LG LP1213GXR/00 Owner’s Manual

OWNER’S MANUAL

AIR CONDITIONER

Please read this manual carefully before operating
your air conditioner and retain it for future reference.

TYPE PORATBLE AIR CONDITIONER
MODELS LP1213GXR

www.lgappliances.com

INTRODUCTION

IMPORTANT SAFETY INSTRUCTIONS

Basic Safety Precautions . . . . . . . . . . . . . . . . . . 3 - 4

Electrical Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

PARTS AND FEATURES

Key Parts and Components . . . . . . . . . . . . . . . . . . . 8

Control Panel and Remote . . . . . . . . . . . . . . . . . . . . 9

HOW TO USE

Before Using Your Air Conditioner
Using the Controls

. . . . . . . . . . . . . . . . . . . . . . . 12–14

. . . . . . . . . . . . 9,10

INSTALLATION INSTRUCTIONS

Preparing for Installation . . . . . . . . . . . . . . . . . . . . . 15

Selection of Installation Location . . . . . . . . . . . . . . . 16

Window Vent Panel and Extensions . . . . . . . . . . . . 17

Installation in Vertical Sliding Windows. . . . . . . 18, 19

Installation in Casement Style Windows . . . . . 20, 21

CARE AND CLEANING

Cleaning the Case. . . . . . . . . . . . . . . . . . . . . . . . . . 22

Cleaning the Air Filter . . . . . . . . . . . . . . . . . . . . . . . 22

Emptying the Water Collection Tank . . . . . . . . . . . . 23

Storing the Air Conditioner

.. . . . . . .

.. . . . . . . . . . . 24

THANK YOU!

Congratulations on your purchase
and welcome to the LG family.
Your new LG Air Conditioner
combines high-efficiency operation
with portable convenience.
If you follow the operating and care
instructions in this manual, your
air conditioner will provide you with
many years of reliable service.

TROUBLESHOOTING

Before Calling for Service. . . . . . . . . . . . . . . . . 25, 26

WARRANTY

Product Registration Information . . . . . . . . . . . . . 27

2

IMPORTANT SAFETY INSTRUCTIONS

BASIC SAFETY PRECAUTIONS

Do not store flammables like
gasoline benzene thinner
etc. near the air conditioner.

EnglishEnglish

3

IMPORTANT SAFETY INSTRUCTIONS

Unplug the unit when not
using it for a long time.

Wax

Thinner

4

IMPORTANT SAFETY INSTRUCTIONS

Hold the plug by the head

（not the cable）when taking

it out.

For inner cleaning, contact an Authorized Service Center or a dealer.

Do not use harsh detergent that causes corrosion or damage on the unit.

Harsh detergent may also cause failure of prod

Do not use this appliance for
special purposes such as
cooling pets
machinery，or objects of art

，

foods，

precision

uct, fire, or electric shock.

When gas leaks, open the
window for ventilation before
operating the unit.

EnglishEnglish

5

IMPORTANT SAFETY INSTRUCTIONS

If the liquid from the battery gets onto your skin
or clothers，

not use the remote if the battery has leaked.

wash it well with clean water. Do

y

ELECTRICAL SAFETY

WARNING

Electrical Shock Hazard

Failure to follow these instructions can result
in death, fire, or electrical shock.

• This unit must be properly grounded.

• Do not, under any circumstances, cut or

remove the ground prong.

• If you do not have a properly grounded
outlet, or if there is any doubt that the outlet
is not properly grounded, a qualified
electrician should check the outlet and
circuit, and, if necessary, install a properly
grounded outlet.

If you eat the liquid from the battery,brush
your teeth and see doctor.Do not use the

remote if the battery has leaked.

y

• This air conditioner must be plugged
into a grounded 60 Hz, 120 VAC outlet
protected by a 15 amp time delay fuse
or circuit breaker.

• This air conditioner must be installed in
accordance with national wiring codes.

• Do not alter or modify the plug or cord
of this air conditioner. If the power cord

becomes worn or damaged, the cord should
only be replaced by a qualified service
technician using genuine replacement parts.

• Do not use an extension cord.

6

IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USE

ELECTRICAL SAFETY

INTEGRATED CIRCUIT BRE AKER

For additional safety,
the powe r cord

Reset
Test

button then the RESET button. If the TEST
button does not cause the circuit breaker to trip,
or if the RESET button will not stay engaged ,
unplug t he air co nditioner immediately and
contact your LG service technician.

Due to potential safety hazards, the use of
an adapter plug is strongly discouraged.

For temporary connections, use only a
UL-listed adapter. Ensure that the large slot
in the adapter is aligned with the large slot
in the outlet.

features an integrated
circuit breaker. Test
and reset buttons are
provided on the plug
case.

The circuit breaker
should b e tested
periodical ly by
pressing the TEST

PREFERRED
GROUNDING METHOD

Ensure proper
ground exists
before use.

English

TEMPORARY GROUNDING
METHOD

To prevent damage to the adapter’s ground
terminal, hold the adapter in place while
plugging in or unplugging the air conditioner.

• Attaching the adapter ground terminal to
the wall receptacle cover screw does not
ground the appliance unless the cover
screw is metal and not insulated, and the
wall receptacle is grounded through the
house wiring.

SAVE THESE INSTRUCTIONS

Ensure proper
ground exists
before use.

• Frequent connection and disconnection
can damage the ground terminal on the
adapter. Never use a broken or damaged
adapter.

7

PARTS AND FEATURES

KEY PARTS AND COMPONENTS

1

CONTROL PANEL AND DISPLAY

Easy-to-read white LED display shows the
operating state. Digital touch buttons (simple push
buttons) make changing settings quick and easy.

MOTORIZED AIR DISCHARGE

2

The adjustable louvered air discharge opens
automatically when the air conditioner is turned
on, and closes when it is turned off. It can also
be set to oscillate to distribute air more evenly
through the room.

3

INFRARED REMOTE CONTROL

Th

e LCD
temperature and operate most functions of the
air conditioner from across the room.

HOSE AND DIFFUSER

4

Use the diffuser and hose to connect the air
conditioner to the window installation kit to vent
exhaust air outside.

remote control allows you to adjust the

1

2

FILTER

5

You can pull out and insert the filter easily.

HANDLES

6

The handles provide a convenient grip
when lifting the air conditioner.

SWIVELING CASTERS

7

Swiveling casters allow you to move the air
conditioner easily on most floor surfaces.

BOTTOM DRAIN PORT

8

Before moving the air conditioner, drain the
internal water in collection tank completely
using bottom drain port.

9

POWER SUPPLY CORD HOLDER

Wrap the power supply cord around the holders
for your convenience.

3

5

4

6

9

7

8
