User Guide

8/27/10

LG RUMOR TOUCH

www.sprint.com

Consejo: Para encontrar esta guía para usuarios en español,

por favor visita a

Support > Phones & Devices.

To find this user guide in Spanish, please visit

www.sprint.com and click

Devices

Important Privacy Message

apply to third-party applications. Third-party applications may access your personal information or require Sprint to disclose your customer information to the third-party application provider. To find out how a third-party application will collect, access, use, or disclose your personal information, check the application provider’s policies, which can usually be found on their website. If you aren’t comfortable with the third-party application’s policies, don’t use the application.

Sprint UG_9a_070709

www.sprint.com y haz clic en

Support > Phones &

– Sprint’s policies often do not

Table of Contents

Tip:

Looking for something? If you don’t see it in the headings listed here, try the Index on page 142.

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

Your Phone’s Menu . . . . . . . . . . . . . . . . . . . . . . . . i

Section 1: Getting Started . . . . . . . . . . . . . . . . . 1

1A. Setting Up Service . . . . . . . . . . . . . . . . . . . 2

Setting Up Your Phone . . . . . . . . . . . . . . . . . . . . . . 2

Activating Your Phone . . . . . . . . . . . . . . . . . . . . . . . 3

Setting Up Your Voicemail . .

Sprint Account Passwords . . . . . . . . . . . . . . . . . . . 4

Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Section 2: Your Phone . . . . . . . . . . . . . . . . . . . . 7

2A. Phone Basics . . . . . . . . . . . . . . . . . . . . . . . . 8

Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Viewing the Display Screen . . . . . . . . . . . . . . . . . 12

Getting to Know the Touch Screen

Turning Your Phone On and Off . . . . . . . . . . . . . 16

Calibrating the Touch Screen . . . . . . . . . . . . . . . 17

. . . . . . . . . . . . . . . . . 3

. . . . . . . . . . . 16

Battery and Charger . . . . . . . . . . . . . . . . . . . . . . . 17

Navigating Through the Menus . . . . . . . . . . . . . 19

Displaying Your Phone Number . . . . . . . . . . . . . 20

Making and Answering Calls . . . . . . . . . . . . . . . 21

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

2B. Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Text Entry Settings . . . . . . . . . . . . . . . . . . . . . . . . . 39

Location Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Messaging Settings . . . . . . . . . . . . . . . . . . . . . . . 40

Airplane Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

TTY Use With Sprint Service . . . . . . . . . . . . . . . . 42

Phone Setup Options . . . . . . . . . . . . . . . . . . . . . . 43

Security Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 44

2C. History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Viewing History . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

History Options . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Making a Call From History . . . . . . . . . . . . . . . . . 50

Saving a Number From History . . . . . . . . . . . . . 50

Prepending a Number From History . . . . . . . . . 51

Erasing History . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

2D. Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Adding a New Contacts Entry . . . . . . . . . . . . . . . 52

Saving a Phone Number . . . . . . . . . . . . . . . . . . 53

Contacts Entry Options . . . . . . . . . . . . . . . . . . . . 53

Editing a Contacts Entry . . . . . . . . . . . . . . . . . . . 54

Adding a Number to a Contacts Entry . . . . . . . 54

Editing a Contacts Entry’s Number

Assigning Speed Dial Numbers . . . . . . . . . . . . 55

Selecting a Ringer Type for an Entry . . . . . . . . 56

Assigning a Picture to an Entry . . . . . . . . . . . . . . 57

Creating a Group . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Finding Contacts Entries . . . . . . . . . . . . . . . . . . . 58

Secret Contacts Entries . . . . . . . . . . . . . . . . . . . . 58

Dialing Sprint Services . . . . . . . . . . . . . . . . . . . . 59

Wireless Backup . . . . . . . . . . . . . . .

Hello UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

s . . . . . . . . . 55

. . . . . . . . . . . 60

2E. Calendar & Tools . . . . . . . . . . . . . . . . . . . . 64

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

File Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Alarm Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Document Viewer . . . . . . . . .

EZ Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

World Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Unit Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Updating Phone Software

Updating the PRL . . . . . . . . . . . . . . . . . . . . . . . . . . 72

. . . . . . . . . . . . . . . . 70

. . . . . . . . . . . . . . . . . . 72

2F. Voice Services . . . . . . . . . . . . . . . . . . . . . . 73

Automatic Speech Recognition (ASR) . . . . . . . . 73

Managing Voice Memos . . . . . . . . . . . . . . . . . . . 75

2G. microSD Card . . . . . . . . . . . . . . . . . . . . . . 77

Your Phone’s microSD Card and Adapter . . . . 77

microSD Card Settings . . . . . . . . . . . . . . . . . . . . . 79

microSD Card Folders . . . . . . . . . . . . . . . . . . . . . 80

Connecting Your Phone to Your Computer . . . 80

2H. Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Taking Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Recording Videos . . . . . . . . . . . . . . . . . . . . . . . . . 85

Storing Pictures and Videos . . . . . . . . . . . . . . . . 87

Sending Sprint Picture Mail . . . . . . . . . . . . . . . . . 89

Printing Pictures From Your Phone . . . . . . . . . . . 91

2I. Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Turning Bluetooth On and Off . . . . . . . . . . . . . . . 94

Bluetooth Settings . . . . . . . . . . . . . . . . . . . . . . . . . 95

Pairing Bluetooth Devices . . . . . . . . . . . . . . . . . . 95

Sending Items via Bluetooth . . . . . . . . . . . . . . . . 96

Section 3: Sprint Service . . . . . . . . . . . . . . . . . 97

3A. Sprint Service: The Basics . . . . . . . . . . . 98

Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Messaging (SMS/MMS) . . . . . . . . . . . . . . . . . . . 100

Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Making a 3-Way Call . . . . . . . . . . . . . . . . . . . . . . 103

Call Forwarding . . . . . . . . . . . . . .

Roaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

. . . . . . . . . . . . 104

3B. Web and Data Services . . . . . . . . . . . . . 108

Getting Started With Data Services . . . . . . . . . 108

Accessing Messages . . . . . . . . . . . . . . . . . . . . . 112

Downloading Games, Ringers, and More . . . . 114

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Browser Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Data Services FAQs . . . . . . . . . . .

. . . . . . . . . . . 118

3C. Entertainment: TV and Music . . . . . . . . 120

TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Music – Sprint Music Store . . . . . . . . . . . . . . . . 123

Streaming Music . . . . . . . . . . . . . . . . . . . . . . . . . 127

3D. GPS Navigation . . . . . . . . . . . . . . . . . . . . 128

GPS Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Sprint Navigation . . . . . . . . . . . . . . . . . . . . . . . . . 128

Sprint Family Locat

or . . . . . . . . . . . . . . . . . . . . . 129

Section 4: Safety and

Warranty Information . . . . . . . . . . . . . . . . . . . . 131

4A. Important Safety Information . . . . . . . . 132

General Precautions . . . . . . . . . . . . . . . . . . . . . . 132

Maintaining Safe Use of and

Access to Your Phone . . . . . . . . . . . . . . . . . . . . 133

Using Your Phone With a Hearing Aid Device 134

Caring for the Battery . . . . . . . . . . . . . . . . . . . . . 136

Radio Fr

equency (RF) Energy . . . . . . . . . . . . . 136

Owner’s Record . . . . . . . . . . . . . . . . . . . . . . . . . . 138

4B. Manufacturer’s Warranty . . . . . . . . . . . . 139

Manufacturer’s Warranty . . . . . . . . . . . . . . . . . . 139

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Introduction

Your Phone’s Menu

This User Guide introduces you to Sprint® service and all the features of your new phone. It’s divided into four sections:

Section 1: Getting Started

Section 2: Your Phone

Section 3: Sprint Service Features

Section 4: Safety and Warranty Information

Note: Because of updates in phone software, this printed

guide may not be the most current version for your phone. Visit to access the most recent version of the user guide.

WARNING: Please refer to the Important Safety Information

www.sprint.com and sign on to My Sprint

section on page 132 to learn about information that will help you safely use your phone. Failure to read and follow the Important Safety Information in this phone guide may result in serious bodily injury, death, or property damage.

The following table outlines your phone’s main menu structure. For more information about using your phone’s menus, see “Navigating Through the Menus” on page 19.

Web

Maps

Sprint Navigation

Sprint Family Locator

Entertainment

Music

Sprint TV

Games

My Stuff

Application Manager

Games

Ringers

Screen Savers

Applications

Call Tones

Options

Memory Info My Content Manager Get New

Photos & Videos

Camera

Touch > to view the following options:

Color Tone Enable Auto-Send Image Controls Zoom Fun Frames Go to Album Settings Camcorder Mode Self Timer Cancel

Camcorder (Video Mail/Long Video)

Touch > to view the following options:

Color Tone Zoom Image Controls Go to Album Settings Camera Mode Self Timer Cancel Enable Auto-Send

My Photos & Videos

In Phone Memory Card

My Places

Auto-Send

Auto-Send Places Enable Notifications Enable Auto-Send

Other Settings

Auto-Save to Location Status Bar Slideshow Interval

Messaging

Voicemail

Send Message

Messages

Settings

Callback Number Signature Preset Messages

Social Networking

Facebook

MySpace

Twitter

Social Zone

Settings

Display

Screen Savers

Brightness

Backlight

Backlight Dim Backlight Off

Picture ID

Contacts Private/Unknown Unsaved Numbers

Font Size

Messages Notepad Browser Applications

Power Save Mode

Whisper Notification

Touch Calibration

Volume

Incoming Ringer

Playback Volume

Power Up/Down

Key Beeps

Tone Length Tone Type Tone Volume

Ringers

Incoming Calls

Contacts Private/Unknown Unsaved Numbers

Call Alerts

Beep Each Minute Connect Out of Service Signal Fade/Call Drop

Voicemail

Messages

Alarm/Calendar

Power Up/Down

iii

Vibration

Text Entry

Phone Info

Lock Phone

Parental Controls

Incoming Calls

Contacts Private/Unknown Unsaved Numbers

Voicemail

Messages

Alarm/Calendar

Touch Vibration

Vibration Level Vibration Type

Word Complete Word Scan Next Word Complete

Phone#/User ID Version Icon Glossary Advanced Memory Info My Account Battery Status

Lock Now Change Lock Code

Parental Control

Change Parental Control Code

Restriction

Voice Call Camera / Camcorder Messaging Force Location On Web

Call Setup

Auto-Answer Contacts Match Abbreviated Dialing

TTY

Airplane/Music Mode

Data

On/Off Update Profile Net Guard

Headset Mode

Language (Idioma)

Location

Roaming

Set Mode Data Roam Guard Call Guard

Reset/Delete

Reset Settings Delete Stuff Reset Phone Change Lock Code

Tools

Clock

Alarm Stopwatch World Clock

Calendar

Bluetooth

Bluetooth Trusted Devices Visibility My Bluetooth Info Add New Help

Update Phone

Update Firmware Update PRL

Wireless Backup

Mass Storage

Connect to PC Format Memory Card File Manager Memory Info

Voice Service

Voice Command

Call [Name][Type]/[Number] Send Msg to [Name][Type]/[Number] Find [Name][Type] Go to [Menu] Check [Item] Voice command Training Exit Voice Command

Voice Reader

Voice Guide Phone Status

Voice Memo

Settings & Info

Set Speaker Help

Calculator

Calculator Unit Converter Ez Tip Calculator

Notepad

Document Viewer

Shopping

In Call Menu

Mute

Speaker

Dial Pad

End Call

Save Voice Memo Main Menu Phone Info 3-Way Call Cancel Contacts

Section 1

Getting Started

Setting Up Your Phone (page 2)

1A. Setting Up Service

Talk

Activating Your Phone (page 3)

Setting Up Your Voicemail (page 3)

Sprint Account Passwords (page 4)

Getting Help (page 5)

Setting Up Your Phone

1. Install the battery.

Remove the battery from its packaging. Press up on the bottom part of the battery cover

with your thumb and slide the cover upward to remove it from the back of the phone.

Insert the battery into the opening in the back of the phone, making sure the connectors align. Gently press down to secure the battery.

2 1A. Setting Up Service

Position the battery cover over the battery compartment and slide it downward until you hear a click.

2. Press and hold on the right side of the

phone to turn the phone on.

If your phone is activated, it will turn on, search for Sprint service, and enter standby mode.

If your phone is not yet activated, see “Activating Your Phone” on page 3 for more information.

3. Make your first call.

Press to display the dial pad. Use your dial pad to enter a phone number. Touch or press .

Note: Your phone’s battery should have enough charge for

your phone to turn on and find a signal, set up your voicemail, and make a call. You should fully charge your battery as soon as possible. See “Charging the Battery” on page 18 for details.

Activating Your Phone

If you purchased your phone at a Sprint Store, it is

probably activated and ready to use.

If you received your phone in the mail and it is for a new Sprint account or a new line of service, it is designed to

activate automatically. To confirm your activation, make a phone call.

If you received your phone in the mail and you are activating a new phone for an existing number on your account, you will need to go online to activate your

new phone.

From your computer’s Web browser, go to

www.sprint.com/activate and complete the

onscreen instructions to activate your phone.

When you have finished, make a phone call to confirm your activation. If your phone is still not activated or you do not have access to the Internet,

contact Sprint Customer Service at

1-888-211-4727

for assistance.

Tip: Do not press while the phone is being activated.

Pressing

Note: If you are having difficulty with activation, contact Sprint

Customer Service by dialing other phone.

cancels the activation process.

1-888-211-4727 from any

Setting Up Your Voicemail

Your phone automatically transfers all unanswered calls to your voicemail, even if your phone is in use or turned off. You should set up your Sprint Voicemail and personal greeting as soon as your phone is activated. Always use a passcode to protect against unauthorized access.

1. From home screen, press to display the

dial pad.

2. Touch and hold .

3. Follow the system prompts to:

Create your passcode. Record your name announcement.

1A. Setting Up Service 3

Setting Up Service

Record your greeting.

Note: Voicemail Passcode

Sprint strongly recommends that you create a passcode when setting up your voicemail to protect against unauthorized access. Without a passcode, anyone who has access to your phone is able to access your voicemail messages.

For more information about using your voicemail, see “Voicemail” on page 98.

Sprint Account Passwords

As a Sprint customer, you enjoy unlimited access to your personal account information, your voicemail account, and your data services account. To ensure that no one else has access to your information, you will need to create passwords to protect your privacy.

Account Username and Password

If you are the account owner, you will create an account username and password when you sign on to

www.sprint.com. (Click Need to register for access? to get

started.) If you are not the account owner (if someone

4 1A. Setting Up Service

else receives the bill for your Sprint service), you can get a sub-account password at

www.sprint.com.

Voicemail Password

You’ll create your voicemail password (or passcode) when you set up your voicemail. See “Setting Up Your Voicemail” on page 3 for more information on your voicemail password.

Data Services Password

With your Sprint phone, you may elect to set up an optional data services password to control access and authorize Premium Service purchases.

For more information, or to change your passwords, sign on to Service at

www.sprint.com or call Sprint Customer

1-888-211-4727.

Getting Help

Talk3Talk

Talk

411

Talk

Managing Your Account

Online: www.sprint.com

Access your account information. Check your minutes used (depending on your Sprint

service plan). View and pay your bill. Enroll in Sprint online billing and automatic payment. Purchase accessories. Shop for the latest Sprint phones. View available Sprint service plans and options. Learn more about data services and other products

like Sprint Picture Mail, games, ringers, screen savers, and more.

From Your Sprint Phone

Press and choose from these options:

Touch to check minute usage and account balance.

Touch to make a payment. Touch to access a summary of your

Sprint service plan or get answers to other questions. Touch to add a new line of service,

upgrade your phone, or access other account services.

From Any Other Phone

Sprint Customer Service: 1-888-211-4727. Business Customer Service: 1-800-927-2199.

Sprint 411

Sprint 411 gives you access to a variety of services and information, including residential, business, and government listings; movie listings or showtimes; driving directions, restaurant reservations, and major local event information. You can get up to three pieces of information per call, and the operator can automatically connect your call at no additional charge.

There is a per-call charge to use Sprint 411, and you will be billed for airtime.

Touch .

1A. Setting Up Service 5

Setting Up Service

Sprint Operator Services

Talk

Sprint Operator Services provides assistance when you place collect calls or when you place calls billed to a local telephone calling card or third party.

Touch .

For more information or to see the latest in products and services, visit us online at

6 1A. Setting Up Service

www.sprint.com.

Section 2

Your Phone

2A. Phone Basics

Tip: Phone Software Upgrades – Updates to your phone’s

8 2A. Phone Basics

Your Phone (page 8)

Viewing the Display Screen (page 12)

Getting to Know the Touch Screen (page 16)

Turning Your Phone On and Off (page 16)

Calibrating the Touch Screen (page 17)

Battery and Charger (page 17)

Navigating Through the Menus (page 19)

Displaying Your Phone Number (page 20)

Making and Answering Calls (page 21)

Entering Text (page 28)

software may become available from time to time. Sprint will automatically upload critical updates to your phone. You can also use the menu to check for and download updates. Touch more menu items) >

Firmware

> Main Menu > (slide the screen up to display

Tools > Update Phone > Update

to search for and download available updates.

1. Earpiece

2. Status Light

3. Status Bar Icons

4. Battery Strength Indicator

5. Touch Screen

6. Home Key

7. Back Key

8. Talk Key

9. Microphone

10.

QWERTY Keyboard

Key Functions

1. Earpiece lets you hear the caller and automated

prompts.

2. Status Light indicates incoming calls, new

messages, or other events by blinking. It is red while charging and turns green when charging is completed.

3. Status Bar Icons provide information about your

phone’s status and options, such as signal strength, roaming, ringer setting, messaging, and battery charge.

4. Battery Strength Indicator represents the amount of

remaining battery charge currently available in your phone. When all bars are displayed in the battery icon, the phone’s battery is fully charged. When no bars are displa nearly completely discharged.

5. Touch Screen displays all the information needed

to operate your phone, such as the call status, the Contacts list, the date and time, and the signal and battery strength.

yed, the phone’s battery is

6. Home Key lets you go back to Home screen in any

menu display. To go back to standby mode, press this key again.

7. Back Key returns you to the previous menu when in

a sub-menu. This key also allows you to return to the previous screen in a data session.

8. Talk Key brings the dial pad on the screen. Hold

down to activate Voice Command while in standby mode.

9. Microphone allows other callers to hear you clearly

when you are speaking to them.

10. QWERTY Keyboard lets you enter numbers, letters,

and characters. Press number keys for speed dialing.

2A. Phone Basics 9

Phone Basics

18. BACK Key

17. ENTER Key

13. Emoticon Key

15. SPACE Key

14. Symbols Key

12. Function Key

11. SHIFT Key

16. Arrow Keys

11. SHIFT Key lets you change letter capitalization

when entering text using the QWERTY keyboard.

12. Function Key allows you enter the alternate

character (such as @ for the R key) on the QWERTY keyboard. (See “Entering Text With the QWERTY Keyboard” on page 32 for details.)

10 2A. Phone Basics

13. Emoticon Key lets you enter emoticons when

composing text messages.

14. Symbols Key lets you enter symbols when

composing text messages.

15. SPACE Key lets you enter a space.

16. Arrow Keys let you move the cursor up, down, right

or left.

17. ENTER Key lets you move the cursor to the

g of the next line when composing text

beginnin messages.

18. BACK Key deletes characters from the display in

text entry mode. When in a menu, pressing the Back key returns you to the previous menu. This key also allows you to return to the previous screen in a data session.

19. Volume Button allows you to adjust the ringer

19. Volume Button

20. Camera Button

21. Charger/Accessory Jack

22. Headset Jack

23. Power/Lock Button

24. microSDTM Card Slot

volume or adjust the voice volume during a call.

20. Camera Button lets you activate the camera and

camcorder and take pictures and videos.

21. Charger/Accessory Jack allows you to connect the

phone charger or an optional USB cable. CAUTION! Inserting an accessory into the incorrect jack may damage the phone.

22. Headset Jack allows you to plug in either a stereo

headset or an optional headset for convenient, hands-free conversations. CAUTION! Inserting an accessory into the incorrect jack may damage the phone.

23. Power/Lock Button lets you turn the phone on or

off. It also locks or unlocks the phone.

24. microSD™ Card Slot lets you use the microSD card

to expand the memory of your phone. (See “Inserting the microSD Card” on page 77.)

2A. Phone Basics 11

Phone Basics

Camera Lens used for picture taking and video

25. Camera Lens

26. Speaker

Mute

25.

recording. Keep clean for optimal performance.

26. Speaker lets you hear the different ringers and

sounds. You can mute the ringer when receiving incoming calls by touching . The speaker also lets you hear the caller’s voice when in speakerphone mode.

12 2A. Phone Basics

Viewing the Display Screen

Your phone’s display screen provides information about your phone’s status and options. This list identifies the symbols you’ll see on your phone’s display screen:

Tip: To view a list of your phone’s icons and descriptions, from

the main menu touch

Phone Info > Icon Glossary

Status Bar – Service Icons

1x Signal Strength – Shows your current 1xRTT

signal strength. (More bars = stronger signal.) (Bars are yellow.)

EVDO Signal Strength – Shows your current

EVDO signal strength.

signal.) (Bars are white.)

No Service – Your phone cannot find a usable

signal.

Roaming – Your phone is “roaming” off the

Nationwide Sprint Network.

> Main Menu > Settings >

(More bars = stronger

Status Bar – Service Icons

EVDO Data Service – Sprint mobile broadband

data service (EVDO) is available. When active, the icon is animated.

1x Service Activated – Indicates that Sprint

1xRTT data service is available. When active, the icon is animated.

1x Service Deactivated – Indicates that Sprint

1xRTT data service is deactivated.

1x Service Unavailable – Data service is

currently unavailable.

Status Bar – Status Icons

Airplane/Music Mode – Indicates that the phone

is in Airplane/Music Mode.

Full Battery – Shows your current battery charge

level. (Icon shown is fully charged.)

Low Battery – Shows the battery is low.

Ringer Only – Indicates ringer only is set for call

alert.

Vibrate Only – Indicates ringer volume is set to

vibrate only.

1 Beep – Indicates one beep is set for call alert.

1 Beep & Vibrate – Indicates one beep and

vibration is set for call alert.

Vibrate All – Indicates ringer volume is set to

vibrate all.

Ringer Off – The ringer is set to off.

Silence All – All sounds are turned off.

Ringer & Vibrate – Indicates ringer and vibrate

mode is set.

2A. Phone Basics 13

Phone Basics

Status Bar – Status Icons

Bubble Icon – Indicates you have missed alerts

such as voicemail, missed calls, new messages, scheduled events, or a completed wireless backup.

Location On – Your phone’s location feature is

on and available for location-based services such as GPS Navigation.

Location Off – Your phone’s location feature is

off. Your location is available only for 911 (see page 39).

TTY – Indicates your phone is operating in TTY

mode.

Speaker – Indicates speaker is activated.

Bluetooth Enabled (Hidden)

Bluetooth Enabled (Visible)

Bluetooth Connected

Bluetooth Connected (Mono/Stereo Headset)

14 2A. Phone Basics

Status Bar – Status Icons

Bluetooth Connected (Stereo Speaker)

Alarm Clock – Indicates alarm is activated.

Camera/Picture – Indicates camera mode.

Camcorder/Video – Indicates camcorder mode.

1 Background Application – Indicates that one

application is active.

2 Background Applications – Indicates that 2

applications are active.

3 Background Applications – Indicates that 3

applications are active.

4 Background Applications – Indicates that 4

applications are active.

5 Background Applications – Indicates that 5

applications are active.

Camera Resolution 2M – Indicates camera

resolution is set to 2M.

Camcorder Resolution QVGA – Indicates

camcorder resolution is set to QVGA.

Status Bar – Status Icons

Camera Resolution High – Indicates camera

resolution is set to High.

Camera/Camcorder Resolution Med – Indicates

camera resolution is set to Med.

Camera/Camcorder Resolution Low – Indicates

camera resolution is set to Low.

Enable Auto-Send – Indicates Auto-Send feature

is enabled.

Disable Auto-Send – Indicates Auto-Send

feature is disabled.

Zoom

Self Timer

Color Tone

Night Mode Setting

– Indicates that Night mode

is set.

Status Bar – Messaging Icons

Urgent Message – Indicates you have new

urgent messages.

Sent Message – Indicates the message is sent.

Received Message – Indicates the message is

received.

Recipient – Indicates recipient field.

File Attachment – Indicates file attachment field.

Phone Basics

File Attached – Indicates a file is attached.

Audio file attached – Indicates an audio file is

attached.

Voice file attached – Indicates a voice file is

attached.

Calendar file attached – Indicates a calendar file

is attached.

Contact file attached – Indicates a contact file is

attached.

2A. Phone Basics 15

Getting to Know the Touch Screen

Touch key sensors are very sensitive and require only a light touch — you don’t need to press them forcefully to use them. Pressing touch keys too hard may damage the touch keypad.

Use the tip of your finger to touch the center of a touch key. If you touch off-center it may activate an adjacent key instead.

The touch screen is automatically locked when the backlight is off. To lock manually, press the lock button on the right side of the phone.

To unlock the touch screen, press and hold the lock button on the right side of the phone.

– or –

Touch and hold the lock toggle key and drag to .

16 2A. Phone Basics

WARNING: Don’t place anything heavy on the touch screen.

Be careful not to scratch the touch screen with sharp objects. Do not store your phone in extreme conditions (places that are too humid, hot, or cold), or around chemicals, which may change the cosmetic or functional features of your phone.

Turning Your Phone On and Off

Turning Your Phone On

Press and hold .

Once your phone is on, it may display “Searching for Service.” When your phone finds a signal, it enters standby mode – the phone’s idle state. At this point, you are ready to begin making and receiving calls.

If your phone is unable to find a signal after 15 minutes of searching, a Power Save feature is automatically activated. When a signal is found, your phone automatically returns to standby mode.

In Power Save mode, your phone searches for a signal periodically without your intervention. You can also

initiate a search for Sprint service by pressing any key (when your phone is turned on).

Tip: The Power Save feature conserves your battery power

when you are in an area where there is no signal.

4. When the message “Complete Calibration?”

appears, touch an option:

Accept to accept the calibration. Try Again to restart touch calibration.

Turning Your Phone Off

Press and hold for two seconds until you see the powering-down animation on the display screen.

Your screen remains blank while your phone is off (unless the battery is charging).

Calibrating the Touch Screen

When you first activate the phone, you will be asked to calibrate the touch screen to improve touch accuracy, based on your touch. If you don’t want this, touch

Time or Never.

1. When the phone is turned on, touch Calibrate Now.

2. Touch the screen to start touch calibration.

3. Touch the target each time it appears.

Battery and Charger

WARNING: Use only Sprint-approved or LG-approved

Sprint-approved or LG-approved batteries and accessories can be found at Sprint Stores or through LG; or you can call 1-866-866-7509 to order. They’re also available at

Battery Capacity

Your phone is equipped with a Lithium-Ion Polymer (Lipoly) battery. It allows you to recharge your battery before it is fully drained. The battery provides up to 7 hours of continuous digital talk time.

batteries and chargers with your phone. The failure to use a Sprint-approved or LG-approved battery and charger may increase the risk that your phone will overheat, catch fire, or explode, resulting in serious bodily injury, death, or property damage.

www.sprint.com.

2A. Phone Basics 17

Phone Basics

When the battery reaches 5% of its capacity, the battery icon blinks. When there are approximately two minutes of talk time left, the phone sounds an audible alert and then turns off.

Note: Long backlight settings, searching for service, vibrate

mode, browser use, and other variables may reduce the battery’s talk and standby times.

Tip: Watch your phone’s battery level indicator and charge the

battery before it runs out of power.

Installing the Battery

See “Setting Up Your Phone” on page 2.

Removing the Battery

1. Make sure the power is off so that you don’t lose

any stored numbers or messages.

2. Hold the phone securely with both hands.

3. Place your thumb on the bottom of the phone and

push the cover upward until it clicks out of place. Then, remove the battery cover.

4. Use the opening near the top of the battery to lift

the battery out.

18 2A. Phone Basics

WARNING: Do not handle a damaged or leaking Li-poly

battery as you can be burned.

Charging the Battery

Keeping track of your battery’s charge is important. If your battery level becomes too low, your phone automatically turns off, and you will lose any information you were working on.

Always use a Sprint-appro charger, travel charger, or vehicle power adapter to charge your battery.

ved or LG-approved desktop

Plug the small end of the charger into the phone’s

Header Icon

charger jack and the other end into an electrical outlet.

A red indicator light means the battery is charging. A green indicator light means the battery is at

least 90 percent charged.

With the Sprint-approved Li-poly battery, you can recharge the battery before it becomes completely run down.

Navigating Through the Menus

Touch > Main Menu to access menus.

On the Touch Screen

To scroll through lists, touch the screen and slide your finger up the screen as shown in the following figure. The list will move up so more items are visible. To display the top list back, slide the screen down.

Phone Basics

To select an item, touch it on the menu. Your phone will vibrate slightly when it recognizes you’ve touched a menu.

For example, to view your text messages:

1. Touch and then Main Menu to access the main

menu.

2. Touch Messaging.

3. Touch Messages. (If you have any text messages,

they are displayed.)

2A. Phone Basics 19

Using the QWERTY Keyboard

Arrow keys on the keyboard let you scroll through onscreen items. To navigate through a menu, press the up and down arrow keys. As you navigate through the menu, menu options are highlighted. Select any option by highlighting it and pressing .

For example, to view your text messages:

1. From standby mode, press and press the down

arrow key to highlight

to access the main menu.

2. Select Messaging by pressing the down arrow key

until you see that menu option and pressing

3. Use the down arrow key to find the Messages

menu option and press .

ou have any text messages, they are displayed.)

(If y

For the purposes of this guide, the steps described (using either the touch keypad or the QWERTY keyboard) condense into:

Touch > Main Menu > Messaging > Messages.

20 2A. Phone Basics

Main Menu. Then press

For a diagram of your phone’s menu, please see “Your Phone’s Menu” on page i.

Backing Up Within a Menu

To go to the previous menu:

Press .

– or –

Press on the keyboard.

To return to standby mode:

Press twice.

– or –

Touch the header icon (see illustration on page 19).

Displaying Your Phone Number

Touch > Main Menu > Settings > Phone Info >

Phone#/User ID. (Your phone number and other

information about your phone and account will be displayed.)

Dial pad

Contacts

Dial pad

Contacts

Recent History

Hello UI

Talk

Call

Making and Answering Calls

Making Calls

1. Press and enter a phone number using the

dial pad or the keyboard. (If you make a mistake while dialing, touch or press to erase the numbers.)

2. Touch or press . (To make a call when

you are roaming and Call Guard is enabled, touch

Roam Call and touch . See “Call Guard” on

page 106.)

3. To end the call, drag the toggle key to .

Tip: To redial other recent numbers, press , and

touch , the desired number, and .

When making calls off the Nationwide Sprint Network, always dial using 11 digits (1 + area code + phone number).

You can also place calls from your phone by speed dialing numbers from your Contacts (page 27), using your History listings (page 48), and ASR (Automatic Speech Recognition) (page 73).

Dialing Options

When you enter numbers you will see a variety of dialing options displayed on the phone’s screen.

To initiate an option, touch the corresponding key.

Save: Enter a seven-digit or ten-digit number (phone

number and area code) and touch

Save to save the

2A. Phone Basics 21

Phone Basics

phone number in your Contacts. (See “Saving a

Answer

Phone Number” on page 25.)

Contact Details: Displays Contacts details for

numbers that are already saved in the phone.

Send Msg: Enter a seven-digit or ten-digit number

and touch this to quickly send a message to the number.

Pause: Enter digits and touch this to enter a pause

within a number string. (See “Dialing and Saving Phone Numbers With Pauses” on page 26.)

Tip: To speed dial a phone number, touch and hold the

speed dial number. If the speed dial number is two digits, enter the first digit, and then touch and hold the second digit. (For information on setting up speed dial numbers, see “Assigning Speed Dial Numbers” on page 53.) (This feature will not work when you are roaming off the Nationwide Sprint Network; when roaming you must dial using eleven digits [1 + the area code + the seven-digit phone number].)

22 2A. Phone Basics

Answering Calls

1. Make sure your phone is on. (If your phone is off,

incoming calls go to voicemail.)

2. Touch .

– or –

Touch and drag the toggle key to .

Your phone notifies you of incoming calls in the following ways:

The phone rings or vibrates. The indicator light flashes. The backlight illuminates. The screen displays an incoming call message.

If the incoming call is from a number stored in your Contacts, the entry’s name is displayed. You may also see the caller’s phone number, if available.

You also see the following options if your phone is on standby. To select an option, touch the corresponding touch key.

Silence to mute the ringer. Send to Voicemail to send the call to voicemail.

Ignore with Text to send a text message. You can

End Call

Call

Send

Msg

911

Talk

send the preset message or write a new one.

Answer to answer the call.

Answering a Roam Call With Call Guard Enabled

Call Guard is an option that helps you manage your roaming charges when making or receiving calls while outside the Nationwide Sprint Network. Please see “Roaming” on page 104 for more information about roaming.

Touch Answer to answer the call. (See “Call Guard” on page 106 for additional information.)

Note: When your phone is off, calls go directly to voicemail

Ending a Call

Touch .

Missed Call Notification

When you do not answer an incoming call, your screen displays the Missed Call log in a bubble on the standby screen.

Touch the entry. (To dial the phone number, touch

. To send a message, touch )

Calling Emergency Numbers

You can place calls to 911 (dial ), even if your account is restricted.

Note: When you place an emergency call, your phone

automatically enters Emergency mode.

During an emergency call, you will see a variety of options displayed on the screen.

To initiate an option, touch the following:

My Phone# to display your phone number during an

emergency call.

Speaker to activate speakerphone mode. (If you are

in speakerphone mode, the option is displayed as

Speaker Off to deactivate.) Dial Pad to display the dial pad. More to access the following options:

Contacts to display Contacts list. Voice Memo to record the current conversation.

2A. Phone Basics 23

Phone Basics

Phone Info to check the phone number, version,

End Call

Exit

etc.

Cancel to close the pop-up menu.

To exit Emergency mode:

1. Touch to end a 911 call.

2. Touch to exit from the Emergency mode.

Enhanced 911 (E911) Information

This phone features an embedded Global Positioning System (GPS) chip necessary for utilizing E911 emergency location services where available.

When you place an emergency 911 call, the GPS feature of your phone seeks information to calculate your approximate location. Depending on several variables, including availability and access to satellite signals, it may take up to 30 seconds or more to determine and report your approximate location.

Important: Always report your location to the 911 operator

24 2A. Phone Basics

when placing an emergency call.

designated emergency call takers, known as Public Safety Answering Points (PSAPs) may not be equipped to receive GPS location information from your phone.

Some

In-Call Options

To select an option, touch the corresponding touchkey. The following options may be available through the Options menu:

Mute to mute the microphone. Touch Unmute to

unmute the microphone.

Speaker to activate speakerphone mode. (If you are

in speakerphone mode, the option is displayed as

Speaker Off to deactivate.)

WARNING: Because of higher volume levels, do not place

Dial Pad to display the dial pad. End Call to end the call. More to access the following options:

the phone near your ear during speakerphone use.

Save to save a phone number in your Contacts.

(See “Saving a Phone Number” on page 53.)

Contact Details to display the contact details (if the

contact is saved in the Contacts).

Main Menu to display the phone’s main menu. 3-Way Call to initiate a 3-way call.

Contacts to display your Contacts list.

Save

New Entry

Existing Entry

Done

Call

Voice Memo to record the current conversation. Phone Info to check the phone number, version,

etc.

Cancel to close the pop-up menu.

Saving a Phone Number

You can store up to seven phone numbers and 600 Contacts entries in your phone. Each entry’s name can contain 64 characters. Your phone automatically sorts the Contacts entries alphabetically. (For more information, see “2D. Contacts” on page 52.)

To save a number from standby mode:

1. Press to display the dial pad.

2. Enter a phone number.

3. Touch .

4. Touch for a new contact or

to add a number to an existing contact.

5. Touch a label for the number (Mobile, Home, Work,

Pager, Fax, or Other).

6. Touch the Name field and enter the new contact

me using the touch keypad or QWERTY

na keyboard.

– or –

Search an existing contact name and touch it to save the new number.

7. Touch to save the new entry.

Finding a Phone Number

You can search Contacts for entries by name.

1. Press and touch . The Contacts list is

displayed.

2. Touch and enter the first letter or letters of an

entry. (The more letters you enter, the more specific the search.) To display an entry, touch it.

3. To dial a number, touch or press .

2A. Phone Basics 25

Phone Basics

Dialing and Saving Phone Numbers With

Pause

Talk

Save

Talk

Pauses

You can dial or save phone numbers with pauses for use with automated systems, such as voicemail or credit card billing numbers.

Note: You can have multiple pauses in a phone number.

To dial or save phone numbers with pauses:

1. Press and enter the phone number.

2. Touch .

3. Enter additional numbers.

4. Touch to dial the number.

– or –

Touch to save the number in your Contacts.

Note: When dialing a number with a pause, touch Send

Tones

26 2A. Phone Basics

Abbreviated Dialing

Abbreviated Dialing is similar to speed dialing. You can use either of the following abbreviated dialing features.

Contacts Match – Retrieve any number saved in your

Contacts by entering any consecutive three digits of the number. Touch to dial the retrieved number. (See “To activate the Contacts Match feature:” on page 43.)

Prepend – Prepend the first five or six digits (for

example, the area code and prefix) to any four or five digits you enter. Touch to dial the resulting number. (See “To activate the Prefix feature:” on page 43.)

To place a call using Contacts Match Abbreviated Dialing:

1. Press and enter three to six digits of a

Contacts entry’s phone number. The numbers in your Contacts list that contain matches will display.

2. Touch to display the details.

3. Touch the contact you want to call and then touch

To place a call using Prepend Abbreviated Dialing:

Talk

Call

Contact

Details

1. Press and enter the last four or five digits of

the phone number. The Abbreviated Dialing number will display.

2. Touch to display the details.

3. Touch the number and touch .

Dialing From the Contacts List

1. Press and touch .

2. Touch the entry you want to call and touch .

3. If multiple numbers are saved in the Contact entry,

touch then the number you wish to dial.

Speed Dialing

You can store up to 98 numbers in your phone’s speed dial memory. Dial speed dial entries using one key touch for locations 2–9 or two key touches for locations 10–99.

To use One-Touch Dialing for speed dial loca

Touch and hold the appropriate key for approximately two seconds. The display confirms that you have dialed the number when it shows “Connecting...”.

To use Two-Touch Dialing for speed dial locations 10–99:

1. Press or touch the first digit.

2. Press or touch and hold the second digit for

approximately two seconds. The display confirms that you have dialed the number when it shows “Connecting...”.

Note: Speed dialing is not available when you are roaming;

when you are roaming off the Nationwide Sprint Network, you must always dial using eleven digits (1 + area code + number).

2A. Phone Basics 27

tions 2–9:

Phone Basics

Plus (+) Code Dialing

Talk

Abc

When placing international calls, Plus Code Dialing automatically enters the international access code for your location (for example, 011 for international calls made from the U.S.).

1. Press or touch and hold until you see a “+” on

the display screen.

2. Dial the country code and phone number, and

then touch . (The phone automatically prepends the access code for international dialing, followed by the country code and phone number.)

Entering Text

Selecting a Text Input Mode

Your phone provides convenient ways to enter letters, numbers, and symbols whenever you are prompted to enter text (for example, when adding a Contacts entry or when using email and text messaging). You can use the touch keypad or the QWERTY keyboard. While you are using the touch keypad, you can switch to and from the QWERTY keyboard.

28 2A. Phone Basics

On the Touch Keypad

1. From a screen where you can enter text, touch

to change the text input mode.

2. Select one of the following options:

Predictive to enter text using a predictive text entry

system that reduces the number of keystrokes required to enter a word. (See page 29.)

Abc to use multi-touch entry – touch once for

“a,” twice for “b”, three times for “c.” (See page 29.)

123 to enter numbers by touching the numbers

on the keypad. (See page 30.)

Symbols to enter symbols. (See page 30.)

Emoticon to enter “emoticons.” (See page 30.)

SHIFT

Done

455

Smileys to enter smileys. (See page 30.)

Tip: When entering text, touch or press to

change letter capitalization (Abc > ABC > abc).

Predictive Text Input

Predictive Text Input lets you enter text using a few keystrokes per word. (To select the mode when entering text, see “Selecting a Text Input Mode” on page 28.)

Predictive Text Input uses an intuitive word database to analyze the letters you enter and create a suitable word. (The word may change as you type.)

1. Select the Predictive text input mode.

2. Enter a couple of letters of a word. When you enter

a letter of a word, a small window will appear and shows the words starting with the let make a mistake, touch or press to erase a single character. Touch and hold or press and hold to erase an entire word.)

3. Scroll to the desired word and touch it or press

to select it.

Predictive Text

ters. (If you

4. If a word you want to enter is not displayed in the

list, select

Add Word? to add a word to the

Predictive Text Input database.

5. Enter the word and touch or press .

The word will appear as an option the next time you scroll through options during Predictive Text Input.

For more information about Predictive Text Input, visit the Tegic Web site at

www.T9.com.

ABC Mode (Touch Keypad Only)

In Abc mode, also known as multi-touch entry, you touch keys one, two, three, or four times to enter the letters you see on the keypad. For example, touch once for “a,” twice for “b”, or three times for “c”; or touch

once for “p,” twice for “q,” three times for “r,” or four

times for “s.”

1. Select the Abc mode. (See “Selecting a Text Input

Mode” on page 28.)

2. Touch the corresponding keys repeatedly until the

correct letter appears. (For example, to enter the word “Bill,” touch twice, three times, three times, and three times again.)

2A. Phone Basics 29

Phone Basics

(If you make a mistake, touch to erase a single

shift

character. Touch and hold to erase an entire word.)

By default, the first letter of an entry is capitalized and the following letters are lowercased. You can change the letter case using .

Characters scroll in the following order:

Key

Upper Case

. @ ? 1 , ! * # /

A B C 2

D E F 3

G H I 4

J K L 5

M N O 6

P Q R S 7

T U V 8

W X Y Z 9

Space

English Sequence

Lower Case

a b c 2

d e f 3

g h i 4

j k l 5

m n o 6

p q r s 7

t u v 8

w x y z 9

30 2A. Phone Basics

Entering Numbers, Symbols, Emoticons, Smileys and Preset Messages

To enter numbers:

Select the 123 mode and touch the appropriate key. (See “Selecting a Text Input Mode” on page 28.)

To enter symbols:

Select the Symbols mode. (See “Selecting a Text Input Mode” on page 28.) To enter a symbol, touch the appropriate key indicated on the display.

To enter “emoticons” (graphics):

Select the Emoticon mode and touch the appropriate key. (See “Selecting a Text Input Mode” on page 28.)

To enter smileys (text):

Select the Smileys mode and touch the appropriate key. (See “Selecting a Text Input Mode” on page 28.)

To enter preset messages:

Preset Msgs

PEN

Done

1. Touch on the right top of the screen.

2. Select the message you want by touching it.

Note: Preset messages make composing text messages

easier by allowing you to enter quick messages, such as “Meet me at,” “Let’s get lunch,” or a customized message of your own. (For more information on preset messages, please see “Managing Preset Messages” on page 40.)

Handwriting entry screen

Handwriting

When entering text, besides “typing” the text with the touch keypad, you also have the option to write with your fingertip. The touch screen converts your movements into characters.

Phone Basics

1. On the text entry screen, touch . The

handwriting entry screen appears.

2. Write within the handwriting entry screen. To

change letter case or shift between letters, numbers, and symbols, touch the icons just above the handwriting entry screen. When you are finished, touch .

2A. Phone Basics 31

Entering Text With the QWERTY Keyboard

Abc

Preset Msgs

Your phone has a built-in QWERTY keyboard, specifically designed for easy and comfortable text entry. The QWERTY keyboard uses the same layout and works just like the keyboard on your computer. The easiest way to enter text is by using your thumbs to type on the QWERTY keyboard.

32 2A. Phone Basics

1. From a screen where you can enter text, touch

and select whether to turn the predictive

text entry system on or off.

2. Use your thumbs to enter text.

To change capitalization, press . To enter an alternate character on a key, press the

function key and then press the alternate character’s key. To lock the function key, press

twice.

To enter “emoticons,” press and touch a symbol, or press the arrow keys to highlight an emoticon and press .

To enter symbols, press and touch the desired one or press the arrow keys to highlight a symbol and press .

To enter preset messages, touch on the right top of the screen. Select the message you want by touching it.

Sound Settings (page 33)

2B. Settings

Display Settings (page 37)

Text Entry Settings (page 39)

Location Settings (page 39)

Messaging Settings (page 40)

Airplane Mode (page 41)

TTY Use With Sprint Service (page 42)

Phone Setup Options (page 43)

Security Settings (page 44)

Sound Settings

Ringer Types

Ringer types help you identify incoming calls and messages. You can assign ringer types to individual Contacts entries, types of calls, and types of messages.

Selecting Ringer Types for Voice Calls

Your phone provides a variety of ringer options that allow you to customize your ring and volume settings. These options allow you to identify incoming calls by the ring.

1. Touch > Main Menu > (slide the screen up) >

Settings > Ringers > Incoming Calls.

2. Touch Contacts, Unsaved Numbers, or Private/

Unknown. For Contacts, touch the following:

Contacts with Default Ringer: You can set a ringer

type for calls from contacts with default ringer.

One Contact: You can set a specific ringer type for

calls from one specific contact.

2B. Settings 33

Settings

Select a category, and then scroll through the available ringers. Touch to hear a sample ringer.

4. Touch a ringer to assign it.

Getting New Ringers

A wide variety of new ringers are available from the Sprint Digital Lounge, and you can access them right from your phone. (Additional charges may apply, but some are free.)

1. Touch > Main Menu > (slide the screen up) >

Settings > Ringers > Incoming Calls, Voicemail, Messages, or Alarm/Calendar.

2. Select a call or message type to display a list of

ringer type categories.

3. Select Downloaded Ringers > Get New. (The

browser starts and displays the Ringers menu.)

4. Scroll through available ringers. When you find one

you want, touch it.

5. To make a purchase, touch Buy. (Your phone

automatically downloads the ringer.)

34 2B. Settings

6. When the download is finished, select an option to

continue:

Listen to listen to the ringer. Set As to finish assigning the ringer. Shop to browse for other items to download.

Selecting Ringer Types for Messages

1. Touch > Main Menu > (slide the screen up) >

Settings > Ringers > Messages.

2. Select a category, and then scroll through the

available ringers. Touch to hear a sample ringer.

3. Touch a ringer to assign it.

Assigning Ringers to Contacts

1. Touch > Main Menu > (slide the screen up) >

Settings > Ringers > Incoming Calls > Contacts > One Contact.

2. Touch a contact entry.

3. Select a category, and then scroll through the

available ringers. Touch to hear a sample ringer.

4. Touch a ringer to assign it.

Done

Selecting Ringer Types for Voicemail

1. Touch > Main Menu > (slide the screen up) >

Settings > Ringers > Voicemail.

2. Select a category, and then scroll through the

available ringers. Touch to hear a sample ringer.

3. Touch a ringer to assign it.

Adjusting the Phone’s Volume Settings

Adjust your phone’s volume settings to suit your needs and your environment.

1. Touch > Main Menu > (slide the screen up) >

Settings > Volume.

2. Select Incoming Ringer, Playback Volume, or Key

Beeps.

3. Touch a level bar to set the volume, or select

Silence All, Vibrate All, Ringer Off, or 1 Beep.

4. Toggle the VIBRATE setting. (Note: This toggle key

is not available when Silence All or Vibrate All is selected.)

5. Touch .

Tip: You can adjust the ringer volume in any screen (or the

earpiece volume during a call) by using the volume button on the left side of your phone.

Vibrate

To set your phone to vibrate instead of making any sounds:

Press the volume button down until you see “Vibrate All” on the screen.

To set your phone to vibrate in addition to any ringer settings:

1. Press the volume button up or down until a

Volume Level appears on the screen.

2. Toggle the VIBRATE setting to ON. (Note: This

toggle key is not activated when Silence All or Vibrate All is selected.)

To select the vibrate type:

1. Touch > Main Menu > (slide the screen up) >

Settings > Vibration.

2. Select Incoming Calls, Voicemail, Messages, Alarm/

Calendar, or Touch Vibration. For Incoming Calls,

2B. Settings 35

Settings

you can assign different vibrate types to Contacts,

Unsaved Numbers, and Private/Unknown.

3. Scroll through the available vibrate types. Touch

to sample a vibrate type.

4. Touch the a vibrate type to select it.

Silence All

The Silence All option allows you to mute all sounds without turning your phone off.

To activate Silence All:

Press the volume button down until you see “Silence All” on the screen.

To deactivate Silence All:

Press the volume button up repeatedly to select a volume level.

36 2B. Settings

Alert Notification

Set your phone to alert you with an audible tone when you change service areas, once a minute during a voice call, or when a call has been connected or dropped.

1. Touch > Main Menu > (slide the screen up) >

Settings > Ringers > Call Alerts.

2. Select Beep Each Minute, Out of Service, Connect, or

Signal Fade/Call Drop.

3. Touch and hold ON or OFF and slide left to change

a setting.

Selecting a Key Tone

Your phone offers a number of options for selecting the audible tones accompanying a keypress.

1. Touch > Main Menu > (slide the screen up) >

Settings > Volume > Key Beeps.

2. Select an option.

Tone Length to select a key tone length. (During a

call, longer tone lengths may be better for tone

recognition when dialing voicemail or other automated systems.)

Tone Volume to select a keypress volume level. Tone Type to select the sound of a keypress.

Display Settings

Changing the Backlight Time Length

Select how long the display screen and keypad remain backlit after you press any key.

1. Touch > Main Menu > (slide the screen up) >

Settings > Display > Backlight

2. Select Backlight Dim or Backlight Off.

3. Touch a time setting.

Note: Long backlight settings reduce the battery’s talk and

standby times.

Changing the Display Screen

Choose what you see on the display screen when in standby mode.

1. Touch > Main Menu > (slide the screen up) >

Settings > Display > Screen Savers.

2. Select No Image, Preloaded, My Photos, Assigned

Media, Downloaded Images, or Take New Picture.

3. Touch an image to view it. (While viewing an

image, you c through and view other available images.)

an flick the screen left or right to scroll

4. Touch Assign to assign an image.

Changing the Brightness

Adjust your screen’s brightness to suit your surroundings.

1. Touch > Main Menu > (slide the screen up) >

Settings > Display > Brightness.

2. Touch a brightness level bar to select it.

2B. Settings 37

Settings

Display Language

Done

You can choose to display your phone’s onscreen menus in English or in Spanish.

1. Touch > Main Menu > (slide the screen up) >

Settings > Language (Idioma).

2. Touch English or Español.

Changing the Font Size

Adjust the font you see when you are entering text (for example, when using the notepad or when adding a Contacts entry).

1. Touch > Main Menu > (slide the screen up) >

Settings > Display > Font Size.

2. Select Messages, Browser, Notepad, or Applications.

3. Touch a size setting and .

Whisper Notification

Set your phone to notify you with the whisper of new messages while you are operating the phon You can get new messages notification without interruption to what you are doing on the phone.

38 2B. Settings

1. Touch > Main Menu > (slide the screen up) >

Settings > Display > Whisper Notification.

2. Slide the Whisper Notification button to On.

Calibrating the Touch Screen

You can calibrate the touch screen for improved touch accuracy based on your touch.

1. Touch > Main Menu > (slide the screen up) >

Settings > Display > (slide the screen up) > Touch Calibration.

2. Touch the screen to start touch calibration.

3. Touch the target each time it appears.

4. When the message “Complete Calibration?”

appears, touch an option:

Accept to accept the calibration. Try Again to restart touch calibration.

Text Entry Settings

Location Settings

You can specify more automated features in the predictive text entry mode. These options can help streamline the text entry process by expanding the word database and completing the most commonly used words for you.

1. Touch > Main Menu > (slide the screen up) >

Settings > Text Entry.

2. Select Word Complete, Next Word Complete, or

Word Scan.

3. Touch and hold On or Off and slide left or right to

toggle each setting.

Word Complete to set the phone to complete a

word after entering a preset number of characters.

Next Word Complete to set the phone to predict

possible word candidates after you have entered a preset number of characters.

Word Scan to automatically update the word

database with new words from incoming messages.

Your phone is equipped with a Location feature for use in connection with location-based services.

The Location feature allows the network to detect your position. Turning Location off will hide your location from everyone except 911.

Note: Turning Location on will allow the network to detect

your position using GPS technology, making some Sprint applications and services easier to use. Turning Location off will disable the GPS location function for all purposes except 911, but will not hide your general location based on the cell site serving your call. No application or service may use your location without your request or permission. GPS-enhanced 911 is not available in all areas.

To enable or disable your phone’s Location feature:

1. Touch > Main Menu > (slide the screen up) >

Settings > Location. (You will see the Location

disclaimer.)

2. Read the disclaimer and touch Continue.

3. Touch On or Off to change the existing Location

setting.

2B. Settings 39

Settings

When you turn the Location feature on, the phone

Save

Edit

Save

Delete

displays the phone displays the

icon. When you turn Location off, the

icon.

Messaging Settings

Your phone’s advanced messaging capabilities let you send and receive many different kinds of text messages without placing a voice call. (For more information, see “Accessing Messages” on page 112.)

Messaging settings allow you to decide how you would like to be notified of new messages, to create a signature with each sent message, and to create your own preset messages.

Callback Number

1. Touch > Main Menu > Messaging > Settings >

Callback Number.

2. Select None, My Phone Number, or Other. (If you

40 2B. Settings

Other, enter a number and touch .)

select

Managing Preset Messages

Your phone is loaded with 20 preset messages to help

sending text messages easier. Customize or

make delete these messages, such as “Where are you?,” “Let’s get lunch,” and “Meet me at” to suit your needs, or add your own messages to the list.

To edit or delete a preset message:

1. Touch > Main Menu > Messaging > Settings >

Preset Messages. (You will see the list of preset

messages.)

2. Touch a message you want to edit or delete.

3. Touch , edit the message (see “Entering

Text” on page 28), and touch .

– or –

Touch to delete the message. (Touch

Cancel to cancel the deletion.)

Note: To delete multiple messages, touch on the top

right of the screen when the list of preset messages displays. Then select

Delete Multiple or Delete All.

To add a new preset message:

Add New

Save

1. Touch > Main Menu > Messaging > Settings >

Preset Messages. (You will see the list of preset

messages.)

2. To add a new message, touch .

3. Enter your message and touch . (Your new

message will be added to the beginning of the list.)

Adding a Customized Signature

Add a customized signature to each message you send.

1. Touch > Main Menu > Messaging > Settings >

Signature.

2. Select Custom. (If you do not wish to attach a

signature, select

3. Enter a signature and touch .

None.)

Airplane Mode

Airplane Mode allows you to use many of your phone’s features, such as Games, Notepad, and Voice Memos, when you are in an airplane or in any other area where making or receiving calls or data is prohibited. When you set your phone to Airplane Mode, it cannot send or receive any calls or access online information.

1. Touch > Main Menu > (slide the screen up) >

Settings > Airplane/Music Mode.

2. Read the disclaimer and touch Continue.

3. Select On, Off, or On Power Up.

While in Airplane Mode, your phone’s standby screen will display “Phone off.”

2B. Settings 41

Settings

TTY Use With Sprint Service

Talk

A TTY (also known as a TDD or Text Telephone) is a telecommunications device that allows people who are deaf, hard of hearing, or who have speech or language disabilities, to communicate by telephone.

Your phone is compatible with select TTY devices. Please check with the manufacturer of your TTY device to ensure that it is compatible with digital cell phones. Your phone and TTY device will connect via a special cable that plugs into your phone’s headset jack. If this cable was not provided with your TTY de your TTY device manufacturer to purchase the connector cable.

When establishing your Sprint service, please call Sprint Customer Service via the state Telecommunications Relay Service (TRS) by first

7-1-1 . Then provide the state TRS with

dialing this number:

866-727-4889.

To turn TTY Mode on or off:

1. Touch > Main Menu > (slide the screen up) >

Settings > TTY. (You will see an informational

message.)

42 2B. Settings

vice, contact

2. Touch Continue.

3. Touch On to turn TTY mode on.

– or –

Off to turn TTY mode off.

Touch

Note: In TTY Mode, your phone will display the TTY access

icon when the TTY device is plugged into the phone.

When enabled, TTY mode may impair the audio quality of non-TTY devices connected to the headset jack.

WARNING: 911 Emergency Calling

Sprint recommends that TTY users make emergency calls by other means, including Telecommunications Relay Services (TRS), analog cellular, and landline communications. Wireless TTY calls to 911 may be corrupted when received by public safety answering points (PSAPs), rendering some communications unintelligible. The problem encountered appears related to software used by PSAPs. This matter has been brought to the attention of the FCC, and the wireless industry and the PSAP community are currently working to resolve this.

Phone Setup Options

Done

Home Screen

Your phone offers you the option of customizing the home screen with the most frequently used menus for direct access.

1. Touch to open the home screen.

2. Touch Add. (Main menus are displayed.)

3. Touch to the right of a menu option to add that

menu option to your home screen. To navigate to a specific submenu, touch a menu option repeatedly until you see the submenu you want and touch

4. When you finish selecting menus to add, touch

Auto-Answer Mode

Set your phone to automatically pick up incoming calls when connected to an optional hands-free car kit.

1. Touch > Main Menu > (slide the screen up) >

Settings > Call Setup > Auto-Answer.

2. Touch an option.

Off to disable Auto-Answer. Headset to answer calls automatically when the

phone is connected to an optional headset. Remember, your phone will answer calls in AutoAnswer mode even if you are not present.

Setting Abbreviated Dialing

To activate the Contacts Match feature:

1. Touch > Main Menu > (slide the screen up) >

Settings > (slide the screen up) > Call Setup.

2. Slide the Contacts Match button to On.

To activate the Prefix feature:

1. Touch > Main Menu > (slide the screen up) >

Settings > (slide the screen up) > Call Setup.

2B. Settings 43

Settings

Unlock

Slide the Abbreviated Dialing button to On.

3. Enter the first five- or six-digit prefix in the Prefix

field and then touch .

To deactivate this feature, select Off during step 2 above.

Tip: To make an Abbreviated Dial call, see “Abbreviated

Dialing” on page 26.

Note: Abbreviated Dialing does not apply to 911 or Sprint 411.

Security Settings

You can customize your phone to meet your personal security needs. You must enter your lock code to change the security settings.

Tip: If you can’t recall your lock code, try using the last four

digits of your wireless phone number. If this doesn’t work, call Sprint Customer Service at

44 2B. Settings

1-888-211-4727.

Your Phone’s Lock Feature

Locking Your Phone

When your phone is locked, you can only receive incoming calls or make calls to 911, Sprint Customer Service, or special numbers. (See “Parental Controls” on page 45.)

1. Touch > Main Menu > (slide the screen up) >

Settings > Lock Phone and enter your lock code.

Please note that you will be asked if you want to change or keep the default lock code the first time you access this menu.

2. Touch Lock Now.

Unlocking Your Phone

1. From standby mode, touch .

2. Enter your lock code.

Changing the Lock Code

Dialer

Talk

Continue

1. Touch > Main Menu > (slide the screen up) >

Settings > Lock Phone and enter your lock code.

2. Touch Change Lock Code, and then enter and re-

enter your new lock code.

Tip: To access Change Lock Code menu, you can also

> Main Menu > (slide the screen up) >

Touch

Settings > Reset/Delete

Change Lock Code.

select

and enter your lock code. Then,

Calling in Lock Mode

You can place calls to 911 and to your special numbers when in lock mode. (For information on special numbers, see “Parental Controls” on page 45.)

To call an emergency number, special number, or Sprint Customer Service, touch , enter the phone number, and touch .

Parental Controls

Parental Controls give you a convenient way to manage wireless usage and access for everyone on your account. Kids get stylish phones to keep connected with friends and family, while you can

control Internet access, texting, content purchases, voice calls and camera use.

To activate the Parental Control feature:

1. Touch > Main Menu > (slide the screen up) >

Settings > Parental Controls.

2. Slide the Parental Control button to On and then

enter and re-enter a new parental lock code.

3. Select Restriction. (You will see a disclaimer.)

4. Read the disclaimer and touch .

5. Slide the button to for each option you want

to set below:

Voice Call to set call restrictions. Messaging to restrict messaging. Web to restrict Web access, including other

applications using data network.

Camera/Camcorder to restrict camera and

camcorder usage.

Force Location On to force the phone not to turn

off the location mode.

2B. Settings 45

Settings

Erasing Phone Content

Use the Security menu to quickly erase all the content you have created or stored in your phone.

1. Touch > Main Menu > (slide the screen up) >

Settings > Reset/Delete and enter your lock code.

2. Select Delete Stuff.

3. Touch an option.

Messages to delete all messages. Call Logs to delete all call logs. Browser Cookies and Cache to delete the

browser’s cookies and cache.

Downloaded Content to delete all the contents you

have downloaded.

Contacts to delete all the contents of your

Contacts list.

My Photos & Videos to delete all pictures and

videos in My Photos & Videos.

Voice Memo to delete all voice memos. Shortcuts to delete the menus you added on the

home screen.

My Places to delete all places set as My Places.

46 2B. Settings

4. Touch Delete to confirm the deletion.

Resetting Default Settings

Resetting the phone to default settings restores all the factory defaults, including the ringer types and display settings. The Contacts, Call History, Calendar, and Messaging are not affected.

To reset default settings:

1. Touch > Main Menu > (slide the screen up) >

Settings > Reset/Delete and enter your lock code.

2. Select Reset Settings. (You will see a disclaimer.)

3. Read the disclaimer and if you are certain that you

would like to restore all the factory settings, touch

Reset.

Resetting Your Phone

Disable

Enable

Resetting the phone restores all the factory defaults, including the ringer types and display settings. The Contacts, history, Scheduler, and Messaging items will be deleted.

1. Touch > Main Menu > (slide the screen up) >

Settings > Reset/Delete and enter your lock code.

2. Select Reset Phone.

3. If you are certain that you would like to restore all

factory settings, touch

Reset.

Security Features for Data Services

Enabling and Disabling Data Services

You can disable data services without turning off your phone; however, you will not have access to all data services, including Web. Disabling data services will avoid any charges associated with these services. While signed out, you can still place or receive phone calls, check voicemail, and use other voice services. You may enable data services again at any time.

To disable data services:

1. Touch > Main Menu > (slide the screen up) >

Settings > Data > On/Off. (You will see a message.)

2. Touch to confirm that you want to disable

data services.

To enable data services:

1. Touch > Main Menu > (slide the screen up) >

Settings > Data > On/Off. (A message is displayed.)

2. Touch to enable data services.

Settings

2B. Settings 47

Net Guard

When you first connect to the Web, the Net Guard will be displayed to confirm that you want to connect. This feature helps you avoid accidental connections. You can disable the Net Guard in the future by selecting

Always Auto-Connect when the Net Guard is displayed.

To change your Net Guard settings:

Touch > Main Menu > (slide the screen up) >

Settings > Data > Net Guard.

Slide the Net Guard switch to On to activate it. Slide the Net Guard switch to Off to deactivate it.

48 2B. Settings

Viewing History (page 49)

2C. History

History Options (page 49)

Making a Call From History (page 50)

Saving a Number From History (page 50)

Prepending a Number From History (page 51)

Erasing History (page 51)

Each entry contains the phone number (if it is available) and Contacts entry name (if the number is in your Contacts). Duplicate calls (same number and type of call) may only appear once on the list.

1. From standby mode, press and touch .

2. Touch an entry.

Note: History records only calls that occur while the phone is

turned on. If a call is received while your phone is turned off, it will not be included in history.

If you return a call from the voicemail menu, it will not be included in your phone’s history.

Viewing History

History is a list of the last 60 phone numbers (or Contacts entries) for calls you placed, accepted, or missed. History makes redialing a number fast and easy. It is continually updated as your phone automatically adds new numbers to the beginning of the list and removes the oldest entries from the bottom of the list.

History Options

Touch a History entry to access the following options:

Call to dial the entry. Send Msg to send a message. History to view all the history of the caller or receiver. Save Contact to save the number if it is not already in

your Contacts. (See “Saving a Number From History” on page 50.)

2C. History 49

History

Contact Details to view the contact information (if the

Delete

Done

number has already been saved to Contacts).

Touch on the right top of the screen to delete multiple or all History entries.

Making a Call From History

1. From standby mode, press and touch .

2. Scroll through the History entries and touch to

dial the entry.

Note: You cannot make calls from History to entries identified

No ID or Restricted.

50 2C. History

Saving a Number From History

Your phone can store up to 600 Contacts entries. Contacts entries can store up to a total of seven phone numbers, and each entry’s name can contain 64 characters.

1. Touch a History entry and touch Save Contact.

2. Select New Entry to create a new Contacts entry for

the number or an existing entry.

3. Touch the phone label to select it (Mobile, Home,

Work, Pager, Fax, or Other).

4. Touch the Enter Name field and enter the new

contact name using the touch keypad or QWERTY keyboard, and then touch .

– or –

Search an save the new number.

5. Touch to save the new entry.

Note: You cannot save phone numbers already in your

Contacts or from calls identified as

Existing Entry to save the number to

existing contact name and touch it to

No ID or Restricted.

Prepending a Number From History

Delete

If you need to make a call from History and you are outside your local area code, you can add the appropriate prefix by prepending the number.

1. From standby mode, press and touch .

2. Touch a History entry and then touch History.

3. Touch an entry and touch Prepend.

4. Enter the prefix and press to call the

number.

Erasing History

1. From standby mode, press and touch .

2. Touch in the top right corner of the screen

and select

3. After selecting entries to erase, touch .

– or –

If you are certain you want to erase all the History entries, touch .

Delete Multiple or Delete All.

History

2C. History 51

Adding a New Contacts Entry (page 52)

2D. Contacts

Add New

Done

Saving a Phone Number (page 53)

Contacts Entry Options (page 53)

Editing a Contacts Entry (page 54)

Adding a Number to a Contacts Entry (page 54)

Editing a Contacts Entry’s Numbers (page 55)

Assigning Speed Dial Numbers (page 55)

Selecting a Ringer Type for an Entry (page 56)

Assigning a Picture to an Entry (page 57)

Creating a Group (page 57)

Finding Contacts Entries (page 58)

Secret Contacts Entries (page 58)

Dialing Sprint Services (page 59)

Wireless Backup (page 60)

Hello UI (page 61)

52 2D. Contacts

Adding a New Contacts Entry

Your phone can store up to 600 Contacts entries. Contacts entries can store up to a total of 7 phone numbers, and each entry’s name can contain 64 characters.

1. From standby mode, touch > Contacts.

2. Touch > New Contact.

3. Touch Enter Name and enter the new contact

name using the touch keypad or QWERTY keyboard, and then touch .

4. Touch Add Number, enter a phone number, and

then touch .

5. Touch a phone label to select it (Mobile, Home,

Work, Pager, Fax, or Other).

6. Scroll down to additional fields and enter or edit

information as desired.

7. Touch .

fter saving the number, your phone display the

A Contacts list. (See “Contacts Entry Options” on page 53.)

Tip: ICE – In Case of Emergency

Save

New Entry

Existing Entry

Done

Contact

Details

Edit

To make it easier for emergency personnel to identify important contacts, you can list your local emergency contacts under “ICE” in your phone’s Contacts list. For example, if your mother is your primary emergency contact, list her as “ICE–Mom” in your Contacts. To list more than one emergency contact, use “ICE1–___,” “ICE2–___,” etc.

Saving a Phone Number

To save a number from standby mode:

1. Press to display the dial pad.

2. Enter a phone number.

3. Touch .

4. Touch for a new contact or

to add a number to an existing contact.

5. Touch a phone label to select it (Mobile, Home,

Work, Pager, Fax, and Other).

6. Touch Enter Name and enter the new contact

name using the touch keypad or QWERTY keyboard, and then touch .

– or –

Search an existing contact name and touch it to save the new number.

7. Touch to save the new entry.

Contacts

Contacts Entry Options

To display a Contacts entry:

1. From standby mode, touch > Contacts.

2. Touch an entry and then touch .

Contacts entry options:

Display an entry and touch on the top right of the screen.

Add Number to add a phone to the entry. Add Email to add an email address to the entry. Add URL to add a website’s URL to the entry. Default Ringer to assign a preprogrammed or

downloaded ringer.

Default Vibrate Type to assign a vibration type for

incoming calls from the contact.

2D. Contacts 53

Enter Address to add an address.

Edit

Done

Edit

Done

Pause

Done

Enter Birthday to add a birthday. Enter Memo to add a note, or other information. Enter Job Title to add a job title. Enter Company to add a company. No Secret/Secret to change to Secret to hide an

entry’s phone number(s).

Editing a Contacts Entry

1. Display a Contacts entry (see “Contacts Entry

Options” on page 53) and touch on the right top of the screen.

2. Highlight the information you wish to edit (Name,

Ringer, etc.).

3. Add or edit the information and touch (if

applicable).

4. Touch to save your changes.

54 2D. Contacts

Adding a Number to a Contacts Entry

1. Display a Contacts entry. (See “Contacts Entry

Options” on page 53.)

2. Touch on the top right of the screen and

then touch

3. Enter the new phone number and touch .

Note: To add a pause, touch and enter additional

4. Touch a label for the number.

5. Touch to save the new number.

Add Number.

numbers.

Editing a Contacts Entry’s Numbers

Edit

Done

1. Display a Contacts entry (see “Contacts Entry

Options” on page 53) and touch on the right top of the screen.

2. Touch a number.

3. Touch to clear one digit at a time, or touch and

hold to erase the entire number.

4. Re-enter or edit the number and touch .

5. Touch to save the number.

Assigning Speed Dial Numbers

Your phone can store up to 98 phone numbers in speed dial locations. (For details on how to make calls using speed dial numbers, see “Speed Dialing” on page 27.)

To assign a speed dial number to a new phone number:

1. Add a phone number to a new or to an existing

Contacts entry. (See “Adding a New Contacts Entry” on page 52 or “Adding a Number to a Contacts Entry” on page 54.)

2. Touch > Settings > Speed Numbers.

3. Touch an available speed dial location.

Note: To move to far below quickly, touch the scroll thumb tag

and drag to the desired location.

4. Select a phone number in the Contacts. (A

confirmation is displayed.)

To assign a speed dial number to an existing phone number:

1. From standby mode, touch > Contacts.

2. Touch > Settings > Speed Numbers.

3. Touch an available speed dial location.

Note: To move to far below, touch the scroll thumb tag and

drag to the desired location.

4. Select a phone number in the Contacts. (A

confirmation is displayed.)

To replace an already in-use speed dial location with a new phone number:

1. From standby mode, touch > Contacts.

2. Touch > Settings > Speed Numbers.

2D. Contacts 55

Contacts

Replace

Call

Edit

Done

Touch a speed dial location to replace.

Note: To move to far below quickly, touch the scroll thumb tag

and drag to the desired location.

4. Touch and select the new phone number.

(A confirmation is displayed.)

Note: To delete the speed dial number assigned, touch the

speed dial location and select Remove.

Finding Speed Dial Numbers

1. From standby mode, touch > Contacts.

2. Touch > Settings > Speed Numbers.

3. Scroll through speed dial entries. Speed dial

numbers are displayed in numeric order.

– or –

Enter the number of a speed dial location using your keypad.

4. To display an entry, touch it.

5. To dial the entry, touch .

56 2D. Contacts

Selecting a Ringer Type for an Entry

Assign a ringer type to a Contacts entry so you can identify the caller by the ringer type. (See “Ringer Types” on page 33.)

1. Display a Contacts entry (see “Contacts Entry

Options” on page 53) and touch on the right top of the screen.

2. Slide the screen up and touch the current ring type

to display the Ringer Type menu.

3. Select a ringer menu, such as Default Ringer,

Downloaded Ringers, Other Ringers, No Ringer, My Videos, Voice Memo, My Audio

4. Scroll through available ringers. (To hear a sample

ringer, touch .)

5. Touch a ringer to select it.

6. Touch to save the new ringer type.

or Assigned Media.

Assigning a Picture to an Entry

Edit

Done

Add New

Continue

Done

Creating a Group

Assign a picture to display each time a certain contact calls you.

1. Display a Contacts entry (see “Contacts Entry

Options” on page 53) and touch at the top right of the screen.

2. Touch an entry’s current image or placeholder to

display the Picture ID menu.

3. Select an option, such as No Image, Take New

Picture, My Photos, Downloaded Images, or Assigned Media.

4. Touch a picture and touch Assign to assign it.

If you selected Take New Picture, the camera will launch so that you can take a new picture. (See “2H. Camera” on page 82 for details.)

If you selected My Photos, you may need to select

In Phone or Memory Card to find the picture you

want to use.

5. Touch to save the assigned picture.

Create a group to send a message to the members of a group at a time. Created groups also will be shown in Contacts in alphabetical order.

1. From standby mode, touch > Contacts.

2. Touch and select New Group.

3. Touch each member to assign to the group. When

multiple phone numbers or email addresses are saved for a Contacts entry, touch the phone number or email address you wish to associate with that entry.

4. After selecting all members, touch .

5. Touch Enter Group Name to enter a name for the

new group, and then touch .

6. Touch .

2D. Contacts 57

Contacts

Finding Contacts Entries

Call

Contact

Details

Finding Contacts by Name

1. From standby mode, touch > Contacts.

2. Scroll through all the entries.

– or –

To quickly move up or down in the list alphabetically, touch and hold the thumb tab on the right side and drag to an initial letter.

– or –

Touch and enter the first letter or letters of a name (such as “dav” for “Dave”). (The more letters you enter, the more your search narrows.)

3. To display an entry, touch it.

4. To dial the entry’s default phone number,

touch .

– or –

To close the entry display, touch the entry again.

58 2D. Contacts

Finding Group Entries

1. From standby mode, touch > Contacts.

2. Scroll through the Contacts list. To display entries

belonging to a group, touch the group and then

Group Details.

Secret Contacts Entries

You can designate an entry as Secret and, if you choose, hide it from the Contacts list. When you set to hide secret contact entries, they will not be shown in the Contacts list.

To make an entry secret:

1. From standby mode, touch > Contacts.

2. Display a contact and then touch .

3. Slide the Secret switch to On.

4. Press to go back to Contacts list.

5. Touch > Settings > Hide Secret.

6. Enter the lock code to hide the contact entries set

as secret.

To make an hidden entries public:

Talk

411

Talk

211

Talk

311

Talk

511

Talk

611

Talk

711

Talk

811

Talk

1. On the Contacts list, touch > Settings >

Show Secret.

2. Enter the lock code. (The contact will reappear on

your contacts list.)

Dialing Sprint Services

Your Contacts list is preprogrammed with contact numbers for various Sprint services.

To dial a service from your Contacts:

1. From standby mode, touch > Contacts.

2. Touch > Settings > Services and select an

available service, such as

Customer Service, Dir Assistance (Sprint 411), Sprint Operator, Pay Bill, Voicemail, Community Information, Non-Emergency Svcs, Traffic Information, Carrier Service Repair, TRS for TTY Users, or Call Before You Dig.

To dial a service from standby mode using your dial pad:

1. Press to display the dial pad.

Account Info, Sprint

2. Dial the appropriate service number:

Account Info. –

Sprint Customer Service –

Dir Assistance (Sprint 411) –

Sprint Operator –

Pay Bill –

Voicemail –

Community Information –

Non-Emergency Svcs –

Traffic Information –

Carrier Service Repair –

TRS for TTY Users –

Call Before You Dig –

2D. Contacts 59

Contacts

Wireless Backup

Subcribe Now

This feature allows you to back up all of your contacts to the Sprint website and restore them if your phone is lost, stolen, damaged, or replaced.

Tip: To use the wireless backup service, you are required to

activate the service from your phone.

To subscribe to the wireless backup service, you must purchase a license to use the service through your phone. The license expires after a set period of time and you must renew it regularly. As part of the initial subscription process, the service generates a random wireless backup password. The service sends the password to your phone as a text message.

Activating and Deactivating Wireless Backup

To activate the wireless backup service:

1. Touch > Main Menu > (slide the screen up) >

Tools > Wireless Backup.

2. Touch and follow the onscreen

instructions to purchase the license.

60 2D. Contacts

3. Please wait while registering the license. (You will

see a confirmation screen once registration is complete.)

Note: Once you have completed the registration, you will

receive a text message with your password. This password is required for the Wireless Backup website (

www.wirelessbackup.sprint.com) in order to edit your

contacts from your computer.

Tip: Each time you edit contacts on your phone, they are

backed up at

www.wirelessbackup.sprint.com.

To deactivate the wireless backup service:

1. Touch > Main Menu > (slide the screen up) >

Tools > Wireless Backup > Unsubscribe. (A

message is displayed.)

2. Follow the onscreen instructions to unsubscribe

from the wireless backup service.

Note: You can unsubscribe from the wireless backup service

only through the Sprint website.

Viewing Your Wireless Backup Status

Done

Settings

Done

Touch > Main Menu > (slide the screen up) >

Tools > Wireless Backup > View Status.

Setting the Wireless Backup Alert

This feature turns the pop-up alert on or off when your contact info is backed up by wireless backup.

1. Touch > Main Menu > (slide the screen up) >

Tools > Wireless Backup > Alerts.

2. Select Alert me or No alerts.

Tip: To see more wireless backup information, touch >

Main Menu >

You can also select troubleshooting guide.

Tools > Wireless Backup > Learn More.

Troubleshooting to display the

Hello UI

Add your favorite contacts to groups that you can access quickly with a few keystrokes. You can create up to four groups with six members in each group.

Customizing Hello UI

1. From standby mode, press and touch .

2. Touch to add a contact.

3. Touch each contact you want to assign to the

group.

4. After making your selections, touch .

To change to a seasonal theme:

1. While in the Hello UI screen, touch at the

top right of the screen.

2. Slide the Theme button switch to On.

3. Touch .

2D. Contacts 61

Contacts

Hello UI Contacts Options:

Abc

Done

SYM

Touch a Contact on Hello UI.

Delete

Contact Details

Call

Message History

Send Message

Character

(touch to change)

Sending a Message to Selected Group Members

1. From standby mode, press and touch .

2. Using your finger, draw a line around the group

members you wish to include.

62 2D. Contacts

3. Touch the envelope icon (for example, -- the

number on the icon shows how many members were included).

4. Touch the text field to enter a message or use the

preset messages, symbols, smileys, or emoticons.

To type a message, use your keyboard or touch keypad to enter your message. (See “Entering Text” on page 28.)

To use a preset message, touch Preset Msgs in the upper right corner, and then touch a message to enter.

To enter a symbol, an emoticon, or a smiley:

● (On the touch keypad) touch and select

Symbols, Emoticons, or Smileys. Touch a desired symbol, emoticon, or smiley and

. (See “Entering Numbers, Symbols, Emoticons, Smileys and Preset Messages” on page 30.)

– or –

● (On the keyboard) press or , and

touch a desired symbol or emoticon. (See “Entering Text With the QWERTY Keyboard” on page 32.)

5. Touch Done.

Add Attachment

Send

6. To attach attachments, touch for the

available options.

7. Review your message and touch (You may

select additional messaging options by touching

to add subject, set the message priority

urgent, set the callback number, or save it as draft.

Note: If an attachment or subject is added to a text message,

the message type will change to Picture Message and you will be charged accordingly. (See “Sending Pictures and Videos From Messaging” on page 90.)

Contacts

2D. Contacts 63

Calendar (page 64)

2E. Calendar & Tools

Add New

End

Done

All Day

Save

File Manager (page 67)

Alarm Clock (page 68)

Notepad (page 69)

EZ Tips (page 70)

Calculator (page 71)

Stopwatch (page 71)

World Clock (page 71)

Unit Converter (page 72)

Updating Phone Software (page 72)

Updating the PRL (page 72)

64 2E. Calendar & Tools

Calendar

Adding an Event to the Calendar

Your Calendar helps organize your time and reminds you of important events.

1. Touch > Main Menu > (slide the screen up) >

Tools > Calendar.

2. Touch the day to which you would like to add an

event and touch . (The current day is the default.)

3. Touch Time to select a time for the event. Slide the

hour, minute, and AM/PM wheel up or down. Touch and then set the end time and touch

For an all-day event, touch .

4. Touch Content to enter a notes about the event.

Enter a note or memo and touch . (See “Entering Text” on page 28.)

5. Touch Related person to select contacts related to

the event.

After selecting related persons in the Contacts list

Done

Save

Done

Save

touch .

6. Touch Alarm to set an alarm time.

Select None, On time, 5 minutes, 10 minutes, 1 hour,

1 day, or 2 days and touch .

7. Touch Alarm Bell to select a ringer type.

Select a ringer menu and touch a ringer.

8. Touch Volume to select a ringer volume.

Touch the bar at the volume level you want and then touch .

9. Touch Vibration Type to select a vibration type.

Touch the desired vibration type and then touch

10. Touch Vibration Level to select a vibration level.

Touch the vibration bar at the level you want and then touch .

11. Touch Location to enter a location.

Enter the event location and touch . (See “Entering Text” on page 28.)

12. Touch Set Repeat to select a repeating status.

Select None, Daily, Mon - Fri, Select Days, Weekly,

Monthly, or Yearly and then touch .

13. Touch to save the event.

Event Alert Menu

When your phone is turned on and you have an event alarm scheduled, your phone alerts you and displays the event summary. There are several ways your phone can alert you to scheduled events:

By playing the assigned ringer type. By illuminating the backlight. By flashing the LED.

To silence the alarm and reset the schedule, unlock the screen (if necessary) and touch

To select additional options, Touch an option.

Snooze to silence the alarm and schedules it to

replay again in 10 minutes.

View to display the event detail screen.

Dismiss.

2E. Calendar & Tools 65

Calendar / Tools

Viewing Events

List

# Events

List

# Events

Delete

1. Touch > Main Menu > (slide the screen up) >

Tools > Calendar.

2. Touch the day for which you would like to view

events.

Tip: In the calendar view, days with events scheduled are

underlined.

3. Touch or . (Your phone lists events

in chronological order.)

4. Touch an event to list its details.

Going to the Current Day’s Calendar Menu

On the calendar, touch the “month, year” field and then touch

66 2E. Calendar & Tools

Go to Today.

Erasing a Day’s Events

1. Touch > Main Menu > (slide the screen up) >

Tools > Calendar.

2. Touch the day for which you would like to erase

events and then touch or .

Tip: In calendar view, days with events scheduled are

underlined.

3. Touch at the top right of the screen and

Delete Today.

select

4. Select Delete or Cancel.

Note: If the day for which you are erasing events contains a

repeating event, you will receive the following prompt: “There are some recurring events. Do you want to delete?” Select cancel the deletion of the repeating event.

Yes to erase a all occurrences or No to

Erasing Past Events

To delete events scheduled before a specific time and date:

1. Touch > Main Menu > (slide the screen up) >

Tools > Calendar > > Delete Old.

2. Select the option to erase events older than One

Delete

day, One week, One month, or One year. (You will

see a message informing you how many events were erased.)

Erasing All Events

1. Touch > Main Menu > (slide the screen up) >

Tools > Calendar > > Delete All. (You will see

an alert notifying you that all events will be erased.)

2. Select Delete to erase all events or Cancel to return

to the calendar view.

File Manager

File Manager allows you to manage files such as pictures, videos, music, and applications stored on the microSD™ card.

Accessing File Manager

Touch > Main Menu > (slide the screen up) >

Tools > Mass Storage > File Manager.

Opening Files in File Manager

1. Touch > Main Menu > (slide the screen up) >

Tools

> Mass Storage > File Manager.

2. Touch a folder.

3. Touch a file to open it, if the format is supported.

2E. Calendar & Tools 67

Calendar / Tools

File Manager Options

Save

Add New

When you open a folder, touch . The following options are available.

Create New Folder to create a new folder. Enter a new

folder name and touch . (See “Creating Folders in the microSD Card” on page 79.)

Send Multiple to send multiple files via Bluetooth or

email.

Move Multiple to move multiple files. Copy Multiple to copy multiple files. Search to search for a file. Assign to to select an image file to assign it as screen

saver or a picture ID, or to assign a music file as a ring tone.

Rename to change the name of a file. Rename Current Folder to change the name of the

current folder.

Delete Current Folder to delete the current folder. Delete Multiple to delete selected multiple files. Delete All to delete all files.

68 2E. Calendar & Tools

Folder Info to display information about the folder

such as folder name, location, the number of files, and the number of sub folders.

File Info to display information about the file you

select, such as file name, location, and the file size.

Note: Default folders cannot be deleted or renamed.

Alarm Clock

Your phone comes with a built-in alarm clock that has multiple alarm capabilities.

1. Touch > Main Menu > (slide the screen up) >

Tools > Clock > Alarm

2. Touch .

3. Slide the alarm switch to On.

4. Touch the time to set a time for the alarm.

Tough the digital clock (above the dial) to adjust the clock.

– or –

Touch and drag the hour and minute hands and

Done

Save

Add New

Save

then touch AM/PM to select a time, and then touch .

5. Touch Repeat to select a repetition type.

Touch Daily, Once, Weekly, Mon - Fri, or Sat & Sun.

6. Touch Sound/Vibration to select Always sound &

Vibrate, Always Sound, or Always Vibrate.

7. Touch Alarm Bell to select a ringer type.

Select a ringer menu and touch a ringer.

8. Touch Volume to select a ringer volume.

Touch the bar at the volume level you want and then touch .

9. Touch Vibration Type to select a vibration type.

Touch the desired vibration type.

10. Touch Vibration Level to select a vibration level.

Touch the vibration bar at the level you want and then touch .

11. Touch Snooze to select a snooze interval time.

Select Snooze 5mins, Snooze 10mins, Snooze

15mins, Snooze 20mins, or Snooze Off.

12. Touch to set the alarm.

Notepad

Your phone comes with a notepad that you can use to compose and store reminders and notes to help keep you organized.

To compose a note:

1. Touch > Main Menu > (slide the screen up) >

Tools > (slide the screen up) > Notepad > .

2. Enter your note using the touch keypad or

QWERTY keyboard and touch .

To read a saved note:

1. Touch > Main Menu > (slide the screen up) >

Tools > (slide the screen up) > Notepad.

2. Touch a note.

To delete a saved note:

1. Touch > Main Menu > (slide the screen up) >

Tools > (slide the screen up) > Notepad.

2. Touch a note.

2E. Calendar & Tools 69

Calendar / Tools

Delete

Touch (A confirmation will be displayed.)

4. Touch Delete.

Note: To delete multiple or all notes, touch at the top

right of the screen.

To view a document:

1. Touch > Main Menu > (slide the screen up) >

Tools > (slide the screen up) > Document Viewer.

2. Touch a document.

Document Viewer

You can view all various document types, such as: Word, PowerPoint, Excel and PDF. (Compatible file extensions are .doc, .docx, .ppt, .pptx, .xls, .xlsx, .pdf and .txt.)

To transfer document files:

1. Connect your phone and your computer using a

compatible USB cable. (See “Connecting Your Phone to Your Computer” on page 80.)

2. Select Connect To PC.

3. Read the disclaimer and touch Yes.

4. Drag and drop document files from your computer

into a folder.

5. When you are finished, disconnect the phone. (See

“To remove the connection:” on page 80.)

70 2E. Calendar & Tools

EZ Tips

1. Touch > Main Menu > (slide the screen up) >

Tools > (slide the screen up) > Calculator > Ez Tip Calculator.

2. Touch the Total Bill field and enter the amount of

the total bill.

3. Touch the Tip field and enter a tip percentage.

(EZ Tip instantly calculates the correct tip.)

4. If you’re splitting the check, touch the Split field,

and enter the number of people in your party. (EZ Tip calculates and displays the ‘per person’ amount.)

Calculator

( )

Start

Lap

Stop

New City

list

◀

▶

select

Stopwatch

Your phone comes with a built-in calculator.

1. Touch > Main Menu > (slide the screen up) >

Tools > (slide the screen up) > Calculator > Calculator.

2. Enter numbers using your keypad.

Touch to enter decimal points. Touch to change the value from positive to

negative. After entering a negative number, touch

Touch to clear all numbers.

3. Touch for the total.

Your phone comes with a built-in stopwatch.

1. Touch > Main Menu > (slide the screen up) >

Tools > Clock > Stopwatch.

2. Touch to start stopwatch time.

While measuring time, touch to view lap times.

Touch to stop the stopwatch.

World Clock

To view the time in over 50 different locations:

1. Touch > Main Menu > (slide the screen up) >

Tools > Clock > World Clock.

2. Touch to display the map.

Note: You can search a city from the cities list. Touch ,

touch the search field and enter the city name.

3. Touch or to scroll through continents and

touch to select the continent. (Cities in the continent will be displayed.)

2E. Calendar & Tools 71

Calendar / Tools

◀

▶

select

Touch or to scroll through cities and touch

– or –

Touch and drag the map to find a city, and touch

Unit Converter

1. Touch > Main Menu > (slide the screen up) >

Tools > (slide the screen up) > Calculator > Unit Converter.

2. Select Length, Area, Mass, Volume, Temperature, or

Velocity.

3. Select the known unit type and enter the value. The

conversion is displayed automatically.

Tip: While converting temperatures, touch the +/- key on the

touch keypad to input negative temperatures.

72 2E. Calendar & Tools

Updating Phone Software

The update phone option allows you to download and update the software in your phone automatically. Only the internal software is updated; no Contacts entries or other information saved to your phone will be deleted.

1. Touch > Main Menu > (slide the screen up) >

Tools > Update Phone > Update Firmware.

2. Follow the onscreen instructions.

Updating the PRL

This option allows you to download and update the PRL (preferred roaming list) automatically.

1. Touch > Main Menu > (slide the screen up) >

Tools > Update Phone > Update PRL.

2. Follow the onscreen instructions.

Automatic Speech Recognition (ASR) (page 73)

2F. Voice Services

Managing Voice Memos (page 75)

Automatic Speech Recognition (ASR)

You can use your phone’s built-in automatic speech recognition (ASR) software to dial a phone number in your Contacts or to launch phone functions. All you have to do is to talk into the phone, and ASR will recognize your voice and complete tasks by itself.

Activating ASR

From the standby screen, press and hold .

The screen displays seven voice command options and the phone prompts you to say the name of the command you want to use. To complete your task, simply follow the voice prompts.

Available ASR commands include:

Call [Name] [Type] / [Number] to call an entry in your

Contacts list or a spoken phone number. (See “Making a Voice Call With ASR” on page 74.)

Send Msg to [Name] [Type] / [Number] to send a

message to an entry in your Contacts list or to a spoken phone number.

Find [Name] [Type] to find a Contact entry. Go to [Menu] to jump directly to menu items or

applications. (See “Opening Menus With ASR” on page 74.)

Check [Item] to check your phone’s status. (See

“Checking Phone Status Using ASR” on page 74.)

Tip: Use ASR in a quiet environment so it can accurately

recognize your commands.

2F. Voice Services 73

Voice Services

Making a Voice Call With ASR

1. Press and hold .

2. After you hear “Please say a command”, say “Call”.

3. When you hear “Please say name & phone type or

say number” say a name and phone type or a phone number.

4. Your request will be repeated and you will be

asked to verify. Say “ person. (The number will automatically be dialed.)

No” if you wish to cancel.

Say “

Tip: You can skip step 3 saying a name and location after

“Call” without pausing (for example, “

mobile

”).

Note: If ASR does not recognize the name or number, it will

find the most likely matches and display a list of up to four names or numbers. You will hear “Did you say…” followed by the name or number. You can confirm by

Yes.” Say “No” to skip to the next match.

saying “

74 2F. Voice Services

Yes” to call the number or

Call John Jones

Opening Menus With ASR

You can jump directly to some of the menu items or applications by saying “Go to” followed by a menu option.

1. Press and hold .

2. If you hear “Please say a command,” say “Go To.”

3. If you hear “Please choose,” say an application

name (for example, “Messaging”).

4. The phone opens the selected menu.

Checking Phone Status Using ASR

You can use ASR to obtain information about your phone:

Phone Status Time Signal Strength Battery

1. Press and hold .

Record

Stop

2. Say “Check” after you hear “Please” say a

command.”

3. Say one of the options (above) when prompted.

Voice Command Training

You can train ASR for better voice command recognition.

1. Press and hold .

2. Touch Voice command Training.

Digit to train numbers. Yes/No to train word-based commands. Cancel to cancel and return to the Voice

Command menu.

Managing Voice Memos

Use your phone’s Voice Services to record brief memos to remind you of important events, phone numbers, or grocery list items.

Recording Voice Memos

1. Touch > Main Menu > (slide the screen up) >

Tools > Voice Service > Voice Memo > .

2. Begin recording after the prompt.

To end the recording of your memo:

Touch .

To record a conversation during a phone call:

During a call, touch > Voice Memo. (A minute counter is displayed on the left top of the screen to indicate the amount of time recorded.)

To end the recording of your conversation:

Touch > Stop Voice Memo to end the recording prior to the countdown completion.

2F. Voice Services 75

Voice Services

Note: Your phone can store 30 voice memos with up to a

Delete

total of 10 minutes for all memos.

Voice Memo Options

To play the voice memos you have recorded:

1. Touch > Main Menu > (slide the screen up) >

Tools > Voice Service > Voice Memo.

2. Touch the voice memo you wish to hear.

To choose voice memo options:

1. Touch > Main Menu > (slide the screen up) >

Tools > Voice Service > Voice Memo.

2. Find a voice memo and touch to choose from

the voice memo options:

Send Message to send a message with the voice

memo attached.

Set As to assign as a ringer to Contacts with Default Ringer, One Contact, Unsaved Numbers, Private/Unknown, Voicemail, Messages, or Alarm/ Calendar.

View Details to view the selected voice memo

information.

76 2F. Voice Services

Edit Title to edit the selected voice memo title. Memory Info to view the memory status for voice

memo. The total memory for voice memo is 10 minutes.

Cancel to close the options menu.

Erasing Voice Memos

To delete voice memos:

1. Touch > Main Menu > (slide the screen up) >

Tools > Voice Service > Voice Memo.

2. Touch at the top right of the screen and

select Delete Multiple or Delete All.

Delete Multiple to delete more than one selected

memo at a time.

Delete All to delete all voice memos.

Your Phone’s microSD Card and Adapter (page 77)

2G. microSD Card

microSD Card Settings (page 79)

microSD Card Folders (page 80)

Connecting Your Phone to Your Computer (page 80)

Your Phone’s microSD Card and Adapter

The microSD Card

Your phone is able to use a microSD™ (Secure Digital) memory card to expand the phone’s available memory space. It allows you to store more images, videos, music, and other files in your phone. A 1GB microSD card is supplied with your phone.

Inserting the microSD Card

1. Open the microSD access panel located on the

right side of the phone.

2. Position the microSD card facing up and gently

slide it into place until it is fully inserted and locked.

Note: Be sure to use only recommended microSD cards

(32MB–16GB). Using non-recommended microSD cards could cause data loss and damage your phone.

2G. microSD Card 77

microSD Card

Removing the microSD Card

1. Open the microSD access panel located on the

right side of the phone.

2. Push in to release the microSD card.

3. Pull the microSD card out of the microSD card slot.

Note: You can easily damage the microSD card and its

adapter by improper operation. Please be careful when inserting, removing, or handling them.

DO NOT remove a microSD card while files are being

accessed or transferred. Doing so can result in loss or damage of data.

Make sure your battery is fully charged before using the microSD card. Your data may become damaged or unusable if the battery runs out while using the microSD card.

microSD Adapter

The supplied microSD adapter allows you to use microSD cards in other SD-compatible devices, like computers, cameras, and printers. Before using the microSD card with an SD-compatible device, you will

78 2G. microSD Card

need to insert the microSD card into the microSD adapter.

To insert the microSD card into the microSD adapter:

With the label side of the microSD card facing up, insert the card into the supplied microSD adapter, and gently slide the card until it is fully inserted.

To remove the microSD card from the microSD adapter:

Hold the front edge of the microSD card, and gently pull it out to remove it from the adapter.

Write Protection

The microSDmicroSD adapter has a built-in Write Protection lock to prevent accidental overwriting or removal of your data when the microSD card and adapter are inserted in another device.

Slide the Write Protection lock tab down into the “Lock” position to prevent overwriting of data. To allow data to be added or removed from the microSDmicroSDmicroSD card, slide the Write Protection lock tab up into the normal position.

microSD Card Settings

Creating Folders in the microSD Card

The following steps allow your phone to create default folders for storing files in your microSD card.

1. With the microSD card inserted, touch > Main

Menu > (slide the screen up) > Tools > Mass Storage > File Manager.

2. Touch and select Create New Folder. (The

phone will automatically create the microSD’s default folders: DCIM, MUSIC, EMAIL, BLUETOOTH, SOUND.)

Viewing Memory in the microSD Card

With the microSD card inserted, touch > Main

Menu > (slide the screen up) > Tools > Mass Storage > Memory Info. (The used and available

memory space will be displayed.)

Formatting the microSD Card

Formatting a microSD card permanently removes all files stored on the card.

1. With the microSD card inserted, touch > Main

Menu > (slide the screen up) > Tools > Mass Storage > Format Memory Card. (A warning will be

displayed.)

2. If you are sure you wish to remove all the files from

your microSD card, touch

Note: The formatting procedure erases all the data on the

microSD card, after which the files CANNOT be retrieved. To prevent the loss of important data, please check the contents before you format the card.

Yes.

2G. microSD Card 79

microSD Card

microSD Card Folders

Displaying Your microSD Card Folders

Compatible files stored in your microSD are accessible through your microSD card folders.

1. With the microSD card inserted, touch > Main

Menu > Tools > Mass Storage > File Manager.

2. Touch a folder (for example DCIM, MUSIC, EMAIL,

BLUETOOTH, or SOUND).

3. To view or play a file, touch it or the appropriate

touch key.

Note: For information on file and folder options available

through File Manager, see “File Manager” on page 67.

80 2G. microSD Card

Connecting Your Phone to Your Computer

Before using your phone’s mass storage capabilities, you need to prepare your phone’s settings to synchronize with your desktop or laptop computer. Once you have connected the phone to the computer, you can transfer your data to or from the microSD card.

1. With the microSD card inserted, connect your

phone to your computer using a compatible USB cable.

2. The USB Connection menu should open

automatically; select doesn’t open, then touch the screen up)

PC.

3. Read the notice and touch Yes.

To remove the connection:

When you have finished transferring data, press

and touch device is disconnected, it is safe to remove the USB cable.

Connect to PC. If the menu

> Main Menu > (slide

> Tools > Mass Storage > Connect to

Yes. After the message that your

Important Connection Information

No driver installation is required for Windows 2000/ ME/XP/Vista/7 users.

To avoid loss of data, DO NOT remove the USB cable, the microSD card, or the battery while files are being accessed or transferred.

DO NOT use your computer to change or edit folder or file names on the microSD card, and do not attempt to transfer large amounts of data from the computer to the microSD card. Doing so may cause the microSD card to fail.

DO NOT turn off or restart your computer, or put it into standby mode, while using a mass storage device. Doing so will result in loss or damage of data.

While you are connected to the computer, your phone’s screen will display “Phone Off.” You cannot make or receive calls.

If you connect a mass storage device to a peripheral device, your device may not work properly.

microSD Card

2G. microSD Card 81

Taking Pictures (page 82)

2H. Camera

CAPTURE

Take New Picture

Recording Videos (page 85)

Storing Pictures and Videos (page 87)

Sending Sprint Picture Mail (page 89)

Printing Pictures From Your Phone (page 91)

Taking Pictures

Taking pictures with your phone’s built-in camera is as simple as choosing a subject, pointing the lens, and pressing a button.

1. Touch > Main Menu > Photos & Videos >

Camera to activate camera mode. (Additional

camera options are available through the camera mode options menu. See “Camera Mode Options” on page 83 for more information.)

82 2H. Camera

Shortcut: To activate camera mode, you can also press the

side camera button ( ) twice, or press and

hold the side camera button ( ). (See

illustration on page 11.)

2. Using the phone’s display screen as a viewfinder,

aim the camera lens at your subject.

3. Touch or press the side camera button

until the shutter sounds. (Your phone automatically saves the picture to the default storage area.)

To return to camera mode to take another picture, touch , or the side camera button.

4. Touch for more options:

Send to send your picture in a message. (See

page 89 for details.)

Assign to assign the picture as a:

● Screen Saver to use the picture as a screen

saver.

● Picture ID to display the picture for all

incoming calls.

Delete to delete the picture you just took.

Go to Album to go to the In Phone folder or

Memory Card folder (if available) to review your saved pictures.

Print to print the pictures. Use a PictBridge-

enabled printer (see page 91), or use a Bluetooth-enabled printer (see page 92).

Take New Picture to return to camera mode to take

another picture.

Assigning Pictures

After taking a picture, assign it as a screen saver or as a picture ID for a Contacts entry.

1. Take a picture. (See steps 1–3 on page 82.)

2. With the picture displayed, touch > Assign,

and select an option.

Screen Saver to assign the picture as a screen

saver. (If the size of the picture is larger than screen, you are required to select between

Screen and Select Area.) Picture ID to assign the picture as a Picture ID to a

Contacts entry:

Fit to

● Contacts with No Picture to assign the picture

to all contacts that don’t already have an assigned picture ID

● One Contact to assign the picture to a

particular contact

● Private/Unknown Numbers to assign the

picture to incoming calls from restricted or private numbers.

● Unsaved Numbers to assign the picture for

incoming calls from unsaved numbers.

Follow the prompts to assign the picture IDs.

Tip: You can also assign pictures from the My Photos &

Videos menu. See “In Phone Folder and microSD Card Options” on page 88.

Camera Mode Options

In camera mode, touch to display additional camera options:

Color Tone to adjust the color tone. Select Normal, Black & White, Negative, or Sepia. (The default setting

Normal.)

Image Controls to select from the following options:

Brightness to select Auto or Manual brightness

control. If you select

Manual brightness, move the

2H. Camera 83

Camera

scroll bar up (increase) or down (decrease) to

START

CANCEL

select a setting.

White Balance to adjust white balance based on

changing conditions. Select from

Fluorescent, Sunny, Cloudy, or Manual. If you

Manual, move the scroll bar left (decrease)

select

Auto, Tungsten,

or right (increase).

Fun Frames to take a picture in a fun frame. Touch a

frame style at the bottom of the screen to see how it will look full-screen; drag the screen left or right to see the next or previous frame.

Settings to select Resolution, Quality, Shutter Sound, Status Bar, or Night Mode. (See “Camera Settings” on

page 85 for details.)

Self Timer to activate the camera’s timer. (See “Self

timer” below.)

Enable Auto-Send to set the phone automatically to

send the picture to the selected place.

Zoom to zoom in on a subject. (Not available at the

highest resolution, see “Zoom” on page 85.)

Go to Album to go to the In Phone folder or Memory

Card folder (if available) to review your saved pictures.

84 2H. Camera

Camcorder Mode to switch to video mode. (See

“Recording Videos” on page 85.)

Self timer

1. From Camera mode, touch > Self Timer.

- or -

From Camera mode, touch .

2. Touch the length of delay you want the timer to use

Off, 5 seconds, or 10 seconds).

(

3. Touch when you are ready to start the

timer. (A countdown is displayed in the middle of the screen.)

To cancel the Self-timer after it has started:

Touch .

Note: While the Self-timer is active, some of the touch keys

are disabled.

Zoom

CAPTURE

This feature allows you to zoom in on an object when you take a picture. Depending on your resolution settings, you can adjust the zoom from 1× to 15×.

1. From camera mode, touch > Zoom.

2. Move the gauge bar left (zoom out) or right (zoom

in).

3. Touch , or press the side camera button

to take the picture. (Your phone automatically saves the picture in your default storage area.)

Note: Zoom is not supported when the Resolution setting is

2M(1600 x 1200).

Camera Settings

1. From camera mode, touch > Settings.

2. Touch an option

Resolution to select a picture’s file size (2M

[1600×1200], High [1280 x 960], Med [640 x 480],

Low [320 x 240]).

Quality to select the picture quality setting (Fine, Normal, or Economy).

Shutter Sound to select a shutter sound (Shutter, Say Cheese, Ready 123, Smile, or Off).

Status Bar to show or hide the status bar (On or Off).

Night Mode to toggle the low-light setting (On or Off).

Recording Videos

In addition to taking pictures, you can record, view, and send videos with your phone’s built-in video camera.

1. Touch > Main Menu > Photos & Videos >

Camcorder to activate video mode. (Additional

video options are available through the video mode options menu. See “Video Mode Options” on page 86.)

2. Select Video Mail or Long Video.

Note: Video Mail can be at most 30 seconds in length or

600KB in size, otherwise, they cannot be uploaded, sent, or posted. but the length of a Long Video is dependent on both the quality settings and storage type used (phone or memory card).

2H. Camera 85

Camera

RECORD

PAUSE

RESUME

Done

Send

Using the phone’s display screen as a viewfinder, aim the camera lens at your subject.

4. Touch , or press the side camera button.

To pause and then resume the recording, press touch or .

5. Touch , or press the side camera button to

stop recording. (Your phone automatically saves the video in your default storage area.)

6. Touch for more options:

(only for Video Mail videos) to send the video. (See page 87 for details.)

Play to play the video that was just recorded. Assign to assign the video as a ringer. Take New Video to return to camcorder mode. Delete to delete the video that was just recorded. Review My Videos to go to the In Phone folder or

Memory Card folder (if available) to review your saved videos.

Cancel to close the options menu.

86 2H. Camera

Video Mode Options

In camcorder mode, touch to display additional camera options:

Color Tone to adjust the color tone from Normal, Black & White, Negative, and Sepia. (The default setting is Normal.)

Image Controls to select from the following options:

Brightness to select Auto or Manual brightness

control. If you select up (increase) or down (decrease) to select a setting.

White Balance to adjust white balance based on

the different lighting conditions. Select from

Tungsten, Fluorescent, Sunny, Cloudy, or Manual (10

levels).

Settings to select Resolution, Quality, Cue Sound, Status Bar, or Video Length. (See “Video Settings” on

page 87 for details.)

Self Timer to activate the camcorder’s timer. (See

“Self timer” on page 84.)

Enable Auto-Send to set the phone automatically to

send the video to a selected place.

Manual, move the scroll bar

Auto,

Zoom to zoom in on a subject. (See “Zoom” on

page 85.)

Go to Album to go to the In Phone folder or Memory

Card folder (if available) to review your saved videos.

Camera Mode to switch to camera mode. (See

“Taking Pictures” on page 82.)

Video Settings

1. From camcorder mode, touch > Settings.

2. Touch an option.

Resolution to select a video’s file size (QVGA [320

Med [174 x 144], or Low [128 x 96]).

x 240],

Quality to select the video quality setting (Fine, Normal, or Economy).

Cue Sound to select a cue sound (Cue 1, Cue 2, Cue 3, or Off).

Status Bar to show or hide the status bar (On or Off).

Video Length to select a video length (Video Mail

Long Video).

Storing Pictures and Videos

Your phone’s picture and video storage area is

My Photos & Videos. There are two folders in My

called

Photos & Videos:

In Phone Memory Card

Storage Options

1. Touch > Main Menu > Photos & Videos > Other

Settings > Auto-Save to.

2. Select Memory Card or In Phone.

(The phone stores pictures to the In Phone folder if no microSD card is installed.)

2H. Camera 87

Camera

In Phone Folder

Your phone’s internal storage area is called the In

Phone folder. From the In Phone folder, you can view all

the pictures and videos you have stored there, delete files, and access additional options.

To review your stored pictures and videos in the In Phone folder:

1. Touch > Main Menu > Photos & Videos > My

Photos & Videos > In Phone.

2. Scroll through the pictures and videos and touch a

picture or video to view it.

microSD Picture and Video Folders

You can save pictures and videos directly to the microSD card using your phone’s pictures and videos settings. You c 1,000 pictures in each folder on the microSD card.

To review your stored pictures and videos on the microSD card:

1. Touch > Main Menu > Photos & Videos > My

Photos & Videos > Memory Card.

88 2H. Camera

an store and manage a maximum of

2. Scroll through the pictures and videos and touch a

picture or video to view it.

In Phone Folder and microSD Card Options

After you open a picture or video in the In Phone folder or the Memory Card folder, touch to display the following options:

Select Multiple/ Select Single to select multiple or

single pictures or videos to delete, print (.JPG format pictures), copy, or move.

Thumbnail to display pictures in thumbnail view. Play to play a selected video. Slide Show to view your pictures in slideshow mode. Assign to assign the picture as a screen saver or

picture ID, or the video as a ringer.

Delete to delete the picture or video.

Note: Deleting pictures will free up memory space in your

phone to enable you to take more pictures.

Print to print selected pictures. You can use a

PictBridge-enabled printer (see page 91) or a Bluetooth-enabled printer (see page 92).

LG LGLN510 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
