQUIPMENT SETUP
Connecting with an HDMI to DVI cable
Connect the digital set-top box to HDMI/DVI IN jack on the SET.
1
Connect the audio output of the digital set-top box to the AUDIO IN (RGB/DVI) jack on the SET.
EXTERNAL EQUIPMENT SETUP
2
Turn on the digital set-top box.
3
(Refer to the owner’s manual for the digital set-top box.)
Select HDMI input source using the INPUT button on the remote control.
4
2
1
20
DVD SETUP
Connecting with a component cable
Connect the video outputs (Y, PB, PR) of the DVD
1
to the COMPONENT IN VIDEO jacks on the SET.
Connect the audio outputs of the DVD to the
2
COMPONENT IN AUDIO jacks on the SET.
Turn on the DVD player, insert a DVD.
3
Select Component input source using the INPUT
4
button on the remote control.
Refer to the DVD player's manual for operating
5
instructions.
EXTERNAL EQUIPMENT SETUP
1
2
Component Input ports
To achieve better picture quality, connect a DVD player to the component input ports as shown below.
Component ports on the SET Y P
Y P
Video output ports
on DVD player
Y B-Y R-Y
Y Cb Cr
Y Pb Pr
B
B
P
R
P
R
21
EXTERNAL EQUIPMENT SETUP
Connecting with a Euro Scart cable
Connect the Euro scart socket of the DVD to the AV
1
IN Euro scart socket on the SET.
EXTERNAL EQUIPMENT SETUP
2
Turn on the DVD player, insert a DVD.
Select AV input source using the INPUT button on the
3
remote control.
Refer to the DVD player's manual for operating
4
instructions.
Scart
AV O O O Analogue TV, Digital TV
Current input mode
Video Audio RGB Video, Audio
Digital TV Digital TV O
Input Output
Output Type
AV
(TV Out)
AV
(When DTV scheduled recoring is in
progress using recording equipment)
► TV Out : Outputs Analogue TV
or Digital TV signals.
22
Analogue TV, AV Analogue TV
Component / RGB Analogue TV
HDMI X
NOTE
!
►Signal type RGB, i.e. the signals red, green and blue can only be selected for the Euro scart and the
AV can be received. These signals are transmitted, for example, by a paid TV decoder, game
machine or photo CD unit, etc.
►Please use shielded scart cable.
(The input mode is converted
O
to DTV)
Connecting the HDMI cable
Connect the HDMI output of the DVD to the HDMI/DVI
1
IN jack on the SET
Select HDMI input source using the INPUT button on
2
the remote control.
EXTERNAL EQUIPMENT SETUP
Refer to the DVD player's manual for operating
3
instructions.
1
NOTE
!
►Check that your HDMI cable is High Speed HDMI Cable. If the HDMI cables are not High Speed
HDMI Cable, flickering or no screen display can result. Please use the High Speed HDMI Cable.
23
EXTERNAL EQUIPMENT SETUP
VCR SETUP
■ To avoid picture noise (interference), allow adequate distance between the VCR and SET.
Connecting with a RF cable
1
EXTERNAL EQUIPMENT SETUP
2
Connect the ANT OUT socket of the VCR to the ANTENNA / CABLE IN socket on the SET.
1
Connect the antenna cable to the ANT IN socket of the VCR.
2
Press the PLAY button on the VCR and match the appropriate channel between the SET and VCR
3
for viewing.
Wall Jack
Antenna
24
Connecting with a Euro Scart cable
Connect the Euro scart socket of the VCR to the AV
1
IN Euro scart socket on the SET.
Insert a video tape into the VCR and press PLAY on
2
the VCR. (Refer to the VCR owner’s manual.)
Select AV input source using the INPUT button on the
3
remote control.
Refer to the VCR player's manual for operating
4
instructions.
Scart
AV O O O Analogue TV, Digital TV
Current input mode
Video Audio RGB Video, Audio
Digital TV Digital TV O
Input Output
Output Type
AV
(TV Out)
AV
(When DTV scheduled recoring is in
progress using recording equipment)
EXTERNAL EQUIPMENT SETUP
1
► TV Out : Outputs Analogue TV
or Digital TV signals.
Analogue TV, AV Analogue TV
Component / RGB Analogue TV
HDMI X
NOTE
!
(The input mode is converted
O
to DTV)
►Signal type RGB, i.e. the signals red, green and blue can only be selected for the Euro scart and the
AV can be received. These signals are transmitted, for example, by a paid TV decoder, game
machine or photo CD unit, etc.
►Please use shielded scart cable.
25
EXTERNAL EQUIPMENT SETUP
INSERTION OF CI MODULE
- To view the encrypted (pay) services in digital TV mode.
- This feature is not available in all countries.
Insert the CI Module to PCMCIA (Personal Computer Memory Card International Association)
1
CARD SLOT of SET as shown.
EXTERNAL EQUIPMENT SETUP
For further information, see p.57
26
HDMI/DVI IN
NOTE
!
►Check if the CI module is inserted into the PCMCIA card slot in the right direction. If the module is
not inserted properly, this can cause damage to the SET and the PCMCIA card slot.
DIGITAL AUDIO OUT SETUP
Sending the TV’s audio signal to external audio equipment via the Digital Audio Output (Optical) port.
If you want to enjoy digital broadcasting through 5.1-channel speakers, connect the OPTICAL DIGITAL AUDIO OUT
terminal on the back of TV to a Home Theater (or amp).
Connect one end of an optical cable to the TV Digital Audio (Optical) Output port.
1
Connect the other end of the optical cable to the digital audio (Optical) input on the audio equipment.
2
Set the “TV Speaker option - Off ” in the AUDIO menu. (► P. 88)
3
Refer to the external audio equipment instruction manual for operation.
EXTERNAL EQUIPMENT SETUP
1
2
CAUTION
►Do not look into the optical output port. Looking at the laser beam may damage your vision.
27
EXTERNAL EQUIPMENT SETUP
USB SETUP
Connect the USB device to the USB IN jacks on the side of SET.
1
After connecting the USB IN jacks, you use the USB function. (► p.109)
2
EXTERNAL EQUIPMENT SETUP
Memory Stick USB Cable
28
HEADPHONE SETUP
You can listen the sound through the headphone.
Plug the headphone into the headphone socket.
1
To adjust the headphone volume, press the + or - button. If you press the MUTE button, the
2
sound from the headphone is switched off.
EXTERNAL EQUIPMENT SETUP
NOTE
!
► AUDIO menu items are disabled when connecting a headphone.
► Optical Digital Audio Out is not available when connecting a headphone.
29
EXTERNAL EQUIPMENT SETUP
PC SETUP
When using the remote control, aim it at the remote control sensor on the SET.
When connecting with a D-sub 15 pin cable
Connect the signal cable from the monitor output socket
1
EXTERNAL EQUIPMENT SETUP
of the PERSONAL COMPUTER to the PC input socket
of the SET.
Connect the audio cable from the PC to the AUDIO IN
2
(RGB/DVI) sockets of the SET.
Press the INPUT button to select RGB.
3
4
Switch on the PC, and the PC screen appears on the set.
The set can be operated as a PC monitor.
NOTE
!
►Connect the signal input cable and tighten it up by turning in
the direction of the arrow as shown in the figure.
1 2
30
Loading...
