Micro Hi-Fi System
OWNER’S MANUAL
MODELS: LX-M145A/X/D
LXS-M145
Please read this manual carefully before operating
your set.
Retain it for future reference.
Designs and specifications are subject to change
without notice for improvement.
The working life of this product is 7 years
since the date of purchase.
MOSCOW_LX-M140(Eng)_42U
CD-R/RW
Precautions
2
Explanation Graphical Symbols:
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance(servicing) instructions in the literature
accompanying the appliance.
WARNING
TO REDUCE THE RISK OF FIRE OF ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
To avoid electrical shock, do not open the cabinet,
Refer servicing to qualified personnel only.
The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
Warning:
Do not install this equipment in a confined space such
a book case or similar unit.
This label is located on the interior.
This Compact Disc player is classified as a CLASS 1
LASER product.
The CLASS 1 LASER PRODUCT label is located on
the exterior.
CAUTION
Use of controls or adjustments or performance of procedures other than those specified herein may result
in hazardous radiation exposure.
Laser component in this product is capable of emitting radiation exceeding the limit for Class 1.
CAUTION:INVISIBLE LASER RADIATION WHEN
OPEN AND INTERLOCKS DEFEATED. AVOID
EXPOSURE TO BEAM.
VARNING:OSYNLIG LASERSTRÅLNING NÄR
DENNA DEL ÄR ÖPPNAD STRÅLEN ÄR FARLIG.
Attention:Quand l'appareil est ouvert, ne pas
s'exposer aux radiations invisibles du faisceau laser.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
CLASSE 1 PRODUIT LASER
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CAUTION
CAUTION:TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER(OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
Table of Contents
INTRODUCTION
3
INTRODUCTION
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . 3
Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Precautions. . . . . . . . . . . . . . . . . . . . . 4
Notes on Discs. . . . . . . . . . . . . . . . . . . . . . . . 4
Notes on Remote Control . . . . . . . . . . . . . . . 4
Notes on Tapes . . . . . . . . . . . . . . . . . . . . . . . 4
Adjusting the voltage (OPTIONAL). . . . . . . . . . 4
Front Panel/Rear Panel . . . . . . . . . . . . . . . . . . 5
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . 6
Display Window. . . . . . . . . . . . . . . . . . . . . . . . . 6
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Speaker System Connection . . . . . . . . . . . . . 7
Antenna (Aerial) Connections . . . . . . . . . . . . 7
BEFORE OPERATION
Setting the CLOCK . . . . . . . . . . . . . . . . . . . . . . 8
Sleep Function . . . . . . . . . . . . . . . . . . . . . . . . . 8
Auxiliary Function. . . . . . . . . . . . . . . . . . . . . . . 8
Timer Function . . . . . . . . . . . . . . . . . . . . . . . . . 9
Audio Adjustment . . . . . . . . . . . . . . . . . . . . . . . 9
Volume Adjustment . . . . . . . . . . . . . . . . . . . . 9
XDSS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
MUTE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Sound Quality Adjustment . . . . . . . . . . . . . . . 9
RDS Function - OPTIONAL . . . . . . . . . . . . . . . 10
OPERATION
Presetting the radio stations . . . . . . . . . . . . . 11
Listening to the radio . . . . . . . . . . . . . . . . . . . 11
Tape Playback . . . . . . . . . . . . . . . . . . . . . . . . . 12
Basic Playback. . . . . . . . . . . . . . . . . . . . . . . 12
To Stop Play. . . . . . . . . . . . . . . . . . . . . . . . . 12
To Pause Play . . . . . . . . . . . . . . . . . . . . . . . 12
To Play Fast Rewind or Fast Forward . . . . . 12
Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Basic Setting . . . . . . . . . . . . . . . . . . . . . . . . 12
Recording from Radio, CD or Auxiliary
source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
CD to Tape Synchronized Recording. . . . . . 12
CD Playback . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Basic Playback. . . . . . . . . . . . . . . . . . . . . . . 13
To Pause Play . . . . . . . . . . . . . . . . . . . . . . . 13
To Stop Play. . . . . . . . . . . . . . . . . . . . . . . . . 13
To Skipping the Track . . . . . . . . . . . . . . . . . 13
To Play Fast Rewind or Fast Forward . . . . . 13
To Repeat Play. . . . . . . . . . . . . . . . . . . . . . . 13
To check MP3 file information . . . . . . . . . . . 13
To Program Play . . . . . . . . . . . . . . . . . . . . . 14
About MP3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
REFERENCE
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 15
Specifications
About the symbols for instructions
Indicates hazards likely to cause harm to the
unit itself or other material damage.
Indicates special operating features of this
unit.
Indicates tips and hints for making the task
easier.
Before Use
4
Safety Precautions
Handling the unit
When shipping the unit
The original shipping carton and packing materials
come in handy. For maximum protection, re-pack the
unit as it was originally packed at the factory.
To keep the surface clean
Do not use volatile liquids, such as insecticide spray,
near the unit. Do not leave rubber or plastic products in
contact with the unit for a long period of time. They will
leave marks on the surface.
Cleaning the unit
To clean the cabinet
Use a soft, dry cloth. If the surfaces are extremely dirty,
use a soft cloth lightly moistened with a mild detergent
solution. Do not use strong solvents, such as alcohol,
benzine, or thinner, as these might damage the surface
of the unit.
Notes on Discs
Handling discs
Do not touch the playback side of the disc.
Hold the disc by the edges so that fingerprints will not
get on the surface.
Do not stick paper or tape on the disc.
Storing discs
After playing, store the disc in its case.
Do not expose the disc to direct sunlight or sources
of heat, or leave it in a parked car exposed to direct
sunlight, as there may be a considerable temperature
increase inside the car.
Cleaning discs
Fingerprints and dust on the disc can cause poor
picture quality and sound distortion. Before playing,
clean the disc with a clean cloth. Wipe the disc from
the center out.
Do not use strong solvents such as alcohol, benzine,
thinner, commercially available cleaners, or anti-static
spray intended for analog records.
Notes on Remote Control
Remote Control Operation Range
Point the remote control at the remote sensor and press
the buttons.
• Distance: About 23 ft (7 m) from the front of the
remote sensor.
• Angle: About 30° in each direction of the front
of the remote sensor.
Remote control battery installation
Detach the battery cover on the rear
of the remote control, and insert two
R03 (size AAA) batteries with
and aligned correctly.
Caution
Do not mix old and new batteries.
Never mix different types of batteries (standard,
alkaline, etc.).
Notes on Tapes
Preventing overwriting a recording
Removing the safety tab(s) of the cassette (with a small
screwdriver) will prevent accidental erasure.
To record again, cover the hole of the tab with adhesive
tape.
Adjusting the voltage (OPTIONAL)
If your unit is equipped with a voltage selector at the
back side, be sure to set it to your local power supplied
before connecting the AC power cord.
Side A
Tab for side B
Tab for side A
Adhesive tape.
Front Panel/Rear Panel
INTRODUCTION
5
1. CD DOOR
2. DISPLAY
3. POWER indicator
4. POWER (STANDBY/ON) button
5. Remote Control Sensor
6. • CD PLAY/PAUSE (CD/) button
• TUNING ( ) buttons - TUNER
• CD SKIP/SEARCH (
/
) buttons
• PRESET ( ) buttons
7. HEADPHONE SOCKET (PHONES): 3.5mm
8. CASSETTE Holder
9. • RECORD ( ) button - TAPE
• PLAY ( ) button - TAPE
• REWIND ( ) button - TAPE
• FAST FORWARD ( ) button - TAPE
• STOP/EJECT(/) button - TAPE
• PAUSE ( ) button - TAPE
10. • CLOCK button
• TIMER button
• REPEAT button
• PROGRAM/MEMORY button
• ( )STOP/CLEAR button
11. VOLUME CONTROL KNOB
12. • FUNCTION SELECT (FUNCTION) button
(TUNER/ CD/ TAPE /AUX)
• TUNER/BAND button
• RDS (OPTIONAL)/SET button
• MODE/RIF button
13. EQUALIZER PATTERN (EQ) button
14. XDSS button
15. CD OPEN/CLOSE ( OPEN/CLOSE) button
16. VOLTAGE SELECT SWITCH : OPTIONAL
17. POWER CORD
18. SPEAKER TERMINAL
19. AUXILIARY INPUT SOCKET (AUX)
20. ANTENNA TERMINAL
R
L
OPTIONAL
1
15
14
13
12
11
9
8
7
4
3
2
5
10
20
19
18
17
16
6
6
Remote Control
1. POWER button
2. PRESET ( ) button
3. CD FUNCTION buttons
• CD PLAY/ PAUSE ( ) button
• CD STOP( ) button
• CD SKIP/SEARCH (
/
) buttons
• REPEAT button
4. • EQUALIZER PATTERN (EQ PATT.) button
• XDSS button
5. NUMBER buttons
6. MP3 file information display (MP3 Info) button
7. PROGRAM button
8. SLEEP button
9. VOLUME CONTROL ( ) button
10. MUTE button
11.• TUNER/BAND button
• AUX button
/
/
1. PLAY/ PAUSE indicator
2. FUNCTION indicators
3. MP3 indicator
4. CD REPEAT indicator
5. • PROGRAM indicator
• RECORD/ RECORD PAUSE indicator
6. CD SYNCHRO RECORDING indicator
7. RDS indicator : OPTIONAL
8. MEMORY indicator
9. TIMER indicator
10. SLEEP indicator
11. MUTE indicator
12. XDSS indicator
13. • FM STEREO indicator
• FM STEREO RECEIVING indicator
Display Window
11
10
9
8
7
6
5
4
3
2
1
1
3
4
5
6
8
9
10
11
12
13
7
2
Connections
INTRODUCTION
7
Speaker System Connection
Connect the speaker cords to the speaker terminals.
R
L
otes
• Be sure to match the speaker cord to the appropriate terminal on the components: + to + and – to –.
If the cords are reversed, the sound will be distorted and will lack base.
• If you use front speakers with low maximum input rating, adjust the volume carefully to avoid excessive output on
the speakers.
• Do not disassemble the front cover of supplied speaker.
otes
•To prevent noise pickup, keep the AM loop antenna away from the unit and other components.
• Be sure to fully extend the FM wire antenna.
• After connecting the FM wire antenna, keep it as horizontal as possible.
Antenna (Aerial) Connections
Connect the supplied FM/AM antennas for listening to the radio.
AM (MW) loop
antenna (aerial)
(Supplied)
FM wire antenna
(supplied)
AM
FM 75
AM
FM
75 ohms
AM loop antenna (aerial)
(Supplied)
FM external
antenna (aerial)
(not supplied)
FM indoor antenna (aerial)
Position it for
the best reception
coaxial
cable
FM external
antenna (aerial)
(not supplied)
For AM (MW) reception, connect
the loop antenna (aerial) to the
terminal marked AM
8
11
Press CLOCK.
(If the clock requires setting, press and hold
CLOCK for more than 2 seconds.)
- The hours begin to flash.
22
Select a 12 hour cycle or 24 hour cycle by
pressing TUNING
()
on the front panel.
33
Press SET to confirm the selected hour cycle.
44
Use TUNING
()
buttons to set the
correct hours on the front panel.
55
Press SET.
66
Use TUNING
()
buttons to set the
correct minutes on the front panel.
77
Press SET and the correct time is shown on
the display.
88
Press CLOCK at any time to display the time
for about 3 seconds.
ote
The unit can also set the clock function in power off
state.
(12HR)
(24HR)
or
Sleep Function
When the sleep timer is used, the power is automatically turned off after the specified time has elapsed.
11
To specify the time delay before the power is
turned off, press SLEEP.
In the display window you can see
for about 5 seconds. This means that the system
turns off automatically after 90 minutes.
Each time the button is pressed the time interval
before it turns off is reduced by 10 minutes. i.e.
80...70... etc.
Select the desired time to turn off.
22
To check the remaining time until the power is
turned off.
While the sleep function is active press SLEEP
briefly. The time remaining until it turns off is
displayed for about 5 seconds.
ote
If you press SLEEP while the sleep time is displayed,
the SLEEP time is reset.
To cancel the sleep timer mode
If you wish to stop the function, press the SLEEP button
repeatedly until “SLEEP 10” appears, and then press
SLEEP once again while “SLEEP 10” is displayed.
Setting the CLOCK
Auxiliary Function
11
Connect an auxiliary device i.e. TV or VCR, via the rear mounted AUX phone sockets.
22
Press AUX.
ote
You can also record from the auxiliary input source, see Recording Section.
Timer Function
BEFORE OPERATION
9
With the TIMER function you can have the radio reception and recording, CD play, auxiliary source play and recording turned on and off at the time desired.
11
Press CLOCK to check the current time.
For your reference
If you don’t set clock, timer function doesn’t work.
22
Press TIMER to enter the timer setting mode.
TUNER-CD flashes in the display window in turn.
For your reference
If you want to correct the previous memorized TIMER
setting, press and hold the TIMER button more than 2
seconds.
- The previous memorized timer on time and “TIMER”
indicators appear in the display.
33
Press SET when the desired function is
flashing.
44
When you select the TUNER or CD function.
- “ON TIME” indicator appears for about 0.5
seconds in the display window and then
disappears.
55
Set the hour to switch on by pressing
TUNING
()
buttons on the front panel.
66
Press SET to confirm the hour to switch on.
77
Set the minute to switch on by pressing
TUNING
()
buttons on the front panel.
88
Press SET to confirm the minute to switch on.
“OFF TIME” indicator appears for about 0.5 seconds
in the display window and then disappears .
99
Set the hour to switch off by pressing
TUNING
()buttons on the front panel.
1100
Press SET to confirm the hour to switch off.
1111
Set the minute to switch off by pressing
TUNING
()
buttons on the front panel.
1122
Press SET.
1133
Adjust the volume level by pressing
TUNING
()
buttons on the front panel.
1144
Press SET.
“TIMER” appears in the display window and the
timer setting has been completed.
1155
Switch the system off.
The selected function is automatically switched
on and off at the time set.
To cancel or check the timer
Each time the TIMER button is pressed you can select
the timer set or cancel. You can also check the timer
setting status.
To activate or check the timer, press the TIMER
button so that “TIMER” appears in the display window.
To cancel the TIMER, press the TIMER button so that
“TIMER” disappears in the display window.
ote
The unit can also set the clock function in power off
state.
Audio Adjustment
Volume Adjustment
• Press VOLUME CONTROL KNOB clockwise to
increase the sound level, or counterclockwise to
decrease it on the front panel.
• Press VOLUME CONTROL ( ) to increase the
sound level, or press the VOLUME CONTROL ( ) to
decrease it on the remote control.
XDSS (Extreme Dynamic Sound System)
Press XDSS to reinforce treble, bass and the
surround effect. The “XDSS ON” or “XDSS OFF” indicator lights. To cancel, press XDSS again.
MUTE
Press MUTE to mute your unit.
You can mute your unit in order, for example, to answer
the telephone, “MUTE” indicator flashes in the display
window.
Sound Quality Adjustment
•To activate stereo sound
You can choose between 4 fixed sound impressions.
Select a desired sound mode by using the EQ PATT.
button.
FLAT : linear frequency response
ROCK : more bass, more treble
POP : less bass, less treble
CLASSIC : for orchestral music
• Headphone Socket
Connect a stereo headphone plug ( 3.5mm) into the
headphone jack.
The speakers are automatically disconnected when
you plug in the headphones (not supplied).
10
RDS Function - OPTIONAL
About RDS
This unit is equipped with RDS (Radio Data System),
which brings a wide range of information from FM radio.
RDS is a system for transmitting station call signs or
network information, a description of station programme
type text message about the station or specifics of musical selection and the correct time.
RDS Tuning
When a FM station containg RDS data is tuned in, the
unit will automatically display the station’s call sign and
the RDS indicator will light in the Display Window as
well as indicators for the programme type recognition
(PTY), Radio Text (RT), Clock Time (CT) and RDS services programme (PS) if transmitted by the station.
RDS Display Options
The RDS system is capable of transmitting a wide variety of information in addition to the initial call sign that
appears when a station is first tuned. In normal RDS
operation the display will indicate the station name,
broadcast network or call letters. Pressing RDS on the
front panel enables you to cycle through the various
data types in the sequence:
(PS FREQUENCY PTY RT CT)
• PTY (Programme type recognition)- The programme
type is shown on the display window.
• RT (Radio text recognition)- The radio station’s name
is displayed on the display window.
• CT (Time controlled by the channel)- Enable the unit
to receive the actual time and show it on the display
window.
• PS (Programme Service name)- The programme title
is displayed on the display window.
ote
Some RDS stations may not choose to include some of
these additional features. If the data required for the
selected mode is not being transmitted, the Display
Window will show a PTY NONE, RT NONE, CT NONE,
PS NONE message.
Programme Search (PTY)
A major benefit of RDS is its ability to encode broadcasts with Programme Type (PTY) codes that indicate
the type of material being broadcast. The following list
shows the abbreviations used to indicate each PTY
along with an explanation of the PTY.
You may search for a specific Programme Type (PTY)
by following these steps:
11
Press TUNER/BAND to select FM mode.
22
Select a desired station by pressing
TUNING
()
.
When the RDS transmission is received, the
display shows the program service name (PS) after
RDS indicator appears.
33
Press the RDS to select PTY mode.
44
To search for a different PTY, press the PRESET
()
while the last PTY in use is still displayed
to scroll through the list of available PTY types.
55
When the PTY is selected, press the
/within 5 seconds.
The unit will go into an automatic search mode and
attempt to find the next station with acceptable
signal strength that matches the desired PTY type.
Presetting the radio stations
OPERATION
11
You can preset 50 stations for FM and AM. Before
tuning, make sure that you have turned down the
volume to the minimum.
11
Press TUNER/BAND to select the FM or AM
you want in the display window.
Every time you press TUNER/BAND, FM and AM
changes alternately.
22
Press TUNING ()on the front panel
until the frequency indication starts to change,
then release.
Scanning stops when the unit tunes in a
station.
otes
•
Tuning in automatically
Press TUNING () for more than 0.5 seconds.
•
Tuning in manually
Press TUNING () briefly and repeatedly.
33
Press PROGRAM/MEMORY on the front panel.
A preset number will flash in the display window.
44
Press PRESET () (or PRESET ( )
on the remote control) to select the preset
number you want.
55
Press PROGRAM/MEMORY.
- The station is stored.
66
Repeat steps 3 to 6 to store other stations.
To clear all the memorized stations
Press and hold PROGRAM/MEMORY on the front panel
for about two seconds, “CLEAR” appears in the display
window and then press CLEAR, the stations are
cleared.
For your reference
If all stations have already been entered, FULL message
will appear in the display window for a moment and then
a preset number will flash. To change the preset number,
follow the steps 5-6.
To recall presets
Press and hold PRESET () (or PRESET ( )
on the remote control) until the desired preset number
appears or press it repeatedly.
/
/
11
Press TUNER/BAND to select the FM or AM
you want in the display window.
The last received station is tuned in.
22
Press PRESET () (or PRESET ( )
on the remote control) repeatedly to select the
preset station you want.
- Each time you press the button, the unit tunes in
one preset station at a time.
33
Adjust the volume by pressing VOLUME CONTROL KNOB on the front panel or VOLUME
() on the remote control repeatedly.
To listen to non-preset radio stations
• Use manual or automatic tuning in step 2.
• For automatic tuning, press and hold TUNING
() on the front panel.
To turn off the radio
Press POWER to turn the unit off or select another
function mode (CD, TAPE or AUX).
For your reference
• If an FM program is noisy
Press MODE/RIF so that “
STEREO
” disappears in
the display window. There will be no stereo effect,
but the reception will improve. Press MODE/RIF
again to restore the stereo effect.
• To improve reception
Reposition the supplied antennas.
otes
• Use MODE/RIF (Radio Interference Filter) function to
switch to mono reception if stereo reception is distorted by noise.
• When recording the MW(AM)broadcast, beat noises
may occur. If it does, press MODE/RIF once.
/
/
Listening to the radio
Tape Playback
12
Basic Playback
11
Press FUNCTION repeatedly to appear TAPE
indicator.
22
Open cassette deck by pushing STOP/EJECT
(/) button.
33
Insert a cassette with the tape side to the
bottom and then close deck.
44
Press PLAY ( ).
To Stop Play
Press STOP/EJECT (/) during playback.
To Pause Play
Press PAUSE ( ) during playback.
Press this button again it to resume play.
To Play Fast Rewind or Fast Forward
After pressing REWIND/FAST FORWARD (
/
)
on the front panel during playback or stopping.
AUTO STOP DECK
After auto stop deck plays only front side, the unit stops
automatically.
Basic Setting
11
Select the function (MP3/CD, TUNER/BAND or
AUX) you want to record.
22
Open the cassette deck and insert a blank
cassette into the cassette compartment.
Recording from Radio, CD or Auxiliary
source
11
Press FUNCTION button to select desired
recording source, and then press RECORD
() button.
The recording begins.
For your reference
When you press RECORD ( ) button, PLAY ( )
button is pressed automatically.
22
To pause recording
Press PAUSE ( ) button during recording.
• Press PAUSE ( ) button again to resume
recording.
33
To stop recording
Press STOP/EJECT ( / ).
CD to Tape Synchronized Recording
The CD synchro recording function dubs a complete CD
and programmed titles automatically into a cassette.
11
When you select CD function, press RECORD
() button.
“REC” appears and “ ” displays in the
display window.
22
The synchronized recording is started
automatically after about 8 seconds.
otes
• If you wish to record from the desired track, select the
desired track with CD SKIP/SEARCH (
/
) before commencing CD synchro
recording.
• The function change is not possible during recording.
Wind the tape to the point recording starts. (Use only normal tapes.)
Recording
CD Playback
OPERATION
13
Basic Playback
11
Press FUNCTION repeatedly to appear CD
indicator.
If no disc is loaded then “NO DISC” is displayed.
22
Press CD OPEN/CLOSE ( OPEN/ CLOSE) and
place the disc into the disc tray.
ote
To load an 8cm(3 inch) disc, put it onto the inner circle
of the tray.
33
Press CD OPEN/CLOSE ( OPEN/ CLOSE) to
close the disc compartment.
Audio CD: “READING” appears in the display win-
dow, and then the total number of
tracks and the playing time are
displayed.
MP3 CD: “READING” appears in the
display window, and then the total number of files is displayed.
44
Press CD PLAY/ PAUSE ( ).
To Pause Play
Press CD PLAY/ PAUSE ( ) during playback.
Press this button again it to resume play.
To Stop Play
Press CD STOP ( ) during playback.
To Skipping the Track
• Press the CD SKIP/SEARCH ()button to
go to the next track.
• When the CD SKIP/SEARCH ( ) button is
pressed once midway through a track, the player
returns to the start of that track. When it is
pressed again, a track is skipped each time the
button is pressed.
To Play Fast Rewind or Fast Forward
After pressing CD SKIP/SEARCH (
/
) buttons for more the 2 seconds on the
front panel, then release during playback, press
PLAY ( ) at the point you want.
ote
This function is not available to play a MP3 file.
To Repeat Play
To play one track repeatedly
Press REPEAT once during playback.
- “REPEAT 1” appears in the display.
To play all tracks repeatedly
Press REPEAT again during playback.
- “REPEAT ALL” appears in the display.
To cancel repeat play
Press REPEAT once more during playback.
- “Repeat indicator” disappears.
To check MP3 file information
Press the MP3 Info button during MP3 file
playback.
- The information (Title, Artist or Album) of the MP3 file
will be shown in the display window.
- If there is no information of the MP3 file, “NO ID3
TAG” indicator will be shown in the display window.
- The “MP3 file name” and “ID3 TAG” should be named
using English.
ote
This unit can play a CD-R or CD-RW that
contains audio titles or MP3 files.
CD Playback
14
To Program Play
You can arrange the order of the tracks on the discs and
create your own program. The program can contain up
to 20 tracks.
11
Press PROGRAM/MEMORY (or PROGRAM on
the remote control) on the stop mode.
22
Press CD SKIP/SEARCH (
/
)
buttons to select the track you want.
33
Press PROGRAM/MEMORY (or PROGRAM on
the remote control).
44
Repeat 1~3.
55
Press CD PLAY/ PAUSE ( ).
To check program contents
Press PROGRAM/MEMORY (or PROGRAM on the
remote control) on the stop mode.
-Atrack and program number will be displayed.
To clear program contents
Press PROGRAM/MEMORY (or PROGRAM on the
remote control) on the stop mode. And then press
( )STOP/CLEAR on the front panel or STOP( ) on
the remote control.
To add program contents
1. Press PROGRAM/MEMORY (or PROGRAM on the
remote control) repeatedly on the program stop
mode until “Track Number” blinks.
2. Repeat 2~5.
To modify program contents
1. Press the PROGRAM/MEMORY (or PROGRAM on
the remote control) to display program number you
want to modify.
2. Repeat 2~4.
About MP3
• An MP3 file is audio data compressed by using the
MPEG1 audio layer-3 file-coding scheme. We call files
that have the “.mp3” file extension “MP3 files”.
• The unit can not read an MP3 file that has not “.mp3”
file extension.
MP3 Disc compatibility with this unit is limited as
follows:
1. Sampling Frequency / 8 - 48kHz
2. Bit rate / 8 - 320kbps
3. CD-R physical format should be “ISO 9660”
4. If you record MP3 files using the software which can-
not create a FILE SYSTEM, for example
“Direct-CD” etc., it is impossible to playback MP3
files. We recommend that you use “Easy-CD
Creator”, which creates an ISO9660 file system.
5. File names should be named using 30 letters or less
and must incorporate “.mp3” extension
e.g. “********.MP3”.
6. Do not use special letters such as “/ : * ? “ < > ” etc.
7. Even if the total number of files on the disc have
more than 1000, it will only be shown up to 999.
About MULTI SESSION
- This function recognizes the multi session disc according
to a disc of CD-ROM type.
ex) If there are MP3 files in the first session, the MP3
file in the first session is only played.
If there are only MP3 files in the whole session, all
of the MP3 files in the session are played.
If there is Audio CD in the first session, only the
Audio CD in the first session is played.
REFERENCE
15
Troubleshooting
Check the following guide for the possible cause of a problem before contacting service.
Symptom
No power.
No sound.
The unit does not start
playback.
The remote control
does not work properly.
Cause
• The power cord is disconnected.
• The audio cables are not
connected securely.
• The power of the external source equipment is switched off.
• No disc or tape is inserted.
• An unplayable disc or tape is inserted.
• The disc is placed upside down.
• The disc is not placed within the guide.
• The disc is dirty.
• The remote control is not pointed at the
remote sensor of the unit.
• The remote control is too far from the
unit.
• There is an obstacle in the path of the
remote control and the unit.
• The batteries in the remote
control are exhausted.
Correction
• Plug the power cord into the wall outlet
securely.
• Connect the audio cable into the jacks
securely.
• Switch on the external source equipment.
• Insert a disc or tape.
• Insert a playable disc or tape.
• Place the disc with the playback side
down.
• Place the disc on the disc tray correctly
inside the guide.
• Clean the disc.
• Point the remote control at the remote
sensor of the unit.
• Operate the remote control within about
23 ft (7 m).
• Remove the obstacle.
• Replace the batteries with new ones.
Specifications
[General][CD]
[Tuner]
AM
FM
(MW)
[Amp]
[Speakers]
[
TAPE
]
Power supply Refer to the back panel of the unit.
Power consumption 20W
Mass 3kg
External dimensions (WxHxD) 146 X 234 X 251mm
Frequency response 40 - 18000 Hz
Signal-to-noise ratio 60 dB
Dynamic range 60 dB
Tuning Range 87.5 - 108.0 MHz or 65 - 74 MHz, 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
Signal to Noise Ratio 55/50 dB
Frequency Response 60 - 10000 Hz
Tuning Range 522 - 1611 kHz or 530 - 1610 kHz
Intermediate Frequency 450 kHz
Signal to Noise Ratio 35 dB
Frequency Response 100 - 1800 Hz
Output Power 5W + 5W
T.H.D 0.5%
Frequency Response 60 - 20000 Hz
Signal-to-noise ratio 60 dB
Tape Speed 4.75cm/sec
Wow Flutter 0.25% (MTT -111, JIS-WTD)
F.F/REW Time 120sec (C-60)
Frequency Response 250 - 8000Hz
Signal to Noise Ratio 43dB
Channel Separation 50dB(P/B)/45dB(R/P)
Erase Ratio 55dB (MTT-5511)
Type 1 Way 1 Speaker
Impedance 4 Ω
Frequency Response 100 - 18000 Hz
Sound Pressure Level 88 dB/W (1m)
Rated Input Power 5W
Max. Input Power 10W
Net Dimensions (WxHxD) 146 x 234 x 182mm
Net Weight (1EA) 1.4kg
Designs and specifications are subject to change without notice.
P/NO :3834RH0042U
Loading...
